2007 Honda Civic Hybrid Owners Manual

Main MenuTable of ContentsstImportant Maintenance Precautions If you have the required service done but do not reset the display, or reset the display without doing the service, the system will not show the proper maintenance intervals. This can lead to serious mechanical problems because you will no longer have an accurate record of when maintenance is needed.

Your authorized Honda dealer knows your vehicle best and can provide competent, efficient service.

4.

Press the SEL/RESET button for more than 5 seconds. The maintenance item code(s) will disappear, and the engine oil life will reset to ‘‘100.’’

Maintenance Minder

However, service at a dealer is not mandatory to keep your warranties in effect. Maintenance may be done by any qualified service facility or person who is skilled in this type of automotive service. Make sure to have the service facility or person reset the display as previously described. Keep all receipts as proof of completion, and have the person who does the work fill out the maintenance record. Check your warranty booklet for more information.

We recommend using Honda parts and fluids whenever you have maintenance done. These are manufactured to the same high quality standards as the original components, so you can be confident of their performance and durability.

CONTINUED

183

Main MenuTable of ContentsstMaintenance Minder

U.S. Vehicles: Maintenance, replacement, or repair of emissions control devices and systems may be done by any automotive repair establishment or individual using parts that are ‘‘certified’’ to EPA standards.

＃

According to state and federal regulations, failure to perform maintenance on the items marked with will not void your emissions warranties. However, all maintenance services should be performed in accordance with the intervals indicated by the information display.

184

Owner’s Maintenance Checks Youshouldcheckthefollowing items at the specified intervals. If you are unsure of how to perform any check, turn to the appropriate page listed.

−

Lights Check the operation of the headlights, parking lights, taillights, high-mount brake light, turn signals, brake lights, and license plate light monthly. See page

197

Engine oil level Check every time you fill the fuel tank. See page

153

−

Engine coolant level Check the radiator reserve tank every time youfillthefueltank.Seepage

154

−

Automatic transmission Check the fluid level monthly. See page 195

−

Brakes Check the fluid level monthly. See page

196

−

−

Tires Check the tire pressure monthly. Examine the tread for wear and foreign objects. See page 207

Main MenuTable of ContentsstSymbol

Maintenance Main Items

Replace engine oil Replace engine oil and oil filter Inspect front and rear brakes Check parking brake adjustment Inspect these items:

Tie rod ends, steering gear box, and boots Suspension components Driveshaft boots Brake hoses and lines (including ABS) All fluid levels and condition of fluids Exhaust system ＃ Fuel lines and connections ＃

1 :

If the message ‘‘SERVICE OIL’’ does not appear more than 12 months after the display is reset, change the engine oil every year.

＃

NOTE:

See information on maintenance and emissions warranty on page

183

Independent of the maintenance minder display, replace the brake fluid every 3 years. Inspect idle speed every 160,000 miles (256,000 km). Adjust the valves during services A, B, 1, 2, or 3 only if they are noisy.

Symbol

Maintenance Minder

Maintenance Sub Items

Rotate tires Replace air cleaner element

If you drive in dusty conditions, replace every 15,000 miles (24,000 km).

Replace dust and pollen filter

If you drive primarily in urban areas that have high concentrations of soot in the air from industry and from diesel-powered vehicles, replace every 15,000
miles (24,000 km).

Inspect drive belt Replace transmission fluid Replace spark plugs Inspect valve clearance Replace engine coolant

185

Main MenuTable of ContentsstMaintenance Record

You or the servicing dealer can record all completed maintenance here. When maintenance is performed, record the mileage, circle the coded item(s) completed, and write in any other non-coded items (such as brake fluid replacement) below the codes. Keep the receipts for all work done on your vehicle. Maintenance can also be recorded in your Honda service history booklet.

