File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
[LG01775(ALL)04/93]
[LG01780(ALL)01/92]
one third page art:0032087-B
[LG01800(ALL)01/94]
*[LG01950(ALL)01/95] %*[LG01975(ALL)05/95] [LG01980(ALL)03/94]
The mechanical cluster on the Probe GT model is similar to the one shown. The two exceptions are: the speedometer on the GT model shows 140 mph (225 km/h) and it has a 7,000 rpm red-line tachometer.
GT model speedometer and tachometer The following warning lights and gauges are on the cluster. All of the warning lights and gauges alert you to possible problems with your vehicle. The following sections detail what each of these indicators means. Indicator Lights and Chimes Safety Belt Warning Light and Chime This warning light and chime remind you to fasten your safety belt. If you do not fasten your safety belt before the ignition is turned to ON, the chime will sound for 4 to 8 seconds and the warning light will illuminate for 1 to 2 minutes, or until the safety belt is fastened. If you fasten the safety belt before the ignition is turned to ON, neither the light nor chime will activate.
54
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
[LG01995(ALL)01/92]
one inch art:0032097-A
*[LG02000(ALL)01/95] *[LG02050(ALL)06/93]
[LG02100(ALL)01/92]
one inch art:0032051-A
*[LG02120(ALL)05/95]
*[LG02200(ALL)03/95] [LG02300(ALL)02/91]
Safety belt light Air Bag Readiness Light This light illuminates for six seconds when the ignition is turned to the ON position. If the light fails to illuminate, continues to flash, remains on, or if a series of five beeps is heard, have the system serviced as soon as possible.
Air bag readiness light
RWARNING
If any of these things happen, even intermittently, have the air bag system serviced at your Ford or Lincoln-Mercury dealer immediately.
Brake System Warning Light Your vehicle has a divided brake system. If one part isn’t working, the other part can still work and stop you. For good braking, though, you need both systems working well. If the warning light goes on, there could be a problem. Have your brake system inspected right away.
55
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
[LG02350(ALL)01/94]
[LG02550(ALL)06/93]
one inch art:0030319-E
[LG02600(ALL)01/93]
*[LG02650(ALL)02/94]
*[LG02700(ALL)05/95]
This light should come on as you start the vehicle. If it doesn’t come on then, have it fixed so it will be ready to warn you if there’s a problem.
Brake system and parking brake light This light comes on briefly when you turn the ignition key to START. It normally goes off shortly after the engine starts and you release the parking brake, but it may stay on for up to 60 seconds. If the light stays on for longer than 60 seconds or comes on after you have fully released the parking brake, have the hydraulic brake system serviced. This light will also come on if the parking brake does not release fully. If it does stay on after the parking brake is fully released, it means there may be a brake problem. Pull off the road and stop carefully. You may notice that the pedal is harder to push, the pedal may go closer to the floor, or it may take longer to stop the vehicle. Try the brakes again after you have stopped.
RWARNING
The BRAKE light indicates that the brakes may not be working properly. Have the brakes checked immediately.
56
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
%*[LG02750(ALL)02/95] [LG02760(ALL)01/94]
[LG02771(ALL)06/95]
one inch art:0032359-C
*[LG02780(ALL)05/95]
*[LG02785(ALL)06/95]
*[LG02790(ALL)09/93]
Anti-Lock Brake System Warning Light When the ignition switch is turned to the ON position, the anti-lock brake system warning light will come on. When the engine is started, the anti-lock brake system control unit will determine if all components of the system are operating correctly. The warning light could remain on for two to four seconds.
The anti-lock brake system warning light
RWARNING
If the anti-lock brake system warning light remains on or comes on while driving, have the braking system checked by a qualified service technician as soon as possible.
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is not lit, the anti-lock system is disabled but normal brake function remains operational.
NOTE: If your vehicle must be jump-started
because of a low battery, the anti-lock brake system warning light could remain on. This is due to low battery voltage and does not indicate a malfunction in the system. Under these circumstances, you should drive your vehicle only after the battery has had time to charge and the light has gone out.
57
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
[LG04360(ALL)04/95]
[LG04375(ALL)08/91]
[LG04395(ALL)01/92]
one inch art:0032048-A
*[LG04500(ALL)01/95] *[LG04600(ALL)03/95]
*[LG04700(ALL)01/92]
one inch art:0030174-A
%*[LG05300(ALL)03/95] *[LG05400(ALL)05/95]
*[LG05450(ALL)09/93]
one inch art:0030175-B
The Low Fuel Light This light comes on when fuel level in your tank has reached approximately 2-3 gallons (7-10
liters).Low fuel light High Beam Light This light comes on when the headlamps are turned to high beam or when you flash the lights.
High beam light Check Engine Warning Light This light comes on when the electronic engine control system is not working properly. This is the computer system that controls the operating conditions of the engine.
Check engine warning light
58
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
*[LG05600(ALL)05/95]
*[LG05800(ALL)05/95]
[LG05885(ALL)06/93]
[LG05886(ALL)05/95]
[LG05888(ALL)06/93]
[LG05889(ALL)01/94]
one inch art:0032053-A
This light comes on briefly when you turn the ignition to the ON position, but should turn off when the engine starts. If the light does not come on when you turn the ignition to the ON position or if it comes on and stays on when you are driving, have your vehicle serviced as soon as possible. This indicates a possible problem with one of the engine’s emission control systems. You do not need to have your vehicle towed in. If the light turns on and off briefly while you are driving, it means that the condition is no longer present. O/D OFF Light (If equipped) This light tells you that the overdrive off (O/D OFF) button on the shift selector has been pushed. When the light is on, the transaxle will not shift into overdrive. Depressing the button on the shift selector again will return the vehicle to “overdrive on” mode. The transaxle will be in the “overdrive on” mode when the vehicle is started even if the O/D OFF mode was selected when the vehicle was last shut off. If the light does not come on when the O/D OFF button is pressed, or if the light flashes when you are driving, have your vehicle serviced at the first opportunity. If this condition persists, damage could occur to the transaxle.
