13. Using the wrench, tighten the five bolts evenly,


following the sequence illustrated, until all bolts are tight. Observe a tightening torque of 80 ft.lb. (110 Nm).


14. Vehicles with steel rims


Installation of wheel cover: Position small wheel cover opening over tire valve and press wheel cover against wheel rim. Now press (do not hit) opposite side of wheel cover against wheel rim until seated. Make certain that the springs of the wheel cover are firmly seated in the outer rim of the steel wheel.


Notes: Before storing the jack, it should be fully collapsed, with handle folded in. For proper storage of vehicle jack see page 304.


Tire inflation pressure A table (see fuel filler flap) lists the tire inflation pressures specified for Mercedes-Benz recommended tires as well as for the varying operating conditions.


Warning! Always replace wheel bolts that are damaged or rusted. Never apply oil or grease to wheel bolts. Damaged wheel hub threads should be repaired immediately. Incorrect mounting bolts or improperly tightened mounting bolts can cause the wheel to come off. This could cause an accident. Be sure to use the correct mounting bolts.


Important! Tire pressure changes by approximately 1.5 psi (0.1 bar) per 18°F (10°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage – especially in the winter. Example: If garage temperature = approximately +68°F (+20°C) and ambient temperature = approximately +32°F (0°C) then the adjusted air pressure = specified air pressure +3 psi (+0.2 bar). Tire pressures listed for light loads are minimum values offering high driving comfort. Increased inflation pressures for heavy loads produce favorable handling characteristics with lighter loads and are perfectly permissible. The ride of the vehicle, however, will become somewhat harder. Tire temperature and pressure increase with the vehicle speed. Tire pressure should therefore only be checked and corrected on cold tires. Correct tire pressure in


315


Tires, Wheels


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Battery


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


warm tires only if pressure has dropped below the pressure listed in the table and the respective operating conditions are taken into consideration. An underinflated tire due to a slow leak (e.g. due to a nail in the tire) may cause damage such as tread separation, bulging etc. Regular tire pressure checks (including the spare tire) at intervals of no more than 14 days are therefore essential. If a tire constantly loses air, it should be inspected for damage. The spare tire should be checked periodically for condition and inflation. Spare tire will age and become worn over time even if never used, and thus should be inspected and replaced when necessary.


Warning! Do not overinflate tires. Overinflating tires can result in sudden deflation (blowout) because they are more likely to become punctured or damaged by road debris, potholes etc. Follow recommended inflation pressures. Do not overload the tires by exceeding the specified vehicle capacity weight as indicated by the label on the driver’s door latch post). Overloading the tires can overheat them, possibly causing a blowout.


316


Battery


Warning! Failure to follow these instructions can result in severe injury or death. Never lean over batteries while connecting, you might get injured. Battery fluid contains sulfuric acid. Do not allow this fluid to come in contact with eyes, skin or clothing. In case it does, immediately flush affected area with water and seek medical help if necessary. A battery will also produce hydrogen gas, which is flammable and explosive. Keep flames or sparks away from battery, avoid improper connection of jumper cables, smoking etc.


Important! Battery replacement information: The maintenance-free battery is located in the engine compartment on the right hand side. The service life of the battery is dependent on its condition of charge. The battery should always be kept sufficiently charged, in order to last an optimum length of time.


Therefore, we strongly recommend that you have the battery charge checked frequently, and corrected if necessary, especially if you use the vehicle less than approximately 200 miles (300 km) per month, mostly for short distance trips, or if it is not used for long periods of time. Only charge a battery with a battery charger after the battery has been disconnected from the vehicle’s electrical circuit. Always disconnect the battery negative lead first and connect last. When removing and connecting the battery, always make sure that all electrical consumers are off and the electronic key is in starter switch position 0. The battery, its filler caps, the vent tube and the opposite plug must always be securely installed when the vehicle is in operation.


While the engine is running the battery terminal clamps must not be loosened or detached, otherwise the generator and other electronic components would be damaged.


Removal of filter box: Release three clamps (1) and remove filter box. Installation of filter box: Install filter box properly and secure with three clamps (1).


Battery


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


317


Instruments and controls


Jump starting


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Note: After reconnecting the battery also set the clock (vehicles with COMAND: see COMAND operator’s manual) resynchronize the front seat head restraints, the express feature of the power windows, the sliding/ pop-up roof, and the electronic stability program (see individual settings on page 111, head restraints on page 47, power windows on page 184, synchronizing the sliding / pop-up roof on page 188 and electronic stability program on page 260).


Battery recycling Batteries contain materials that can harm the environment with improper disposal. Large 12 Volt storage batteries contain lead. Recycling of batteries is the preferred method of disposal. Many states require sellers of batteries to accept old batteries for recycling.


