i The vehicle is equipped with full-time four-wheel drive. Both the front and rear axles are powered at all times when the vehicle is being operated.

Controls in detail Transfer case

199

Controls in detail Good visibility

For information on the windshield wipers, see “Windshield wipers” (컄 page 60).

Headlamp cleaning system*

The button is located on the left side of the dashboard.

1 Headlamp washer button

200

왘 Switch on the ignition (컄 page 40). 왘 Press button 1.

The headlamps are cleaned with a high-pressure water jet.

i The headlamps will automatically be cleaned when you have 앫 switched on the headlamps

and

앫 operated the windshield wipers with wind-

shield washer fluid fifteen times

When you switch off the ignition, the counter resets.

For information on filling up the washer reservoir, see “Windshield/rear window washer system and headlamp cleaning system*” (컄 page 363).

Rear view mirrors

For more information on setting the rear view mirrors, see “Mirrors” (컄 page 49).

Interior rear view mirror, antiglare position

1 Lever 왘 Tilt the mirror to the antiglare position by moving lever 1 towards the wind- shield. The interior rear view mirror is dimmed.

Controls in detail Good visibility

Auto-dimming rear view mirrors* The reflection brightness of the exterior rear view mirror on the driver’s side and the interior rear view mirror will respond automatically to glare when 앫 the ignition is switched on

and

앫 incoming light from headlamps falls on

the sensor in the interior rear view mirror

The rear view mirror will not react if 앫 the automatic transmission is set to

position R

앫 the interior lighting is turned on

Warning!

The auto-dimming function does not react if incoming light is not aimed directly at sen- sors in the interior rear view mirror.

The interior rear view mirror and the exterior rear view mirror on the driver’s side do not react, for example, when transporting cargo which covers the rear window.

Light hitting the mirror(s) at certain angles (incident light) could blind you. As a result, you may not be able to observe traffic con- ditions and could cause an accident.

Warning!

In case of an accident, liquid electrolyte may escape from the mirror housing if the mirror glass breaks.

Electrolyte has an irritating effect. Do not allow the liquid to come into contact with eyes, skin, clothing, or respiratory system. In case it does, immediately flush affected area with water, and seek medical help if necessary.

! Electrolyte liquid coming into contact with the vehicle paint finish can be completely removed only while in the liquid state and by applying plenty of water.

Warning!

Exercise care when using the passen- ger-side exterior rear view mirror. The mirror surface is convex (outwardly curved surface for a wider field of view). Objects in mirror are closer than they appear. Check your interior rear view mirror or glance over your shoulder before changing lanes.

201

Controls in detail Good visibility

Power folding exterior rear view mirrors*

! Before you drive the vehicle through an automatic car wash, fold the exterior rear view mirrors in. Otherwise they may get damaged.

Folding the exterior rear view mirrors in and out automatically When the corresponding function in the control system is activated (컄 page 178): 앫 The exterior rear view mirrors automat- ically fold in as soon as the vehicle is locked from the outside.

앫 The exterior rear view mirrors automat- ically fold out as soon as the vehicle is unlocked and the driver’s or front pas- senger door are subsequently opened.

Synchronizing exterior rear view mirrors The power folding rear view mirrors may have to be synchronized after the vehicle battery has been disconnected or dis- charged. If the exterior rear view mirrors do not fold properly upon locking or un- locking the vehicle although the corre- sponding function in the control system is activated (컄 page 178), do the following: 왘 Fold each exterior rear view mirror in

completely (컄 page 203).

왘 Fold each exterior rear view mirror out

completely (컄 page 203).

When the exterior rear view mirrors fold properly upon locking the vehicle, the exte- rior mirrors are synchronized. Otherwise repeat the above steps.

Folding the exterior rear view mirrors in and out manually

i The exterior rear view mirrors can vibrate if they are not folded out completely.

The button is located on the door control panel.

1 Button for folding exterior rear view

mirrors in and out

왘 Switch on the ignition (컄 page 40).

202

Controls in detail Good visibility

Folding in 왘 Briefly press button 1.

Both exterior rear view mirrors fold in.

Sun visors

The sun visors protect you from sun glare while driving.

i If you are driving at more than approximately 30 mph (47 km/h), you will not be able to fold the exterior mirrors in.

Warning!

Do not use the vanity mirror while driving.

Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others.

1 Sun visor 2 Additional sun visor* 3 Mirror lamp 4 Vanity mirror cover 5 Vanity mirror 6 Holder for gas cards 7 Mounting

Folding out 왘 Briefly press button 1 again.

Both exterior rear view mirrors fold out.

! If an exterior rear view mirror housing is forcibly pushed forward (hit from the rear) or forcibly pushed rearward (hit from the front) press button 1 to fold mirrors in, then press button 1 again to fold mirrors out. Do not force mirrors by hand as this may damage the adjust- ment mechanism. The mirror housing is then properly positioned and you can adjust the mirror in the usual manner. Please make sure both rear view mirrors are folded out before driving off.

203

! To avoid damage to vanity mirror cover 4 (컄 page 203), make sure it is closed before pivoting sun visor 1 to the side. 왘 Adjust sun visor 1 by pushing or pull-

ing in the direction of arrows.

왘 Swing down additional sun visor* 2 when you experience additional glare through the windshield.

Controls in detail Good visibility

Glare through the windshield 왘 Swing sun visor 1 down. 왘 Make sure sun visor 1 is properly en-

gaged in mounting 7.

왘 When you do not experience glare any-

more, swing sun visor 1 up.

Vanity mirror 왘 Swing sun visor 1 down. 왘 Flip up cover 4 to access vanity

mirror 5. Vanity mirror lamp 3 comes on.

왘 After using vanity mirror 5, flip down

cover 4.

왘 Swing sun visor 1 up.

Glare through a side window

1 Sun visor 2 Additional sun visor* 왘 Swing sun visor 1 down. 왘 Disengage sun visor 1 from

mounting 7 (컄 page 203).

왘 Pivot sun visor 1 to the side.

