– CONTINUED – 11-67 Maintenance and service ! High beam light bulbs 1. Disconnect the electrical connector from the bulb. UGB519BA UGB520BA 2. Remove the bulb from the headlight assembly by turning it counterclockwise. 3. Replace the bulb with new one. 4. Reconnect the electrical connector. At this time, use care not to touch the bulb surface. 5. To install the bulb to the headlight assembly, turn it clockwise until it clicks. 11-68 ! Front turn signal light bulbs Maintenance and service 1. Remove the bulb socket from the headlight assem- bly by turning it counterclockwise. UGB536CA UGB531BA 2. Pull the bulb out of the socket. Install a new bulb. 3. Set the bulb socket into the headlight assembly and turn it clockwise until it locks. 4. Install the headlight assembly and the front grille in the reverse order of removal. – CONTINUED – 11-69 Maintenance and service ! Parking light ! Before removing the headlight assembly UGB523BB UGB525BA 1. Loosen four clips at the top of the front bumper. 1) Parking light The headlight assembly must be removed before the parking light bulbs can be replaced. When the head- light assembly has been removed and then rein- stalled, it may become necessary to make a headlight aiming adjustment. It may be difficult to replace the bulbs. Have your SUBARU dealer replace the bulbs if necessary. 11-70 Maintenance and service #: Clip $: Hook UGB528BA UGB529BA 2. Remove the front grille. Use a screwdriver to de- tach the four clips at the top and the two hooks on each side. – CONTINUED – 11-71 Maintenance and service ! Removal of headlight assembly 1. Remove two bolts and disconnect connectors. UGB534BA UGB551BA 2. Pull the headlight assembly toward you and re- move it from the vehicle. UGB533CA 11-72 ! Parking light bulbs Maintenance and service 1. Remove the bulb socket from the headlight assem- bly by turning it counterclockwise. UGB535BA UGB532BA 2. Pull the bulb out of the socket. Install a new bulb. 3. Set the bulb socket into the headlight assembly and turn it clockwise until it locks. 4. Install the headlight assembly and the front grille in the reverse order of removal. ! Front fog light It may be difficult to replace the bulbs. Have your SUB- ARU dealer replace the bulbs if necessary. – CONTINUED – 11-73 Maintenance and service ! Rear combination lights ! Sedan 1. Remove the clip from the rear trunk trim with a reg- ular screwdriver. UGB538BA 11-74 54 UGB539BB 1) Backup light 2) Rear turn signal light 3) Brake light 4) Tail light 5) Brake/tail light 2. Open the rear portion of the side trunk trim panel. 3. Remove the bulb holder from the rear combination light assembly by turning it counterclockwise. 4. Remove the bulb from the socket by pushing it and turning counterclockwise. Install a new bulb. 5. Set the bulb holder into the rear combination light assembly and turn it clockwise until it locks. 6. Secure the rear trunk trim panel with the clips. ! Wagon Maintenance and service 1. Using a Phillips screwdriver, remove the upper and lower screws that secure the side cover of the rear combination light assembly. UGB540BA 2. Remove the upper and lower screws. Then, slide the rear combination lamp assembly to the rear and remove it from the vehicle. UGB541BA – CONTINUED – 11-75 Maintenance and service UGB542BB 1) Tail/brake light 2) Rear turn signal light 3) Backup light 3. Remove the bulb holder from the rear combination light assembly by turning it counterclockwise. 4. Remove the bulb from the socket by pushing it and turning counterclockwise. Install a new bulb. 5. Set the bulb holder into the rear combination light assembly and turn it clockwise until it locks. 6. Close the cover and latch the lock. 7. Reinstall the rear combination light assembly and its side cover. 11-76 ! License plate light UGB543BA 1. Remove the mounting screws using a phillips screwdriver. 2. Remove the cover and lens. 3. Pull the bulb out of the socket. Install a new bulb. 4. Reinstall the lens and cover. 5. Tighten the mounting screws. ! Dome light, map light and cargo area light Maintenance and service HSB088BA UGB544BA UGB078BA 1. Remove the lens by prying the edge of the lens with – CONTINUED – 11-77 Maintenance and service a regular screwdriver. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the lens. ! High mount stop light ! Sedan ! Trunk light UGB545BA 1. Remove the cover by squeezing its sides and pull- ing it. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the cover. UGB546BA 1. Remove the high mount stop light cover by prying the edge with a screwdriver. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the cover. 11-78 ! Wagon SUBARU dealer replace these bulbs if necessary. Maintenance and service HSB091BA 1. Remove the mounting screw covers by prying the edge with a screwdriver. 2. Remove the mounting screws using a phillips screwdriver and then remove the high mount stop light cover. 3. Remove the bulbs from the socket by pushing it and turning counterclockwise. Install a new bulb. 4. Reinstall the cover. 5. Tighten the mounting screws then reinstall the cov- ers. NOTE Other bulbs may be difficult to replace. Have your – CONTINUED – 11-79 Specifications Dimensions ....................................................... Engine ................................................................ Electrical system .............................................. Capacities .......................................................... Tires ................................................................... Wheel alignment ............................................... Specifications ................................................ 12-2 12-2 12-3 12-3 12-4 12-5 12-5 Fuses and circuits ........................................ 12-6 12-6 Fuse panel located behind the coin tray ....... Fuse panel located in the engine compartment 12-8 Bulb chart ...................................................... 12-9 Vehicle identification .................................... 