318


Jump starting


Warning! Failure to follow these directions will cause damage to the electronic components, and can lead to a battery explosion and severe injury or death. Never lean over batteries while connecting or jump starting, you might get injured. Battery fluid contains sulfuric acid. Do not allow this fluid to come in contact with eyes, skin or clothing. In case it does, immediately flush affected area with water, and seek medical help if necessary. A battery will also produce hydrogen gas, which is flammable and very explosive. Keep flames or sparks away from battery, avoid improper connection of jumper cables, smoking etc. Read all instructions before proceeding.


Important! A discharged battery can freeze at approximately +14°F (–10°C). In that case, it must be thawed out before jumper cables are used. Attempting to jump start a frozen battery can result in it exploding, causing personal injury. Jumper cable specifications: • Minimum cable cross-section of 25 mm2 or


approximately 2 AWG


• Maximum length of 11.5 ft. (3.5 m).


If the battery is discharged, the engine should be started with jumper cables and the (12 V) battery of another vehicle. Only use 12 V battery to jump start your vehicle. Jump starting with more powerful battery could damage the vehicle’s electrical systems, which will not be covered by the Mercedes-Benz Limited Warranty. The battery is located in the engine compartment on the right hand side.


1 Negative (–) under hood terminal 2 Positive (+) under hood terminal


Jump starting


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


319


Instruments and controls


Jump starting


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


320


Important!


5. Start engine of the vehicle with the charged battery


and run at high idle. Make sure the cables are not on or near pulleys, fans, or other parts that move when the engine is started. Allow the discharged battery to charge for a few minutes. Start engine of the disabled vehicle in the usual manner.


6. After the engine has started, remove jumper cables


by exactly reversing the above installation sequence, starting with the last connection made first. When removing each clamp, make sure that it does not touch any other metal while the other end is still attached.


Proceed as follows:


1. Position the vehicle with the charged battery so that


the jumper cables will reach, but never let the vehicles touch. Make sure the jumper cables do not have loose or missing insulation.


2. On both vehicles:


• Turn off engine and all lights and accessories, except hazard warning flashers or work lights. • Apply parking brake and shift selector lever to position “P” (manual transmission to Neutral).


Important!


3. Clamp one end of the first jumper cable to the


positive (+) under hood terminal of the discharged battery and the other end to the positive (+) terminal of the charged battery. Make sure the cable clamps do not touch any other metal parts.


4. Clamp one end of the second jumper cable to the


grounded negative (–) terminal of the charged battery and the final connection to the negative (–) under hood terminal of the disabled vehicle.


Note: If engine does not run after several unsuccessful starting attempts, have it checked at the nearest authorized Mercedes-Benz Center. Excessive unburned fuel may damage the catalytic converter.


Towing the vehicle


Warning! Prior to towing the vehicle with all wheels on the ground, make certain that the electronic key is in starter switch position 2. If the electronic key is left in the starter switch position 0 for an extended period of time, it can no longer be turned in the switch. In this case, the steering is locked. To unlock, remove electronic key from starter switch and reinsert.


Towing the vehicle


321


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Towing the vehicle


322


Important! When towing the vehicle, please, note the following: With the automatic central locking activated and the electronic key in starter switch position 2, the vehicle doors lock if the left front wheel as well as the right rear wheel are turning at vehicle speeds of approximately 9 mph (15 km/h) or more. To prevent the vehicle door locks from locking, deactivate the automatic central locking. See “VEHICLE” under “Individual settings” on page 119. Towing of the vehicle should only be done using the properly installed towing eye bolt. Never attach tow cable, tow rope or tow rod to vehicle chassis, frame or suspension parts.


Notes: The selector lever will remain locked in position “P” and the electronic key cannot be turned in the starter switch if the battery is disconnected or discharged. See battery on page 316 or jump starting on page 318. Transmission selector lever, manually unlocking, see page 325.


1 Cover on right side of front bumper


To remove cover: Press mark on cover in direction of arrow and lift cover off to reveal threaded hole for towing eye bolt. The towing eye bolt is supplied with the tool kit (located in trunk in spare wheel). Screw towing eye bolt in to its stop and tighten with lug wrench. To reinstall cover: Fit cover and snap into place.


We recommend that the vehicle be transported using flat bed equipment. This method is preferable to other types of towing.


