2002 Toyota MR2 Spyder Owners Manual

page 8 in Section 1–2. If your keys are locked in the vehicle and you cannot get a duplicate, many Toyota dealers can still open the door for you, using If you must break a window in, we suggest breaking the side window because it is the to replace. Be ex- tremely cautious to avoid cuts from the glass.

the suggestion given in “Keys” on

least expensive

their special

to get

tools.

SD04003

3. To push the link, insert a key or

screwdriver to the hole. The lever can be operated while the link is being pushed.

4. Shift into the ”N” position. 5. Re–insert the cover. 6. Start the engine while depressing the

brake pedal.

Be sure to have the system checked by your Toyota dealer as soon as possible.

166

01 05 22

02 MY MR2 SMT(U) L/O 0108

SECTION 4

IN CASE OF AN EMERGENCY If your vehicle will not start If your engine stalls while driving If you cannot increase the engine speed If your vehicle overheats If you have a flat tire If your vehicle needs to be towed If you cannot shift the sequential manual transmission selector lever If you lose your keys

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

168
171
171
172
173
182

186
186

167

01 05 22

to start

followed in

the other keys will start

If your vehicle will not start— (a) Simple checks Before making these checks, make sure the correct starting you have procedure given “How the engine” on page 140 in Section 3 and that fuel. Also check you have sufficient whether the engine. If they work, your key may be broken. Have the key checked at your Toyota dealer. If none of your keys work, the engine immobiliser system is possibly broken. Call your Toyota dealer. (See “Keys” on page 8 in Section 1- 2.) If the engine is not turning over or is turning over too slowly— 1. Check the battery

terminals are

that

tight and clean.

2. If the battery terminals are O.K., switch

on the interior light.

3. If the light

is out, dim or goes out when the starter is cranked, the battery is discharged. You may try jump start- ing. See “(c) Jump starting” on page 169 for further instructions.

If the light is O.K., but the engine still will not start, it needs adjustment or repair. Call a Toyota dealer or qualified repair shop.

168

02 MY MR2 SMT(U) L/O 0108

NOTICE

(cid:1) Sequential manual

transmission only: Your vehicle cannot be pull- or push-started.

(cid:1) Do not pull- or push-start the ve- hicle. It may damage the vehicle or cause a collision when the engine starts. Also the three-way catalytic converter may overheat and become a fire hazard.

If the engine turns over at its normal speed but will not start— 1. The engine may be flooded because of repeated cranking. See “(b) Starting a flooded engine” on page 168 for further instructions.

2. If the engine still will not start, it needs repair. Call a Toyota

adjustment or dealer or qualified repair shop.

try cranking

(b) Starting a flooded engine If the engine will not start, your engine may be flooded because of repeated cranking. Sequential manual transmission: If this happens, turn the key to “START” with the accelerator pedal and brake pedal held down. Keep the key, accelerator pedal and brake pedal in these positions for 15 sec- onds and release them. Then release the accelerator pedal, and the engine with the brake pedal depressed. Manual this happens, turn the key to “START” with the accelera- tor pedal held down. Keep the key and accelerator pedal in these positions for 15
seconds and release them. Then try start- ing the engine with your foot off the accel- erator pedal. If the engine does not start after 15 sec- onds of cranking, release the key, wait a few minutes and try again. If the engine still will not start, it needs adjustment or repair. Call a Toyota dealer or qualified repair shop for assistance.

transmission:

If

NOTICE

Do not crank for more than 30 sec- onds at a time. This may overheat the starter and wiring systems.

01 05 22

02 MY MR2 SMT(U) L/O 0108

(c) Jump starting To avoid serious personal injury and damage to your vehicle which might re- sult from battery explosion, acid burns, electrical burns, or damaged electronic components, these instructions must be followed precisely. If you are unsure about how to follow this procedure, we strongly that you seek the help of a competent me- chanic or towing service.

recommend

CAUTION

(cid:1) Batteries

contain

sulfuric

acid which is poisonous and corrosive. Wear protective safety glasses when jump starting, and avoid spilling acid on your skin, clothing, or ve- hicle.

(cid:1) If you should accidentally get acid on yourself or in your eyes, remove any contaminated clothing and flush the affected area with water imme- diately. Then get immediate medical attention. If possible, continue to apply water with a sponge or cloth while en route to the medical office.

(cid:1) The gas normally produced by a battery will explode if a flame or spark is brought near. Use only standardized jumper cables and do not smoke or light a match while jump starting.

Warning: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause can- cer and reproductive harm. Wash hands after handling.

NOTICE

The battery used for boosting must be 12 V. Do not jump start unless you are sure that the booster battery is correct.

JUMP STARTING PROCEDURE 1. If

the booster battery

installed in another vehicle, make sure the vehicles are not touching. Turn off all unneces- sary lights and accessories.

is

2. If required, remove all the vent plugs from the booster and discharged batter- ies. Lay a cloth over the open vents on the batteries. (This helps reduce the explosion hazard, personal injuries and burns.)

3. If the engine in the vehicle with the booster battery is not running, start it and let it run for a few minutes. During jump starting, run the engine at about 2000 rpm with the accelerator pedal lightly depressed.

169

01 05 22

02 MY MR2 SMT(U) L/O 0108

Discharged battery

SB41055

Booster battery

Jumper cable

SB41056

SB41040

Positive terminal (“+” mark)

Jumper cable

Positive terminal (“+” mark)

4. Make the cable connections in the or-

der a, b, c, d. a. Connect the clamp of the positive (red) jumper cable to the positive (+) terminal on the discharged battery. b. Connect the clamp at the other end of the positive (red) jumper cable to the positive (+) terminal on the booster battery.

