REAR PASSENGER’S FLOOR MAT
ANCHOR
Unlock
Lock
Make sure the rear floor mats are properly hooked to the floor mat anchors. Your vehicle is equipped with front passenger’s seat weight sensors. If the rear passenger’s floor mat is on the seat rail of the front passenger’s seat, the sensors will detect the decreased weight on the seat, and they may not work properly.
477
11/07/20 19:03:12 31SJA670_483
Wiper Blades
Check the condition of the wiper blades at least every 6 months. Replace them if you find signs of cracking in the rubber, areas that are getting hard, or if they leave streaks and unwiped areas when used.
478
HOLDING LOCATIONS
COVER
WIPER ARMS
BLADE
SCREWS
1.
Adjust the windshield wiper arms to the winter position by holding both wiper arms as shown in the illustration at the same time (see page ). Raise the wiper arms off the windshield.
139
2.
Push the end of the cover on the blade assembly until the other end is pivoted out, and remove the cover.
3.
Disconnect the blade assembly from the wiper arm by removing the two screws from the arm.
Do not open the hood when the wiper arms are raised, or you will damage the hood and the wiper arms.
11/07/20 19:03:19 31SJA670_484
BLADE
BLADE
4.
Remove the blade from its holder by grabbing the tabbed end of the blade. Pull up firmly until the tabs come out of the holder.
REINFORCEMENT
5.
Examine the new wiper blades. If they have no plastic or metal reinforcement along the back edge, remove the metal reinforcement strips from the old wiper blade, and install them in the slots along the edge of the new blade.
Wiper Blades
6.
Slide the new wiper blade into the holder until the tabs lock.
7.
8.
Reinstall the blade assembly to the wiper arm and tighten the two screws securely. Reinstall the cover by pushing it in.
Set the wiper arms back on the windshield. Adjust the windshield wipers to their previously parked position.
479
11/07/20 19:03:24 31SJA670_485
Exterior Care, Wheels
Exterior Care
Chemical solvents and strong cleaners can damage the paint, metal, and plastic on your vehicle.
Wheels Clean the wheels as you would the rest of the exterior. Wash them with the same solution, and rinse them thoroughly.
Aluminum alloy wheels have a protective clear-coat that keeps the aluminum from corroding and tarnishing. Cleaning the wheels with harsh chemicals (including some commercial wheel cleaners) or a stiff brush can damage the clear-coat. To clean the wheels, use a mild detergent and a soft brush or sponge.
480
11/07/20 19:03:34 31SJA670_486
To safely operate your vehicle, your tires must be the proper type and size, in good condition with adequate tread, and correctly inflated.
The following pages give more detailed information on how to take care of your tires and what to do when they need to be replaced.
Using tires that are excessively worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.
Follow all instructions in this owner’s manual regarding tire inflation and maintenance.
Inflation Guidelines Keeping the tires properly inflated provides the best combination of handling, tread life, and riding comfort.
Underinflated tires wear unevenly, adversely affect handling and fuel economy, and are more likely to fail from being overheated.
Overinflated tires can make your vehicle ride more harshly, are more prone to damage from road hazards, and wear unevenly.
The tire pressure monitoring system (TPMS) will warn you when a tire pressure is low. See page for information on the TPMS.
429
Tires
Even though your vehicle is equipped with TPMS, we recommend that you visually check your tires every day. If you think a tire might be low, check it immediately with a tire gauge.
Use a gauge to measure the air pressure in each tire at least once a month. Even tires that are in good condition may lose one to two psi (10
to 20 kPa, 0.1 to 0.2 kgf/cm ) per month. Remember to check the spare tire at the same time.CONTINUED
481
11/07/20 19:03:44 31SJA670_487
Tires
You should get your own tire pressure gauge and use it whenever you check your tire pressures. This will make it easier for you to tell if a pressure loss is due to a tire problem and not due to a variation between gauges.
While tubeless tires have some ability to self-seal if they are punctured, you should look closely for punctures if a tire starts losing pressure.
Check the pressure in the tires when they are cold. This means the vehicle has been parked for at least three hours, or driven less than 1 mile (1.6
km).Add or release air, if needed, to match the recommended cold tire pressures on this page.
If you check the pressure when the tires are hot [driven for several miles (kilometers)], you will see readings 4
to 6 psi (30 to 40 kPa, 0.3 to 0.4 kgf/cm ) higher than the cold reading. This is normal; do not release air to match the cold pressure. The tires will be underinflated.482
Recommended Tire Pressures The following charts show the recommended cold tire pressures for most normal driving conditions.
