VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefor. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents. Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.


WARNING!


Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower, and your judgment is impaired when you have been drinking. Never drink and then drive.


This manual illustrates and describes the operation of features and equipment that are either standard or op- tional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle. Chrysler LLC reserves the right to make changes in design and specifications, and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previ- ously manufactured.


Copyright © 2008 Chrysler LLC


SECTION


TABLE OF CONTENTS


PAGE


INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11


UNDERSTANDING THE FEATURES OF YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77


UNDERSTANDING YOUR INSTRUMENT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185


STARTING AND OPERATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287


WHAT TO DO IN EMERGENCIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .399


MAINTAINING YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413


MAINTENANCE SCHEDULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 469


IF YOU NEED CONSUMER ASSISTANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .485


10


INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 495


10


INTRODUCTION


CONTENTS


䡵 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
䡵 Rollover Warning . . . . . . . . . . . . . . . . . . . . . . . . 5
䡵 How To Use This Manual . . . . . . . . . . . . . . . . . . 6


䡵 Warnings And Cautions . . . . . . . . . . . . . . . . . . . 8
䡵 Vehicle Identification Number . . . . . . . . . . . . . . . 8
䡵 Vehicle Modifications/Alterations . . . . . . . . . . . . 9


4 INTRODUCTION


INTRODUCTION This is a specialized utility vehicle designed for both on-road and off-road use. It can go places and perform tasks for which conventional two-wheel drive enclosed vehicles were not intended. It handles and maneuvers differently from many passenger cars both on-road and off-road, so take time to become familiar with your vehicle. The two-wheel drive utility vehicle was designed for on-road use only. It is not intended for off-road driving or use in other severe conditions suited for a four-wheel drive vehicle. Before you start to drive this vehicle, read the Owner’s Manual. Be sure you are familiar with all vehicle controls, particularly those used for braking, steering, transmis- sion, and transfer case shifting. Learn how your vehicle handles on different road surfaces. Your driving skills will improve with experience. When driving off-road or


working the vehicle, don’t overload the vehicle or expect the vehicle to overcome the natural laws of physics. Always observe federal, state, provincial and local laws wherever you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident. Refer to “On-Road/Off-Road Driving Tips” in Section 5 of this manual. This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully. Following the instruc- tions and recommendations in this manual will help assure safe and enjoyable operation of your vehicle.


NOTE: After you read the manual, it should be stored in the vehicle for convenient reference and remain with the vehicle when sold so that the new owner will be aware of all safety warnings. When it comes to service, remember that your authorized dealer knows your vehicle best, has the factory-trained technicians and genuine MOPAR威 parts, and is inter- ested in your satisfaction.


ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many passenger cars. It is capable of performing better in a wide variety of off-road applications. Driven in an unsafe manner, all vehicles can go out of control. Because of the higher center of gravity, if this vehicle is out of control it may roll over when some other vehicles may not.


INTRODUCTION 5


Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this vehicle safely may result in an accident, rollover of the vehicle, and severe or fatal injury. Drive carefully.


Rollover Warning Label


6 INTRODUCTION


Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Always buckle up.


HOW TO USE THIS MANUAL Consult the Table of Contents to determine which section contains the information you desire.


The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects. Consult the following table for a description of the symbols that may be used on your vehicle or throughout this Owner’s Manual:


INTRODUCTION 7


8 INTRODUCTION


WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information. Observe all Warnings and Cautions.


VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on a label located on the left front corner of the instrument panel pad, visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information Disclosure Label affixed to a window on your vehicle. Save this label for a convenient record of your vehicle identification number and optional equip- ment.


NOTE:


It is illegal to remove the VIN label.


VIN Location


VEHICLE MODIFICATIONS/ALTERATIONS


WARNING!


Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.


INTRODUCTION 9


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


CONTENTS


䡵 A Word About Your Keys . . . . . . . . . . . . . . . . . 14
▫ Wireless Ignition Node (WIN) . . . . . . . . . . . . . 14
▫ Integrated Ignition Key . . . . . . . . . . . . . . . . . 15
▫ Ignition Key Removal . . . . . . . . . . . . . . . . . . 15
▫ Key-In-Ignition Reminder . . . . . . . . . . . . . . . . 17
䡵 Sentry Key威 Immobilizer System . . . . . . . . . . . . 17
▫ Replacement Keys . . . . . . . . . . . . . . . . . . . . . 18
▫ Customer Key Programming . . . . . . . . . . . . . 19
▫ General Information . . . . . . . . . . . . . . . . . . . . 20


䡵 Vehicle Security Alarm System . . . . . . . . . . . . . 20
▫ Rearming The System . . . . . . . . . . . . . . . . . . 20
▫ To Set The Alarm . . . . . . . . . . . . . . . . . . . . . . 20
▫ To Disarm The System . . . . . . . . . . . . . . . . . . 21
䡵 Illuminated Entry . . . . . . . . . . . . . . . . . . . . . . . 21
䡵 Remote Keyless Entry . . . . . . . . . . . . . . . . . . . . 21
▫ To Unlock The Doors . . . . . . . . . . . . . . . . . . . 22
▫ To Lock The Doors . . . . . . . . . . . . . . . . . . . . 23
▫ To Release The Liftgate Flipper Glass . . . . . . . 24


12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


▫ Express Down Window Feature — If


Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
▫ Using The Panic Alarm . . . . . . . . . . . . . . . . . 24
▫ Programming Additional RKE Transmitters . . . 25
▫ RKE Transmitter Battery Service . . . . . . . . . . . 25
▫ General Information . . . . . . . . . . . . . . . . . . . . 26
䡵 Remote Starting System — If Equipped . . . . . . . 27
. . . . . . . . . . . . . . . 27
䡵 Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
▫ Manual Door Locks . . . . . . . . . . . . . . . . . . . . 29
▫ Power Door Locks . . . . . . . . . . . . . . . . . . . . . 30
▫ Passive Entry System — If Equipped . . . . . . . . 31


▫ How To Use Remote Start


▫ To Place An RKE Transmitter In The Vehicle


For Safekeeping – Vehicles Equipped With Keyless Go Only . . . . . . . . . . . . . . . . . . . . . . 32
▫ Child Protection Door Lock . . . . . . . . . . . . . . 33
䡵 Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
▫ Power Windows . . . . . . . . . . . . . . . . . . . . . . 34
▫ Wind Buffeting . . . . . . . . . . . . . . . . . . . . . . . 37
䡵 Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
▫ Liftgate Flipper Glass . . . . . . . . . . . . . . . . . . . 38
▫ Power Liftgate — If Equipped . . . . . . . . . . . . 39
䡵 Occupant Restraints . . . . . . . . . . . . . . . . . . . . . 42
▫ Lap/Shoulder Belts . . . . . . . . . . . . . . . . . . . . 43
▫ Lap/Shoulder Belt Operating Instructions . . . . 44


