Windshield Wiper/Washer


With the ignition in ACC/ ACCESSORY or ON/RUN/START, move the windshield wiper lever to select the wiper speed. HI : Use for fast wipes. LO : Use for slow wipes.


( (Heated Steering Wheel, If Equipped) : Press to turn the heated steering wheel on or off. A light next to the button displays when the feature is turned on. The steering wheel takes about three minutes to be fully heated.


INT (Intermittent Wipes) : Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. If the windshield wipers are in use for about six seconds while driving, the exterior lamps come on automatically if the exterior lamp control is in AUTO. See “Wiper-Activated Headlamps” later in this section. OFF : Use to turn the wipers off. 1X (Mist) : For a single wipe, briefly move the wiper lever down. For several wipes, hold the wiper lever down. Clear snow and ice from the wiper blades and windshield before using them. If frozen to the windshield, carefully loosen or thaw them. Damaged blades should be replaced. See Wiper Blade Replacement 0 288. Heavy snow or ice can overload the wiper motor. See Electrical System Overload 0 291.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Wiper Parking When using intermittent or Rainsense™ wipes, the wipers pause briefly on the windshield. If the wiper lever is moved to OFF or if Rainsense and additional wipes are not required, the wipers may move to the base of the windshield. If the ignition is put in OFF while the wipers are on LO, HI, or INT, they will immediately stop. If the windshield wiper lever is then moved to OFF before the driver door is opened or within 10 minutes, the wipers will restart and move to the base of the windshield. If the ignition is put in OFF while the wipers are performing wipes due to windshield washing or Rainsense wipes, the wipers continue to run until they reach the base of the windshield. Rainsense If equipped with Rainsense, a sensor near the top center of the windshield detects the amount of water on the windshield and controls the frequency of the


Instruments and Controls


109


windshield wiper. To turn this feature on or off, see “Rain Sense Wipers” under Vehicle Personalization 0 152. Keep this area of the windshield clear of debris to allow for best system performance. INT (Rainsense Wipe Sensitivity Control) : When enabled, move the windshield wiper lever to INT. Turn the x INT band on the wiper lever to adjust the sensitivity.


. Turn the band up for more


sensitivity to moisture.


. Turn the band down for less


sensitivity to moisture.


. Move the windshield wiper lever


out of the INT position to deactivate Rainsense.


Wiper Arm Assembly Protection If equipped with wiper arm assembly protection, when using an automatic car wash, move the windshield wiper lever to OFF. This disables the automatic Rainsense windshield wipers. With Rainsense, if the transmission is in N (Neutral) and the vehicle speed is very slow, the wipers will automatically stop at the base of the windshield. The wiper operations return to normal when the transmission is no longer in N (Neutral) or the vehicle speed has increased. n L(Windshield Washer) : Pull the windshield wiper lever toward you to spray windshield washer fluid and activate the wipers. The wipers will continue until the lever is released or the maximum wash time is reached. When the windshield wiper lever is released, additional wipes may occur depending on how long the windshield washer had been activated. See Washer Fluid 0 283
for information on filling the windshield washer fluid reservoir.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


110


Instruments and Controls


{ Warning


In freezing weather, do not use the washer until the windshield is warmed. Otherwise the washer fluid can form ice on the windshield, blocking your vision.


Wiper-Activated Headlamps This feature activates the headlamps and parking lamps after the windshield wipers have been in use for about six seconds. For this feature to work, the exterior lamp control must be in AUTO. The wiper-activated headlamps immediately turn off when the ignition is turned to LOCK/OFF, or the windshield wiper control is turned off.


Compass The vehicle may have a compass display on the Driver Information Center (DIC). The compass receives its heading and other information from the Global Positioning


System (GPS) antenna, StabiliTrak®, and vehicle speed information. The compass system is designed to operate for a certain number of miles or degrees of turn before needing a signal from the GPS satellites. When the compass display shows CAL, drive the vehicle for a short distance in an open area where it can receive a GPS signal. The compass system will automatically determine when a GPS signal is restored and provide a heading again. See Compass Messages 0 141 for the messages that may be displayed for the compass.


Clock The infotainment system controls are used to access the time and date settings through the menu system. See “Home Page” in the infotainment manual for information about how to use the menu system.


Setting the Clock


Time To set the time: 1. From the Home Page, touch


the SETTINGS screen button, then touch Time and Date.


2. Touch Set Time, then touch + or − to increase or decrease hours or minutes, and change AM or PM.


3. Touch 12-24 Hr for a 12 or


24 hour clock.


4. Touch [ Back to go back to the


previous menu.


Date To set the date: 1. Touch the SETTINGS screen


button and touch Time and Date.


2. Touch Set Date and touch + or


− to increase or decrease month, day, or year.


3. Touch [ Back to go back to the


previous menu.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


111


Auto Set When on, the time and date will automatically update. To set auto set: 1. Touch the SETTINGS screen


button, then touch Time and Date.


2. Touch Set Time or Set Date. 3. Touch Auto Set, then select


On-Cell Network or Off-Manual to manually set the time and date.


4. Touch [ Back to go back to the


previous menu.


If auto set is on, the time displayed on the clock may not update immediately when driving into a new time zone.


2. Touch Clock Display, then


select Off or On.


3. Touch [ Back to go back to the


previous menu.


Power Outlets


Power Outlets 12 Volt Direct Current Accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. The vehicle has three 12-volt accessory power outlets:


Inside the center console storage in front of the armrest cover. Inside the storage area under the armrest cover.


Clock Display When on, the digital clock will display on the infotainment screen. To set the clock display: 1. Touch the SETTINGS screen


button and touch Time and Date.


. On the rear of the center


console, if equipped.


These outlets are powered while the vehicle is in ON/RUN/START or ACC/ACCESSORY mode, or until the driver door is opened within 10 minutes of turning off the vehicle.


