They’ll be ready and willing to help if you need it.


Here are some things you can check before a trip: D Windshield Washer Fluid: Is the reservoir full?


Are all windows clean inside and outside?


D Wiper Blades: Are they in good shape? D Fuel, Engine Oil, Other Fluids: Have you checked


all levels?


D Lamps: Are they all working? Are the lenses clean? D Tires: They are vitally important to a safe,


trouble-free trip. Is the tread good enough for long-distance driving? Are the tires all inflated to the recommended pressure?


D Weather Forecasts: What’s the weather outlook


along your route? Should you delay your trip a short time to avoid a major storm system? D Maps: Do you have up-to-date maps?


4-23


Hill and Mountain Roads


Driving on steep hills or mountains is different from driving in flat or rolling terrain.


Highway Hypnosis Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy. Don’t let it happen to you! If it does, your vehicle can leave the road in less than a second, and you could crash and be injured. What can you do about highway hypnosis? First, be aware that it can happen. Then here are some tips: D Make sure your vehicle is well ventilated, with a


comfortably cool interior.


D Keep your eyes moving. Scan the road ahead and to


the sides. Check your rearview mirrors and your instruments frequently.


D If you get sleepy, pull off the road into a rest, service or parking area and take a nap, get some exercise, or both. For safety, treat drowsiness on the highway as an emergency.


4-24


If you drive regularly in steep country, or if you’re planning to visit there, here are some tips that can make your trips safer and more enjoyable. D Keep your vehicle in good shape. Check all fluid


levels and also the brakes, tires, cooling system and transmission. These parts can work hard on mountain roads.


D Know how to go down hills. The most important


thing to know is this: let your engine do some of the slowing down. Shift to a lower gear when you go down a steep or long hill.


CAUTION:


If you don’t shift down, your brakes could get so hot that they wouldn’t work well. You would then have poor braking or even none going down a hill. You could crash. Shift down to let your engine assist your brakes on a steep downhill slope.


CAUTION:


Coasting downhill in NEUTRAL (N) or with the ignition off is dangerous. Your brakes will have to do all the work of slowing down. They could get so hot that they wouldn’t work well. You would then have poor braking or even none going down a hill. You could crash. Always have your engine running and your vehicle in gear when you go downhill.


D Know how to go uphill. You may want to shift down


to a lower gear. The lower gears help cool your engine and transmission, and you can climb the hill better. D Stay in your own lane when driving on two-lane roads in hills or mountains. Don’t swing wide or cut across the center of the road. Drive at speeds that let you stay in your own lane.


D As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident. D You may see highway signs on mountains that warn of special problems. Examples are long grades, passing or no-passing zones, a falling rocks area or winding roads. Be alert to these and take appropriate action.


4-25


Winter Driving


Here are some tips for winter driving: D Have your vehicle in good shape for winter. D You may want to put winter emergency supplies in


your vehicle.


Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth and a couple of reflective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet or a couple of burlap bags to help provide traction. Be sure you properly secure these items in your vehicle.


4-26


Driving on Snow or Ice Most of the time, those places where your tires meet the road probably have good traction. However, if there is snow or ice between your tires and the road, you can have a very slippery situation. You’ll have a lot less traction or “grip” and will need to be very careful.


What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get wet ice when it’s about freezing (32_F; 0_C) and freezing rain begins to fall. Try to avoid driving on wet ice until salt and sand crews can get there. Whatever the condition -- smooth ice, packed, blowing or loose snow -- drive with caution. If you have traction control, keep the system on. It will improve your ability to accelerate when driving on a slippery road. Even though your vehicle has a traction control system, you’ll want to slow down and adjust your driving to the road conditions. See “Traction Control System” in the Index. If you don’t have the traction control system, accelerate gently. Try not to break the fragile traction. If you accelerate too fast, the drive wheels will spin and polish the surface under the tires even more.


4-27


Your anti-lock brakes improve your vehicle’s stability when you make a hard stop on a slippery road. Even though you have the anti-lock braking system, you’ll want to begin stopping sooner than you would on dry pavement. See “Anti-Lock” in the Index. D Allow greater following distance on any


slippery road.


D Watch for slippery spots. The road might be fine until you hit a spot that’s covered with ice. On an otherwise clear road, ice patches may appear in shaded areas where the sun can’t reach: around clumps of trees, behind buildings or under bridges. Sometimes the surface of a curve or an overpass may remain icy when the surrounding roads are clear. If you see a patch of ice ahead of you, brake before you are on it. Try not to brake while you’re actually on the ice, and avoid sudden steering maneuvers.


4-28


If You’re Caught in a Blizzard


If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow. Here are some things to do to summon help and keep yourself and your passengers safe: D Turn on your hazard flashers.


D Tie a red cloth to your vehicle to alert police that


you’ve been stopped by the snow.


D Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats -- anything you can wrap around yourself or tuck under your clothing to keep warm.


You can run the engine to keep warm, but be careful.


CAUTION:


Snow can trap exhaust gases under your vehicle. This can cause deadly CO (carbon monoxide) gas to get inside. CO could overcome you and kill you. You can’t see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that is blocking your exhaust pipe. And check around again from time to time to be sure snow doesn’t collect there. Open a window just a little on the side of the vehicle that’s away from the wind. This will help keep CO out.


Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged. You will need a well-charged battery to restart the vehicle, and possibly for signaling later on with your headlamps. Let the heater run for a while.


4-29


Then, shut the engine off and close the window almost all the way to preserve the heat. Start the engine again and repeat this only when you feel really uncomfortable from the cold. But do it as little as possible. Preserve the fuel as long as you can. To help keep warm, you can get out of the vehicle and do some fairly vigorous exercises every half hour or so until help comes. Recreational Vehicle Towing Your vehicle was not designed to be towed with all four wheels on the ground. If your vehicle must be towed, see “Towing Your Vehicle” in the Index.


NOTICE:


Towing your vehicle with all four wheels on the ground will damage drivetrain components.


4-30


Loading Your Vehicle


Two labels on your vehicle show how much weight it may properly carry. The Tire-Loading Information label found on the rear edge of the driver’s door tells you the proper size, speed rating and recommended inflation pressures for the tires on your vehicle. It also gives you important information about the number of people that can be in your vehicle and the total weight that you can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo, and all nonfactory-installed options.


And, if you do have a heavy load, you should spread it out. Don’t carry more than 100 lbs. (45 kg) in your rear area.


CAUTION:


Do not load your vehicle any heavier than the GVWR, or either the maximum front or rear GAWR. If you do, parts on your vehicle can break, and it can change the way your vehicle handles. These could cause you to lose control and crash. Also, overloading can shorten the life of your vehicle.


If you put things inside your vehicle -- like suitcases, tools, packages or anything else -- they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they’ll keep going.


4-31


The other label is the Certification label, found on the rear edge of the driver’s door. It tells you the gross weight capacity of your vehicle, called Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel and cargo. Never exceed the GVWR for your vehicle, or the Gross Axle Weight Rating (GAWR) for either the front or rear axle.


CAUTION:


Things you put inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash. D Put things in the rear area of your vehicle.


Try to spread the weight evenly.


D Never stack heavier things, like suitcases, inside the vehicle so that some of them are above the tops of the seats.