Overdrive OFF light
59
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
*[LG05890(ALL)10/93] *[LG05900(ALL)01/95] *[LG06000(ALL)01/95] *[LG06025(ALL)05/93]
*[LG06075(ALL)05/93]
[LG06100(ALL)01/89]
[LG06200(ALL)05/95]
[LG06300(ALL)01/94]
*[LG06310(ALL)05/94] [LG06330(ALL)05/95]
[LG06335(ALL)11/91] *[LG06340(ALL)01/95] *[LG06350(ALL)04/95]
Gauges Fuel Gauge The fuel gauge displays approximately how much fuel you have in the fuel tank. The ignition must be turned off while putting fuel in the tank in order to get a correct fuel gauge reading after the ignition is turned on. The fuel gauge indicator may vary slightly while the vehicle is in motion. This is the result of fuel movement within the tank. You can get a more accurate reading with the vehicle on smooth, level ground. Charging System Gauge This gauge tells you your battery’s voltage when you turn your ignition key to ON. When you start your engine, the pointer should move to the NORMAL range if you are not operating any electrical accessories. (If electrical accessories are operating and the engine is not running, the pointer may move into the red area). If the pointer moves into the red area when no electrical accessories are operating, have the vehicle’s electrical system checked. Engine Oil Pressure Gauge The gauge needle should stay in the NORMAL range (indicating normal engine oil pressure). If the needle drops below the NORMAL range into the low range, there is a loss of oil pressure. If this happens: 1. Pull off the road as soon as safely possible. 2. Shut off the engine immediately or severe
engine damage could result.
60
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
[LG06360(ALL)05/95]
[LG06370(ALL)11/91]
*[LG06400(ALL)01/95] *[LG06500(ALL)03/95]
*[LG06600(ALL)03/94]
*[LG06700(ALL)05/95]
*[LG06800(ALL)01/95] *[LG06900(ALL)03/95] *[LG07000(ALL)04/95] *[LG07100(ALL)05/95] *[LG07200(ALL)03/95]
3. Check the oil level when the vehicle is on
level ground.
4. Add only as much oil as the engine needs before you drive the vehicle again. Do not overfill the oil reservoir. For more information, see Adding engine oil in the Index.
Engine Coolant Temperature Gauge This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level or mixture, the gauge indication will not be accurate. The pointer usually moves from C (cold) into the NORMAL band as your vehicle warms up. Under most driving conditions, the pointer should stay in the NORMAL band. If you are driving in heavy traffic or on an extended grade in hot weather, the pointer may reach to the top of the NORMAL band. If, under any circumstances, the pointer moves above the NORMAL band, the engine coolant is overheating and continued operation may cause engine damage. If your engine coolant overheats: 1. Pull off the road as soon as it is safely
possible.
2. Shut off the engine immediately or severe
engine damage could result.
3. Let the engine cool. 4. Check the coolant level following the
instructions on checking and adding coolant to your engine. (See Engine coolant in the Index.) If you do not follow these instructions, you or others could be injured.
61
File:prlgp.ex Update:Fri Jun 23 19:38:06 1995
*[LG07250(ALL)03/95]
*[LG07300(ALL)05/92]
*[LG07500(ALL)01/95] *[LG07600(ALL)01/95] *[LG07700(ALL)01/95] *[LG07800(ALL)01/95] *[LG08000(ALL)11/94] [LG08050(ALL)01/95]
*[LG09000(ALL)02/95] [LG09001(ALL)01/95]
For instructions on checking and adding coolant to your engine, see Engine coolant in the Index. If you do not follow these instructions, you or others could be injured. 5. Add as much coolant as your engine needs. If the engine continues to overheat, have the coolant system serviced.
Speedometer The speedometer tells you how many miles (kilometers) per hour your vehicle is moving. Odometer The odometer tells you the total number of miles (kilometers) your vehicle has been driven. Trip Odometer Use the trip odometer to track your mileage. Simply set the trip odometer to zero by pressing the reset button. Tachometer The tachometer indicates approximate engine revolutions per minute, and is located on the right-hand side of the instrument cluster. The tachometer pointer may move slightly when the key is placed in the ACC or ON position, with the engine off. This pointer movement is normal, and will not affect the accuracy of the tachometer once the engine is running.
62
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
Instrument Panel Controls
[IP00800(ALL)05/95]
The main controls for the climate control system, clock, and radio are on the instrument panel.
63
F
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
%*[IP00875(ALL)05/95]
*[IP00900(ALL)05/95] *[IP01000(ALL)02/91]
[IP01100(ALL)01/95]
[IP01300(ALL)05/95]
[IP01400(ALL)02/93]
one third page art:0032040-C
[IP01800(ALL)04/95]
[IP01900(ALL)04/95]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the instrument panel should be avoided. The dull finish in this area is to help protect the driver from undesirable windshield reflection.
The Climate Control System Heating Only System (Without Air Conditioning) Function selection The heater in your vehicle has three controls used for air direction, temperature and fan speed. The function selector control lets you direct heated or unheated air through the instrument panel registers, or down to the floor. It also allows you to vent your vehicle with outside air.
Heating only system control panel Turning the function selector control all the way to the right (V) directs air to defroster vents and the side window defoggers only. With the function selector control in the MIX position, air is directed out the defrosters, side defoggers and the floor heater outlets.
65
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
[IP02000(ALL)08/91]
[IP02025(ALL)01/95]
[IP03325(ALL)06/94]
[IP03330(ALL)11/91]
[IP03400(ALL)06/94]
[IP03500(ALL)04/95]
*[IP03600(ALL)06/94] *[IP03800(ALL)10/93] [IP03850(ALL)08/91]
[IP03900(ALL)08/91]
[IP03975(ALL)08/91]
[IP04000(ALL)08/91]
The FLOOR position directs air out the floor outlets and the side window defoggers. Ventilate your vehicle with outside air by choosing the VENT position. Temperature control The air temperature can be adjusted by moving the marker on the temperature control to the red area for warm air, or to the blue area for unheated air. The air will become warmer or cooler depending on how far the control is turned. Fan speed control Fan speed can be controlled by turning the control from LO to HI. Turning On the Heat To heat the inside of your vehicle: 1. Turn the function selector control to FLOOR.