Discharged battery

Booster battery

Negative terminal (“- ” mark)

c. Connect the clamp of the negative (black) jumper cable to the negative (- ) terminal on the booster battery. d. Connect the clamp at the other end of the negative (black) jumper cable to a solid, stationary, unpainted, metallic point of the vehicle with the discharged battery. The recommended connecting point is shown in the following illustration:

Connecting point

Do not connect the cable to or near any part that moves when the engine is cranked.

CAUTION

the connections,

to When making avoid serious injury, do not lean over the battery or accidentally the jumper cables or clamps touch any- thing except the correct battery termi- nals or the ground.

let

170

01 05 22

ignition switch

5. Sequential manual transmission: Turn the to “ON” position. Hold down the brake pedal firmly, and place the selector lever to “N” position. Make sure that the “N” indicator in the instrument cluster comes on. Then start your engine in a normal way. Manual transmission: Start your en- gine in the normal way. After starting, run it at about 2000 rpm for several minutes with the accelerator pedal lightly depressed.

6. Carefully disconnect the cables in the exact reverse order: the negative cable and then the positive cable.

7. Carefully dispose of the battery cover cloths—they may now contain sulfuric acid.

8. If removed, replace all the battery vent

plugs.

If the cause of your battery discharging is not apparent (for example, lights left on), you should have it checked.

02 MY MR2 SMT(U) L/O 0108

If your engine stalls while driving If your engine stalls while driving... 1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place.

2. Turn on your emergency flashers. 3. Sequential manual transmission: Turn the ignition key to “ACC” or “LOCK” position. Approximately 5 seconds after, try starting the engine again. Manual transmission: Turn the ignition key to “ACC” or “LOCK”, and try start- ing the engine again.

If the engine will not start, see “If your vehicle will not start—” on page 168 in this section.

If you cannot increase the engine speed If the engine speed does not increase with the accelerator pedal depressed down to about the middle position, there may be a problem somewhere in your electronic throttle control system. At this time, if you depress the accelera- tor pedal more firmly and slowly, you can drive you vehicle at low speeds. Have your vehicle checked by your Toyota deal- er as soon as possible. Even if the abnormality of the electronic throttle control system is corrected during low speed driving, the system may not be recovered until the engine is stopped and the ignition key to ”ACC” or ”LOCK” position.

turned

is

CAUTION

CAUTION

If the engine is not running, the pow- er assist for the brakes and steering will not work so steering and braking will be much harder than usual.

Be especially careful to prevent erro- neous pedal operation.

171

01 05 22

If your vehicle overheats If your engine coolant temperature gauge indicates overheating, if you ex- perience a loss of power, or if you hear a loud knocking or pinging noise, the engine has probably overheated. You should follow this procedure... 1. Pull safely off the road, stop the ve- turn on your emergency hicle and flashers. Put the transmission in “N” (sequential manual transmission) or in neutral (manual transmission) and ap- ply the parking brake. Turn off the air conditioning if it is being used.

2. If coolant or steam is boiling out of the radiator or reservoir, stop the engine. Wait until the steam subsides before opening the hood. If there is no coolant boiling over or steam, leave the engine running and make sure the electric cooling fan is operating. If it is not, turn the ignition off.

CAUTION

injury, keep To help avoid personal the hood closed until there is no steam. Escaping steam or coolant is a sign of very high pressure.

172

02 MY MR2 SMT(U) L/O 0108

6. After

the engine coolant

temperature has cooled to normal, again check the coolant level in the reservoir. If neces- sary, bring it up to half full again. Seri- ous coolant loss indicates a leak in the system. You should have it checked as soon as possible at your Toyota dealer.

3. Look for obvious coolant leaks from the radiator, hoses, and under the vehicle. However, note that water draining from the air conditioning is normal if it has been used.

CAUTION

the engine

When is running, keep hands and clothing away from the moving fan and engine drive belts.

4. If the coolant is leaking, stop the en- gine immediately. Call a Toyota dealer for assistance.

5. If there are no obvious leaks, check the coolant reservoir. If it is dry, add coolant to the reservoir while the en- gine is running. Fill it about half full.

CAUTION

Do not attempt to remove the coolant reservoir cap or air release valve when the engine and radiator are hot. Serious from scalding hot fluid and steam blown out under pressure.

injury could

result

01 05 22

02 MY MR2 SMT(U) L/O 0108

If you have a flat tire— 1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place well away from the traffic. Avoid stopping on the center divider of a highway. Park on a level spot with firm ground.

2. Stop

the engine and

turn on your

emergency flashers.

3. Firmly engage the parking brake and put the transmission lever in “R” (se- quential manual transmission) or in re- verse (manual transmission).

4. Have everyone get out of the vehicle

on the side away from traffic.

5. Read oughly.

the

following

instructions

thor-

CAUTION

When jacking, be sure to observe the following to reduce the possibility of personal injury: (cid:1) Follow jacking instructions. (cid:1) Do not put any part of your body under the vehicle supported by the jack. Personal injury may occur.

(cid:1) Do not start or run the engine while is supported by the

your vehicle jack.

(cid:1) Stop the vehicle on a

the transmission

level firm ground, firmly set the parking brake and put in “R” (sequential manual transmission) or in reverse transmission). Block the wheel diagonally opposite to the one being changed if neces- sary.

(manual

(cid:1) Make sure to set the jack properly in the jack point. Raising the ve- hicle with improperly posi- tioned will damage the vehicle or may allow the vehicle to fall off the jack and cause personal injury.

jack

(cid:1) Never get under the vehicle when the vehicle is supported by the jack alone.

(cid:1) Use the jack only for lifting your

vehicle during wheel changing.

(cid:1) Do not raise the vehicle with some-

one in the vehicle.

(cid:1) When raising the vehicle, do not put an object on or under the jack. (cid:1) Raise the vehicle only high enough

to remove and change the tire.

