Integrated universal remote control*
115n
4. Simultaneously press the transmit
button on the original hand-held transmitter and the desired memory button 1 of the integrated universal remote control. The LED 2 flashes slowly at first. As soon as the LED 2 flashes rapidly, release both buttons. If the LED 2 does not flash rapidly after approx. 15 seconds, alter the distance.
5. To program other original hand-held
transmitters, repeat steps 3 and 4.
The corresponding memory button 1 is now programmed with the signal of the original hand-held transmitter. You can operate the system when the engine is running or when the ignition is switched on.
If the system cannot be operated after repeated programming,
check whether the original hand-held transmitter uses an alternating-code system. To do so, either read the instructions of the original hand-held transmitter or press and hold down the programmed memory button 1 of the integrated universal remote control.
If the LED 2 on the integrated universal remote control flashes quickly for a brief period and then remains lit up for approx. two seconds, this indicates that the original hand-held transmitter is equipped with an alternating code. In the case of an alternating-code system, program the memory buttons 1 as described in the section on alternating- code hand-held transmitters. If you have additional questions, please consult your BMW Sports Activity Vehi- cle center or call 1-800-355-3515. You can also visit our website www.bmwusa.com.<
Alternating-code hand-held transmitter To program the integrated universal remote control, consult the Owner's Manuals for the equipment to be set. You will find information there on the possibilities for synchronization. When programming alternating-code hand-held transmitters, please follow the supplementary instructions below:
Programming will be easier with the aid of a second person.<
Programming 1 Memory buttons 2 LED
Fixed-code hand-held transmitter 1. Switch on the ignition. 2. For initial use: press both outer
buttons 1 for approx. 20 seconds until the LED 2 flashes. The three memory buttons 1 are cleared.
3. Hold the original hand-held transmit- ter at a distance of approx. 2 to 8 in/ 5 to 20 cm from the memory but- tons 1.
The required distance between the hand-held transmitter and memory buttons 1 depends on the relevant system of the original hand- held transmitter used.<
116nIntegrated universal remote control*
Car phone*
1. Park your vehicle within the range of
the remote-controlled device
2. Program the integrated universal
remote control as described at the section on fixed-code hand-held transmitters
3. Locate the button on the receiver of the device you want to set up, e.g. on the upper section of the motor
4. Press the button on the receiver of the device you want to set up. After step 4, you have approx. 30 seconds for step 5
5. Press the programmed memory
button 1 on the integrated universal remote control three times.
The corresponding memory button 1 is now programmed with the signal of the original hand-held transmitter.
If you have any additional ques- tions, please contact your BMW
Sports Activity Vehicle center.<
Clearing memory buttons It is not possible to clear memory but- tons 1 individually. To clear all three memory buttons 1, proceed as follows: Press both outer buttons 1 of the inte- grated universal remote control for approx. 20 seconds, maintaining pres- sure until the LED 2 starts to flash.
Hands-free system On vehicles with telephone provisions*, the hands-free microphone is located in the headliner. For further information on the tele- phone, refer to the telephone Owner's Manual.
Interior rearview mirror with digital compass*
117n
1 Adjusting knob for compass zones 2 Display The display indicates the cardinal and/ or intercardinal direction in which you are currently driving.
Setting compass zones Depending on where you and your vehi- cle are located, it is necessary to set the appropriate compass zone, refer to world map with compass zones, page 118. To set the compass zone, press the adjusting button in the mirror frame for approx. 3-4 seconds with a sharp object, e.g. a ball-point pen or the like. The display indicates the number of the currently set compass zone.
How to correct this: 1. Make sure that there are no large metal objects or overhead power lines in the vicinity of your vehicle and that you have enough space to drive in a circle
2. Input the currently applicable com-
pass zone
3. Press the adjustment button to bring
up C or CAL. Then drive in a com- plete circle at a maximum speed of 4 mph/7 km/h. If the calibration was successful, the displays C or CAL are replaced with the points of the compass.
To change the zone setting, press the adjusting button repeatedly until the number of the compass zone that applies to your current position is dis- played. The compass will be operational again after approximately 10 seconds. For automatic dimming action, refer to Interior and exterior mirrors, automatic dimming feature on page 138.