Mileage

Maintenance Performed

Signature

Date

Mileage

Maintenance Performed

Signature

Date

mi km

mi km

mi km

mi km

mi km

mi km

mi km

186

mi km

mi km

mi km

mi km

mi km

mi km

mi km

Main MenuTable of ContentsstMileage

Maintenance Performed

Signature

Date

Mileage

Maintenance Performed

Signature

Date

Maintenance Record

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

mi km

187

Main MenuTable of ContentsstFluid Locations

ENGINE OIL DIPSTICK (Orange loop)

BRAKE FLUID (Black cap)

ENGINE OIL FILL CAP

WASHER FLUID (Blue cap)

188

AUTOMATIC TRANSMISSION (CVT) FLUID DIPSTICK (Yellow loop)

ENGINE COOLANT RESERVOIR

RADIATOR CAP

Main MenuTable of ContentsstENGINE OIL FILL CAP

Recommended Engine Oil Oil is a major contributor to your engine’s performance and longevity. Always use a premium-grade 0W-20
detergent oil displaying the API Certification Seal. This seal indicates the oil is energy conserving, and that it meets the American Petroleum Institute’s latest requirements.

API CERTIFICATION SEAL

Unscrew and remove the engine oil fill cap on the valve cover. Pour in the oil slowly and carefully so you do not spill any. Clean up any spills immediately. Spilled oil could damage components in the engine compartment. Reinstall the engine oil fill cap, and tighten it securely. Wait a few minutes, and recheck the oil level on the engine oil dipstick. Do not fill above the upper mark; you could damage the engine.

Honda Motor Oil is the preferred 0W-20 lubricant for your vehicle. It is highly recommended that you use Honda Motor Oil in your vehicle for

Adding Engine Oil

optimum engine protection. Make sure the API Certification Seal says ‘‘For Gasoline Engines’’.

The oil viscosity or weight is provided on the container’s label.

Ambient Temperature

A very low-viscosity, fuel-efficient 0W-20 oil is the preferred engine lubricant for your Civic Hybrid. This special oil is formulated to help your engine use less fuel. It is available at your dealer. A 5W-20 oil may be used if 0W-20 is not available.

189

Main MenuTable of ContentsstAdding Engine Oil, Changing the Oil and Filter

Synthetic Oil You may use a synthetic motor oil if it meets the same requirements given for a conventional motor oil: it displays the API certification seal, and it is the proper weight. You must follow the oil and filter change intervals shown on the information display.

Engine Oil Additives Your vehicle does not require any oil additives. Additives may adversely affect the engine or transmission performance and durability.

HOLDING CLIP

BOLTS

3. OnlyonU.S.models

Remove the nine holding clips with a flat-tipped screwdriver and two bolts, then pull the under- cover down.

Changing the Oil and Filter Always change the oil and filter according to the maintenance messages shown on the information display. The oil and filter collect contaminants that can damage your engine if they are not removed regularly.

Changing the oil and filter requires special tools and access from underneath the vehicle. The vehicle should be raised on a service station- type hydraulic lift for this service. Unless you have the knowledge and proper equipment, you should have this maintenance done by a skilled mechanic.

1.

Run the engine until it reaches normal operating temperature, then shut it off.

2.

Open the hood, and remove the engine oil fill cap.

190

Main MenuTable of ContentsstDRAIN BOLT

OIL FILTER

WASHER

4.

Remove the oil drain bolt and washer from the bottom of the engine. Drain the oil into an appropriate container.

5.

Remove the oil filter, and let the remaining oil drain. A special wrench (available from your dealer) is required.

Make sure the oil filter gasket is not stuck to the engine block. If it is, remove it before installing a new oil filter.

6.

Install a new oil filter according to the instructions that come with it.

Changing the Oil and Filter

7.

Put a new washer on the drain bolt, then reinstall the drain bolt. Tighten the drain bolt to:

29 lbf·ft (39 N·m , 4.0 kgf·m)

8.

Refill the engine with the recommended oil.

Engine oil change capacity (including filter):

3.4 US qt (3.2 )

9.

Reinstall the engine oil fill cap. Start the engine. The oil pressure indicator should go out within 5
seconds. If it does not, turn off the engine, and check your work.