NormalDriving
Tire Size/Type P245/45R18 96V
Compact Spare T155/70D17
110M
Cold Tire Pressure
Front 32 psi (220 kPa , 2.2 kgf/cm ) Rear 30 psi (210 kPa , 2.1 kgf/cm ) 60 psi (420 kPa , 4.2 kgf/cm )
11/07/20 19:03:53 31SJA670_488
For convenience, the recommended tire sizes and cold tire pressures are on a label on the driver’s doorjamb.
For additional technical information about your tires, see page
528
Tires
High Speed Driving We strongly recommend that you do not drive faster than the posted speed limits and conditions allow. If you ever drive in a sanctioned competitive event at sustained high speeds (over 112 mph or 181 km/h), be sure to adjust the cold tire pressures as shown below. If you do not, excessive heat can build up and cause sudden tire failure.
The recommended tire pressures for high speed driving are not on the label on the driver’s doorjamb, contact your dealer for more information about the tire pressures.
When you return to normal speed driving, be sure to readjust the tire pressure for normal driving. You should wait until the tires are cold before adjusting the tire pressure.
HighSpeedDriving
Tire Size
Cold Tire Pressure
P245/45R18 96V
Front 36 psi (250 kPa , 2.5 kgf/cm ) Rear 35 psi (240 kPa , 2.4 kgf/cm )
483
11/07/20 19:04:01 31SJA670_489
Tires
Tire Inspection Every time you check inflation, you should also examine the tires for damage, foreign objects, and wear.
You should look for:
Bumps or bulges in the tread or side of the tire. Replace the tire if you find either of these conditions.
Cuts, splits, or cracks in the side of the tire. Replace the tire if you can see fabric or cord.
Excessive tread wear.
484
INDICATOR LOCATION MARKS
Tire Service Life The service life of your tires is dependent on many factors, including, but not limited to, driving habits, road conditions, vehicle loading, inflation pressure, maintenance history, speed, and environmental conditions (even when the tires are not in use).
TREAD WEAR INDICATOR
Your tires have wear indicators molded into the tread. When the tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the tread. This shows there is less than 1/16 inch (1.6 mm) of tread left on the tire.A tire this worn gives very little traction on wet roads. You should replace the tire if you can see three or more tread wear indicators.
11/07/20 19:04:07 31SJA670_490
In addition to your regular inspections and inflation pressure maintenance, it is recommended that you have annual inspections performed once the tires reach five years old. It is also recommended that all tires, including the spare, be removed from service after 10 years from the date of manufacture, regardless of their condition or state of wear.
The last four digits of the TIN (tire identification number) are found on the sidewall of the tire and indicate Tire the date of manufacture (See Labeling
on page
530
).
Tire Maintenance In addition to proper inflation, correct wheel alignment helps to decrease tire wear. If you find a tire is worn unevenly, have your dealer check the wheel alignment.
Have your dealer check the tires if you feel a consistent vibration while driving. A tire should always be rebalanced if it is removed from the wheel. When you have new tires installed, make sure they are balanced. This increases riding comfort and tire life. For best results, have the installer perform a dynamic balance.
Tires
Improper wheel weights can damage your vehicle’s aluminum wheels. Use only Acura wheel weights f or balancing.
485
11/07/20 19:04:14 31SJA670_491
Tires
Tire Rotation
Front
Front
When the tires are rotated, make sure the air pressures are checked.
(For Non-directional Tires and Wheels)
(For Directional Tires and Wheels)
To help increase tire life and distribute wear more evenly, rotate the tires according to the maintenance messages displayed on the multi-information display. Move the tires to the positions shown in the illustration each time they are rotated. If you purchase directional tires, rotate only front-to-back.
486
Replacing Tires and Wheels Replace your tires with radial tires of the same size, load range, speed rating, and maximum cold tire pressure rating (as shown on the tire’s sidewall).
Mixing radial and bias-ply tires on your vehicle can reduce braking ability, traction, and steering accuracy. Using tires of a different size or construction can cause the ABS and vehicle stability assist system (VSA) to work inconsistently.
The ABS and VSA system work by comparing the speed of each wheel. When replacing tires, use the same size originally supplied with the vehicle. Tire size and construction can affect wheel speed and may cause the system to activate.