When FLOOR is selected, air is directed through the floor registers, and a little air is also directed at the windshield and side windows to help prevent fogging.
2. Turn the temperature control all the way to
the right in the red area, or to the desired temperature.
3. Set the fan at the desired speed.
66
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
*[IP04300(ALL)01/89]
[IP04500(ALL)04/95]
[IP04550(ALL)04/95]
[IP04600(ALL)08/91]
*[IP04650(ALL)10/93] *[IP04700(ALL)01/89] [IP05000(ALL)08/91]
[IP05100(ALL)01/89]
*[IP05200(ALL)01/94] *[IP05300(ALL)01/93]
[IP05450(ALL)08/91]
[IP05475(ALL)08/91]
[IP05550(ALL)08/91]
*[IP05600(ALL)01/89]
Defrosting the Windshield and Side Windows 1. Turn the function selector control to the
defrost position.
When V is selected, air is directed to the windshield and side windows. 2. Turn the temperature control to the desired
temperature.
3. Set the fan at the desired speed. Heating and Defrosting at the Same Time 1. Set the function selector control to MIX. 2. Set the temperature and fan speed as
desired.
Ventilating Your Vehicle With Outside Air On mild days, you may want to ventilate your vehicle with outside air. To open the vents: 1. Turn the function selector control to VENT.
When VENT is selected, air is directed out of the panel registers.
2. Turn the temperature control to the desired
temperature.
3. Set the fan speed as desired.
67
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
*[IP05800(ALL)12/91] *[IP05900(ALL)03/94]
*[IP06000(ALL)03/94]
[IP06150(ALL)04/95]
*[IP06200(ALL)01/89] *[IP06300(ALL)01/89] *[IP06400(ALL)12/91]
*[IP06500(ALL)12/03]
*[IP06600(ALL)06/93] [IP06850(ALL)01/95]
[IP06900(ALL)08/91]
one third page art:0032041-A
Tips for Controlling the Temperature in Your Vehicle q To vary the temperature inside your vehicle, move the temperature selector toward the red area for warmer air and toward the blue area for cooler air. If you drive with the fan off and the windows closed, the windows may fog up. To prevent fogging:
1. Set the function selector control to VENT,
MIX, FLOOR or the V position.
2. Set the desired temperature. 3. Set the desired fan speed. q Do not put objects under the front seats that will interfere with the flow of air to the back seats.
q Remove any snow, ice, or leaves from the
area below the windshield on the outside of your vehicle. They could block the air intake.
Air Conditioning System (If equipped) Operate the air conditioning by using the climate controls on the center of the instrument panel.
Air conditioning controls
68
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
*[IP06950(ALL)01/95]
*[IP07000(ALL)01/95]
*[IP07050(ALL)01/95]
[IP07150(ALL)08/91]
[IP07350(ALL)01/95] [IP07360(ALL)01/95]
*[IP07375(ALL)09/93] [IP07400(ALL)08/91]
[IP07450(ALL)08/91]
[IP07475(ALL)08/91] *[IP07500(ALL)09/93]
Sometimes you may notice slight engine surging if you have the air conditioner on. This is normal, as the system is designed to cycle the compressor on and off to maintain desired cooling. The reduced compressor operation should benefit fuel economy. On some vehicles with air conditioning, wide-open throttle acceleration will temporarily cut off the air conditioning. Since the air conditioner removes a lot of moisture from the air during operation, it is normal for water to drip on the pavement under the air conditioner drain after you have stopped the vehicle. Action for heating and windshield defrosting are identical for cars equipped with either the Heating Only System or the Heating and Air Conditioning System. For instructions about these functions, see the previous section, Heating Only System. For instructions about using the air conditioning, see the following sections. MAX A/C When MAX A/C is selected, cooled interior air is recirculated through the system. This position is more efficient than NORM A/C. To cool your vehicle quickly in warm weather: 1. Turn the function selector control to MAX
A/C.
2. Turn the temperature control to the blue
(cool) area.
3. Set the fan at the desired speed.
If the inside of your vehicle is very warm, drive for a few minutes with the windows down. This forces most of the hot, stale air out of the vehicle and helps the air conditioning cool the vehicle faster.
69
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
[IP07550(ALL)01/95]
[IP07560(ALL)11/91]
[IP07575(ALL)08/91]
[IP07800(ALL)04/95]
[IP08025(ALL)01/94]
[IP08050(ALL)05/95]
[IP08075(ALL)08/91]
[IP08150(ALL)08/91]
*[IP08175(ALL)10/93] [IP08400(ALL)01/95]
Because MAX A/C uses recirculated air, MAX is usually more efficient than NORM A/C. You can switch to outside air (NORM A/C) at any time, especially after the vehicle has cooled down. You will notice a slight odor when using the MAX A/C position. This is normal. If the odor becomes annoying, switch the function selector to NORM A/C. To provide the most quiet operation when using MAX A/C, reduce the fan speed after a comfortable temperature has been reached. NORM A/C When maximum air conditioning is not needed, you can use the NORM A/C position to cool your vehicle with outside air. Cooling your vehicle this way brings in outside air and is quieter, but it is less efficient. To cool your vehicle using outside air: 1. Turn the function selector control to NORM
A/C.
2. Turn the temperature control all the way to
left to the blue (cool) area.
3. Set the fan at the desired speed. In mild weather, setting the function selector control in the VENT position will add cool air to your vehicle without using the air conditioning. You will get better fuel economy without using the air conditioning.
70
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
*[IP13850(ALL)02/91] *[IP13875(ALL)02/91]
[IP13890(ALL)01/95]
*[IP13900(ALL)12/93]
[IP14000(ALL)06/94]
quarter page art:0032068-D
[IP14200(ALL)01/95]
Engine Idle Speed Control System Genuine Ford air conditioning (either factory-installed or dealer-installed) has an engine idle speed control system that compensates for engine speed loss that may occur when the air conditioning compressor is running. This idle speed control holds the engine idle essentially constant, regardless of whether the air conditioning system is on or off. NOTE: Whenever service to the air
conditioning system is required, make sure the service facility uses a refrigerant recycling system. These systems will capture the refrigerant for reuse. Releasing certain refrigerants into the atmosphere is hazardous to the environment.