10.

Let the engine run for several minutes, then check the drain bolt and oil filter for leaks.

CONTINUED

191

Main MenuTable of ContentsstIf Honda antifreeze/coolant is not available, you may use another major-brand non-silicate coolant as a temporary replacement. Make sure it is a high-quality coolant recommended for aluminum engines. Continued use of any non-Honda coolant can result in corrosion, causing the cooling system to malfunction or fail. Have the cooling system flushed and refilled with Honda antifreeze/coolant as soon as possible.

Changing the Oil and Filter, Engine Coolant

11.

Turn off the engine, let it sit for several minutes, then check the oil level on the dipstick. If necessary, add more oil.

12. OnlyonU.S.models

Put the under-cover back in place and reinstall the nine holding clips. Lock the clips securely by pushing on the center of each clip.

Improper disposal of engine oil can be harmf ul to the environment. If you change your own oil, please dispose of the used oil properly. Put it in a sealed container and take it to a recycling center. Do not discard it in a trash bin or dump it on the ground.

192

Adding Engine Coolant

RESERVE TANK

If the coolant level in the reserve tank is at or below the MIN line, add coolant to bring it up to between the MIN and MAX lines. Inspect the cooling system for leaks.

Always use Honda Long-Life Antifreeze/Coolant Type 2. This coolant is pre-mixed with 50 % antifreeze and 50 % water. Never add straight antifreeze or plain water.

Main MenuTable of ContentsstIf the reserve tank is completely empty, you should also check the coolant level in the radiator.

Removing the radiator cap while the engine is hot can cause the coolant to spray out, seriously scalding you.

Always let the engine and radiator cool down before removing the radiator cap.

Engine Coolant

4.

The coolant level should be up to the base of the filler neck. Add coolant if it is low.

Pour the coolant slowly and carefully so you do not spill any. Clean up any spill immediately; it could damage components in the engine compartment.

5.

Put the radiator cap back on, and tighten it fully.

6.

Pour coolant into the reserve tank. Fill it to halfway between the MAX and MIN marks. Put the cap back on the reserve tank.

Do not add any rust inhibitors or other additives to your vehicle’s cooling system. They may not be compatible with the coolant or engine components.

193

RADIATOR CAP

1.

Make sure the engine and radiator are cool.

2.

Relieve any pressure in the cooling system by turning the radiator cap counterclockwise, without pressing down.

3.

Remove the radiator cap by pushing down and turning counterclockwise.

Main MenuTable of ContentsstWindshield Washers

Check the fluid level in the windshield washer reservoir at least monthly during normal use.

Check the fluid level by removing the cap and looking at the level gauge.

OnCanadianmodels: level indicator comes on when the level is low (see page

The low washer

61

).

Fill the reservoir with a good-quality windshield washer fluid. This increases the cleaning capability and prevents freezing in cold weather.

When you refill the reservoir, clean the edges of the windshield wiper blades with windshield washer fluid on a clean cloth. This will help to condition them.

Do not use engine antif reeze or a vinegar/water solution in the windshield washer reservoir. Antif reeze can damage your vehicle’s paint, while a vinegar/water solution can damage the windshield washer pump. Use only commercially-available windshield washer f luid.

194

Main MenuTable of ContentsstContinuously Variable Transmission (CVT)

2.

3.

Remove the dipstick (yellow loop) from the transmission, and wipe it with a clean cloth.

Insert the dipstick all the way into the transmission securely as shown in the illustration.

DIPSTICK

Check the fluid level with the engine at normal operating temperature.

1.

Park the vehicle on level ground. Start the engine and let it run until the radiator fan comes on, then shut off the engine. For accurate results, wait about 60 seconds before going to step 2, but don’t wait longer than 90 seconds.

HOT Range

UPPER MARK LOWER MARK

4.

Remove the dipstick and check the fluid level. It should be between the upper and lower marks within the HOT range.

Transmission Fluid

5.

If the level is below the lower mark, add fluid into the dipstick hole to bring it to the level between the upper and lower marks.