Important! To prevent damage during transport, do not tie down vehicle by its chassis or suspension parts. Towing restrictions for vehicles with automatic transmission: The vehicle may be towed with all wheels on the ground and the selector lever in position “N” for distances up to 30 miles (50 km) and at a speed not to exceed 30 mph (50 km/h). The electronic key must be in starter switch position 2. To be certain to avoid a possibility of damage to the transmission, however, we recommend the drive shaft be disconnected at the rear axle drive flange for any towing beyond a short tow to a nearby garage. Do not tow with sling-type equipment. Towing with sling-type equipment over bumpy roads will damage radiator and supports.


2 Cover on right side of rear bumper


To remove cover: Press mark on cover in direction of arrow and lift cover off to reveal threaded hole for towing eye bolt. The towing eye bolt is supplied with the tool kit (located in trunk in spare wheel). Screw towing eye bolt in to its stop and tighten with lug wrench. To reinstall cover: Fit cover and snap into place.


Towing the vehicle


323


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Towing the vehicle


324


Use wheel lift, dolly, or flat bed equipment, with electronic key in starter switch turned to position 0.


Upon canceling the turn signal, the hazard warning flasher will operate again.


Warning! With the engine not running, there is no power assistance for the braking and steering systems. In this case, it is important to keep in mind that a considerably higher degree of effort is necessary to brake and steer the vehicle.


Note: To signal turns while being towed with hazard warning flasher in use, turn electronic key in starter switch to position 2 and activate combination switch for left or right turn signal in usual manner – only the selected turn signal will operate.


Caution! If the vehicle is towed with the front axle raised, the engine must be shut off (electronic key in starter switch position 0 or 1). Otherwise, the ESP will immediately be engaged and will apply the rear wheel brakes. Switch off the tow-away alarm (see page 39) as well as the ESP (see page 260).


Transmission selector lever, manually unlocking


To do so, open storage compartment in front of center armrest. Using a small coin, release the coin holder (1) and swing it aside. Insert a tool (2), e.g. the screw driver, into the opening below the coin holder. While pushing the tool down, move selector lever from position “P”. After removal of the tool from the opening, reinstall the coin holder. The selector lever is locked again when moving it to position “P”.


In the case of power failure the transmission selector lever can be manually unlocked, e.g. to tow the vehicle.


Towing the vehicle


325


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Exterior lamps


Exterior lamps


326


Replacing bulbs


Headlamp adjustment Correct headlamp adjustment is extremely important. Check and readjust headlamps at regular intervals and when a bulb has been replaced.


Warning! Because of high voltage in Xenon lamps, it is dangerous to replace the bulb or repair the lamp and its components. We recommend that you have such work done by a qualified technician.


Warning! Bulbs and bulb holders can be very hot. Allow the lamp to cool down before changing a bulb. Halogen lamps contain pressurized gas. A bulb can explode if you:


• touch or move it when hot, • drop the bulb, • scratch the bulb.


Wear eye and hand protection.


Notes: To prevent a possible electrical short circuit, switch off lamp prior to replacing a bulb. When replacing bulbs, install only 12 volt bulbs with the specified watt rating. When replacing halogen bulbs do not touch glass portion of bulb with bare hands. Use plain paper or a clean cloth. If the newly installed bulb does not light up, switch the lamp off and on again. If the bulb still does not light up, have the system checked at an authorized Mercedes-Benz Center.


Headlamp assembly


1 Headlamp cover for low beam headlamp 2 Headlamp cover for parking and standing lamp, and


high beam headlamp


3 Bulb socket for turn signal lamp 4 Electrical connector for low beam headlamp bulb


(Halogen type)


5 Electrical connector for high beam headlamp bulb 6 Bulb socket for parking and standing lamp


Exterior lamps


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


327


Instruments and controls


Exterior lamps


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Bulbs for high and low beam H7 (55 W) Open hood. Press the clamp and remove headlamp cover (1 or 2). Pull electrical connector off. Unclip the retainer spring and take out the bulb. Insert the new bulb so that the base locates in the recess on the holder. Clip in retainer springs and plug the connector onto the bulb. Align headlamp cover (1 or 2) and click into place.


Xenon (optional) Bulb for low beam


Warning! Because of high voltage in Xenon lamps, it is dangerous to replace the bulb or repair the lamp and its components. We recommend that you have such work done by a qualified technician.


328


Turn signal lamp 1156 NA (26.9/5 W/32/4 cp) Open hood. Twist bulb socket (3) counterclockwise and pull out. Push bulb into socket, turn counterclockwise and remove. Insert new bulb in socket, push in and twist clockwise. Reinstall bulb socket.


Parking and standing lamp W 5W Open hood. Press the clamp and remove headlamp cover (2). Pull out bulb socket (6). Remove bulb from socket. Insert new bulb in socket and push in. Reinstall bulb socket. Align headlamp cover (2) and click into place.


