Introduction

Instrument Cluster

Warning and control lights Gauges

Entertainment Systems

AM/FM stereo cassette with CD AM/FM stereo cassette AM/FM stereo with CD

Climate Controls

Heater only Manual heating and air conditioning

Lights

Headlamps Turn signal control Bulb replacement Driver Controls

Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control

Locks and Security

Keys Locks

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

77

77
83
93
97
113

113
116
119
126
135

135
136
136
138
144
152
157
158

166
167

171

Table of Contents

Seating and Safety Restraints

Seating Safety restraints Air bags Child restraints

Driving

Starting Brakes Transmission operation Trailer towing

Roadside Emergencies

Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing

Customer Assistance

Reporting safety defects (U.S. only)

Cleaning

Underbody preservation

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Maintenance and Specifications

Engine compartment Engine oil Battery Fuel information Air filter(s) Part numbers Refill capacities Lubricant specifications

Accessories

Index

Table of Contents

173

174
176
179
190
204
210
211
215
222

225

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Copyright © 2002 Ford Motor Company

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Australia: www.ford.com.au • In Mexico: www.ford.com.mx Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the

engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside emergencies chapter.

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE There are no particular guidelines for breaking-in your vehicle. During the first 1,600 km (1,000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in.

SPECIAL NOTICES

Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Data Recording Computers in your vehicle are capable of recording detailed data potentially including but not limited to information such as: • the use of restraint systems including seat belts by the driver and • information about the performance of various systems and modules in • information related to engine, throttle, steering, brake or other system

the vehicle, and

passengers,

status.

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Any of this information could potentially include information regarding how the driver operates the vehicle potentially including but not limited to information regarding vehicle speed, brake or accelerator application or steering input. This information may be stored during regular operation or in a crash or near crash event. This stored information may be read out and used by: • Ford Motor Company. • service and repair facilities. • law enforcement or government agencies. • others who may assert a right or obtain your consent to know such

information.

Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental Restraint System (SRS) in the Seating and safety restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear facing child or infant seats should NEVER be used in front of a passenger side air bag unless the

air bag can be and is turned OFF.

Notice to owners of diesel-powered vehicles Read the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for information regarding correct operation and maintenance of your diesel-powered light truck. Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death. Using your vehicle as an ambulance If your light truck is equipped with the Ford Ambulance Preparation Package, it may be utilized as an ambulance. Ford urges ambulance

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual, Ford Truck Body Builder’s Layout Book and the Qualified Vehicle Modifiers (QVM) Guidelines as well as pertinent supplements. For additional information, please contact the Truck Body Builders Advisory Service 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance usage without the preparation package could cause high underbody temperatures, overpressurized fuel and a risk of spraying fuel which could lead to fires. If your vehicle is equipped with the Ford Ambulance Preparation Package, it will be indicated on the Certification label. The label is located on the driver’s side door pillar or on the rear edge of the driver’s door. You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer. Ford Ambulance Preparation Package is only available on certain 7.3L Diesel engine equipped vehicles.

Notice to owners of natural gas fueled vehicles Before you drive your vehicle, be sure to read the Dedicated Natural Gas Vehicle supplement. This book contains important operation and maintenance information.

Middle East/North Africa vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner Guide for all other required information and warnings.

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Air Bag-Front

Air Bag-Side

Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Child Seat Lower Anchor

Brake System

Brake Fluid - Non-Petroleum Based

Traction Control

AdvanceTrac娂

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Fuel Pump Reset

Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Vehicle Symbol Glossary

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm

Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot

Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

MAX MIN

Emission System

Engine Air Filter

Passenger Compartment Air Filter

Jack

Check fuel cap

Low tire warning

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately. Service engine soon: The Service engine soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

SERVICE ENGINE SOON

Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

10

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may

occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

BRAKE

Brake reserve system warning (if equipped): Illuminates to indicate normal Hydromax booster reserve system activation when the engine is OFF and the service brake pedal is applied. This light may also illuminate momentarily if the engine is running and the driver turns the steering wheel fully in one direction while braking. If the light remains on while the engine is running, this indicates inadequate hydraulic booster pressure or reserve pump system failure. Stop the vehicle safely as soon as possible and seek service immediately. Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated.