12-10 12 12-1 Specifications SpecificationsSpecifications These specifications are subject to change without notice. ! Dimensions Item 2.5-liter RS Sedan 2.0-liter (Turbo) WRX 2.5-liter (Turbo) WRX-STi Wagon 2.5-liter 2.0-liter (Turbo) in (mm) TS OUTBACK SPORT WRX Drive system Transmission type Overall length Overall width Sedan Wagon Overall height Without roofrail With roofrail Wheel base Tread Front Rear AT MT AT MT MT AWD AT 173.8 (4415) MT AT MT AT MT 68.5 (1740) – 56.7 (1440) – 99.4 (2525) 58.5 (1485) 58.1 (1475) 58.3 (1480) 66.7 (1695) 57.7 (1465) 58.5 (1485) – 67.3 (1710) 58.1 (1475) 58.9 (1495) 99.4 (2525) 66.7 (1695) 57.7 (1465) 58.5 (1485) 57.7 (1465) 57.5 (1460) 57.7 (1465) 57.3 (1455) 5.9 (150) 6.3 (160) 6.1 (155) 56.3 (1430) 100 (2540) 58.7 (1490) 58.5 (1485) 5.7 (145) Ground clearance*1 5.9 (150) 6.1 (155) *1: Measured with vehicle empty AT: Automatic transmission MT: Manual transmission 12-2 ! Engine Engine model Engine type Displacement cu in. (cc) Bore × Stroke in. (mm) Compression ratio Firing order ! Electrical system MT Battery type and capacity (5HR) AT Alternator Spark plugs AT: Automatic transmission MT: Manual transmission Specifications EJ251(2.5-liter, SOHC, EJ205 (2.0-liter, DOHC, turbo) EJ257 (2.5-liter, DOHC, turbo) non-turbo) Horizontally opposed, liquid cooled 4 cylinder, 4-stroke gasoline engine 150 (2,457) 122 (1,994) 150 (2,457) 3.9 × 3.1 (99.5 × 79.0) 3.6 × 2.9 (92.0 × 75.0) 3.9 × 3.1 (99.5 × 79.0) 10.0 : 1 8.0 : 1 1 – 3 – 2 – 4 8.2 : 1 With 2.5-liter engine With 2.0-liter turbo engine 2.5-liter and 2.0-liter turbo engine 2.5-liter turbo engine 2.5-liter engine 2.0-liter turbo engine 2.5-liter turbo engine 12V-48AH (55D23L) 12V-52AH (75D23L) 12V-52AH (65D23L) 12V – 75A 12V – 90A RC10YC4 (Champion) BKR6E-11 (NGK) BKR5E-11 (NGK) PFR6G (NGK) IFLR6B (NGK) – CONTINUED – 12-3 2.5-liter engine model 2.0-liter turbo engine model 2.5-liter turbo engine model 5 speed 6 speed 2.5-liter engine model 2.0-liter turbo engine model 2.5-liter turbo engine model MT AT MT AT MT 15.9 US gal (60 liters, 13.2 Imp gal) 4.2 US qt (4.0 liters, 3.5 Imp qt) 4.8 US qt (4.5 liters, 4.0 Imp qt) 3.7 US qt (3.5 liters, 3.1 Imp qt) 4.3 US qt (4.1 liters, 3.6 Imp qt) 10.0 US qt (9.5 liters, 8.4 Imp qt) 0.7 US qt (0.7 liter, 0.6 Imp qt) 7.4 US qt (7.0 liters, 6.2 Imp qt) 7.3 US qt (6.9 liters, 6.1 Imp qt) 8.1 US qt (7.7 liters, 6.8 Imp qt) 8.0 US qt (7.6 liters, 6.7 Imp qt) 8.1 US qt (7.7 liters, 6.8 Imp qt) Specifications ! Capacities Fuel tank Engine oil Transmission oil (MT) Transmission oil (AT) Power steering gear fluid Engine coolant AT: Automatic transmission MT: Manual transmission 12-4 ! Tires Tire size Wheel size Pressure Front Rear Temporary spare tire Size Pressure ! Wheel alignment Specifications P195/60R15 87H P205/55R16 89V 215/45R17 87W 225/45R17 90W 15 × 6 JJ 32 psi (220 kPa, 2.2 kg/cm2) 16 × 61/2 JJ 29 psi (200 kPa, 2.0 kg/cm2) 17 × 7 JJ 33 psi (230 kPa, 2.3 kg/cm2) 32 psi (220 kPa, 2.2 kg/cm2) T135/70 D16 60 psi (420 kPa, 4.2 kg/cm2) 17 × 71/2 JJ 36 psi (250 kPa, 2.5 kg/cm2) 30 psi (210 kPa, 2.1 kg/cm2) T135/70 D17 Item Sedan Wagon 2.5-liter non- turbo RS 2.0-liter turbo 2.5-liter turbo 2.5-liter non-turbo 2.0-liter turbo WRX WRX-STi TS OUTBACK SPORT WRX Drive system Toe Camber Front Rear Front Rear AWD 0 mm (0 in) 0 mm (0 in) −0°15’ −1°25’ −0°25’ −1°30’ −0°30’ −1°40’ −0°10’ −1°15’ −0°05’ −1°10’ −0°20’ −1°20’ – CONTINUED – 12-5 Specifications Fuses and circuits ! Fuse panel located behind the coin tray 10 11 12 13 14 15 16 17 18 19 20 21 22 23 HSC001BB 12-6 Fuse panel Fuse rating Circuit 10 11 15A 15A 15A 20A 10A 15A 15A 20A 15A Empty 15A " Heater fan " Heater fan " Power door lock " Remote keyless entry " Cigarette lighter " Remote controlled rear view mirrors " Tail light " Parking light " SRS airbag " Fog light " ABS solenoid " Radio " Engine ignition system " SRS airbag " AT control system Fuse panel Fuse rating Circuit Fuse panel Fuse rating Circuit Specifications 23 20A 12 13 14 15 16 17 18 19 20 21 22 10A 10A 10A 30A 20A 15A 15A 20A Empty Empty 10A " Illumination brightness control " Combination meter " SRS lamp " Rear window wiper and washer " Windshield wiper and washer " Brake light " Air conditioner " Backup light " Cruise control " Mirror heater " ABS ignition " Accessory power outlet (cargo) " Seat heater – CONTINUED – 12-7 Specifications ! Fuse panel located in the engine com- partment 9 10 11 12 6 7 8 1 2 HSC002BB A) FWD socket (AT models except Turbo) B) Main fuse 12-8 Fuse panel Fuse rating Circuit 10 11 12 20A 20A 30A 20A 15A 15A 10A 10A 15A 15A 20A 15A " Radiator cooling fan (Main) " Radiator cooling fan (Sub) " ABS motor " Rear window defogger " Hazard warning flasher " Horn " Turn signal lights " Automatic transmis- sion control unit " Alternator " Headlight (right side) " Headlight (left side) " Lighting switch " Clock " Interior light Bulb chart Description Headlight U.S. spec. WRX- STi version Low beam High beam Except U.S. spec. WRX-STi version Low beam High beam Front fog light Front turn signal Parking light Rear combination light Wattage Bulb type 12V-35W 12V-60W D2R 9005 (HB3) 12V-55W 12V-60W 12V-55W 12V-21W 12V-5W H1 9005 (HB3) H3 — 168 Description High mount stop light Sedan (in compartment) Sedan (in rear spoiler) Wagon License plate light Trunk room light Cargo area light Front ashtray light Dome light Map light Brake light (sedan) 12V-21W Brake/tail light Turn signal light 12V-21/5W 12V-21W (Amber) 12V-21/5W 12V-21W 7440 7443 — 7443 7440 Tail light (sedan) Back-up light Specifications Wattage Bulb type 12V-18W 921 12V-1.2W 12V-13W 12V-5W 12V-16W 12V-13W 12V-1.4W 12V-8W 12V-8W — 912 168 W16W — — — — – CONTINUED – 12-9 1) Vehicle identification number 2) Vacuum hose connections la- bel/Emission control label 3) Tire inflation pressure label 4) Certification plate 5) Bar cord label (USA only) 6) Vehicle identification number plate 7) Model number plate Specifications Vehicle identification UGC010BB 12-10 Consumer information and Reporting safety defects Uniform tire quality grading standards ....... 13-2 13-2 13-2 13-3 Reporting safety defects (USA) ................... 13-4 Treadwear .......................................................... Traction AA, A, B, C .......................................... Temperature A, B, C ......................................... 13 13-1 Consumer information and Reporting safety defects Consumer information and Reporting safety defects For U.S.A. The following information has been compiled accord- ing to Code of Federal Regulations “Title 49, Part 575”. Uniform tire quality grading stan- dards This information indicates the relative performance of passenger car tires in the area of treadwear, traction, and temperature resistance. This is to aid the consum- er in making an informed choice in the purchase of tires. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A The quality grades apply to new pneumatic tires for use on passenger cars. However, they do not apply to deep tread, winter type snow tires, space-saver or temporary use spare tires, tires with nominal rim diam- eters of 12 inches or less, or to some limited produc- tion tires. All passenger car tires must confirm to Federal Safety 13-2 Requirements in addition to these grades. ! Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1-1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service prac- tices and differences in road characteristics and cli- mate. ! Traction AA, A, B, C The traction grades, from highest to lowest, are AA, A, B and C. Those grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance. The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hy- droplaning, or peak traction characteristics. sible tire failure. Consumer information and Reporting safety defects ! Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure. The grade C corresponds to a level of perfor- mance which all passenger car tires must meet under the Federal Motor Vehicle Safety Standards No. 109. Grades B and A represent higher levels of perfor- mance on the laboratory test wheel than the minimum required by law. The temperature grade for this tire is estab- lished for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and pos- – CONTINUED – 13-3 Consumer information and Reporting safety defects Reporting safety defects (USA) If you believe that your vehicle has a defect which could cause a crash or could cause in- jury or death, you should immediately inform the National Highway Traffic Safety Admin- istration (NHTSA) in addition to notifying Subaru of America, Inc. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Subaru of America, Inc. To con- tact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington D.C. area) or write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline. 13-4 Index 14 14-1 Index ABS (Anti-lock Brake System) ............................... 7-30 Warning light ................................................. 3-23, 7-31 Accessories ......................................................... 5-3, 11-63 Accessory power outlet ................................... 6-9, 6-11 1-6 Active head restraint .................................................. Air cleaner element ..................................................... 11-23 Air conditioner operation .......................................... 4-9 4-20 Air filtration system ..................................................... Air flow selection .......................................................... 4-2 Aluminum wheels ........................................................ 11-53 Ambient temperature gauge ......................... 3-11, 3-18 5-2 Antenna system ........................................................... Anti-lock Brake System (ABS) ............................... 7-30 Arming the system ...................................................... 2-15 1-9 Armrest ............................................................................ Ashtray ............................................................................. 6-12 AT OIL TEMPerature warning light ...................... 3-22 5-3 Audio set ......................................................................... Auto-dimming mirror /compass ............................. 3-44 Automatic/Emergency Locking Retractor 1-15 (A/ELR) ....................................................................... Automatic transmission ............................................. 7-21 Capacities ................................................................. 12-4 Fluid ............................................................................ 11-31 Selector lever .......................................................... 7-22 Shift lock release ................................................... 7-26 14-2 Temperature warning light ................................. 3-22 Brake Battery ............................................................................... 11-58 Jump starting ........................................................... 9-14 Replacement (Remote keyless entry system) .................................................................... 2-9 Booster ....................................................................... 11-40 Fluid ............................................................................. 11-37 Pad and lining .......................................................... 11-42 Pedal ........................................................................... 11-40 Brake system ................................................................. 7-29 Warning light ............................................................ 3-24 Braking .............................................................................. 7-28 Breaking-in of new brake pads and linings . 11-43 Tips .............................................................................. 7-28 Brake pedal Bulb Free play .................................................................... 11-40 Reserve distance ................................................... 11-41 Chart ............................................................................ 12-9 Replacing ................................................................... 11-64 Capacities ........................................................................ 12-4 Cargo 6-15 Area cover ................................................................ Area light ......................................................... 6-2, 11-77 Tie-down hooks ...................................................... 6-17 8-4 Catalytic converter ...................................................... Center Console ..................................................................... Ventilators ................................................................. Visor ............................................................................ 6-6 4-3 6-4 Flat tire ....................................................................... 9-5 Oil and oil filter ........................................................ 11-12 3-21 Charge warning light .................................................. CHECK ENGINE warning light/ Malfunction indicator lamp .................................. 3-20 Changing Checking Brake pedal free play ........................................... 11-40 Brake pedal reserve distance ........................... 11-41 Clutch function ........................................................ 11-41 Clutch pedal free play .......................................... 