Taillamp assemblies


Open trunk lid. Fold trim to the side. Turn locking lever (1) to vertical position and remove bulb carrier. Push bulb into socket, turn counterclockwise and remove. Insert new bulb in socket, push in and twist clockwise. Reinstall bulb socket. Reinstall trim.


2 Driver’s side: rear fog lamp (P 21 W/32 cp bulb)


3 Backup lamp (P 21 W/32 cp bulb) 4 Stop lamp (P 21 W/32 cp bulb) 5 Turn signal lamp (PY 21 W bulb [yellow]) 6 tail, parking, standing and


side marker lamp (R 5 W/4 cp bulb)


Exterior lamps


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


329


Instruments and controls


Exterior lamps


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


330


High mounted stop lamp, Additional turn signals on the exterior mirror The high mounted stop lamp (3rd brake lamp), and the additional turn signals on the exterior mirrors are equipped with LEDs. Have the system checked at an authorized Mercedes-Benz Center if a malfunction occurs.


License plate lamp


Loosen both securing screws (1), remove lamp and replace tubular lamp (C 5 W/4 cp).


Trunk lamp The trunk lamp will switch off after approximately 10 minutes if the trunk lid is left open.


Standby bulb function a) The stop lamps, dimmed, will act as a replacement lamp, if one taillamp stops working. b) The left stop lamp acts as a replacement for the rear fog lamp, if it stops working. c) The respective fog lamp, dimmed, will act as a replacement lamp, if the left or right standing lamp stops working.


Notes: The multifunction display will indicate that a bulb has failed. See malfunction and warning messages on page 274.


Trunk lamp


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


331


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Electronic main key


332


Changing batteries in the electronic main key


P80.20-2201-26


P80.35-2029-26


1 Transmit buttons 2 Lamp for battery check and function control


Changing batteries Move locking tab (3) in direction of right arrow and remove mechanical key (4, left arrow).


Checking batteries If one of the transmit buttons (1) is pressed, the battery check lamp (2) lights up briefly – indicating that the batteries are in order. Change batteries if the battery check lamp (2) does not light up briefly.


5


P80.35-2025-26


Insert mechanical key (4) in side opening (5) to open latch. Press briefly (do not use mechanical key as lever) to release battery compartment. Remove mechanical key from side opening. Carefully remove battery compartment in direction of arrow (6).


P80.35-2027-26


Change batteries (7), inserting new ones under contact spring (8) with plus (+) side facing up. Return battery compartment into housing until locked in place and slide mechanical key back into electronic main key.


Electronic main key


333


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Emergency engine shut-down


334


Important! Batteries contain materials that can harm the environment if disposed of improperly. Recycling of batteries is the preferred method of disposal. For disposal, please follow manufacturer’s recommendation on battery package. Replacement Battery: Lithium, type CR 2025 or equivalent.


Synchronizing remote control The remote control may have to be resynchronized, if the vehicle cannot be locked or unlocked. To synchronize insert electronic key in starter switch. The remote control should once again be operational.


Emergency engine shut-down If the engine can no longer be stopped using the electronic key, the engine can be turned off by removing two fuses. For easy removal of fuses use the fuse extractor (located in the auxiliary fuse box in the trunk) to pull out the fuses marked on the fuse chart as “ENGINE EMERGENCY OFF”. The fuse chart is located in the fuse box in the passenger compartment. For fuses see page 295.


Fuel filler flap, manual release


Emergency operation of sliding/pop-up roof


Open the trunk lid and fold right-side taillamp trim aside. Reach inside and pull the release knob (arrow). Open the fuel filler flap.


The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur. The sliding/pop-up roof drive is located behind the lens (1) of the interior overhead light.


Emergency engine shut-down


335


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Emergency engine shut-down


336


Slide both locking tabs (2) in direction of arrow, lower rear of cover and remove.


Note: Do not disconnect electrical connectors.


Obtain crank (3) (supplied with vehicle) and insert through hole. To slide roof closed or to raise the roof at the rear: turn crank clockwise. To slide the roof open or to lower the roof at the rear: turn crank counterclockwise. See page 188 for instructions on synchronizing the sliding/pop-up roof after closing manually.


Replacing wiper blade inserts For safety reasons, remove electronic key from steering lock before replacing the wiper blades, otherwise the motor can suddenly turn on and cause injury.


Notes: Do not open engine hood with wiper arm folded forward. Do not allow the wiper arm to contact the windshield glass without a wiper blade inserted. The glass may be scratched or broken. Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage.


Removal: Fold wiper arm forward. Press safety tab down (1), push wiper blade downward (2) and remove.


