2k15_chev_trax_23118885A.ai (Modern Bridge - Level 2 / #23321109) Spine = Printer Adjust Color = Black Date = 05/08/14
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (1,1)
2015 Chevrolet TRAX Owner Manual M
In Brief . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Instrument Panel . . . . . . . . . . . . . . 1-2
Initial Drive Information . . . . . . . . 1-4
Vehicle Features . . . . . . . . . . . . . 1-15
Performance andMaintenance . . . . . . . . . . . . . . . . 1-19
Keys, Doors, and
Windows . . . . . . . . . . . . . . . . . . . . 2-1
Keys and Locks . . . . . . . . . . . . . . . 2-1
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Vehicle Security. . . . . . . . . . . . . . 2-10
Exterior Mirrors . . . . . . . . . . . . . . . 2-12
Interior Mirrors . . . . . . . . . . . . . . . . 2-13
Windows . . . . . . . . . . . . . . . . . . . . . 2-14
Roof . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16Seats and Restraints . . . . . . . . . 3-1
Head Restraints . . . . . . . . . . . . . . . 3-2
Front Seats . . . . . . . . . . . . . . . . . . . . 3-4
Rear Seats . . . . . . . . . . . . . . . . . . . . 3-9
Safety Belts . . . . . . . . . . . . . . . . . . 3-13
Airbag System . . . . . . . . . . . . . . . . 3-26
Child Restraints . . . . . . . . . . . . . . 3-43Storage . . . . . . . . . . . . . . . . . . . . . . . 4-1
Storage Compartments . . . . . . . . 4-1
Additional Storage Features . . . 4-2
Roof Rack System . . . . . . . . . . . . . 4-4Instruments and Controls . . . . 5-1
Controls . . . . . . . . . . . . . . . . . . . . . . . 5-2
Warning Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . . 5-8
Information Displays . . . . . . . . . . 5-23
Vehicle Messages . . . . . . . . . . . . 5-25
Trip Computer . . . . . . . . . . . . . . . . 5-26
Vehicle Personalization . . . . . . . 5-28Lighting . . . . . . . . . . . . . . . . . . . . . . . 6-1
Exterior Lighting . . . . . . . . . . . . . . . 6-1
Interior Lighting . . . . . . . . . . . . . . . . 6-5
Lighting Features . . . . . . . . . . . . . . 6-6Infotainment System . . . . . . . . . 7-1
Introduction . . . . . . . . . . . . . . . . . . . . 7-1
Radio . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Audio Players . . . . . . . . . . . . . . . . 7-18
Phone . . . . . . . . . . . . . . . . . . . . . . . . 7-26
Downloadable Applications . . . 7-45
Bluetooth Phone/Devices . . . . . 7-51Trademarks and License
Agreements . . . . . . . . . . . . . . . . . 7-59
Climate Controls . . . . . . . . . . . . . 8-1
Climate Control Systems . . . . . . 8-1
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 8-4
Maintenance . . . . . . . . . . . . . . . . . . . 8-5Driving and Operating . . . . . . . . 9-1
Driving Information . . . . . . . . . . . . . 9-2
Starting and Operating . . . . . . . 9-14
Engine Exhaust . . . . . . . . . . . . . . 9-22
Automatic Transmission . . . . . . 9-23
Manual Transmission . . . . . . . . . 9-26
Drive Systems . . . . . . . . . . . . . . . . 9-28
Brakes . . . . . . . . . . . . . . . . . . . . . . . 9-29
Ride Control Systems . . . . . . . . 9-31
Cruise Control . . . . . . . . . . . . . . . . 9-34
Driver Assistance Systems . . . 9-37
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 9-40
Towing . . . . . . . . . . . . . . . . . . . . . . . 9-44
Conversions and Add-Ons . . . 9-44Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (2,1)
2015 Chevrolet TRAX Owner Manual M
Vehicle Care . . . . . . . . . . . . . . . . . 10-1
General Information . . . . . . . . . . 10-2
Vehicle Checks . . . . . . . . . . . . . . . 10-3
Headlamp Aiming . . . . . . . . . . . 10-29
Bulb Replacement . . . . . . . . . . 10-29
Electrical System . . . . . . . . . . . . 10-32
Wheels and Tires . . . . . . . . . . . 10-41
Jump Starting . . . . . . . . . . . . . . . 10-69
Towing . . . . . . . . . . . . . . . . . . . . . . 10-71
Appearance Care . . . . . . . . . . . 10-74Service and Maintenance . . . 11-1
General Information . . . . . . . . . . 11-1
Maintenance Schedule . . . . . . . 11-2
Special ApplicationServices . . . . . . . . . . . . . . . . . . . . 11-8
Additional Maintenance
and Care . . . . . . . . . . . . . . . . . . . . 11-8
Recommended Fluids,
Lubricants, and Parts . . . . . . 11-11
Maintenance Records . . . . . . . 11-14Technical Data . . . . . . . . . . . . . . . 12-1
Vehicle Identification . . . . . . . . . 12-1
Vehicle Data . . . . . . . . . . . . . . . . . . 12-2Customer Information . . . . . . . 13-1
Customer Information . . . . . . . . 13-1
Reporting Safety Defects . . . . 13-12
Vehicle Data Recording andPrivacy. . . . . . . . . . . . . . . . . . . . 13-13
OnStar . . . . . . . . . . . . . . . . . . . . . . . 14-1
OnStar Overview . . . . . . . . . . . . . 14-1
OnStar Services . . . . . . . . . . . . . . 14-2
OnStar AdditionalInformation . . . . . . . . . . . . . . . . . . 14-6
Index . . . . . . . . . . . . . . . . . . . . . i-1Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (3,1)
This manual describes features that may or may not be on the vehicle because of optional equipment that was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner manual. Refer to the purchase documentation relating to your specific vehicle to confirm the features. Keep this manual in the vehicle for quick reference.