Rear Window Defroster (If equipped) (Standard in Canada)
Rear window defroster button The defroster for the rear window clears frost, fog, or thin ice from both the inside and outside of the rear window. The rear window defroster button is located on the lower right of the instrument panel below the climate control panel. This button is also used to activate your heated power mirrors (if equipped).
71
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
*[IP14300(ALL)02/95] *[IP14400(ALL)02/95] *[IP14500(ALL)09/93] [IP14600(ALL)03/91]
[IP14800(ALL)01/92]
%*[IP14900(ALL)03/94]
*[IP17700(ALL)01/92] *[IP20500(ALL)01/95] *[IP20600(ALL)01/92]
*[IP20700(ALL)09/93]
[IP20800(ALL)01/94]
quarter page art:0030050-B
To defrost the rear window: 1. Clear any snow from the rear window. 2. Get in your vehicle and start the engine. 3. Press the rear defrost button. The indicator
light turns on.
The defroster turns off automatically after 15 to 25 minutes. If the window is not clear, turn on the defroster again. It will also automatically shut off any time the engine is shut off. NOTE: Never use sharp instruments or
window cleaners with abrasives to clean the inside of your rear window. If you do, you may damage the heating elements that are bonded to the inside of the rear window and cause damage to the rear window defroster.
Interior Lights Lighting Up the Interior and Instrument Panel With the parking lamps or headlamps on, the brightness of the instrument panel lighting can be adjusted. To brighten or dim the instrument panel lighting, rotate the dimmer control thumbwheel as desired.
Dimmer control thumbwheel
72
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
[IP20900(ALL)01/94]
[IP21800(ALL)02/91]
[IP22950(ALL)05/95]
[IP23100(ALL)05/95]
half page art:0030286-L
[IP23125(ALL)04/95]
[IP23150(ALL)01/95]
[IP23200(ALL)01/95]
The dimmer control thumbwheel is located to the left of the steering wheel on the instrument panel. Dome Lamp The dome lamp illuminates whenever one of the front doors is opened and turns off automatically when the doors are closed. You may turn the dome lamp on and off while the doors are closed by using the ON/OFF switch located on the interior/map lamp control panel.
Interior/map lamp control panel Map lamps (if equipped) The map lamps can be turned on by using the interior/map lamp control panel located between the sun visors. There are two map lamps, one for the driver and one for the passenger. To turn on the map lamp, push the button that is next to the lamp.
73
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
[IP23210(ALL)05/95]
half page art:0032392-A
[IP23225(ALL)04/95] *[IP23250(ALL)04/95]
*[IP23300(ALL)04/95] [IP23400(ALL)05/93]
Push the buttons again to turn the map lamps off.
Cleaning the Interior Lamps Your interior dome lamps and map lamps are plastic and should be cleaned with a mild detergent diluted in water. Rinse them with clear water. Fog Lamps (If equipped) The fog lamps only operate when the headlamps are on low beam. To activate fog lamps, push the button on the control panel below the climate controls. An indicator light on the button will illuminate. Push the button again to turn the fog lamps off.
74
File:pripp.ex Update:Fri Jun 23 19:37:35 1995
[IP23500(ALL)05/95]
quarter page art:0032079-E
*[IP24200(ALL)05/95] *[IP24300(ALL)04/95]
*[IP24400(ALL)04/95]
*[IP24500(ALL)05/94]
*[IP24550(ALL)05/92] [IP24600(ALL)05/92]
Fog lamp button Radio For information about the radio in your vehicle, refer to the Ford Electronic Sound Systems Operating Guide in this Owner Guide. Clock Controls on Electronic Radios The electronic radios have a built-in clock. For complete operating instructions, refer to the Ford Electronic Sound Systems Operating Guide in this owner guide. Radio Antenna The radio antenna is mounted on the rear passenger side quarter panel of the vehicle. It is a fixed mast antenna and cannot be retracted.
75
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC00300(ALL)01/95]
*[SC00400(ALL)01/95] *[SC00500(ALL)01/95]
*[SC00600(ALL)08/91] *[SC00700(ALL)03/95] *[SC00800(ALL)01/95] *[SC00900(ALL)05/95] *[SC00950(ALL)08/91] *[SC00975(ALL)01/92]
[SC01000(ALL)05/95]
[SC01050(ALL)05/95]
Steering Column Controls
The controls on the steering column and wheel are designed to give you easy access to the controls while you are driving. The Turn Signal Lever You can use the turn signal lever on the left side of the steering column to:
operate the headlamps and parking lamps
operate the turn signals and cornering lamps
turn the high beams on/off
flash the lamps
Headlamps and Parking Lamps
To turn the parking lamps or headlamps on, twist the knob at the end of the turn signal lever.
FIRST STOP — Turning the knob to the first stop (g) will turn on the the license plate lamps, parking lamps, side marker lamps, tail lamps and instrument panel lamps.
SECOND STOP — Turning the knob to the second stop (B) will turn on the headlamps, license plate lamps, parking lamps, side marker lamps, tail lamps and instrument panel lamps.
77
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC01105(ALL)08/91]
quarter page art:0032032-A
*[SC01110(ALL)01/95] *[SC01115(ALL)03/95] *[SC01120(ALL)05/95]
*[SC01130(ALL)05/95] *[SC01140(ALL)01/92] *[SC01150(ALL)01/92] *[SC01175(ALL)05/95]
Headlamp control Daytime Running Light System (Canadian vehicles only) In Canada, certain regulations require vehicles to be driven with lights illuminated during daytime operation. It is for that reason that the daytime running lights are automatically illuminated when the ignition switch is turned to the ON position. The daytime running lights are switched off under the following conditions: q when the headlamps are switched on q when the parking brake is applied q when the flash-to-pass system is used
RWARNING
The Daytime Running Light (DRL) system will not illuminate the tail lamps and parking lamps. Turn on your headlamps at dusk. Failure to do so may result in a collision.