Replacing wiper blade insert


337


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Replacing wiper blade insert


338


Roof rack


Place wiper blade on firm support. Press down both tabs and slide (direction of arrow) the wiper blade insert out of the retainer claws. Installation: Slide (direction of arrow) wiper blade insert into retainer claws until tabs are engaged. Slide wiper blade onto wiper arm until it locks in place.


Only mount roof racks to the fastening bolts (see arrows) located under the door weatherstrips. Use only those roof racks approved by Mercedes-Benz to avoid damage to the vehicle. Follow manufacturer’s installation instructions.


Vehicle care


Cleaning and care of


the vehicle ..................................340
Power washer ..............................341
Tar stains .....................................341
Paintwork, painted body components .................................341
Engine cleaning ..........................342
Vehicle washing .........................342
Ornamental moldings ................343
Headlamps, taillamps, turn signal lenses ...........................................343


Window cleaning ....................... 343
Wiper blade ................................ 343
Light alloy wheels ..................... 344
Instrument cluster ..................... 344
Steering wheel and gear selector lever ............................................. 344
Cup holder .................................. 344
Seat belts ..................................... 345
Headliner and shelf below rear window ........................................ 345
Leather upholstery .................... 345
Hard plastic trim items ............. 345
Plastic and rubber parts ........... 345


Contents - Vehicle care


339


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Cleaning and care of the vehicle


340


Cleaning and care of the vehicle


Warning! Many cleaning products can be hazardous. Some are poisonous, others are flammable. Always follow the instructions on the particular container. Always open your vehicle’s doors or windows when cleaning the inside. Never use fluids or solvents that are not designed for cleaning your vehicle.


In operation, your vehicle is subjected to varying external influences which, if gone unchecked, can attack the paintwork as well as the underbody and cause lasting damage. Such damage is caused not only by extreme and varying climatic conditions, but also by air polution, road salt, tar, gravel and stone chipping. Grease and oil, fuel, coolant, brake fluid, bird droppings, insects, tree resins etc. should be removed immediately to avoid paint damage. Frequent washing reduces and/or eli minates the aggressiveness and potency of the above adverse influences.


More frequent washings are necessary to deal with unfavorable conditions; for example, near the ocean, in industrial areas (smoke, exhaust emissions), or during winter operation. You should check your vehicle from time to time for stone chipping or other damage. Any damage should be repaired as soon as possible to prevent the start of corrosion. In doing so, do not neglect the underside of the vehicle. A prerequisite for a thorough check is a washing of the underbody followed by a thorough inspection. Damaged areas need to be reundercoated. Your vehicle has been treated at the factory with a wax- base rustproofing in the body cavities which will last for the lifetime of the vehicle. Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later. We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at your authorized Mercedes-Benz Center.


Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here. In such cases it is best to seek aid at your authorized Mercedes-Benz Center. The following topics deal with the cleaning and care of your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care products. Additional information can be found in the booklet titled “Vehicle Care Guide”.


Power washer When using a power washer for cleaning the vehicle always observe manufacturer’s operating instructions.


Caution! Never use a round nozzle to power wash tires. The intense jet of water can result in damage to the tire. Always replace a damaged tire. Always keep the jet of water moving across the surface. Do not aim directly at electrical parts, electrical connectors, seals, or other rubber parts.


Tar stains Quickly remove tar stains before they dry and become more difficult to remove. A tar remover is recommended.


Paintwork, painted body components Mercedes-Benz approved Paint Care should be applied when water drops on the paint surface do not “bead up”, normally in 3 to 5 months, depending on climate and washing detergent used. Mercedes-Benz approved Paint Cleaner should be applied if paint surface shows signs of dirt embedding (i.e. loss of gloss). Do not apply any of these products or wax if your vehicle is parked in the sun or if the hood is still hot. Use the appropriate MB-Touch-Up Stick for quick and provisional repairs of minor paint damage (i.e. chips from stones, vehicle doors etc.).


Cleaning and care of the vehicle


341


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Cleaning and care of the vehicle


342


Engine cleaning Prior to cleaning the engine compartment make sure to protect electrical components and connectors from the intrusion of water and cleaning agents. Corrosion protection, such as MB Anticorrosion Wax should be applied to the engine compartment after every engine cleaning. Before applying, all control linkage bushings and joints should be lubricated. The poly-V-belt and all pulleys should be protected from any wax.


Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Use only a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo. Thoroughly spray the vehicle with a diffused jet of water. Direct only a very weak spray towards the ventilation intake. Use plenty of water and rinse the sponge and chamois frequently. Rinse with clear water and thoroughly wipe dry with a chamois. Do not allow cleaning agents to dry on the finish. Due to the width of the vehicle, prior to running the vehicle through an automatic car wash, fold back the outside mirrors to prevent them from getting damaged. In the winter, thoroughly remove all traces of road salt as soon as possible. When washing the underbody, do not forget to clean the inner sides of the wheels.