Pour the fluid slowly and carefully so you do not spill any. Clean up any spill immediately; it could damage components in the engine compartment.

Always use Honda CVT Fluid (Continuously Variable Transmission fluid).

CONTINUED

195

Main MenuTable of ContentsstTransmission Fluid, Brake Fluid

To thoroughly flush the transmission, the technician should drain and refill it with Honda CVT fluid, then drive the vehicle for a short distance. Do this three times. Then drain and refill the transmission a final time.

6.

Insert the dipstick all the way back into the transmission securely.

The transmission should be drained and refilled with new fluid when this service is indicated by a maintenance message on the information display.

If you are not sure how to add fluid, contact your dealer.

Brake Fluid Check the brake fluid level in the reservoirs monthly.

Replace the brake fluid every 3 years, independent of mileage.

Always use Honda Heavy Duty Brake Fluid DOT 3. If it is not available, you should use only DOT 3
or DOT 4 fluid, from a sealed container, as a temporary replacement.

Using any non-Honda brake fluid can cause corrosion and decrease the life of the system. Have the brake system flushed and refilled with Honda Heavy Duty Brake Fluid DOT 3 as soon as possible.

Brake fluid marked DOT 5 is not compatible with your vehicle’s braking system and can cause extensive damage.

196

MAX

MIN

The fluid level should be between the MIN and MAX marks on the side of the reservoir. If the level is at or below the MIN mark, your brake system needs attention. Have the brake system inspected for leaks or worn brake pads/shoes.

Main MenuTable of ContentsstHeadlight Aiming The headlights were properly aimed when your vehicle was new. If you regularly carry heavy items in the trunk, readjustment may be required. Adjustment should be done by your dealer or other qualified mechanic.

Replacing a Headlight Bulb Your vehicle has halogen headlight bulbs. When replacing a bulb, handle it by its base, and protect the glass from contact with your skin or hard objects. If you touch the glass, clean it with denatured alcohol and a clean cloth.

Halogen headlight bulbs get very hot when lit. Oil, perspiration, or a scratch on the glass can cause the bulb to overheat and shatter.

HighBeamHeadlight

CLIP

Lights

CLIP

COOLANT TUBE

HOLDER

1.

Open the hood. To change a bulb on the left side, remove the coolant tube from the two clips.

Remove the reserve tank from its holder by pulling it straight up.

CONTINUED

197

Main MenuTable of ContentsstLights

BULB

SOCKET CONNECTOR

TAB

2.

3.

Remove the bulb from the headlight assembly by turning it one-quarter turn counterclockwise.

Remove the electrical connector from the socket by pushing on the tab and pulling the connector down.

198

4.

5.

Push the electrical connector back onto the bulb. Make sure it is on all the way.

Install the new bulb, and turn it one-quarter turn clockwise to lock it in place.

6.

Turn on the headlights to test the new bulb.

7.

If you replaced a headlight bulb on the driver’s side, reinstall the engine coolant reserve tank.

LowBeamHeadlight

HOLDING CLIP

1.

To change the bulb on the driver’s side, start the engine, turn the steering wheel all the way to the right, then turn off the engine. To change the bulb on the passenger’s side, turn the steering wheel to the left.

2.

Use a flat-tipped screwdriver to remove the two holding clips from the inner fender, and pull the inner fender cover back.

Main MenuTable of Contentsst5.

6.

Install the new bulb, and turn it one-quarter turn clockwise to lock it in place.

Push the electrical connector back onto the bulb. Make sure it is on all the way.

7.

Turn on the headlights to test the new bulb.

8.

Reinstall the inner fender cover. Then reinstall the holding clips, and lock them in place by pushing on their centers.

SOCKET

BULB

TAB

3.

4.

Remove the bulb from the headlight assembly by turning it one-quarter turn counterclockwise.

Remove the electrical connector from the socket by pushing on the tab and pulling the connector down.

Lights

Replacing the Front Side Marker/ Turn Signal Light Bulb

HOLDING CLIP

1.