78
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC01200(ALL)08/91]
[SC01250(ALL)01/95]
[SC01255(ALL)02/92]
[SC01260(ALL)03/94]
[SC01270(ALL)02/92]
[SC01280(ALL)05/95]
[SC01290(ALL)05/95]
Raising the Headlamps Manually If the power headlamp door system becomes inoperative, your vehicle has a manual retractor system that allows you to raise the headlamps manually (the headlamps will not turn on). The retractors are located under the hood and behind each headlamp. Remove the cap and turn the knob. Each headlamp must be raised separately. Before using the manual retractors to raise your headlamps, the RETRA fuse must be removed. Open the main fuse panel. Refer to the underhood fuse panel in Servicing Your Probe later in this owner guide. Pull the RETRA (20A) fuse straight out. Inspect the removed fuse. If it is blown, replace it with a new one of the same rating. If it isn’t blown or if a new fuse does not solve the problem, remove it and operate the headlamp manually.
RWARNING
Always remove the RETRA (20A) fuse before manually operating a headlamp retractor or attempting to remove anything from the headlamp. Failure to remove the RETRA fuse could cause injury to a hand or fingers.
RWARNING
When reinstalling the RETRA fuse, make sure nothing is near the headlamp retractor. It may move suddenly while the fuse is being inserted, causing injury to hands and fingers.
79
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC01300(ALL)02/92]
half page art:0032085-B
*[SC02075(ALL)05/95] *[SC02080(ALL)05/95]
*[SC02085(ALL)05/95]
Manual headlamp retractors located behind the headlamps High Beams and Flashing the Lamps To turn on the high beams, turn the headlamp control knob to the headlamp ON position and push the turn signal lever away from you until it latches. When the high beams are ON, the high beam indicator light on the instrument panel comes on. To turn off the high beams, pull the lever toward you until it latches. The high beam indicator light turns off.
80
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC02090(ALL)05/95] *[SC02091(ALL)06/95]
[SC02093(ALL)08/91]
quarter page art:0032034-A
[SC02095(ALL)11/91]
%*[SC02097(ALL)05/95] *[SC02098(ALL)05/95]
%*[SC02100(ALL)03/95] *[SC02200(ALL)09/93]
*[SC02300(ALL)01/94]
Flashing the Lights To flash the headlamps, pull the lever toward you for a moment and then release it. The headlamps will flash whether the headlamp knob is in the on or off position.
Highbeam and flash-to-pass operation If the headlamps are retracted when you pull the lever toward you, they will pop up and flash. Cleaning the Exterior Lamps Do not use dry paper towel, chemical solvents or abrasive cleaners to clean the lamps, as these may cause scratches or crack the lamps. Hazard Flasher To alert other drivers to hazardous situations, press the flasher switch on the top of the steering column. All the turn signals will flash on and off at the same time. The flashers will also operate while the brake pedal is applied. To turn the hazards off, press the switch again. The flashers work whether your vehicle is running or not. The flashers will work for up to two hours when the battery is fully charged and in good condition. They will not drain the battery excessively unless they are left on for an extended period of time.
81
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC02475(ALL)04/95]
[SC02500(ALL)08/91]
half page art:0032030-A
If the flashers run for longer than 2 hours while your engine is not running, or if your battery is not fully charged, your battery could be drained.
Hazard warning flasher switch
82
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC02600(ALL)01/95] *[SC02650(ALL)03/95]
[SC02710(ALL)01/95]
*[SC02720(ALL)03/95]
[SC03000(ALL)11/91]
half page art:0032033-A
Turn Signals Move the lever up to signal a right turn. Move it down to signal a left turn. The corresponding indicator light in the instrument cluster will flash. If the turn signal stays on after you turn, move the lever back to the center (OFF) position. For lane changes, move the lever far enough to signal but not to latch. The lever will return to the off position when you release it.
Turn signal
83
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC03100(ALL)03/95] *[SC03200(ALL)08/91]
[SC03600(ALL)01/92]
[SC04050(ALL)02/92]
quarter page art:0032071-C
[SC04100(ALL)01/94]
[SC04150(ALL)01/92]
quarter page art:0032058-B
Windshield Wipers and Washer To operate the windshield wipers and washers, make sure your ignition key is turned to the ON position. The windshield wipers have two speeds. To operate the wipers, pull down the lever on the right side of your steering column. The first position is LO (Low) and the second position is HI (High). To turn the wipers off, return the lever to the uppermost position.
Windshield wiper control ONE-TOUCH WIPER CONTROL (If equipped) — For one wiping cycle, push the lever away from you and release it with the lever in the OFF or interval position. The ignition switch must be in the ON position for this operation.
One touch wiper control
84
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC04220(ALL)11/91]
[SC04240(ALL)08/91]
[SC04260(ALL)01/92]
quarter page art:0032035-B
[SC04280(ALL)11/91]
*[SC04300(ALL)05/95] [SC04425(ALL)01/92]
[SC04450(ALL)01/92]
quarter page art:0032057-B
Interval Wipers (If equipped) In addition to two speed wipers, your vehicle may have wipers that you can set to operate at varying intervals. For example, you can set the interval so they wipe less often when it drizzles and more often in heavier rain.
Variable interval wiper control To set the interval wipers, pull the lever down to the first position. Turn the ring on the lever to the frequency of wiper operation you desire. Windshield Washer To clean the windshield, pull the wiper lever toward you. Washer fluid sprays until the lever is released.
Windshield washer/control
85
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC04550(ALL)05/95]
*[SC04700(ALL)01/95]
*[SC04800(ALL)01/93]
If the washer does not work, check the washer fluid level visually and fill if needed. See Servicing Your Probe later in this owner guide. If there is fluid in the reservoir, and your washer doesn’t work, consult your Ford or Lincoln-Mercury dealer. Do not try to clean the windshield when the washer fluid container is empty or activate the washers at any time for more than 15 seconds continuously. This could damage the washer pump system.