▫ Adjustable Upper Shoulder Belt Anchorage . . . 48
▫ Automatic Locking Mode — If Equipped . . . . . 49
▫ Energy Management Feature . . . . . . . . . . . . . 49
▫ Seat Belt Pretensioners . . . . . . . . . . . . . . . . . . 50
▫ Enhanced Seat Belt Use Reminder System


(BeltAlert威) . . . . . . . . . . . . . . . . . . . . . . . . . . 50
▫ Seat Belts And Pregnant Women . . . . . . . . . . . 52
▫ Seat Belt Extender . . . . . . . . . . . . . . . . . . . . . 52
▫ Driver And Front Passenger Supplemental


Restraint Systems (SRS) . . . . . . . . . . . . . . . . . 52


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13


▫ Child Restraints . . . . . . . . . . . . . . . . . . . . . . . 64
䡵 Engine Break-In Recommendations . . . . . . . . . . 73
䡵 Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
▫ Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . . . . 74
▫ Safety Checks You Should Make Inside The


Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75


▫ Safety Checks You Should Make Outside The


Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75


14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Remote Keyless Entry (RKE) transmitter with integrated ignition key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided key into the ignition switch with either side up. Keyless Go Feature This vehicle may be equipped with the Keyless Go feature, for more information, refer to “Keyless Go — If Equipped” under “Starting Procedure” in Section 5 of this manual. Wireless Ignition Node (WIN) The Wireless Ignition Node (WIN) operates similar to an ignition switch. It has four operating positions, three of which are detented and one spring-loaded. The detented positions are LOCK, ACC, and ON. The START position is a spring-loaded momentary contact position. When


released from the START position, the switch automati- cally returns to the detented ON position.


Wireless Ignition Node (WIN)


1 — LOCK 2 — ACC (ACCESSORY) 3 — ON 4 — START


Integrated Ignition Key The integrated ignition key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a valet key, which stores in the rear of the RKE transmitter. The valet key allows for entry into the vehicle should the battery in the vehicle or the RKE transmitter go dead. The valet key is also for locking the glove box. You can keep the valet key with you when valet parking. To remove the valet key from the RKE transmitter, slide the mechanical latch at the top of the RKE transmitter sideways with your thumb and then pull the key out with your other hand.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15


Three-Button FOBIK (FOB with Integrated Key)


NOTE: You can insert the double-sided valet key into the lock cylinders with either side up. Ignition Key Removal Place the shift lever in PARK. Turn the ignition key to the LOCK position, and remove the key.


16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


NOTE: • If you try to remove the key before you place the shift lever in PARK, it may become trapped temporarily in the ignition switch. If this occurs, rotate the key to the right slightly, then remove the key as described. If a malfunction occurs, the system will trap the key in the ignition switch to warn you that this safety feature is inoperable. The engine can be started and stopped, but the key cannot be removed until you obtain service. • For vehicles equipped with the Electronic Vehicle Information Center the power window switches, radio, power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned to the LOCK posi- tion. Opening either front door will cancel this feature. The time for this feature is programmable. For details, refer to “Key Off Power Delay,” under “Personal


(EVIC),


Settings (Customer-Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual.


WARNING!


Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Do not leave the key in the ignition. A child could operate power windows, other controls, or move the vehicle.


CAUTION!


An unlocked car is an invitation to thieves. Always remove key from the ignition and lock all doors when leaving the vehicle unattended.


Key-In-Ignition Reminder If you open the driver’s door with the integrated ignition key in the ignition, a chime will sound to remind you to remove the key. The Key-In-Ignition reminder only sounds NOTE: when the integrated ignition key is placed in the LOCK or ACC position.


SENTRY KEY姞 IMMOBILIZER SYSTEM The Sentry Key威 Immobilizer system prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked. The system uses the factory-mated Remote Keyless Entry (RKE) transmitter with integrated key and Wireless Igni- tion Node (WIN) to prevent unauthorized vehicle opera- tion. Therefore, only RKE transmitters that are pro- grammed to the vehicle can be used to start and operate


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17


the vehicle. The system will shut the engine off in two seconds if an invalid RKE transmitter is used to start the engine. After turning the ignition switch to the ON position, the Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the light begins to flash after the bulb check, it indicates that someone used an invalid RKE transmitter to start the engine. Either of these conditions will result in the engine being shut off after two seconds. If the Vehicle Security Light turns on during normal vehicle operation (vehicle running for longer than 10 sec- onds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon as possible.


18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


NOTE: • The Sentry Key威 Immobilizer system is not compatible with aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. • Exxon/Mobil Speedpass™, additional RKE transmit- ters, or any other transponder-equipped components on the same key chain will not cause a fault unless the additional part is physically held against the RKE transmitter being used to start the vehicle. Cell phones, pagers, or other RF electronics will not cause interference with this system.


All of the RKE transmitters provided with your new vehicle have been programmed to the vehicle electronics. Replacement Keys


NOTE: Only RKE transmitters that are programmed to the vehicle electronics can be used to start and operate


the vehicle. Once an RKE transmitter is programmed to a vehicle, it cannot be programmed to any other vehicle.


CAUTION!


Always remove the keys from the vehicle and lock all doors when leaving the vehicle unattended.


At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). Keep the PIN in a secure location. This number is required for authorized dealer replacement of RKE transmitters. Dupli- cation of RKE transmitters may be performed at an autho- rized dealer or by using the Customer Key Programming procedure. This procedure consists of programming a blank transmitter to the vehicle electronics. A blank transmitter is one that has never been programmed. NOTE: When having the Sentry Key威 Immobilizer system serviced, bring all vehicle RKE transmitters with you to the authorized dealer.


Customer Key Programming If you have two valid RKE transmitters with integrated keys, you can program new transmitters to the system by performing the following procedure: 1. Insert the first valid integrated key into the ignition switch and turn the ignition switch to the ON position for at least three seconds, but no longer than 15 seconds. Turn the ignition switch to the LOCK position and remove the first key. 2. Insert the second valid integrated key and turn the ignition switch to the ON position within 15 seconds. After 10 seconds, a chime will sound and the Vehicle Security Light will begin to flash. Turn the ignition switch to the LOCK position and remove the second key. 3. Insert a blank integrated key into the ignition switch and turn the ignition switch to the ON position within 60 seconds. After 10 seconds, a single chime will sound


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19


and the Vehicle Security Light will stop flashing, turn on again for three seconds, and then turn off. The new integrated key is programmed. The RKE trans- mitter will also be programmed during this procedure. Repeat this procedure to program up to eight keys. If you do not have a programmed RKE transmitter with inte- grated key, contact your authorized dealer for details. If a programmed key is lost, see your authorized NOTE: dealer to have all remaining keys erased from the sys- tem’s memory. This will prevent the lost key from starting your vehicle. The remaining keys must then be reprogrammed. All vehicle keys must be taken to an authorized dealer at service to be reprogrammed.


the time of


20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


General Information The Sentry Key威 system complies with FCC rules Part 15
and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference that may be received, including interference that may cause undes- ired operation.


liftgate,


VEHICLE SECURITY ALARM SYSTEM This Vehicle Security Alarm system monitors the vehicle doors, liftgate flipper glass, and ignition for unauthorized operation. When the alarm is activated, the system provides both audible and visible signals. The horn, headlights, and tail lights will sound/flash repeat- edly for three minutes. If disturbance is still present (driver’s door, passenger door, other doors, ignition) after three minutes, the headlights and tail lights will flash for an additional 15 minutes.