D Don’t leave an unsecured child restraint in


your vehicle.


D When you carry something inside the


vehicle, secure it whenever you can.


D Don’t leave a seat folded down unless you


need to.


4-32


Towing a Trailer


CAUTION:


If you don’t use the correct equipment and drive properly, you can lose control when you pull a trailer. For example, if the trailer is too heavy, the brakes may not work well -- or even at all. You and your passengers could be seriously injured. You may also damage your vehicle; the resulting repairs would not be covered by your warranty. Pull a trailer only if you have followed all the steps in this section. Ask your dealer for advice and information about towing a trailer with your vehicle.


Your vehicle can tow a trailer if it is equipped with the proper trailer towing equipment. To identify what the vehicle trailering capacity is for your vehicle, you should read the information in “Weight of the Trailer” that appears later in this section. But trailering is different than just driving your vehicle by itself. Trailering means changes in handling, durability and fuel economy. Successful, safe trailering takes correct equipment, and it has to be used properly.


That’s the reason for this part. In it are many time-tested, important trailering tips and safety rules. Many of these are important for your safety and that of your passengers. So please read this section carefully before you pull a trailer. Load-pulling components such as the engine, transmission, rear axle, wheel assemblies and tires are forced to work harder against the drag of the added weight. The engine is required to operate at relatively higher speeds and under greater loads, generating extra heat. What’s more, the trailer adds considerably to wind resistance, increasing the pulling requirements. If You Do Decide To Pull A Trailer If you do, here are some important points: D There are many different laws, including speed limit restrictions, having to do with trailering. Make sure your rig will be legal, not only where you live but also where you’ll be driving. A good source for this information can be state or provincial police.


D Consider using a sway control. You can ask a hitch


dealer about sway controls.


D Don’t tow a trailer at all during the first 1,000 miles (1 600 km) your new vehicle is driven. Your engine, axle or other parts could be damaged.


D Then, during the first 500 miles (800 km) that you


tow a trailer, don’t drive over 50 mph (80 km/h) and don’t make starts at full throttle. This helps your engine and other parts of your vehicle wear in at the heavier loads.


D Obey speed limit restrictions when towing a trailer. Don’t drive faster than the maximum posted speed for trailers (or no more than 55 mph (90 km/h)) to save wear on your vehicle’s parts.


Three important considerations have to do with weight: D the weight of the trailer, D the weight of the trailer tongue D and the total weight on your vehicle’s tires. Weight of the Trailer How heavy can a trailer safely be? It should never weigh more than 1,500 lbs. (680 kg) under normal driving conditions. It should never weigh more than 1,000 lbs. (450 kg) when driven on long grades at high ambient temperatures (above 90_F /32_C). But even that can be too heavy. It depends on how you plan to use your rig. For example, speed, altitude, road grades, outside temperature and how much your vehicle is used to pull a trailer are all important. And, it can also depend on any special equipment that you have on your vehicle.


4-33


You can ask your dealer for our trailering information or advice, or you can write us at:


Pontiac-GMC Customer Assistance Center P.O. Box 436008
Pontiac, MI 48343-6008


In Canada, write to:


General Motors of Canada Limited Customer Communication Centre 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7


Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total or gross weight of your vehicle. The Gross Vehicle Weight (GVW) includes the curb weight of the vehicle, any cargo you may carry in it, and the people who will be riding in the vehicle. And if you tow a trailer, you must add the tongue load to the GVW because your vehicle will be carrying that weight, too. See “Loading Your Vehicle” in the Index for more information about your vehicle’s maximum load capacity.


4-34


If you’re using a weight-carrying hitch, the trailer tongue (A) should weigh 10 percent of the total loaded trailer weight (B). If you have a weight-distributing hitch, the trailer tongue (A) should weigh 12 percent of the total loaded trailer weight (B). After you’ve loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they aren’t, you may be able to get them right simply by moving some items around in the trailer.


Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the upper limit for cold tires. You’ll find these numbers on the Tire-Loading Information label at the rear edge of the driver’s door or see “Loading Your Vehicle” in the Index. Then be sure you don’t go over the GVW limit for your vehicle, including the weight of the trailer tongue. Hitches It’s important to have the correct hitch equipment. Crosswinds, large trucks going by and rough roads are a few reasons why you’ll need the right hitch. Here are some rules to follow: D The rear bumper on your vehicle is not intended for


hitches. Do not attach rental hitches or other bumper-type hitches to it. Use only a frame-mounted hitch that does not attach to the bumper.


D Will you have to make any holes in the body of your


vehicle when you install a trailer hitch? If you do, then be sure to seal the holes later when you remove the hitch. If you don’t seal them, deadly carbon monoxide (CO) from your exhaust can get into your vehicle (see “Carbon Monoxide” in the Index). Dirt and water can, too.


Safety Chains You should always attach chains between your vehicle and your trailer. Cross the safety chains under the tongue of the trailer so that the tongue will not drop to the road if it becomes separated from the hitch. Instructions about safety chains may be provided by the hitch manufacturer or by the trailer manufacturer. Follow the manufacturer’s recommendation for attaching safety chains and do not attach them to the bumper. Always leave just enough slack so you can turn with your rig. And, never allow safety chains to drag on the ground. Trailer Brakes If your trailer weighs more than 1,000 lbs. (450 kg) loaded, then it needs its own brakes -- and they must be adequate. Be sure to read and follow the instructions for the trailer brakes so you’ll be able to install, adjust and maintain them properly. Because you have anti-lock brakes, do not try to tap into your vehicle’s brake system. If you do, both brake systems won’t work well, or at all.


4-35


Driving with a Trailer Towing a trailer requires a certain amount of experience. Before setting out for the open road, you’ll want to get to know your rig. Acquaint yourself with the feel of handling and braking with the added weight of the trailer. And always keep in mind that the vehicle you are driving is now a good deal longer and not nearly as responsive as your vehicle is by itself. Before you start, check the trailer hitch and platform (and attachments), safety chains, electrical connector, lamps, tires and mirror adjustment. If the trailer has electric brakes, start your vehicle and trailer moving and then apply the trailer brake controller by hand to be sure the brakes are working. This lets you check your electrical connection at the same time. During your trip, check occasionally to be sure that the load is secure, and that the lamps and any trailer brakes are still working. Following Distance Stay at least twice as far behind the vehicle ahead as you would when driving your vehicle without a trailer. This can help you avoid situations that require heavy braking and sudden turns.


4-36


Passing You’ll need more passing distance up ahead when you’re towing a trailer. And, because you’re a good deal longer, you’ll need to go much farther beyond the passed vehicle before you can return to your lane. Backing Up Hold the bottom of the steering wheel with one hand. Then, to move the trailer to the left, just move that hand to the left. To move the trailer to the right, move your hand to the right. Always back up slowly and, if possible, have someone guide you. Making Turns


NOTICE:


Making very sharp turns while trailering could cause the trailer to come in contact with the vehicle. Your vehicle could be damaged. Avoid making very sharp turns while trailering.


When you’re turning with a trailer, make wider turns than normal. Do this so your trailer won’t strike soft shoulders, curbs, road signs, trees or other objects. Avoid jerky or sudden maneuvers. Signal well in advance.