RWARNING
In freezing weather, the washer solution may freeze on the windshield and obscure your vision. Always warm up the windshield with the defroster before you use the washer fluid. If you cannot see through the windshield clearly, it can increase the risk of being involved in a collision.
86
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC05000(ALL)01/95] *[SC05200(ALL)08/91]
[SC05450(ALL)08/91]
half page art:0032036-A
Horn To sound the horn, push the horn button on either side of the steering wheel. Check the horn regularly to be sure it operates properly.
Using the horn
87
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC05500(ALL)10/91]
*[SC05510(ALL)04/95]
*[SC05520(ALL)04/95]
[SC05900(ALL)08/91]
half page art:0032044-A
Tilt Steering Column (If equipped)
RWARNING
Never adjust the steering column/wheel when the vehicle is moving. You could lose control of the vehicle and injure someone.
To change the position of the steering column/wheel, pull the release lever on the column toward you. Tip the steering wheel to the desired position. Release the lever to lock the steering wheel in place.
Tilt steering column
88
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC06000(ALL)03/91] *[SC06050(ALL)06/95]
*[SC06060(ALL)05/95]
[SC06100(ALL)06/94]
half page art:0032031-C
*[SC06150(ALL)03/95] [SC06250(ALL)01/95]
*[SC06300(ALL)06/95]
Speed Control (If equipped) If your vehicle has speed control, you can automatically maintain a constant speed at or above 30 mph (50 km/h). Use of radio transmitting equipment that is not Federal Communications Commission (FCC) or in Canada the Canadian Radio and Telecommunications Commission (CRTC) approved may cause the speed control to malfunction. Therefore, use only properly installed FCC (CRTC in Canada) approved radio transmitting equipment in your vehicle.
Speed control switches on the steering wheel To set the speed control: 1. Press the ON switch and release it
immediately.
2. Accelerate to the desired speed above
30 mph (50 km/h) using the accelerator pedal.
89
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC06400(ALL)01/95]
*[SC06450(ALL)06/95] *[SC06500(ALL)06/95]
[SC06510(ALL)05/95]
[SC06520(ALL)01/94]
3. Press SET ACC and release it immediately to
set your speed. If you keep this button depressed, your speed will continue to increase.
4. Take your foot off the accelerator pedal.
Your vehicle will maintain the speed you set.
If you drive up or down a steep hill, your vehicle may momentarily slow down or speed up, even though the speed control is on. This is normal. NOTE: If your vehicle is equipped with an
automatic transaxle, and if your speed increases above your set speed while driving in Overdrive on a downhill grade, you may want to turn the Overdrive off and use Drive. You may turn the Overdrive off by pressing the Overdrive off (O/D OFF) button. This will reduce vehicle speed. Speed control cannot reduce the vehicle speed if it goes above your set speed on a downhill grade.
NOTE: If your vehicle is equipped with a
5-speed manual transaxle, and if your speed increases above your set speed while driving in 5 (Fifth) gear on a downhill grade, you may want to shift to 4 (Fourth) gear to reduce vehicle speed. Depressing the clutch pedal cancels speed control, therefore speed control must be reset by pressing the SET ACC or RSM switches. Speed control cannot reduce the vehicle speed if it goes above your set speed on a downhill grade.
90
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC06550(ALL)05/95]
%*[SC06600(ALL)06/95] *[SC06650(ALL)03/95]
[SC06660(ALL)03/94]
*[SC06750(ALL)03/95]
[SC06800(ALL)05/95]
RWARNING
Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Accelerating With the Speed Control Operating If you want to speed up momentarily or regain preset speed on hills when the speed control is operating, simply accelerate using the accelerator pedal. Manually accelerating to a higher speed does not interfere with the speed control; when you take your foot off the accelerator, the vehicle returns to the set speed. You can also speed up by pressing the SET ACC button. Release the button when the vehicle has accelerated to the desired speed. NOTE: If your vehicle has a 5-speed manual transaxle, you may want to drive in 4
(Fourth) gear in mountainous areas or at high altitudes to improve speed control performance.NOTE: When driving uphill, especially with a
heavy load, significant speed drops may occur. If the speed drops more than 8 to 14 mph (15-25 km/h) the automatic speed control will, by design, be cancelled. You may need to control your speed manually while driving up steep grades in order to maintain the selected speed.
91
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC06850(ALL)05/95]
*[SC06900(ALL)01/95] [SC06950(ALL)05/95]
[SC06975(ALL)01/94]
[SC07000(ALL)05/95]
[SC07050(ALL)01/94]
[SC07100(ALL)01/94]
[SC07125(ALL)01/94]
NOTE: If your vehicle has an automatic
overdrive transaxle, you may want to drive with the Overdrive off when driving in hilly terrain or at high altitudes. You may turn the Overdrive off and use Drive by pressing the Overdrive off (O/D OFF) button. This will improve speed control performance.
Resetting the Speed Control To reset the speed control to a lower speed, press and hold the CST switch. Let your vehicle slow down to the desired speed and release the CST switch. If you have a 2.0L automatic transaxle vehicle you may reset the vehicle speed control to a lower speed by pushing, and then quickly releasing, the CST switch. Each time you do this, the set speed will decrease by 1 mph (1.6 km/h). See Tap Up and Tap Down in this chapter. To reset the speed control to a higher speed, you can follow one of these procedures: q Accelerate to the desired speed using the accelerator pedal, then press the SET ACC switch and release it immediately.
q Press and hold the SET ACC switch until the vehicle accelerates to the desired speed, then release the switch.
q Push, and then quickly release, the SET ACC switch. Each time you do this, the set speed will increase by 1 mph (1.6 km/h). (NOTE: This feature is only available on 2.0L automatic transaxle vehicles.) See Tap Up and Tap Down in this chapter.