NOTE: The Panic and Security alarms are quite differ- ent. Please take a moment to activate the Panic and the Security modes to hear the differences in the horn. In case one should go off in the future, you will need to know which mode has been activated in order to deactivate it. Rearming The System: If something triggers the alarm, and no action is taken to disarm it, the system will turn off the horn after three minutes, turn off all of the visual signals after 15 minutes, and then the system will rearm itself. To Set the Alarm The alarm will set when you use the Remote Keyless Entry (RKE) transmitter to lock the doors and liftgate, or when you use the power door lock switch while the door is open. After all the doors are locked and closed, the Vehicle Security Light (located in the instrument cluster) will flash rapidly for about 16 seconds to signal that the system is arming. During this 16 second arming period,


opening any door or the liftgate will cancel the arming. If the system successfully arms, the Vehicle Security Light will flash at a slower rate to indicate the alarm is set. To Disarm the System To disarm the system, you will need to press the UN- LOCK button on the RKE transmitter or turn the ignition key to the ON position. If something has triggered the system in your absence, the horn will sound three times when you unlock the doors. Check the vehicle for tam- pering. The Vehicle Security Alarm system is designed to protect your vehicle; however, you can create conditions where the system will arm unexpectedly. If you remain in the vehicle and lock the doors with the RKE transmitter, once the system is armed (after 16 seconds), when you pull the door handle to exit, the alarm will sound. If this occurs, press the UNLOCK button on the RKE transmitter to disarm the system. You may also accidentally disarm the


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21


system by unlocking the driver’s door with the key and then locking it. The door will be locked but the Vehicle Security Alarm will not arm.


ILLUMINATED ENTRY The interior lights come on when you open any door. They will remain on for about 30 seconds after all doors are closed then fade to off. The lights also will fade to off if you turn on the ignition after you close all the doors.


REMOTE KEYLESS ENTRY This system allows you to lock or unlock the doors and liftgate, or activate the panic alarm, from distances up to about 66 ft (20 m) using a handheld RKE radio transmit- ter. The RKE transmitter does not need not be pointed at the vehicle to activate the system.


22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Inserting the Fob with Integrated Key (FOBIK) NOTE: into the ignition switch disables all buttons on that transmitter; however, the buttons on the remaining trans- mitters will continue to work. Driving the vehicle over 5 mph disables all transmitter buttons, for all Fobs, until the ignition is turned back to Off Lock.


Three-Button FOBIK


To Unlock the Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. Remote Key Unlock, Driver Door/All Doors First Press This feature lets you program the system to unlock either the driver’s door, or all doors, on the first press of the UNLOCK button on the RKE transmitter. To change the current setting, proceed as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Remote Key Unlock” (Customer- Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual.


“Personal


Settings


under


Flash Lights with Remote Key Lock This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- ter. This feature can be turned on or off. To change the current setting, proceed as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Flash Lamps with Lock” (Customer- Programmable Features)” under ⬙Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual.


“Personal


Settings


under


Turn Headlights On with Remote Key Unlock This feature activates the headlights for up to 90 seconds when the doors are unlocked with the RKE transmitter. The time for this feature is programmable on vehicles equipped with the Electronic Vehicle Information Center (EVIC). For details, refer to “Headlamp Off Delay” under


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23


“Personal Settings (Customer-Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual. To Lock the Doors Press and release the LOCK button on the RKE transmit- ter to lock all doors. The turn signal lights will flash and the horn will chirp to acknowledge the signal. Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter. This feature can be turned on or off. To change the current setting, proceed as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Sound Horn with Lock,” (Customer- Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual.


“Personal


Settings


under


24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


To Release the Liftgate Flipper Glass Press the FLIPPER GLASS/TRUNK RELEASE button two times (the second press within 5 seconds of the first press) to open liftgate flipper glass


WARNING!


Driving with the flipper glass open can allow poi- sonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the flipper glass closed when you are operating the vehicle.


Express Down Window Feature — If Equipped This feature allows you to remotely lower both front door windows at the same time. To use this feature, press and release the UNLOCK button on the RKE transmitter and then immediately press and hold the UNLOCK button until the windows lower to the level desired or until they lower completely.


Using the Panic Alarm To turn the Panic Alarm feature on or off, press and hold the PANIC button on the RKE transmitter for at least one second and release. When the Panic Alarm is on, the headlights and park lights will flash, the horn will pulse on and off, and the interior lights will turn on. The Panic Alarm will stay on for three minutes unless you turn it off by either pressing the PANIC button a second time, or drive the vehicle at a speed of 15 mph (24 km/h) or greater. NOTE: • The interior lights will turn off if you turn the ignition switch to the ACC or ON position while the Panic Alarm is activated. However, the exterior lights and horn will remain on. • You may need to be less than 67 ft (20 m) from the vehicle when using the RKE transmitter to turn off the Panic Alarm due to the Radio Frequency (RF) noises emitted by the system.


Programming Additional RKE Transmitters Refer to Sentry Key威 “Customer Key Programming.” If you do not have a programmed RKE transmitter, contact your authorized dealer for details. RKE Transmitter Battery Service The recommended replacement battery is one CR2032
battery. NOTE: • Perchlorate Material — special handling may apply. • Do not touch the battery terminals that are on the back


See www.dtsc.ca.gov/hazardouswaste/perchlorate


housing or the printed circuit board.


1. Battery access is through a door located on the rear of the fob. Insert a small, flat blade screwdriver into the slot and gently pry open the access door.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25


Battery Replacement


1— Battery Access Door 2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. Reposition the access door panel over the battery opening and snap into place.


26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


If Equipped With Passive Entry 1. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal. 2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To assemble the RKE transmitter case, snap the two halves together. General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference.


• This device must accept any interference received, includ-


ing interference that may cause undesired operation.


NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your Remote Keyless Entry (RKE) transmitter fails to operate from a normal distance, check for these two conditions. 1. A weak battery in the RKE transmitter. The expected life of the battery is a minimum of three years. 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios.


REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) trans- mitter to start the engine conveniently from outside the vehicle while still maintaining security. The system has a targeted range of 328 ft (100 m). How to Use Remote Start All of the following conditions must be met before the engine will remote start: • Shift lever in PARK • Doors closed • Hood closed • Liftgate closed • Hazard switch off • Brake switch inactive (brake pedal not pressed) • Ignition key removed from ignition switch


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27


• Battery at an acceptable charge level, and • RKE PANIC button not pressed. To Enter Remote Start Mode


Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds. The parking lights will flash and the horn will honk twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15 minute cycle. NOTE: • If an engine fault is present the vehicle will start and • The park lamps will turn on and remain on during • For security, power window and power sunroof op- eration (if so equipped) are disabled when the vehicle is in the Remote Start mode.


then shut down 10 seconds later.