Ornamental moldings For regular cleaning and care of very dirty chrome- plated parts, use a chrome cleaner.


Window cleaning Use a window cleaning solution on all glass surfaces. An automotive glass cleaner is recommended.


Headlamps, taillamps, turn signal lenses Use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo, with plenty of water. To prevent scratches, never apply strong force and use only a soft, non-scratchy cloth when cleaning the lenses. Do not attempt to wipe dirty lenses with a dry cloth or sponge.


Note: For safety reasons, switch off wipers and remove electronic key from starter switch before cleaning the windshield, otherwise the wiper motor can suddenly turn on and cause injury.


Wiper blades Clean the wiper blade rubbers with a clean cloth and detergent solution.


Note: For safety reasons, remove electronic key from starter switch before cleaning the wiper blades, otherwise the wiper motor can suddenly turn on and cause injury.


Cleaning and care of the vehicle


343


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Cleaning and care of the vehicle


344


Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes- Benz approved Wheel Care, using a soft bristle brush and a strong spray of water. Follow instructions on container.


Note: Use only acid-free cleaning materials. The acid could lead to corrosion.


Instrument cluster Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution. Do not use scouring agents.


Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care.


Cup holder Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution. Do not use scouring agents.


Seat belts The webbing must not be treated with chemical cleaning agents. Use only clear, lukewarm water and soap. Do not dry the webbing at temperatures above 176°F (80°C) or in direct sunlight.


Warning! Do not bleach or dye seat belts as this may severely weaken them. In a crash they may not be able to provide adequate protection.


Headliner and shelf below rear window Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt.


Leather upholstery Using aftermarket seat covers or wearing clothing that have the tendency to give off coloring (e.g. when wet etc.) may cause the upholstery to become permanently discolored. By lining the seats with a proper intermediate cover, contact-discoloration will be prevented. Leather Upholstery Wipe leather upholstery with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Exercise particular care when cleaning perforated leather as its underside should not become wet. MB Tex Upholstery Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure.


Hard plastic trim items Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure.


Plastic and rubber parts Do not use oil or wax on these parts.


Cleaning and care of the vehicle


345


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Technical data


Spare parts service ........................348
Warranty coverage .........................348
Identification labels .......................349
Layout of poly-V-belt drive ............350
Technical data ................................351
Fuels, coolants, lubricants etc. -


capacities ...................................355
Engine oils ......................................357


Engine oil additives ...................... 357
Air conditioner refrigerant .......... 357
Brake fluid ...................................... 357
Premium unleaded gasoline ........ 358
Fuel requirements ........................ 358
Gasoline additives ......................... 359
Coolants .......................................... 359
Consumer information ................. 361
Uniform tire quality grading ....... 361


Contents - Technical data


347


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Technical data


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Spare parts service All authorized Mercedes-Benz Centers maintain a stock of original spare parts required for maintenance and repair work. In addition, strategically located parts distribution centers provide quick and reliable parts service. More than 300 000 different spare parts, for Mercedes-Benz models, are available. Mercedes-Benz original spare parts are subjected to stringent quality inspections. Each part has been specifically developed, manufactured or selected for and adapted to Mercedes-Benz vehicles. Therefore, Mercedes-Benz original spare parts should be installed.


Important! The use of non-genuine parts and accessories not authorized by Mercedes-Benz could damage the vehicle which damage is not covered by the Mercedes-Benz Limited Warranty or compromise its durability or safety.


348


Warranty coverage Your vehicle is covered under the terms of the “warranties” printed in the Service and Warranty Information booklet and your authorized Mercedes-Benz Center will exchange or repair any defective parts originally installed on the vehicle in accordance with the terms of the following warranties:


1. New vehicle limited warranty 2. Emission systems warranty 3. Emission performance warranty 4. California, Massachusetts, and Vermont emission


control systems warranty


Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center.


Loss of Service and Warranty Information Booklet Should you lose your Service and Warranty Information booklet, have your authorized Mercedes-Benz Center arrange for a replacement. It will be mailed to you.


Identification labels


1 Certification label


2 Vehicle Identification Number (VIN)


(below right rear passenger seat)


Technical data


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


349


Instruments and controls


Technical data


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


350


Layout of poly-V-belt drive


3 VIN, visible (lower edge of windshield) 4 Engine number 5 Emission control label 6 Information label, California version


Vacuum line routing for emission control system


When ordering spare parts, please specify vehicle identification and engine numbers.


