2013 Jeep Grand Cherokee Owners Manual

Download PDF Manual
2 0 1 3 O W N E R ’ S M A N U A L Grand Cherokee Chrysler Group LLC 13WK741-126-AE Fifth Edition Printed in U.S.A. VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefore. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents. Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated non- drinking driver, call a cab, a friend, or use public trans- portation. WARNING! Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower, and your judgment is impaired when you have been drinking. Never drink and then drive. This manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment de- scribed in this manual that are not on this vehicle. Chrysler Group LLC reserves the right to make changes in design and specifications, and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products pre- viously manufactured. Copyright © 2013 Chrysler Group LLC SECTION TABLE OF CONTENTS PAGE INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 UNDERSTANDING THE FEATURES OF YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115 UNDERSTANDING YOUR INSTRUMENT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297 STARTING AND OPERATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 433 6 WHAT TO DO IN EMERGENCIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 581 7 MAINTAINING YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 605 8 MAINTENANCE SCHEDULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 663 10 IF YOU NEED CONSUMER ASSISTANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 671 INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681 10 INTRODUCTION CONTENTS 䡵 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . .4 䡵 ROLLOVER WARNING . . . . . . . . . . . . . . . . . . .5 䡵 HOW TO USE THIS MANUAL . . . . . . . . . . . . . .6 䡵 WARNINGS AND CAUTIONS . . . . . . . . . . . . . .8 䡵 VEHICLE IDENTIFICATION NUMBER . . . . . . . .8 䡵 VEHICLE MODIFICATIONS/ALTERATIONS . . . .9 4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This is a specialized utility vehicle. It can go places and perform tasks that conventional passenger cars are not intended. It handles and maneuvers differently from many passenger cars both on-road and off-road, so take time to become familiar with your vehicle. The two-wheel drive version of this vehicle was designed for on-road use only. It is not intended for off-road driving or use in other severe conditions suited for a four-wheel drive vehicle. Before you start to drive this vehicle, read the Owner’s Manual. Be sure you are familiar with all vehicle controls, particularly those used for braking, steering, transmis- sion, and transfer case shifting. Learn how your vehicle handles on different road surfaces. Your driving skills will improve with experience. When driving off-road or working the vehicle, don’t overload the vehicle or expect the vehicle to overcome the natural laws of physics. Always observe federal, state, provincial and local laws wherever you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or a collision. Refer to “On-Road/Off-Road Driving Tips” in “Starting And Operating” for further information. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by Warranty Information, and various customer-oriented documents. Please take the time to read these publications carefully. Following the instruc- tions and recommendations in this manual will help assure safe and enjoyable operation of your vehicle. NOTE: After reviewing the owner information, it should be stored in the vehicle for convenient referenc- ing and remain with the vehicle when sold. When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained tech- nicians and genuine MOPAR® parts, and cares about your satisfaction. ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many passenger cars. It is capable of performing better in a wide variety of off-road applications. Driven in an unsafe man- ner, all vehicles can go out of control. Because of the higher center of gravity, if this vehicle is out of control it may roll over when some other vehicles may not. INTRODUCTION 5 Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this vehicle safely may result in a collision, rollover of the vehicle, and severe or fatal injury. Drive carefully. Rollover Warning Label 6 INTRODUCTION Failure to use the driver and passenger seat belts pro- vided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Always buckle up. HOW TO USE THIS MANUAL Consult the Table of Contents to determine which section contains the information you desire. Since the specification of your vehicle depends on the items of equipment ordered, certain descriptions and illustrations may differ from your vehicle’s equipment. The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects. Consult the following table for a description of the symbols that may be used on your vehicle or throughout this Owner’s Manual: INTRODUCTION 7 8 INTRODUCTION WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information. Observe all Warnings and Cau- tions. VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on a plate located on the left front corner of the instrument panel pad, visible from outside of the vehicle through the windshield. This number also is stamped into the right front body, behind the right front seat. Move the right front seat forward to allow better viewing of the stamped VIN. This number also appears on the Automobile Information Disclosure Label affixed to a window on your vehicle. Save this label for a convenient record of your vehicle identifi- cation number and optional equipment. VIN Location VEHICLE MODIFICATIONS/ALTERATIONS INTRODUCTION 9 WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Right Front Body VIN Location NOTE: It is illegal to remove or alter the VIN. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS 䡵 A WORD ABOUT YOUR KEYS . . . . . . . . . . . . .14 ▫ Wireless Ignition Node (WIN) . . . . . . . . . . . . .14 ▫ Key Fob . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 ▫ Removing Key Fob From Ignition . . . . . . . . . .16 ▫ Key-In-Ignition Reminder . . . . . . . . . . . . . . . .18 䡵 SENTRY KEY® . . . . . . . . . . . . . . . . . . . . . . . . .19 ▫ Replacement Keys . . . . . . . . . . . . . . . . . . . . .20 ▫ Customer Key Programming . . . . . . . . . . . . . .20 ▫ General Information . . . . . . . . . . . . . . . . . . . .20 䡵 VEHICLE SECURITY ALARM — IF EQUIPPED . . . . . . . . . . . . . . . . . . . . . . . . . .21 ▫ Rearming The System . . . . . . . . . . . . . . . . . . .21 ▫ To Arm The System. . . . . . . . . . . . . . . . . . . . .21 ▫ To Disarm The System . . . . . . . . . . . . . . . . . . .22 ▫ Tamper Alert . . . . . . . . . . . . . . . . . . . . . . . . .23 䡵 ILLUMINATED ENTRY . . . . . . . . . . . . . . . . . . .23 䡵 REMOTE KEYLESS ENTRY (RKE) . . . . . . . . . . .24 ▫ To Unlock The Doors. . . . . . . . . . . . . . . . . . . .25 ▫ To Lock The Doors . . . . . . . . . . . . . . . . . . . . .26 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Using The Panic Alarm . . . . . . . . . . . . . . . . . .26 ▫ Programming Additional Transmitters. . . . . . . .27 ▫ Transmitter Battery Replacement . . . . . . . . . . .27 ▫ General Information . . . . . . . . . . . . . . . . . . . .29 䡵 REMOTE STARTING SYSTEM — IF EQUIPPED . . . . . . . . . . . . . . . . . . . . . . . . . .29 ▫ How To Use Remote Start . . . . . . . . . . . . . . . .30 䡵 DOOR LOCKS . . . . . . . . . . . . . . . . . . . . . . . . .34 ▫ Power Door Locks . . . . . . . . . . . . . . . . . . . . .35 ▫ Child-Protection Door Lock System — Rear Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 䡵 KEYLESS ENTER-N-GO™ . . . . . . . . . . . . . . . . .38 䡵 WINDOWS . . . . . . . . . . . . . . . . . . . . . . . . . . .42 ▫ Power Windows . . . . . . . . . . . . . . . . . . . . . . .42 ▫ Wind Buffeting . . . . . . . . . . . . . . . . . . . . . . .46 䡵 LIFTGATE . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 ▫ Liftgate Flipper Glass . . . . . . . . . . . . . . . . . . .47 ▫ Power Liftgate — If Equipped . . . . . . . . . . . . .48 䡵 OCCUPANT RESTRAINTS . . . . . . . . . . . . . . . .51 ▫ Lap/Shoulder Belts . . . . . . . . . . . . . . . . . . . .55 ▫ Lap/Shoulder Belt Operating Instructions . . . . .56 ▫ Lap/Shoulder Belt Untwisting Procedure . . . . .59 ▫ Adjustable Upper Shoulder Belt Anchorage . . .60 ▫ Seat Belts In Passenger Seating Positions . . . . . .61 ▫ Automatic Locking Retractor Mode (ALR) — If Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 ▫ Energy Management Feature . . . . . . . . . . . . . .63 ▫ Seat Belt Pretensioners . . . . . . . . . . . . . . . . . .63 ▫ Supplemental Active Head Restraints (AHR) . . .63 ▫ Enhanced Seat Belt Use Reminder System (BeltAlert®) . . . . . . . . . . . . . . . . . . . . . . . . . .67 ▫ Seat Belt Lock Out. . . . . . . . . . . . . . . . . . . . . .68 ▫ Seat Belts And Pregnant Women . . . . . . . . . . .68 ▫ Seat Belt Extender . . . . . . . . . . . . . . . . . . . . .68 ▫ Supplemental Restraint System (SRS) — Air Bags . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 ▫ Advanced Front Air Bag Features . . . . . . . . . . .71 ▫ Air Bag Deployment Sensors And Controls . . . .75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 ▫ Event Data Recorder (EDR) . . . . . . . . . . . . . . .82 ▫ Child Restraints . . . . . . . . . . . . . . . . . . . . . . .83 䡵 ENGINE BREAK-IN RECOMMENDATIONS . . .108 䡵 SAFETY TIPS . . . . . . . . . . . . . . . . . . . . . . . . .109 ▫ Transporting Passengers . . . . . . . . . . . . . . . ..109 ▫ Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . . . .110 ▫ Safety Checks You Should Make Inside The Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111 ▫ Periodic Safety Checks You Should Make Outside The Vehicle . . . . . . . . . . . . . . .113 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the Key Fob into the ignition switch with either side up. Keyless Enter-N-Go™ Feature This vehicle is equipped with the Keyless Enter-N-Go™ feature, refer to “Starting Procedures” in “Starting And Operating” for further information. Wireless Ignition Node (WIN) The Wireless Ignition Node (WIN) operates similar to an ignition switch. It has four operating positions, three of which are detented and one spring-loaded. The detented positions are OFF, ACC, and ON/RUN. The START position is a spring-loaded momentary contact position. When released from the START position, the switch automatically returns to the detented ON/RUN position. NOTE: With the Keyless Enter-N-Go™ feature, the Elec- tronic Vehicle Information Center (EVIC) will display the ignition switch position (OFF/ACC/RUN). Refer to “Elec- tronic Vehicle Information Center (EVIC)” in “Understand- ing Your Instrument Panel” for further information. 2 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle on the driver’s side should the battery in the vehicle or the RKE transmitter go dead. The emergency key is also for locking the glove box. You can keep the emergency key with you when valet parking. NOTE: Entering a vehicle using the emergency key with the security alarm armed, will result in the alarm sound- ing. Insert the Key Fob (even if the Key Fob battery is dead) into the ignition switch to disarm security alarm. Wireless Ignition Node (WIN) 1 — OFF 2 — ACC (ACCESSORY) 3 — ON/RUN 4 — START 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand. Emergency Key Removal NOTE: You can insert the double-sided emergency key into the lock cylinders with either side up. Removing Key Fob From Ignition Place the shift lever in PARK. Turn the Key Fob to the OFF position and then remove the Key Fob. With the Keyless Enter-N-Go™ feature, the EVIC will display the ignition switch position “OFF/ACC/RUN”. Refer to “Electronic Vehicle Information Center (EVIC)” in “Understanding Your Instrument Panel” for further information. NOTE: • If you try to remove the Key Fob before you place the shift lever in PARK, it may become trapped temporar- ily in the ignition switch. If this occurs, rotate the key to the right slightly, then remove the Key Fob as described. If a malfunction occurs, the system will trap the key in the ignition switch to warn you that this safety feature is inoperable. The engine can be started and stopped, but the Key Fob cannot be removed until you obtain service. • The power window switches, radio, power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition switch is turned to the OFF position. Opening either front door will cancel this feature. The time for this feature is programmable. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information. CAUTION! • If your vehicle battery becomes low or dead, your Key Fob will become locked in the ignition. • Do not attempt to remove the Key Fob while in this condition, damage could occur to the Key Fob or ignition module. Only remove the emergency key for locking and unlocking the doors. (Continued) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 CAUTION! (Continued) • Leave the Key Fob in the ignition and either: • Jump Start the vehicle. • Charge the battery. WARNING! • When leaving the vehicle, always remove the Key Fob from the vehicle and lock your vehicle. • Never leave children alone in a vehicle, or with access to an unlocked vehicle. • Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Chil- dren should be warned not to touch the parking brake, brake pedal or the shift lever. (Continued) 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not leave the Key Fob in or near the vehicle, or in a location accessible to children, and do not leave a vehicle equipped with Keyless Enter-N- Go™ in the ACC or ON/RUN mode. A child could operate power windows, other controls, or move the vehicle. • Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may cause serious injury or death. CAUTION! An unlocked car is an invitation to thieves. Always remove Key Fob from the ignition and lock all doors when leaving the vehicle unattended. Key-In-Ignition Reminder Opening the driver’s door when the Key Fob is in the ignition and the ignition switch position is OFF or ACC, sounds a signal to remind you to remove the Key Fob. NOTE: The Key-In-Ignition reminder only sounds when the Key Fob is placed in the OFF or ACC ignition position. With the Keyless Enter-N-Go™ feature, opening the driver’s door when the vehicle’s ignition switch is placed in ACC or ON/RUN (engine stopped) will cause the reminder chime to sound. Refer to “Starting Procedures” in “Starting And Operating” for further information. SENTRY KEY® The Sentry Key® Immobilizer system prevents unauthor- ized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked. The system uses the factory-mated Key Fob with Remote Keyless Entry (RKE) transmitter and Wireless Ignition Node (WIN) to prevent unauthorized vehicle operation. Therefore, only Key Fobs that are programmed to the vehicle can be used to start and operate the vehicle. The system will shut the engine off in two seconds if an invalid Key Fob is used to start the engine. After turning the ignition switch to the ON/RUN posi- tion, the Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the light begins to flash after THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 the bulb check, it indicates that someone used an invalid Key Fob to start the engine. Either of these conditions will result in the engine being shut off after two seconds. If the Vehicle Security Light turns on during normal vehicle operation (vehicle running for longer than 10 sec- onds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon as possible by an authorized dealer. CAUTION! • Do not make modifications or alterations to the immobilizer system. Modifications or alterations to the immobilization system may result in a loss of security protection. • The Sentry Key® Immobilizer system is not com- patible with some after-market remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE All of the Key Fobs provided with your new vehicle have been programmed to the vehicle electronics. Replacement Keys NOTE: Only Key Fobs that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Key Fob is programmed to a vehicle, it cannot be programmed to any other vehicle. CAUTION! • Always remove the Key Fobs from the vehicle and lock all doors when leaving the vehicle unat- tended. • For vehicles equipped with Keyless Enter-N-Go™, always remember to place the ignition in the OFF position. At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). Keep the PIN in a secure location. This number is required for authorized dealer replacement of Key Fobs. Duplication of Key Fobs may be performed at an autho- rized dealer, this procedure consists of programming a blank Key Fob to the vehicle electronics. A blank Key Fob is one that has never been programmed. NOTE: When having the Sentry Key® Immobilizer Sys- tem serviced, bring all vehicle keys with you to an authorized dealer. Customer Key Programming Programming Key Fobs or RKE transmitters may be performed at an authorized dealer. General Information The Sentry Key® system complies with FCC rules Part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference that may be received, including interference that may cause unde- sired operation. VEHICLE SECURITY ALARM — IF EQUIPPED This Vehicle Security Alarm monitors the vehicle doors, liftgate, liftgate flipper glass, and ignition for unauthor- ized operation. When the alarm is activated, the interior switches for door locks, power liftgate and flipper glass are disabled. The Vehicle Security Alarm provides both audio and visual signals, the horn will sound, the head- lights will turn on, park lamps and/or turn signals will flash repeatedly for three minutes. If the disturbance is still present (driver’s door, passenger door, other doors, ignition) after three minutes, the headlights, park lamps and/or turn signals will flash for an additional 15 min- utes. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 NOTE: The Panic and Security alarms are quite differ- ent. Please take a moment to activate the Panic and the Security modes to hear the differences in the horn. In case one should go off in the future, you will need to know which mode has been activated in order to deactivate it. Rearming The System If something triggers the alarm, and no action is taken to disarm it, the Vehicle Security Alarm will turn off the horn after three minutes, turn off all of the visual signals after 15 minutes, and then the Vehicle Security Alarm will rearm itself. To Arm The System Follow these steps to arm the Vehicle Security Alarm: 1. Remove the key from the ignition system (refer to ⬙Starting Procedures⬙ in ⬙Starting And Operating⬙ for further information). vehicle: 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles equipped with Keyless Enter-N-Go™, make sure the vehicle ignition system is ⬙OFF⬙. • For vehicles not equipped with Keyless Enter-N-Go™, make sure the vehicle ignition system is ⬙OFF⬙ and the key is physically removed from the ignition. 