Turn Signals When Towing a Trailer When you tow a trailer, your vehicle may need a different turn signal flasher and/or extra wiring. Check with your dealer. The arrows on your instrument panel will flash whenever you signal a turn or lane change. Properly hooked up, the trailer lamps will also flash, telling other drivers you’re about to turn, change lanes or stop. When towing a trailer, the arrows on your instrument panel will flash for turns even if the bulbs on the trailer are burned out. Thus, you may think drivers behind you are seeing your signal when they are not. It’s important to check occasionally to be sure the trailer bulbs are still working. Driving On Grades Reduce speed and shift to a lower gear before you start down a long or steep downgrade. If you don’t shift down, you might have to use your brakes so much that they would get hot and no longer work well. On a long uphill grade, shift down and reduce your speed to around 45 mph (70 km/h) to reduce the possibility of engine and transmission overheating. If you are towing a trailer and you have an automatic transmission with overdrive, you may prefer to drive in THIRD (3) instead of AUTOMATIC OVERDRIVE (D) (or, as you need to, a lower gear).


Or, if you have a manual transmission with FIFTH (5) (or SIXTH (6)) gear and you are towing a trailer, it’s better not to use FIFTH (5) (or SIXTH (6)) gear. Just drive in FOURTH (4) (drive in FIFTH (5) if you have a six-speed manual transmission) or, as you need to, a lower gear. Parking on Hills


CAUTION:


You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged.


But if you ever have to park your rig on a hill, here’s how to do it: 1. Apply your regular brakes, but don’t shift into


PARK (P) yet, or into gear for a manual transmission. 2. Have someone place chocks under the trailer wheels.


4-37


3. When the wheel chocks are in place, release the regular brakes until the chocks absorb the load.


4. Reapply the regular brakes. Then apply your parking brake, and then shift to PARK (P), or REVERSE (R) for a manual transmission. 5. Release the regular brakes. When You Are Ready to Leave After Parking on a Hill 1. Apply your regular brakes and hold the pedal down


while you: D Start your engine; D Shift into a gear; and D Release the parking brake.


2. Let up on the brake pedal. 3. Drive slowly until the trailer is clear of the chocks. 4. Stop and have someone pick up and store the chocks.


Maintenance When Trailer Towing Your vehicle will need service more often when you’re pulling a trailer. See the Maintenance Schedule for more on this. Things that are especially important in trailer operation are automatic transmission fluid (don’t overfill), engine oil, axle lubricant, drive belts, cooling system and brake system. Each of these is covered in this manual, and the Index will help you find them quickly. If you’re trailering, it’s a good idea to review this information before you start your trip. Check periodically to see that all hitch nuts and bolts are tight. Engine Cooling When Trailer Towing Your cooling system may temporarily overheat during severe operating conditions. See “Engine Overheating” in the Index.


4-38


Section 5 Problems on the Road


Here you’ll find what to do about some problems that can occur on the road.


5-2
5-3
5-3
5-7
5-8


Hazard Warning Flashers Other Warning Devices Jump Starting Towing Your Vehicle Engine Overheating


5-11
5-22
5-23
5-33
5-33


Cooling System If a Tire Goes Flat Changing a Flat Tire Compact Spare Tire If You’re Stuck: In Sand, Mud, Ice or Snow


5-


5-1


Hazard Warning Flashers


Press the button in to make your front and rear turn signal lamps flash on and off.


Your hazard warning flashers work no matter what position your key is in, or even if the key isn’t in.


To turn off the flashers, pull out on the collar.


Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will flash on and off.


5-2


When the hazard warning flashers are on, your turn signals won’t work.


Other Warning Devices If you carry reflective triangles, you can set one up at the side of the road about 300 feet (100 m) behind your vehicle. Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your vehicle. But please use the following steps to do it safely.


CAUTION:


Batteries can hurt you. They can be dangerous because: D They contain acid that can burn you. D They contain gas that can explode or ignite. D They contain enough electricity to


burn you.


If you don’t follow these steps exactly, some or all of these things can hurt you.


NOTICE:


Ignoring these steps could result in costly damage to your vehicle that wouldn’t be covered by your warranty. The ACDelcoR battery in your vehicle has a built-in hydrometer. Do not charge, test or jump start the battery if the hydrometer looks clear or light yellow. Replace the battery when there is a clear or light yellow hydrometer and a cranking complaint. Trying to start your vehicle by pushing or pulling it won’t work, and it could damage your vehicle.


1. Check the other vehicle. It must have a 12-volt


battery with a negative ground system.


NOTICE:


If the other system isn’t a 12-volt system with a negative ground, both vehicles can be damaged.


5-3


2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other. If they are, it could cause a ground connection you don’t want. You wouldn’t be able to start your vehicle, and the bad grounding could damage the electrical systems. To avoid the possibility of the vehicles rolling, set the parking brake firmly on both vehicles involved in the jump starting procedure. Put an automatic transmission in PARK (P) before setting the parking brake.


3. Turn off the ignition on both vehicles. Unplug


unnecessary accessories plugged into the cigarette lighter. Turn off all lamps that aren’t needed as well as radios. This will avoid sparks and help save both batteries. In addition, it could save your radio.


NOTICE:


If you leave your radio on, it could be badly damaged. The repairs wouldn’t be covered by your warranty.


4. Open the hoods and locate the batteries.


Find the positive (+) and negative (-) terminals on each battery.


CAUTION:


Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water. You don’t need to add water to the ACDelcoR battery installed in every new GM vehicle. But if a battery has filler caps, be sure the right amount of fluid is there. If it is low, add water to take care of that first. If you don’t, explosive gas could be present. Battery fluid contains acid that can burn you. Don’t get it on you. If you accidentally get it in your eyes or on your skin, flush the place with water and get medical help immediately.


5-4


5. Check that the jumper cables don’t have loose or


missing insulation. If they do, you could get a shock. The vehicles could be damaged, too. Before you connect the cables, here are some basic things you should know. Positive (+) will go to positive (+) and negative (-) will go to a heavy, unpainted metal engine part. Don’t connect positive (+) to negative (-) or you’ll get a short that would damage the battery and maybe other parts, too. And don’t connect negative (-) to negative (-) on the dead battery, as this can cause sparks.


CAUTION:


Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running.


6. Connect the


red positive (+) cable to the positive (+) terminal of the vehicle with the dead battery. Use a remote positive (+) terminal if the vehicle has one.


7. Don’t let the other end touch metal. Connect it to the positive (+) terminal of the good battery. Use a remote positive (+) terminal if the vehicle has one.


5-5


8. Now connect the black


negative (-) cable to the good battery’s negative (-) terminal.


9. Attach the cable at least 18 inches (45 cm) away from the dead battery, but not near engine parts that move. The electrical connection is just as good there, but the chance of sparks getting back to the battery is much less.


Don’t let the other end touch anything until the next step. The other end of the negative (-) cable doesn’t go to the dead battery. It goes to a heavy, unpainted metal engine part on the engine of the vehicle with the dead battery.


10. Now start the vehicle with the good battery and run


the engine for a while.


11. Try to start the vehicle with the dead battery. If it won’t start after a few tries, it probably needs service.


5-6


12. Remove the cables in reverse order to prevent


electrical shorting. Take care that they don’t touch each other or any other metal.