92
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
*[SC07150(ALL)04/95] *[SC07200(ALL)06/95]
[SC07250(ALL)05/93]
%*[SC07300(ALL)05/95] [SC07350(ALL)01/94]
*[SC07400(ALL)05/95] %*[SC07450(ALL)06/95] [SC07500(ALL)04/95]
*[SC07550(ALL)06/95] *[SC07600(ALL)05/93]
To Cancel Speed Control You can cancel the speed control while you are driving. Press the brake pedal or clutch pedal (manual transaxle) slightly. The speed control is cancelled, but you can reset it by pressing SET ACC or RSM. To Turn Off the Speed Control System Press the OFF switch. The speed control system is off and will remain off until you press the ON switch and reset the speed control. In addition, the speed control is turned off each time you turn the vehicle off. Cancelling and Resuming a Set Speed If you press the brake pedal, the clutch pedal (manual transaxle), or shift the transaxle into N (Neutral) the speed control is suspended. You can return to the speed you set by using the RSM switch. To resume the speed you had before, you must be driving at least 30 mph (50 km/h). Press and release the RSM switch. Your vehicle gradually returns to the previously set speed and then maintains it.
93
File:prscp.ex Update:Fri Jun 23 19:37:07 1995
[SC07625(ALL)06/93]
[SC07635(ALL)04/95]
Tap Up and Tap Down (2.0L vehicles with automatic transaxle only) Tap Up and Tap Down is a new feature which, like SET ACC and CST, can be used to either increase or decrease the set speed. Speed changes are made in 1 mph (1.6 km/h) increments. Once the speed has been set by pressing the ON and the SET ACC switches, the set speed may be increased by 1 mph (1.6 km/h) by a momentary tap of the SET ACC button. The set speed can be reduced by 1 mph (1.6 km/h) by a momentary tap of the CST button. Multiple taps will cause the set speed to increase or decrease in increments of 1 mph (1.6 km/h). For example, if the current set speed is 60 mph (100 km/h) five taps of the ACC switch will increase the vehicle speed and SET it at 65 mph (105 km/h).
94
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV00250(ALL)02/95]
*[FV00400(ALL)01/95] [FV00700(ALL)04/95]
quarter page art:0030072-C
Features
Your vehicle has a variety of features designed for your comfort, convenience and safety. Read this chapter to find out about standard and optional features. Doors
[FV00800(ALL)06/94]
The outside of the door
one third page art:0030073-C
[FV00900(ALL)01/89]
The inside of the door
If you close the door with the lock button depressed, the door will remain locked.
95
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV02400(ALL)04/95] [FV02500(ALL)01/94]
[FV02550(ALL)02/92]
Power Door Locks (If equipped) If your vehicle has power door locks, the controls to lock the doors are below the inside door handles on each door. When you close the doors after you set the door locks, the doors remain locked. If the power mechanism ever fails, the manual door locks will override the power controls. NOTE: Vehicles equipped with power locks
have a safety feature which allows you to unlock one or both front doors from either door key lock cylinder. To unlock the driver’s or passenger door only, insert the key in the door lock cylinder and turn to the left (counterclockwise) to the first position. To unlock the other door at the same time, simply continue turning the key to the left to the second position. Both doors are locked by turning the key to the right (clockwise).
96
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV02600(ALL)06/94]
half page art:0030079-C
[FV02920(ALL)08/91]
[FV02940(ALL)01/94]
[FV02950(ALL)06/94]
[FV02960(ALL)05/95]
Power locks on the driver’s door Remote Keyless Entry System (If equipped) Your vehicle may be equipped with a remote keyless entry system. This option will allow you to open your vehicle using a remote transmitter from distances of up to 33 feet (10 meters) away. The remote feature will operate only when the ignition is in the OFF position. The transmitter can unlock the driver’s door, unlock all doors, lock all doors, or activate the vehicle’s horn and hazard warning lamps for the panic alarm feature. By pressing the UNLOCK button on the transmitter once, you can unlock the driver side door. Pressing the UNLOCK button a second time within five seconds of unlocking the driver’s door will unlock the other doors.
97
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV02970(ALL)05/95]
[FV02990(ALL)06/94]
[FV03000(ALL)05/95]
[FV03050(ALL)01/95]
one third page art:0032046-C
[FV03052(ALL)06/95]
[FV03054(ALL)06/95]
You can lock all your vehicle doors by pressing the LOCK button. If you press the LOCK button a second time within five (5) seconds, the horn will sound briefly to verify that the doors have been locked. When the PANIC button is pressed, the horn will sound and the hazard warning lamps will flash. This will continue for up to approximately two minutes and 45 seconds unless it is turned off by pressing the PANIC button a second time. The panic mode can also be cancelled by turning the ignition key to ON or ACC. Up to four transmitters can be programmed for your vehicle. Your vehicle comes with two transmitters. Additional transmitters can be ordered from your dealer.
Remote keyless entry transmitter The remote keyless entry system is equipped with an illuminated entry system. This system is activated by opening the door. When the system is activated, the dome lamp will illuminate, and will stay lit for approximately 25 seconds. The dome lamp will shut off when the doors are closed.
98
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
%*[FV03055(ALL)02/95] *[FV03060(ALL)01/95]
*[FV03065(ALL)02/95]
[FV03070(ALL)01/92]
one third page art:0032393-A
Replacing the batteries The remote entry transmitter is powered by two coin type three-volt lithium 1616
batteries (included) that should last for several years of normal use. If you notice a significant decrease in operating range, the batteries should be replaced. Replacement batteries can be purchased at most pharmacies, watch stores or at your Ford or Lincoln-Mercury dealer. NOTE: The operating range of the remoteentry system can also be affected by weather conditions (such as very cold temperatures) or structures around the vehicle (buildings, other vehicles, radio and TV towers, etc.). Typical operating range will allow you to be up to 33
feet (10 meters) away from your vehicle.Opening the remote transmitter
99
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV03075(ALL)01/92]
%*[FV03080(ALL)02/95] [FV03082(ALL)05/95]
*[FV03084(ALL)01/95]
[FV03085(ALL)06/94]
*[FV03090(ALL)04/94]
quarter page art:0060566-B
The transmitter can be snapped apart to replace the batteries by twisting a thin coin between the two halves of the transmitter. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. Carefully remove the old batteries. When installing the new batteries, be sure to place the positive (+) side down as marked. Snap the two halves back together. Replacement/additional transmitters In the event a transmitter is lost, return the remaining transmitter(s) to your dealer for reprogramming of your remote entry system. This is necessary to prevent unauthorized use of the lost transmitter. Additional transmitters may be purchased from your dealer (remote entry system will work with up to four transmitters). Follow the same programming procedure as above. All transmitters must be programmed (or reprogrammed) at the same time. If the programming mode is entered and the transmitters are not programmed (or reprogrammed) at the same time, they will not operate with the system.