2. Perform one of the following methods to lock the • Press LOCK on the interior power door lock switch with the driver and/or passenger door open. • Press the LOCK button on the exterior Passive Entry Door Handle with a valid Key Fob available in the same exterior zone (refer to ⬙Keyless Enter-N-Go™⬙ in ⬙Things To Know Before Starting Your Vehicle⬙ for further infor- mation). • Press the LOCK button on the Remote Keyless Entry (RKE) transmitter. 3. If any doors are open, close them. Entry (RKE) transmitter. To Disarm The System The Vehicle Security Alarm can be disarmed using any of the following methods: • Press the UNLOCK button on the Remote Keyless • Grasp the Passive Entry Unlock Door Handle (if equipped, refer to ⬙Keyless Enter-N-Go™⬙ in ⬙Things To Know Before Starting Your Vehicle⬙ for further information). • Cycle the vehicle ignition system out of the OFF position. • For vehicles equipped with Keyless Enter-N-Go™, press the Keyless Enter-N-Go™ Start/Stop button (requires at least one valid Key Fob in the vehicle). • For vehicles not equipped with Keyless Enter-N- Go™, insert a valid key into the ignition switch and turn the key to the ON position. NOTE: • The driver’s door key cylinder and the liftgate button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm. • The Vehicle Security Alarm remains armed during power liftgate entry. Pressing the liftgate button will not disarm the Vehicle Security Alarm. If someone enters the vehicle through the liftgate and opens any door the alarm will sound. • When the Vehicle Security Alarm is armed, the interior power door lock switches will not unlock the doors. The Vehicle Security Alarm is designed to protect your vehicle; however, you can create conditions where the system will give you a false alarm. If one of the previ- ously described arming sequences has occurred, the Vehicle Security Alarm will arm regardless of whether THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 you are in the vehicle or not. If you remain in the vehicle and open a door, the alarm will sound. If this occurs, disarm the Vehicle Security Alarm. If the Vehicle Security Alarm is armed and the battery becomes disconnected, the Vehicle Security Alarm will remain armed when the battery is reconnected; the exterior lights will flash, the horn will sound. If this occurs, disarm the Vehicle Security Alarm. Tamper Alert If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times and the exterior lights blink three times when you unlock the doors. Check the vehicle for tampering. ILLUMINATED ENTRY The courtesy lights will turn on when you use the Remote Keyless Entry (RKE) transmitter to unlock the doors or open any door. 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This feature also turns on the approach lighting in the outside mirrors (if equipped). Refer to “Mirrors” in “Understanding The Features Of Your Vehicle” for fur- ther information. The lights will fade to off after approximately 30 seconds or they will immediately fade to off once the ignition switch is turned to ON/RUN from the OFF position. NOTE: • The front courtesy overhead console and door cour- tesy lights do not turn on if the dimmer control is in the ⬙Dome ON⬙ position (extreme top position). • The Illuminated Entry system will not operate if the is in the “Dome defeat” position dimmer control (extreme bottom position). REMOTE KEYLESS ENTRY (RKE) This system allows you to lock or unlock the doors and liftgate, or activate the panic alarm, from distances up to approximately 66 ft (20 m) using a hand-held Key Fob with RKE transmitter. The RKE transmitter does not need to be pointed at the vehicle to activate the system. NOTE: Inserting the Key Fob with RKE transmitter into the ignition switch disables the system from responding to any button presses from that RKE transmitter. Driving at speeds 5 mph (8 km/h) and above disables the system from responding to all RKE transmitter buttons for all RKE transmitters. 2 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 Refer to “Keyless Enter-N-Go™” under “Things To Know Before Starting Your Vehicle” for further information. Remote Unlock Sequence This feature lets you program the system to unlock either the driver’s door or all doors, on the first press of the UNLOCK button on the RKE transmitter. To change the current setting, refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer- Program- mable Features)” in “Understanding Your Instrument Panel” for further information. Flash Lamps With Lock This feature will cause the turn signal lamps to flash when the doors are locked or unlocked with the RKE transmitter. This feature can be turned on or off. To change the current setting, refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer- Programmable Features)” in “Understanding Your In- strument Panel” for further information. Key Fob With Five-Button RKE Transmitter To Unlock The Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door or twice to unlock all doors. The turn signal lamps will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Illuminated Approach This feature activates the headlights for up to 90 seconds when the doors are unlocked with the RKE transmitter. The time for this feature is programmable on vehicles equipped with the Electronic Vehicle Information Center (EVIC). Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Fea- tures)” in “Understanding Your Instrument Panel” for further information. To Lock The Doors Press and release the LOCK button on the RKE transmit- ter to lock all doors. The turn signal lamps will flash and the horn will chirp to acknowledge the signal. Refer to “Keyless Enter-N-Go™” under “Things To Know Before Starting Your Vehicle” for further information. Sound Horn With Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter or the Passive Entry feature. The horn chirp feature can be turned on or off. To change the current setting, refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer- Programmable Features)” in “Understanding Your In- strument Panel” for further information. Using The Panic Alarm To turn the Panic Alarm feature on or off, press and hold the PANIC button on the RKE transmitter for at least one second and release. When the Panic Alarm is on, the headlights turn on, the park lamps will flash, the horn will pulse on and off, and the interior lights will turn on. The Panic Alarm will stay on for three minutes unless you turn it off by either pressing the PANIC button a second time, or drive the vehicle at a speed of 15 mph (24 km/h) or greater. NOTE: The interior lights will turn off if you turn the ignition switch to the ACC or ON/RUN position while the Panic Alarm is activated. However, the exterior lamps and horn will remain on. Programming Additional Transmitters Programming Key Fobs or RKE transmitters may be performed at an authorized dealer. Transmitter Battery Replacement The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. • Do not touch the battery terminals that are on the back See www.dtsc.ca.gov/hazardouswaste/perchlorate housing or the printed circuit board. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 1. Remove the emergency key by sliding the mechanical latch at the top of the RKE transmitter sideways with your thumb and then pull the key out with your other hand. Emergency Key Removal 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the tip of the emergency key or a #2 flat blade screwdriver into the slot and gently pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal. Inserting Emergency Key Into Slot Separating RKE Transmitter 3. Remove and replace the battery. When replacing the battery, match the + sign on the battery to the + sign on the inside of the battery clip, located on the back cover. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 4. To assemble the RKE transmitter case, snap the two halves together. General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration. NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1. A weak battery in the RKE transmitter. The expected life of the battery is a minimum of three years. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios. REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conve- niently from outside the vehicle while still maintaining security. The system has a range of approximately 300 ft (91 m). NOTE: • The vehicle must be equipped with an automatic • Obstructions between the vehicle and RKE transmitter transmission to be equipped with Remote Start. may reduce this range. 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use Remote Start All of the following conditions must be met before the engine will remote start: • Shift lever in PARK • Doors closed • Hood closed • Liftgate/Flipper Glass closed • Hazard switch off • Brake switch inactive (brake pedal not pressed) • Ignition key removed from ignition switch • Battery at an acceptable charge level • RKE PANIC button not pressed • System not disabled from previous remote start event • Vehicle theft alarm not active • Ignition in Off position for Keyless Enter-N-Go™ • Fuel level meets minimum requirement vehicle WARNING! • Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Mon- oxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious in- jury or death when inhaled. • Keep Remote Keyless Entry (RKE) transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause serious injury or death. Remote Start Abort Message On Electronic Vehicle Information Center (EVIC) — If Equipped The following messages will display in the EVIC if the vehicle fails to remote start or exits remote start prema- turely: • Remote Start Aborted — Door Ajar • Remote Start Aborted — Hood Ajar • Remote Start Aborted — Fuel Low • Remote Start Aborted — Liftgate Ajar • Remote Start Disabled — Start Vehicle To Reset The EVIC message stays active until the ignition is turned to the ON/RUN position. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 To Enter Remote Start Mode Press and release the REMOTE START button on the RKE transmitter twice within five sec- onds. The vehicle doors will lock, the parking lights will flash and the horn will chirp twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15 minute cycle. NOTE: • If an engine fault is present or fuel level is low, the vehicle will start and then shut down in 10 seconds. • The park lamps will turn on and remain on during • For security, power window and power sunroof op- eration (if equipped) are disabled when the vehicle is in the Remote Start mode. Remote Start mode. 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The engine can be started two consecutive times with the RKE transmitter. However, the ignition must be cycled by pushing the START/STOP button twice (or the ignition switch must be cycled to the ON/RUN position) before you can repeat the start sequence for a third cycle. To Exit Remote Start Mode Without Driving The Vehicle Press and release the REMOTE START button one time or allow the engine to run for the entire 15 minute cycle. NOTE: To avoid unintentional shutdowns, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request. To Exit Remote Start Mode And Drive The Vehicle Before the end of 15 minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped). Then, prior to the end of the 15 minute cycle, press and release the START/STOP button. the START/STOP button is not present, insert the Key Fob into the ignition switch and turn the switch to the ON/RUN position. If NOTE: • For vehicles not equipped with the Keyless Enter-N- Go™ feature, the ignition switch must be in the ON/RUN position in order to drive the vehicle. • For vehicles not equipped with the Keyless Enter-N- Go™ feature, the message “Remote Start Active — Insert Key and Turn To Run” will display in the EVIC until you insert the key. Refer to “Electronic Vehicle Information Center (EVIC)” for further information. • For vehicles equipped with the Keyless Enter-N-Go™ feature, the message “Remote Start Active — Push Start Button” will display in the EVIC until you push the START button. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 is activated, Remote Start Comfort Systems — If Equipped When remote start the heated steering wheel, and driver heated seat features will automatically turn on in cold weather. In warm weather, the driver vented seat feature will automatically turn on when the remote start is activated. These features will stay on through the duration of remote start or until the ignition switch is turned to the ON/RUN position. The Remote Start Comfort System can be activated and deactivated through the Electronic Vehicle Information Center (EVIC). For more information on Remote Start Comfort System operation refer to “Electronic Vehicle Information Center (EVIC)/Customer-Programmable Features (SETUP)” in “Understanding Your Instrument Panel”. 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS The power door locks can be manually locked from inside the vehicle by using the door lock knob. To lock each door, push the door lock knob on each door trim panel downward. To unlock the front doors, pull the inside door handle to the first detent. To unlock the rear doors, pull the door lock knob on the door trim panel upward. If the lock knob is down when the door is closed, the door will lock. Therefore, make sure the key is not inside the vehicle before closing the door. Manual Door Lock Knob WARNING! • For personal security and safety in the event of a collision, lock the vehicle doors when you drive, as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the Key Fob from the ignition and lock your vehicle. • Never leave children alone in a vehicle, or with access to an unlocked vehicle. • Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Chil- dren should be warned not to touch the parking brake, brake pedal or the shift lever. • Do not leave the Key Fob in or near the vehicle, and do not leave Keyless Enter-N-Go™ in the ACC or ON/RUN mode. A child could operate power win- dows, other controls, or move the vehicle. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Power Door Locks The power door lock switch is located on each front door panel. Press the switch to lock or unlock the doors. Power Door Lock Switch If the lock knob is down when the door is closed, the door will lock. Therefore, make sure the Key Fob is not inside the vehicle before closing the door. 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the door lock switch while the Key Fob is in the ignition switch and the driver’s door is open, the doors will not lock. If a rear door is locked, it cannot be opened from inside the vehicle without first unlocking the door. The door may be unlocked manually by raising the lock knob. Automatic Door Locks — If Equipped When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 15 mph (24 km/h). The auto door lock feature can be enabled or disabled by your authorized dealer . Please see your authorized dealer for service. Automatic Unlock On Exit Feature — If Equipped If Auto Unlock is enabled, this feature will unlock all the doors when the driver’s door is opened if the vehicle is stopped and in PARK or NEUTRAL. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information. Child-Protection Door Lock System — Rear Doors To provide a safer environment for small children riding in the rear seats, the rear doors are equipped with Child-Protection Door Lock system. To Engage Or Disengage The Child-Protection Door Lock System 1. Open the rear door. 2. Insert the tip of the emergency key into the lock and rotate to the LOCK or UNLOCK position. 3. Repeat steps 1 and 2 for the opposite rear door. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Child-Protection Door Lock Location Child-Protection Door Lock Function WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged (locked). 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For emergency exit from the rear seats when the Child-Protection Door Lock System is engaged, manually raise the door lock knob to the unlocked position, roll down the window, and open the door using the outside door handle. KEYLESS ENTER-N-GO™ The Passive Entry system is an enhancement to the vehicle’s Remote Keyless Entry (RKE) system and a feature of Keyless Enter-N-Go™. This feature allows you to lock and unlock the vehicle’s door(s) without having to press the RKE transmitter lock or unlock buttons. NOTE: • Passive Entry may be programmed ON/OFF; refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Un- derstanding Your Instrument Panel” for further informa- tion. • If a Passive Entry door handle has not been used for 72 hours, the Passive Entry feature for the handle may time out. Pulling the deactivated front door handle will reactivate the door handle’s Passive Entry feature. • If wearing gloves on your hands, or if it has been raining on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower re- sponse time. To Unlock From The Driver’s Side: With a valid Passive Entry RKE transmitter within 5 ft (1.5 m) of the driver’s door handle, grab the driver’s front door handle to unlock the driver’s door automatically. The interior door panel lock knob will raise when the door is unlocked. 2 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Door 1st Press” and “Unlock All Doors 1st Press”, refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Under- standing Your Instrument Panel” for further information. To Unlock From The Passenger Side: With a valid Passive Entry RKE transmitter within 5 ft (1.5 m) of the passenger door handle, grab the front passenger door handle to unlock all four doors automati- cally. The interior door panel lock knob will raise when the door is unlocked. NOTE: All doors will unlock when the front passenger door handle is grabbed regardless of the driver’s door unlock preference setting (“Unlock Driver Door 1st Press” or “Unlock All Doors 1st Press”). Grab The Door Handle To Unlock NOTE: If “Unlock All Doors 1st Press” is programmed all doors will unlock when you grab hold of the driver’s front door handle. To select between “Unlock Driver 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Preventing Inadvertent Locking Of Passive Entry RKE Transmitter In Vehicle To minimize the possibility of unintentionally locking a Passive Entry RKE transmitter inside your vehicle, the Passive Entry system is equipped with an automatic door unlock feature which will function if there is no Key Fob present in the ignition. If one of the vehicle doors is open and the door panel switch is used to lock the vehicle, once all open doors have been closed the vehicle checks the inside and outside of the vehicle for any valid Passive Entry RKE transmitters. If one of the vehicle’s Passive Entry RKE transmitters is detected inside the vehicle, and no other valid Passive Entry RKE transmitters are detected out- side the vehicle, the Passive Entry System automatically unlocks all vehicle doors and chirps the horn three times (on the third attempt ALL doors will lock and the Passive Entry RKE transmitter can be locked in the vehicle). To Enter The Liftgate With a valid Passive Entry RKE transmitter within 3 ft (1.0 m) of the