Towing Your Vehicle


CAUTION:


Removal Procedure


A. Heavy, Unpainted Metal Engine Part B. Good Battery C. Dead Battery


To help avoid serious personal injury to you or others: D Never let passengers ride in a vehicle that is


being towed.


D Never tow faster than safe or posted speeds. D Never tow with damaged parts not


fully secured.


D Never get under your vehicle after it has


been lifted by the tow truck.


D Always secure the vehicle on each side with


separate safety chains when towing it.


D Use only the correct hooks.


5-7


NOTICE:


Use the proper towing equipment to avoid damage to the bumper, fascia or fog lamp areas of the vehicle.


With current trends in automotive styles and design, it is essential that the correct towing equipment is used to tow a vehicle. Your vehicle can be towed with wheel-lift or car-carrier equipment. Consult your dealer or a professional towing service if you need to have your vehicle towed. See “Roadside Assistance” in the Index. Engine Overheating You will find a coolant temperature gage on your instrument panel cluster. See “Engine Coolant Temperature Gage” in the Index.


Overheated Engine Protection Operating Mode This emergency operating mode allows your vehicle to be driven to a safe place in an emergency situation. Should an overheated engine condition exist, an overheat protection mode which alternates firing groups of cylinders helps prevent engine damage. In this mode, you will notice a significant loss in power and engine performance. The CHECK GAGES light may come on and the temperature gage will indicate an overheat condition exists. Towing a trailer in the overheat protection mode should be avoided.


NOTICE:


After driving in the overheated engine protection operating mode, to avoid engine damage, allow the engine to cool before attempting any repair. The engine oil will be severely degraded. Repair the cause of coolant loss and change the oil. See “Engine Oil” in the Index.


5-8


If Steam Is Coming From Your Engine


CAUTION:


Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Just turn it off and get everyone away from the vehicle until it cools down. Wait until there is no sign of steam or coolant before you open the hood. If you keep driving when your engine is overheated, the liquids in it can catch fire. You or others could be badly burned. Stop your engine if it overheats, and get out of the vehicle until the engine is cool. See “Overheated Engine Protection Operating Mode” in the Index.


5-9


NOTICE:


If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty. See “Overheated Engine Protection Operating Mode” in the Index.


If No Steam Is Coming From Your Engine If you get an engine overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: D Climb a long hill on a hot day. D Stop after high-speed driving. D Idle for long periods in traffic. D Tow a trailer.


If you get the overheat warning with no sign of steam, try this for a minute or so: 1. If your air conditioner is on, turn it off. 2. Turn on your heater to full hot at the highest fan


speed and open the window as necessary.


3. If you’re in a traffic jam, shift to NEUTRAL (N);


otherwise, shift to the highest gear while driving -- AUTOMATIC OVERDRIVE (D) or THIRD (3) for automatic transmissions.


If you no longer have the overheat warning, you can drive. Just to be safe, drive slower for about 10 minutes. If the warning doesn’t come back on, you can drive normally. If the warning continues, pull over, stop, and park your vehicle right away. If there’s still no sign of steam, idle the engine for three minutes while you’re parked. If you still have the warning, turn off the engine and get everyone out of the vehicle until it cools down. Also, see “Overheated Engine Protection Operating Mode” listed previously in this section. You may decide not to lift the hood but to get service help right away.


5-10


Cooling System When you decide it’s safe to lift the hood, here’s what you’ll see:


CAUTION:


An electric engine cooling fan under the hood can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan.


If the coolant inside the coolant recovery tank is boiling, don’t do anything else until it cools down.


A. Electric Engine Cooling Fans B. Radiator Pressure Cap C. Coolant Recovery Tank


5-11


CAUTION:


Heater and radiator hoses, and other engine parts, can be very hot. Don’t touch them. If you do, you can be burned. Don’t run the engine if there is a leak. If you run the engine, it could lose all coolant. That could cause an engine fire, and you could be burned. Get any leak fixed before you drive the vehicle.


NOTICE:


Engine damage from running your engine without coolant isn’t covered by your warranty. See “Overheated Engine Protection Operating Mode” in the Index.


When it is cool, remove the coolant recovery tank cap and look at the dipstick. When the engine is cold, the coolant level should be at the FULL COLD mark. If it isn’t, you may have a leak in the radiator hoses, heater hoses, radiator, water pump or somewhere else in the cooling system.


5-12


NOTICE:


When adding coolant, it is important that you use only DEX-COOLR (silicate-free) coolant. If coolant other than DEX-COOL is added to the system, premature engine, heater core or radiator corrosion may result. In addition, the engine coolant will require change sooner -- at 30,000 miles (50 000 km) or 24 months, whichever occurs first. Damage caused by the use of coolant other than DEX-COOLR is not covered by your new vehicle warranty.


If there seems to be no leak, with the engine on, check to see if the electric engine cooling fans are running. If the engine is overheating, both fans should be running. If they aren’t, your vehicle needs service.


How to Add Coolant to the Coolant Recovery Tank If you haven’t found a problem yet, but the coolant level isn’t at the FULL COLD mark, add a 50/50 mixture of clean, drinkable water and DEX-COOLR engine coolant at the coolant recovery tank. (See “Engine Coolant” in the Index for more information.)


CAUTION:


Adding only plain water to your cooling system can be dangerous. Plain water, or some other liquid like alcohol, can boil before the proper coolant mixture will. Your vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, your engine could get too hot but you wouldn’t get the overheat warning. Your engine could catch fire and you or others could be burned. Use a 50/50 mixture of clean, drinkable water and DEX-COOLR coolant.


5-13


NOTICE:


CAUTION:


In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use the recommended coolant and the proper coolant mixture.


You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Don’t spill coolant on a hot engine.


When the coolant in the coolant recovery tank is at the FULL COLD mark, start your vehicle. If the overheat warning continues, there’s one more thing you can try. You can add the proper coolant mixture directly to the radiator, but be sure the cooling system is cool before you do it.


5-14


CAUTION:


Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They are under pressure, and if you turn the radiator pressure cap -- even a little -- they can come out at high speed. Never turn the cap when the cooling system, including the radiator pressure cap, is hot. Wait for the cooling system and radiator pressure cap to cool if you ever have to turn the pressure cap.


5-15


How to Add Coolant to the Radiator (3800 V6 Engine Only)


NOTICE:


Your engine has a specific radiator fill procedure. Failure to follow this procedure could cause your engine to overheat and be severely damaged.


1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly counterclockwise until it first stops. (Don’t press down while turning the pressure cap.) If you hear a hiss, wait for that to stop. A hiss means there is still some pressure left.


5-16


2. Then keep turning the pressure cap, but now push


down as you turn it. Remove the pressure cap.


CAUTION:


You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Don’t spill coolant on a hot engine.


3. After the engine cools, open the coolant air


bleed valve. There is one bleed valve. It is located on the thermostat housing.


5-17


4. Fill the radiator with the proper DEX-COOLR


coolant mixture, up to the base of the filler neck. (See “Engine Coolant” in the Index for more information about the proper coolant mixture.) If you see a stream of coolant coming from an air bleed valve, close the valve. Otherwise, close the valve after the radiator is filled.