Introduction
iii
Canadian Vehicle Owners
Propriétaires Canadiens A French language manual can be obtained from your dealer, at www.helminc.com, or from: On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse savant: Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170
Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.
The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, and TRAX are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division wherever it appears in this manual.
Litho in U.S.A. Part No. 23118885 A First Printing
©2014 General Motors LLC. All Rights Reserved.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (4,1)
iv
Introduction
About Driving the Vehicle As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident. Be sure to read the driving guidelines in this manual in the section called “Driving and Operating” and specifically Driver Behavior on page 9-2, Driving Environment on page 9-2, and Vehicle Design on page 9-2.
Danger, Warnings, and Cautions Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them.
{ Danger
Danger indicates a hazard with a high level of risk which will result in serious injury or death.
{ Warning
Warning indicates a hazard that could result in injury or death.
{ Caution
Caution indicates a hazard that could result in property or vehicle damage.
Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator. M : This symbol is shown when you need to see your owner manual for additional instructions or information. * : This symbol is shown when you need to see a service manual for additional instructions or information.
A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (5,1)
Introduction
Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index. 9 : Airbag Readiness Light # : Air Conditioning ! : Antilock Brake System (ABS) % : Audio Steering Wheel Controls or OnStar® (if equipped) $ : Brake System Warning Light " : Charging System I : Cruise Control B : Engine Coolant Temperature O : Exterior Lamps # : Fog Lamps
. : Fuel Gauge + : Fuses 3 : Headlamp High/Low-Beam Changer j : LATCH System Child Restraints * : Malfunction Indicator Lamp : : Oil Pressure P : Power / : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/StabiliTrak® M : Windshield Washer Fluid
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (6,1)
vi
Introduction
2 NOTES
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (1,1)
In Brief
1-1
Performance and Maintenance
Traction Control/Electronic
Stability Control . . . . . . . . . . . . 1-19
Tire Pressure Monitor . . . . . . . . 1-20
Engine Oil Life System . . . . . . 1-20
Driving for Better FuelEconomy . . . . . . . . . . . . . . . . . . . 1-21
Roadside Assistance
Program . . . . . . . . . . . . . . . . . . . . 1-21
OnStar® . . . . . . . . . . . . . . . . . . . . . 1-21In Brief
Instrument Panel
Instrument Panel . . . . . . . . . . . . . . 1-2
Initial Drive Information
Initial Drive Information . . . . . . . . 1-4
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . 1-4
Remote Vehicle Start . . . . . . . . . 1-4
Door Locks . . . . . . . . . . . . . . . . . . . 1-5
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Windows . . . . . . . . . . . . . . . . . . . . . . 1-6
Seat Adjustment . . . . . . . . . . . . . . 1-6
Second Row Seats . . . . . . . . . . . 1-8
Heated Seats . . . . . . . . . . . . . . . . . 1-8
Head Restraint Adjustment . . . . 1-8
Safety Belts . . . . . . . . . . . . . . . . . . . 1-9
Passenger Sensing System(U.S. and Canada) . . . . . . . . . . 1-9
Mirror Adjustment . . . . . . . . . . . . . 1-9Steering Wheel
Adjustment . . . . . . . . . . . . . . . . . 1-10
Interior Lighting . . . . . . . . . . . . . . 1-10
Exterior Lighting . . . . . . . . . . . . . 1-11
Windshield Wiper/Washer . . . . 1-12
Climate Controls . . . . . . . . . . . . . 1-13
Transmission . . . . . . . . . . . . . . . . 1-14Vehicle Features
Radio(s) . . . . . . . . . . . . . . . . . . . . . 1-15
Satellite Radio . . . . . . . . . . . . . . . 1-16
Portable Audio Devices . . . . . . 1-16
Bluetooth® . . . . . . . . . . . . . . . . . . . 1-16
Steering Wheel Controls . . . . . 1-17
Cruise Control . . . . . . . . . . . . . . . 1-17
Driver InformationCenter (DIC) . . . . . . . . . . . . . . . 1-18
Rear Vision
Camera (RVC) . . . . . . . . . . . . . 1-18
Parking Assist . . . . . . . . . . . . . . . 1-18
Power Outlets . . . . . . . . . . . . . . . 1-18
Sunroof . . . . . . . . . . . . . . . . . . . . . . 1-19Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (2,1)
1-2
In Brief
Instrument Panel
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (3,1)
1. Air Vents on page 8-4. 2. Turn Signal Lever. See Turn and
Lane-Change Signals on page 6-4. Headlamp High/Low-Beam Changer on page 6-2. Instrument Cluster on page 5-9.
3. 4. Windshield Wiper/Washer on
page 5-3. Rear Window Wiper/Washer on page 5-4.
5. Light Sensor. See Automatic
6.
7. 8.
Headlamp System on page 6-3. Instrument Panel Storage on page 4-1. Infotainment on page 7-1. Instrument Panel Storage on page 4-1 (If Equipped).
9. Hood Release. See Hood on
page 10-4.