Remote Start mode.


28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


• The engine can be started two consecutive times (two 15 minute cycles) with the RKE transmitter. However, the ignition must be cycled by pushing the START/ STOP button twice (or the ignition switch must be cycled to the ON position) before you can repeat the start sequence for a third cycle.


To Exit Remote Start Mode Without Driving the Vehicle Allow the engine to run for the entire 15 minute cycle. To Exit Remote Start Mode and Drive the Vehicle Before the end of 15 minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped). Then, prior to the end of the 15 minute cycle, simply press and release the START/STOP button. If the START/STOP button is not present, insert the key into the ignition switch and turn the switch to the ON position.


NOTE: • For the vehicle not equipped with Keyless Go feature, the ignition switch must be in the ON position in order to drive the vehicle. • For the vehicle not equipped with Keyless Go feature, the message “Insert Key/Turn To On” will display in the EVIC until you insert the key. Once inserted, the message “Turn To On” will display in the EVIC until you turn the key to On. Refer to “Electronic Vehicle this Information Center (EVIC)” in Section 4 of manual. • For the vehicle equipped with Keyless Go feature, the message “Push Button/Insert Key” will display in the EVIC until you push the START Button.


To Turn Off the Engine While in Remote Start Mode Press and release the REMOTE START button one time. NOTE: To avoid inadvertent shutdowns, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request.


DOOR LOCKS


Manual Door Locks Use the manual door lock plunger to lock the doors from inside the vehicle. If the plunger is down when the door is closed, the door will lock. Therefore, make sure the key is not inside the vehicle before closing the door.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29


WARNING!


• For personal security and safety in the event of an accident, lock the vehicle doors when you drive, as well as when you park and leave the vehicle. • When leaving the vehicle always remove the key from the ignition, and lock your vehicle. Do not leave unattended children in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe personal in- juries and death.


30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Power Door Locks The power door lock switch is located on each front door panel. Press the switch to lock or unlock the doors.


Power Door Lock Switch


If the plunger is down when the door is closed, the door will lock. Therefore, make sure the key is not inside the vehicle before closing the door.


If you press the door lock switch while the keys are in the ignition switch, and the driver’s door is open, the doors will not lock. The rear doors cannot be opened from inside the vehicle until you pull up the lock plungers. Automatic Door Locks lock If this feature is selected, your door locks will automatically when the vehicle speed is above 15 mph (24 km/h) and all doors are closed. It will reset whenever a door is opened. This feature is selectable and can be turned on or off. Refer “Customer- Programmable Features” under “Electronic Vehicle Infor- mation Center (EVIC)” in Section 4 of this manual or see your authorized dealer.


to “Auto Door Locks” under


Automatic Unlock on Exit Feature — Only Available if Auto Lock is Enabled This feature will unlock all the doors when the driver’s door is opened if the vehicle is stopped and in PARK or NEUTRAL. Refer to “Auto Unlock on Exit” under “Customer-Programmable Features” in the “Electronic Vehicle Information Center (EVIC),” in Section 4 of this manual or see your authorized dealer. Passive Entry System — If Equipped The Passive Entry system allows you to unlock the vehicle’s door(s) without using the Remote Keyless Entry (RKE) transmitter unlock button, or the unlock button located on the vehicle’s interior door panel. To use this feature you must have a valid RKE transmitter within 5 ft (1.5 m) of the door handle you desire to use, and it must be located outside of the vehicle.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31


To Unlock the Vehicle’s Doors To unlock the vehicle’s door(s), grasp the door handle and the door(s) will unlock. NOTE: • If the vehicle has not been used for 72 hours or it has been raining for 24 hours, you may have to pull a door handle to reactivate this feature. • If the vehicle’s door locks are programmed to “Unlock Driver’s Door 1st Press,” only the driver’s door will unlock when the driver’s door handle is grasped. If the vehicle’s door locks are programmed to “Unlock All Doors 1st Press”, all doors will unlock if any door handle is grasped. Refer to “Remote Key Unlock” under “Personal Settings (Customer-Programmable Features)” in the “Electronic Vehicle Information Cen- ter (EVIC)” in Section 4 of this manual.


32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


• If you accidentally lock your RKE transmitter in the vehicle using the door panel switch, ALL doors will unlock and the horn will chirp three times after all doors are closed. If you do this three times, the system will not chirp and the doors will remain locked on the third attempt. To re-enable the system the vehicle must be unlocked with another valid RKE transmitter.


To Lock the Vehicle’s Doors The vehicle doors can be locked by using the RKE transmitter lock button or the lock button located on the vehicle’s interior door panel. To Place an RKE Transmitter in the Vehicle for Safekeeping – Vehicles Equipped with Keyless Go only If you want to lock an RKE transmitter in your vehicle by using the door panel switch perform the following pro- cedure: 1. With the desired RKE transmitter in the vehicle, press the door lock switch located on the door panel. All doors


will lock. When all doors are closed you will hear three chirps of the horn and the doors will unlock. This is the same lock/unlock and chirping sound that you would experience if you accidentally locked your RKE transmit- ter in the vehicle. 2. Open the door and repeat Step 1 two more times (three times total). The doors will remain locked; no audible warnings will occur. NOTE: Any RKE transmitter that is locked in the vehicle either by a passive lock, another RKE lock, or the door panel lock switch will be disabled from Keyless Go. The disabled RKE transmitter(s) will be re-enabled after a passive unlock or RKE unlock.


Child Protection Door Lock The rear doors of your vehicle are equipped with Child Protection Door Locks. If you push up on the lever on the open edge of the door it cannot be opened from the inside of the vehicle. Push the lever down to disengage the Child Protection Door Locks.


WARNING!


Avoid trapping anyone in the vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child Protection Door Locks are engaged.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33


Child Protection Door Lock


34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WINDOWS


Power Windows The power window controls are located on the driver’s door trim panel. There is a single switch on the front passenger door/rear doors which operate the front passenger/rear passenger door windows. The window controls will operate only when the ignition switch is in the ON or ACC position.


Power Window Switches


The power window switches remain active for up to 10 minutes after the ignition switch has been turned OFF. Opening a vehicle front door will cancel this feature.


Auto Down Both the driver and front passenger window switch have an Auto Down feature. Press the window switch past the first detent, release, and the window will go down automatically. To cancel the Auto Down movement, operate the switch in either the up or down direction and release the switch. To stop the window from going all the way down during the Auto Down operation, pull up on the switch briefly. To open the window part way, press to the first detent and release it when you want the window to stop. The power window switches remain active for 10 min- utes after the ignition has been turned off. Opening either front door will cancel this feature.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35


Auto Up Feature with Anti-Pinch Protection (Driver’s and Front Passenger Door Only) Lift the window switch to the second detent, release, and the window will go up automatically. To stop the window from going all the way up during the Auto Up operation, push down on the switch briefly. To close the window part way, lift the window switch to the first detent and release when you want the window to stop. If the window runs into any obstacle during the NOTE: auto-closure, it will reverse direction and then stop. Remove the obstacle and use the window switch again to close the window. Any impact due to rough road condi- tions may trigger the auto reverse function unexpectedly during auto closure. If this happens, pull the switch lightly to the first detent and hold to close the window manually.