5. Then fill the coolant recovery tank to the


FULL COLD mark.


6. Put the cap back on the coolant recovery tank, but


leave the radiator pressure cap off.


5-18


7. Start the engine and let it run until you can feel the


upper radiator hose getting hot. Watch out for the engine cooling fans.


8. By this time, the coolant level inside the radiator filler neck may be lower. If the level is lower, add more of the proper DEX-COOLR coolant mixture through the filler neck until the level reaches the base of the filler neck.


9. Then replace the pressure cap. At any time during this procedure if coolant begins to flow out of the filler neck, reinstall the pressure cap. Be sure the arrows on the pressure cap line up like this.


5-19


How to Add Coolant to the Radiator (V8 Engine Only)


1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly counterclockwise until it first stops. (Don’t press down while turning the pressure cap.) If you hear a hiss, wait for that to stop. A hiss means there is still some pressure left.


5-20


2. Then keep turning the pressure cap, but now push


down as you turn it. Remove the pressure cap.


CAUTION:


You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol, and it will burn if the engine parts are hot enough. Don’t spill coolant on a hot engine.


7. Shut the engine off and replace the pressure cap.


Be sure the arrows on the cap line up like this.


3. Fill with the proper DEX-COOLR coolant mixture. 4. Continue to fill the radiator up to the base of the


filler neck.


5. Rinse or wipe the spilled coolant from the engine


and compartment.


6. Start the engine and allow it to run in idle for approximately four minutes. By this time, the coolant level inside the radiator will be lower. Add more of the proper mixture through the filler neck until the level reaches the base of the filler neck.


5-21


If a Tire Goes Flat It’s unusual for a tire to “blow out” while you’re driving, especially if you maintain your tires properly. If air goes out of a tire, it’s much more likely to leak out slowly. But if you should ever have a “blowout,” here are a few tips about what to expect and what to do: If a front tire fails, the flat tire will create a drag that pulls the vehicle toward that side. Take your foot off the accelerator pedal and grip the steering wheel firmly. Steer to maintain lane position, and then gently brake to a stop well out of the traffic lane. A rear blowout, particularly on a curve, acts much like a skid and may require the same correction you’d use in a skid. In any rear blowout, remove your foot from the accelerator pedal. Get the vehicle under control by steering the way you want the vehicle to go. It may be very bumpy and noisy, but you can still steer. Gently brake to a stop -- well off the road if possible. If a tire goes flat, the next part shows how to use your jacking equipment to change a flat tire safely.


8. Then fill the coolant recovery tank to the


proper level.


5-22


Changing a Flat Tire If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning flashers.


CAUTION:


Changing a tire can cause an injury. The vehicle can slip off the jack and roll over you or other people. You and they could be badly injured. Find a level place to change your tire. To help prevent the vehicle from moving:


1. Set the parking brake firmly. 2. Put an automatic transmission shift lever in PARK (P), or shift a manual transmission to FIRST (1) or REVERSE (R).


3. Turn off the engine.


To be even more certain the vehicle won’t move, you can put blocks at the front and rear of the tire farthest away from the one being changed. That would be the tire on the other side of the vehicle, at the opposite end.


The following steps will tell you how to use the jack and change a tire. Removing the Spare Tire and Tools The equipment you’ll need is located in the rear area behind the trim panel on the passenger’s side. First you must remove the cargo cover. See “Cargo Cover” in the Index.


5-23


On convertible models, you must also remove the trunk access panel. It’s at the upper back of the trunk. Turn the two wing fasteners under the trunk edge a quarter turn counterclockwise to remove the panel.


If you have speakers in the trim panel, you may have to disconnect the wire from the speaker. The speaker wire may be long enough to remove the trim panel without disconnecting the wire.


To remove the jack and wheel wrench, loosen and remove the bolt and remove the plastic cover.


Find the plastic screw heads in the trim panel over the spare tire. (See “Compact Spare Tire” in the Index for more information about the compact spare.) Use a coin or a key to turn the screw heads until the slots point front and back to the unlock position. Gently lift the trim panel’s front forward edge and remove the panel.


5-24


Remove the wing nut and adapter and pull out the spare.


The tools you’ll be using include the jack (A) and wheel wrench (B).


5-25


Removing the Flat Tire and Installing the Spare Tire


The jack has a bolt at the end. Attach the wheel wrench to the jack bolt. Turn the wheel wrench clockwise to raise the lift head a little. Your vehicle has alloy wheels, first remove the decorative nut caps using the wheel wrench. Each wheel may have one locknut in place of the standard wheel nut. A special wheel lock key (removal tool) and instructions are located in the center console. Attach the wheel lock key to the socket of the wheel wrench. Remove the locking wheel nut by turning counterclockwise.


5-26


1. Using the wheel wrench, loosen all the wheel nuts.


Don’t remove them yet.


2. Position the jack under the vehicle. There is a notch


in the vehicle’s rocker flange on the coupe model. Raise the jack head until it fits firmly into the notch nearest the flat tire. On convertible models, place the jack in a similar location.


5-27


CAUTION:


Getting under a vehicle when it is jacked up is dangerous. If the vehicle slips off the jack, you could be badly injured or killed. Never get under a vehicle when it is supported only by a jack.


CAUTION:


Raising your vehicle with the jack improperly positioned can damage the vehicle and even make the vehicle fall. To help avoid personal injury and vehicle damage, be sure to fit the jack lift head into the proper location before raising the vehicle.


Stay away from moldings or fender flanges to avoid damaging them. Put the compact tire near you.


5-28


3. Raise the vehicle by turning the wheel wrench clockwise. Raise the vehicle far enough off the ground so there is enough room for the spare tire to fit.


4. Remove all the wheel nuts and take off the flat tire.


5. Remove any rust or dirt


from the wheel bolts, mounting surfaces and spare wheel.


CAUTION:


Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts become loose after a time. The wheel could come off and cause an accident. When you change a wheel, remove any rust or dirt from the places where the wheel attaches to the vehicle. In an emergency, you can use a cloth or a paper towel to do this; but be sure to use a scraper or wire brush later, if you need to, to get all the rust or dirt off.


5-29


CAUTION:


Never use oil or grease on studs or nuts. If you do, the nuts might come loose. Your wheel could fall off, causing a serious accident.


6. Install the spare tire and replace the wheel nuts


with the rounded end of the nuts toward the wheel. Tighten each nut by hand until the wheel is held against the hub.


5-30


7. Lower the vehicle by turning the wheel wrench counterclockwise. Lower the jack completely.


8. Tighten the wheel nuts


firmly in a crisscross sequence as shown. Install the plastic nut caps and tighten by hand.


NOTICE:


Improperly tightened wheel nuts can lead to brake pulsation and rotor damage. To avoid expensive brake repairs, evenly tighten the wheel nuts in the proper sequence and to the proper torque specification.


Then, using the wheel wrench, tighten an additional one-quarter turn.


Storing a Flat or Spare Tire and Tools


CAUTION:


Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off. This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts. Stop somewhere as soon as you can and have the nuts tightened with a torque wrench to 100 lb-ft (140 N·m).


CAUTION:


Storing a jack, a tire or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.