204

Rear window defroster

The rear window defroster uses a large amount of power. To keep battery drain to a minimum, switch off the defroster as soon as the rear window is clear. The de- froster is automatically deactivated after approximately 6 to 17 minutes of operation depending on the outside tem- perature.

Activating 왘 Press button 1 on the climate con- trol panel (컄 page 208) or the automat- ic climate control* panel (컄 page 222). The indicator lamp on the button comes on.

Deactivating 왘 Press button 1 once more.

Warning!

The indicator lamp on the button goes out.

Any accumulation of snow and ice should be removed from the rear window before driv- ing. Visibility could otherwise be impaired, endangering you and others.

왘 Switch on the ignition (컄 page 40).

! If the rear window defroster switches off too soon and the indicator lamp starts flashing, too many electrical consumers are operating simul- taneously and there is insufficient voltage in the battery. The system responds automatically by switching the rear window defroster off. As soon as the battery has sufficient voltage, the rear window defroster switches back on auto- matically.

Controls in detail Good visibility

205

Controls in detail Climate control

206

Controls in detail Climate control

i For draft-free ventilation, move the sliders for center air vents and side air vents to the middle position.

1 Driver’s door air vent, fixed 2 Left side air vent, adjustable 3 Thumbwheel for air volume control

for left side and door air vent

4 Thumbwheel for air volume control

for left center air vent

5 Left center air vent, adjustable 6 Right center air vent, adjustable 7 Thumbwheel for air volume control

for right center air vent

8 Thumbwheel for air volume control

for right side and door air vent 9 Right side air vent, adjustable a Front passenger door air vent, fixed b Climate control panel

207

Controls in detail Climate control

208

1 Temperature control, left 2 Air distribution and air volume

(automatic, manual)

3 Front defroster 0 USA only P Canada only

4 Increasing air volume 5 Air distribution (directs air through

the windshield and side air vents)

6 Rear climate control* on/off Air supply for rear passenger compartment on/off : USA only < Canada only

7 Temperature control, right

8 AC cooling on/off

Residual heat/ventilation

9 Air distribution (directs air through

center and side air vents)

a Air distribution (directs air through

the footwells and side air vents)

b Air volume display c Decreasing air volume d Rear window defroster

1 USA only F Canada only

e Air recirculation f Interior temperature sensor g Climate control on/off

The climate control is operational whenev- er the engine is running. You can operate the climate control system in either the automatic or manual mode. The system cools or heats the interior depending on the selected interior temperature and the current outside temperature.

Nearly all dust particles, pollutants and odors are filtered out before outside air en- ters the passenger compartment through the air distribution system. The air conditioning will not engage (no cooling) if the A/C mode is deactivated (컄 page 216).

Warning!

Warning!

Follow the recommended settings for heat- ing and cooling given on the following pag- es. Otherwise the windows could fog up, impairing visibility and endangering you and others.

When operating the climate control, the air that enters the passenger compartment through the air vents can be very hot or very cold (depending on the set temperature). This may cause burns or frostbite to unpro- tected skin in the immediate area of the air vents.

Always keep sufficient distance between un- protected parts of the body and the air vents. If necessary, use the air distribution controls (컄 page 208) to direct the air to air vents in the vehicle interior that are not in the immediate area of unprotected skin.

Controls in detail Climate control

i Severe conditions (e.g. strong air pollution) may require replacement of the filter before its scheduled interval. A clogged filter will reduce the air volume to the interior. If the vehicle interior is hot, ventilate the interior before driving off, see “Summer opening fea- ture” (컄 page 239). The climate control will then adjust the interior temperature to the set value much faster. Keep the air intake grille in front of the wind- shield free of snow and debris.

209

Controls in detail Climate control

Deactivating the climate control system

Warning!

When the climate control system is switched off, the outside air supply and cir- culation are also switched off. Only choose this settings for a short time. Otherwise the windows could fog up, impairing visibility and endangering you and others.

Deactivating 왘 Press button ´ (컄 page 208). The indicator lamp on the button comes on.

Reactivating 왘 Press button U (컄 page 208).

i You can also press button ´ (컄 page 208) on the climate control panel. If you press button 0 (컄 page 208) to reactivate the climate control system, the defrosting mode is activated.

Operating the climate control system in automatic mode

i When operating the climate control system in automatic mode, you will only rarely need to adjust the temperature, air volume and air distri- bution. In automatic mode, cooling with dehumidify is switched on. This function can be switched off if necessary (컄 page 216).

Activating 왘 Press button U (컄 page 208) while

the engine is running. The indicator lamp on the button comes on. The air volume and air distri- bution are adjusted automatically.

왘 Use temperature controls 1 and 7 (컄 page 208) to separately adjust the air temperature on each side of the passenger compartment. The interior air temperature is adjusted automatically.

i The settings for the passenger side are also used for the rear passenger compartment.

210

Setting the temperature

Use temperature controls 1 and 7 (컄 page 208) to separately adjust the air temperature on each side of the passenger compartment. You should raise or lower the temperature setting in small incre- ments, preferably starting at 72°F (22°C). The climate control will adjust to the set temperature as fast as possible.

Deactivating 왘 Press button ˜ or Q

(컄 page 208). The indicator lamp on button U goes out. The automatic operation of air volume switches off. The selected blower speed is shown in the air volume display b (컄 page 208).

or 왘 Press air distribution button 5, 9,

or a (컄 page 208). The indicator lamp on button U goes out. The automatic operation of air distribution switches off.

Controls in detail Climate control

Increasing 왘 Turn temperature control 1

and/or 7 (컄 page 208) slightly clock- wise. The climate control system will corre- spondingly adjust the interior air tem- perature.

Decreasing 왘 Turn temperature control 1

and/or 7 (컄 page 208) slightly coun- terclockwise. The climate control system will corre- spondingly adjust the interior air tem- perature.

211

Controls in detail Climate control

Adjusting air distribution

Adjusting air volume

Press air distribution button 5, 9, or a (컄 page 208) to adjust the air distribution. The following symbols are found on the controls:

Symbol Function a Directs air through the center

and side air vents

Z Directs air to the windshield

and side air vents

Y Directs air to the footwells and

side air vents

왘 Press the desired air distribution

button 5, 9, or a (컄 page 208). The indicator lamp on button U goes out.