Calibrating digital compass In the following situations, the digital compass must be calibrated: > C or CAL appears on the display > The wrong cardinal direction appears
on the display
> The cardinal direction displayed does
not change despite a change in the direction of travel
> Not all cardinal directions are dis-
played.
118nInterior rearview mirror with digital compass*
Glove compartment
Storage compartments
119n
Locking Use one of the master keys. A master key is also required for unlocking.
If you turn over only your spare key for valet parking, for example, refer to page 30, this prevents unautho- rized access to the glove compart- ment.<
Rechargeable flashlight Located on the left-hand side of the glove compartment. Features integral overload-protection, so it can be left in its holder continu- ously.
To avoid completely discharging and possibly damaging the lamp,
always ensure that it is switched off before inserting it into the socket.<
Opening Pull the handle. The lamp inside the glove compartment comes on.
Closing Fold the cover up.
To prevent injury in the event of an accident, close the glove com-
partment immediately after use.<
You will find two storage compartments in the armrest between the front seats. To open the top compartment: Press the button, refer to arrow 1. A built-in phone* is located in this com- partment. To move the armrest or open the lower compartment: Pull the handle, refer to arrow 2. This compartment contains a coin tray and a storage compartment* for cas- settes or CDs. You will find additional storage com- partments in all of the doors as well as on the backrests of the front seats.
120nStorage compartments
Cup holders
Clothes hooks
When suspending clothing from the hooks, ensure that it will not
obstruct the driver's vision. Do not hang heavy objects on the hooks. If you do so, they could cause endanger passen- gers during braking or evasive maneu- vers.<
Front Below the sliding cover, refer to illustra- tion.
Rear At the end of the center console under the lighter. Briefly press to open; push back inward to close.
Do not place glass containers in the cup holders, otherwise there is
a danger of injury in an accident.<
Ashtray, front
Ashtray, rear
121n
Socket The cigarette lighter socket can be used to plug in hand flashlights, car vacuum cleaners etc., with power rat- ings of up to approx. 200 W at 12 V. Be careful not to damage the socket with unsuitable plugs. Additional sockets are located in the cargo area, refer to page 128, and in the front passenger footwell.
Emptying Remove the insert tray.
Emptying Press the edge of the lid, refer to arrow: the ashtray moves up and can be removed.
Cigarette lighter, front Press the lighter 1 in. The lighter can be removed as soon as it pops out.
Hold or briefly press the hot ciga- rette lighter by the knob only.
Holding or touching it in other areas could result in burns. The cigarette lighter remains opera- tional when the ignition key has been removed. For this reason, do not leave unsupervised children in the vehicle.<
122nCigarette lighter, rear
Press the lighter in. The lighter can be removed as soon as it pops out.
Hold or briefly press the hot ciga- rette lighter by the knob only.
Holding or touching it in other areas could result in burns. The cigarette lighter remains opera- tional when the ignition key has been removed. For this reason, do not leave unsupervised children in the vehicle.<
Ski bag*
The ski bag allows the safe and clean transport of up to four pairs of standard skis or up to two snowboards. With the length of the ski bag and the additional space in the cargo area, you can store skis up to 6.8 ft/2.1 m length. Because stowing skis of this maximum length causes the ski bag to narrow, it can only accommodate two pairs of skis with a length of 6.8 ft/2.1 m.
Loading 1. Fold down the center armrest. Loosen the trim from the upper Velcro® fastener and place it onto the armrest
123n
2. Press button 1 downward and swing
the cover forward
3. Press button 2: the cover in the
cargo area is unlocked. With pull-out cargo floor, refer to page 128: pull out floor, release cover and push back floor again; the floor then conceals the cover
4. Place ski bag between the front
seats and load. The zip fastener facil- itates access to the stowed items.
Make sure that only clean skis are loaded into the ski bag. Wrap sharp edges so that no damage occurs.
124nSki bag*
Cargo area
If the cover in the cargo area is concealed by the pull-out cargo floor, do not fold the larger rear back- rest down. If you do so, it will damage the cover.<
Securing load After loading, secure the ski bag and its contents. To do so, tighten the retaining belt at the buckle.