To change the bulb on the driver’s side, start the engine, turn the steering wheel all the way to the right, then turn off the engine. To change the bulb on the passenger’s side, turn the steering wheel to the left.

CONTINUED

199

Main MenuTable of ContentsstLights

BULB

2.

Use a flat-tipped screwdriver to remove the two holding clips from the inner fender, and pull the inner fender cover back.

3.

Remove the bulb from the headlight assembly by turning it one-quarter turn counterclockwise.

200

4.

Remove the bulb from the socket by pushing the bulb in and turning it counterclockwise until it unlocks.

5.

Install the new bulb in the socket. Turn it clockwise to lock it in place.

6.

Insert the socket back into the headlight assembly. Turn it clockwise to lock it in place.

7.

Turn on the lights to make sure the new bulb is working.

8.

Reinstall the inner fender cover. Then reinstall the holding clips, and lock them in place by pushing on their centers.

Replacing Rear Bulbs (In Fenders)

FASTENER

FASTENER

1.

2.

Open the trunk. Use the flat-tipped screwdriver to remove the screws in the center of each fastener on the side of the boot lining. Remove the fasteners first, then pull the lining back carefully. Determine which of the four bulbs is burned out: stop/tail-light, back- up light, side marker light, or turn signal light.

Main MenuTable of ContentsstLights

Replacing Rear Bulbs (in Trunk Lid)

BULBS

BULB

SOCKETS

SOCKETS

BULB

3.

Remove the socket by turning it one-quarter turn counterclockwise.

6.

Turn on the lights to make sure the new bulb is working.

4.

5.

Pull the bulb straight out of its socket. Push the new bulb straight into the socket until it bottoms.

Reinstall the socket into the light assembly by turning it clockwise until it locks.

7.

8.

Reinstall the trunk lining. Make sure it is installed under the edge of the trunk seal.

Put the fasteners into the holes on the side of the trunk lining. Reinstall the screws.

FASTENER

1.

Open the trunk.

Use the Phillips-head screwdriver to remove the screws in the center of each fastener on the back of the boot lid. Remove the fasteners first, then pull the lining back carefully.

CONTINUED

201

Main MenuTable of ContentsstLights, Roof Antenna

BULB

SOCKET

2.

Remove the socket by turning it one-quarter turn counterclockwise.

3.

4.

Pull the bulb straight out of its socket. Push the new bulb straight into the socket until it bottoms.

Insert the socket back into the light assembly. Turn it clockwise to lock it in place.

5.

Turn on the lights to make sure the new bulb is working.

6.

Push the trunk lid trim back into position.

7.

Put the fasteners into the holes on the trunk lid trim. Reinstall the screws.

Roof Antenna

Before using an automatic car wash, remove the radio antenna so it does not get damaged. Remove the antenna by unscrewing it. When you reinstall the antenna, tighten it securely.

Before entering or parking in areas with low ceiling height, remove the antenna.

202

Main MenuTable of ContentsstSeat Belts

Floor Mats

LOOP

Cleaning the Seat Belts, Floor Mats

If you use non-Honda floor mats, make sure they fit properly and that they can be used with the floor mat anchors. Do not put additional floor mats on top of the anchored mats.

If your seat belts get dirty, use a soft brush with a mixture of mild soap and warm water to clean them. Do not use bleach, dye, or cleaning solvents. Let the belts air dry before you use the vehicle. Dirt build-up in the loops of the seat belt anchors can cause the belts to retract slowly. Wipe the insides of the loops with a clean cloth dampened in mild soap and warm water or isopropyl alcohol.

Ifequipped The floor mats that came with your vehicle hooks over the floor mat anchors. This keeps the floor mat from sliding forward and possibly interfering with the pedals.

If you remove the driver’s floor mat, make sure to re-anchor it when you put it back in your vehicle.

CONTINUED

203

Main MenuTable of ContentsstDust and Pollen Filter, Wiper Blades

Wiper Blades Check the condition of the wiper blades at least every 6 months. Replace them if you find signs of cracking in the rubber, and areas that are getting hard or if they leave streaks and unwiped areas when used.