11/07/20 19:04:23 31SJA670_492
It is best to replace all four tires at the same time. If that is not possible or necessary, replace the two front tires or two rear tires as a pair. Replacing just one tire can seriously affect your vehicle’s handling.
If you ever replace a wheel, make sure that the wheel’s specifications match those of the original wheels.
Also be sure you use only TPMS specific wheels. If you do not, the tire pressure monitoring system will not work on that tire.
Replacement wheels are available at your dealer.
Installing improper tires on your vehicle can affect handling and stability. This can cause a crash in which you can be seriously hurt or killed.
Always use the size and type of tires recommended in this owner’s manual.
Tires
Wheel and Tire Specifications Wheels:
18 x 8.0J AL (TPMS)
Tires:
P245/45R18 96V
528
for DOT tire quality
See page grading information, and page for tire size explanation. 530
487
11/07/20 19:04:30 31SJA670_493
Tires
Winter Driving Tires marked ‘‘M S’’ or ‘‘All Season’’ on the sidewall have an all- weather tread design suitable for most winter driving conditions.
＋
For the best performance in snowy or icy conditions, you should install snow tires or tire chains. They may be required by local laws under certain conditions.
SnowTires If you mount snow tires on your vehicle, make sure they are radial tires of the same size and load range as the original tires. Mount snow tires on all four wheels. The traction provided by snow tires on dry roads may be lower than your original tires. Check with the tire dealer for maximum speed recommendations.
TireChains Mount tire chains on your tires when required by driving conditions or local laws. Install them only on the front tires.
Because your vehicle has limited tire clearance, Acura strongly recommends using the chain listed below, made by Security Chain Company (SCC).
Cable-type: SCC Radial Chain SC1040
488
11/07/20 19:04:34 31SJA670_494
Tires
When installing cables, follow the manufacturer’s instructions, and mount them as tight as you can. Make sure they are not contacting the brake lines or suspension. Drive slowly with them installed. If you hear them coming into contact with the body or chassis, stop and investigate. Remove them as soon as you begin driving on cleared roads.
Using the wrong chains, or not properly installing chains, can damage the brake lines and cause a crash in which you can be seriously injured or killed.
Follow all instructions in this owner’s manual regarding the selection and use of tire chains.
Traction devices that are the wrong size or improperly installed can damage your vehicle’s brake lines, suspension, body, and wheels. Stop driving if they are hitting any part of the vehicle.
489
11/07/20 19:04:41 31SJA670_495
Checking the Battery
TEST INDICATOR WINDOW
Check the condition of the battery monthly by looking at the test indicator window. The label on the battery explains the test indicator’s colors. To see the label, remove the battery cover (see page
492
).
490
Check the terminals for corrosion (a white or yellowish powder). To remove it, cover the terminals with a solution of baking soda and water. It will bubble up and turn brown. When this stops, wash it off with plain water. Dry off the battery with a cloth or paper towel. Coat the terminals with grease to help prevent future corrosion.
If additional battery maintenance is needed, see your dealer or a qualified technician.
Battery posts,
WARNING: terminals, and related accessories contain lead and lead compounds. Wash your hands after handling.
If you need to connect the battery to a charger, disconnect both cables to prevent damaging your vehicle’s electrical system. Always disconnect the negative ( − reconnect it last.
) cable first, and
The battery gives off explosive hydrogen gas during normal operation.
A spark or flame can cause the battery to explode with enough force to kill or seriously hurt you.
Wear protective clothing and a face shield, or have a skilled technician do the battery maintenance.
11/07/20 19:04:48 31SJA670_496
If your vehicle’s battery is disconnected or goes dead, all stored driving positions will be lost. To store the driving positions again, see the storing procedure on page
164
Onvehicleswithnavigationsystem The navigation system will also disable itself. The next time you turn on the ignition switch, the system will require you to enter a PIN before it can be used. Refer to the navigation system manual.
Onvehicleswithoutnavigationsystem The compass system will also disable itself. The next time you turn on the ignition switch, the system will require you to enter a PIN before it can be used. Enter the four-digit anti- theft security code (see page ). You will also need to reset the clock according to the instruction of 313
setting the clock (see page298
).
Checking the Battery
If your vehicle’s battery is disconnected or goes dead, the audio system may disable itself. The next time you turn on the radio you will see ‘‘ display. Use the preset buttons to enter the code (see page
’’ in the frequency
280
).