Secure the ski bag in this way. If you fail to do so, it could endanger
occupants during braking or evasive maneuvers.<
When stowing the ski bag, proceed in the reverse order from loading.
Folding rear backrests down Reach into the recess and pull forward, refer to arrow.
When you fold back the backrest, be sure that the catch engages
securely. The red warning indicator dis- appears in the recess when the catch is engaged. The center safety belt can only be pulled out when the larger backrest is locked.<
Cargo area
125n
Roll-up cover Pull out the roll-up cover and hook it into the brackets at the rear. You can carry light objects such as items of clothing on the roll-up cover.
Do not place heavy or hard objects on the roll-up cover. If you
do so, they could pose a danger to vehicle occupants during braking or evasive maneuvers. Do not allow the roll-up cover to snap back, otherwise it could be damaged.<
Removing roll-up cover 1. Unlock the case with the button,
refer to arrow 1, lift it out of the bracket on the side and hold it in place on the opposite side with the other hand
2. Then push the case toward the side window, refer to arrow 2. This pulls it out of the second bracket and it can be removed.
Installation Lay the case in the two side brackets and then press down until it engages.
Partition net* 1. Remove the bag with the partition
net from the retainer by releasing the hooks from the lashing eyes on both sides
126nCargo area
2. Remove the partition net from the
3. Slide back the covers on the retain-
bag, unroll it half way and hook it into the retaining strap on both sides, refer to arrow
ers for the partition net on both sides of the roof, refer to arrow
4. Insert the curved ends of the partition
6. Pull the partition net down by the loop on both sides, refer to arrow, and hook the hook into the eye on the backrest
Note how the partition net is stored in the bag and secured in the vehicle so that you can return everything to its proper place again after use. If your vehicle has a pull-out cargo floor, follow the instructions on page 128.<
net rod into the retainers on both sides
5. Now you can slide the covers toward
the front again, refer to arrow
The case with the roll-up cover is not shown in the illustration. With the case removed, it is easier to hook the hooks of the partition net onto the backrest.<
Cargo area
127n
7. When the rear backrests are folded down, you can unhook the partition net from the retaining straps, com- pletely unroll it, insert it in the front retainers on the roof and attach the three hooks into the eyes on the backrests. The illustration shows securing at the bottom right as an example.
Side covers Pull the handle to open the side covers.
Floor cover To access the spare wheel. To open: press the recess in the han- dle, refer to arrow, and raise the cover with the handle.
128nCargo area
Folding floor cover up Disengage the loop end on the under- side of the floor cover and hook it in with the catch on the upper frame of the liftgate cutout. Before swinging down the floor cover, reengage the loop end in the retainer on the underside of the floor cover.
Sockets When you fold the cover caps up, you have access to additional sockets. You can use the sockets for flashlights, car vacuum cleaners or other automo- tive appliances with up to approx. 200 watts at 12 volts. Be careful not to damage the socket with unsuitable plugs. Also refer to page 121.
Pull-out cargo floor* To release, pull the handle recess upward. Then pull the floor out.
Do not drive when the cargo floor is pulled out.
Do not release the cargo floor on steep grades. If you do, it could extend auto- matically and cause personal injuries. A load which is not properly secured could slide if the floor extends automat- ically and then drop to the ground as a result of the rapid braking of the cargo floor at the limit stop.<
Cargo area
When it is extended, you can load the cargo floor: > With up to 990 lbs./450 kg, distrib-
uted evenly across the entire surface
> With up to 330 lbs./150 kg on the
rear edge.
Do not overload the cargo floor when it is extended. If you do so, it
could cause damage. When sliding the cargo floor back in, do not reach under the floor. Otherwise there is a risk of injury.<
Raising cargo floor For access to the spare wheel or other stored items: Swing the cargo floor up and secure it with the rod, refer to illustration.