173

01 05 22

02 MY MR2 SMT(U) L/O 0108

NOTICE

Do not continue driving with a de- flated tire. Driving even a short dis- tance can damage a tire and wheel beyond repair.

SU41031

The compact spare tire can be used many times, if necessary. It has tread life of up to 4800 km (3000 miles) depending on road conditions and your driving habits. When tread wear indicators appear on the tire, replace the tire. See also the tire section on page 215 in Section 7- 2 for details on the tread wear indicators and other service information.

CAUTION

Compact spare tire The compact spare tire is designed for temporary emergency use only. The compact spare tire is identified by the distinctive wheel design and color and special wording “TEMPORARY USE ONLY” molded into the side wall of the tire. The standard tire should be repaired and replaced as soon as possible. The compact spare tire saves space in your trunk, and its lighter weight helps to improve fuel economy and permits easier installation in case of a flat tire.

174

(cid:1) The compact spare

tire was de- signed especially for your Toyota. Do not use it on any other vehicle. (cid:1) Do not exceed 80 km/h (50 mph) the compact

when driving with spare tire.

(cid:1) Avoid sudden acceleration, sudden deceleration and sharp turns with the compact spare tire.

01 05 22

NOTICE

Your ground clearance is reduced when the compact spare tire is installed so avoid driving over ob- stacles and drive slowly on rough, unpaved roads and speed bumps. Also, do not attempt to go through an automatic car wash as the vehicle may get caught, resulting in damage.

02 MY MR2 SMT(U) L/O 0108

—Required tools and compact spare tire

SB41053

Compact spare tire

SB41054

Tool bag

1. Get the tool bag and compact spare

tire.

You will find a jack in the tool bag. To prepare yourself for an emergency, you should familiarize yourself with the use of the jack, each of the tools and their stor- age locations.

175

01 05 22

02 MY MR2 SMT(U) L/O 0108

SB41047

SB41061

SB41063

To remove the compact spare tire: 1. Open the front box cover in the trunk.

2. Remove the spare wheel cover.

176

3. Loosen the bolt and remove it. Then take the compact spare tire out of the vehicle. When storing the compact spare tire, put it in place with the outer side of the wheel facing up. Then secure the tire by repeat- ing the above removal steps in reverse order to prevent it from flying forward dur- ing a collision or sudden braking.

01 05 22

02 MY MR2 SMT(U) L/O 0108

—Blocking the wheel

—Loosening wheel nuts

SB41064

SB41035

SB41027

When you store the replaced flat ground tire in the place where the compact spare tire was loaded, install the spare wheel extension to the spare wheel clamp.

NOTICE

The replaced ground tire should be fixed steadily by the spare wheel clamp or it may damage the vehicle’s body.

2. Block the wheel diagonally opposite the flat tire to keep the vehicle from rolling when it is jacked up.

When blocking the wheel, place a wheel block from the front for the front wheels or from the rear for the rear wheels.

3. Loosen all the wheel nuts. Always loosen the wheel nuts before rais- ing the vehicle. Turn the wheel nuts counterclockwise to loosen. To get maximum leverage, fit the wrench to the nut so that the handle is on the right side, as shown above. Grab the wrench near the end of the handle and pull up on the handle. Be careful that the wrench does not slip off the nut. Do not remove the nuts yet—just unscrew them about one- half turn.

177

01 05 22

02 MY MR2 SMT(U) L/O 0108

—Positioning the jack

—Raising your vehicle

CAUTION

Never get under the vehicle when the vehicle jack alone.

is supported by

the

SB41036

SB41029

4. Position the jack at the correct jack

point as shown.

Make sure the jack level and solid place.

is positioned on a

5. After making sure that no one is in the vehicle, raise it high enough so that the compact spare tire can be installed.

tire

than when removing

Remember you will need more ground the compact clearance when putting on spare the flat tire. To raise the vehicle, insert the jack handle into the jack (it is a loose fit) and turn it clockwise. As the jack touches the vehicle and begins to lift, double- check that it is properly positioned.

178

01 05 22

02 MY MR2 SMT(U) L/O 0108

—Changing wheels

—Reinstalling wheel nuts

SB41028

SB41044

SB41030

6. Remove the wheel nuts and change

tires.

it

the flat

tire straight off and put

Lift aside. Roll the compact spare wheel into position and align the holes in the wheel with the bolts. Then lift up the wheel and get at least the top bolt started through its hole. Wiggle the tire and press it back over the other bolts.

Before putting wheels on, remove any cor- rosion on the mounting surfaces with a wire brush or such. Installation of wheels without good metal- to- metal contact at the mounting surface can cause wheel nuts to loosen and eventually cause a wheel to come off while driving. Therefore after the first 1600 km (1000 miles), check to see that the wheel nuts are tight.

7. Reinstall all the wheel nuts with

finger tight.

Reinstall the wheel nuts (tapered end in- ward) and tighten them as much as you can by finger. Press back on the tire back and see if you can tighten them more.

179

01 05 22

02 MY MR2 SMT(U) L/O 0108

—Lowering your vehicle

CAUTION

When lowering the vehicle, make sure all portions of your body and all oth- er persons around will not be injured as the ground.

the vehicle

lowered

to

is

SB41031

8. Lower the vehicle completely and

tighten the wheel nuts.

Turn the jack handle counterclockwise to lower the vehicle. Use only the wheel nut wrench and turn it clockwise to tighten the nuts. Do not use other tools or any additional leverage other than your hands, such as a hammer, pipe or your foot. Make sure the wrench is securely engaged over the nut. Tighten each nut a little at a time in the order shown. Repeat the process until all the nuts are tight.

180

—After changing wheels 9. Check the air pressure of the

replaced tire.