1 Automatic belt tensioner 2 Crankshaft 3 Air conditioner compressor 4 Generator (alternator) 5 Idler pulley 6 Power steering pump 7 Coolant pump, fan


Technical data


Model Engine Mode of operation No. of cylinders Bore Stroke Total piston displacement Compression ratio Output acc. to SAE J 1349


C 240 (203.0611) 112.912
4-stroke engine, gasoline injection 3.54 in (89.90 mm) 2.68 in (68.20 mm) 158,5 cu.in. (2597 cm3) 10:1
167 hp/6000 rpm (125 kW/6000 rpm) Maximum torque acc. to SAE J 1349 130 ft.lb/4500 rpm (240 Nm/4500 rpm) 6200 rpm 1-4-3-6-2-5
2390 mm


Maximum engine speed Firing order Poly-V-belt


C 320 (203.0641) 112.946
4-stroke engine, gasoline injection 3.54 in (89.90 mm) 3.30 in (84.00 mm) 195.2 cu.in. (3199 cm3) 10:1
221 hp/5600 rpm (165 kW/5600 rpm) 232 ft.lb/3000 rpm (315 Nm/3000 rpm) 6000 rpm 1-4-3-6-2-5
2390 mm


1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies


and special equipment.


Technical data


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


351


Instruments and controls


Technical data


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


352


Rims — Tires


Model Rims (light alloy) Wheel offset: All season tires: Radial-ply tires Winter tires: Radial-ply tires


Spare wheel Rim (light alloy) Wheel offset: All season tires: Radial-ply tires


C 240 (203.061) 7J x 16 H2
1.46 in (37 mm)


C 320 (203.064) 7J x 16 H2
1.46 in (37 mm)


C 240 (Canada only – incl. spare wheel) (steel rims) 61/2 J x 16 H2
1.46 in (37 mm)


205/55 R16 91 H


205/55 R16 91 H


205/55 R 16 91 H


205/55 R16 91 H M+S


205/55 R16 91 H M+S


205/55 R 16 91 H M+S


7J x 16 H2
1.46 in (37 mm)


7J x 16 H2
1.46 in (37 mm)


205/55 R16 91 H


205/55 R16 91 H


Electrical system


Model Generator (alternator) Starter motor Battery Spark plugs


Electrode gap Tightening torque


Weights


Roof load max. Trunk load max.


C 240 (203.061) 14 V/120 A 12V/1.7 kW 12V/100 Ah Bosch F 8 DPER Beru 14 FGH 8 DPUR X 2
NGK IFR 5 D 10
0.039 in (1.0 mm) 15 – 22 ft.lb (20 – 30 Nm)


C 320 (203.064) 14 V/120 A 12V/1.7 kW 12V/100 Ah Bosch F 8 DPER Beru 14 FGH 8 DPUR X 2
NGK IFR 5 D 10
0.039 in (1.0 mm) 15 – 22 ft.lb (20 – 30 Nm)


220 lb (100 kg) 220 lb (100 kg)


Technical data


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


353


Instruments and controls


Technical data


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


354


Main Dimensions


Model


Overall vehicle length Overall vehicle width Overall vehicle height Wheel base Track, front Track, rear


C 240 (203.061) C 320 (203.064) 178.2 in (4526 mm) 68.0 in (1728 mm) 56.1 in (1426 mm) 106.9 in (2715 mm) 59.3 in (1505 mm) 58.1 in (1476 mm)


Fuels, coolants, lubricants etc. - capacities


Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.


Engine with oil filter Automatic transmission Rear axle Power steering Front wheel hubs Accelerator control linkage Brake system Cooling system Fuel tank


Capacity 8.5 US qt (8.0 l) 8.5 US qt (8.0 l) 1.2 US qt (1.1 l) approx. 1.1 US qt (1.0 l) approx. 2.1 oz (60 g) each


approx. 0.5 US qt (0.5 l) approx. 9.5 US qt (10.5 l) 16.4 US gal (62.0 l)


including a reserve of


2.1 US gal (8.0 l)


Fuels, coolants, lubricants etc. Recommended engine oils Automatic transmission fluid Hypoid gear oil SAE 85 W 90
MB Power steering fluid High temperature roller bearing grease Hydraulic fluid MB Brake fluid (DOT 4+) MB Anticorrosion/antifreeze Premium unleaded gasoline: Posted Octane 91
(Avg. of 96 RON/86 MON)


Fuels, coolants, lubricants etc. - capacities


355


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Fuels, coolants, lubricants etc. - capacities


356


Air conditioner system


Windshield washer and headlamp cleaning system


Capacity


Vehicles without headlamp cleaning system: Capacity approx. 3.2 US qt (3.0 l) Vehicles with headlamp cleaning system: Capacity approx. 6.4 US qt (6.0 l)


Fuels, coolants, lubricants etc. R-134a refrigerant and special PAG lubricant (Never R-12) MB Windshield washer concentrate1


1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and


commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing. Follow suggested mixing ratios, see page 303.