If your vehicle has a partition net: Take the bag with the partition net
out of the retainer, refer to page 125, before you raise the cargo floor. Other- wise, the bag could slide downward.<
129n
130nCargo loading
Avoid overloading the vehicle so that the permissible loading capacity of the tires is not exceeded. Overloading can lead to overheating and increases the rate at which damage develops inside the tires. The ultimate result can assume the form of a sudden air loss.<
Determining loading limit 1. Locate the following statement on
your vehicle's placard*:
The combined weight of occu- pants and cargo should never
exceed XXX lbs. or YYY kg, other- wise the vehicle may be damaged and unstable driving conditions may result.<
2. Determine the combined weight of
the driver and passengers that will be riding in your vehicle
3. Subtract the combined weight of the driver and passengers from XXX lbs. or YYY kg
4. The resulting figure equals the avail-
able amount of cargo and luggage load capacity. For example, if the XXX amount equals 1,350 lbs. and there will be five 150 lbs. passengers in your vehi- cle, the amount of available cargo and luggage load capacity is 600 lbs.: 1,350 lbs. minus 750 lbs. = 600 lbs. 5. Determine the combined weight of
luggage and cargo being loaded into the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in step 4
6. If your vehicle will be towing a trailer,
load from your trailer will be trans- ferred to your vehicle. Consult the manual for transporting a trailer to determine how this may reduce the available cargo and luggage load capacity of your vehicle.
Cargo loading
131n
Load: The permitted load is the total of the weight of occupants and cargo/lug- gage. The greater the weight of occu- pants, the less cargo/luggage can be transported.
Stowing cargo > Use the partition net to protect the
occupants, refer to page 125
> Position heavy cargo as far forward as possible directly behind the back- rests and as low as possible
> Cover sharp edges and corners > Do not pile objects higher than the
top edge of the backrest
> Appropriately wrap objects that could
strike the rear window while driving
> If you are transporting very heavy
loads when the rear seat is not occu- pied, secure the outer safety belts in the opposite buckles.
Securing load > Secure smaller, light pieces with the retaining straps or a luggage net*, or use elastic straps, refer to page 37 > Heavy-duty cargo straps* for secur-
ing larger and heavier objects are available at your BMW Sports Activity Vehicle center. The lashing eyes pro- vided at the corners of the cargo area serve for mounting these heavy-duty cargo straps
> Read and comply with the informa- tion enclosed with the heavy-duty cargo straps.
132nCargo loading
Roof-mounted luggage rack*
Always position and secure the load as described above. If you do
not, it can endanger the passengers during braking or evasive maneuvers. Do not exceed the permissible gross vehicle weight and the permissible axle loads, refer to page 182. If you do, the operating safety of the vehicle is no longer ensured and you are in violation of the law. You should never transport heavy or hard objects unsecured in the passen- ger compartment, as they could fly around and pose a safety hazard to the vehicle's occupants even during abrupt braking or evasive maneuvers.<
A special rack system is available as an option for your BMW. Please comply with the precautions included with the installation instructions.
Mounting points Access to the mounting points: To fold up the cover, refer to arrow, please use the tool which is provided with the rack system.
Loading luggage rack Roof-mounted luggage racks raise the center of gravity of the vehicle when they are loaded and therefore signifi- cantly effect the vehicle's handling and steering response. It is thus crucial never to exceed the approved roof weight, the approved gross vehicle weight or the axle loads when loading the rack. You will find the specifications under Technical data on page 182. Make sure that the load is distributed evenly, and that it does not extend out- ward to beyond the limits of the loading surface. Always load the heaviest pieces on the bottom. Be sure that ade- quate clearance is maintained for rais- ing the panorama glass roof, and that objects do not project into the opening path of the liftgate.
Always ensure that roof-mounted loads are tightly secured, as loose
loads can shift or even fly off the roof, posing a serious hazard for following traffic.<
Drive smoothly. Avoid sudden accelera- tion and braking maneuvers. Take cor- ners gently.
133n
134n
135n
Overview
Controls and features
Operation, maintenance
Owner service procedures
Technical data
Index
Maintena
136n
Breaking-in
Moving parts should be allowed to break in. To ensure that your vehicle provides maximum economy through- out a long service life, we request that you comply with the following instruc- tions:
Engine and differential Obey your local and state maximum speed limits. Up to 1,200 miles/2,000 km: Drive at varying engine speeds and road speeds, but do not exceed 4,500 rpm and the following road speeds during this initial period: > 6-cylinder engine
100 mph/160 km/h
> 8-cylinder engine
106 mph/170 km/h
Avoid full-throttle operation and use of the transmission's kick-down mode during these initial miles. From 1,200 miles/2,000 km: The engine and vehicle speed can gradually be increased.