Dust and Pollen Filter This filter removes the dust and pollen that is brought in from the outside through the heating and cooling system/climate control system.

Have your dealer replace the filter when this service is indicated by a maintenance message on the information display. It should be replaced every 15,000 miles (24,000
km) if you drive primarily in urban areas that have high concentrations of soot in the air, or if the flow from the heating and cooling system becomes less than usual.

204

WIPER ARMS

To replace a wiper blade:

1.

Raise each wiper arm off the windshield, lifting the driver’s side first, then the passenger’s side.

Do not open the hood when the wiper arms are raised, or you will damage the hood and wiper arms.

Main MenuTable of ContentsstCOVER

2.

Remove the cover, by squeezing the two tabs and pulling it straight out.

As shown above, cover the tip of a flat-tipped screwdriver with a cloth and move the screwdriver in the direction of the arrow.

Wiper Blades

BLADE ASSEMBLY

TAB

3.

Disconnect the blade assembly from the wiper arm:

Press and hold the lock tab. Slide the blade assembly toward the lock tab until it releases from the wiper arm.

When replacing a wiper blade, make sure not to drop the wiper blade or wiper arm down on the windshield.

CONTINUED

205

Main MenuTable of ContentsstWiper Blades

REINFORCEMENT STRIP

WIPER BLADE

4.

Remove the blade from the blade assembly:

Find the side of the blade labeled ‘‘LOCK.’’ This is the side you pull out. Pull back the end of the blade assembly on the ‘‘LOCK’’ side of the blade. Then grab the end of the blade, and slide it out.

5.

Examine the new wiper blades. If they have no plastic or metal reinforcement along the back edge, remove the metal reinforcement strips from the old wiper blade, and install them in the slots along the edge of the new blade.

206

6.

Install the new blade onto the blade assembly:

Pull back either end of the blade assembly. Place the side of the blade not labeled ‘‘LOCK’’ on the end of the blade assembly, and slide the blade onto the assembly until it is fully installed.

7.

Slide the wiper blade assembly onto the wiper arm. Make sure it locks in place.

8.

Reinstall the cover onto the blade assembly.

9.

Make sure the blade is completely installed and that its edge is not bunched up.

10.

Lower the wiper arm down against the windshield, the passenger’s side first, then the driver’s side.

Main MenuTable of ContentsstWheels, Tires

Wheels Clean the wheels as you would the rest of the exterior. Wash them with the same solution, and rinse them thoroughly.

Tires To safely operate your vehicle, your tires must be the proper type and size, in good condition with adequate tread, and correctly inflated.

Inflation Guidelines Keeping the tires properly inflated provides the best combination of handling, tread life, and riding comfort.

Aluminum alloy wheels have a protective clear-coat that keeps the aluminum from corroding and tarnishing. Cleaning the wheels with harsh chemicals (including some commercial wheel cleaners) or a stiff brush can damage the clear-coat. To clean the wheels, use a mild detergent and a soft brush or sponge.

The following pages give more detailed information on how to take care of your tires and what to do when they need to be replaced.

Underinflated tires wear unevenly, adversely affect handling and fuel economy, and are more likely to fail from being overheated.

Using tires that are excessively worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.

Follow all instructions in this owner’s manual regarding tire inflation and maintenance.

Overinflated tires can make your vehicle ride more harshly, are more prone to damage from road hazards, and wear unevenly.

We recommend that you visually check your tires every day. If you think a tire might be low, check it immediately with a tire gauge.

207

Main MenuTable of ContentsstTires

Use a gauge to measure the air pressure in each tire at least once a month. Even tires that are in good condition may lose 1 to 2 psi (10 to 20 kPa, 0.1 to 0.2 kgf/cm ) per month. Remember to check the sparetireatthesametime.