Engine oils Engine oils are specifically tested for their suitability in our engines. Therefore, use only engine oils recommended by Mercedes-Benz. Information on recommended brands is available at your authorized Mercedes-Benz Center. Please follow Service Booklet recommendations for scheduled oil changes. Failure to do so could result in engine damage not covered by the Mercedes-Benz Limited Warranty.


Engine oil additives Do not blend oil additives with engine oil. They may be harmful to the engine operation. Damage or malfunctions resulting from blending oil additives are not covered by the Mercedes-Benz Limited Warranty.


Air conditioner refrigerant R-134a (HFC) refrigerant and special PAG lubricating oil is used in the air conditioner system. Never use R-12 (CFC) or mineral-based lubricating oil, otherwise damage to the system will occur.


Brake fluid During vehicle operation, the boiling point of the brake fluid is continuously reduced through the absorption of moisture from the atmosphere. Under extremely hard operating conditions, this moisture content can lead to the formation of bubbles in the system thus reducing the system’s efficiency. The brake fluid must therefore be replaced every two years, preferably in the spring. It is recommended to use only brake fluid approved by Mercedes-Benz. Your authorized Mercedes-Benz Center will provide you with additional information.


Fuels, coolants, lubricants etc. - capacities


357


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Fuels, coolants, lubricants etc. - capacities


358


Premium unleaded gasoline


Caution! To maintain the engine’s durability and performance, premium unleaded gasoline must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: • have the fuel tank filled only partially with unleaded regular and fill up with premium unleaded as soon as possible,


• avoid full throttle driving and abrupt acceleration, • do not exceed an engine speed of 3000 rpm, if the


vehicle is loaded with a light load such as two persons and no luggage,


• do not exceed 2/3 of maximum accelerator pedal


position, if the vehicle is fully loaded or operating in mountainous terrain.


Fuel requirements Use only Premium unleaded meeting ASTM standard D 439: The octane number (posted at the pump) must be 91 min. It is an average of both the Research (R) octane number and the Motor (M) octane number: (R+M)/2). This is also known as ANTI-KNOCK INDEX. Unleaded gasoline containing oxygenates such as Ethanol, IPA, IBA and TBA can be used provided the ratio of any one of these oxygenates to gasoline does not exceed 10%, MTBE not to exceed 15%. The ratio of Methanol to gasoline must not exceed 3% plus additional cosolvents. Using mixtures of Ethanol and Methanol is not allowed. Gasohol, which contains 10% Ethanol and 90% unleaded gasoline, can be used. These blends must also meet all other fuel requirements such as resistance to spark knock, boiling range, vapor pressure etc.


Gasoline additives A major concern among engine manufacturers is carbon build up caused by gasoline. Mercedes-Benz recommends the use of only quality gasoline containing additives that prevent the build up of carbon deposits. After an extended period of using fuels without such additives, carbon deposits can build up especially on the intake valves and in the combustion area, leading to engine performance problems such as: • warm-up hesitation, • unstable idle, • knocking/pinging, • misfire, • power loss. Do not blend other specific fuel additives with fuel. They only result in unnecessary cost, and may be harmful to the engine operation. Damage or malfunctions resulting from poor fuel quality or from blending specific fuel additives are not covered by the Mercedes-Benz Limited Warranty.


Coolants The engine coolant is a mixture of water and anticorrosion/antifreeze, which provides: • corrosion protection, • freeze protection, • boiling protection (by increasing the boiling point). The cooling system was filled at the factory with a coolant providing freeze protection to approximately - 22°F (- 30°C) and corrosion protection. If the antifreeze mixture is effective to - 22°F (- 30°C), the boiling point of the coolant in the pressurized cooling system is reached at approximately 266°F (130°C). The coolant solution must be used year round to provide the necessary corrosion protection and increase in the boil-over protection. You should have it replaced every 3 years. To provide the important corrosion protection, the solution must be at least 45% anticorrosion/antifreeze (equals a freeze protection to approximately - 22°F (- 30°C). If you use a solution that is more than 55% anticorrosion/antifreeze (freeze protection to approximately - 49°F (- 45°C), the engine temperature


Fuels, coolants, lubricants etc. - capacities


359


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care


Technical


data


Index


Instruments and controls


Operation


Driving


Instrument cluster display


Practical hints


Car care

Loading...
x