10. Exterior Lamp Controls on
19. Shift Lever. See Automatic
In Brief
1-3
Transmission on page 9-23 or Manual Transmission on page 9-26.
20. Hazard Warning Flashers on
page 6-3.
21. Passenger Safety Belt
Reminder Light. See Safety Belt Reminders on page 5-11.
page 6-1. Instrument Panel Illumination Control on page 6-5. Front Fog Lamps on page 6-4.
11. Data Link Connector (DLC)
(Out of View). See Malfunction Indicator Lamp on page 5-13. Instrument Panel Storage on page 4-1 (If Equipped).
12.
13. Steering Wheel Adjustment on
page 5-2.
14. Horn on page 5-3. 15.
Ignition Positions on page 9-15.
16. Traction Control/Electronic
Stabilty Control Button. See Traction Control/Electronic Stability Control on page 9-31.
17. Climate Control Systems on
page 8-1.
18. Parking Brake on page 9-30.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (4,1)
1-4
In Brief
Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.
Remote Keyless Entry (RKE) System The RKE transmitter may work up to 30 m (98 ft) away from the vehicle.
7 : If equipped, press and hold briefly to initiate vehicle locator. Press and hold for at least three seconds to sound the panic alarm. Press again to cancel the panic alarm. See Keys on page 2-1 and Remote Keyless Entry (RKE) System Operation on page 2-3.
Remote Vehicle Start For vehicles with this feature, the engine can be started from outside the vehicle. Starting the Vehicle 1. Aim the RKE transmitter at the
vehicle.
2. Press and release Q. 3.
Immediately after completing Step 2, press and hold / for several seconds or until the turn signal lamps flash.
Press the key release button to extend the key blade. The key can be used for the ignition and all locks. K : Press to unlock the driver door, all doors, or, if equipped, the locking fuel door. The hazard warning flashers may flash. Q : Press to lock the doors, or, if equipped, the locking fuel door. Lock and unlock feedback can be personalized. See Vehicle Personalization on page 5-28.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (5,1)
Door Locks To lock or unlock a door manually:
Q : Press to lock the doors. See Power Door Locks on page 2-7.
In Brief
1-5
Liftgate
From the inside, to lock the door, use the lock knob on the top of the door panel. From the outside, turn the key toward the front or rear of the vehicle, or press K or Q on the Remote Keyless Entry (RKE) transmitter.
Power Door Locks
When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on. The engine will continue to run for 10 minutes. Repeat the steps for a 10-minute time extension. Remote start can be extended only once. Canceling a Remote Start To cancel a remote start, do one of the following: . Aim the RKE transmitter at the vehicle and press and hold / until the parking lamps turn off. Turn on the hazard warning flashers. Turn the vehicle on and then off.
See Remote Vehicle Start on page 2-5.
K : Press to unlock the doors.
To open the liftgate, press K on the door lock switch or on the Remote Keyless Entry (RKE) transmitter to unlock all doors, then use the touch pad on the trunk. Press Q on the door lock switch or on the RKE transmitter to lock the liftgate.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (6,1)
1-6
In Brief
See Remote Keyless Entry (RKE) System Operation on page 2-3. See Liftgate on page 2-9.
Windows
Accessory Power (RAP) is active. See Retained Accessory Power (RAP) on page 9-19.
3. Try to move the seat back and
forth to be sure it is locked in place.
Seat Adjustment
Manual Seats
Height Adjustment
Press the switch to lower the window. Pull up on the front edge of the switch to raise it. See Power Windows on page 2-14. The switches work when the vehicle is in ON/RUN or ACC/ ACCESSORY, or when Retained
To adjust a manual seat: 1. Pull the handle at the front of
the seat.
2. Slide the seat to the desired
position and release the handle.
If available, move the lever up or down to manually raise or lower the seat. See Seat Adjustment on page 3-4.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (7,1)
Power Seats
See Power Seat Adjustment on page 3-4. Lumbar Adjustment
Reclining Seatbacks
In Brief
1-7
To adjust the power driver seat, if available: . Move the seat forward or
rearward by sliding the control forward or rearward.
. Raise or lower the front part of the seat cushion by moving the front of the control up or down.
. Raise or lower the entire seat by moving the rear of the control up or down.
Manual Seat Shown, Power Seat
Similar
If available, press the front or rear of the switch to increase or decrease lumbar support. Release the switch when the desired level of support is reached. See Lumbar Adjustment on page 3-5.
Manual Seat Shown, Power Seat
Similar
To recline the seatback: 1. Lift the lever.
If necessary, move the safety belt out of the way to access the lever.
2. Move the seatback to the
desired position, then release the lever to lock the seatback in place.
3. Push and pull on the seatback to
make sure it is locked.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (8,1)
1-8
In Brief
To return the seatback to an upright position: 1. Lift the lever fully without applying pressure to the seatback, and the seatback returns to the upright position.
2. Push and pull on the seatback to
make sure it is locked.
See Reclining Seatbacks on page 3-5.
Second Row Seats The rear seatbacks can be folded down to increase cargo space. See Rear Seats on page 3-9.
Heated Seats
If available, the controls are on the climate control panel. To operate, the engine must be running.
Press M or L to heat the driver or passenger seat. See Heated Front Seats on page 3-7.
Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. See Head Restraints on page 3-2
and Seat Adjustment on page 3-4.Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (9,1)
Safety Belts
Refer to the following sections for important information on how to use safety belts properly: . Safety Belts on page 3-13. . How to Wear Safety Belts
Properly on page 3-14. Lap-Shoulder Belt (U.S. and Canada) on page 3-15 or Lap-Shoulder Belt (Mexico) on page 3-20.