liftgate, press the button on the right side of the chrome accent bar, which is located on the liftgate below the liftgate glass to lock or unlock the vehicle. Liftgate Passive Entry Button NOTE: If “Unlock All Doors 1st Press” is programmed in EVIC, all doors will unlock when you push the button on the liftgate. If ⬙Unlock Driver Door 1st press⬙ is programmed in EVIC, the liftgate will unlock when you press the button on the liftgate For further information, refer to “Electronic Vehicle Information Center (EVIC)/ Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel”. To Lock The Vehicle’s Doors With one of the vehicle’s Passive Entry RKE transmitters within 5 ft (1.5 m) of the driver or passenger front door handle, press the door handle LOCK button to lock all four doors and liftgate. Do NOT grab the door handle, when pressing the door handle lock button. This could unlock the door(s). THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Press The Door Handle Button To Lock 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Do NOT Grab The Door Handle When Locking NOTE: • After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking. • The Passive Entry system will not operate if the RKE transmitter battery is dead. The vehicle doors can also be locked by using the RKE transmitter lock button or the lock button located on the vehicle’s interior door panel. WINDOWS Power Windows The power window controls are located on the driver’s door trim panel. There is a single switch on the front passenger door and rear doors which operate the front passenger and rear passenger door windows. The win- dow controls will operate only when the ignition switch is in the ON/RUN or ACC position. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 WARNING! Never leave children in a vehicle with the key in or near the vehicle, or leave a vehicle with Keyless Enter-N-Go™ in the ACC or ON/RUN position. Oc- cupants, particularly unattended children, can be- come entrapped by the windows while operating the power window switches. Such entrapment may re- sult in serious injury or death. Auto-Down Both the driver and front passenger window switches have an “Auto-Down” feature. Press the window switch past the first detent, release, and the window will go down automatically. To cancel the “Auto-Down” move- ment, operate the switch in either the up or down direction and release the switch. Power Window Switches The power window switches remain active for up to 10 minutes after the ignition switch has been turned OFF. Opening a vehicle front door will cancel this feature. 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To open the window part way, press to the first detent and release it when you want the window to stop. To stop the window from going all the way up during the Auto Up operation, push down on the switch briefly. To close the window part way, lift the window switch to the first detent and release when you want the window to stop. Auto Down Window Switches Auto Up Feature With Anti-Pinch Protection — Driver And Front Passenger Door Only Lift the window switch fully upward to the second detent, release, and the window will go up automatically. Auto Up Window Switches THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 NOTE: If the window runs into any obstacle during Auto Up it will reverse direction and then go back down. Remove the obstacle and use the window switch again to close the window. Any impact due to rough road condi- tions may trigger the auto reverse function unexpectedly during Auto Up. If this happens, pull the switch lightly to the first detent and hold it to close the window manually. Resetting The Auto Up Feature Should the Auto Up feature stop working, the window probably needs to be reset. To reset Auto Up: 1. Pull the window switch up to close the window completely and continue to hold the switch up for an additional two seconds after the window is closed. WARNING! There is no anti-pinch protection when the window is almost closed. Be sure to clear all objects from the window before closing. 2. Push the window switch down firmly to the second detent to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open. 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Button The Window Lockout button on the driver’s door allows you to disable the window controls on the rear doors. To disable the window controls on the rear doors, press the Window Lockout button. To enable the window controls, press the Window Lockout button again. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occur- rence and can be minimized. If the buffeting occurs with the rear windows open, then open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sun- roof opening to minimize the buffeting. LIFTGATE To open the liftgate, pull up on the handle and lift. Manually unlocking the vehicle doors with the plunger or a key in the lock cylinder will not unlock the liftgate. Window Lockout Button THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Liftgate Flipper Glass The liftgate flipper glass is also unlocked when the liftgate is unlocked. To open the flipper glass, push up on the window switch located on the liftgate. NOTE: The liftgate flipper glass will not open if the liftgate is ajar. Liftgate Release WARNING! Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your pas- sengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. Liftgate Glass Release 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Once the liftgate flipper glass has been opened, connec- tion to the rear window wiper is interrupted, preventing activation of the rear wiper blade while the flipper glass is open. NOTE: If a malfunction to the liftgate latch should occur, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the liftgate trim panel. WARNING! Driving with the flipper glass open can allow poi- sonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the flipper glass closed when you are operating the vehicle. Power Liftgate — If Equipped The power liftgate may be opened by pulling up on the liftgate handle or by pressing the LIFTGATE button on the Remote Keyless Entry (RKE) transmitter. Press the LIFTGATE button on the RKE transmitter twice within five seconds, to open the power liftgate. Once the liftgate is open, pressing the button twice within five seconds a second time will close the liftgate. The power liftgate may also be opened or closed by pressing the LIFTGATE button located on the front overhead console, or closed by pressing the LIFTGATE button located on left rear trim, near the liftgate opening. Pressing the LIFTGATE button located on left rear trim once will close the liftgate only, this button cannot be used to open the liftgate. To operate the power liftgate manually in the open direction, pull the liftgate handle once to initiate a power cycle and then pull the handle a second time to put liftgate into manual mode. When the LIFTGATE button on the RKE transmitter is pressed two times, the turn signals will flash twice to signal that the liftgate is opening or closing (if Flash Lamps with Lock is enabled in the EVIC) and the liftgate chime will be audible. For further information, refer to ⬙Customer-Programmable Features (System Setup)/ Electronic Vehicle Information Center (EVIC)⬙ in ⬙Under- standing Your Instrument Panel⬙. NOTE: • In the event of a power malfunction to the liftgate, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the lift- gate trim panel. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • If liftgate is left open for an extended period of time, the liftgate may need to be closed manually to reset power liftgate functionality. WARNING! During power operation, personal injury or cargo damage may occur. Ensure the liftgate travel path is clear. Make sure the liftgate is closed and latched before driving away. NOTE: • The power liftgate buttons will not operate if the vehicle is in gear or the vehicle speed is above 0 mph (0 km/h). • The power liftgate will not operate in temperatures below −22°F (−30°C) or temperatures above 150°F (65°C). Be sure to remove any buildup of snow or ice from the liftgate before pressing any of the power liftgate switches. 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If anything obstructs the power liftgate while it is closing or opening, the liftgate will automatically reverse to the closed or open position, provided it meets sufficient resistance. • There are also pinch sensors attached to the side of the liftgate. Light pressure anywhere along these strips will cause the liftgate to return to the open position. • The power liftgate must be in the full open position for rear liftgate close button on the left rear trim, near the liftgate opening to operate. If the liftgate is not fully open, press the Liftgate button on the Key Fob to fully open the liftgate, and then press it again to close. • If the liftgate handle is pulled while the power liftgate is closing, the liftgate will reverse to the full open position. • If the liftgate handle is pulled while the power liftgate is opening, the liftgate motor will disengage to allow manual operation. • If the power liftgate encounters multiple obstructions within the same cycle, the system will automatically stop and the liftgate must be opened or closed manually. • If your liftgate is power closing and you put the vehicle in gear, the liftgate will continue to power close. However, vehicle movement may result in a detection of an obstruction. WARNING! • Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. (Continued) WARNING! (Continued) • If you are required to drive with the liftgate open, make sure that all windows are closed, and the climate control blower switch is set at high speed. Do not use the recirculation mode. Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems: • Three-point lap and shoulder belts for the driver and • Advanced Front Air Bags for driver and front all passengers passenger THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 • Supplemental Active Head Restraints (AHR) located on top of the front seats (integrated into the head restraint) • Supplemental Driver Side Knee Air Bag • Supplemental Side Air Bag Inflatable Curtains (SABIC) for the driver and passengers seated next to a window • Supplemental Seat-Mounted Side Air Bags (SAB) • An energy-absorbing steering column and steering wheel • Knee bolsters for front seat occupants • Front seat belts incorporate pretensioners that may enhance occupant protection by managing occupant energy during an impact event • All seat belt systems (except the driver’s) include Auto- matic Locking Retractors (ALRs), which lock the seat belt webbing into position by extending the belt all the way out and then adjusting the belt to the desired length to restrain a child seat or secure a large item in a seat — if equipped 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Please pay close attention to the information in this section. It tells you how to use your restraint system properly, to keep you and your passengers as safe as possible. If you will be carrying children too small for adult-sized seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold infant and child restraint systems. For more information on LATCH, refer to Lower Anchors and Tether for CHildren (LATCH). NOTE: The Advanced Front Air Bags have a multistage inflator design. This allows the air bag to have different rates of inflation based on several factors, including the severity and type of collision. Here are some simple steps you can take to minimize the risk of harm from a deploying air bag: 1. Children 12 years old and under should always ride buckled up in a rear seat. WARNING! Infants in rear facing child restraints should never ride in the front seat of a vehicle with a passenger Ad- vanced Front Air Bag. An air bag deployment can cause severe injury or death to infants in that position. Children that are not big enough to wear the vehicle seat belt properly (see section on Child Restraints) should be secured in the rear seat in child restraints or belt- positioning booster seats. Older children who do not use child restraints or belt-positioning booster seats should ride properly buckled up in the rear seat. Never allow children to slide the shoulder belt behind them or under their arm. If a child from 1 to 12 years old (not in a rear facing child seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint. (Refer to “Child Restraints”) You should read the instructions provided with your child restraint to make sure that you are using it properly. 2. All occupants should always wear their lap and shoulder belts properly. 3. The driver and front passenger seats should be moved back as far as practical to allow the Advanced Front Air Bags room to inflate. 4. Do not lean against the door or window. If your vehicle has side air bags, and deployment occurs, the side air bags will inflate forcefully into the space between you and the door. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 5. If the air bag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center. Phone numbers are provided under ⴖIf You Need Assistanceⴖ. WARNING! • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won’t deploy at all. Always wear your seat belts even though you have air bags. (Continued) 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Being too close to the steering wheel or instrument panel during Advanced Front Air Bag deployment could cause serious injury, including death. Air Bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel. • Supplemental Side Air Bag Inflatable Curtain (SABIC) and Seat-Mounted Side Air Bags (SAB) also need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat. (Continued) WARNING! (Continued) • In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly. • Being too close to the Supplemental Side Air Bag Inflatable Curtain (SABIC) and/or Seat-Mounted Side Air Bag (SAB) during deployment could cause you to be severely injured or killed. Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision that includes you. This can happen far away from home or on your own street. Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. The belt webbing retractor is de- signed to lock during very sudden stops or collisions. This feature allows the shoulder part of the belt to move freely with you under normal conditions. However, in an collision the belt will lock and reduce the risk of you striking the inside of the vehicle or being thrown out. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 WARNING! • Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of a collision the best. Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your passengers safe, too. • Two people should never be belted into a single seat belt. People belted together can crash into one another in a collision, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size. (Continued) 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • It is dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. • Be sure everyone in your vehicle is in a seat and using a seat belt properly. Lap/Shoulder Belt Operating Instructions Latch Plate 1. Enter the vehicle and close the door. Sit back and adjust the seat. 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you prop- erly. In a sudden stop you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly. Latch Plate to Buckle (Continued) 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries. Ribs aren’t as strong as shoulder bones. Wear the belt over your shoulder so that your stron- gest bones will take the force in a collision. • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together. 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision. WARNING! • A lap belt worn too high can increase the risk of injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdo- men. Always wear the lap part of your seat belt as low as possible and keep it snug. • A twisted belt may not protect you properly. In a collision, it could even cut into you. Be sure the belt is straight. If you can’t straighten a belt in your vehicle, take it to your authorized dealer immedi- ately and have it fixed. 5. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retrac- tor will withdraw any slack in the belt. Removing Slack From Belt 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow it to retract fully. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assem- blies must be replaced after a collision if they have been damaged (bent retractor, torn webbing, etc.). Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate. 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate. 4. Continue to slide the latch plate up until it clears the folded webbing. Adjustable Upper Shoulder Belt Anchorage In the front seating positions, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Press the release button to release the anchorage, and then move it up or down to the position that fits you best. Adjusting Upper Shoulder Belt As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you will prefer a higher position. When you release the button, verify the shoulder belt anchorage is latched by pulling downward on the shoulder belt anchorage until it is locked into position. NOTE: The adjustable upper shoulder belt anchorage is equipped with an Easy Up feature. This feature allows the shoulder belt anchorage to be adjusted in the upward position without pushing the release button. To verify the shoulder belt anchorage is latched, pull downward on the shoulder belt anchorage until it is locked into position. Seat Belts In Passenger Seating Positions The seat belts in the passenger seating positions are equipped with Automatic Locking Retractors (ALR) which are used to secure a child restraint system. For additional information, refer to “Installing Child Re- straints Using The Vehicle Seat Belt” under the “Child Restraints” section. The chart below defines the type of feature for each seating position. First Row Second Row Driver N/A ALR Center N/A ALR Passenger ALR ALR THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • N/A — Not Applicable • ALR — Automatic Locking Retractor If the passenger seating position is equipped with an ALR and is being used for normal usage: Only pull the belt webbing out far enough to comfortably wrap around the occupant’s mid-section so as to not activate the ALR. If the ALR is activated, you will hear a ratcheting sound as the belt retracts. Allow the webbing to retract completely in this case and then carefully pull out only the amount of webbing necessary to comfort- ably wrap around the occupant’s mid-section. Slide the latch plate into the buckle until you hear a ⬙click.