Replace the jack, wheel wrench and flat tire using the storage instructions. When you replace the trim panel, be sure to tuck it under the weatherstrip.


5-31


1. Trim Panel 2. Bolt 3. Cover 4. Jack 5. Wing Nut 6. Adapter 7. Compact Spare Tire 8. Full-Size Tire 9. Carpet Flap 10. Tire Storage Bolt 11. Trunk Access Panel (Convertible Only) 12. Knob


5-32


Compact Spare Tire Although the compact spare tire was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated. The compact spare is made to perform well at speeds up to 65 mph (105 km/h) for distances up to 3,000 miles (5 000 km), so you can finish your trip and have your full-size tire repaired or replaced where you want. Of course, it’s best to replace your spare with a full-size tire as soon as you can. Your spare will last longer and be in good shape in case you need it again.


NOTICE:


When the compact spare is installed, don’t take your vehicle through an automatic car wash with guide rails. The compact spare can get caught on the rails. That can damage the tire and wheel, and maybe other parts of your vehicle.


Don’t use your compact spare on other vehicles. And don’t mix your compact spare tire or wheel with other wheels or tires. They won’t fit. Keep your spare tire and its wheel together.


NOTICE:


Tire chains won’t fit your compact spare. Using them can damage your vehicle and can damage the chains too. Don’t use tire chains on your compact spare.


If You’re Stuck: In Sand, Mud, Ice or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you don’t want to spin your wheels too fast. The method known as “rocking” can help you get out when you’re stuck, but you must use caution.


5-33


Rocking Your Vehicle To Get It Out First, turn your steering wheel left and right. That will clear the area around your front wheels. If your vehicle has traction control, you should turn the system off. (See “Traction Control System” in the Index.) Then shift back and forth between REVERSE (R) and a forward gear (or with a manual transmission, between FIRST (1) or SECOND (2) and REVERSE (R)), spinning the wheels as little as possible. Release the accelerator pedal while you shift, and press lightly on the accelerator pedal when the transmission is in gear. By slowly spinning your wheels in the forward and reverse directions, you will cause a rocking motion that may free your vehicle. If that doesn’t get you out after a few tries, you may need to be towed out. If you do need to be towed out, see “Towing Your Vehicle” in the Index.


CAUTION:


If you let your tires spin at high speed, they can explode, and you or others could be injured. And, the transmission or other parts of the vehicle can overheat. That could cause an engine compartment fire or other damage. When you’re stuck, spin the wheels as little as possible. Don’t spin the wheels above 35 mph (55 km/h) as shown on the speedometer.


NOTICE:


Spinning your wheels can destroy parts of your vehicle as well as the tires. If you spin the wheels too fast while shifting your transmission back and forth, you can destroy your transmission.


For information about using tire chains on your vehicle, see “Tire Chains” in the Index.


5-34


Section 6 Service and Appearance Care


Here you will find information about the care of your vehicle. This section begins with service and fuel information, and then it shows how to check important fluid and lubricant levels. There is also technical information about your vehicle, and a part devoted to its appearance care.


6-2
6-3
6-5
6-6
6-8
6-8
6-12
6-18
6-20
6-24
6-25
6-26
6-26
6-30
6-31
6-32
6-35
6-36


Service Fuel Fuels in Foreign Countries Filling Your Tank Filling a Portable Fuel Container Checking Things Under the Hood Engine Oil Engine Air Cleaner/Filter Automatic Transmission Fluid Manual Transmission Fluid Hydraulic Clutch Rear Axle Engine Coolant Power Steering Fluid Windshield Washer Fluid Brakes Battery Bulb Replacement


6-


6-44
6-53
6-53
6-55
6-56
6-56
6-57
6-58
6-59


6-60
6-61
6-62
6-62
6-63
6-69
6-69
6-71


Tires Appearance Care Cleaning the Inside of Your Vehicle Care of Safety Belts Cleaning Glass Surfaces Cleaning a Removeable Roof Panel Cleaning the Outside of Your Vehicle Cleaning Your Removeable Top Cleaning Aluminum or Chrome-Plated Wheels (If Equipped) Underbody Maintenance GM Vehicle Care/Appearance Materials Vehicle Identification Number (VIN) Service Parts Identification Label Electrical System Replacement Bulbs Capacities and Specifications Normal Maintenance Replacement Parts


6-1


Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to your dealer for all your service needs. You’ll get genuine GM parts and GM-trained and supported service people. We hope you’ll want to keep your GM vehicle all GM. Genuine GM parts have one of these marks:


Doing Your Own Service Work If you want to do some of your own service work, you’ll want to use the proper service manual. It tells you much more about how to service your vehicle than this manual can. To order the proper service manual, see “Service and Owner Publications” in the Index. Your vehicle has an air bag system. Before attempting to do your own service work, see “Servicing Your Air Bag-Equipped Vehicle” in the Index. You should keep a record with all parts receipts and list the mileage and the date of any service work you perform. See “Maintenance Record” in the Index.


6-2


CAUTION:


You can be injured and your vehicle could be damaged if you try to do service work on a vehicle without knowing enough about it. D Be sure you have sufficient knowledge,


experience, the proper replacement parts and tools before you attempt any vehicle maintenance task.


D Be sure to use the proper nuts, bolts and other fasteners. “English” and “metric” fasteners can be easily confused. If you use the wrong fasteners, parts can later break or fall off. You could be hurt.


Adding Equipment to the Outside of Your Vehicle Things you might add to the outside of your vehicle can affect the airflow around it. This may cause wind noise and affect windshield washer performance. Check with your dealer before adding equipment to the outside of your vehicle. Fuel The 8th digit of your vehicle identification number (VIN) shows the code letter for your engine. You will find the VIN at the top left of your instrument panel. (See “Vehicle Identification Number” in the Index.) If you have the 3800 V6 engine (VIN Code K), use regular unleaded gasoline rated at 87 octane or higher. If you have the 5.7L V8 engine (VIN Code G), use premium unleaded gasoline rated at 91 octane or higher for best performance. You may use middle grade or regular unleaded gasolines, but your vehicle’s acceleration may be slightly reduced.


6-3


It is recommended that the gasoline meet specifications which have been developed by the American Automobile Manufacturers Association (AAMA) and endorsed by the Canadian Motor Vehicle Manufacturers Association for better vehicle performance and engine protection. Gasolines meeting the AAMA specification could provide improved driveability and emission control system performance compared to other gasolines. Be sure the posted octane for premium is at least 91 (at least 89 for middle grade and 87 for regular). If the octane is less than 87, you may get a heavy knocking noise when you drive. If it’s bad enough, it can damage your engine. If you’re using fuel rated at the recommended octane or higher and you hear heavy knocking, your engine needs service. But don’t worry if you hear a little pinging noise when you’re accelerating or driving up a hill. That’s normal, and you don’t have to buy a higher octane fuel to get rid of pinging. It’s the heavy, constant knock that means you have a problem.