11-42 Engine oil level ....................................................... 11-11 Fluid level ....................... 11-31, 11-36, 11-37, 11-38 Gear oil level ................................ 11-28, 11-33, 11-34 Child restraint systems ............................................... 1-31 1-35 1-42 Installation with seatbelt ..................................... Lower and tether anchorages .......................... Child safety .................................................................... Index 2-21 Locks .......................................................................... Chime Key .............................................................................. 3-4 Seatbelt ........................................................... 1-15, 3-19 6-10 Cigarette lighter socket ............................................. Cleaning Aluminum wheels .................................................. Interior ........................................................................ Ventilator grille ........................................................ 10-3 10-6 4-19 Climate control system Manual ....................................................................... 4-4 4-11 Semi-automatic ...................................................... Clock ................................................................................. 3-28 Clutch fluid ...................................................................... 11-38 Clutch pedal ................................................................... 11-41 Coat hook ....................................................................... 6-14 Coin tray .......................................................................... 6-7 Cooling system ............................................................. 11-18 Corrosion protection ......................................... 8-14, 10-4 Cruise control ................................................................ 7-37 3-26 Indicator light ........................................................... Set indicator light ................................................... 3-26 Cup holder ...................................................................... 6-7 Daytime running light system ................................. Differential gear oil 3-31 14-3 Index Front ........................................................................... 11-33 Rear ............................................................................ 11-34 Dimensions .................................................................... 12-2 Disarming the system ................................................ 2-17 7-29 Disc brake pad wear warning indicators ............ Dome light ............................................................ 6-2, 11-77 Door locks ....................................................................... 2-3 3-25 Door open warning lights ......................................... Drive belts ....................................................................... 11-27 Driver’s control center differential ........................ 7-18 Auto indicator light ................................................ 3-26 3-27 Indicator light .......................................................... Driving Drinking ..................................................................... Drugs .......................................................................... Foreign countries .................................................. 8-6 Mobile phone .......................................................... 10 10 Pets ............................................................................. Tips ........................................................... 7-14, 7-17, 8-7 Tired or sleepy ........................................................ 8-13 Snowy and icy roads ............................................ EBD (Electronic brake force distribution) system ......................................................................... Electrical system .......................................................... 7-32 12-3 14-4 Electronic Brake force Distribution (EBD) system .......................................................................... 7-32 Emergency Locking Retractor (ELR) ................... 1-14 Engine Compartment overview ........................................ 11-8 Coolant ....................................................................... 11-19 Exhaust gas (Carbon monoxide) ..................... 8, 8-3 Hood ............................................................................ 11-5 Oil ................................................................................. 11-11 Overheating .............................................................. 9-16 Starting ....................................................................... 7-9 Stopping ..................................................................... 7-11 Exterior care ................................................................... 10-2 Flat tires ............................................................................ 9-5 Floor mat .......................................................................... 6-13 Fluid level Automatic transmission ....................................... 11-31 Brake ........................................................................... 11-37 Clutch .......................................................................... 11-38 Power steering ........................................................ 11-36 Fog light switch ............................................................. 3-35 Folding down the rear seat ....................................... 1-12 Front Differential gear oil ................................................. 11-33 Fog light ..................................................................... 11-73 1-27 Seatbelt pretensioners ....................................... 1-2 Seats ........................................................................... Turn signal light and parking light ................... 11-70 Front-wheel drive warning light .............................. 3-25 7-2 Fuel .................................................................................... Economy hints ........................................................ 8-2 Filler lid and cap ..................................................... 7-4 Gauge .................................................................. 3-9, 3-16 Requirements .......................................................... 