ABS

11

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected. Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

Low fuel: Illuminates when the fuel level in the fuel tank is at, or near empty (refer to Fuel gauge in this chapter).

LOW FUEL

is high.

Oil pressure/Engine coolant: Illuminates when any of the following conditions has occurred: • The engine coolant temperature • The engine oil pressure is low. Transmission control indicator light (TCIL): Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily, have the system serviced immediately. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.

OVERDRIVE

12

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

High beams: Illuminates when the high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.

GAUGES

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

13

Instrument Cluster

Never remove the coolant reservoir cap while the engine is running or hot.

Odometer: Registers the total kilometers (miles) of the vehicle.

Trip odometer: Registers the kilometers (miles) of individual journeys. To reset, depress the control.

18

Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level. Add oil if needed. If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician.

14

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

15

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Entertainment Systems

AM/FM STEREO

1. Seek: Press to find the next listenable station down/up the frequency band. 2. Tune: Press to manually adjust the radio frequency down/up.

3. AM/FM: Press to choose a frequency band in radio mode.

4. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns.

AM/FM

16

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

5. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

VOL PUSH ON

CLK

TONE

VOL PUSH ON

6. Tone: Press TONE until the desired level — Bass, Treble, Fade appears on the display. Turn the volume control to raise/lower the levels, or to move the audio sound from the right to left or the front to back (if equipped). 7. CLK (Clock): To set the hour, press and hold CLK until CLOCK SET appears in the display. Press SEEK to decrease increase To set the minute, press and hold CLK until CLOCK SET appears in the display. Press TUNE to decrease

the minutes.

or increase

the hours.

or

TONE

CLK

17

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

AM/FM STEREO CASSETTE

12

13

14 15 16 17

VOL - PUSH ON

AM

FM

BASS

TREB

FM1

ST

BAL

FADE

CLK

TAPE AMS

SIDE REW

1 - 2
FF

11

10

SEEK

TUNE

SCAN

EJ

1. Balance: Press to shift sound to the left/right speakers.

2. Fade: Press to shift sound to the rear/front speakers.

3. CLK: To set the hour, press and hold CLK. Then press SEEK to decrease hours. To set the minute, press and hold CLK and press TUNE to decrease or increase

the minutes.

or increase

the

CLK

18

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

TAPE AMS

4. Tape AMS: In tape mode, press and hold to activate Automatic Music Search (allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection). The tape MUST have a blank section of at least four seconds duration between programs. 5. Side 1–2: Press to change tape direction.

SIDE

1 - 2

6. REW (rewind): Press to rewind the tape.

FF (fast forward): Press to advance the tape.

REW

FF

Dolby威 noise reduction: Works in tape mode only. Reduces tape

7. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 8. noise and hiss; press to activate/deactivate. 9. Scan: Press SCAN to hear a brief sampling of all listenable radio stations or all tape selections. Press again to stop. 10. Tune: Works in radio mode only. Press TUNE frequency down/up 11. Seek: Press and for previous/next release strong station, selection or track.

to change

19

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

12. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

13. AM/FM: Press to choose a frequency band in radio mode.

14. Bass: Press decrease/increase the bass output.

to

15. Treble: Press decrease/increase the treble output.

to

16. EJ (Eject): Press to eject a tape.

EJ

17. Cassette door: Insert a cassette into the cassette door.

20

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD

Entertainment Systems

1. Power/volume: Press to turn ON/OFF; turn to increase/decrease volume.

SCAN

2. Scan: Press to hear a brief sampling of all listenable stations, tape selections or CD tracks. Press again to stop. 3. CD Door: Insert a CD with the label side up. CD unit are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should

21

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information. 4. Cassette door: Insert the cassette with the opening to the right.

5. Eject: Press to eject the cassette/CD. The radio will resume playing.

6. Tape: Press to start tape play. Press to stop tape during rewind/fast forward. CD: Press to start CD play. With the dual media audio, press CD to toggle between single CD and CD changer play (if equipped). 7. Mute: Press to MUTE playing media; press again return to playing media.