Tires Due to technical factors associated with their manufacture, tires do not achieve their full traction potential until after an initial break-in period. Therefore, drive reservedly during the first 200 miles/ 300 km. Obey your local and state maximum speed limits.
When the vehicle is operated on wet or slushy roads, a wedge of water may form between the tire and the road surface. This phenomenon is referred to as hydroplaning and can lead to partial or complete loss of trac- tion, vehicle control and braking effec- tiveness. Reduce your speed on wet roads.<
Brake system Brakes require an initial break-in period of approx. 300 miles/500 km to achieve optimal contact and wear patterns between brake pads and rotors. To break in the separate handbrake drums, apply the handbrake lightly when coasting to a standstill at a traffic signal, for instance, provided that traffic conditions allow you to do so.
To avoid corrosion, repeat this proce- dure from time to time.
The brake lamps do not light up when the handbrake is applied.
Vacuum for the brake system servo unit on your BMW is available only when the engine is running. When you move the vehicle with the engine switched off, when towing, for instance, substantially higher levels of pedal force will be required to brake the vehicle.<
Clutch The function of the clutch is only at its optimized level after a distance driven of approx. 300 miles/500 km. During this break-in period, engage the clutch gently.
Following component replacements Observe the break-in instructions again if previously addressed components must be replaced again during subse- quent driving.
General driving notes
Closing liftgate/tailgate
Operate the vehicle only when the tailgate and liftgate are completely
closed. Otherwise, exhaust fumes could enter into the passenger com- partment.<
However, if special circumstances should make it absolutely necessary to operate the vehicle with the liftgate/tail- gate open: 1. Close all windows and the panorama
glass roof
2. Increase the air supply for the air conditioner or automatic climate control to a high level, refer to page 105 or 109.
Hot exhaust system
Mobile communications devices in vehicle
BMW advises against using mobile communications devices such as mobile phones inside the vehi- cle unless they are directly connected to the external antenna. Otherwise, it is impossible to prevent a mutual interfer- ence of the vehicle electronics with the mobile phone device. Also, there is no guarantee that the radiation generated by the transmission will be conveyed out from the interior of the vehicle.<
When vehicle is parked Condensation forms in the air condi- tioner system during operation and then exits under the vehicle. Traces of water on the ground are therefore normal.
Extreme temperatures occur on the exhaust system on any vehi-
Brakes
cle. Do not remove the heat shields installed adjacent to it, and never apply undercoating to them. When driving, standing at idle and while parking, take care to avoid possible contact between a hot exhaust system and any highly flammable materials such as hay, leaves, grass etc. Otherwise, there is a danger of ignition and fire, with the risk of serious injuries and damage.<
Do not drive with your foot resting on the brake pedal. Even light but
consistent pedal pressure can lead to excessively high temperatures, brake wear and possibly even brake failure.<
137n
Road hazards
If road hazards, obstacles or curbs are unavoidable, only drive over them very slowly and carefully, other- wise the wheels and suspension parts, especially on vehicles fitted with low profile tires, can be damaged.<
For more information on wheels and tires, refer to page 146.
Before driving into a car wash Fold in the exterior mirrors, refer to page 53, otherwise they could be dam- aged due to the width of the vehicle.
Hydroplaning
When driving on wet or slushy roads, reduce road speed. If you
do not, a wedge of water can form between tires and road surface. This state can cause a partial or total loss of contact with the road surface, of braking control and of control over the vehicle.<
138nGeneral driving notes
Driving through water
Do not drive through water on the road if it is deeper than 20 in/
50 cm, and then only at walking speed at the most. Otherwise, the vehicle's engine, the electrical systems and the transmission may be damaged. When equipped with 2-axle self leveling sus- pension*, switch the vehicle into the Off-Road setting before driving through, refer to page 97.<
Using handbrake on slopes
Do not hold the vehicle in place on slopes by slipping or riding the
clutch; use the handbrake instead. Oth- erwise, severe clutch wear will result.<
Interior and exterior mirrors, automatic dimming feature* Two photocells serve to control the automatic dimming of the interior and exterior rearview mirrors. One photocell is in the mirror glass, refer to arrow, while the other is on the back of the mirror, offset somewhat from the first. For trouble-free operation, keep the photocells clean and do not cover the area between the interior rearview mir- ror and the windshield. Do not attach any kind of stickers to the windshield in front of the mirror either.