⬙ Automatic Locking Retractor Mode (ALR) — If Equipped In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The Automatic Locking Mode is available on 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE all passenger-seating positions with a combination lap/ shoulder belt. Use the Automatic Locking Mode anytime a child safety seat is installed in a seating position that has a belt with this feature. Children 12 years old and under should always be properly restrained in the rear seat. How To Engage The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the Automatic Locking Mode. How To Disengage The Automatic Locking Mode Unbuckle the combination lap/shoulder belt and allow it to retract completely to disengage the Automatic Locking Mode and activate the vehicle sensitive (emergency) locking mode. WARNING! • The belt and retractor assembly must be replaced if the seat belt assembly Automatic Locking Retractor (ALR) feature or any other seat belt function is not working properly when checked according to the procedures in the Service Manual. • Failure to replace the belt and retractor assembly could increase the risk of injury in collisions. Energy Management Feature This vehicle has a safety belt system with an Energy Management feature in the front seating positions to help further reduce the risk of injury in the event of a head-on collision. This safety belt system has a retractor assembly that is designed to release webbing in a controlled manner. This feature is designed to help reduce the belt force acting on the occupant’s chest. Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision. Pretensioners work for all size occu- pants, including those in child restraints. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the Occupant Re- straint Controller (ORC). Like the air bags, the preten- sioners are single use items. A deployed pretensioner or a deployed air bag must be replaced immediately. Supplemental Active Head Restraints (AHR) These head restraints are passive, deployable compo- nents, and vehicles with this equipment cannot be readily identified by any markings, only through visual inspec- tion of the head restraint. The head restraint will be split in two halves, with the front half being soft foam and trim, the back half being decorative plastic. 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How The Active Head Restraints (AHR) Work The Occupant Restraint Controller (ORC) determines whether the severity, or type of rear impact will require the Active Head Restraints (AHR) to deploy. If a rear impact requires deployment, both the driver and front passenger seat AHRs will be deployed. When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts. NOTE: The Active Head Restraints (AHR) may or may not deploy in the event of a front or side impact. However if during a front impact, a secondary rear impact occurs, the AHR may deploy based on the sever- ity and type of the impact. Active Head Restraint (AHR) Components 1 — Head Restraint Front Half (Soft Foam and Trim) 2 — Seatback 3 — Head Restraint Back Half (Decorative Plastic Rear Cover) 4 — Head Restraint Guide Tubes CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision. NOTE: For more information on properly adjusting and positioning the head restraint, refer to “Adjusting Active Head Restraints” in “Understanding The Features Of Your Vehicle”. Resetting Active Head Restraints (AHR) If the Active Head Restraints are triggered in a collision, you must reset the head restraint on the driver’s and front passenger seat. You can recognize when the Active Head Restraint has been triggered by the fact that they have moved forward (as shown in step three of the resetting procedure). THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 1. Grasp the deployed AHR from the rear seat. Hand Positioning Points On AHR 2. Position the hands on the top of the deployed AHR at a comfortable position. 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. 1 — Downward Movement 2 — Rearward Movement 3 — Final Downward Movement To Engage Locking Mechanism 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. 2 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Enhanced Seat Belt Use Reminder System (BeltAlert®) BeltAlert® is a feature intended to remind the driver and front passenger (if equipped with front passenger BeltAlert®) to fasten their seat belts. The feature is active whenever the ignition is on. If the driver or front seat passenger is unbelted, the Seat Belt Reminder Light will turn on and remain on until both front seat belts are fastened. The BeltAlert® warning sequence begins after the vehicle speed is over 5 mph (8 km/h), by blinking the Seat Belt Reminder Light and sounding an intermittent chime. Once the sequence starts, it will continue for the entire duration or until the respective seatbelts are fastened. After the sequence completes, the Seat Belt Reminder Light remains illuminated until the respective seat belts are fastened. The driver should instruct all other occu- pants to fasten their seat belts. If a front seat belt is AHR In Reset Position Head Restraints, see an authorized dealer. NOTE: • If you have difficulties or problems resetting the Active • For safety reasons, have the Active Head Restraints checked by a qualified specialist at an authorized dealer. 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE unbuckled while traveling at speeds greater than 5 mph (8 km/h), BeltAlert® will provide both audio and visual notification. The front passenger seat BeltAlert® is not active when the front passenger seat is unoccupied. BeltAlert® may be triggered when an animal or heavy object is on the front passenger seat or when the seat is folded flat (if equipped). It is recommended that pets be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts, and cargo is properly stowed. BeltAlert® can be enabled or disabled by your autho- rized dealer. Chrysler Group LLC does not recommend deactivating BeltAlert®. NOTE: Although BeltAlert® has been deactivated, the Seat Belt Reminder Light will continue to illuminate while the driver’s or front passenger (if equipped with BeltAlert®) seat belt remains unfastened. Seat Belt Lock Out The center rear seat belt system has a lock out feature that will not allow you to extract the center webbing unless the rear seat upper latch is engaged. Seat Belts And Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug across the hips as possible. Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision. Seat Belt Extender If a seat belt is too short even when fully extended and when the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, your authorized dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not long enough. When it is not required, remove the ex- tender and store it. WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug and in the recommended seating posi- tions. Remove and store the extender when not needed. Supplemental Restraint System (SRS) — Air Bags This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s Advanced Front Air Bag is mounted in the center of the steering wheel. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 The passenger’s Advanced Front Air Bag is mounted in the instrument panel, above the glove compartment. The words SRS AIRBAG are embossed on the air bag covers. Advanced Front Air Bag And Knee Bolster Locations 1 — Driver And Passenger Advanced Front Air Bags 2 — Knee Bolster 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Driver and Front Passenger Advanced Front Air Bags are certified to the new Federal regulations for Advanced Air Bags. The Advanced Front Air Bags have a multistage inflator design. This allows the air bag to have different rates of inflation based on several factors, including the severity and type of collision. This vehicle may be equipped with driver and/or front passenger seat track position sensors that may adjust the inflation rate of the Advanced Front Air Bags based upon seat position. This vehicle may be equipped with a driver and/or front passenger seat belt buckle switch that detects whether the driver or front passenger seat belt is fastened. The seat belt buckle switch may adjust the inflation rate of the Advanced Front Air Bags. This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABIC) to protect the driver, front, and rear passengers sitting next to a window. The SABIC air bags, are located above the side windows and their covers are also labeled: SRS AIRBAG. This vehicle is equipped with Supplemental Seat- Mounted Side Air Bags (SAB) to provide enhanced protection for an occupant during a side impact. The Supplemental Seat-Mounted Side Air Bags are located in the outboard side of the front seats. NOTE: • Air Bag covers may not be obvious in the interior trim, • After any collision, the vehicle should be taken to an but they will open during air bag deployment. authorized dealer immediately. Air Bag System Components Your vehicle may be equipped with the following air bag system components: • Occupant Restraint Controller (ORC) • Air Bag Warning Light • Steering Wheel and Column • Instrument Panel • Knee Impact Bolster • Driver Advanced Front Air Bag • Passenger Advanced Front Air Bag • Supplemental Seat-Mounted Side Air Bags (SAB) • Supplemental Side Air Bag Inflatable Curtains (SABIC) • Supplemental Driver Side Knee Air Bag THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 • Front and Side Impact Sensors • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors Advanced Front Air Bag Features The Advanced Front Air Bag system has multistage driver and front passenger air bags. This system provides output appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), which may receive information from the front impact sensors. The first stage inflator is triggered immediately during an impact that requires air bag deployment. This low output is used in less severe collisions. A higher energy output is used for more severe collisions. 