36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


There is no anti-pinch protection when the window is almost closed. Be sure to clear all objects from the window before closing.


Resetting the Auto Up Feature Should the Auto Up feature stop working, the window probably needs to be reset. To reset Auto Up, pull the window switch up and close the window completely, then pull and hold the switch for one second. Window Lockout Switch The Window Lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the Window Lockout button. To enable the window controls, press the Window Lockout button again.


Window Lockout Switch


Wind Buffeting


Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occur- rence and can be minimized. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting.


LIFTGATE To open the liftgate, pull up (squeeze) on the handle and lift. Manually unlocking the vehicle doors with the plunger or a key in the lock cylinder will not unlock the liftgate.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37


Liftgate Release


WARNING!


Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your pas- sengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle.


38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Liftgate Flipper Glass The liftgate flipper glass is also unlocked when the liftgate is unlocked. To open the flipper glass, push up on the window switch located on the liftgate.


Liftgate Glass Release


WARNING!


To avoid injury, stand back when opening. Glass will automatically rise.


Once the liftgate flipper glass has been opened, connec- tion to the rear window wiper is interrupted, preventing activation of the rear wiper blade while the flipper glass is open.


WARNING!


Driving with the flipper glass open can allow poi- sonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the flipper glass closed when you are operating the vehicle.


Power Liftgate — If Equipped The power liftgate may be opened manually or by pressing the LIFTGATE button on the Fob with Inte- grated Key (FOBIK). Press the LIFTGATE button on the Fob with Integrated Key (FOBIK) twice within five seconds, to open the power liftgate. Once the liftgate is fully open, pressing the button twice within five seconds a second time will close the liftgate.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39


Power Liftgate Button


40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Also, the power liftgate may be closed by pressing the Liftgate switch located on the left rear trim, near the liftgate opening. Pressing once will close the liftgate only. This button cannot be used to open the liftgate.


Rear Liftgate Switch


When the LIFTGATE button on the Fob with Integrated Key (FOBIK) is pressed two times and the “Lamp Flash”


feature is enabled, the turn signals will flash twice to signal that the liftgate is opening or closing. NOTE: • In the event of a power malfunction to the liftgate, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the lift- gate trim panel.


WARNING!


During power operation, personal injury or cargo damage may occur. Ensure the liftgate travel path is clear. Make sure the liftgate is closed and latched before driving away.


A beeping signal will sound two seconds before the liftgate starts to open or close.


NOTE: • If anything obstructs the power liftgate while it is closing or opening, the liftgate will automatically reverse to the closed or open position, provided it meets sufficient resistance. • There are also pinch sensors attached to the side of the liftgate. Light pressure anywhere along these strips will cause the liftgate to return to the open position. • The power liftgate must be in the full open position for any of the buttons to operate. If the liftgate is not fully open, press the Liftgate button on the Fob with Inte- grated Key (FOBIK) to fully open the liftgate, and then press it again to close. • If the liftgate handle is pulled while the power liftgate is closing, the liftgate will reverse to the full open position. • If the liftgate handle is pulled while the power liftgate is opening, the liftgate motor will disengage to allow manual operation.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41


• The power liftgate buttons will not operate if the vehicle is in gear or the vehicle speed is above 0 mph (0 km/h). • The power liftgate will not operate in temperatures below ⫺22°F (⫺30°C) or temperatures above 150°F (65°C). Be sure to remove any buildup of snow or ice from the liftgate before pressing any of the power liftgate switches. • If the power liftgate encounters multiple obstructions within the same cycle, the system will automatically stop and must be opened or closed manually. • If your liftgate is power closing and you put the vehicle in gear, the liftgate will continue to power close. However, vehicle movement may result in a detection of an obstruction.


42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


• Driving with the liftgate open can allow poison- ous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. • If you are required to drive with the liftgate open, make sure that all windows are closed, and the climate control blower switch is set at high speed. DO NOT use the recirculation mode.


Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather.


OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, front airbags for both the driver and right front passenger, and, window bags for the driver and passengers seated next to a window. If you will be carrying children too small for adult-size belts, your seat belts also can be used to hold infant and child restraint systems. NOTE: The front airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. Please pay close attention to the information in this section. It tells you how to use your restraint system properly to keep you and your passengers as safe as possible.


WARNING!


• In a collision, you and your passengers can suffer injuries, including fatalities, if you are not prop- erly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly. • Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision which includes you. This can happen far away from home or on your own street.


(Continued)


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43


WARNING! (Continued)


• Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times to reduce or prevent injuries.


Lap/Shoulder Belts All seating positions in your vehicle have combination lap/shoulder belts. The belt webbing retractor is de- signed to lock during very sudden stops or collisions. This feature allows the shoulder part of the belt to move freely with you under normal conditions. But in a colli- sion, the belt will lock and reduce the risk of you striking the inside of the vehicle or being thrown out.


Lap/Shoulder Belt Operating Instructions


1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap.


44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


• Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of a collision the best. Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too. • Two people should never be belted into a single seat belt. People belted together can crash into one another in an accident, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45


3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.”


Latch Plate


Latch Plate to Buckle


46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


• A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you as well. In a sudden stop you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly. • A belt that is worn under your arm is very dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries. Ribs are not as strong as shoulder bones. Wear the belt over your shoulder so that your stron- gest bones will take the force in a collision.


(Continued)


WARNING! (Continued)


• A shoulder belt placed behind will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.


4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.


WARNING!


• A lap belt worn too high can increase the risk of injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your ab- domen. Always wear the lap part of your seat belt as low as possible and keep it snug. • A twisted belt cannot do its job as well. In a collision it could even cut into you. Be sure the belt is straight. If you cannot straighten a belt in your vehicle, take it to your authorized dealer and have it fixed.


5. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47


Removing Slack from Belt


6. To release the belt, push the red button marked PRESS on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow it to retract fully.


48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after an accident if they have been damaged (i.e., bent retractor, torn web- bing, etc.).


Adjustable Upper Shoulder Belt Anchorage In the front seating positions, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Press the RELEASE button to release the anchorage, and then move it up or down to the position that serves you best.


Adjusting Upper Shoulder Belt


As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position.


Automatic Locking Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. The belt will still retract to remove any slack in the shoulder belt. When to Use the Automatic Locking Mode The Automatic Locking mode should be used anytime a child safety seat is installed in a second or third row seating position. Children 12 years old and younger should be properly restrained in a rear seat whenever possible. How to Use the Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the Automatic Locking mode.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49


How to Disengage the Automatic Locking Mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the Automatic Locking mode and activate the Vehicle Sensitive (Emer- gency) Locking mode. Energy Management Feature This vehicle has a safety belt system with an Energy Management feature in the front seating positions to help further reduce the risk of injury in the event of a head-on collision. This safety belt system has a retractor assembly that is designed to release webbing in a controlled manner. This feature is designed to help reduce the belt force acting on the occupant’s chest.