Adjust the air pressure to the specification designated on page 240 in Section 8. If the pressure is lower, drive slowly to the nearest service station and fill to the cor- rect pressure. Do not forget to reinstall the tire inflation valve cap as dirt and moisture could get into the valve core and possibly cause air leakage. If the cap is missing, have a new one put on as soon as possible. 10. Restow all the tools, jack and flat

tire securely.

tighten

the wheel nuts

As soon as possible after changing wheels, the torque specified on page 240 in Section 8 with a torque wrench. Have a technician repair the flat tire and replace the com- pact spare tire with it.

to

01 05 22

02 MY MR2 SMT(U) L/O 0108

CAUTION

Before driving, make sure all the tools, jack and flat tire are securely in place in their storage location to reduce the possibility of personal in- jury during a collision or sudden braking.

SB41025

SB41037

Remove the wheel ornament from the flat tire before restowing the flat tire.

NOTICE

The size of the front wheel and the rear wheel is different. In order to prevent the wrong installation, there is a pin on the assembly surface in- side the rear wheel as shown above. Therefore, the rear wheels cannot be installed on the front.

181

01 05 22

02 MY MR2 SMT(U) L/O 0108

If your vehicle needs to be towed—

(a) Towing with wheel lift type truck—

—From front

—From rear

SB41062

(b) Using flat bed truck

182

in

If towing is necessary, we recommend you to have it done by your Toyota dealer or a commercial tow truck ser- vice. In consultation with them, have your vehicle towed using either (a) or (b). Only when you cannot receive a towing service from a Toyota dealer or com- mercial tow truck service, tow your ve- hicle carefully in accordance with the instructions given “—Emergency towing” on page 183 in this section. Proper equipment will help ensure that your vehicle is not damaged while being towed. Commercial operators are generally aware of local laws pertaining to towing. Your vehicle can be damaged is towed incorrectly. Although most operators know the correct procedure, it is possible to make a mistake. To avoid damage to your vehicle, make sure the following pre- cautions are observed. If necessary, show this page to the tow truck driver. TOWING PRECAUTIONS: Use a safety chain system for all towing, and abide by the state/provincial and local laws. The wheels and axle on the ground must be in good condition. If they are damaged, use a towing dolly.

the state/provincial and

if

it

(a) Towing with wheel lift type truck From front—We recommend using a tow- ing dolly under the rear wheels. If you do not use a towing dolly, release the parking brake and put the transmission in “N” (se- quential manual transmission) or in neutral (manual transmission). The key must be in “ACC” (sequential manual transmission). Sequential manual transmission only: After shifting the selector lever to the “N” position, always make sure that the gear is actually disengaged and is in neutral by pushing the vehicle by hand or other means. In case the gear can not be put in neutral, turn the ignition switch from the “OFF” to “ON” position, and operate the selector lever once from “N” to “S” or “R”, then back turn the ignition switch from to “OFF” position. These procedures may help put the gear in neutral. If the gear still can not be put in neutral, you can not tow without a towing dolly. From rear—Place the ignition key in the “ACC” position.

to “N” again. Then the “ON”

01 05 22

02 MY MR2 SMT(U) L/O 0108

CAUTION

(c) Towing with sling type truck

—Emergency towing

ignition switch

Do not tow without a towing dolly when the in the “ON” position and/or when the trans- mission in the neutral gear position. Otherwise, you may be in- volved in an unexpected accident.

is not

is

NOTICE

(cid:1) When lifting wheels, take care to ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Otherwise, the bumper and/or underbody of the towed vehicle will be damaged dur- ing towing.

(cid:1) Do not tow with the key removed or in the “LOCK” position, as the steering lock mechanism is not strong enough to hold the front wheels straight while towing.

(b) Using flat bed truck

SB41057

SB41045

(c) Towing with sling type truck

Remove the cover (front)

NOTICE

Do not tow with sling type truck, ei- ther from the front or rear. This may cause body damage.

SB41033

Install the eyelet (front)

183

01 05 22

02 MY MR2 SMT(U) L/O 0108

To install: Remove the cover of eyelet and firmly install it as shown in the illustration.

CAUTION

(cid:1) Use extreme caution when towing a vehicle. Avoid sudden starts or er- ratic driving maneuvers which would place excessive stress on the emergency towing eyelets and tow- ing cable or chain. The eyelets and towing cable or chain may break and cause serious injury or dam- age.

(cid:1) When

installing the eyelet on the vehicle, be sure to tighten the eye- let securely. is loose, it may come off when being towed and result in death or seri- ous injury.

tightening

the

If

SB41046

If towing is necessary, we recommend you to have it done by your Toyota dealer or a commercial tow truck ser- vice. If a towing service is not available in an emergency, your vehicle may be temporarily towed by a cable or chain secured to either the emergency towing eyelet* on the front of the vehicle or the right emergency towing eyelet* on the rear of the vehicle. Use extreme caution when towing vehicles.

Remove the cover (rear)

NOTICE

Only use specified towing eyelet; otherwise your vehicle may be dam- aged.

A driver must be in the vehicle to steer it and operate the brakes. Towing in this manner may be done only on hard- surfaced roads for a short dis- tance and at the wheels, axles, drive train, steering and brakes must all be in good condition. * : Eyelet The eyelet is stored in the luggage space with the jack handle.

low speeds. Also,

SB41034

Install the eyelet (rear)

184

01 05 22

02 MY MR2 SMT(U) L/O 0108

NOTICE

(cid:1) Use only a cable or chain specifi- cally intended for use in towing ve- hicles. Securely fasten the cable or chain to the towing eyelets pro- vided.