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • No objects should be placed over or near the air bag on the instrument panel, because any such objects could cause harm if the vehicle is in a collision severe enough to cause the air bag to inflate. • Do not put anything on or around the air bag covers or attempt to open them manually. You may damage the air bags and you could be injured because the air bags may no longer be functional. The protective covers for the air bag cushions are designed to open only when the air bags are inflating. • Do not drill, cut or tamper with the knee bolster in any way. • Do not mount any accessories to the knee bolster such as alarm lights, stereos, citizen band radios, etc. Supplemental Seat-Mounted Side Air Bags (SAB) Supplemental Seat-Mounted Side Air Bags (SAB) may provide enhanced protection to help protect an occupant during a side impact. The SAB is marked with an air bag label sewn into the outboard side of the front seats. Supplemental Seat-Mounted Side Air Bag Label When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only. Supplemental Side Air Bag Inflatable Curtain (SABIC) SABIC air bags may offer side-impact and vehicle roll- over protection to front and rear seat outboard occupants in addition to that provided by the body structure. Each air bag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side-impact head injuries. The SABIC deploy down- ward, covering both windows on the impact side. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Supplemental Side Air Bag Inflatable Curtain (SABIC) Label Location but they will open during air bag deployment. 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • Air Bag covers may not be obvious in the interior trim, • Being too close to the SAB and SABIC air bags during deployment could cause you to be severely injured or killed. • Should a vehicle rollover occur, the pretensioners and/or SAB and SABIC air bags on both sides of the vehicle may deploy. The system includes side impact sensors that are cali- brated to deploy the Supplemental Seat-Mounted Side Air Bags and SABIC air bags during impacts that require side air bag occupant protection. WARNING! • Your vehicle is equipped with left and right SABIC, do not stack luggage or other cargo up high enough to block the location of the SABIC. The area where the side curtain air bag is located should remain free from any obstructions. • Do not use accessory seat covers or place objects between you and the SAB; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. • Your vehicle is equipped with SABIC air bags, do not have any accessory items installed which will alter the roof, including adding a sunroof to your vehicle. Do not add roof racks that require perma- nent attachments (bolts or screws) for installation on the vehicle roof. Do not drill into the roof of the vehicle for any reason. Always sit upright as possible with your back against the seat back, use the seat belts properly, and use the appropriate sized child restraint, infant restraint or booster seat recommended for the size and weight of the child. Knee Impact Bolsters The Knee Impact Bolsters help protect the knees of the driver and the front passenger, and position front occu- pants for the best interaction with the Advanced Front Air Bag. Along with seat belts and pretensioners, Advanced Front Air Bags work with the knee bolsters to provide im- proved protection for the driver and front passenger. Side air bags also work with seat belts to improve occupant protection. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Air Bag Deployment Sensors And Controls Occupant Restraint Controller (ORC) The ORC is part of a Federally regulated safety system required for this vehicle. The ORC determines if deployment of the front and/or side air bags in a frontal or side collision is required. Based on the impact sensor’s signals, a central electronic ORC deploys the Advanced Front Air Bags, SABIC air bags, SAB air bags, and front seat belt pretensioners, as required, depending on several factors, including the severity and type of impact. Advanced Front Air Bags and Supplemental Driver and Front Passenger Knee Air Bags are designed to provide additional protection by supplementing the seat belts in certain frontal collisions depending on several factors, including the severity and type of collision. Advanced Front Air Bags are not expected to reduce the risk of injury in rear, side, or rollover collisions. 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bags and Supplemental Driver and Front Passenger Knee Air Bags will not deploy in all frontal collisions, including some that may produce sub- stantial vehicle damage — for example, some pole colli- sions, truck underrides, and angle offset collisions. On the other hand, depending on the type and location of impact, Advanced Front Air Bags may deploy in crashes with little vehicle front-end damage but that produce a severe initial deceleration. The side air bags will not deploy in all side collisions. Side air bag deployment will depend on the severity and type of collision. Because air bag sensors measure vehicle deceleration over time, vehicle speed and damage by themselves are not good indicators of whether or not an air bag should have deployed. Seat belts are necessary for your protection in all colli- sions, and also are needed to help keep you in position, away from an inflating air bag. The ORC monitors the readiness of the electronic parts of the air bag system whenever the ignition switch is in the START or ON/RUN position. If the key is in the OFF position, in the ACC position, or not in the ignition, the air bag system is not on and the air bags will not inflate. The ORC contains a backup power supply system that may deploy the air bags even if the battery loses power or it becomes disconnected prior to deployment. Also, the ORC turns on the Air Bag Warning Light in the instrument panel for approxi- mately four to eight seconds for a self-check when the ignition is first turned on. After the self-check, the Air Bag Warning Light will turn off. If the ORC detects a malfunction in any part of the system, it turns on the Air Bag Warning Light, either momentarily or continuously. A single chime will sound if the light comes on again after initial startup. It also includes diagnostics that will illuminate the instru- ment cluster Air Bag Warning Light if a malfunction is noted that could affect the air bag system. The diagnos- tics also record the nature of the malfunction. WARNING! Ignoring the Air Bag Warning Light in your instru- ment panel could mean you won’t have the air bags to protect you in a collision. If the light does not come on as a bulb check when the ignition is first turned on, stays on after you start the vehicle, or if it comes on as you drive, have an authorized dealer service the air bag system immediately. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Driver And Passenger Advanced Front Air Bag Inflator Units The Driver and Passenger Advanced Front Air Bag Inflator Units are located in the center of the steering wheel and on the right side of the instrument panel. When the ORC detects a collision requiring the Ad- vanced Front Air Bags, it signals the inflator units. A large quantity of non-toxic gas is generated to inflate the Advanced Front Air Bags. Different air bag inflation rates are possible, based on several factors, including the collision type and severity. The steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as the air bags inflate to their full size. The air bags fully inflate in about 50 to 70 milliseconds. This is about half of the time it takes to blink your eyes. The air bags then quickly deflate while helping to restrain the driver and front passenger. 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bag gas is vented through the vent holes in the sides of the air bag. In this way, the air bags do not interfere with your control of the vehicle. Supplemental Seat-Mounted Side Air Bag (SAB) Inflator Units The Supplemental Seat-Mounted Side Air Bags are de- signed to activate only in certain side collisions. The ORC determines if a side collision requires the side air bags to inflate, based on the severity and type of collision. Based on the severity and type of collision, the side air bag inflator on the crash side of the vehicle may be triggered, releasing a quantity of non-toxic gas. The inflating SAB exits through the seat seam into the space between the occupant and the door. The SAB fully inflate in about 10 milliseconds. The side air bag moves at a very high speed and with such a high force that it could injure you if you are not seated properly, or if items are positioned in the area where the side air bag inflates. This especially applies to children. Supplemental Side Air Bag Inflatable Curtain (SABIC) Inflator Units During collisions where the impact is confined to a particular area of the side of the vehicle, the ORC may deploy the SABIC air bags, depending on the severity and type of collision. In these events, the ORC will deploy the SABIC only on the impact side of the vehicle. A quantity of non-toxic gas is generated to inflate the SABIC. The inflating SABIC pushes the outside edge of the headliner out of the way and covers the window. The SABIC inflates in about 30 milliseconds (about one- quarter of the time that it takes to blink your eyes) with enough force to injure you if you are not belted and