Lift the cover to access the accessory power outlet. Certain electrical accessories may not be compatible with the accessory power outlet and could overload a vehicle circuit breaker or adapter fuse. If overloaded, the circuit breaker will reset after all devices are disconnected or if Retained Accessory Power (RAP) is turned off and then back on. See Retained Accessory Power (RAP) 0 206. Wait one minute to allow the circuit breaker to reset before reconnecting devices or turning RAP back on. If the problem continues, the issue could be within your device. Try another known good device to make sure the circuit breaker is operating properly. If this does not resolve your problem, see your dealer. It is possible to replace the factory power outlet with a cigar lighter receptacle, if desired. This requires the factory installed circuit breaker to be replaced with a standard minifuse by the dealer. A minifuse will not reset and will have to be replace if blown.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


112


Instruments and Controls


Caution


Failure to replace the circuit breaker with the minifuse could overheat the cigar lighter and damage the vehicle.


When adding electrical equipment, be sure to follow the proper installation instructions included with the equipment. See Add-On Electrical Equipment 0 259.


Caution


Hanging heavy equipment from the power outlet can cause damage not covered by the vehicle warranty. The power outlets are designed for accessory power plugs only, such as cell phone charge cords.


Power Outlet 110/120 Volt Alternating Current If equipped, this power outlet is inside the center console. It can be used to plug in electrical equipment that uses a maximum limit of 150
watts.


An indicator light on the outlet turns on to show it is in use. The light comes on when the ignition is in ON/RUN, equipment requiring less than 150 watts is plugged into the outlet, and no system fault is detected.


The indicator light does not come on when the ignition is in LOCK/OFF or if the equipment is not fully seated into the outlet. If equipment is connected using more than 150 watts or a system fault is detected, a protection circuit shuts off the power supply and the indicator light turns off. To reset the circuit, unplug the item and plug it back in or turn the Retained Accessory Power (RAP) off and then back on. See Retained Accessory Power (RAP) 0 206. The power restarts when equipment using 150 watts or less is plugged into the outlet and a system fault is not detected. The power outlet is not designed for the following and may not work properly, if this equipment is plugged in: . Equipment with high initial peak


wattage such as: compressor-driven refrigerators and electric power tools.


. Other equipment requiring an extremely stable power supply such as:


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


113


microcomputer-controlled electric blankets, touch sensor lamps, etc.


. Medical equipment.


Wireless Charging The vehicle may have wireless charging in the storage behind the climate control system. See Instrument Panel Storage 0 103. The system wirelessly charges one PMA or Qi compatible mobile device. To check for phone or other device compatibility, see www.gmtotalconnect.com. { Warning


Wireless charging can affect the operation of an implanted pacemaker or other medical devices. If you have one, it is recommended to consult with your doctor before using the wireless charging system.


The vehicle must be in ON/RUN/ START, ACC/ACCESSORY, or Retained Accessory Power


(RAP). The wireless charging feature may not correctly indicate charging when the vehicle is in RAP. See Retained Accessory Power (RAP) 0 206. The operating temperature is −20 °C (−4 °F) to 60 °C (140 °F) for the charging system and 0 °C (32 °F) to 35 °C (95 °F) for the phone. { Warning


Remove all metal objects from the charging pad before charging your mobile device. Metal objects, such as coins, keys, rings, or paper clips, between the phone and charging pad will become very hot. On the rare occasion that the charging system does not detect a metal object, and the object gets wedged between the phone and charger, remove the phone and allow the metallic object to cool before removing it from the charging pad, to prevent burns.


To charge a mobile device: 1. Open the climate control


system panel.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


114


Instruments and Controls


Warning Lights, Gauges, and Indicators Warning lights and gauges can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement. Paying attention to the warning lights and gauges could prevent injury.


Some warning lights come on briefly when the engine is started to indicate they are working. When one of the warning lights comes on and stays on while driving, or when one of the gauges shows there may be a problem, check the section that explains what to do. Waiting to do repairs can be costly and even dangerous.


2. Remove all objects from the


charging pad. The system may not charge if there are any objects on the charging pad. 3. Place the mobile device face up on the @ symbol on the charging pad.


4. The ~ will display on the V


on the infotainment screen. This indicates that the mobile device is properly positioned and charging. If a phone is placed on the charging pad and ~ does not display, remove the phone from the pad, and wait three seconds before placing/aligning the phone on the pad again.


Keep the storage door closed while driving.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instrument Cluster


Instruments and Controls


115


English Base Cluster with Auto Stop Shown, Metric Similar


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


116


Instruments and Controls


English Uplevel Balanced Cluster Shown, Metric Similar


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


117


Reconfigurable Instrument Cluster The uplevel cluster display layout can be changed.


Balanced Configuration The Balanced configuration has three interactive display zones: one in the center of each of the gauges.


Use the five-way control on the right side of the steering wheel to move between the different display zones and scroll through the different displays. To change the cluster configuration: 1. Find the Options page in one of the interactive display zones on the cluster.


2. Press SEL to enter the


Options menu.


3. Scroll down to highlight Display


Layout. Then press SEL to select it.


4. Each layout in the menu is


represented by a small preview image of the display layout. Scroll up or down and highlight the selection. Press SEL to select the desired cluster configuration.


5. Exit the Display Layout menu


by pressing S.


Enhanced Configuration


The Enhanced configuration has three interactive display zones.


Performance Configuration (CTS-V


Series and V Sport Only)


The Performance configuration has two interactive display zones.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


118


Instruments and Controls


Cluster Application Displays The cluster can display information regarding Navigation, Audio, and Phone. On the base cluster, a speedometer can also be displayed in the center zone.


Navigation If there is no active route, a compass will be displayed. If there is an active route, press SEL to end route guidance or turn the voice prompts on or off.