(cid:1) Do not use the left rear eyelet. It is

not designed for towing.

transmission: The

Before towing, release the parking brake and put the transmission in “N” (sequential manual transmission) or in neutral (manual transmission). Sequential manual key must be in “ACC”. Manual transmission: The key must be in “ACC” (engine off) or “ON” (engine run- ning). Sequential manual transmission only: After shifting the selector lever to the “N” position, always make sure that the gear is actually disengaged and is in neutral by pushing the vehicle by hand or other means. In case the gear can not be put in neutral, turn the ignition switch from the “OFF” to “ON” position, and operate the selector lever once from “N” to “S” or “R”, turn the then back ignition switch from to “OFF” position. These procedures may help put the gear in neutral. If the gear still can not be put in neutral, you can not tow with cables or chains.

to “N” again. Then the ”ON”

CAUTION

is not running, the (cid:1) If the engine power assist the brakes and for steering will not work so steering and braking will be much harder than usual.

(cid:1) Do not tow with a cable or chain when the ignition switch is in the “ON” position and/or when the transmission is not in the neutral gear position. Otherwise, you may be involved in an unexpected acci- dent.

185

01 05 22

02 MY MR2 SMT(U) L/O 0108

If you cannot shift the sequential manual transmission selector lever

SD04002

SD04003

3. To push the link, insert a key or

screwdriver to the hole. The lever can be operated while the link is being pushed.

4. Shift into the ”N” position. 5. Re- insert the cover. 6. Start the engine while depressing the

brake pedal.

Be sure to have the system checked by your Toyota dealer as soon as possible.

In case the selector lever lock is not released and the selector lever cannot be moved even ignition switch is turned to the ”ON” position, follow the procedures below: 1. Turn the ignition key to the ”LOCK”

though

the

or “ACC” position. Make sure the parking brake is applied.

2. Pry up the cover with a flat- bladed

screwdriver or equivalent.

186

If you lose your keys You can purchase a new key at your Toyota dealer if you can give them the key number and master key. Even if you lose only one key, contact your Toyota dealer to make a new key. If you lose all your master keys, you cannot make new keys; the whole engine immobi- liser system must be replaced. See page 8 in Section 1- 2. If your keys are locked in the vehicle and you cannot get a duplicate, many Toyota dealers can still open the door for you, If you must using break a window in, we suggest breaking the side window because it is the to replace. Be ex- tremely cautious to avoid cuts from the glass.

the suggestion given in “Keys” on

least expensive

their special

to get

tools.

01 05 22

02 MY MR2 SMT(U) L/O 0108

SECTION 5

CORROSION PREVENTION AND APPEARANCE CARE Protecting your Toyota from corrosion Washing and waxing your Toyota Cleaning the interior

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

168
169
172

167

01 03 28

the

Protecting your Toyota from corrosion Toyota, through its diligent research, de- sign and use of the most advanced technology available, has done its part to help prevent corrosion and has provided you with vehicle construction. Now, it is up to you. Proper care of your Toyota can help ensure long– term corrosion prevention. The most common causes of corrosion to your vehicle are: (cid:1) The accumulation of road salt, dirt and moisture in hard–to–reach areas under the vehicle.

quality

finest

(cid:1) Chipping of paint, or undercoating caused by minor accidents or by stones and gravel.

Care is especially important if you live in particular areas or operate your ve- hicle under certain environmental condi- tions: (cid:1) Road salt or dust control chemicals will accelerate corrosion, as will the pres- ence of salt in the air near the sea– coast or in areas of industrial pollution. (cid:1) High humidity accelerates corrosion es- pecially when temperatures range just above the freezing point.

168

02 MY MR2 SMT(U) L/O 0108

(cid:1) Wetness or dampness to certain parts of your vehicle for an extended period of time, may cause corrosion even though other parts of the vehicle may be dry.

(cid:1) High ambient temperatures can cause corrosion to those components of the vehicle which are prevented from quick–drying due to lack of proper ven- tilation.

The above signifies the necessity to keep your vehicle, particularly the underside, as clean as possible and to repair any dam- age to paint or protective coatings as soon as possible. To help prevent corrosion on your Toyota, follow these guidelines: Wash your vehicle frequently. It is, of course, necessary to keep your vehicle clean by regular washing, but to prevent corrosion, the following points should be observed: (cid:1) If you drive on salted roads

the winter or if you live near the ocean, you should hose off the undercarriage at least once a month to minimize cor- rosion.

in

(cid:1) High pressure water or steam is effec- tive for cleaning the vehicle’s underside and wheel housings. Pay particular attention to these areas as it is difficult to see all the mud and dirt. It will do more harm than good to simply wet the mud and debris without removing them. The lower edge of doors, rocker panels and frame members have drain holes which should not be allowed to clog with dirt as these areas can cause corrosion.

trapped water

in

(cid:1) Wash the underside of the vehicle thor-

oughly when winter is over.

See “Washing and waxing your Toyota” on page 169 for more tips. Check the condition of your vehicle’s paint and trim. If you find any chips or scratches in the paint, touch them up im- mediately to prevent corrosion from start- ing. If the chips or scratches have gone through the bare metal, have a qualified body shop make the repair.

01 03 28

02 MY MR2 SMT(U) L/O 0108

Check the interior of your vehicle. Wa- ter and dirt can accumulate under the floor mats and could cause corrosion. Oc- casionally check under the mats to make sure the area is dry. Be particularly care- ful when transporting chemicals, cleans- ers, fertilizers, salt, etc.; these should be transported in proper containers. If a spill or leak should occur, immediately clean and dry the area. Use mud shields on your wheels. If you drive on salted or gravel roads, mud shields help protect your vehicle. Full–size shields, which come as near to the ground as possible, are the best. We recommend that the fittings and the area where the shields are installed be treated to resist corrosion. Your Toyota dealer will be happy to assist in supplying and installing the shields if they are recommended for your area. Keep your vehicle in a well ventilated garage or a roofed place. Do not park your vehicle in a damp, poorly venti- lated garage. If you wash your vehicle in the garage, or if you drive it in covered with water or snow, your garage may be so damp it will cause corrosion. Even if your garage is heated, a wet vehicle can corrode if the ventilation is poor.