8. Auto: Press to set first six strongest stations (if available) into AM, FM1 or FM2 memory buttons; press again to return to normal stations.

9. Clock: Press and hold to set the clock. Press the decrease hours or SEEK increase hours. Press the

to TUNE

SEEK to

22

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

to increase minutes. If your vehicle

to decrease minutes or TUNE has a stand alone clock this control will not function. 10. Balance: Press BAL; then press SEL left/right speakers.

to shift sound to the

Fade: Press FADE; then press SEL rear/front speakers.

to shift sound to the

11. Memory preset buttons: To set a station: Select frequency band AM/FM, tune to a station, press and hold a preset button until sound returns. 12. Shuffle (CD): Press to play tracks in random order.

13. Compression (CD): Press to bring soft and loud passages together for a more consistent listening level. Dolby威 noise reduction: 14. Works in tape mode only. Reduces tape noise and hiss; press to activate/deactivate. The Dolby威 noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolby威 and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. 15. Side 1–2: Works in tape mode only. Press to play reverse side of the tape.

23

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

FF

REW

SEL

SEEK

TUNE

SEEK

TUNE

Entertainment Systems

16. Fast Forward (FF): Press for a slow advance, press and hold for a fast advance. 17. Rewind (REW): Press for a slow rewind, press and hold for a fast rewind. 18. Select (SEL): Use with Bass, Treble, Balance and Fade controls.

19. Bass: Press BASS; then press to decrease/increase SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

to decrease/increase

20. Tune: Works in radio mode only. Press TUNE frequency down/up.

to change

21. Seek: Press and release for previous/next SEEK strong station, selection or track.

22. AM/FM: Press to select AM/FM1/FM2 frequency band.

24

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

PREMIUM IN-DASH SIX CD SOUND SYSTEM

15

16

17

SHUF

SCAN

DISC TUNE

SEEK

REW

FF

COMP

14

13

LOAD

PUSH ON

MUTE

EJ

BASS

BAL

SEL

TREB

FADE

AM FM

CD

MENU

12

11

10

for previous/next

1. Seek: Press and release SEEK strong station, or track of the current disc. 2. Rewind: Press and hold until the desired selection is reached.

Fast forward: Press and hold until the desired selection is reached.

3. Comp (Compression): The compression feature operates in CD mode and brings soft and loud CD passages together for a more consistent listening level. Press the COMP control until COMP ON is displayed. 4. Mute: Press to MUTE playing media; press again return to playing media 5. Eject: Press to eject a CD. Press and hold to eject all loaded discs. If disc is not removed, it will reload into the system. Works with the ignition on or off.

25

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

to decrease/increase

6. Bass: Press BASS; then press SEL the bass output. Treble: Press TREB; then press SEL the treble output.

to decrease/increase

to shift sound to the

7. Select: Use with Bass, Treble, Balance and Fade controls to adjust levels. Use with MENU to set the clock and RDS function on/off. 8. Balance: Press BAL; then press to shift sound to the SEL left/right speakers. Fade: Press FADE; then press SEL rear/front speakers. 9. Menu: Press MENU and SEL to access clock mode, RDS on/off, Traffic announcement mode and Program type mode. 10. Memory presets: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 11. CD: Press to select CD mode.

12. AM/FM: Press to select AM/FM1/FM2 frequency band. In CD mode, press to begin radio play. Autostore:Stores the six strongest stations without erasing your current presets. To activate, press and momentarily hold AM/FM. Autostore will flash in the display. The six strongest stations will fill the memory preset buttons for AM/FM1/FM2 if enough stations are available. If not, stations will be repeated. Press again to deactivate.