Audio While the Audio application page is displayed, press SEL to enter the Audio menu. In the Audio menu, search for music, select from favorites, or change the audio source


Phone While the Phone application page is displayed, press SEL to enter the Phone menu. In the Phone menu, if there is no active phone call, view recent calls, select from favorites,


or scroll through contacts. If there is an active call, mute the phone or switch to handset operation. Cluster Options Menu To enter the cluster Options menu: 1. Use the five-way control on the right side of the steering wheel to find the Options page in one of the interactive display zones on the cluster.


2. Press SEL on the center of the


five-way control to enter the Options menu.


Units : Press SEL while Units is highlighted to enter the Unit menu. Choose English or metric units by pressing SEL while the desired item is highlighted. A checkmark will be displayed next to the selected item. Info Pages : Press SEL while Info Pages is highlighted to select the items to be displayed in the DIC info displays. See Driver Information Center (DIC) 0 134. Fav Button Options : Press SEL while Fav Button Options is highlighted to select between FAV


Primary and SEEK Primary. This selection allows for configuration of the C and B steering wheel controls. When FAV Primary is selected, pressing C and B will go to the next or previous favorite and pressing and holding C and B will seek. When SEEK Primary is selected, pressing C and B will seek and pressing and holding C and B will go to the next or previous favorite. Display Layout : Press SEL while Display Layout is highlighted to change the configuration of the uplevel cluster. See “Reconfigurable Instrument Cluster” earlier in this section. Open Source Software : Press SEL while Open Source Software is highlighted to display open source software information.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


119


Fuel Gauge


Base Level


Speedometer The speedometer shows the vehicle's speed in either kilometers per hour (km/h) or miles per hour (mph).


Odometer The odometer shows how far the vehicle has been driven, in either kilometers or miles.


Trip Odometer The trip odometer shows how far the vehicle has been driven since the trip odometer was last reset. The trip odometer is accessed and reset through the Driver Information Center (DIC). See Driver Information Center (DIC) 0 134.


Tachometer The tachometer displays the engine speed in revolutions per minute (rpm). On the Base cluster, if the vehicle has the Stop/Start system, when the ignition is in ON/RUN, the


tachometer indicates the vehicle status. When pointing to AUTO STOP, the engine is off but the vehicle is on and can move. The engine could auto start at any time. When the indicator points to OFF, the vehicle is off. When the engine is on, the tachometer will indicate the engine’s revolutions per minute (rpm). The tachometer may vary by several hundred rpm’s, during auto stop mode, when the engine is shutting off and restarting. A slight bump may be felt when the transmission is determining the most fuel efficient operating range.


Caution


If the engine is operated with the rpm’s in the warning area at the high end of the tachometer, the vehicle could be damaged, and the damage would not be covered by the vehicle warranty. Do not operate the engine with the rpm’s in the warning area.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


120


Instruments and Controls


. At the service station, the fuel


pump shuts off before the gauge reads full. It takes a little more or less fuel to fill up than the gauge indicated. For example, the gauge may have indicated the tank was half full, but it actually took a little more or less than half the tank's capacity to fill the tank.


. The gauge moves a little while


turning a corner or speeding up. . The gauge takes a few seconds


to stabilize after the ignition is turned on, and goes back to empty when the ignition is turned off.


Boost Gauge (Performance Configuration Only)


Metric


Uplevel Balanced Configuration


Shown


When the ignition is on, the fuel gauge indicates about how much fuel is left in the tank. There is an arrow near the fuel gauge pointing to the side of the vehicle the fuel door is on. When the indicator nears empty, the low fuel light comes on. There still is a little fuel left, but the vehicle should be refueled soon. Here are four things that some owners ask about. None of these show a problem with the fuel gauge:


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


121


Engine Oil Temperature Gauge (Performance Configuration Only)


English


This gauge indicates boost under heavier throttle. It displays the air pressure level in the intake manifold before it enters the engine's combustion chamber. The gauge is automatically centered at zero every time the engine is started. Actual boost is displayed from this zero point. Changes in ambient pressure, such as driving in mountains and changing weather, will slightly change the zero reading.


Metric


English


This gauge shows the engine oil temperature. If the gauge pointer moves into the high end, it means that the engine oil has overheated. If the vehicle has been operated under normal driving conditions, pull off the road, stop the vehicle, and turn off the engine as soon as possible. See Engine Oil 0 271.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


122


Instruments and Controls


Engine Coolant Temperature Gauge


English Base Level


Metric Base Level


English Uplevel Balanced


Configuration Shown


This gauge measures the temperature of the vehicle's engine. While driving under normal operating conditions, if the needle moves into the red area, the engine is too hot. Pull off the road, stop the vehicle, and turn off the engine as soon as possible.


Metric Uplevel Balanced


Configuration Shown


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Safety Belt Reminders


Driver Safety Belt Reminder Light There is a driver safety belt reminder light on the instrument cluster.


Passenger Safety Belt Reminder Light There is a passenger safety belt reminder light near the passenger airbag status indicator. See Passenger Sensing System 0 78.


When the vehicle is started, this light flashes and a chime may come on to remind the driver to fasten their safety belt. Then the light stays on solid until the belt is buckled. This cycle may continue several times if the driver remains or becomes unbuckled while the vehicle is moving. If the driver safety belt is buckled, neither the light nor the chime comes on.


When the vehicle is started, this light flashes and a chime may come on to remind passengers to fasten their safety belt. Then the light stays on solid until the belt is buckled. This cycle continues several times if the passenger remains or becomes unbuckled while the vehicle is moving. If the passenger safety belt is buckled, neither the chime nor the light comes on. The front passenger safety belt reminder light and chime may turn on if an object is put on the seat such as a briefcase, handbag,


Instruments and Controls


123


grocery bag, laptop, or other electronic device. To turn off the reminder light and/or chime, remove the object from the seat or buckle the safety belt.