Lower Anchors and Tethers for Children (LATCH System) on page 3-50.
Passenger Sensing System (U.S. and Canada)
United States
In Brief
1-9
passenger sensing system. See Passenger Sensing System (U.S. and Canada) on page 3-36 for important information. The passenger airbag status indicator will be visible on the instrument panel when the vehicle is started. See Passenger Airbag Status Indicator (U.S. and Canada) on page 5-12.
Mirror Adjustment
Exterior Mirrors
Canada
The passenger sensing system turns off the front outboard passenger frontal airbag and knee airbag under certain conditions. No other airbag is affected by the
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (10,1)
Automatic Dimming Rearview Mirror If equipped, automatic dimming reduces the glare of headlamps from behind. The dimming feature comes on when the vehicle is started. See Automatic Dimming Rearview Mirror on page 2-13.
Steering Wheel Adjustment
To adjust the steering wheel: 1. Pull the lever down. 2. Move the steering wheel up,
down, forward, and backward.
3. Pull the lever up to lock the
steering wheel in place.
Do not adjust the steering wheel while driving.
Interior Lighting
Front and Rear Dome Lamps
1-10
In Brief
To adjust the mirrors: 1. Turn the selector switch to L
(Left) or R (Right) to choose the driver or passenger mirror.
2. Move the control to adjust the
mirror.
3. Turn the selector switch to ( to
deselect the mirror.
Interior Mirror
Adjustment Adjust the rearview mirror to get a clear view of the area behind the vehicle.
Manual Rearview Mirror If equipped, push the tab forward for daytime use and pull it for nighttime use to avoid the glare of headlamps from behind. See Manual Rearview Mirror on page 2-13.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (11,1)
The front dome lamp controls are in the overhead console. ( : Press to turn the lamps off, even when a door is open. H : When the button is returned to the middle position, the lamps turn on automatically when a door is opened. ' : Press to turn on the dome lamps.
9 : Press to turn the lamps off, even when a door is open. H : When the button is returned to the middle position, the lamps turn on automatically when a door is opened. R : Press to turn on the dome lamps. Reading Lamps
The rear dome lamp controls are in the headliner above the rear seats.
The front reading lamps are in the overhead console. # or $ : Press to turn each lamp on or off.
In Brief
1-11
For more information about interior lighting, see Instrument Panel Illumination Control on page 6-5 or Courtesy Lamps on page 6-5.
Exterior Lighting
The exterior lamp control is to the left of the steering column on the instrument panel. There are four positions: O : Briefly turn to this position to turn the automatic lamp control off or on again.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (12,1)
1-12
In Brief
If equipped with the auto
AUTO: headlamp system, it turns the headlamps on automatically at normal brightness, together with the parking lamps, taillamps, license plate lamps, sidemarker lamps, and instrument panel lights. ; : Turns on the parking lamps including all lamps except the headlamps. 5 : Turns on the headlamps together with the parking lamps and instrument panel lights. A warning chime sounds if the driver door is opened when the ignition switch is off and the headlamps are on. # : If equipped with fog lamps, press to turn the lamps on or off. See: . Exterior Lamp Controls on
page 6-1
Front Fog Lamps on page 6-4Windshield Wiper/Washer
The windshield wiper/washer lever is located on the right side of the steering column. Move the lever to one of the following positions: HI: Use for fast wipes. LO: Use for slow wipes.
INT: Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. OFF: Use to turn the wipers off. 1X: For a single wipe, briefly move the wiper lever down. For several wipes, hold the wiper lever down. b : Pull the windshield wiper lever toward you to spray windshield washer fluid and activate the wipers.
Rear Window Wiper/Washer If equipped with the rear wiper/ washer, the controls are on the end of the windshield wiper lever. ON: Press the upper portion of the button for continuous rear window wipes. OFF: The rear wiper turns off when the button is returned to the middle position.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (13,1)
In Brief
1-13
INT (Intermittent Rear Wipes): Press the lower portion of the button to set a delay between wipes. m = REAR (Rear Washer): Push the windshield wiper lever forward to spray washer fluid on the rear window. The lever returns to its starting position when released. See Windshield Wiper/Washer on page 5-3 and Rear Window Wiper/ Washer on page 5-4 (If Equipped).
Climate Controls If equipped with these climate control systems, the heating, cooling, and ventilation can be controlled for the vehicle.
Climate Control System with Heater and Air Conditioning
1. Temperature Control 2. Fan Control 3. Air Delivery Mode Control 4. Driver and Passenger Heated
Seats
5. Air Conditioning 6. Rear Window Defogger 7. Recirculation
Climate Control System with
Heater Only 1. Temperature Control 2. Fan Control 3. Air Delivery Mode Control 4. Rear Window Defogger See Climate Control Systems on page 8-1.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (14,1)
1-14
In Brief
Transmission
Driver Shift Control (DSC)
2. Press the + (plus) end of the button on the side of the shift lever to upshift, or push the − (minus) end of the button to downshift.
See Manual Mode on page 9-25. Manual Transmission
See Manual Transmission on page 9-26. Up-Shift Light
If the vehicle has a manual transmission, it may have an up-shift light that indicates when to shift to the next higher gear for the best fuel economy. See Manual Transmission on page 9-26.