Washing and waxing your Toyota Washing your Toyota Keep your vehicle clean by regular washing. The following cases may cause weakness to the paint or corrosion to the body and parts. Wash your vehicle as soon as pos- sible. (cid:1) When driving in a coastal area (cid:1) When driving on a road sprinkled with

antifreeze

(cid:1) When having coal tar, tree sap, bird

droppings and carcass of an insect

(cid:1) When driving in the areas where there is a lot of smoke, soot, dust, iron dust and chemical substance

(cid:1) When the vehicle becomes remarkably

dirty with dust and mud Hand–washing your Toyota Work in the shade and wait until the vehicle body is not hot to the touch.

CAUTION

When cleaning under floor or chassis, be careful not to injure your hands.

For washing instructions for soft top, see “Soft top” on page 171. 1. Rinse off loose dirt with a hose. Re- move any mud or road salt from the underside of the wheel wells.

the vehicle or

in

169

01 03 28

02 MY MR2 SMT(U) L/O 0108

SB51001

Spray water on the side windows or top seals from above, at a 45(cid:2) angle to the ground.

NOTICE

Do not spray water at side windows and top seals in a way which may cause water to enter the vehicle.

170

2. Wash with a mild car–wash soap, mixed according to the manufacturer’s instructions. Use a soft cotton mitt and keep it wet by dipping it frequently into the wash water. Do not rub hard—let the soap and water remove the dirt.

Plastic wheel ornaments: The plastic wheel ornaments are damaged easily by organic substances. If any organic sub- stances splashes an ornament, be sure to wash it off with water and check if the ornament is damaged.

CAUTION

tar: Remove with

Road turpentine or cleaners that are marked safe for painted surfaces.

NOTICE

Do not use organic substances (gaso- line, kerosene, benzine or strong sol- vents) which may be toxic or cause damage.

3. Rinse

thoroughly—dried

can cause streaking. In hot weather you may need to rinse each section right after you wash it.

soap

Do not attach the heavily damaged plastic wheel ornament. It may fly off the wheel and cause accidents while the vehicle is moving.

Aluminum wheels: Use only a mild soap or neutral detergent. Plastic bumpers: Wash carefully. Do not scrub with abrasive cleaners. The bumper faces are soft.

4. To prevent water spots, dry the vehicle using a clean soft cotton towel. Do not rub or press hard—you might scratch the paint.

Automatic car wash

NOTICE

Do not run your Toyota through auto- matic car washes or possible damage to the soft top may result.

01 03 28

02 MY MR2 SMT(U) L/O 0108

Waxing your Toyota Polishing and waxing is recommended to maintain the original beauty of your Toyota’s finish. Once a month or if the vehicle surface does not repel water well, apply wax. 1. Always wash and dry the vehicle be- fore you begin waxing, even if you are using a combined cleaner and wax.

2. Use a good quality polish and wax. If the finish has become extremely weath- ered, use a car–cleaning polish, fol- lowed by a separate wax. Carefully fol- low the manufacturer’s instructions and precautions. Be sure to polish and wax the chrome trim as well as the paint. the vehicle again when water does not bead but remains on the sur- face in large patches.

3. Wax

NOTICE

(cid:3) Always remove the plastic bumpers if your vehicle is re–painted and placed in a high heat paint waxing booth. High temperatures could damage the bumpers.

(cid:3) Do not apply wax on the soft top.

It may damage the soft top.

the paint soon after

Touch–up paint Touch–up paint may be used to cover small chips or scratches. Apply the damage occurs or corrosion may set in. To do a good job, use a small artist’s brush and stir the paint well. Make sure the area is clean and dry. To apply the touch–up paint so it is hardly noticeable, the trick is to apply it only to the bare spots. Apply only the smallest amount possible and do not paint the surface around the scratch or chip. Soft top General cleaning— Follow the procedure shown below. 1. Brush off any loose dirt and rinse off

with a hose.

2. Using a sponge, wash with a mild solu- tion of soap (hand soap) in luke warm water (below 38(cid:2)C or 100(cid:2)F).

3. Rinse thoroughly to remove soap.

NOTICE

(cid:3) Do not use harsh or abrasive clean- ers as they may damage the top material.

(cid:3) Do not use water–repellents, wax or other preservative finishes as they may stain the top material.

cleaning

(for more difficult

Additional stains)— Follow the procedure shown below using a mild cleaning solution composed of the following ingredient. (cid:1) 110 g (4 oz.) of chlorine bleach (cid:1) 60 g (2 oz.) of soap (hand soap) (cid:1) 3.8L (1.0 gal., 0.8 lmp. gal.) of luke

warm water (below 38(cid:2)C or 100(cid:2)F).

1. Rinse

the top,

then spread the mild cleaning solution on the entire top. Do not put excessive amounts of liquid on the fabric.

171

01 03 28

2. Scrub with a small, soft bristle hand- brush. Add water as needed until the cleaner becomes soapy. Allow solution to settle for two to five minutes. Use a cloth or sponge to remove dirt so it will not be ground top. Be careful not to allow any cleaner to dry on it may cause streaks.

the body paint as

into the

3. Rinse thoroughly. If any dirt is left, repeat the procedure. After the top has been cleaned, rinse the vehicle with clean water to remove all the cleaner. After cleaning, always make sure the top is completely dry before you lower it. Low- ering top while wet or damp may cause interior water damage, water stains or mildew of the top material.

the

172

02 MY MR2 SMT(U) L/O 0108

Cleaning the interior

CAUTION

Do not wash the vehicle floor with water, or allow water to get onto the floor when cleaning the vehicle interi- or or exterior. Water may get into audio components or other electrical components above or under the floor carpet (or mat) and cause a malfunc- tion; and it may cause body corro- sion.