26

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

14. Load: Press to load a CD. Press and hold to load up to six discs.

15. Shuffle: Press to play tracks and CDs in random order.

16. Scan: Press SCAN to move up the radio frequency band. SCAN automatically finds a station, plays it for five seconds, then moves to the next station. Press again to stop. CD: Press SCAN for a brief sampling of CD tracks. Press again to stop. 17. Disc tune: Radio: Press or the radio frequency band. CD: Press the CD.

to select the previous track or

to manually tune down or up

to select the next track on

27

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

REAR SEAT ENTERTAINMENT SYSTEM (IF EQUIPPED)

Quick Start — How to get going

To operate the system: 1. Your AutoVision威 system is automatically activated when the vehicle ignition and the audio system are ON. 2. If a movie is desired, insert a VHS cassette into the VCP and the video should start playing. 3. Press the MEDIA control to toggle to any other desired media source.

28

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

To play a video game: 1. Connect the video line from your game device to the VIDEO jack. 2. Connect the left and right audio cables to the left (L) and right (R) audio jacks. 3. Ensure that the system is in AUX mode. The LCD screen will turn on and the AUX indicator will illuminate. 4. If desired, press the control and plug a 3.5mm headphone into the headphone jack. With the headphones ON, the rear speakers will not operate. Your AutoVision威 System allows you to watch movie rentals and your favorite home videocassettes. It also allows you to plug in and play a variety of standard video games. Please review this user manual to become familiar with the AutoVision威 features and controls as well as the very important safety information. Should you have any questions regarding your AutoVision威 System, please feel free to call the toll free assistance hotline at 1 (877) 848–6434.

Safety information Read all of the safety and operating instructions before operating the system and retain for future reference. Do not attempt to service, repair or modify the AutoVision威 System. See your Ford or Lincoln Mercury dealer.

29

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Do not insert foreign objects into the videocassette player (VCP) tape cassette compartment.

The front glass on the liquid crystal display may break when hit with a hard surface. If the glass breaks, do not touch the liquid

crystalline material. In case of contact with skin, wash immediately with soap and water.

The driver must not attempt to operate any function of the floor console mounted VCP while the vehicle is in motion. Give full attention to driving and to the road. Pull off the road and park in a safe place before inserting or extracting video tapes from the VCP. A remote control is included in the system to allow the rear seat occupants to operate the VCP functions without distracting the driver.

Be sure to review User Manuals for video games and video game equipment when used as auxiliary inputs for your AutoVision威 System. Do not operate video games or video equipment if the power cords and/or cables are broken, split or damaged. Carefully place cords and/or cables where they will not be stepped on or interfere with the operation of seats and/or compartments. Disconnect video games and video equipment power cords and/or cables when not in use. Avoid touching auxiliary input jacks with your fingers. Do not blow on them or allow them to get wet or dirty. Do not clean any part of the AutoVision威 system with benzene, paint thinner or any other solvent. Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference and radio communications.

30

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help.

Care of the videocassette player (VCP) Environmental extremes Videocassette players subjected to harsh environmental conditions may be damaged or perform at less than maximum capability. To avoid these outcomes, avoid leaving the VCP: • in extremely hot or cold temperatures. • in direct sunlight. • in high humidity. • in a dusty environment. • in locations where strong magnetic fields are generated. • on a surface that is instable or subject to vibrations. Temperature extremes When the vehicle is parked under direct sunlight or in an extremely cold place for a long period of time, wait until the cabin temperature of the vehicle is at normal temperature before operating the system. High/low temperature sensor circuit • Excessively high or low temperatures may cause damage to the VCP. • When the temperature of the VCP becomes too high or low, the

temperature sensor circuit stops machine operation, ejects the cassette and the WAIT indicator illuminates. The lamp will remain illuminated until the system has returned to a safe operating temperature.

Humidity and moisture condensation Moisture in the air will condense in the VCP under extremely humid conditions or when moving from a cold place to a warm one. Moisture condensation on the tape playback head drum may damage the videocassette and/or drum. If moisture condensation occurs, do not insert a videocassette into the player. If a videocassette is already in the player, remove it. Turn the VCP power ON to dry the moisture before inserting a videocassette. This could take an hour or more.

31

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

tape may be damaged if the VCP is operated.