DSC allows you to shift an automatic transmission similar to a manual transmission. To use the DSC feature: 1. Move the shift lever from
D (Drive) rearward to M (Manual).
To engage R (Reverse), with the vehicle stationary, pull up on the button on the selector lever and engage the gear. If the gear does not engage, set the lever in Neutral, release the clutch pedal and apply it again; then repeat gear selection.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (15,1)
Vehicle Features
Radio(s)
Radio Controls without Touchscreen O /VOL: Press to turn the system on and off. Turn to increase or decrease the volume. RADIO/BAND: Press to select AM, FM, or SiriusXM® (if equipped). © Seek ¨ : Press to seek the previous or next station. Buttons 1−6: Press to save and select favorite stations. INFO: Press to view current radio information. For more information about these and other radio features, see Operation on page 7-8. Storing a Favorite Station Stations from all bands can be stored in the favorite lists in any order. Up to six stations can be
stored in each favorite page and the number of available favorite pages can be set. To store the station to a position in the list, press the corresponding button 1−6 until a beep is heard. See “Storing a Station as a Favorite” in AM-FM Radio on page 7-11. Radio Controls with Touchscreen
Audio Source Menu z VOL y: Press to increase or decrease the volume. O : Press and hold to turn the system on and off. D : Press to enter the Home Page. Storing a Favorite Station Stations from all bands can be stored in any order in the favorite pages. Up to five stations can be stored in each of the seven favorites pages.
In Brief
1-15
Storing Stations To store the station to a position in the list, press the corresponding button 1−5 until a beep is heard. 1. Select the desired station. 2. Press S or T to select the
desired page of saved favorites.
3. Hold down any of the preset
buttons to save the current radio station to that button of the selected favorites page.
To change a preset button, tune to the new desired radio station and hold the button.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (16,1)
1-16
In Brief
See “Storing a Station as a Favorite” in "Playing the Radio with Touchscreen" under AM-FM Radio on page 7-11. Setting the Clock See Clock on page 5-5.
Satellite Radio If equipped, vehicles with a SiriusXM® satellite radio tuner and a valid SiriusXM satellite radio subscription can receive SiriusXM programming. SiriusXM Satellite Radio Service SiriusXM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. SiriusXM satellite radio has a wide variety of programming and commercial-free music, coast to coast, and in digital-quality sound. A fee is required to receive the SiriusXM service.
Refer to: . www.siriusxm.com or call
1-866-635-2349 (U.S.). . www.xmradio.ca or call
1-877-209-0079 (Canada).
See Satellite Radio on page 7-15.
Portable Audio Devices There is a USB port in the storage area to the right of the infotainment system. If equipped, there is a 3.5 mm (1/8 in) AUX input jack on the front of the infotainment system. External devices such as iPods®, laptop computers, MP3 players, CD changers, and USB storage devices may be connected, depending on the audio system. See USB Port on page 7-20 and Auxiliary Devices on page 7-24.
Bluetooth® The Bluetooth® system allows users with a Bluetooth-enabled mobile phone to make and receive hands-free calls using the vehicle audio system and controls. The Bluetooth-enabled mobile phone must be paired with the in-vehicle Bluetooth system before it can be used in the vehicle. Not all phones will support all functions. See Bluetooth (Voice Recognition) on page 7-36 or Bluetooth (Infotainment Controls) on page 7-27 or Bluetooth (Overview) on page 7-26 and Hands-Free Phone on page 7-42.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (17,1)
Steering Wheel Controls
Some audio steering wheel controls could differ depending on the vehicle's options. Some audio steering wheel controls can be adjusted at the steering wheel. b / g : Press to interact with the available Bluetooth or OnStar systems. $ / i : Press to decline an incoming call, to end speech recognition, or to end a current call. Press to silence the vehicle
speakers while using the infotainment system. Press again to turn the sound on. For vehicles with OnStar or Bluetooth systems, press to reject an incoming call, or end a current call. _ SRC ^ : Press to select an audio source. Toggle up or down to select the next or previous favorite radio station, CD/MP3 track, USB file, iPod/ iPhone song or Bluetooth music. Toggle and hold up or down to fast forward or reverse the radio stations, CD/MP3 tracks, USB files, iPod/iPhone songs or Bluetooth music. + x −: Press + or − to increase or decrease the volume. See Steering Wheel Controls on page 5-2.
In Brief
1-17
Cruise Control
o : Press to turn the cruise control system on and off. A white indicator comes on in the instrument cluster when cruise is turned on. RES/+: memory, move the thumbwheel up briefly to resume to that speed or hold upwards to accelerate. If cruise control is already active, use to increase vehicle speed.
If there is a set speed in
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (18,1)
1-18
In Brief
SET/−: Move the thumbwheel down briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease speed. n : Press to disengage cruise control without erasing the set speed from memory. See Cruise Control on page 9-34.
Driver Information Center (DIC) If equipped, the DIC display is in the instrument cluster. It shows the status of many vehicle systems. The controls for the DIC are on the turn signal lever.
1. SET/CLR: Press to set or clear
the menu item displayed.
2. w x : Use the thumbwheel to
scroll through the items in each menu.
3. MENU: Press to display the DIC menus. This button is also used to return to or exit the last screen displayed on the DIC.
See Driver Information Center (DIC) on page 5-23.
Rear Vision Camera (RVC) If equipped, RVC displays a view of the area behind the vehicle, on the center stack display, when the vehicle is shifted into R (Reverse). See Rear Vision Camera (RVC) on page 9-38.