Five blower speeds are available. 왘 Press button ˜ to decrease or button Q to increase air volume (컄 page 208) to the desired level. The indicator lamp on button U (컄 page 208) goes out. The automatic operation of air volume switches off. The selected blower speed is shown in the air volume display b (컄 page 208).

Adjusting air volume for the center and side air vents

Opening the center air vents 왘 Turn thumbwheels 4 and 7

(컄 page 206) to the right. The corresponding center air vents on the left and right are open.

Closing the center air vents 왘 Turn thumbwheels 4 and 7

(컄 page 206) to the left. The corresponding center air vents on the left and right are closed.

Opening the side air vents 왘 Turn thumbwheels 3 and 8

(컄 page 206) to the right. The corresponding side air vents on the left and right are open.

Closing the side air vents 왘 Turn thumbwheels 3 and 8

(컄 page 206) to the left. The corresponding side air vents on the left and right are closed.

212

Front defroster

You can use this setting to defrost the windshield, for example if it is iced up. You can also use it to defog the windshield and side windows.

i Keep this setting selected only until the windshield or the side windows are clear again. When the defrost setting has been selected, only the rear window defroster can be switched on. No other settings are possible.

Activating 왘 Press button 0(컄 page 208). The indicator lamp on the button comes on.

The climate control switches to the follow- ing functions automatically: 앫 maximum blower speed and heating

power

앫 air flows onto the windshield and the front side windows (side air vents must be open)

앫 the air conditioning compressor

switches on at outside temperatures above approximately 41°F (5°C) for air-drying

Deactivating 왘 Press button 0 (컄 page 208) once

more. The indicator lamp on the button goes out. Defrosting is turned off. The previous settings are in effect again. The air conditioning compressor remains switched on.

i To switch off, you can also press button ´ or U (컄 page 208).

Windshield fogged on the outside

i Keep this setting selected only until the windshield is clear again.

Controls in detail Climate control

왘 Switch the windshield wipers on

(컄 page 61).

왘 Press button 0(컄 page 208). The indicator lamp on the button comes on.

The climate control switches automatically to the following functions: 앫 maximum blower speed and heating

power

앫 air flows onto the windshield and the front side windows (side air vents must be open)

앫 the air conditioning compressor

switches on at outside temperatures above approximately 41°F (5°C) for air-drying

If the automatic air distribution is switched off: 왘 Press air distribution button 9 or a

(컄 page 208).

213

Controls in detail Climate control

Air recirculation mode

Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside (e.g. before driving through a tunnel). This setting cuts off the intake of outside air and recirculates the air in the passenger compartment.

Warning!

Fogged windows impair visibility, endangering you and others. If the windows begin to fog on the inside, switching off the air recirculation mode immediately should clear interior window fogging. If interior win- dow fogging persists, make sure the air conditioning (컄 page 208) is activated, or press button 0.

Activating 왘 Press button : (컄 page 208). The indicator lamp on the button comes on.

i The air recirculation mode is activated auto- matically at high outside temperatures. The indicator lamp on button : is not lit when the air recirculation mode is switched on auto- matically. A quantity outside air is added after approximately 30 minutes. If you have turned off the air conditioning (컄 page 216) or the outside temperature is below 41°F (5°C), the air recirculation mode will not switch on automatically.

i To cool the interior as fast as possible, the climate control automatically switches to air recirculation. The indicator lamp on button : is not lit when the air recirculation mode has been switched on automatically.

Deactivating 왘 Press button :.

The indicator lamp on the button goes out.

i The air recirculation mode is deactivated automatically 앫 after 5 minutes if the outside temperature is

below approximately 41°F (5°C)

앫 after 5 minutes if the air conditioning and

air-drying is turned off

앫 after 30 minutes if the outside temperature

is above approximately 41°F (5°C)

214

Controls in detail Climate control

Air recirculation mode with conve- nience closing and opening feature

Convenience closing 왘 Press button : for approximately

Convenience opening 왘 Press button : for approximately

Warning!

Never operate the windows and tilt/sliding sunroof* if there is the possibility of anyone being harmed by the opening or closing pro- cedure.

In case the procedure causes potential danger:

Vehicles with or without tilt/sliding sun- roof*: The closing of the windows can be im- mediately halted by pressing or pulling the respective window switch. The closing of the tilt/sliding sunroof* can be immediately halted by moving the switch for the tilt/slid- ing sunroof* in any direction.

The closing of the windows and the tilt/sliding sunroof* can be reversed by again pressing and holding the : button.

2 seconds. The windows and/or tilt/sliding sun- roof* will close. You can release button : once the closing proce- dure has begun. The windows and tilt/sliding sunroof* continue closing until they are fully closed. The indicator lamp on the button comes on. The air recirculation mode is activated.

2 seconds. The windows and/or tilt/sliding sun- roof* will return to their previous posi- tions. You can release button : once the opening procedure has be- gun. The windows and tilt/sliding sun- roof* continue opening until they have reached their previous positions. The indicator lamp on the button goes out. The air recirculation mode is deactivat- ed.

i A window or the tilt/sliding sunroof* will only return to its previous position if it has not been moved to another position using the re- spective window switch or tilt/sliding sunroof* switch after it was closed with button :.

215

Controls in detail Climate control

Air conditioning

The air conditioning is operational while the engine is running and cools the interior air to the temperature set by the operator. In addition, the air conditioning dehumidi- fies the interior air at outside temperatures above 41°F (5° C) and helps prevent window fogging.

i Condensation may drip out from underneath the vehicle. This is normal and not an indication of a malfunction.

Warning!

If you turn off the cooling function, the interior air is not dried. The windows can fog up more quickly. Window fogging may impair visibility and endanger you and others.

216

Deactivating It is possible to deactivate the air condi- tioning (cooling) function of the climate control system. The air in the vehicle will then no longer be cooled or dehumidified. 왘 Press button 9 (컄 page 208).

The indicator lamp on the button goes out.

Activating Moist air can fog up the windows. You can dehumidify the air with the air condition- ing. 왘 Press button 9 (컄 page 208) again.