If your vehicle is certified to meet California Emission Standards (indicated on the underhood emission control label), it is designed to operate on fuels that meet California specifications. If such fuels are not available in states adopting California emissions standards, your vehicle will operate satisfactorily on fuels meeting federal specifications, but emission control system performance may be affected. The malfunction indicator lamp on your instrument panel may turn on and/or your vehicle may fail a smog-check test. (See “Malfunction Indicator Lamp” in the Index.) If this occurs, return to your authorized Pontiac dealer for diagnosis to determine the cause of failure. In the event it is determined that the cause of the condition is the type of fuels used, repairs may not be covered by your warranty. Some gasolines that are not reformulated for low emissions may contain an octane-enhancing additive called methylcyclopentadienyl manganese tricarbonyl (MMT); ask your service station operator whether or not the fuel contains MMT. General Motors does not recommend the use of such gasolines. If fuels containing MMT are used, spark plug life may be reduced and your emission control system performance may be affected. The malfunction indicator lamp on your instrument panel may turn on. If this occurs, return to your authorized Pontiac dealer for service.


6-4


To provide cleaner air, all gasolines in the United States are now required to contain additives that will help prevent deposits from forming in your engine and fuel system, allowing your emission control system to function properly. Therefore, you should not have to add anything to the fuel. In addition, gasolines containing oxygenates, such as ethers and ethanol, and reformulated gasolines may be available in your area to contribute to clean air. General Motors recommends that you use these gasolines, particularly if they comply with the specifications described earlier.


NOTICE:


Your vehicle was not designed for fuel that contains methanol. Don’t use it. It can corrode metal parts in your fuel system and also damage plastic and rubber parts. That damage wouldn’t be covered under your warranty.


Fuels in Foreign Countries If you plan on driving in another country outside the United States or Canada, the proper fuel may be hard to find. Never use leaded gasoline or any other fuel not recommended in the previous text on fuel. Costly repairs caused by use of improper fuel wouldn’t be covered by your warranty. To check on fuel availability, ask an auto club, or contact a major oil company that does business in the country where you’ll be driving. You can also write us at the following address for advice. Just tell us where you’re going and give your Vehicle Identification Number (VIN).


General Motors Overseas Distribution Corporation 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7


6-5


Filling Your Tank


CAUTION:


Gasoline vapor is highly flammable. It burns violently, and that can cause very bad injuries. Don’t smoke if you’re near gasoline or refueling your vehicle. Keep sparks, flames and smoking materials away from gasoline.


The cap is located behind a hinged door on the driver’s side of your vehicle. 6-6


While refueling, hang the cap by the tether from the hook on the filler door. To remove the cap, turn it slowly to the left (counterclockwise). The cap has a spring in it; if you let go of the cap too soon, it will spring back to the right.


CAUTION:


If you get gasoline on yourself and then something ignites it, you could be badly burned. Gasoline can spray out on you if you open the fuel filler cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather. Open the fuel filler cap slowly and wait for any “hiss” noise to stop. Then unscrew the cap all the way.


Be careful not to spill gasoline. Clean gasoline from painted surfaces as soon as possible. See “Cleaning the Outside of Your Vehicle” in the Index.


When you put the cap back on, turn it to the right (clockwise) until you hear a clicking sound. Make sure you fully install the cap. The diagnostic system can determine if the fuel cap has been left off or improperly installed. This would allow fuel to evaporate into the atmosphere. See “Malfunction Indicator Lamp” in the Index.


NOTICE:


If you need a new cap, be sure to get the right type. Your dealer can get one for you. If you get the wrong type, it may not fit properly. This may cause your malfunction indicator lamp to light and your fuel tank and emissions system may be damaged. See “Malfunction Indicator Lamp” in the Index.


6-7


Filling a Portable Fuel Container


Checking Things Under the Hood


CAUTION:


CAUTION:


Never fill a portable fuel container while it is in your vehicle. Static electricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle damaged if this occurs. To help avoid injury to you and others: D Dispense gasoline only into


approved containers.


D Do not fill a container while it is inside a


vehicle, in a vehicle’s trunk, pickup bed or on any surface other than the ground. D Bring the fill nozzle in contact with the


inside of the fill opening before operating the nozzle. Contact should be maintained until the filling is complete.


D Don’t smoke while pumping gasoline.


An electric fan under the hood can start up and injure you even when the engine is not running. Keep hands, clothing and tools away from any underhood electric fan.


CAUTION:


Things that burn can get on hot engine parts and start a fire. These include liquids like gasoline, oil, coolant, brake fluid, windshield washer and other fluids, and plastic or rubber. You or others could be burned. Be careful not to drop or spill things that will burn onto a hot engine.


6-8


Hood Release


To open the hood, first pull the handle located inside the vehicle below the instrument panel on the driver’s side.


Then go to the front of the vehicle and pull up on the hood release located at the center of your hood. Lift the hood.


6-9


When you open the hood of the 3800 V6 engine, you’ll see:


A. Engine Coolant Reservoir B. Battery C. Radiator Fill Cap D. Engine Oil Fill Cap E. Automatic Transmission Fluid


Dipstick (If Equipped)


6-10


F. Windshield Washer


Fluid Reservoir


G. Engine Cooling Fans H. Engine Air Cleaner/Filter I. Power Steering Fluid Reservoir


J. Engine Oil Dipstick K. Brake Fluid Reservoir L. Clutch Fluid Reservoir


(If Equipped)


When you open the hood of the 5.7L V8 engine, you’ll see:


A. Engine Coolant Reservoir B. Battery C. Engine Oil Dipstick D. Engine Oil Fill Cap E. Windshield Washer


Fluid Reservoir


F. Engine Cooling Fans G. Automatic Transmission Fluid


Dipstick (If Equipped)


H. Engine Air Cleaner/Filter


I. Power Steering Fluid Reservoir J. Brake Fluid Reservoir K. Clutch Fluid Reservoir


(If Equipped)


6-11


Before closing the hood, be sure all the filler caps are on. Then pull the hood down and close it firmly. Engine Oil


If the LOW OIL light appears on the instrument panel, it means you need to check your engine oil level right away. For more information, see “Low Oil Light” in the Index.


You should check your engine oil level regularly; this is an added reminder. Checking Engine Oil It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground.


6-12


The engine oil dipstick is the yellow loop near the back of the engine. Do not check the 5.7L V8 engine oil level after the engine has been sitting overnight. A higher than normal reading might be obtained. Check oil level with the oil warm. Turn off the engine and give the oil several minutes to drain back into the oil pan. If you don’t, the oil dipstick might not show the actual level.


Pull out the dipstick and clean it with a paper towel or cloth, then push it back in all the way. Remove it again, keeping the tip down, and check the level.


3800 V6 Engine


5.7L V8 Engine


When to Add Engine Oil If the oil is at or below the ADD line, then you’ll need to add at least one quart of oil. But you must use the right kind. This part explains what kind of oil to use. For crankcase capacity, see “Capacities and Specifications” in the Index.


6-13


NOTICE:


Don’t add too much oil. If your engine has so much oil that the oil level gets above the cross-hatched area that shows the proper operating range, your engine could be damaged.


The oil fill cap is located at the rear of your engine compartment on the passenger’s side of the vehicle. Be sure to fill it enough to put the level somewhere in the proper operating range. Push the dipstick all the way back in when you’re through.


What Kind of Engine Oil to Use Oils recommended for your vehicle can be identified by looking for the starburst symbol. This symbol indicates that the oil has been certified by the American Petroleum Institute (API). Do not use any oil which does not carry this starburst symbol.