Dew sensor circuit • Under high moisture (dewed) conditions, the tape heads and cassette • When the vehicle’s cabin temperature is very low and then is heated quickly, or the humidity is very high within the vehicle, the inside of the windows most likely will be fogged. Under these conditions, the inside of the VCP most likely is dewed. • When a dewed condition exists, the dew sensor circuit stops machine operation, ejects the cassette and the WAIT indicator illuminates. The lamp will remain illuminated until the system is dry enough to operate safely.

Cleaning video heads Magnetic video heads convert the videocassette into pictures on the screen during playback. Over a period of time, particles rub off the tape and are left on the heads. Using an old or poor quality tape together with dust and air particles, high temperature and humidity cause dirty heads. Dirty heads generally cause “snowy” pictures and, in some severe cases, blurred or interrupted pictures. A variety of products are available at video stores to clean tape heads. Use these products sparingly, because some are abrasive to the video heads. If normal head cleaning procedures do not resolve the problem, have the system checked by a service technician. Foreign substances Exercise care to prevent dirt and foreign objects from entering the VCP compartment. Be especially careful not to spill liquids of any kind onto the media controls or into the videocassette player. If liquid is accidentally spilled onto the system, immediately turn the system OFF and consult a qualified service technician.

AutoVision姞 system Features • 2–head hi-fi playback • AutoPlay feature • Digital auto tracking • Dual stereo headphone with electric volume control • Self docking connection for easy mobile installation • Latching system for secure safety • Carrying handle for portability

32

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

• Water resistant tape door • On screen display • Protection circuits Playback and format • The videocassette player of your AutoVision威 system can only be used in the “playback” mode. You are not able to record with your system. • The system plays standard videocassettes marked “VHS” (or “S-VHS).

VCP protection circuits

Tape protection circuit • When the system is in PAUSE mode, the tape mechanism will • When the VCP is in still playback, FFWD (fast forward) or REW

continue to create tension on the tape.

(reverse) mode for more than five minutes, the tape protection circuit automatically returns the system to PLAY mode to avoid damage to the tape.

Your AutoVision System is also equipped with a Dew sensor circuit and a High/low temperature sensor circuit. For more information on these circuits, please refer to Humidity and moisture condensation and Temperature extremes in this chapter.

33

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

VCP controls

1. LED display The display lamp will light up in green when power is supplied to the videocassette player. 2. POWER key Press to toggle between ON/OFF. When the power is ON, other keys (PLAY, FF, REW, STOP) will illuminate. 3. PLAY key Press to playback a videocassette tape. 4. REWIND/REVIEW button Press to enter the reverse picture mode when in PLAYBACK mode. If in STOP mode, the tape will rewind at a high speed. 5. FAST FORWARD/CUE button Press to enter forward picture search mode when in PLAYBACK mode. If in STOP mode, the tape will fast-forward at a high speed. 6. STOP button Press to stop the tape. 7. HEADPHONE VOLUME UP/DOWN KEYS button For home use only, please refer to the In-Home Use section. 8. EJECT button Located inside the videocassette cover. Press to eject the tape.

34

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Remote control

Entertainment Systems

10

1. POWER button Press to turn the videocassette player (VCP) ON or OFF. 2. ENCORE button Press to reverse the casssette for 5 seconds. Normal playback will then resume when in PLAYBACK mode. 3. STILL/ADVANCE (frame advance button) Press to temporarily suspend playback. Press again to make the tape advance one frame at a time. 4. RETRACKING button Press to activate Auto Tracking in the playback mode. 5. TRACKING + button Press for manual tape tracking. 6. TRACKING — button Press for manual tape tracking. 7. PLAY button Press to play the tape.

35

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

8. REW button Press to rewind the tape. 9. FF button Press to fast forward the tape. 10. STOP button Press to stop the tape. Battery replacement

Batteries are supplied with the remote control unit. However, they are simply for operation check and will only work for a short time. Slide battery cover off as shown on remote control to access the batteries. The remote control unit uses two AAA batteries. The need for battery replacement is usually indicated if the remote control only functions at extremely close distances to the entertainment center or not at all. When replacing batteries, use two new batteries (alkaline recommended) and install with correct orientation (+ and − polarities). Ensure that you use only new batteries of the same brand. If you will not be using the remote control for a considerably long time, remove the batteries.