Parking Assist If equipped, this system uses sensors on the rear bumper to assist with parking and avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph). Rear Parking Assist (RPA) uses audible beeps to provide distance and system information. Keep the sensors on the vehicle's rear bumper clean to ensure proper operation. See Parking Assist on page 9-37.
Power Outlets The accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. The vehicle has an accessory power outlet in front of the cupholders on the center stack. See Power Outlets on page 5-6.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (19,1)
Sunroof
Open/Close: Press and hold the front or rear of switch (1) to open or close the sunroof. Vent: Press and hold the front or rear of switch (2) to vent or close the sunroof. Manually close the sunshade. The sunroof will not operate if the vehicle has an electrical failure. See Sunroof on page 2-16.
If equipped, the sunroof only operates when the ignition is turned to ON/RUN or Retained Accessory Power (RAP) is active.
In Brief
1-19
Performance and Maintenance
Traction Control/ Electronic Stability Control If equipped, the traction control system limits wheel spin. The system is on when the vehicle is started. If equipped, the StabiliTrak system assists with directional control of the vehicle in difficult driving conditions. The system is on when the vehicle is started.
To turn off traction control, press and release g on the center stack. i illuminates in the instrument cluster.
. Press and release g again to turn traction control back on.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (20,1)
1-20
In Brief
To turn off both Traction Control and StabiliTrak, press and hold g until g and i illuminate in the instrument cluster.
. Press g again to turn on both
systems.
See Traction Control/Electronic Stability Control on page 9-31.
Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS).
The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and
Loading Information label. See Vehicle Load Limits on page 9-10. The warning light will remain on until the tire pressure is corrected. The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures. See Tire Pressure Monitor System on page 10-49.
Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the : % CHANGE message on the DIC when it is necessary to change the engine oil and filter.
Remember, the oil life display must be reset after each oil change. It will not reset itself.
Resetting the Oil Life System 1. Press the MENU button to show
Remaining Oil Life on the display. This display shows an estimate of the oil’s remaining useful life. If 99% is displayed, that means that 99% of the current oil life remains.
2. To reset the engine oil life
system, press the SET/CLR button while the oil life display is active. After a few seconds, there will be a single chime and the oil life will be reset to 100%.
Be careful not to reset the oil life display accidentally at any time other than when the oil has just been changed. It cannot be reset accurately until the next oil change. See Engine Oil Life System on page 10-11.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (21,1)
In Brief
1-21
OnStar® This vehicle may be equipped with a comprehensive, in-vehicle system that can connect to a live OnStar Advisor for Emergency, Security, Navigation, Connection, and Diagnostic Services. OnStar services may require a paid subscription. See OnStar Overview on page 14-1.
Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. . Avoid fast starts and accelerate
smoothly.
. Brake gradually and avoid
abrupt stops.
. Avoid idling the engine for long
periods of time.
. When road and weather
conditions are appropriate, use cruise control.
. Always follow posted speed
limits or drive more slowly when conditions require.
. Keep vehicle tires properly
inflated.
. Combine several trips into a
single trip.
. Replace the vehicle's tires with
the same TPC Spec number molded into the tire's sidewall near the size. Follow recommended scheduled maintenance.
Roadside Assistance Program U.S.: 1-800-243-8872
TTY Users (U.S. Only): 1-888-889-2438
Canada: 1-800-268-6800
New Chevrolet owners are automatically enrolled in the Roadside Assistance Program. See Roadside Assistance Program on page 13-5.Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (22,1)
1-22
In Brief
2 NOTES
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (1,1)
Keys, Doors, and Windows
2-1
Exterior Mirrors
Convex Mirrors . . . . . . . . . . . . . . 2-12
Power Mirrors . . . . . . . . . . . . . . . . 2-12
Folding Mirrors . . . . . . . . . . . . . . . 2-13
Heated Mirrors . . . . . . . . . . . . . . . 2-13Interior Mirrors
Interior Rearview Mirrors . . . . . 2-13
Manual Rearview Mirror . . . . . . 2-13
Automatic Dimming RearviewMirror . . . . . . . . . . . . . . . . . . . . . . . 2-13
Windows
Windows . . . . . . . . . . . . . . . . . . . . . 2-14
Power Windows . . . . . . . . . . . . . 2-14
Sun Visors . . . . . . . . . . . . . . . . . . . 2-16Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . 2-16
Keys and Locks
Keys
{ Warning
Leaving children in a vehicle with the ignition key is dangerous and children or others could be seriously injured or killed. They could operate the power windows or other controls or make the vehicle move. The windows will function with the keys in the ignition, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with the ignition key.
Keys, Doors, and Windows
Keys and Locks
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . 2-2
Remote Keyless Entry (RKE)
System Operation . . . . . . . . . . . 2-3
Remote Vehicle Start . . . . . . . . . 2-5
Door Locks . . . . . . . . . . . . . . . . . . . 2-7
Power Door Locks . . . . . . . . . . . . 2-7
Delayed Locking . . . . . . . . . . . . . . 2-8
Automatic Door Locks . . . . . . . . . 2-8
Safety Locks . . . . . . . . . . . . . . . . . . 2-8Doors
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Vehicle Security
Vehicle Security . . . . . . . . . . . . . . 2-10
Vehicle Alarm System . . . . . . . 2-10
Immobilizer . . . . . . . . . . . . . . . . . . 2-11
Immobilizer Operation . . . . . . . . 2-11Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (2,1)
2-2
Keys, Doors, and Windows
If locked out of the vehicle, see Roadside Assistance Program on page 13-5. With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview on page 14-1.