The indicator lamp on the button comes on.

The air conditioning uses the refrigerant R134a. This refrigerant is free of CFCs which are harmful to the ozone layer.

! If the air conditioning cannot be turned on again, this indicates that the air conditioning is losing refrigerant. The compressor has turned off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Light Truck Center.

Residual heat and ventilation

With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes. This feature makes use of the residual heat produced by the engine.

i How long the system will provide heating depends on 앫 the coolant temperature 앫 the battery voltage Regardless of the temperature and air volume set on the climate control panel, the interior tem- perature is set to 72°F (22°C) and the blower runs on low speed to protect the vehicle battery.

Rear climate control*

The control panel for the rear climate control is only available if your vehicle is equipped with seat heating* for the rear seats. The control panel is located on the rear of the front center console.

Controls in detail Climate control

1 Left rear center air vent, adjustable 2 Right rear center air vent, adjustable 3 Rear climate control on

(automatic mode)

4 Air distribution (directs air through

the center air vents)

5 Air distribution (directs air through

the footwells and side air vents)

6 Rear air conditioning off

Activating 왘 Switch off the ignition (컄 page 40). 왘 Press button 9 (컄 page 208). The indicator lamp on the button comes on.

Deactivating 왘 Press button 9 (컄 page 208).

The indicator lamp on the button goes out.

i The residual heat is automatically turned off: 앫 when the ignition is switched on 앫 after about 30 minutes 앫 if the coolant temperature is too low 앫 if the battery voltage drops

Rear climate control panel

217

Controls in detail Climate control

Activating rear climate control

i The climate control must be switched on (컄 page 218). 왘 Press button U.

The indicator lamp on the button comes on. The air volume and air distri- bution are adjusted automatically.

i The temperature is adjusted according to the settings for the front passenger side made on the front climate control panel (컄 page 211).

Deactivating rear climate control 왘 Press button ´.

The indicator lamp on the button comes on. The cooling function switches off after a short delay.

i Switch off the rear climate control for im- proved cooling or heating output in the front pas- senger compartment. You can also switch off the rear climate control from the front passenger compartment (컄 page 218).

Operating from the front

Deactivating 왘 Press button : on the front climate

control panel (컄 page 208). The indicator lamp on the button comes on.

Reactivating 왘 Press button : on the front climate

control panel (컄 page 208). The indicator lamp on the button goes out. The rear climate control is adjust- ed automatically.

218

Adjusting air distribution Use the air distribution controls 4 or 5 to adjust the air distribution for the rear passenger compartment. The following symbols are found on the controls:

Symbol Function Z Directs air to the center air

vents

Y Directs air to the footwells and

the side air vents

Adjusting manually 왘 Press the desired air distribution

control 4 or 5. The indicator lamp in the U button goes out.

Adjusting automatically 왘 Press button U (컄 page 217). The indicator lamp on the button comes on. The air distribution is adjust- ed automatically.

Adjusting air volume The air volume for the rear zone corre- sponds to the air volume settings for the front passenger side. You can switch off the air supply for the rear zone. You can switch off the supplied amount of air volume. 왘 Press button ´ (컄 page 217). The indicator lamp on the button comes on.

Controls in detail Climate control

219

Controls in detail 3-zone automatic climate control*

220

Controls in detail 3-zone automatic climate control*

i For draft-free ventilation, move the sliders for center air vents and side air vents to the middle position.

1 Driver’s door air vent, fixed 2 Left side air vent, adjustable 3 Thumbwheel for air volume control

for left side and door air vent

4 Thumbwheel for air volume control

for left center air vent

5 Left center air vent, adjustable 6 Right center air vent, adjustable 7 Thumbwheel for air volume control

for right center air vent

8 Thumbwheel for air volume control

for right side and door air vent 9 Right side air vent, adjustable a Front passenger door air vent, fixed b Automatic climate control panel

221

Controls in detail 3-zone automatic climate control*

222

1 Temperature control, left 2 Air distribution and air volume

(automatic, manual)

3 Air distribution, driver’s side 4 Front defroster 0 USA only P Canada only

5 Increasing air volume 6 Rear window defroster

1 USA only F Canada only

7 Air distribution, passenger side 8 Rear automatic climate control

on/off > USA only ™ Canada only

9 Temperature control, right a Automatic climate control on/off b Air distribution, passenger side c Air distribution, passenger side d AC cooling on/off

Residual heat/ventilation

e Display f Decreasing air volume g Air recirculation h Air distribution, driver’s side j Air distribution, driver’s side k Interior temperature sensor l Adopting driver’s side settings for all

zones

The automatic climate control is a 3-zone intelligent automatic climate control sys- tem. Your vehicle interior is divided into 3 zones.

Warning!

When operating the automatic climate con- trol, the air that enters the passenger com- partment through the air vents can be very hot or very cold (depending on the set tem- perature). This may cause burns or frostbite to unprotected skin in the immediate area of the air vents.

Always keep sufficient distance between un- protected parts of the body and the air vents. If necessary, use the air distribution controls (컄 page 222) to direct the air to air vents in the vehicle interior that are not in the immediate area of unprotected skin.

Controls in detail 3-zone automatic climate control*

With the help of a sun sensor, the automat- ic climate control determines the relation of the sun to the vehicle and automatically adjusts the inside temperature for every individual zone. The automatic climate control is operation- al whenever the engine is running. It cools the vehicle’s interior according to the an- gle and intensity of the sun’s rays, the out- side temperature and the selected temperature. You can operate the auto- matic climate control in either the auto- matic or manual mode. Nearly all dust particles, pollutants and odors are filtered out before outside air en- ters the passenger compartment through the air distribution system. The air conditioning will not engage (no cooling) if the A/C mode is deactivated (컄 page 222).

223

Controls in detail 3-zone automatic climate control*

Warning!

Deactivating the automatic climate control system

Reactivating 왘 Press button U(컄 page 222).

i You can also press button ´ (컄 page 222) on the automatic climate control panel. If you press button 0 (컄 page 222) to reacti- vate the automatic climate control system, the defrosting mode is activated.