36

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

AutoVision姞 controls

Entertainment Systems

The AutoVision威 controls allow the rear seat passengers to operate the radio, tape, CD or CD DJ(if equipped). Parental control Your AutoVision威 system allows you to have control over the rear seat controls. The system is automatically activated when the ignition is ON. This enables rear seat passengers to play a videocassette or listen to any of the available media sources. Once the headphone mode is activated, the Press the memory preset controls 3
and 5 simultaneously on the front audio controls to disable the AutoVision威 controls. They will remain disabled until the front seat passengers “enable” them again by simultaneously pressing the 3 and 5 preset controls. The settings of the front seat controls will always override those of the rear seat controls.

symbol will appear in the radio display.

37

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Adjusting the volume This control allows the rear seat passengers to adjust the volume level of the audio system. Press the + control to increase the volume. Press the — control to decrease the volume.

From the AutoVision威 controls, the speaker volume cannot be set higher than the current volume radio setting. When in headphone mode, the AutoVision威 controls can change the volume setting to any desired level. Using headphones/Personal Audio Feature The Personal Audio Feature allows the rear seat passengers to listen to one media source (radio, TAPE, CD, CDDJ, VCP, or AUX) while the front seat passengers listen to another. To activate, press the control and plug a 3.5mm headphone into the headphone jack. With the headphones ON, the rear speakers will not operate. Press the MEDIA control to toggle to the desired media source. Use the SEEK, VOLUME and MEM controls to make any desired adjustments.

Press the deactivate the Personal Audio Feature.

control again to engage the rear speakers and

38

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Speakers ON/OFF mode With the speakers ON, you can adjust the audio output to all system speakers — front and rear together (headphones are disabled in this mode). The rear seat passengers can not raise the volume of the system above the level on the front radio bezel. With the speakers OFF, the headphones are enabled. The rear seat passengers have control over the desired volume levels. Media select Press the MEDIA control to toggle between AM, FM1, FM2, TAPE, CD, CDDJ, VCP and AUX modes. When selected, the media source will illuminate.

• AM — AM radio frequency band • FM1, FM2 — FM radio frequency bands • TAPE — cassette tape (if equipped) • CD — single cd player (if equipped) • CDDJ — compact disc changer (if equipped) • VCP — video cassette player • AUX — auxiliary jack input

39

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Memory preset control In radio mode, press the MEM (Memory) control successively to scroll through the memory presets in AM, FM1 or FM2. In CDDJ mode, press the MEM (Memory) control to select the next disc in the compact disc changer. Play will begin with the first track.

Seek function The SEEK control has varying functions depending on which mode is enabled. In radio mode (AM, FM1, FM2): control to find the Press the next listenable station down the frequency band. Press the next listenable station up the frequency band. In tape mode, press the SEEK control to access the previous ( or the next (

control to find the

) selection.

In CD mode, press the SEEK control to access the previous ( next (

) track.

) or the

In CDDJ mode, press the SEEK control to access the previous ( the next (

) track of the currently selected disc.

) or

40

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Flip-down screens

Entertainment Systems

The screens rotate down to view and up into the housing to store when not in use. Ensure that the screens are latched into the housing when being stored.

1. 6.4” (diagonal) color liquid crystal display (LCD) screen. 2. Screen housing. 3. Dimmer switch. Rotate to increase/decrease the brightness of the screen. General operation • When the engine is not running, use the system sparingly otherwise it • Do not leave the videocassette in the VCP overnight or for long • When the ignition is turned ON, audio is through the headphones as

will run the battery down.

periods of time.

LOW volume. Press the (+) control to increase volume. To listen through the vehicle’s speaker system, press the speaker button ( on the media control panel.