Airbag Readiness Light This light shows if there is an electrical problem with the airbag system. The system check includes the airbag sensor(s), passenger sensing system, the pretensioners, the airbag modules, the wiring, and the crash sensing and diagnostic module. For more information on the airbag system, see Airbag System 0 72.


The airbag readiness light comes on for several seconds when the vehicle is started. If the light does not come on then, have it fixed immediately.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


124


Instruments and Controls


{ Warning


If the airbag readiness light stays on after the vehicle is started or comes on while driving, it means the airbag system might not be working properly. The airbags in the vehicle might not inflate in a crash, or they could even inflate without a crash. To help avoid injury, have the vehicle serviced right away.


If there is a problem with the airbag system, a Driver Information Center (DIC) message may also come on. See Airbag System Messages 0 149.


Passenger Airbag Status Indicator The vehicle has a passenger sensing system. See Passenger Sensing System 0 78 for important safety information. The passenger airbag status indicator is in the overhead console.


outboard passenger frontal airbag and knee airbag are allowed to inflate. If the word OFF or the off symbol is lit on the airbag status indicator, it means that the passenger sensing system has turned off the front outboard passenger frontal airbag and knee airbag. If, after several seconds, both status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger sensing system. See your dealer for service.


{ Warning


If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system. To help avoid injury to yourself or others, have the vehicle serviced right away. See Airbag Readiness Light 0 123 for more information, including important safety information.


United States


Canada and Mexico


When the vehicle is started, the passenger airbag status indicator will light ON and OFF, or the symbol for on and off for several seconds as a system check. Then, after several more seconds, the status indicator will light either ON or OFF, or the on or off symbol to let you know the status of the front outboard passenger frontal airbag and knee airbag. If the word ON or the on symbol is lit on the passenger airbag status indicator, it means that the front


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


125


Charging System Light


On some vehicles the charging system light comes on briefly when the ignition is turned on, but the engine is not running, as a check to show the light is working. It should go out when the engine is started. For vehicles with a reconfigurable cluster, this light may not come on when the ignition is turned on. If the light stays on, or comes on while driving, there may be a problem with the electrical charging system. Have it checked by your dealer. Driving while this light is on could drain the battery. When this light comes on, or is flashing, the Driver Information Center (DIC) also displays a message. See Battery Voltage and Charging Messages 0 140.


If a short distance must be driven with the light on, be sure to turn off all accessories, such as the radio and air conditioner.


Malfunction Indicator Lamp (Check Engine Light) This light is part of the vehicle’s emission control on-board diagnostic system. If this light is on while the engine is running, a malfunction has been detected and the vehicle may require service. The light should come on to show that it is working when the ignition is in Service Only Mode. See Ignition Positions 0 202.


Malfunctions are often indicated by the system before any problem is noticeable. Being aware of the light and seeking service promptly when it comes on may prevent damage.


Caution


If the vehicle is driven continually with this light on, the emission control system may not work as well, the fuel economy may be lower, and the vehicle may not run smoothly. This could lead to costly repairs that might not be covered by the vehicle warranty.


Caution


Modifications to the engine, transmission, exhaust, intake, or fuel system, or the use of replacement tires that do not meet the original tire specifications, can cause this light to come on. This could lead to


(Continued)


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


126


Instruments and Controls


Caution (Continued)


costly repairs not covered by the vehicle warranty. This could also affect the vehicle’s ability to pass an Emissions Inspection/ Maintenance test. See Accessories and Modifications 0 261.


If the light is flashing : A malfunction has been detected that could damage the emission control system and increase vehicle emissions. Diagnosis and service may be required. To help prevent damage, reduce vehicle speed and avoid hard accelerations and uphill grades. If towing a trailer, reduce the amount of cargo being hauled as soon as possible. If the light continues to flash, find a safe place to park. Turn the vehicle off and wait at least 10 seconds before restarting the engine. If the light is still flashing, follow the


previous guidelines and see your dealer for service as soon as possible. If the light is on steady : A malfunction has been detected. Diagnosis and service may be required. Check the following:


If fuel has been added to the vehicle using the capless funnel adapter, make sure that it has been removed. See “Filling the Tank with a Portable Gas Can” under Filling the Tank 0 252. The diagnostic system can detect if the adapter has been left installed in the vehicle, allowing fuel to evaporate into the atmosphere. A few driving trips with the adapter removed may turn off the light.


. Poor fuel quality can cause


inefficient engine operation and poor driveability, which may go away once the engine is warmed up. If this occurs, change the fuel brand. It may require at


least one full tank of the proper fuel to turn the light off. See Fuel 0 250.


If the light remains on, see your dealer. Emissions Inspection and Maintenance Programs If the vehicle requires an Emissions Inspection/Maintenance test, the test equipment will likely connect to the vehicle's Data Link Connector (DLC).


The DLC is under the instrument panel to the left of the steering wheel. Connecting devices that are not used to perform an Emissions Inspection/Maintenance test or to service the vehicle may affect vehicle operation See Add-On Electrical Equipment 0 259. See your dealer if assistance is needed.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


127


The vehicle may not pass inspection if: . The light is on when the engine


is running.


. The light does not come on


when the ignition is in Service Only Mode.


. Critical emission control systems


have not been completely diagnosed. If this happens, the vehicle would not be ready for inspection and might require several days of routine driving before the system is ready for inspection. This can happen if the 12-volt battery has recently been replaced or run down, or if the vehicle has been recently serviced.


See your dealer if the vehicle will not pass or cannot be made ready for the test.


Brake System Warning Light The vehicle brake system consists of two hydraulic circuits. If one circuit is not working, the remaining


circuit can still work to stop the vehicle. For normal braking performance, both circuits need to be working. If the warning light comes on, there is a brake problem. Have the brake system inspected right away.


Metric


English


This light comes on briefly when the vehicle is turned on. If it does not come on then, have it fixed so it will be ready to warn if there is a problem. If the light comes on and stays on, there is a brake problem. { Warning


The brake system might not be working properly if the brake system warning light is on.