Follow the recommended settings for heat- ing and cooling given on the following pag- es. Otherwise the windows could fog up, impairing visibility and endangering you and others.

i Severe conditions (e.g. strong air pollution) may require replacement of the filter before its scheduled interval. A clogged filter will reduce the air volume to the interior. If the vehicle interior is hot, ventilate the interior before driving off, see “Summer opening fea- ture” (컄 page 239). The automatic climate con- trol will then adjust the interior temperature to the set value much faster. Keep the air intake grille in front of the wind- shield free of snow and debris.

Warning!

When the automatic climate control system is switched off, the outside air supply and circulation are also switched off. Only choose this settings for a short time. Other- wise the windows could fog up, impairing visibility and endangering you and others.

Deactivating 왘 Press button ´ (컄 page 222) until the display e (컄 page 222) is cleared. The indicator lamp on the button comes on.

224

Operating the automatic climate control system in automatic mode

You can switch the automatic climate con- trol system on and off separately for each zone as needed.

i When operating the automatic climate control system in automatic mode, you will only rarely need to adjust the temperature, air volume and air distribution. In automatic mode, cooling with dehumidify is switched on. This function can be switched off if necessary.

Activating 왘 Press button U (컄 page 222) while

the engine is running. The indicator lamp on the button comes on. AUTO appears in the display e (컄 page 222). Air volume and air distribution are controlled sep- arately for each zone.

왘 Use temperature controls 1 and 9 (컄 page 222) to separately adjust the air temperature on each side of the passenger compartment. The temperature of the interior is ad- justed automatically.

Deactivating 왘 Press one button of the air distribution

(컄 page 222) or press button ˜ or Q (컄 page 222). The indicator lamp on button U goes out and AUTO disappears in the display e (컄 page 222). Depending on which button you press – the air distribution button or the air vol- ume button ˜ or Q – automatic control of either the air distribution or air volume is switched off.

Controls in detail 3-zone automatic climate control*

Setting the temperature

Use temperature control 1 and 9 (컄 page 222) to separately adjust the air temperature on each side of the passenger compartment. You should raise or lower the temperature setting in small incre- ments, preferably starting at 72°F (22°C). The automatic climate control will adjust to the set temperature as fast as possible.

Increasing 왘 Turn temperature control 1 and/or 9 slightly clockwise. The automatic climate control system will correspondingly adjust the interior air temperature.

Decreasing 왘 Turn the temperature control 1

and/or 9 slightly counterclockwise. The automatic climate control system will correspondingly adjust the interior air temperature.

225

Controls in detail 3-zone automatic climate control*

Adjusting air distribution

Use the air distribution controls 3, h, or j for the driver’s side, or 7, b, or c (컄 page 222) for the passenger side to separately adjust the air distribution on each side of the passenger compartment. The following symbols are found on the buttons:

Symbol

Function

Passen- ger side

Driver’s side 6 Z Directs air to the

windshield and side air vents

7 a Directs air through the center, side and rear passenger compartment air vents

8 Y Directs air to the footwells and side air vents

226

Opening the side air vents 왘 Turn thumbwheels 3 and 8

(컄 page 220) to the right. The corresponding side air vents on the left and right are open.

Closing the side air vents 왘 Turn thumbwheels 3 and 8

(컄 page 220) to the left. The corresponding side air vents on the left and right are closed.

왘 Press the desired air distribution but-

ton (컄 page 222). The indicator lamp on the desired but- ton goes out.

Adjusting the air distribution for the center and side air vents

Opening the center air vents 왘 Turn thumbwheels 4 and 7

(컄 page 220) to the right. The corresponding center air vents on the left and right are open.

Closing the center air vents 왘 Turn thumbwheels 4 and 7

(컄 page 220) to the left. The corresponding center air vents on the left and right are closed.

Adjusting air volume

Front defroster

Five blower speeds are available. 왘 Press button ˜ to decrease or button Q to increase air volume (컄 page 222) to the desired level. The indicator lamp on button U goes out. The AUTO display disappears in the display e (컄 page 222) and the auto- matic mode is switched off. The select- ed blower speed appears in the display e (컄 page 222).

You can use this setting to defrost the windshield, such as when it is iced up. You can also use it to defog the windshield and side windows.

i Keep this setting selected only until the windshield or the side windows are clear again. When the defrost setting has been selected, only the rear window defroster can be switched on. No other settings are possible.

Activating 왘 Press button 0 (컄 page 222). The indicator lamp on the button comes on.

Controls in detail 3-zone automatic climate control*

The automatic climate control switches to the following functions automatically: 앫 maximum blower speed and heating

power

앫 air flows onto the windshield and the front side windows (side air vents must be open)

앫 the air conditioning compressor

switches on at outside temperatures above approximately 41°F (5°C) for air-drying

Deactivating 왘 Press button 0 (컄 page 222).

The indicator lamp on the button goes out. Defrosting is turned off. The previous settings are once again in effect.

i To switch off, you can also press button ´ or U (컄 page 222).

227

Controls in detail 3-zone automatic climate control*

Windshield fogged on the outside

Maximum cooling MAX COOL

Air recirculation mode

i Keep this setting selected only until the windshield is clear again. 왘 Switch the windshield wipers on

(컄 page 61).

왘 Press button U (컄 page 222).

AUTO appears in the display e (컄 page 222). Air volume and air distri- bution are controlled separately for each zone.

If the automatic air distribution and air vol- ume are switched off: 왘 Press buttons 8 and Y

(컄 page 222).

If the air distribution control as well as the airflow volume control are set to U and there is a high need for cooling, the MAX COOL function is activated. “MAX COOL” appears in the front and rear display. This provides the fastest possible cooling of the vehicle interior (when windows and tilt/sliding sunroof* are closed).

Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside (e.g. before driving through a tunnel). This setting cuts off the intake of outside air and recirculates the air in the passenger compartment.

Warning!

Fogged windows impair visibility, endangering you and others. If the windows begin to fog on the inside, switching off the air recirculation mode immediately should clear interior window fogging. If interior win- dow fogging persists, make sure the air conditioning (컄 page 230) is activated, or press button 0.