If your vehicle’s battery is disconnected or goes dead, the power tilt and telescopic steering wheel system will be disabled. The system needs to be reset after reconnecting the battery (see page 149
).
491
11/07/20 19:04:55 31SJA670_497
Checking the Battery
Removing the Battery Cover
CLIPS
Unlock Lock
KNOB
3.
To reinstall the cover, reinstall the two holding clips and secure them by pushing on the center of each fastener head.
4.
Turn the knob of the cover to LOCK position as shown in the illustration.
Push to remove clip Push to reset/install clip
1.
Turn the knob of the battery cover to UNLOCK as shown in the illustration.
2.
Remove the holding clips by pushing on the center of each fastener head.
492
11/07/20 19:05:05 31SJA670_498
If you need to park your vehicle for an extended period (more than 1
month), there are several things you should do to prepare it for storage. Proper preparation helps prevent deterioration and makes it easier to get your vehicle back on the road. If possible, store your vehicle indoors.Fill the fuel tank.
Wash and dry the exterior completely.
Clean the interior. Make sure the carpeting, floor mats, etc., are completely dry.
Leave the parking brake off. Put the transmission in Park.
Block the rear wheels.
If the vehicle is to be stored for a longer period, it should be supported on jackstands so the tires are off the ground.
Leave one window open slightly (if the vehicle is being stored indoors).
Disconnect the battery.
Support the front wiper blade arms with a folded towel or rag so they do not touch the windshield.
To minimize sticking, apply a silicone spray lubricant to all door and trunk seals. Also, apply a vehicle body wax to the painted surfaces that mate with the door and trunk seals.
Vehicle Storage
Cover the vehicle with a ‘‘breathable’’ cover, one made from a porous material such as cotton. Non-porous materials, such as plastic sheeting, trap moisture, which can damage the paint.
If possible, periodically run the engine until it reaches full operating temperature (the cooling fans cycle on and off twice). Preferably, do this once a month.
493
11/07/20 19:05:08 31SJA670_499
Interior Care
Leather Vacuum dirt and dust from the leather frequently. Pay close attention to the pleats and seams. Clean the leather with a soft cloth dampened with a 90% water and 10% neutral wool detergent solution. Then buff it with a clean, dry cloth. Remove any dust or dirt on leather surfaces immediately.
494
11/07/20 19:05:12 31SJA670_500
Taking Care of the Unexpected
This section covers the more common problems that motorists experience with their vehicles. It gives you information about how to safely evaluate the problem and what to do to correct it. If the problem has stranded you on the side of the road, you may be able to get going again. If not, you will also find instructions on getting your vehicle towed.
Compact Spare Tire Changing a Flat Tire If the Engine Won’t Start Jump Starting If the Engine Overheats Low Oil Pressure Indicator Charging System Indicator Malfunction Indicator Lamp Brake System Indicator Opening the Fuel Fill Door
...................... .................... ............. ................................ .............. ......... .......... ....... ...............
Manually
.................................... .............................................. .............................. ...................... ..........
Fuses Fuse Locations Emergency Towing If Your Vehicle Gets Stuck
. 496
. 497
. 501
. 502
. 505
. 508
. 508
. 509
. 510. 511
. 512
. 518
. 521
. 521495
11/07/20 19:05:21 31SJA670_501
Compact Spare Tire
Use the compact spare tire as a temporary replacement only. Get your regular tire repaired or replaced, and put it back on your vehicle as soon as you can.
Check the air pressure of the compact spare tire every time you check the other tires. It should be inflated to:
60 psi (420 kPa , 4.2 kgf/cm )
496
Follow these precautions:
INDICATOR LOCATION MARKS
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and less traction on some road surfaces. Use greater caution while driving.
Do not mount snow chains on the compact spare tire.
Do not use your compact spare tire on another vehicle unless it is the same make and model.
After the flat tire is replaced with the spare tire, the low tire pressure/TPMS indicator stays on. After several miles (kilometers) driving with the spare, this indicator begins to flash, then stays on again. You will also see a ‘‘CHECK TPMS SYSTEM’’ message on the multi-information display (see page
433
).
TREAD WEAR INDICATOR
Replace the tire when you can see the tread wear indicator bars. The replacement tire should be the same size and design, mounted on the same wheel. The spare tire is not designed to be mounted on a regular wheel, and the spare wheel is not designed for mounting a regular tire.
11/07/20 19:05:30 31SJA670_502
If you have a flat tire while driving, pull over safely. Drive slowly along the shoulder until you get to an area far away from traffic lanes.