(Continued)


Warning (Continued)


Driving with the brake system warning light on can lead to a crash. If the light is still on after the vehicle has been pulled off the road and carefully stopped, have the vehicle towed for service.


Parking Brake Light


Metric


English


This light comes on when the parking brake is applied. If the light continues flashing after the parking brake is released, or while driving, there is a problem with the Electric Parking Brake system or another system. A message may also display in the Driver Information Center (DIC). See Brake System Messages 0 140.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


128


Instruments and Controls


If the light does not come on, or remains flashing, see your dealer.


Service Electric Parking Brake Light


displays in the Driver Information Center (DIC), see Brake System Messages 0 140.


Antilock Brake System (ABS) Warning Light


On some vehicles the service electric parking brake light should come on briefly when the vehicle is in ON/RUN. If it does not come on, have it fixed so it will be ready to warn if there is a problem. For vehicles with the reconfigurable cluster, this light may not come on when the vehicle is in ON/RUN. If this light stays on, there is a problem with a system on the vehicle that is causing the parking brake system to work at a reduced level. The vehicle can still be driven, but should be taken to a dealer as soon as possible. See Electric Parking Brake 0 214. If a message


This light comes on briefly when the engine is started. If the light does not come on, have it fixed so it will be ready to warn if there is a problem. If the light comes on while driving, stop as soon as it is safely possible and turn off the vehicle. Then start the engine again to reset the system. If the ABS light stays on, or comes on again while driving, the vehicle needs service. A chime may also sound when the light comes on steady.


If the ABS light is the only light on, the vehicle has regular brakes, but the antilock brakes are not functioning. If both the ABS and the brake system warning light are on, the vehicle's antilock brakes are not functioning and there is a problem with the regular brakes. See your dealer for service. See Brake System Warning Light 0 127 and Brake System Messages 0 140.


Lane Keep Assist (LKA) Light


For some vehicles, this light comes on briefly while starting the vehicle. If it does not come on, have the vehicle serviced.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


For vehicles with the uplevel cluster, this light may not come on when starting the vehicle. This light is green if LKA is available to assist. LKA may assist by gently turning the steering wheel if the vehicle approaches a detected lane marking without using the turn signal in that direction. The LKA light will turn amber. This light is amber and flashes as a Lane Departure Warning (LDW) alert, to indicate that the lane marking has been crossed. See Lane Keep Assist (LKA) 0 248.


Vehicle Ahead Indicator


If equipped, this indicator will display green when a vehicle is detected ahead and amber when you are following a vehicle ahead much too closely. See Forward Collision Alert (FCA) System 0 242.


Traction Off Light


Instruments and Controls


129


The traction off light comes on when the Traction Control System (TCS) has been turned off by pressing and releasing the TCS/StabiliTrak button. This light and the StabiliTrak OFF light come on when StabiliTrak is turned off. If the TCS is off, wheel spin is not limited. Adjust driving accordingly. See Traction Control/Electronic Stability Control 0 216.


StabiliTrak® OFF Light


This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer. If the system is working normally, the indicator light then turns off. For vehicles with a reconfigurable cluster, this light is in the display area and it may not come on when the ignition is turned on.


This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


130


Instruments and Controls


This light comes on when the StabiliTrak system is turned off. If StabiliTrak is off, the Traction Control System (TCS) is also off. If the StabiliTrak and TCS are off, the system does not assist in controlling the vehicle. Turn on the TCS and the StabiliTrak systems and the warning light turns off. See Traction Control/Electronic Stability Control 0 216.


Traction Control System (TCS)/StabiliTrak® Light


If the light is on and not flashing, the TCS and potentially the StabiliTrak system have been disabled. A DIC message may display. Check the DIC messages to determine which feature(s) is no longer functioning and whether the vehicle requires service. If the light is on and flashing, the TCS and/or the StabiliTrak system is actively working. See Traction Control/Electronic Stability Control 0 216.


Engine Coolant Temperature Warning Light


This light comes on briefly when the engine is started. If the light does not come on, have the vehicle serviced by your dealer. If the system is working normally, the indicator light turns off.


On some vehicles this light comes on briefly while starting the vehicle. If it does not, have the vehicle serviced by the dealer. If the system


is working normally the indicator light goes off. For vehicles with the reconfigurable cluster, this light may not come on when starting the vehicle.


Caution


The engine coolant temperature warning light indicates that the vehicle has overheated. Driving with this light on can damage the engine and it may not be covered by the vehicle warranty. See Engine Overheating 0 281.


The engine coolant temperature warning light comes on when the engine has overheated. If this happens pull over and turn off the engine as soon as possible. See Engine Overheating 0 281.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Instruments and Controls


131


Tire Pressure Light


For vehicles with the Tire Pressure Monitor System (TPMS), this light comes on briefly when the engine is started. It provides information about tire pressures and the TPMS.


When the Light Is On Steady This indicates that one or more of the tires are significantly underinflated. A Driver Information Center (DIC) tire pressure message may also display. See Tire Messages 0 150. Stop as soon as possible, and inflate the tires to the pressure value shown on the Tire and Loading Information label. See Tire Pressure 0 308.


When the Light Flashes First and Then Is On Steady If the light flashes for about a minute and then stays on, there may be a problem with the TPMS. If the problem is not corrected, the light will come on at every ignition cycle. See Tire Pressure Monitor Operation 0 311.


Engine Oil Pressure Light


Caution


Lack of proper engine oil maintenance can damage the engine. Driving with the engine oil low can also damage the engine. The repairs would not be covered by the vehicle warranty. Check the oil level as soon as possible. Add oil if required, but if the oil level is within the operating range and the oil pressure is still low, have the vehicle serviced. Always follow the maintenance schedule for changing engine oil.


This light should come on briefly as the engine is started. If it does not come on, have the vehicle serviced by your dealer. If the light comes on and stays on, it means that oil is not flowing through the engine properly. The vehicle could be low on oil and might have some other system problem. See your dealer.