Check the air pressures when the tires are cold. This means the vehicle has been parked for at least 3
hours, or driven less than 1 mile (1.6
km). Add or release air, if needed, to match the recommended cold tire pressures.

208

If you check air pressures when the tires are hot [driven for several miles (kilometers)], you will see readings 4
to6psi(30to40kPa,0.3to0.4
kgf/cm ) higher than the cold readings. This is normal. Do not let air out to match the recommended cold air pressure. The tire will be underinflated.

Youshouldgetyourowntire pressure gauge and use it whenever you check your tire pressures. This will make it easier for you to tell if a pressure loss is due to a tire problem and not due to a variation between gauges.

While tubeless tires have some ability to self-seal if they are punctured, you should look closely for punctures if a tire starts losing pressure.

Recommended Tire Pressures The following chart shows the recommended cold tire pressures for most normal driving conditions.

Tire Size

P195/65R15 89S

Cold Tire Pressure Front/Rear: 32 psi (220 kPa , 2.2
kgf/cm )

The compact spare tire pressure is: 60 psi (420 kPa , 4.2 kgf/cm )

243

or refer to the tire

See page placard on the driver’s doorjamb for correct tire pressure.

For convenience, the recommended tire sizes and cold tire pressures are on a label on the driver’s doorjamb.

Main MenuTable of ContentsstTire Inspection Every time you check inflation, you should also examine the tires for damage, foreign objects, and wear.

You should look for:

Bumps or bulges in the tread or side of the tire. Replace the tire if you find either of these conditions.

Cuts, splits, or cracks in the side of the tire. Replace the tire if you can see fabric or cord.

Excessive tread wear.

INDICATOR LOCATION MARKS

TREAD WEAR INDICATOR

Your tires have wear indicators molded into the tread. When the tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the tread. This shows there is less than 1/16 inch (1.6 mm) of tread left on the tire.

A tire this worn gives very little traction on wet roads. You should replace the tire if you can see three or more tread wear indicators.

Tires

Tire Maintenance In addition to proper inflation, correct wheel alignment helps to decrease tire wear. If you find a tire is worn unevenly, have your dealer check the wheel alignment.

Have your dealer check the tires if you feel a consistent vibration while driving. A tire should always be rebalanced if it is removed from the wheel. When you have new tires installed, make sure they are balanced. This increases riding comfort and tire life. For best results, have the installer perform a dynamic balance.

Improper wheel weights can damage your vehicle’s aluminum wheels. Use only Honda wheel weights f or balancing.

209

Main MenuTable of ContentsstTires

Tire Rotation

Front

Front

(Front Non-directional Tires and Wheels)

(Front Directional Tires and Wheels)

To help increase tire life and distribute wear more evenly, rotate the tires according to the maintenance messages displayed on the information display. Move the tires to the positions shown in the chart each time they are rotated. If you purchase directional tires, rotate only front-to-back.

210

speed and may cause the system to activate.

If you ever replace a wheel, make sure the new one matches the specifications of the original. Replacement wheels are available at your dealer.

Installing improper tires on your vehicle can affect handling and stability. This can cause a crash in which you can be seriously hurt or killed.

Always use the size and type of tires recommended in this owner’s manual.

Replacing Tires and Wheels Replace your tires with radial tires of the same size, load range, speed rating, and maximum cold tire pressure rating (as shown on the tire’s sidewall).

Mixing radial and bias-ply tires on your vehicle can reduce braking ability, traction, and steering accuracy. Using tires of a different size or construction can cause the ABS to work inconsistently.

It is best to replace all four tires at the same time. If that is not possible or necessary, replace the two front tires or two rear tires as a pair. Replacing just one tire can seriously affect your vehicle’s handling.

The ABS works by comparing the speed of the wheels. When replacing tires, use the same size originally supplied with the vehicle. Tire size and construction can affect wheel

Main MenuTable of ContentsstWheel and Tire Specifications Wheels:

15 x 6 J

Tires:

P195/65R15 89S

244

for DOT tire quality

See page grading information, and page for tire size information. 246

Winter Driving Tires marked ‘‘M S’’ or ‘‘All Season’’ on the sidewall have an all- weather tread design suitable for most winter driving conditions.