The vehicle can easily roll off the jack, seriously injuring anyone underneath.
Follow the directions for changing a tire exactly, and never get under the vehicle when it is supported only by the jack.
1.
Park the vehicle on firm, level, and non-slippery ground. Put the transmission in Park. Apply the parking brake. If you are towing a trailer, unhitch it.
2.
Turn on the hazard warning lights, and turn the ignition switch to the LOCK (0) position. Have all passengers get out of the vehicle while you change the tire.
Changing a Flat Tire
TRUNK FLOOR
SPARE TIRE
TOOL CASE
JACK
3.
Open the trunk, and fold the trunk floor forward.
4.
Take the tool case out of the spare tire.
5.
Unscrew the wing bolt, and remove the spacer cone. Then take the spare tire out of its well.
CONTINUED
497
11/07/20 19:05:37 31SJA670_503
Changing a Flat Tire
WHEEL NUT WRENCH
WHEEL NUT WRENCH
6.
Loosen each wheel nut 1/2 turn with the wheel nut wrench.
7.
△
Place the jack under the jacking point nearest the tire you need to change. It is pointed to by a mark molded into the underside of the body. Turn the end bracket clockwise until the top of the jack contacts the jacking point. Make sure the jacking point tab is resting in the jack notch.
EXTENSION
8.
9.
Use the extension and the wheel nut wrench as shown to raise the vehicle until the flat tire is off the ground.
Remove the wheel nuts, then remove the flat tire. Handle the wheel nuts carefully; they may be hot from driving. Place the flat tire on the ground with the outside surface facing up.
498
11/07/20 19:05:44 31SJA670_504
Changing a Flat Tire
BRAKE HUB
10.
Before mounting the spare tire, wipe any dirt off the mounting surface of the wheel and hub with a clean cloth. Wipe the hub carefully; it may be hot from driving.
11.
Put on the spare tire. Put the wheel nuts back on finger-tight, then tighten them in a crisscross pattern with the wheel nut wrench until the wheel is firmly against the hub. Do not try to tighten the wheel nuts fully.
12.
Lower the vehicle to the ground, and remove the jack.
CONTINUED
499
11/07/20 19:05:53 31SJA670_505
Changing a Flat Tire
SPACER CONE
16.
Store the jack and tools in the tool case. Place the tool case in the flat tire.
Loose items can fly around the interior in a crash and could seriously injure the occupants.
Store the wheel, jack, and tools securely before driving.
17.
Lower the trunk floor, then close the trunk lid.
18.
Your vehicle’s original tire has a tire pressure monitoring system sensor. To replace a tire, refer to Changing a Tire with TPMS page
430
).
(see
WING BOLT
13.
Tighten the wheel nuts securely in the same crisscross pattern. Have the wheel nut torque checked at the nearest automotive service facility. Tighten the wheel nuts to: 94 lbf·ft (127 N·m , 13 kgf·m)
14.
Place the flat tire face down in the spare tire well.
15.
Wrap the spacer cone and spare tire wing bolt with cloth or paper, and store them in the spare tire well.
500
11/07/20 19:06:02 31SJA670_506
If the Engine Won’t Start
Diagnosing why the engine won’t start falls into two areas, depending on what you hear when you turn the ignition switch to the START (III) position:
You hear nothing, or almost nothing. The engine’s starter motor does not operate at all, or operates very slowly.
You can hear the starter motor operating normally, or the starter motor sounds like it is spinning faster than normal, but the engine does not start up and run.
Nothing Happens or the Starter Motor Operates Very Slowly When you turn the ignition switch to the START (III) position, you do not hear the normal noise of the engine trying to start. You may hear a clicking sound, a series of clicks, or nothing at all. Check these things:
Make sure the remote is with you, inside the vehicle.
Check the transmission interlock. The transmission must be in Park or neutral or the starter will not operate.
Turn the ignition switch to the ON (II) position. Turn on the headlights, and check their brightness. If the headlights are very dim or do not come on at all, the battery is discharged. See Jump Starting
on page
502
Turn the ignition switch to the START (III) position. If the headlights do not dim, check the condition of the fuses. If the fuses are OK, there is probably something wrong with the electrical circuit for the ignition switch or starter motor. You will need a qualified technician to determine the problem. See Emergency Towing
on page
521
If the headlights dim noticeably or go out when you try to start the engine, either the battery is discharged or the connections are corroded. Check the condition of the battery and terminal connections (see page ). You can then try jump starting the vehicle from a booster battery (see page ).