Low Fuel Warning Light


This light is near the fuel gauge and comes on briefly when the ignition is turned on as a check to show it is working. For vehicles with a


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


132


Instruments and Controls


On some vehicles the immobilizer light should come on briefly as the engine is started. If it does not come on, have the vehicle serviced by your dealer. If the system is working normally, the indicator light turns off. For vehicles with the reconfigurable cluster, this light may not come on when the engine is started. If the light stays on and the engine does not start, there could be a problem with the theft-deterrent system. See Immobilizer Operation 0 44.


High-Beam On Light


IntelliBeam® Light


This light comes on when the IntelliBeam system, if equipped, is enabled. See Exterior Lamp Controls 0 163.


Adaptive Forward Lighting (AFL) Light


reconfigurable cluster, this light is in the display area and may not come on when the ignition is turned on. It also comes on when the fuel tank is low on fuel. The light turns off when fuel is added. If it does not, have the vehicle serviced.


Auto Stop Mode


This light comes on when the engine is in an Auto Stop. See Starting the Engine 0 204.


Security Light


This light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer 0 165.


This light should come on briefly as the vehicle is started. If it does not come on, have the vehicle serviced by your dealer. For vehicles with a reconfigurable cluster, this light is in the display area and may not come on when the ignition is turned on.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


This light comes on solid when there is a problem with the AFL system. It flashes when the system is switching between lighting modes. See Adaptive Forward Lighting (AFL) 0 167.


Lamps On Reminder


The cruise control light is white when the cruise control is on and ready, and turns green when the cruise control is set and active. See Cruise Control 0 224. Adaptive Cruise Control Light


Instruments and Controls


133


Door Ajar Light


This light comes on when the exterior lamps are in use. See Exterior Lamp Controls 0 163.


Cruise Control Light


This light is white when the Adaptive Cruise Control (ACC, if equipped) is on and ready, and turns green when the ACC is set and active. See Adaptive Cruise Control 0 227.


For vehicles equipped with this light, it comes on when a door is open or not securely latched. Before driving, check that all doors are properly closed. See Door Ajar Messages 0 142 for more information.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


134


Instruments and Controls


Information Displays


Driver Information Center (DIC) The DIC displays are shown in the left and right interactive display zones on the instrument cluster. The displays show the status of many vehicle systems. The controls for the DIC are on the right steering wheel control.


y or z : Press to move up or down in a list.


S or T : Press to move between the interactive display zones in the cluster. Press S to go back to the previous menu. SEL (Select) : Press to open a menu or select a menu item. Press and hold to reset values on certain screens. DIC Information Display Options The information displays on the DIC can be turned on or off through the Options menu. 1. Press SEL while viewing the


Options page in the center display zone on the cluster.


2. Scroll to Info Pages and


press SEL.


3. Press y or z to move


through the list of possible information displays.


4. Press SEL while an item is


highlighted to select or deselect that item. When an item is selected, a checkmark will appear next to it.


DIC Information Displays The following is the list of all possible DIC information displays. Some of the information displays may not be available for your particular vehicle. Speed : Shows the vehicle speed in either kilometers per hour (km/h) or miles per hour (mph). Trip 1 and Trip 2 (Base Cluster) / Trip 1 or Trip 2 and Average Fuel Economy (Uplevel Cluster) : Shows the current distance traveled, in either kilometers (km) or miles (mi), since the trip odometer was last reset. The trip odometer can be reset by pressing and holding SEL while this display is active. The average fuel economy shows the approximate average liters per 100 kilometers (L/100 km) or miles per gallon (mpg). This number is calculated based on the number of L/100 km (mpg) recorded since the last time this menu item was reset. This number reflects only the approximate average fuel economy that the vehicle has right now, and


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


will change as driving conditions change. The Average Fuel Economy can be reset along with the trip odometer by pressing and holding SEL while this display is active. Fuel Range : Shows the approximate distance the vehicle can be driven without refueling. LOW will be displayed when the vehicle is low on fuel. The fuel range estimate is based on an average of the vehicle's fuel economy over recent driving history and the amount of fuel remaining in the fuel tank. Average Fuel Economy (Base Cluster) : Shows the approximate average liters per 100 kilometers (L/100 km) or miles per gallon (mpg). This number is calculated based on the number of L/100 km (mpg) recorded since the last time this menu item was reset. This number reflects only the approximate average fuel economy that the vehicle has right now, and will change as driving conditions change. The Average Fuel


Instruments and Controls


135


Economy can be reset by pressing and holding SEL while this display is active. Instantaneous Fuel Economy : Shows the current fuel economy in either liters per 100 kilometers (L/100 km) or miles per gallon (mpg). This number reflects only the approximate fuel economy that the vehicle has right now and changes frequently as driving conditions change. Average Speed : Shows the average speed of the vehicle in kilometers per hour (km/h) or miles per hour (mph). This average is calculated based on the various vehicle speeds recorded since the last reset of this value. The average speed can be reset by pressing and holding SEL while this display is active. Timer : This display can be used as a timer. To start the timer, press SEL while this display is active. The display will show the amount of time that has passed since the timer was last reset. To stop the timer, press SEL briefly while this display is


active and the timer is running. To reset the timer to zero, press and hold SEL while this display is active. Compass (Base Cluster) : Shows the direction the vehicle is driving. Turn Arrow : Shows the next maneuver when using route guidance. Estimated Time to Arrival : Shows the estimated time until arrival at your destination. Distance to Destination : Shows the distance to the destination when using route guidance. Speed Limit : Shows the current speed limit on vehicles with the navigation system. The information for this page comes from a roadway database. Speed Warning : Allows the driver to set a speed that they do not want to exceed. To set the Speed Warning, press SEL when Speed Warning is displayed. Press y or z to adjust the value. This feature can be turned off by pressing and holding SEL while viewing this