Vinyl interior The vinyl upholstery may be easily cleaned with a mild soap or detergent and water. First vacuum over the upholstery to re- move loose dirt. Then, using a sponge or soft cloth, apply the soap solution to the vinyl. After allowing it to soak in for a few minutes to loosen the dirt, remove the dirt and wipe off the soap with a clean damp cloth. If all the dirt do not come off, re- peat the procedure. Commercial foaming– type vinyl cleaners are also available which work well. Follow the manufacturer’s instructions.

NOTICE

Do not use solvent, thinner, gasoline or window cleaner on the interior.

to

foam–type shampoo

Carpets Use a good clean the carpets. Begin by vacuuming thoroughly to remove as much dirt as possible. Several types of foam cleaners are available; some are in aerosol cans and others are powders or liquids which you mix with water to pro- duce a foam. To shampoo the carpets, use a sponge or brush to apply the foam. Rub in overlapping circles. Do not apply water—the best results are obtained by keeping the carpet as dry as possible. Read the shampoo instructions and follow them closely. Seat belts The seat belts may be cleaned with mild soap and water or with lukewarm water. Use a cloth or sponge. As you are clean- ing, check the belts for excessive wear, fraying, or cuts.

01 03 28

02 MY MR2 SMT(U) L/O 0108

NOTICE

NOTICE

(cid:3) Do not use dye or bleach on the

belts—it may weaken them.

(cid:3) Do not use the belts until they be-

come dry.

Windows The windows may be cleaned with any household window cleaner.

NOTICE

When cleaning the inside of the win- dow, be careful not to scratch or damage the heater wires or connec- tors.

Air conditioning control panel, car au- dio, instrument panel, console panel, and switches Use a soft damp cloth for cleaning. Soak a clean soft cloth in water or luke- warm water then lightly wipe off any dirt.

(cid:3) Do not use organic substances (sol- vents, kerosene, alcohol, gasoline, etc.) or alkaline or acidic solutions. These chemicals can cause discol- oring, staining or peeling of the surface.

(cid:3) If you use cleaners or polishing agents, make sure their ingredients do not include the substances men- tioned above.

(cid:3) If you use a liquid car freshener, do not spill the liquid onto the ve- hicle’s interior surfaces. It may con- tain the ingredients mentioned above. Immediately clean any spill using the method mentioned above.

Leather Interior The leather upholstery may be cleaned with neutral detergent for wool. Remove dirt using a soft cloth dampened with 5% solution of neutral detergent for wool. Then thoroughly wipe off all traces of detergent with a clean damp cloth. After cleaning or whenever any part of the leather gets wet, dry with a soft clean cloth. Allow the leather to dry in a venti- lated shaded area.

NOTICE

(cid:3) If a stain should fail to come out with a neutral detergent, apply a cleaner that does not contain an organic solvent.

(cid:3) Never use organic substances such as benzine, alcohol or gasoline, or alkaline or acid solutions for clean- ing the leather as these could cause discoloring.

(cid:3) Use of a nylon brush or synthetic fiber cloth, etc. may scratch the fine grained surface of the leather.

173

01 03 28

(cid:3) Mildew may develop on soiled leath- er upholstery. Be especially careful to avoid oil spots. Try to keep your upholstery always clean.

(cid:3) Long exposure to direct sunlight may cause the leather surface to harden and shrink. Keep your ve- hicle in a shaded area, especially in the summer.

(cid:3) The interior of your vehicle is apt to heat up on hot summer days, so avoid placing on the upholstery items made of vinyl or plastic or containing wax as these tend to stick to leather when warm.

(cid:3) Improper cleaning of the leather up- holstery could result in discolor- ation or staining.

If you have any questions about the cleaning of your Toyota, your local Toyota dealer will be pleased to answer them.

174

02 MY MR2 SMT(U) L/O 0108

01 03 28

02 MY MR2 SMT(U) L/O 0108

SECTION 6

VEHICLE MAINTENANCE AND CARE Maintenance requirements General maintenance Does your vehicle need repairing? Emissions Inspection and Maintenance (I/M) programs

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

176
177
179
180

For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.

175

01 05 30

02 MY MR2 SMT(U) L/O 0108

that both

Maintenance requirements Your Toyota vehicle has been designed for fewer maintenance requirements with lon- ger service intervals to save both your time and money. However, each regular maintenance, as well as day–to–day care, is more important than ever before to en- sure smooth, trouble–free, safe, and eco- nomical drivings. It is the owner’s responsibility to make sure the specified maintenance, including general maintenance service, is performed. Note the new vehicle and emission control system warranties specify that proper maintenance and care must be performed. “Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement” warranty information. General maintenance General maintenance items are those day– to–day care practices that are important to your vehicle for proper operation. It is the owner’s responsibility to insure that the general maintenance items are performed regularly. These checks or inspections can be done either by yourself or a qualified technician, or if you prefer, your Toyota dealer will be pleased to do them at a nominal cost.

complete

See

for

176

is

for

the

repair of

recommend

Scheduled maintenance The scheduled maintenance items listed in the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement” are those required to be serviced at regular inter- vals. For details of your maintenance schedule, read the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It that only genuine Toyota parts be used for maintenance or the emission control system. The owner may elect to use non–Toyota supplied parts replacement pur- poses without invalidating the emission control system warranty. However, use of replacement parts which are not of equivalent quality may impair the effec- tiveness of the emission control sys- tems. You may have maintenance, replacement, or repair of the control devices and system performed by any automotive repair individual without invalidating this warranty. See “Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement” for complete warranty information.