100
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV03175(ALL)02/95] *[FV03200(ALL)03/95] *[FV03300(ALL)07/93]
*[FV03400(ALL)08/91]
*[FV03550(ALL)03/91] [FV03600(ALL)11/91]
[FV03750(ALL)05/95]
%*[FV03800(ALL)02/95]
*[FV03900(ALL)05/95]
Windows Operating the Windows Manually The side windows on your vehicle can be raised or lowered manually by turning the hand crank located on each door. NOTE: If you notice buffeting or pulsation
(wind shock) with either side window open, you should open the opposite window slightly to reduce the condition.
Using the Power Windows (If equipped) Each door has a power control that opens and closes the window on that door. The driver’s door has a master control panel that operates both windows. To use your power windows, your ignition switch must be placed in the ON position. Press the recessed end of the power window switch to lower a window, press the raised end of the switch to raise a window. NOTE: Your vehicle is equipped with a “one
touch down” feature. This feature allows the driver to fully open the driver’s window by firmly pressing the switch and then releasing. The switch will release when the window has fully opened.
RWARNING
Do not let children play with the power windows. They may seriously hurt themselves. Make sure occupants are clear of the window(s) before closing.
101
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV04000(ALL)06/94]
half page art:0030081-C
*[FV04600(ALL)02/95] [FV04650(ALL)01/92]
[FV04700(ALL)11/91]
Master window control on the driver’s door Moon Roof (If equipped) The control switch for the sliding moon roof is on the interior/map lamp control panel located above the windshield and between the sun visors. The ignition must be in the ON position for the moon roof to be operational. To open the sliding moon roof to the vent position, push the recessed part of the moon roof switch until the back of the moon roof tilts into the vent position. You must release the switch after opening the vent before pressing it again to slide the moon roof open. To close, push the other side of the switch until the moon roof sets back into place.
102
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV04800(ALL)01/92]
half page art:0032055-B
[FV04900(ALL)08/91]
*[FV05600(ALL)01/95] *[FV05605(ALL)05/95]
*[FV05610(ALL)05/95]
Sliding moon roof control switch Press the switch until the moon roof is opened to the desired position. When you release the switch, the moon roof will stop sliding open. To close the moon roof, press the other side of the switch and hold it until the roof is closed to the desired position. Seats
RWARNING
Never adjust the driver’s seat or seatback when the vehicle is moving.
RWARNING
To reduce the risk of serious injury in a collision, always drive and ride with your seatback upright and the lap belt snug and low across the hips.
103
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV05620(ALL)05/95]
*[FV05625(ALL)04/95] [FV05650(ALL)01/95]
[FV05700(ALL)05/95]
[FV05800(ALL)05/95]
[FV05900(ALL)05/95]
half page art:0032072-F
RWARNING
To reduce the risk of serious injury in a collision, children should always ride with the seatback upright.
Head Restraints Head restraints help protect your head and neck in a collision. The head restraints on your vehicle are not adjustable. Manual Seat Adjustments You can move the front seats forward or backward or tilt the back of the seat forward or backward. The driver’s seat also has controls for lumbar support (if equipped) and side bolster support (if equipped).
104
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV06000(ALL)05/95] [FV06100(ALL)05/95]
To move the seat forward or backward:
three fourths page art:0032073-E
Manual seat controls for front seats
105
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
*[FV06800(ALL)01/92] [FV06850(ALL)05/95]
To recline the seatback:
three fourths page art:0032389-A
106
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV12300(ALL)05/95]
[FV13600(ALL)05/95]
one third page art:0032066-D
[FV13625(ALL)05/95]
*[FV13630(ALL)06/95]
To gain access to the rear seat on the driver’s or passenger’s side:
Seatback release lever for rear seat access The seatback will return to its set reclined position when pushed back.
RWARNING
A seatback which is folded forward even a small degree may not lock properly in the event of a sudden stop or collision.
107
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV13670(ALL)05/95]
[FV13850(ALL)05/95]
half page art:0032390-A
To inflate the driver’s seatback lumbar support (if equipped) for lower back support, or to inflate the driver’s seatback side bolster supports (if equipped):
108
Six-Way Power Seat Adjustment (if equipped) The six-way power seat control lever is located on the outermost side of the driver’s seat.
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV13890(ALL)05/95]
[FV14000(ALL)05/95]
[FV14500(ALL)05/95]
three fourths page art:0032062-D
109
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV14600(ALL)01/89]
[FV14700(ALL)02/92]
*[FV14800(ALL)11/94] *[FV14900(ALL)11/94]
[FV14950(ALL)02/92]
Your seat cushion power adjust lever is operated by a motor. To avoid damage to the motor, you should avoid operating this feature for an extended period of time. You should also avoid using the six-way power adjust lever continuously with the engine stopped. This could run down the battery. Use the lever to make only one adjustment at a time. Using the Split-Folding Rear Seat Your vehicle is equipped with split-folding rear seats. One or both rear seatbacks can be folded down to provide additional cargo space. NOTE: When folding down the rear seatback, the seat belt tongue should be hanging on the hook of the lower, side trim panel, near the edge of the side of the seat cushion.
110
File:prfvp.ex Update:Fri Jun 23 19:36:28 1995
[FV15000(ALL)01/92]
[FV15050(ALL)05/95]
To lower the rear seatback:
half page art:0030099-D
[FV15300(ALL)05/95]
*[FV17900(ALL)05/95]
*[FV18000(ALL)05/95]
To raise the seatback, lift the seatback rearward until it latches. Make sure the seatback is locked in position by pushing it forward and backward.
RWARNING