Driving your X5
On poor roads When you are driving on poor roads, there are a few points which you should strictly observe — for your own safety, for that of your passengers, and for the safety of the vehicle:
Driving on unpaved terrain can cause damage to the vehicle.<
> Always adapt the driving speed to the
road conditions. The rougher or steeper the road surface is, the lower the speed should be
> You can operate your vehicle on
uphill and downhill gradients with a maximum slope of 50%. If you want to drive on uphill or downhill gradi- ents of this kind, make sure before- hand that the engine oil and coolant levels are near the max mark, refer to pages 152 and 154. Use the HDC Hill Descent Control when driving down steep grades, refer to page 94. It is possible to start off on grades of up to 33%. The permissible body roll is also 50%
> While driving, watch carefully for
obstacles such as rocks or holes. Try to avoid these obstacles whenever possible
Driving your X5
> Please note that it is possible for the
undercarriage to touch the ground, for example on crests and bumpy roads. The ground clearance of the vehicle is: – without self-leveling suspension
X5 3.0i, 4.4i: 8 in/20 cm X5 3.0d: 7 in/17.5 cm
– with 2-axle self-leveling suspen-
sion* 6.5-9 in/16.5-22 cm, depending on the level selected.
> Only drive through water up to a max- imum depth of 20 in/50 cm and only at walking speed, making sure not to stop in the process. When equipped with 2-axle self leveling suspension*, switch the vehicle to the Off-Road setting before driving through, refer to page 97. After leaving the water, apply the footbrake lightly several times while driving at low speeds so as to dry the brakes by braking and to prevent decreased braking action due to wet- ness.
Back onto paved road Our recommendation that you observe the following points after driving on adverse road surfaces is not intended as a beauty treatment for your BMW. Instead, it is intended to maintain driv- ing safety: > Clean the worst of the dirt from the body and inspect the undercarriage for damage.
> Clean mud, snow, ice etc. from the
wheels and tires and check the wheels for damage.
> Check to determine whether rocks,
gravel or accumulations of dirt on the brake rotors and calipers could influ- ence braking performance. Remove all such foreign objects.
> In order to clean the brake rotors, apply the footbrake gently several times while driving at a low speed. Be sure that following traffic is not endangered by this.
> For cleaning the handbrake, apply the
lever slightly at approx. 25 mph/ 40 km/h and continue to drive for approx. 200 yards/200 meters, pro- vided that traffic conditions allow you to do so.
139n
140nSafe braking
Emergency stops You brake most effectively when you apply maximum pedal pressure in situa- tions requiring it: emergency stops. Since the vehicle maintains steering responsiveness, you can nevertheless avoid possible obstacles with a mini- mum of steering effort. Pulsation at the brake pedal combined with sounds from the hydraulic circuits indicates to the driver that ABS is in its active mode.
Brake fluid level If the brake fluid level is too low and brake pedal travel has become longer, there may be a malfunction in one of the two brake system's hydraulic cir- cuits.
Proceed to the nearest BMW Sports Activity Vehicle center.
In so doing, increased pressure on the brake pedal may be required, and slight pulling to the side and longer braking distances may result. Please remember to adapt your driving style accord- ingly.<
Disk brakes When the vehicle is driven only occa- sionally, during extended periods when the vehicle is not used at all, and in operating conditions where brake appli- cations are less frequent, there is an increased tendency for corrosion to form on rotors, while contaminants accumulate on the brake pads. This occurs because the minimal pressure that the pads must exert to clean the rotors during brake applications is not reached. If the brake rotors are corroded, they will tend to respond to braking with a pulsating effect that even extended application will fail to cure. When driving in wet conditions and in heavy rain, it is advisable to apply light pressure to the brake pedal from time to time. Monitor traffic conditions to ensure that this maneuver does not endanger other road users. The heat generated in this process helps dry the pads and rotors to ensure that the brak- ing force is then immediately available when required. Extended or steep mountain descents should be driven in the gear in which only minimal periodic brake application is required. This avoids excessive strain
on the brakes and possible impairment of braking action.