Remote Keyless Entry (RKE) System See Radio Frequency Statement on page 13-11. If there is a decrease in the RKE operating range: . Check the distance. The
transmitter may be too far from the vehicle.
. Check the location. Other vehicles or objects may be blocking the signal.
. Check the transmitter's battery.
See “Battery Replacement” later in this section.
The key that is part of the Remote Keyless Entry (RKE) transmitter can be used for the ignition and all locks.
Press the key release button on the RKE transmitter to extend the key blade. Press the button and the key blade to retract the key. The key code is stamped on the key number plate and can be used to make new keys at any dealer. Store this information in a safe place outside the vehicle. If it becomes difficult to turn the key in the ignition, inspect the key blade for debris. Periodically clean with a brush or pick. See your dealer if a new key is needed.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (3,1)
If the transmitter is still not working correctly, see your dealer or a qualified technician for service.
Remote Keyless Entry (RKE) System Operation The RKE transmitter may work up to 30 m (98 ft) away from the vehicle. Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System on page 2-2.
Keys, Doors, and Windows
2-3
The following may be available: Q (Lock): Press to lock all doors or, if equipped, the locking fuel door. The hazard warning lamps may flash and/or the horn may sound to indicate locking. See “Remote Lock Feedback” under Vehicle Personalization on page 5-28. If the driver door is open when Q is pressed and Unlocked Door Anti Lock Out is enabled through vehicle personalization, all doors will lock and then the driver door will unlock. See “Unlocked Door Anti Lock Out” under Vehicle Personalization on page 5-28. Pressing Q may also arm the alarm system. See Vehicle Alarm System on page 2-10. K (Unlock): Press to unlock the driver door, all doors or, if equipped, the locking fuel door. See “Door Unlock Options” under Vehicle Personalization on page 5-28.
The hazard warning lamps may flash to indicate unlocking. See “Remote Unlock Light Feedback” under Vehicle Personalization on page 5-28. Pressing K will disarm the alarm system. See Vehicle Alarm System on page 2-10. 7 (Vehicle Locator/Panic Alarm): If equipped, press and hold briefly to initiate vehicle locator. The exterior lamps flash and the horn chirps three times. Press and hold 7 for at least three seconds to sound the panic alarm. The horn sounds and the turn signals flash for 30 seconds, or until 7 is pressed again or the key is placed in the ignition and turned to ACC/ACCESSORY or ON/RUN. / (Remote Vehicle Start): If equipped, press Q and then press and hold / to start the engine from
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (4,1)
2-4
Keys, Doors, and Windows
outside the vehicle using the RKE transmitter. See Remote Vehicle Start on page 2-5. The RKE transmitter buttons will not operate when the key is in the ignition. Programming Transmitters to the Vehicle Only RKE transmitters programmed to this vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. When the replacement transmitter is programmed to this vehicle, all remaining transmitters must also be reprogrammed. Any lost or stolen transmitters will no longer work once the new transmitter is programmed.
Programming with a Recognized Transmitter To program a new key: 1.
Insert the original, already programmed key in the ignition and turn to the key to the ON/ RUN position.
2. Turn the key to LOCK/OFF, and
3.
remove the key. Insert the new key to be programmed and turn it to the ON/RUN position within five seconds. The security light will turn off once the key has been programmed.
4. Repeat Steps 1–3 if additional
keys are to be programmed.
If a key is lost or damaged, see your dealer to have a new key made.
Programming without a Recognized Transmitter Program a new key to the vehicle when a recognized key is not available. Canadian regulations require that owners see their dealer. If there are no currently recognized keys available, follow this procedure to program the first key. This procedure will take approximately 30 minutes to complete for the first key. The vehicle must be off and all of the keys you wish to program must be with you. 1.
Insert the new vehicle key into the ignition.
2. Turn to ON/RUN. The security
light will come on.
3. Wait 10 minutes until the
security light turns off.
4. Turn the ignition to LOCK/OFF.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (5,1)
Keys, Doors, and Windows
2-5
5. Repeat Steps 2–4 two more
times. After the third time, turn to ON/RUN; the key is learned and all previously known keys will no longer work with the vehicle.
Remaining keys can be learned by following the procedure in “Programming with a Recognized Transmitter”. Battery Replacement The battery is not rechargeable. To replace the battery:
{ Caution
When replacing the battery, do not touch any of the circuitry on the transmitter. Static from your body could damage the transmitter.
Remote Vehicle Start The vehicle may have this feature that allows you to start the engine from outside the vehicle. / (Remote Vehicle Start): This button will be on the RKE transmitter if the vehicle has remote start. The climate control system will use the previous settings during a remote start. The rear defog may come on during remote start based on cold ambient conditions. The rear fog indicator light does not come on during remote start. If the vehicle has heated seats, they may come on during a remote start. See Heated Front Seats on page 3-7. Laws in some local communities may restrict the use of remote starters. For example, some laws require a person using remote start to have the vehicle in view. Check local regulations for any requirements.
1. Extend the key blade and open the battery cover on the back of the transmitter by prying with a finger.
2. Remove the used battery by
3.
pushing on the battery and sliding it toward the key blade. Insert the new battery, positive side facing up. Push the battery down until it is held in place. Replace with a CR2032 or equivalent battery.