50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


WARNING!


• The belt and retractor assembly must be replaced if the seat belt assembly Automatic Locking Re- tractor (ALR) feature or any other seat belt func- tion is not working properly when checked ac- cording to the procedures in the Service Manual. • Failure to replace the belt and retractor assembly


could increase the risk of injury in collisions.


Seat Belt Pretensioners The driver and front passenger seat belts are equipped with a pretensioning device that is designed to remove any slack from the seat belt systems in the event of a collision. This device improves the performance of the seat belt by assuring that the belt is tight around the occupant early in a collision. Pretensioners work for all size occupants, including those in child restraints.


NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt must still be worn snugly and positioned properly. The pretensioners are triggered by the Occupant Re- straint Control (ORC). Like the front airbags, the preten- sioners are a single use item. After a collision that is severe enough to deploy the airbags and pretensioners, they must be replaced. Enhanced Seat Belt Use Reminder System (BeltAlert姞) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Warning System (BeltAlert威) will alert the driver to buckle their seat belt. The driver should also instruct all other occu- pants to buckle their seat belts. Once the warning is triggered, BeltAlert威 will continue to chime and flash the Seat Belt Warning Light for 96 seconds or until the


driver’s seat belt is buckled. BeltAlert威 will be reactivated if the driver’s seat belt is unbuckled for more than 10 seconds and the vehicle speed is greater than 5 mph (8 km/h). BeltAlert威 can be enabled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position. Chrysler LLC does not recommend deactivating BeltAlert威. 1. Turn the ignition switch to the OFF position, and buckle the driver’s seat belt. 2. Turn the ignition key to the ACC/ON position (engine does not need to be running), and wait for the Seat Belt Warning Light to turn off.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51


3. Within 60 seconds of starting the vehicle, unbuckle and then re-buckle the driver’s seat belt at least three times with 10 seconds, ending with the seat belt buckled. 4. Turn the ignition key to the OFF position. A single chime will sound to signify that you have successfully completed the programming. BeltAlert威 can be reactivated by repeating this procedure. NOTE: Although BeltAlert威 has been deactivated, the Seat Belt Warning Light will continue to illuminate while the driver’s seat belt remains unfastened.


52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug across the hips as possible. Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision. Seat Belt Extender If a seat belt is too short, even when fully extended and when the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, your authorized dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not long enough. When it is not required, remove the ex- tender and store it.


WARNING!


Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions. Remove and store the extender when not needed.


Driver and Front Passenger Supplemental Restraint Systems (SRS) This vehicle has airbags for both the driver and right front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the steering wheel. The passenger side airbag is mounted in the instrument panel, above the glove compartment. The words SRS/AIRBAG are embossed on the airbag covers.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53


The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size. This vehicle is equipped with window bags to protect the driver, front, and rear passengers sitting next to a win- dow. They are located above the side windows. Their covers are also labeled SRS/AIRBAG.


1 — Driver Airbag 2 — Passenger Airbag 3 — Knee Bolster


NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment.


Window Airbag Location


54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


NOTE: Airbag covers may not be obvious in the interior trim; but they will open to allow airbag deployment.


WARNING!


• Do not put anything on or around the front airbag covers or attempt to manually open them. You may damage the airbags and you could be injured because the airbags are no longer functional. These protective covers for the airbag cushions are designed to open only when the airbags are inflat- ing. • Do not stack luggage or other cargo up high enough to block the location of the window bag. The area where the window bag is located should remain free from any obstructions.


(Continued)


WARNING! (Continued)


• Do not have any accessory items installed which will alter the roof, including adding a sunroof to your vehicle. Do not add roof racks that require permanent attachments (bolts or screws) for instal- lation on the vehicle roof. Do not drill into the roof of the vehicle for any reason. • Do not cover or place items on the airbag covers. These items may cause serious injury during inflation.


NOTE: Do not use a clothing bar mounted to the coat hooks in this vehicle. A clothing bar will impede the proper performance of the window bags. The front airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. Along with the seat belts,


front airbags work with the instrument panel knee bol- sters to provide improved protection for the driver and front passenger. Window bags also work with seat belts to improve occupant protection. The seat belts are designed to protect you in many types of collisions. The front airbags deploy in moderate to severe frontal collisions. The window bag on the crash side of the vehicle is triggered in moderate to severe side collisions. In certain types of collisions, both the front and side airbags may be triggered. But even in collisions where the airbags work, you need the seat belts to keep you in the right position for the airbags to protect you properly. Here are some simple steps you can take to minimize the risk of harm from a deploying airbag. 1. Children 12 years and younger should always ride buckled up in a rear seat.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55


WARNING!


Infants in rear facing child restraints should NEVER ride in the front seat of a vehicle with a passenger airbag. An airbag deployment could cause severe injury or death to infants in that position.


Children that are not big enough to properly wear the vehicle seat belt should be secured in the rear seat, in a child restraint or belt-positioning booster seat. Older children who do not use child restraints or belt- positioning booster seats should ride properly buckled up in the rear seat. Never allow children to slide the shoulder belt behind them or under their arm. If a child from 1 to 12 years old must ride in the front passenger seat because the vehicle is crowded, move the seat as far back as possible, and use the proper child restraint. Refer to “Child Restraints” in this section.


56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


You should read the instructions provided with your child restraint to make sure that you are using it properly. 2. All occupants should use their lap and shoulder belts properly. 3. The driver and front passenger seats should be moved back as far as practical to allow the front airbags room to inflate. 4. Do not lean against the door or window, airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center. Phone numbers are provided under “If You Need Assistance” in Section 9 of this manual.


WARNING!


• Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags. • Being too close to the steering wheel or instrument panel during airbag deployment could cause seri- ous injury. Airbags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel. • Side curtain airbags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat.


Airbag System Components The airbag system consists of the following: • Occupant Restraint Control (ORC) • Airbag Warning Light • Driver Airbag • Passenger Airbag • Side Curtain Airbags above Side Windows • Side Remote Acceleration Sensors • Driver Side Seat Track Position Sensor • Steering Wheel and Column • Instrument Panel • Interconnecting Wiring • Knee Impact Bolsters


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57


• Front Acceleration Sensors • Driver and Front Passenger Seat Belt Pretensioners How the Airbag System Works • The Occupant Restraint Control (ORC) determines if a frontal, side, or rollover collision is severe enough to require the front and/or side airbags to inflate. The front airbag inflators are designed to provide different rates of airbag inflation from direction provided by the ORC. The ORC will detect roll overs, not rear impacts. The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON positions. These include all of the items listed above except the knee bolster, the instru- ment panel, and the steering wheel and column. If the key is in the LOCK position, in the ACC position, or not in the ignition, the airbags are not on and will not inflate.