Do not drive with the clutch pedal depressed, at idle or with the
engine switched off, as otherwise there will be no engine braking effect or power assistance for braking and steer- ing. BMW recommends having brake inspections performed at a BMW Sports Activity Vehicle center only. If you do not, parts of the 4-wheel drive system could be damaged. No floor mats, carpets or other objects may lie in the area of pedal travel, as otherwise pedal operation may be impaired.<
Brake pads
For your own safety: use only brake pads that BMW has
approved for your particular vehicle model. BMW cannot evaluate non- approved brake pads to determine if they are suited for use, and therefore cannot ensure the operating safety of the vehicle if they are installed.<
After correcting the inflation pres- sure(s), always reinitialize the Flat
Tire Monitor, refer to page 99.<
Tire inflation pressure
Information for your safety The condition of the tires and the main- tenance of the specified tire pressure are crucial not only to the tire's service life, but also to driving comfort and most importantly, driving safety.
Checking pressure Only check tire inflation pressure when the tires are cold. This means after a maximum of 1.25 miles/2 km driving or when the vehicle has been parked for at least 2 hours. When tires are warm, the tire inflation pressure increases.
Check the tire inflation pressure regularly and correct it as needed, even on the spare wheel: at least twice a month and before starting long trips. If you fail to observe this precaution, you may be driving on tires with incorrect tire pressures, a condition that can not only compromise your vehicle's driving stability, but also lead to tire damage and the risk of an accident. Do not drive with deflated, i.e. flat, tires. A flat tire will seriously impairs your vehicle's handling and braking response. Attempts to drive on a flat tire can lead to loss of control over the vehicle.<
141n
Inflation pressures for factory- installed tires The tire inflation pressure specifications for your factory-installed tires at ambi- ent temperature are listed on the edge of the driver's door and can be con- sulted when the door is open.
Inflation pressures The tire pressure tables in the following pages give all of the pressure specifica- tions for the tire sizes indicated at ambi- ent temperature.
The inflation pressures apply to the tire sizes and tire brands respectively approved and recom- mended by BMW; a list of these is avail- able from your BMW Sports Activity Vehicle center.<
Tire inflation pressures for driving above 100 mph or 160 km/h:
In order to drive at maximum speeds in excess of 100 mph or 160 km/h, please observe, and, if nec- essary, adjust tire pressures for speeds exceeding 100 mph or 160 km/h from the relevant table on the following pages. Otherwise tire damage and acci- dents could occur.<
142nTire inflation pressure
For correct identification of the right tire inflation pressure for your tires, observe the following: > Tire sizes for your vehicle > Load conditions > Maximum allowable driving speed Tire inflation pressures for driving up to 100 mph or 160 km/h: For normal driving up to 100 mph or 160 km/h adjust pressures to the respective tire inflation pressures listed on the following page in the traveling speeds column for normal driving at speeds up to a maximum of 100 mph or 160 km/h to achieve optimum driving comfort.
The permissible top speed for these tire inflation pressures is
100 mph or 160 km/h. Do not exceed this speed, as otherwise tire damage and accidents may result.<
Tire inflation pressure
143n
BMW Tire size
Pressure specifications in psi/kPa
Traveling speeds up to a max. of
100 mph/160 km/h
Traveling speeds
including those exceeding
100 mph/160 km/h
All pressure specifications in the table are indicated in psi/ kilopascal with cold tires, cold = ambient temperature
X5 3.0i
235/65 R 17 104 H M+S 255/55 R 18 105 H M+S Front: 255/50 R 19 103 V Rear: 285/45 R 19 107 V Front: 275/40 R 20 102 W Rear: 315/35 R 20 106 W
32/220
33/230
32/220
32/220
32/220
39/270
32/220
–
32/220
–
–
32/220
–
32/220
32/220
–
32/220
–
–
32/220
–
32/220
32/220
–
32/220
–
–
39/270
–
39/270
You will find more information on permissible loads and weights on page 182.