7-2 Fuses ................................................................................ 11-60 Fuses and circuits ....................................................... 12-6 GAWR (Gross Axle Weight Rating) ..................... Glove box ........................................................................ GVWR (Gross Vehicle Weight Rating ) ............. 8-20 6-6 8-20 Hazard warning flasher ............................................. 3-6 Headlight beam leveler ............................................. 3-33 Headlight indicator light ............................................ 3-27 Headlights ......................................................... 3-29, 11-66 Headrest adjustment (Wagon) .............................. 1-11 Head restraint adjustment (Front) ....................... 1-5 4-6 Heater operation .......................................................... High beam indicator light .......................................... 3-26 High mount stop light ................................................. 11-78 Index Horn .................................................................................. 3-50 Hose and connections ............................................... 11-19 Ignition switch ............................................................... Illuminated entry ........................................................... Illumination brightness control ............................... Indicator light 3-3 2-8 3-32 High beam ................................................................ 3-26 Selector lever position ......................................... 3-26 3-26 Turn signal ............................................................... Inside mirror ................................................................... 3-44 Intercooler water spray ............................................. 11-53 3-25 3-43 2-26 Warning light ........................................................... Switch ........................................................................ Internal trunk lid release handle ............................ Jack and jack handle ................................................. Jump starting ................................................................. 9-24 9-14 Key Interlock release .................................................... Number ...................................................................... Reminder chime ..................................................... 3-5 2-3 3-4 14-5 Index Keys .................................................................................. 2-2 Leather seat materials ............................................... Light control switch ..................................................... Limited slip differential (LSD) ................................. Loading your vehicle .................................................. LSD (Limited slip differential) ................................. 10-6 3-29 7-27 8-17 7-27 Main fuse ........................................................................ 11-63 Maintenance Precautions .............................................................. Schedule ................................................................... Seatbelt ..................................................................... Tools ........................................................................... Manual climate control system .............................. Manual transmission 11-3 11-3 1-27 9-24 4-4 5 speed ..................................................................... 6 speed ..................................................................... 7-15 7-12 Manual transmission oil ............................................ 11-28 Map light ................................................................ 6-3, 11-77 Maximum load limits .................................................. 8-29 Meters and gauges .............................................. 3-7, 3-15 3-44 Mirrors .............................................................................. Moonroof .............................................................. 2-31, 9-23 14-6 New vehicle break-in driving – the first 1,000 miles (1,600 km) ........................ 8-2 Odometer/Trip meter .......................................... 3-8, 3-15 Off road driving .............................................................. 8-8 Oil pressure warning light ......................................... 3-21 Oil filter .............................................................................. 11-12 Oil level Engine ......................................................................... 11-11 Manual transmission ............................................. 11-28 Rear differential ...................................................... 11-34 Outside mirrors .............................................................. 3-47 Overheating engine ..................................................... 9-16 Parking Power Brake ........................................................................... 7-34 Brake stroke ............................................................. 11-44 Light switch ............................................................... 3-34 Tips .............................................................................. 7-35 Door locking switches .......................................... 2-5 Steering ...................................................................... 7-28 Steering fluid ............................................................ 11-36 Windows .................................................................... Printed antenna ............................................................ 2-22 5-2 Rear Combination lights ................................................ 11-74 Differential gear oil ................................................ 11-34 Differential oil temperature warning light ..... 3-22 Gate ............................................................................ 2-29 Seats ........................................................................... 1-8 Rear seat Rear window Folding down (Wagon) ........................................ Defogger switch ..................................................... Wiper and washer switch ................................... 1-12 3-40 3-39 Recommended Automatic transmission fluid ............................. 11-32 Brake fluid ................................................................. 