establishment

emission

elect

also

for

or

to

tips and

Where to go for service? Toyota technicians are well–trained spe- cialists and are kept up to date with the latest service information through technical bulletins, service in–dealership training programs. They learn to work on Toyotas before they work on your vehicle, rather than while they are working on it. You can be confident that your Toyota dealer’s service department performs the best job to meet the maintenance require- ments on your vehicle—reliably and eco- nomically. Your copy of the repair order is proof that all required maintenance has been per- formed for warranty coverage. And if any problems should arise with your vehicle while under warranty, your Toyota dealer will promptly take care of it. Again, be sure to keep a copy of the repair order for any service performed on your Toyota. What about do–it–yourself maintenance? Many of the maintenance items are easy to do yourself if you have a little mechani- cal ability and a few basic automotive tools. Simple instructions for how to per- form them are presented in Section 7.

01 05 30

02 MY MR2 SMT(U) L/O 0108

you are

If skilled do–it–yourself mechanic, the Toyota service manuals are recommended. Please be aware that do–it–yourself maintenance can affect your warranty coverage. See “Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement” for the details.

the

items

listed,

General maintenance Listed below are the general maintenance items that should be performed as fre- quently as specified. In addition to check- ing if you notice any unusual noise, smell or vibration, you should investigate the cause or take your vehicle to your Toyota dealer or a quali- fied service shop immediately. It is recom- mended that any problem you notice be brought to the attention of your dealer or the qualified service shop for their advice.

CAUTION

Make these checks only where ade- quate ventilation can be obtained if you run the engine.

to

time

OUTSIDE THE VEHICLE Items listed below should be performed from time, unless otherwise specified. Tire pressure Check the pressure with a gauge every two weeks, or at least once a month. See page 194 for additional information.

in Section 7–2

for

the nuts

Tire surface and wheel nuts Check the tires carefully for cuts, damage or excessive wear. See page 195 in Sec- tion 7–2 for additional information. When checking the tires, make sure no nuts are missing, and check loose- ness. Tighten them if necessary. Fluid leaks Check underneath for leaking fuel, oil, wa- ter or other the vehicle has been parked for a while. If you smell fuel fumes or notice any leak, have the cause found and corrected immediately. Doors and trunk lid the doors operate Check smoothly and all lock securely. Make sure the trunk lid secondary latch secures the lid from opening when the primary latch is released.

that both

fluid after

latches

177

01 05 30

02 MY MR2 SMT(U) L/O 0108

Accelerator pedal Check the pedal for smooth operation and uneven pedal effort or catching. Clutch pedal Check the pedal for smooth operation. Brake pedal Check the pedal for smooth operation and that the pedal has the proper clearance. Check the brake booster function. Brakes At a safe place, check that the brakes do not pull to one side when applied. Parking brake Check that the lever has the proper travel and that, on a safe incline, your vehicle is held securely with only the parking brake applied.

INSIDE THE VEHICLE Items listed below should be checked regularly, e.g. while performing periodic services, cleaning the vehicle, etc. Lights Make sure the headlights, stop lights, tail lights, turn signal lights, and other lights are all working. Check headlight aim. Service reminder indicators and warning buzzers Check that all service reminder indicators and warning buzzers function properly. Steering wheel Be alert for changes in steering condition, such as hard steering or strange noise. Seats Check that all seat controls such as seat adjusters, seatback recliner, etc. operate smoothly and that all latches lock securely in any position. Check that the latches lock securely. Seat belts Check that the seat belt system such as buckles and retractors operate properly and smoothly. Make sure the belt webbing is not cut, frayed, worn or damaged.

178

IN THE ENGINE COMPARTMENT Items listed below should be checked from time to time, e.g. each time when refueling. Washer fluid Make sure there is sufficient fluid in the tank. See page 205 in Section 7–3 for additional information. Engine coolant level Make sure the coolant level is between the “FULL” and “LOW” lines on the see– through reservoir when the engine is cold. See page 191 in Section 7–2 for addition- al information. Radiator, condenser and hoses Check that the front of the radiator and condenser are clean and not blocked with leaves, dirt, or insects. See page 192 in Section 7–2 for additional information. Battery electrolyte level Make sure the electrolyte level of all bat- tery cells is between upper and lower lev- el lines on the case. Add only distilled water when replenishing. See pgae 202 in Section 7–3 for additional information. Brake fluid level Make sure the brake fluid level is correct. See page 193 in Section 7–2 for addition- al information.

01 05 30

Engine oil level Check the level by the dipstick with the engine turned off and the vehicle parked on a level spot. See page 190 in Section 7–2 for additional information. Power steering fluid level Check the level through the reservoir. The level should be in the “HOT” or “COLD” range depending on the fluid temperature. See page 193 in Section 7–2 for addition- al information. Exhaust system If you notice any change in the sound of the exhaust or smell exhaust fumes, have the cause located and corrected immedi- ately. (See “Engine exhaust cautions” on page 128 in Section 2.)

02 MY MR2 SMT(U) L/O 0108

tip–offs

for changes

Does your vehicle need repairing? Be on the alert in perfor- mance, sounds, and visual that indicate service is needed. Some impor- tant clues are as follows: (cid:1) Engine missing, stumbling, or pinging (cid:1) Appreciable loss of power (cid:1) Strange engine noises (cid:1) A leak under the vehicle (however, wa- ter dripping from the air conditioning after use is normal.)

(cid:1) Change

in exhaust sound (This may indicate a dangerous carbon monoxide leak. Drive with the windows open and have the exhaust system checked im- mediately.)

(cid:1) Flat–looking tire; excessive tire squeal

when cornering; uneven tire wear