＋

For the best performance in snowy or icy conditions, you should install snow tires or tire chains. They may be required by local laws under certain conditions.

Tires

When installing cables, follow the manufacturer’s instructions, and mount them as tight as you can. Make sure they are not contacting the brake lines or suspension. Drive slowly with them installed. If you hear them coming into contact with the body or chassis, stop and investigate. Remove them as soon as you begin driving on cleared roads.

Traction devices that are the wrong size or improperly installed can damage your vehicle’s brake lines, suspension, body, and wheels. Stop driving if they are hitting any part of the vehicle.

SnowTires If you mount snow tires on your vehicle, make sure they are radial tires of the same size and load range as original tires. Mount snow tires on all four wheels. The traction provided by snow tires on dry roads maybelowerthanyouroriginaltires. Check with the tire dealer for maximum speed recommendations.

TireChains Because your vehicle has limited tire clearance, mount only SAE Class ‘‘S’’ cable-type traction devices, with rubber chain tensioners, on the front tires. Use traction devices only when required by driving conditions or local laws. Make sure they are the correct size for your tires. Metal link- type ‘‘chains’’ should not be used.

211

Main MenuTable of ContentsstChecking the 12 Volt Battery

TEST INDICATOR WINDOW

Check the condition of the 12 volt battery monthly by looking at the test indicator window. The label on the battery explains the test indicator’s colors.

212

Check the terminals for corrosion (a white or yellowish powder). To remove it, cover the terminals with a solution of baking soda and water. It will bubble up and turn brown. When this stops, wash it off with plain water. Dry off the battery with a cloth or paper towel. Coat the terminals with grease to help prevent further corrosion.

If additional battery maintenance is needed, see your dealer or a qualified technician.

Battery posts,

WARNING: terminals, and related accessories contain lead and lead compounds. Wash your hands after handling.

If you need to connect the battery to a charger, disconnect both cables to prevent damaging your vehicle’s electrical system. Always disconnect the negative ( − reconnect it last.

) cable first, and

The battery gives off explosive hydrogen gas during normal operation.

A spark or flame can cause the battery to explode with enough force to kill or seriously hurt you.

Wear protective clothing and a face shield, or have a skilled technician do the battery maintenance.

If your vehicle’s 12 volt battery is disconnected or goes dead, the IMA battery level gauge reading will not be correct the next time you turn the ignition switch to the ON (II) position. It will show less than the actual level temporarily. It will show the correct level after you drive for at least 30 minutes.

Main MenuTable of ContentsstVehicle Storage

If you need to park your vehicle for an extended period (more than 1
month), there are several things you should do to prepare it for storage. Proper preparation helps prevent deterioration and makes it easier to get your vehicle back on the road. If possible, store your vehicle indoors.

Fill the fuel tank.

Block the rear wheels.

If the vehicle is to be stored for a longer period, it should be supported on jackstands so the tires are off the ground.

Leave one window open slightly (if the vehicle is being stored indoors).

Change the engine oil and filter.

Disconnect the 12 volt battery.

Cover the vehicle with a ‘‘breathable’’ cover, one made from a porous material such as cotton. Non-porous materials, such as plastic sheeting, trap moisture, which can damage the paint.

Reconnect the 12 volt battery and drive your vehicle every month for about 30 minutes. This will keep the IMA battery charged and in good condition.

Wash and dry the exterior completely.

Clean the interior. Make sure the carpeting, floor mats, etc., are completely dry.

Leave the parking brake off. Put the transmission in Park.

Support the front wiper blade arms with a folded towel or rag so they do not touch the windshield.

To minimize sticking, apply a silicone spray lubricant to all door and trunk seals. Also, apply a vehicle body wax to the painted surfaces that mate with the door and trunk seals.

If possible, periodically run the engine until it reaches full operating temperature (the cooling fans cycle on and off twice). Preferably, do this once a month.