11-37 Clutch fluid ................................................................ 11-39 OIL grade and viscosity ......... 11-16, 11-18, 11-30, 11-33, 11-35 Power steering fluid .............................................. 11-37 Spark plugs .............................................................. 11-26 2-6 Remote keyless entry system ................................ Replacement Brake pad and lining ............................................ 11-42 Windshield wiper blades ..................................... 11-55 Index Replacing Air cleaner element .............................................. 11-23 Battery (remote keyless entry system) ......... 2-9 Lost transmitters (keyless entry system) ..... 2-10 Replacing bulbs ............................................................ 11-64 Cargo area light ..................................................... 11-77 Dome light ................................................................ 11-77 Front fog light .......................................................... 11-73 Front turn signal light ........................................... 11-69 Headlight ................................................................... 11-66 High mount stop light ........................................... 11-78 License plate light ................................................. 11-76 Map light .................................................................... 11-77 Parking light ............................................................. 11-70 Rear combination light ........................................ 11-74 Trunk light ................................................................. 11-78 3-12 8-16 8-21 REV indicator light and buzzer .............................. Rocking the vehicle .................................................... Roof rail and crossbar ............................................... Seat Fabric ......................................................................... Heater ........................................................................ Seatbelt ............................................................................ Maintenance ............................................................ Pretensioners .......................................................... 10-6 1-7 1-27 1-27 14-7 Index Safety tips ................................................................. 1-13 Warning light and chime ........................... 1-15, 3-19 Seatbelts ......................................................................... 1-13 Security system ............................................................ 2-14 7-22 Selector lever ................................................................ Position indicator ................................................... 3-26 Semi-automatic climate control system ............. 4-11 7-26 Shift lock release ......................................................... Side ventilators ............................................................. 4-3 Snow tires ....................................................................... 8-14 Sounding a panic alarm ............................................ 2-9 Spark plugs .................................................................... 11-26 Specifications ................................................................ 12-2 Speedometer .......................................................... 3-7, 3-15 SRS airbag (Supplemental Restraint System airbag) ....................................................... 6, 1-52 3-20 1-56 1-64 7-9 7-7 7-11 6-5 6-4 2-33 1-52 10-6 SRS airbag system warning light .......................... SRS frontal airbag ....................................................... SRS side airbag ........................................................... Starting the engine ...................................................... State emission testing (U.S. only) ........................ Stopping the engine ................................................... Storage compartments .............................................. Sun visors ....................................................................... Sun shades .................................................................... Supplemental Restraint System airbag (SRS) Synthetic leather upholstery ................................... 14-8 Tachometer ............................................................. 3-9, 3-16 Temperature gauge .......................................... 3-10, 3-17 Temporary spare tire .................................................. 9-3 Tie-down hooks ............................................................. 9-18 Tilt steering wheel ........................................................ 3-49 Tire Chains ......................................................................... 8-16 Inspection .................................................................. 11-45 Pressures and wear .............................................. 11-45 Replacement ............................................................ 11-50 Rotation ...................................................................... 11-50 Tires ................................................................................... 12-5 Types .......................................................................... 11-44 Tires and wheels .......................................................... 11-44 Top tether anchorages ............................................... 1-46 Towing .............................................................................. 9-17 All wheels on the ground .................................... 9-21 Flat-bed truck ........................................................... 9-20 Hitch ............................................................................. 8-25 Hitches ........................................................................ 8-34 Towing ........................................................................ 8-29 Towing tips ................................................................ 8-37 Trunk lid ............................................................................ 2-25 Release handle ....................................................... 2-26 Trunk light ........................................................................ 11-78 Trailer 3-26 3-31 6-18 2-17 6-5 Turn signal Indicator lights ......................................................... Lever ........................................................................... Under-floor storage compartment ........................ Valet mode ..................................................................... Vanity mirror .................................................................. Vehicle Capacity weight ...................................................... 8-19 Identification ............................................................ 12-10 Symbols ..................................................................... Ventilator ......................................................................... 4-2 Warning and indicator lights .................................... Warning lights ABS ............................................................................. Anti-lock Brake system ....................................... AT OIL TEMPerature ........................................... Brake system .......................................................... Charge ....................................................................... CHECK ENGINE ................................................... Door open ................................................................. 3-19 3-23 3-23 3-22 3-24 3-21 3-20 3-25 Index 3-25 Front-wheel drive ................................................... 3-21 Oil pressure ............................................................. R.Diff TEMPerature ............................................. 3-22 Seatbelt ........................................................... 1-15, 3-19 3-20 SRS airbag system ............................................... Warranties and maintenance ................................. 8-29 Washing ........................................................................... 10-2 10-3 Waxing and polishing ................................................. Wear indicators ............................................................ 11-49 Wheel Alignment .................................................................. 12-5 Balance ...................................................................... 11-48 Covers ........................................................................ 11-52 Replacement ........................................................... 11-51 2-22 Windows .......................................................................... Windshield Washer fluid ............................................................. 11-54 3-37 Wiper and washer switches .............................. Wiper deicer ............................................................ 3-42 Winter driving ................................................................ 8-11 3-35 Wiper and washer ....................................................... 14-9 3 13 12 11 10 HSF028AA GAS STATION REFERENCE Fuel: ! 2.5 Liter models Use only unleaded gasoline with an octane rat- ing of 87 AKI or higher. ! 2.0 Liter (Turbo) models Use premium unleaded gasoline with an oc- tane rating of 91 AKI or higher. If premium un- leaded gasoline is not available, regular un- leaded gasoline with octane rating of 87 AKI or higher may be temporarily used. For optimum engine performance and driveability, it is rec- ommended that you use premium grade un- leaded gasoline. ! 2.5 Liter (Turbo) models Use premium unleaded gasoline with an oc- tane rating of 94 AKI or higher. If premium un- leaded gasoline with an octane rating of 93 AKI is not available, premium unleaded gasoline with octane rating of 91 AKI or higher may be temporarily used. For optimum engine perfor- mance and driveability, it is recommended that you use premium grade unleaded gasoline with an octane rating of 93 AKI or higher. ! Fuel octane rating This octane rating is the average of the Re- search Octane and Motor Octane numbers and is commonly referred to as the Anti Knock In- dex (AKI). Refer to “Fuel” section in this manu- al. Fuel capacity: 15.9 US gal (60 liters, 13.2 Imp gal) Engine oil: Use only API classification SL with the words “ENERGY CONSERVING” and the New API certification mark (starburst mark) displayed on the container. Engine oil capacity: Non turbo models: 4.2 US qt (4.0 liters, 3.5 Imp qt) Turbo models: 4.8 US qt (4.5 liters, 4.0 Imp qt) Cold tire pressure: See the label located under the driver’s door latch. Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Man- ual has all the information necessary to keep your SUBARU in excel- lent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation. For information not found in this Owner’s Manual, such as details concerning repairs or adjustments, please contact the dealer from whom you purchased your SUBARU or the nearest SUBARU dealer. The information, specifications and illustrations found in this manual are those in effect at the time of printing. FUJI HEAVY INDUSTRIES LTD. reserves the right to change specifications and designs at any time without prior notice and without incurring any obligation to make the same or similar changes on vehicles previously sold. This Owner’s Manual applies to all models and covers all equipment, in- cluding factory installed options. Some explanations, therefore may be for equipment not installed in your vehicle. Please leave this manual in the vehicle at the time of resale. The next owner will need the information found herein. FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN and are registered trademarks of FUJI HEAVY INDUSTRIES, LTD. © copyright 2002 FUJI HEAVY INDUSTRIES LTD. This manual describes the following vehicle types. Sedan Wagon and OUTBACK SPORT UGF053AA UGF055AA Warranties ! Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of Ameri- ca, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: " SUBARU Limited Warranty " Emission Control Systems Warranty " Emissions Performance Warranty All warranty information, including details of coverage and exclusions, is in the “Warranty and Maintenance Booklet”. Please read these warranties carefully. ! Warranties for Canada All SUBARU vehicles distributed by Subaru Canada, Inc. and sold at retail by an authorized SUBARU deal- er in Canada come with the following warranties: " SUBARU Limited Warranty " Anti-Corrosion Warranty " Emission Control Warranty All warranty information, including details of coverage and exclusions, is in the Warranty and Service Book- let. Please read these warranties carefully. ! WRX-STi (U.S. model only) WRX-STi models are equipped with High Intensity Discharge (HID) headlights that contain mercury. For that reason, it is necessary to remove HID headlights before vehicle disposal. Once re- moved, please reuse, recycle or dispose of the HID headlights as hazardous waste. ! All models except U.S. model WRX-STi This vehicle does not contain mercury devices or parts. – CONTINUED – How to use this owner’s manual ! Using your Owner’s manual Before you operate your vehicle, carefully read this manual. To protect yourself and extend the service life of your vehicle, follow the instructions in this manual. Failure to observe these instructions may result in se- rious injury and damage to your vehicle. This manual is composed of fourteen chapters. Each chapter begins with a brief table of contents, so you can usually tell at a glance if that chapter contains the information you want. Chapter 1: Seat, seatbelt and SRS airbags This chapter informs you how to use the seat and seat- belt and contains precautions for the SRS airbags. Chapter 2: Keys and doors This chapter informs you how to operate the keys, locks and windows. Chapter 3: Instruments and controls This chapter informs you about the operation of instru- ment panel indicators and how to use the instruments and other switches. Chapter 4: Climate Control This chapter informs you how to operate the climate control. Chapter 5: Audio This chapter informs you how to operate your audio system. Chapter 6: Interior equipment This chapter informs you how to operate interior equipment. Chapter 7: Starting and operating This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various conditions and explains some safety tips on driving. Chapter 9: In case of emergency This chapter informs you what to do if you have a prob- lem while driving, such as a flat tire or engine over- heating. Chapter 10: Appearance care This chapter informs you how to keep your SUBARU looking good. Chapter 11: Maintenance and service This chapter informs you when you need to take your SUBARU to the dealer for scheduled maintenance and informs you how to keep your SUBARU running properly. Chapter 12: Specifications This chapter informs you about dimension and capac- ities of your SUBARU. Chapter 13: Consumer information and Reporting safety defects This chapter informs you about Uniform tire quality grading standards and Reporting safety defects. Chapter 14: Index This is an alphabetical listing of all that’s in this manu- al. You can use it to quickly find something you want to read. ! Safety warnings You will find a number of WARNINGs, CAUTIONs and NOTEs in this manual. These safety warnings alert you to potential hazards that could result in injury to you or others. Please read these safety warnings as well as all other portions of this manual carefully in order to gain a bet- ter understanding of how to use your SUBARU vehicle safely. A WARNING indicates a situation in which seri- ous injury or death could result if the warning is ignored. A CAUTION indicates a situation in which injury or damage to your vehicle, or both, could result if the caution is ignored. NOTE A NOTE gives information or suggestions how to make better use of your vehicle. ! Safety symbol HSF019AA You will find a circle with a slash through it in this man- – CONTINUED – ual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context. Vehicle symbols There are some of the symbols you may see on your vehicle. Mark Name CAUTION Power door lock and unlock Passenger’s windows lock and un- lock Fuel Front fog lights Parking lights Hazard warning flasher Cigarette lighter Mark Name Mark Name Engine hood Trunk lid (Sedan) Seat heater Rear window wiper and washer Lights Parking lights, tail lights, license plate light and instrument panel illumination Child restraint top tether anchorages Head lights Child restraint lower anchorages Illumination brightness Horn Windshield wiper deicer Wiper intermittent Windshield wiper and washer Fan speed Instrument panel outlets Instrument panel outlets and foot out- lets Foot outlets Windshield defroster and foot outlets – CONTINUED – Mark Name Windshield defroster Rear window defogger/Outside mirror defogger Air recirculation Outside air Engine oil Washer Safety precautions when driving ! Seatbelt and SRS airbag " All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Otherwise, the possibility of serious injury be- comes greater in the event of a sudden stop or accident. " To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seatbelts when the vehicle is moving. The SRS (Supplemental Re- straint System) airbag does not do away with the need to fasten seatbelts. In combination with the seatbelts, it offers the best combined protection in case of a serious accident. Not wearing a seatbelt increases the chance of severe injury or death in a crash even when the car has the SRS airbag. " The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS airbag needs enough space for deploy- ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full ve- hicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat. Carefully read the sections “Seatbelts” and “*SRS air- bag (Supplemental Restraint System airbag)” in chap- ter 1 of this owner’s manual for instructions and pre- cautions concerning the seatbelt system and SRS air- bag system. ! Child safety " Never hold a child on your lap or in your arms while the vehicle is moving. The passenger cannot protect the child from injury in a colli- sion, because the child will be caught between the passenger and objects inside the vehicle. " While riding in the vehicle, infants and small children should always be placed in the REAR seat in an infant or child restraint system which is appropriate for the child’s age, height and weight. If a child is too big for a child restraint system, the child should sit in the REAR seat and be restrained using the seatbelts. Accord- ing to accident statistics, children are safer when properly restrained in the rear seating po- sitions than in the front seating positions. Nev- er allow a child to stand up or kneel on the seat. " Put children aged 12 and under in the REAR seat properly restrained at all times in a child restraint device or in a seatbelt. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained. Because children are lighter and weaker than adults, their risk being injured from deployment is greater. " NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. " Always use the child safety locks whenever a child rides in the rear seat. Serious injury could result if a child accidentally opened the door and fell out. Refer to the “Child safety locks”