228

Activating 왘 Press button : (컄 page 222). The indicator lamp on the button comes on.

Deactivating 왘 Press button : (컄 page 222). The indicator lamp on the button comes on.

i The air recirculation mode is activated auto- matically at high outside temperatures. The indicator lamp on button : is not lit when the air recirculation mode is automatically switched on. A quantity of outside air is added after approxi- mately 30 minutes. If you have turned off the air conditioning (컄 page 230) or the outside temperature is below 41°F (5°C), the air recirculation mode will not switch on automatically.

i To cool the interior as fast as possible, the automatic climate control automatically switch- es to air recirculation. The indicator lamp on button : is not lit when the system switches to air recirculation automatically.

i The air recirculation mode is deactivated automatically 앫 after 5 minutes if the outside temperature is

below approximately 41°F (5°C)

앫 after 5 minutes if the air conditioning and

air-drying is turned off

앫 after 30 minutes if the outside temperature

is above approximately 41°F (5°C)

At outside temperatures above 79°F (26°C) the system will not automatically switch back to outside air. A quantity of outside air is added after approximately 30 minutes.

Controls in detail 3-zone automatic climate control*

Air recirculation mode with conve- nience closing and opening feature

Warning!

Never operate the side windows and tilt/sliding sunroof* if there is the possibility of anyone being harmed by the opening or closing procedure.

In case the procedure causes potential danger:

Vehicles with or without tilt/sliding sun- roof*: The closing of the windows can be im- mediately halted by pressing or pulling the respective window switch. The closing of the tilt/sliding sunroof* can be immediately halted by moving the switch for the tilt/slid- ing sunroof* in any direction.

The closing of the side windows and the tilt/sliding sunroof* can be reversed by again pressing and holding the : button.

229

Controls in detail 3-zone automatic climate control*

Convenience closing 왘 Press button : for approximately

Convenience opening 왘 Press button : for approximately

2 seconds. The windows and/or tilt/sliding sun- roof* will close. You can release button : once the closing proce- dure has begun. The windows and tilt/sliding sunroof* continue closing until they are fully closed. The indicator lamp on the button comes on. The air recirculation mode is activated.

2 seconds. The windows and/or tilt/sliding sun- roof* will return to their previous posi- tions. You can release button : once the opening procedure has be- gun. The windows and tilt/sliding sun- roof* continue opening until they have reached their previous positions. The indicator lamp on the button goes out. The air recirculation mode is deactivat- ed.

i A window or the tilt/sliding sunroof* will only return to its previous position if it has not been moved to another position using the re- spective window switch or tilt/sliding sunroof* switch after it was closed with button :.

Air conditioning

The cooling function, only operational when the engine is running, cools the vehi- cle down to the selected interior tempera- ture. The cooling function also dehumidifies the air in the vehicle interior, thereby preventing the windows from fog- ging up.

i Condensation may drip out from underneath the vehicle. This is normal and not an indication of a malfunction.

Warning!

If you turn off the cooling function, the interior air is not dried. The windows can fog up more quickly. Window fogging may impair visibility and endanger you and others.

230

! If the air conditioning cannot be turned on again, this indicates that the air conditioning is losing refrigerant. The compressor has turned off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Light Truck Center.

Using driver-side settings for all tem- perature zones

You can use the settings of the driver’s side, such as temperature, air volume and air distribution, for all temperature zones. These settings only need to be made once and the automatic climate control system will automatically regulate the settings for all temperature zones quickly and comfort- ably.

Deactivating It is possible to deactivate the air condi- tioning (cooling) function of the automatic climate control system. The air in the vehi- cle will then no longer be cooled or dehu- midified. 왘 Press button 9 (컄 page 222).

The indicator lamp on the button goes out. The cooling function switches off after a short delay.

Activating Moist air can fog up the windows. You can dehumidify the air with the air condition- ing. 왘 Press button 9 again.

The indicator lamp on the button comes on.

The air conditioning uses the refrigerant R-134a. This refrigerant is free of CFCs which are harmful to the ozone layer.

Controls in detail 3-zone automatic climate control*

Activating 왘 Adjust the temperature, air volume and

air distribution (컄 page 222).

왘 Press button ; (컄 page 222). The indicator lamp on the button comes on. The driver-side settings are used for all temperature zones.

Deactivating 왘 Press button ; (컄 page 222) again. The indicator lamp on the button goes out.

i If you manually set the temperature, air vol- ume or air distribution for the passenger side or the rear passenger compartment when the MONO setting is active, the MONO setting will be switched off.

231

Controls in detail 3-zone automatic climate control*

Residual heat and ventilation

With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes. This feature makes use of the residual heat produced by the engine.

i How long the system will provide heating depends on 앫 the coolant temperature 앫 the battery voltage Regardless of the temperature and air volume set on the automatic climate control panel, an interior temperature is aimed at by 72°F (22°C) and the blower runs on low speed to protect the vehicle battery.

Activating 왘 Switch off the ignition (컄 page 39). 왘 Press button 9 (컄 page 222). The indicator lamp on the button comes on.

Deactivating 왘 Press button 9.

The indicator lamp on the button goes out.

i The residual heat is automatically turned off: 앫 when the ignition is switched on 앫 after about 30 minutes 앫 if the coolant temperature is too low 앫 if the battery voltage drops

Rear automatic climate control

The control panel is located at the rear of the front center console.

232

1 Left rear center air vent, adjustable 2 Right rear center air vent, adjustable 3 Temperature control 4 Air distribution and air volume

(automatic, manual)

5 Air distribution (directs air through

the center air vents)

6 Air distribution (directs air through

the footwells and side air vents) 7 Rear automatic climate control

on/off

8 Decreasing air volume 9 Indicator lamps for air volume

settings

a Increasing air volume

Activating rear automatic climate control

i The automatic climate control must be switched on (컄 page 224). 왘 Press button U.

The indicator lamp on the button comes on. The temperature, air vol- ume, and air distribution are adjusted automatically.

Deactivating rear automatic climate control 왘 Press button ´.