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


136


Instruments and Controls


page. If the selected speed limit is exceeded, a pop-up warning is displayed and a chime may sound. Best Fuel Economy : Displays average fuel economy, the best fuel economy over the selected distance, and a bar graph showing instantaneous fuel economy. Driver Assistance (Uplevel Cluster) : Shows information for Lane Keeping Assist (LKA), Lane Departure Warning (LDW), Adaptive Cruise Control (ACC), and Forward Collision Alert (FCA). Performance Timer (CTS-V Only) : Shows the last performance time recorded. Press and hold SEL while viewing the performance timer to reset and stop the timer. Press SEL to enter the performance timer menu. In the menu, set the start speed, set the end speed, and reset the timer. Cruise Set Speed : Shows the speed the cruise control or Adaptive Cruise Control (ACC, if equipped) is set to.


Battery Voltage : Shows the current battery voltage. Engine Boost : Shows the current amount of boost being added. Oil Life : Shows an estimate of the oil's remaining useful life. If REMAINING OIL LIFE 99% is displayed, that means 99% of the current oil life remains. When the remaining oil life is low, the CHANGE ENGINE OIL SOON message will appear on the display. See Engine Oil Messages 0 142. The oil should be changed as soon as possible. See Engine Oil 0 271. In addition to the engine oil life system monitoring the oil life, additional maintenance is recommended in the Maintenance Schedule. See Maintenance Schedule 0 347. The Oil Life display must be reset after each oil change. It will not reset itself. Do not to reset the Oil Life display accidentally at any time other than when the oil has just been changed. It cannot be reset accurately until the next oil change. To reset the engine oil life system,


press and hold SEL for several seconds while the Oil Life display is active. See Engine Oil Life System 0 273. Tire Pressure : Shows the approximate pressures of all four tires. Tire pressure is displayed in either kilopascal (kPa) or in pounds per square inch (psi). If the pressure is low, the value for that tire is shown in amber. See Tire Pressure Monitor System 0 310 and Tire Pressure Monitor Operation 0 311. Vehicle Odometer (Base Cluster) : Shows the odometer. Blank Page : The Blank Page display allows for no information to be displayed in the DIC display zone(s).


Head-Up Display (HUD)


{ Warning


If the HUD image is too bright or too high in your field of view, it may take you more time to see


(Continued)


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Warning (Continued)


things you need to see when it is dark outside. Be sure to keep the HUD image dim and placed low in your field of view.


If equipped with HUD, some information concerning the operation of the vehicle is projected onto the windshield. The image is projected through the HUD lens on top of the instrument panel. The information appears as an image focused out toward the front of the vehicle.


Caution


If you try to use the HUD image as a parking aid, you may misjudge the distance and damage your vehicle. Do not use the HUD image as a parking aid.


The HUD information can be displayed in various languages in some vehicles. The speedometer


Instruments and Controls


137


reading and other numerical values can be displayed in either English or metric units. The language selection is changed through the radio and the units of measurement is changed through the instrument cluster. See Vehicle Personalization 0 152 and “Cluster Settings Menu” under Instrument Cluster 0 115.


. Tachometer . Audio . Phone . Navigation . Collision Alert . Cruise Control . Lane Keep Assist . Low Fuel Some vehicle messages or alerts displayed in the HUD may be cleared by using the steering wheel controls. See Vehicle Messages 0 140.


HUD Display on the Vehicle


Windshield


The HUD may display some of the following vehicle information and vehicle messages or alerts: . Speed


The HUD control is to the left of the steering wheel. To adjust the HUD image:


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


138


Instruments and Controls


1. Adjust the driver seat. 2. Start the engine. Use the following settings to adjust the HUD. $ (Image Adjustment) : Press down or lift up to center the HUD image. The HUD image can only be adjusted up and down, not side to side. ! (Display View) : Press to select the display view. Each press will change the display view. D (Image Brightness) : Lift up and hold to brighten the display. Press down and hold to dim the display. Hold down to turn the display off. The HUD image will automatically dim and brighten to compensate for outside lighting. The HUD brightness control can also be adjusted as needed. The HUD image can temporarily light up depending on the angle and position of the sunlight on the HUD display. This is normal.


Polarized sunglasses could make the HUD image harder to see.


HUD Views There are four views in the HUD. Some vehicle information and vehicle messages or alerts may be displayed in any view.


only appears on vehicles that have these features, and when they are active.


Metric


Metric


English


Audio/Phone View : This displays the speed view along with audio/ phone information. The current radio station, media type, and incoming calls will be displayed. All HUD views may briefly display audio information when the driver uses the steering wheel controls to adjust the audio settings appearing in the instrument cluster.


English


Speed View : This display gives the speedometer reading (in English or metric units), speed limit, Adaptive Cruise Control speed, Lane Departure Warning, and Vehicle Ahead indicator. Some information


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


Incoming phone calls appearing in the instrument cluster, may also display in any HUD view.


Metric


Metric


English


Navigation View : This display includes the information in the speed view along with Turn-by-Turn Navigation information in some vehicles. When navigation routing is not active “No Route Active” is displayed. Navigation Turn-by-Turn Alerts shown in the instrument cluster may also be displayed in any HUD view.


English


Performance View : This displays the speedometer reading, rpm reading, transmission positions, and gear shift indicator. Care of the HUD Clean the inside of the windshield to remove any dirt or film that could reduce the sharpness or clarity of the HUD image. Clean the HUD lens with a soft cloth sprayed with glass cleaner. Wipe the lens gently, then dry it.


Instruments and Controls


139


HUD Troubleshooting Check that: . Nothing is covering the


HUD lens.


. HUD brightness setting is not


too dim or too bright.


. HUD is adjusted to the proper


height.


. Polarized sunglasses are


not worn.


. Windshield and HUD lens are


clean.