41

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Inserting/removing cassette Inserting cassette • Open the AutoVision威 console cover. • Insert the videocassette into the cassette compartment. Inserting a videocassette into the VCP automatically turns the power ON (the indicator lamp will illuminate) and the tape will begin playback. If the vehicle is traveling over rough terrain, it may be difficult to insert the cassette because the machine attempts to hold the cassette firmly to prevent vibration. If this condition is encountered, either press firmly or remove the cassette and insert it again. The system will not allow a cassette to be inserted in the wrong position. • Once the cassette is completely inserted, close the VCP and console

covers.

Removing cassette 1. Open the console cover, open the VCP cover and press the STOP button. 2. Press the EJECT button. Do not insert any foreign substances into the cassette compartment. After removing the cassette from the VCP, close the door. When the engine is turned OFF, the cassette is ejected from the compartment. To play a video game 1. Connect the video line from your video game device to the YELLOW jack. 2. Connect the left and right audio cables to the WHITE and RED jacks respectively. 3. Ensure that the system is in AUX mode. The LCD screen will turn on and the AUX indicator will illuminate. On-screen indicators Playback operation 1. Press the POWER control on the VCP. 2. Insert a videocassette into the VCP. 3. The videocassette should automatically begin playback, and the picture will appear within approximately nine seconds.

42

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

4. Press the STOP control to stop playback or press EJECT to remove the cassette. Fast-forward or rewind (no picture) 1. Press the FF/REW control on the VCP. 2. Press the STOP control to stop or press EJECT to remove the cassette. The tape will fast forward or rewind until it has reached the end or the beginning. Fast-forward or rewind (with picture) 1. While in playback mode, momentarily press the FF/REW key. The VCP will search the playback direction five times faster than normal playback mode. 2. Press the PLAY key to resume normal playback. Special effects playback

Still playback/Frame-to-frame playback (on remote control) 1. Press the STILL/F.ADV key while in playback mode. The playback picture becomes still. 2. Press the STILL/F.ADV key again. Each time the control is pressed, the pictures are played back one frame at a time. The still playback feature can also be used in REW (reverse) mode. If still playback/or frame-to-frame playback is engaged for five minutes or longer, the VCP will automatically begin playback to protect the tape. Automatic tracking is automatically activated the moment the VCP is turned ON or a cassette is inserted. If a videocassette is in poor shape (i.e., badly recorded), any tracking adjustment may result in failure. The VCP will eject the videocassette. Encore (on remote control) • Press the ENCORE control while in playback mode. The VCP will reverse to the previous five seconds of the selection and then operate at normal playback mode.

43

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Auxiliary input jacks The auxiliary input jacks on the AutoVision威 control panel accepts video and audio connectors for all standard video games (Nintendo威, PlayStation威, etc.) Other compatible devices such as DVD players, camcorders and portable CD players can also be connected to the auxiliary jacks. The auxiliary jack is color-coded for identification purposes. They are as follows: • YELLOW (1)— video input • WHITE (2)— left channel audio • RED (3)— right channel audio

input

input

Press the MEDIA control until AUX is illuminated in the control panel. This will allow you to view the video and listen to the audio from the auxiliary input. To listen to another audio source while viewing video from the auxiliary input, press the MEDIA control until the desired media source is illuminated.

44

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Video source selection The MEDIA control determines which video (VCP or Auxiliary input) is seen on the AutoVision威 screen. When the vehicle ignition is ON and the system is not in VCP mode, the AutoVision威 selects the Auxiliary input as the video source. (If there is not a video source connected to the Auxiliary input jack, the screen will be blank.)

AutoPlay feature Your AutoVision威 system is equipped with an AutoPlay Feature. When a video cassette is inserted into the player, video and audio sources are automatically switched to VCP. This will override any other selections currently made.

Indications on the VCP The operation and status of the VCP can be checked by the indications appearing on the LED display. 1. The Power indicator flashes on during POWER ON and will blink when in emergency mode. 2. The HI-FI indicator illuminates when a HI-FI tape is loaded. 3. The HP1 indicator illuminates when the headphone jack 1 is plugged in. 4. The HP2 indicator illuminates when the headphone jack 2 is plugged in. 5. The Operation indicators illuminate when the system is powered ON, a HIFI tape is being played, or headphones are being used.

45

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

The following are some possible messages that may illuminate on your LED display and their meanings. Illuminates when there is a videocassette in the system during power off.