490
502
501
11/07/20 19:06:11 31SJA670_507
If the Engine Won’t Start, Jump Starting
There may be an electrical problem, such as no power to the fuel pump. Check all the fuses (see page
512
).
If you find nothing wrong, you will need a qualified technician to find the problem. See Towing on page
Emergency 521
Jump Starting Although this seems like a simple procedure, you should take several precautions.
A battery can explode if you do not follow the correct procedure, seriously injuring anyone nearby.
Keep all sparks, open flames, and smoking materials away from the battery.
You cannot start your vehicle by pushing or pulling it.
The Starter Operates Normally In this case, the starter motor’s speed sounds normal, or even faster than normal, when you turn the ignition switch to the START (III) position, but the engine does not run.
Are you using the proper starting Starting the procedure? Refer to Engine 401
on page
Are you using a properly coded built-in key or remote? An improperly coded built-in key or remote will cause the immobilizer system indicator in the instrument panel to blink rapidly (see page 150
).
Do you have fuel? Check the fuel gauge; the low fuel indicator may not be working.
502
11/07/20 19:06:20 31SJA670_508
ToJumpStartYourVehicle: 1.
Open the hood, and check the physical condition of the battery. In very cold weather, check the condition of the electrolyte. If it seems slushy or frozen, do not try jump starting until it thaws.
COVER
If a battery sits in extreme cold, the electrolyte inside can f reeze. Attempting to jump start with a f rozen battery can cause it to rupture.
3.
2.
Turn off all the electrical acces- sories: heater, A/C, climate control, stereo system, lights, etc. Put the transmission in Park, and set the parking brake.
492
), then remove the
Remove the battery cover (see page secondary under-hood fuse box cover from the positive ( terminal on the battery.
＋
Jump Starting
BOOSTER BATTERY
The numbers in the illustration show you the order to connect the jumper cables.
4.
＋
Connect one jumper cable to the positive ( ) terminal on your vehicle’s battery. Connect the other end to the positive ( terminal on the booster battery.
＋
CONTINUED
503
11/07/20 19:06:28 31SJA670_509
Jump Starting
Connecting the jumper cable to the secondary under-hood f use box causes the f uses to blow.
504
7.
8.
Start your vehicle. If the starter motor still operates slowly, check that the jumper cables have good metal-to-metal contact.
Once your vehicle is running, disconnect the negative cable from your vehicle, then from the booster battery. Disconnect the positive cable from your vehicle, then from the booster battery.
9.
Reinstall the secondary under- hood fuse box cover over the positive ( ) terminal of the battery, then reinstall the battery cover.
＋
Keep the ends of the jumper cables away from each other and any metal on the vehicle until everything is disconnected. Otherwise, you may cause an electrical short.
5.
−
Connect the second jumper cable to the negative ( ) terminal on the booster battery. Connect the other end to the engine hanger as shown. Do not connect this jumper cable to any other part of the engine.
6.
If the booster battery is in another vehicle, have an assistant start that vehicle and run it at a fast idle.
11/07/20 19:06:37 31SJA670_510
The pointer of the vehicle’s temperature gauge should stay in the midrange. If it climbs to the red mark, you should determine the reason (hot day, driving up a steep hill, etc.).
If your vehicle overheats, you should take immediate action. The only indication may be the temperature gauge climbing to or above the red mark. Or you may see steam or spray coming from under the hood.
Driving with the temperature gauge pointer at the red mark can cause serious damage to the engine.
Steam and spray from an overheated engine can seriously scald you.
Do not open the hood if steam is coming out.
1.
2.
Safely pull to the side of the road. Put the transmission in Park, and set the parking brake. Turn off all the accessories, and turn on the hazard warning lights.
If you see steam and/or spray coming from under the hood, turn off the engine. Wait until you see no more signs of steam or spray, then open the hood.
If the Engine Overheats
3.
If you do not see steam or spray, leave the engine running and watch the temperature gauge. If the high heat is due to overloading, the engine should start to cool down almost immediately. If it does, wait until the temperature gauge comes down to the midpoint, then continue driving.
4.
If the temperature gauge stays at the red mark, turn off the engine.
5.
Look for any obvious coolant leaks, such as a split radiator hose. Everything is still extremely hot, so use caution. If you find a leak, it must be repaired before you Emergency continue driving (see Towing ). 521
on page
CONTINUED
505
11/07/20 19:06:45 31SJA670_511
If the Engine Overheats
6.