If the HUD image is not correct, contact your dealer. The windshield is part of the HUD system. If the windshield needs replacing, see Windshield Replacement 0 289.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


140


Instruments and Controls


Vehicle Messages Messages displayed on the DIC indicate the status of the vehicle or some action that may be needed to correct a condition. Multiple messages may display one after the other. The messages that do not require immediate action can be acknowledged and cleared by pressing SEL. The messages that require immediate action cannot be cleared until that action is performed. All messages should be taken seriously and clearing the messages does not correct the problem. The following are some of the vehicle messages that may be displayed depending on the vehicle content.


Battery Voltage and Charging Messages


BATTERY SAVER ACTIVE This message displays when the vehicle has detected that the battery voltage is dropping beyond a reasonable point. The battery saver system starts reducing features of the vehicle that may be noticed. At the point that features are disabled, this message displays. Turn off unnecessary accessories to allow the battery to recharge. LOW BATTERY This message is displayed when the battery voltage is low. See Battery - North America 0 285. SERVICE BATTERY CHARGING SYSTEM This message is displayed when there is a fault in the battery charging system. Take the vehicle to your dealer for service.


TRANSPORT MODE ON This message is displayed when the vehicle is in transport mode. Some features can be disabled while in this mode, including Remote Keyless Entry (RKE), remote start, and the vehicle alarm system. Take the vehicle to your dealer for service to turn transport mode off.


Brake System Messages


BRAKE FLUID LOW This message displays when the brake fluid level is low. See Brake Fluid 0 284. RELEASE PARKING BRAKE This message displays if the Electric Parking Brake is on while the vehicle is in motion. Release it before attempting to drive. See Electric Parking Brake 0 214. SERVICE BRAKE ASSIST This message displays when there is a problem with the brake boost system. When this message displays, the brake pedal may be


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


harder to push and the stopping distance may be longer. See your dealer for service. SERVICE PARKING BRAKE This message displays when there is a problem with the parking brake. See your dealer for service. STEP ON BRAKE TO RELEASE PARK BRAKE This message displays when attempting to release the Electric Parking Brake without the brake pedal applied. See Electric Parking Brake 0 214.


Compass Messages The compass display will be blank if the vehicle temporarily loses communication with the Global Positioning System (GPS).


Instruments and Controls


141


Cruise Control Messages


ADAPTIVE CRUISE SET TO XXX This message displays when the Adaptive Cruise Control (ACC) speed is set. See Adaptive Cruise Control 0 227. ADAPTIVE CRUISE TEMPORARILY UNAVAILABLE This message displays when attempting to activate Adaptive Cruise Control (ACC) when it is temporarily unavailable. The ACC system does not need service. This can occur under the following conditions: . The radar is not clean. Keep the radar sensors free of mud, dirt, snow, ice, and slush. Clean the entire front and/or rear of the vehicle. For cleaning instructions, see Exterior Care 0 336.


. Heavy rain or snow is interfering with the radar object detection or camera performance.


CRUISE SET TO XXX This message displays when the cruise control speed is set. See Cruise Control 0 224. NO CRUISE BRAKING GAS PEDAL APPLIED This message displays when Adaptive Cruise Control (ACC) is active and the driver is pressing the gas pedal. When this occurs, ACC will not brake. See Adaptive Cruise Control 0 227. SERVICE ADAPTIVE CRUISE CONTROL This message displays when the Adaptive Cruise Control (ACC) needs service. Take the vehicle to your dealer. SHIFT TO PARK BEFORE EXITING This message may display if Adaptive Cruise Control (ACC) is engaged holding the vehicle at a stop, and the driver attempts to exit the vehicle. Put the vehicle in P (Park) before exiting.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


142


Instruments and Controls


Door Ajar Messages


DOOR OPEN A door open symbol will be displayed on the DIC showing which door is open. If the vehicle has been shifted out of P (Park), a DOOR OPEN message will also be displayed. The DOOR OPEN message may also be displayed if the vehicle starts to move. Close the door completely. HOOD OPEN This message will display along with a hood open symbol when the hood is open. Close the hood completely. TRUNK OPEN This message will display along with a symbol when the trunk is open. Close the trunk completely.


Engine Cooling System Messages


A/C OFF ENGINE COOLANT HOT This message displays when the engine coolant becomes hotter than the normal operating temperature. To avoid added strain on a hot engine, the air conditioning compressor automatically turns off. When the coolant temperature returns to normal, the air conditioning compressor turns back on. The vehicle can continue to be driven. If this message continues to appear, have the system repaired by your dealer as soon as possible to avoid damage to the engine. ENGINE OVERHEATED — IDLE ENGINE This message displays and a chime sounds when the engine coolant temperature is too hot. The engine coolant temperature warning light will also be on. Stop and allow the vehicle to idle until it cools down.


ENGINE OVERHEATED — TURN VEHICLE OFF This message displays and a continuous chime sounds if the engine cooling system reaches unsafe temperatures for operation. The engine coolant temperature warning light will flash. Stop and turn off the vehicle as soon as it is safe to do so to avoid severe damage. This message clears when the engine has cooled to a safe operating temperature.


Engine Oil Messages


CHANGE ENGINE OIL SOON This message displays when the engine oil needs to be changed. When you change the engine oil, be sure to reset the oil life system. See Engine Oil Life System 0 273, Driver Information Center (DIC) 0 134, Engine Oil 0 271, and Maintenance Schedule 0 347.


Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9159276) - 2016 - crc - 5/12/15


ENGINE OIL HOT, IDLE ENGINE This message displays when the engine oil temperature is too hot. Stop and allow the vehicle to idle until it cools down. ENGINE OIL LOW — ADD OIL On some vehicles, this message displays when the engine oil level may be too low. Check the oil level before filling to the recommended level. If the oil is not low and this message remains on, take the vehicle to your dealer for service. See Engine Oil 0 271.

Loading...
x