58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


• Tthe ORC also turns on the Airbag Warning Light for 2.5 to 8 seconds for a self-check when the ignition is first turned on. After the self-check, the Airbag Warning Light will turn off. If the ORC detects a malfunction in any part of the system, it turns on the Airbag Warning Light either momentarily or continuously. A single chime will sound if the light comes on again after initial start up.


WARNING!


Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.


• The Driver and Passenger Airbag/Inflator Units are located in the center of the steering wheel and the right side of the instrument panel. When the ORC detects a collision requiring the airbags, it signals the inflator units. A large quantity of nontoxic gas is generated to inflate the front airbags. Different airbag inflation rates are possible, based on collision severity and occupant size. The steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as the bags inflate to their full size. The bags fully inflate in about 50 to 70 milliseconds. This is about half of the time it takes to blink your eyes. The bags then quickly deflate while helping to restrain the driver and front passenger. The driver front airbag gas is vented through the vent holes in the sides of the airbag. The passenger front airbag gas is vented through the vent holes in the sides of the airbag. In this way, the airbags do not interfere with your control of the vehicle.


• The Side Impact SRS Side Curtain Airbags are designed to activate only in certain side or rollover collisions. When the Occupant Restraint Control (ORC) detects a collision requiring the window bags to inflate, it signals the inflators on the crash side of the vehicle, and both sides of the vehicle when rollover is sensed. A quantity of non- toxic gas is generated to inflate the window bag. The inflating window bag pushes the outside edge of the headliner out of the way and covers the window. The airbag inflates in about 30 milliseconds (about one- quarter of the time it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area where the window bag inflates. This especially applies to children. The window bag is only about 3 in (8 cm) thick when it is inflated. • The Knee Impact Bolsters help protect the knees of the driver and the front passenger, and position every- one for the best interaction with the front airbag.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59


If a Deployment Occurs The airbag system is designed to deploy when the Occupant Restraint Control (ORC) detects a moderate-to- severe frontal collision, to help restrain the driver and front passenger, and then to immediately deflate. NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system. This does not mean something is wrong with the airbag system. If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold. The abra- sions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor. They are not caused by contact with chemicals. They are not permanent and normally heal quickly. However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor immediately.


60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


• As the airbags deflate you may see some smoke-like particles. The particles are a normal by-product of the process that generates the nontoxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat. If you have skin or eye irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air. If the irritation continues, see your doctor. If these particles settle on your clothing, follow the garment manufacturer’s instruc- tions for cleaning. • It is not advisable to drive your vehicle after the airbags have deployed. If you are involved in another collision, the airbags will not be in place to protect you.


WARNING!


Deployed airbags and seat belt pretensioners cannot protect you in another collision. Have the airbags, seat belt pretensioners, and seat belt retractor assem- bly replaced by an authorized dealer as soon as possible.


Enhanced Accident Response Feature If the airbags deploy after an impact and the electrical system remains functional, vehicles equipped with power door locks will unlock automatically. The hazard lights will flash and the fuel will be cut off to the engine. In addition, after the vehicle has stopped moving, the interior lights will illuminate to aid visibility and remain lit until the ignition switch is turned off. NOTE: The interior lights can only be deactivated if the key is removed from the ignition switch or the vehicle is driven.


Maintaining Your Airbag System


WARNING!


• Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel. Do not modify the front bumper or vehicle body struc- ture. • You need proper knee impact protection in a collision. Do not mount or locate any aftermarket equipment on or behind the knee bolsters. • It is dangerous to try to repair any part of the airbag system yourself. Be sure to tell anyone who works on your vehicle that it has an airbag system.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61


NOTE: Perchlorate Material – special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate Airbag Warning Light You will want to have the airbag system ready to inflate for your protection in an impact. The airbag system is designed to be maintenance free. If any of the following occurs, have an authorized dealer service the system promptly: • Airbag Warning Light does not come on during the 2.5
to 8 seconds after the ignition switch is first turned on, • Remains on after the 2.5 to 8 second interval, or • Flickers, or comes on and remains on for any period of


time while driving.


62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data parameters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near deployment, and up to a quarter second of high-speed deceleration data during and/or after airbag deployment or near-deployment. EDR data are ONLY recorded if an airbag deploys, or nearly deploys, and are otherwise unavailable. NOTE: • A near-deployment event occurs when the airbag sensor detects severe vehicle deceleration usually in- dicative of a crash, but not severe enough to warrant airbag deployment. • Under certain circumstances, EDR data may not be


recorded (e.g., loss of battery power).


In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be


used by Chrysler LLC and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle performance. In addition to crash investigations initiated by Chrysler LLC, such investigations may be requested by customers, insurance carriers, government officials, and professional crash researchers, such as those associated with universities, and with hospital and insurance organizations. In the event that an investigation is undertaken by Chrysler LLC (regardless of initiative), the company or its designated representative will first obtain permission of the appropriate custodial entity for the vehicle (usually the vehicle owner or lessee) before accessing the elec- tronic data stored, unless ordered to download data by a court with legal jurisdiction (i.e., pursuant to a warrant). A copy of the data will be provided to the custodial entity upon request. General data that does not identify par- ticular vehicles or crashes may be released for incorpo- ration in aggregate crash databases, such as those main- tained by the U.S. government and various states. Data of


a potentially sensitive nature, such as would identify a particular driver, vehicle, or crash, will be treated confi- dentially. Confidential data will not be disclosed by Chrysler LLC to any third party except when: 1. Used for research purposes, such as to match data with a particular crash record in an aggregate database, provided confidentiality of personal data is thereafter preserved. 2. Used in defense of litigation involving a Chrysler LLC product. 3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that may be recorded: • Diagnostic trouble code(s) and warning lamp status for electronically-controlled safety systems, including the airbag system


• Airbag disable lamp status (if equipped)


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63


cycles and vehicle mileage)


• ⬙Time⬙ of airbag deployment (in terms of ignition • Airbag deployment level (if applicable) • Impact acceleration and angle • Seat belt status • Brake status (service and parking brakes) • Accelerator status (including vehicle speed) • Engine control status (including engine speed) • Transmission gear selection • Cruise control status • Traction/stability control status • Tire Pressure Monitoring System status


64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Child Restraints Everyone in your vehicle needs to be buckled up all the time, including babies and children. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it. Children 12 years and younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front. There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat Owner’s Manual to ensure you have the right seat for your child. Use the restraint that is correct for your child:


WARNING!


In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are. The child and others could be badly injured. Any child riding in your vehicle should be in a proper restraint for the child’s size.


Infants and Child Restraints • Safety


experts


recommend that


children ride rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and convertible child seats. • The infant carrier is only used rearward-facing in the vehicle. It is recommended for children who weigh up to about 20 lbs (9 kg). Convertible child seats often have a higher weight limit in the rearward-facing direction than infant carriers do, so they can be used rearward-facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. Both types of child restraints are held in the vehicle by the lap/shoulder belt or the LATCH child restraint an- chorage system (Refer to LATCH — Child Seat An- chorage System in this section.)