7.
If you do not find an obvious leak, check the coolant level in the radiator reserve tank. Add coolant if the level is below the MIN mark.
If there was no coolant in the reserve tank, you may need to add coolant to the radiator. Let the engine cool down until the pointer reaches the middle of the tempera- ture gauge, or lower, before check- ing the radiator.
Removing the radiator cap while the engine is hot can cause the coolant to spray out, seriously scalding you.
Always let the engine and radiator cool down before removing the radiator cap.
506
8.
9.
Using gloves or a large heavy cloth, turn the radiator cap counterclockwise, without pushing down, to the first stop. After the pressure releases, push down on the cap, and turn it until it comes off.
’’). Add coolant to the
Start the engine, and set the temperature to maximum heat (climate control to AUTO at ‘‘ radiator up to the base of the filler neck. If you do not have the proper coolant mixture available, you can add plain water. Remember to have the cooling system drained and refilled with the proper mixture as soon as you can.
10.
Put the radiator cap back on tightly. Run the engine, and check the temperature gauge. If it goes back to the red mark, the engine needs repair (see Towing on page
Emergency 521
).
11.
If the temperature stays normal, check the coolant level in the radiator reserve tank. If it has gone down, add coolant to the MAX mark. Put the cap back on tightly.
11/07/20 19:06:51 31SJA670_512
If the Engine Overheats
Check Radiator System
You can still drive your vehicle even if this message appears on the multi- information display, however you should check the temperature gauge while driving.
If you notice the temperature gauge climbing to or above the red mark, safely pull to the side of the road. Follow the instructions on pages 505
and
506
If there is a problem with the radiator system, you will see a ‘‘CHECK RADIATOR SYSTEM’’ message on the multi-information display. If you see this message, the engine has probably overheated. You should take your vehicle to a dealer, and have it repaired as soon as possible.
507
11/07/20 19:07:00 31SJA670_513
Low Oil Pressure Indicator, Charging System Indicator
Low Oil Pressure Indicator
This indicator should never come on when the engine is running. If it starts flashing or stays on, or if you see a ‘‘CHECK ENGINE OIL LEVEL’’ message on the multi- information display, the oil pressure has dropped very low or lost pressure. Serious engine damage is possible, and you should take immediate action.
Running the engine with low oil pressure can cause serious mechanical damage almost immediately. Turn of f the engine as soon as you can saf ely get the vehicle stopped.
1.
2.
3.
4.
508
Safely pull off the road and shut off the engine. Turn on the hazard warning lights.
Let the vehicle sit for a minute. Open the hood, and check the oil level (see page ). An engine very low on oil can lose pressure during cornering and other driving maneuvers.
387
If necessary, add oil to bring the level back to the full mark on the dipstick (see page
458
).
Start the engine, and watch the oil pressure indicator. If it does not go out within 10 seconds, turn off the engine. There is a mechanical problem that needs to be repaired before you can continue driving (see 521
Emergency Towing ).
on page
Charging System Indicator
If the charging system indicator comes on brightly when the engine is running, or if you see a ‘‘CHECK CHARGING SYSTEM’’ message on the multi-information display, the battery is not being charged.
Immediately turn off all electrical accessories. Try not to use other electrically operated controls such as the power windows. Keep the engine running; starting the engine will discharge the battery rapidly.
Go to a dealer or a service station where you can get technical assistance.
11/07/20 19:07:08 31SJA670_514
If this indicator comes on while driving, or if you see
a ‘‘CHECK EMISSION SYSTEM’’ message on the multi-information display, it means one of the engine’s emissions control systems may have a problem. Even though you may feel no difference in your vehicle’s performance, it can reduce your fuel economy and cause increased emissions. Continued operation may cause serious damage.
If you have recently refueled your vehicle, the indicator coming on could be due to a loose or missing fuel fill cap. You will also see a ‘‘TIGHTEN FUEL CAP’’ message on the multi-information display. Tighten the cap until it clicks at least once (see page ). Tightening the cap will not turn the indicator off immediately; it can take several days of normal driving.
385
Malfunction Indicator Lamp
If the indicator comes on repeatedly, even though it may go off as you continue driving, have the vehicle checked by your dealer as soon as possible.
If the battery in your vehicle has been disconnected or gone dead, these codes may be erased. It can take several days of driving under various conditions to set the codes again.