The indicator lamp on the button goes out. The cooling function switches off after a short delay.

i Switch off the rear automatic climate con- trol for improved cooling or heating output in the front passenger compartment. You can also switch off the rear automatic climate control from the front passenger com- partment (컄 page 222).

Controls in detail 3-zone automatic climate control*

Operating from the front

Deactivating 왘 Press button > (컄 page 222).

The indicator lamp on the button goes out. In display e (컄 page 222), you will see the > symbol followed by MODE for approximately 3 seconds.

왘 Press button ´ (컄 page 222).

In display e (컄 page 222), you will see the > symbol followed by OFF. The rear automatic climate control is switched off.

233

Controls in detail 3-zone automatic climate control*

Reactivating 왘 Press button > (컄 page 222). The indicator lamp on the button comes on. In display e (컄 page 222), you will see the > symbol followed by ON and MODE. The MODE display is cleared and the indicator lamp on button > goes out after approximately 3 seconds. The rear automatic climate control switches on.

234

Setting the temperature 왘 Press button > (컄 page 222). The indicator lamp on the button comes on. In display e (컄 page 222), you will see the > symbol followed by MODE. 왘 Set the desired temperature for the rear passenger compartment using temperature control 3 (컄 page 233). After approximately 3 seconds after the last adjustment, the display switch- es back to its standard display and the indicator lamp on button > goes out.

i You can also press the > button once more to switch back to the standard display.

Adjusting air distribution Use the air distribution controls 5 or 6 to adjust the air distribution for the rear passenger compartment. The symbols on the controls represent the following functions:

Symbol Function Z Directs air to the center air

vents

Y Directs air to the footwells and

the side air vents

Adjusting manually 왘 Press the desired air distribution con-

trol. The indicator lamp on button U goes out.

Controls in detail 3-zone automatic climate control*

Adjusting automatically 왘 Press button U while the engine is

running. The indicator lamp on the button comes on. The air distribution is adjust- ed automatically.

Setting the temperature Use temperature control 3 (컄 page 233) to separately adjust the air temperature of the rear passenger compartment. You should raise or lower the temperature setting in small increments, preferably starting at 72°F (22°C). The automatic cli- mate control will adjust to the set temper- ature as fast as possible.

i The rear automatic climate control will not cool the air when the air conditioning is switched off (컄 page 231).

Increasing the temperature 왘 Turn temperature control 3

(컄 page 233) slightly clockwise. The rear automatic climate control will correspondingly adjust the interior air temperature for the rear passenger compartment.

Decreasing the temperature 왘 Turn temperature control 3

(컄 page 233) slightly counterclock- wise. The rear automatic climate control will correspondingly adjust the interior air temperature for the rear passenger compartment.

Adjusting air volume

Adjusting manually Five blower speeds are available. 왘 Press button ˜ to decrease or

button Q to increase air volume to the desired level. The indicator lamp on the button U goes out. The selected blower speed is shown by the indicator lamps for air volume settings 9 (컄 page 233).

Adjusting automatically 왘 Press button U.

The indicator lamp on the button comes on. The air volume is adjusted automatically.

235

Controls in detail Power windows

Opening and closing

The door windows are opened and closed electrically. The switches for all door win- dows are located on the driver’s door con- trol panel (컄 page 36). The switches for the respective door windows are located on the control panels of the front passen- ger door and the rear doors.

236

1 Left rear door window 2 Left front door window 3 Right front door window 4 Right rear door window 5 Override switch (컄 page 93) 왘 Switch on the ignition (컄 page 40).

Warning!

When closing the windows, make sure that there is no danger of anyone being harmed by the closing procedure. Activate the override switch (컄 page 94) when children are riding in the back seats of the vehicle. The children could otherwise in- jure themselves, e.g. by becoming trapped in the window opening.

The closing of a door window can be imme- diately halted by releasing the switch or, if switch was pulled past the resistance point and released, by either pressing or pulling the respective switch.

If a door window encounters an obstruction that blocks its path in a circumstance where you pulled the switch past the resistance point and released it to close the door win- dow, the automatic reversal function will stop the window and open it slightly.

If a door window encounters an obstruction that blocks its path in a circumstance where you are closing a door window by pulling and holding the switch, or by pressing and hold- ing button ‹ on the SmartKey, by press- ing and holding the lock button (vehicles with KEYLESS-GO*) on a door handle, the automatic reversal function will not operate.

When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment can cause an accident and/or serious personal injury.

i You can also open or close the windows using the SmartKey, see “Summer opening fea- ture” (컄 page 239) and see “Convenience clos- ing feature” (컄 page 239). Depending on the current position, the power windows may also open or close when the air recirculation button : on the control panel of the climate control (컄 page 208) or automatic climate control* (컄 page 222) is pressed and held.

i With the SmartKey in starter switch position 0 or removed from the starter switch, the windows can be operated 앫 until you open the driver’s or front passenger

door

앫 for at least 5 minutes

Controls in detail Power windows

Opening the door windows 왘 Press switch 1, 2, 3, or 4

(컄 page 236) to the resistance point. The corresponding door window moves downwards until you release the switch.

Closing the door windows 왘 Pull switch 1, 2, 3, or 4

(컄 page 236) to the resistance point. The corresponding door window moves upwards until you release the switch.

Warning!

If you pull and hold the switch up when clos- ing the door window, and upward movement of the door window is blocked by some ob- struction including but not limited to arms, hands, fingers, etc., the automatic reversal will not operate.

237

Controls in detail Power windows

Fully opening the door windows (Express-open) 왘 Press switch 1, 2, 3, or 4

(컄 page 236) past the resistance point and release. The corresponding door window opens completely.

Fully closing the door windows (Express-close) 왘 Pull switch 1, 2, 3, or 4

(컄 page 236) past the resistance point and release. The corresponding door window closes completely.

Warning!

Driver’s door only: If within 5 seconds switch is again pulled past the resistance point and released, the automatic reversal will not function.

238

If the upward movement of a door window is blocked during the closing procedure, the door window will stop and open slight- ly. 왘 Remove the obstruction. 왘 Pull the respective power window

switch past the resistance point again and release.

i If the door window still does not close when there is no obstruction, pull and hold the respec- tive power window switch. The door window will then close without the obstruction sensor function.