Illuminates when there is a videocassette in the system during power on.

Illuminates when a videocassette is ejected from the system.

Flashes during emergency mode.

Illuminates during power on when there is not a videocassette present in the system.

Illuminates during power off when there is not a cassette present in the system.

Illuminates when the videocassette is in REW (rewind) mode.

Illuminates when the videocassette is in FF (fast forward) mode.

46

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Illuminates when the videocassette is in STIL (pause) mode.

Illuminates when the videocassette is in PLAY mode.

Illuminates when the videocassette is in REV (review) mode.

Illuminates when the videocassette is in CUE mode.

Flashes separately when the videocassette is in ENCORE mode.

Displays when: • the thermostat detects an

extremely high or low temperature, or

• the dew sensor is activated for high humidity In-home use Your AutoVision威 system is UL registered for in-home use. This system has the unique feature of also being completely portable and able to be used in your home. To remove your AutoVision威 system from your vehicle, depress the lever on the center console labeled VCP RELEASE. This will release the VCP and enable you to remove the system from the vehicle. If pressing the lever does not release your system, please contact your dealer.

47

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

To re-install the VCP in your vehicle, insert the VCP into the console and push lightly until the VCP clicks into place. To use the AutoVision威 system in your home, you will need: • a DC 12V power converter rated for 1.5 amps/min and • Patch cords with RCA style connectors These parts are available in your local electronics store or call toll free 1 (877) 848–6434 for assistance. Auxiliary jacks for home use 1. VIDEO OUT

Connect this terminal to the VIDEO IN terminal of your display (LCD, TV). 2. DC jack in

Connect this jack to the DC source (DC 12V). 3. AUDIO OUT LR

Connect these terminal(s) to the AUDIO IN terminals of your display (LCD, TV).

48

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

1. VIDEO IN

Connect this terminal to the AUDIO OUT terminal of your other apparatus (DVD, game machine, etc.). 2. AUDIO IN LR

Connect these terminal(s) to the AUDIO OUT terminals of your other apparatus (DVD, game machine, etc.).

3.

Plug headphones into these jacks.

RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz

weaker the signal and the weaker the reception.

RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.

CASSETTE/PLAYER CARE Do: • Use only cassettes that are 90 minutes long or less.

49

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

and turning the hub.

Entertainment Systems • Tighten very loose tapes by inserting a finger or pencil into the hole • Remove loose labels before inserting tapes. • Allow tapes which have been subjected to extreme heat, humidity or • Clean the cassette player head with a cassette cleaning cartridge after

cold to reach a moderate temperature before playing.

10–12 hours of play to maintain good sound/operation.

Don’t: • Expose tapes to direct sunlight, extreme humidity, heat or cold. • Leave tapes in the cassette player for a long time when not being

played.

CD/CD PLAYER CARE Do: • Handle discs by their edges only. Never touch the playing surface. • Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

of time.

Don’t: • Expose discs to direct sunlight or heat sources for extended periods • Insert more than one disc into each slot of the CD changer magazine. • Clean using a circular motion. CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

50

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

Climate Controls

HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. 3. Temperature selection: Controls the temperature of the airflow in the vehicle.

: Distributes outside air through the instrument panel vents.

O (OFF): Outside air is shut out and the fan will not operate.

: Distributes outside air through the instrument panel vents and the

floor vents.

: Distributes outside air through the floor vents. : Distributes outside air through the windshield defroster vents and

floor vents.

: Distributes outside air through the windshield defroster vents.

position.

the air flow selector in the

Operating tips • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle during cold or warm weather, do not drive with the air flow selector in the OFF position. • Under normal weather conditions, do not leave the air flow selector in OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the air • Remove any snow, ice or leaves from the air intake area at the base of

flow to the back seats.

the windshield.

To aid in side window defogging/demisting in cold weather: 1. Select 2. Set the temperature control to full heat

51

2003 Econoline (eco) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

3. Set the fan speed to HI 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

MANUAL HEATING AND AIR CONDITIONING SYSTEM 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the