4. Snap the battery cover back on
to the transmitter.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (6,1)
2-6
Keys, Doors, and Windows
Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System on page 2-2.
Starting the Vehicle To start the engine using the remote start feature: 1. Aim the RKE transmitter at the
vehicle.
2. Press and release Q. 3.
Immediately after completing Step 2, press and hold / for several seconds or until the turn signal lamps flash. The turn signal lamps flashing confirms the request to remote start the vehicle has been received.
When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on.
The engine will continue to run for 10 minutes. Repeat the steps for a 10-minute time extension. Remote start can be extended only once. Start the vehicle before driving.
Extending Engine Run Time The engine run time can also be extended by another 10 minutes, if during the first 10 minutes Steps 1–3 are repeated while the engine is still running. This provides a total of 20 minutes. The remote start can only be extended once. When the remote start is extended, the second 10-minute period is added on to the first 10 minutes for a total of 20 minutes. A maximum of two remote starts, or a remote start with an extension, are allowed between ignition cycles. The vehicle's ignition must be changed to ON/RUN/START and then back to OFF before the remote start procedure can be used again.
Canceling a Remote Start To cancel a remote start, do one of the following: . Aim the RKE transmitter at the vehicle and press and hold / until the parking lamps turn off. Turn on the hazard warning flashers. Turn the vehicle on and then off.
Conditions in Which Remote Start Will Not Work The remote vehicle start feature will not operate if:
The key is in the ignition. The hood is not closed. The hazard warning flashers are on. The malfunction indicator lamp is on. The engine coolant temperature is too high. The oil pressure is low.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (7,1)
Keys, Doors, and Windows
2-7
Two remote vehicle starts, or a single remote start with an extension, have already been used. The vehicle is not in P (Park).
Door Locks
{ Warning Unlocked doors can be dangerous.
. Passengers, especially
children, can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle will not open it. The chance of being thrown out of the vehicle in a crash is increased if the doors are not locked. So, all passengers should wear safety belts properly and the doors should be locked whenever the vehicle is driven.
(Continued)
Warning (Continued)
. Young children who get into
unlocked vehicles may be unable to get out. A child can be overcome by extreme heat and can suffer permanent injuries or even death from heat stroke. Always lock the vehicle whenever leaving it.
. Outsiders can easily enter through an unlocked door when you slow down or stop the vehicle. Locking the doors can help prevent this from happening.
To lock or unlock a door manually:
From the inside, to lock the door, use the lock knob on the top of the door panel. From the outside, turn the key toward the front or rear of the vehicle, or press K or Q on the Remote Keyless Entry (RKE) transmitter.
Power Door Locks
Press Q or K to lock or unlock the doors, tailgate, and if equipped, the locking fuel door. If the driver door is open, the driver door and locking fuel door cannot be locked. This can be changed in the Vehicle Settings. See Vehicle Personalization on page 5-28.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (8,1)
See Vehicle Personalization on page 5-28.
Safety Locks The rear door safety locks prevent passengers from opening the rear doors from inside the vehicle. Manual Safety Locks
2-8
Keys, Doors, and Windows
Delayed Locking This feature delays the actual locking of the doors until five seconds after all doors are closed. Delayed locking can only be turned on when the Unlocked Door Anti Lockout feature has been turned off. When Q is pressed on the power door lock switch with the door open, a chime will sound three times indicating that delayed locking is active. The doors will then lock automatically five seconds after all doors are closed. If a door is reopened before five seconds have elapsed, the five-second timer will reset once all the doors are closed again. Press Q on the door lock switch again, or press Q on the RKE transmitter, to override this feature and lock the doors immediately.
Delayed locking can be programmed through the Driver Information Center (DIC). See Vehicle Personalization on page 5-28.
Automatic Door Locks
Automatic Door Lock When the doors are closed, the ignition is on, and the shift lever is moved out of P (Park) for automatic transmissions, or when vehicle speed becomes faster than 13 km/h (8 mph) for manual transmissions, the doors will lock. Automatic door locking can be configured. See Vehicle Personalization on page 5-28. Automatic Door Unlock When the shift lever is moved into P (Park) for automatic transmissions or when the key is removed from the ignition for manual transmissions, the doors will automatically unlock.
Chevrolet TRAX Owner Manual 7576294) - 2015 - crc - 5/8/14
(GMNA-Localizing-U.S./Canada/Mexico-
Black plate (9,1)
Keys, Doors, and Windows
2-9
If equipped, the safety lock is located on the inside edge of the rear doors. To use the safety lock: 1.
Insert the key into the safety lock slot and turn it so the slot is in the horizontal position.
2. Close the door. 3. Do the same for the other
rear door.
To open a rear door when the safety lock is on: 1. Unlock the door by activating the
inside handle, using the power door lock switch, or the Remote Keyless Entry (RKE) transmitter. 2. Open the door from the outside. To cancel the safety lock: 1. Unlock the door and open it from
2.
the outside. Insert the key into the safety lock slot and turn it so the slot is in the vertical position. Do the same for the other door.
Doors
Liftgate
{ Warning
Exhaust gases can enter the vehicle if it is driven with the liftgate, hatch/trunk open, or with any objects that pass through the seal between the body and the hatch/trunk or liftgate. Engine exhaust contains carbon monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. If the vehicle must be driven with the liftgate or hatch/trunk open:
. Close all of the windows. . Fully open the air outlets on
or under the instrument panel.
(Continued)
Warning (Continued)
. Adjust the climate control