Stopping door windows during Express-operation 왘 Press or pull respective power window

switch again.

Synchronizing the door windows

The door windows must be resynchronized 앫 after the battery was disconnected 앫 if the door windows cannot be fully

opened (Express-open) or closed (Express-close)

i Each door window must be resynchronized separately. 왘 Close all doors. 왘 Switch on the ignition (컄 page 40). 왘 Pull and hold power window switch 1,

2, 3, or 4 (컄 page 236). Once a door window is closed com- pletely, hold the respective switch for approximately 3 seconds. The door window is synchronized.

Summer opening feature

왘 Aim transmitter eye of the SmartKey or

Convenience closing feature

Controls in detail Power windows

If the weather is warm, you can ventilate the vehicle before driving off by simulta- neously: 앫 opening the door windows 앫 opening the tilt/sliding sunroof* 앫 switching on the seat ventilation* for

the driver’s seat

SmartKey with KEYLESS-GO* at the driver’s outside door handle. The SmartKey or SmartKey with KEYLESS-GO* must be in close proxim- ity to the driver’s outside door handle.

왘 Press and hold button Œ on the

SmartKey or SmartKey with KEYLESS-GO* until the windows and the tilt/sliding sunroof* have reached the desired position.

왘 Release button Œ on the SmartKey

or SmartKey with KEYLESS-GO* to interrupt the opening procedure.

When locking the vehicle, you can close the windows and the tilt/sliding sunroof* simultaneously.

Warning!

When closing the windows and the tilt/sliding sunroof*, make sure that there is no danger of anyone being harmed by the closing procedure.

If potential danger exists, proceed as fol- lows: 앫 Release button ‹ to stop the closing

procedure. To open, press and hold button Œ. To continue the closing procedure after making sure that there is no danger of anyone being harmed by the closing procedure, press and hold button ‹.

컄컄

239

Controls in detail Power windows

컄컄컄컄

Vehicles with KEYLESS-GO*: 앫 Release the lock button (컄 page 68) on the driver’s outside door handle to stop the closing procedure.

앫 Immediately pull on the same outside door handle and hold firmly. The win- dows and the tilt/sliding sunroof* will open for as long as the door handle is held but the door is not opened.

왘 Aim transmitter eye of the SmartKey or

SmartKey with KEYLESS-GO* at the driver’s outside door handle (컄 page 239). The SmartKey or SmartKey with KEYLESS-GO* must be in close proxim- ity to the driver’s outside door handle.

왘 Press and hold button ‹ on the

SmartKey or SmartKey with KEYLESS-GO* until the windows and the tilt/sliding sunroof* are completely closed.

왘 Release button ‹ on the SmartKey

or SmartKey with KEYLESS-GO* to interrupt the closing procedure.

Vehicles with KEYLESS-GO*: 왘 Press and hold the lock button on an outside door handle (컄 page 68) until the windows and the tilt/sliding sun- roof* are completely closed.

왘 Release the lock button on the outside

door handle to interrupt the closing procedure.

240

왔 Power tilt/sliding sunroof* Opening and closing

The tilt/sliding sunroof is opened and closed electrically. The switch for the tilt/sliding sunroof is located on the overhead control panel.

Controls in detail Power tilt/sliding sunroof*

With the sunroof closed or tilted open, a screen can be slid into the roof opening to guard against sun rays. When sliding the sunroof open, the screen will also retract.

Sunroof switch 1 Push back to slide sunroof open 2 Push forward to slide sunroof closed 3 Push up to raise sunroof at rear 4 Pull down to lower sunroof at rear

241

Controls in detail Power tilt/sliding sunroof*

Warning!

When closing the tilt/sliding sunroof, make sure that there is no danger of anyone being harmed by the closing procedure.

If the tilt/sliding sunroof encounters an ob- struction that blocks its path in a circum- stance where you are closing the tilt/sliding sunroof by moving the tilt/sliding sunroof switch past the resistance point, or by pressing and holding button ‹ on the SmartKey, by pressing and holding the lock button (vehicles with KEYLESS-GO*) on the door handle, the automatic reversal function will not operate.

The opening/closing procedure of the tilt/sliding sunroof can be immediately halt- ed by releasing the switch or, if the switch was moved past the resistance point and re- leased, by moving the switch in any direc- tion.

242

The tilt/sliding sunroof is made out of glass. In the event of an accident, the glass may shatter. This may result in an opening in the roof.

In a vehicle rollover, occupants not wearing their seat belts or not wearing them properly may be thrown out of the opening. Such an opening also presents a potential for injury for occupants wearing their seat belts prop- erly as entire body parts or portions of them may protrude from the passenger compart- ment.

When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock your vehicle. Do not leave children un- attended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment can cause an accident and/or serious personal injury.

! To avoid damaging the seals, do not trans- port any objects with sharp edges which can stick out of the tilt/sliding sunroof.

Do not open the tilt/sliding sunroof if there is snow or ice on the roof, as this could result in malfunctions. The tilt/sliding sunroof can be opened or closed manually should an electrical malfunction occur (컄 page 478). i When the tilt/sliding sunroof is open, reso- nance noises may result in addition to the usual wind noises. They are caused by minimal pres- sure changes in the passenger compartment. To reduce or eliminate these noises, change the po- sition of the tilt/sliding sunroof or open a side window slightly.

i You can also open or close the tilt/sliding sunroof using the SmartKey or the KEYLESS-GO* function, see “Summer opening feature” (컄 page 239) and see “Convenience closing feature” (컄 page 239).

i Depending on the current position, the tilt/sliding sunroof may also open or close when the air recirculation button : on the control panel of the climate control (컄 page 208) or automatic climate control* (컄 page 222) is pressed and held.

왘 Switch on the ignition (컄 page 40).

Opening and closing 왘 To open, close, raise, or lower the

tilt/sliding sunroof, move the sunroof switch to the resistance point in the required direction of arrows 1 to 4 (컄 page 241).

왘 Release the sunroof switch when the tilt/sliding sunroof has reached the de- sired position.

Controls in detail Power tilt/sliding sunroof*