If you keep driving with the malf unction indicator lamp on, you can damage your vehicle’s emissions controls and engine. Those repairs may not be covered by your vehicle’s warranties.
The malfunction indicator lamp may also come on with the ‘‘D’’ indicator.
Readiness Code Your vehicle has certain ‘‘readiness codes’’ that are part of the on-board diagnostics for the emissions systems. In some states, part of the emissions testing is to make sure these codes are set. If they are not set, the test cannot be completed.
To check if they are set, turn the ignition switch to the ON (II) position, without starting the engine. The malfunction indicator lamp will come on for 20 seconds. If it then goes off, the readiness codes are set. If it blinks five times, the readiness codes are not set. If possible, do not take your vehicle for an emissions test until the readiness codes are set. Emissions Testing Refer to more information (see page
for 537
).
509
11/07/20 19:07:14 31SJA670_515
Brake System Indicator
U.S.
Canada
The brake system indicator normally comes on when you turn the ignition switch to the ON (II) position and as a reminder to check the parking brake. If you do not release the parking brake, the indicator will stay on, and you will see a ‘‘RELEASE PARKING BRAKE’’ message on the multi- information display.
If the brake system indicator comes on while driving, the brake fluid level is probably low. You will see a ‘‘BRAKE FLUID LOW’’ message on the multi-information display. Press lightly on the brake pedal to see if it feels normal. If it does, check the brake fluid level the next time you stop at a service station (see page 466
).
510
Slow down by shifting to a lower gear, and pull to the side of the road when it is safe. Because of the long distance needed to stop, it is hazardous to drive the vehicle. You should have it towed and repaired as soon as possible (see Towing 521
Emergency ).
on page
If the fluid level is low, take your vehicle to a dealer, and have the brake system inspected for leaks or worn brake pads.
However, if the brake pedal does not feel normal, you should take immediate action. A problem in one part of the system’s dual circuit design will still give you braking at two wheels. You will feel the brake pedal go down much farther before the vehicle begins to slow down, and you will have to press harder on the pedal.
You will also see a ‘‘CHECK BRAKE SYSTEM’’ message on the multi- information display.
11/07/20 19:07:21 31SJA670_516
Brake System Indicator, Opening the Fuel Fill Door Manually
Opening the Fuel Fill Door Manually
If you must drive the vehicle a short distance in this condition, drive slowly and carefully.
If the ABS indicator and the VSA system indicator come on with the brake system indicator, have your vehicle inspected by your dealer immediately.
MAINTENANCE LID
RELEASE LEVER
If the fuel fill door release button does not work, use the release lever inside the left maintenance lid in the trunk.
To open the fuel fill door, pull the release lever rearward.
511
11/07/20 19:07:28 31SJA670_517
Fuses
INTERIOR FUSE BOX Driver’s side
INTERIOR FUSE BOX Passenger’s side
SECONDARY INTERIOR FUSE BOX Driver’s side
NOTCH
NOTCH
FUSE BOX
To open the secondary fuse box lid, push the tab in the direction as shown in the illustration.
The fuses are located in five fuse boxes. The interior fuse boxes are located under the dashboard on the driver’s and passenger’s side.
To remove the fuse box lid, put your finger in the notch on the lid, pull it toward you, and take it out of its hinges.
512
11/07/20 19:07:34 31SJA670_518
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
TAB
TAB
The primary under-hood fuse box is in the engine compartment on the driver’s side. To open it, push the tabs as shown.
The secondary under-hood fuse box is on the battery. To open it, push the tabs as shown.
To check the fuse box, remove the ). battery cover first (see page
492
Fuses
513
11/07/20 19:07:42 31SJA670_519
Fuses
Checking and Replacing Fuses If something electrical in your vehicle stops working, the first thing you should check for is a blown fuse. Determine from the chart on pages , or the diagram 518 519
on the fuse box lid, which fuse or fuses control that device. Check those fuses first, but check all the fuses before deciding that a blown fuse is the cause. Replace any blown fuses, and check if the device works., and
520
FUSE
BLOWN
BLOWN
1.
Turn the ignition switch to the LOCK (0) position. Make sure the headlights and all other accessories are off.
2.
Remove the cover from the fuse box.
3.
Check each of the large fuses in the under-hood fuse box by looking through the top at the wire inside. Removing these fuses requires a Phillips-head screwdriver.
514
11/07/20 19:07:48 31SJA670_520
FUSE
BLOWN