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65


WARNING!


• Rearward-facing child seats must NEVER be used in the front seat of a vehicle with the front passen- ger airbag unless the airbag is turned off. An airbag deployment could cause severe injury or death to infants in this position. • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint. • A rearward facing infant restraint should only be used in a rear seat. A rearward facing infant restraint in the front seat may be struck by a deploying passenger airbag which may cause se- vere or fatal injury to the infant.


66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. Chrysler LLC also recommends that you try a child restraint in the vehicle seats where you will use it before you buy it. • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits. • Carefully follow the instructions that come with the restraint. If you install the restraint improperly, it may not work when you need it. • The front passenger seat belt is equipped with a cinching latch plate. The second and third row seating positions have automatic locking retractors. Both types of seat belts are designed to keep the lap portion tight around the child restraint so that it is not necessary to


use a locking clip. If the seat belt has a cinching latch plate, pulling up on the shoulder portion of the lap/shoulder belt will tighten the belt (the cinching latch plate will keep the belt tight, however, any seat belt system will loosen with time, so check the belt occasionally and pull it tight if necessary). For the second and third row seat belts with the automatic locking retractor, pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle. Then, pull the belt until it is fully extracted from the retrac- tor. Allow the belt to return to the retractor, pulling on the excess webbing to tighten the lap portion about the child restraint. For additional information, refer to ⬙Automatic Locking Mode⬙ earlier in this section. • In your vehicle’s 2nd row outboard seating positions, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist


the short buckle-end belt several times to shorten it. Insert the latch plate into the buckle with the release button facing out. • If the belt still cannot be tightened, or if pulling and pushing on the restraint loosens the belt, disconnect the latch plate from the buckle, turn the buckle around, and insert the latch plate into the buckle again. If you still cannot make the child restraint secure, try a different seating position. • Buckle the child into the restraint exactly as the • When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle. Do not leave it loose in the vehicle. In a sudden stop or collision, it could strike the occupants or seatbacks and cause serious personal injury.


manufacturer’s instructions tell you.


NOTE: www.seatcheck.org or call 1-866-SEATCHECK.


information


additional


For


refer


to


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67


Older Children and Child Restraints Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction, are for chil- dren who weigh 20 to 40 lbs (9 to 18 kg), and who are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system (Refer to LATCH — Child Seat Anchorage System in this section.) The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seatback, they should use a belt-positioning booster seat. The child and belt- positioning booster seat are held in the vehicle by the lap/shoulder belt.


68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seatback, should use the lap/shoulder belt in a rear seat. • Make sure that the child is upright in the seat. • The lap portion should be low on the hips and as snug • Check belt fit periodically. A child’s squirming or • If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm or behind their back.


slouching can move the belt out of position.


as possible.


LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren) Your vehicle’s second row seat is equipped with the child restraint anchorage system called LATCH. The LATCH system provides for the installation of the child restraint without using the vehicle’s seat belts, instead securing the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle structure. LATCH-compatible child restraint systems are now avail- able. However, because the lower anchorages are to be introduced over a period of years, child restraint systems having attachments for those anchorages will continue to also have features for installation using the vehicle’s seat belts. Child restraints having tether straps and hooks for connection to the top tether anchorages have been avail- able for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap


kits or retro-fit kits. You are urged to take advantage of all the available attachments provided with your child re- straint in any vehicle. NOTE: When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children. Remind all children in the vehicle that the seat belts are not toys and should not be played with, and never leave your child unattended in the vehicle. The second row outboard and center seating positions have lower anchorages that are capable of accommodat- ing LATCH-compatible child seats having flexible, webbing-mounted lower attachments or fixed lower at- tachments. Regardless of the type of lower attachment,


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69


NEVER install LATCH-compatible child seats such that two seats share a common lower anchorage. If your child seats are not LATCH-compatible, you can only install the child seats using the vehicle’s seat belts. For typical installation instructions, refer to “Installing the LATCH-Compatible Child Restraint System”. Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.


70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


The rear seat lower anchorages are round bars, located at the rear of the seat cushion where it meets the seatback, and are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the intersection of the seatback and seat cushion surfaces.


Tether Strap Mounting


Many, but not all restraint systems will be equipped with separate straps on each side, with each having a hook or connector for attachment to the lower anchorage and a means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a


Latch Anchorages


hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap. You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages. Next attach the lower hooks or connectors over the top of the anchorage bars, pushing aside the seat cover material. Then, locate the tether anchorage directly behind the seat where you are placing the child restraint and attach the tether strap to the anchorage, being careful to route the tether strap to provide the most direct path between the anchor and the child restraint. Finally, tighten all three straps as you push the child restraint rearward and downward into the seat, removing slack in the straps according to the child restraint manufacturer’s instruc- tions.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71


WARNING!


Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.


Installing Child Restraints Using the Vehicle Seat Belts The passenger seat belts are equipped with either cinch- ing latch plates or automatic locking retractors, which are designed to keep the lap portion tight around the child restraint so that it is not necessary to use a locking clip. If the seat belt has a cinching latch plate, pulling up on the shoulder portion of the lap/shoulder belt will tighten the belt. The cinching latch plate will keep the belt tight, however, any seat belt system will loosen with time, so check the belt occasionally and pull it tight if necessary.


72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


If the seat belt has an automatic locking retractor, pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle. Then, pull the belt until it is all extracted from the retractor. Allow the belt to return to the retractor, pulling on the excess webbing to tighten the lap portion about the child restraint. Refer to “Automatic Locking Mode” earlier in this section. In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist the short buckle-end belt several times to shorten it. Insert the latch plate into the buckle with the release button facing out. If the belt still can’t be tightened, or if by pulling and pushing on the restraint loosens the belt, you may need to do something more. Disconnect the latch plate from the buckle, turn the buckle around, and insert the latch


plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. To attach a child restraint tether strap:


Tether Strap Mounting


Route the tether strap over the seatback and attach the hook to the tether anchor located on the back of the seat.


For the outboard seating positions, route the tether over the head rests, and attach the hook to the tether anchor located on the back of the seat.


WARNING!


An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.


Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.


THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73


ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration within the limits of local traffic laws, contributes to a good break-in. Wide-open throttle acceleration in low gear can be detri- mental and should be avoided. The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. The recom- mended viscosity and quality grades are shown under “Engine Oil”, under “Maintenance Procedures” in section 7
of this manual. NON-DETERGENT OR STRAIGHT MIN- ERAL OILS MUST NEVER BE USED.


74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE


A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered as a normal part of the break-in and not interpreted as an indication of difficulty.


SAFETY TIPS


Exhaust Gas


WARNING!


Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO), follow these safety tips:


• Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for a extended period. If the vehicle is stopped in an open area with engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle. • Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Always run the climate control in panel or floor mode when driving with any windows open, even if only slightly, to help keep fresh air circulating inside the vehicle; otherwise, poisonous gases could be drawn into the vehicle.


Safety Checks You Should Make Inside the Vehicle


Seat Belts

Loading...
x