If you change your own oil, be sure you use oil that has the starburst symbol on the front of the oil container. If you have your oil changed for you, be sure the oil put into your engine is American Petroleum Institute certified for gasoline engines.


You should also use the proper viscosity oil for your vehicle, as shown in the following chart:


6-14


As shown in the chart, if you have the 5.7L V8 engine, SAE 5W-30 is best for your vehicle. However, you can use SAE 10W-30 if it’s going to be 0_F (-18_C) or above. These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils, such as SAE 20W-50.


5.7L V8 Engine


6-15


As shown in the chart, if you have the 3800 V6 engine, SAE 10W-30 is best for your vehicle. However, you can use SAE 5W-30 if it’s going to be colder than 60_F (16_C) before your next oil change. When it’s very cold, you should use SAE 5W-30. These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils, such as SAE 20W-50.


NOTICE:


Use only engine oil with the American Petroleum Institute Certified For Gasoline Engines starburst symbol. Failure to use the recommended oil can result in engine damage not covered by your warranty.


GM GoodwrenchR oil meets all the requirements for your vehicle. If you are in an area where the temperature falls below -20_F (-29_C), consider using either an SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will provide easier cold starting and better protection for your engine at extremely low temperatures.


3800 V6 Engine


6-16


Engine Oil Additives Don’t add anything to your oil. The recommended oils with the starburst symbol are all you will need for good performance and engine protection. When to Change Engine Oil Your vehicle has a computer that lets you know when to change your engine oil. This is not based on mileage, but on engine revolutions and engine operating temperature. When the computer has calculated that the oil needs changing, the GM Oil Life Systemt will indicate that a change is necessary. The mileage between oil and filter changes will vary depending on how you drive your vehicle -- usually between 3,000 miles (5 000 km) and 7,500 miles (12 500 km) since your last oil and filter change. Under severe conditions, the system may come on before 3,000 miles (5 000 km). Never drive your vehicle more than 7,500 miles (12 500 km) or 12 months (whichever occurs first) without an oil change. The system won’t detect dust in the oil. So, if you drive in a dusty area, be sure to change your oil and filter every 3,000 miles (5 000 km) or sooner. Remember to reset the OIL CHANGE light whenever the oil is changed.


How to Reset the Oil Change Light After changing the engine oil, the system must be reset. 1. Turn the ignition key to RUN and with the engine


turned off.


2. Push the TRIP/OIL RESET button located on the


instrument panel for 12 seconds. The OIL CHANGE light will start to flash to confirm that the system is reset. The reset is complete when the OIL CHANGE light goes out.


What to Do with Used Oil Did you know that used engine oil contains certain elements that may be unhealthy for your skin and could even cause cancer? Don’t let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner. Wash or properly throw away clothing or rags containing used engine oil. (See the manufacturer’s warnings about the use and disposal of oil products.) Used oil can be a real threat to the environment. If you change your own oil, be sure to drain all free-flowing oil from the filter before disposal. Don’t ever dispose of oil by putting it in the trash, pouring it on the ground, into sewers, or into streams or bodies of water. Instead, recycle it by taking it to a place that collects used oil. If you have a problem properly disposing of your used oil, ask your dealer, a service station or a local recycling center for help. 6-17


Engine Air Cleaner/Filter


Refer to the Maintenance Schedule to determine when to replace the air filter. See “Scheduled Maintenance Services” in the Index.


6-18


CAUTION:


Operating the engine with the air cleaner/filter off can cause you or others to be burned. The air cleaner not only cleans the air, it stops flame if the engine backfires. If it isn’t there, and the engine backfires, you could be burned. Don’t drive with it off, and be careful working on the engine with the air cleaner/filter off.


NOTICE:


If the air cleaner/filter is off, a backfire can cause a damaging engine fire. And, dirt can easily get into your engine, which will damage it. Always have the air cleaner/filter in place when you’re driving.


Air Cleaner/Filter Replacement To remove the air cleaner/filter:


1. Unlatch the two clamps located on the front of


the filter.


2. Lift the cover and remove the air filter. 3. Replace the filter. See “Normal Maintenance


Replacement Parts” in the Index for the type of filter to use.


6-19


Automatic Transmission Fluid When to Check and Change A good time to check your automatic transmission fluid level is when the engine oil is changed. Change both the fluid and filter every 15,000 miles (25 000 km) if the vehicle is mainly driven under one or more of these conditions: D In heavy city traffic where the outside temperature


regularly reaches 90_F (32_C) or higher.


D In hilly or mountainous terrain. D Uses such as high performance operation. D When doing frequent trailer towing. D Uses such as found in taxi, police or delivery service. If you do not use your vehicle under any of these conditions, change the fluid and filter every 50,000 miles (83 000 km). See “Scheduled Maintenance Services” in the Index.


4. Close the cover without an overlap (the clamp will


not latch with an overlap) and latch the clamps.


6-20


How to Check Because this operation can be a little difficult, you may choose to have this done at the dealership service department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.


NOTICE:


Too much or too little fluid can damage your transmission. Too much can mean that some of the fluid could come out and fall on hot engine parts or exhaust system parts, starting a fire. Be sure to get an accurate reading if you check your transmission fluid.


Wait at least 30 minutes before checking the transmission fluid level if you have been driving: D When outside temperatures are above 90_F (32_C). D At high speed for quite a while. D In heavy traffic -- especially in hot weather. D While pulling a trailer.


To get the right reading, the fluid should be at normal operating temperature, which is 180_F to 200_F (82_C to 93_C). Get the vehicle warmed up by driving about 15 miles (24 km) when outside temperatures are above 50_F (10_C). If it’s colder than 50_F (10_C), drive the vehicle in DRIVE (D) until the engine temperature gage moves and then remains steady for 10 minutes. Then follow the hot check procedures.


Checking Transmission Fluid Cold A cold check is made after the vehicle has been sitting for eight hours or more with the engine off and is used only as a reference. Let the engine run at idle for five minutes if outside temperatures are 50_F (10_C) or more. If it’s colder than 50_F (10_C), you may have to idle the engine longer. Should the fluid level be low during a cold check, you must perform a hot check before adding fluid. This will give you a more accurate reading of the fluid level.


6-21


Then, without shutting off the engine, follow these steps:


Checking the Fluid Level Prepare your vehicle as follows: D Park your vehicle on a level place. Keep the


engine running.


D With the parking brake applied, place the shift lever


in PARK (P).


D With your foot on the brake pedal, move the shift lever through each gear range, pausing for about three seconds in each range. Then, position the shift lever in PARK (P).


D Let the engine run at idle for three minutes or more.


3800 V6 Dipstick


5.7L V8 Dipstick


1. The red transmission dipstick is located near the


back of the engine. Flip the handle up and then pull out the dipstick and wipe it with a clean rag or paper towel.


2. Push it back in all the way, wait three seconds and


then pull it back out again.


6-22


3. Check both sides of the dipstick, and read the lower


level. The fluid level must be in the COLD area, below the cross-hatched area, for a cold check or in the HOT area or cross-hatched area for a hot check. 4. If the fluid level is in the acceptable range, push the


dipstick back in all the way; then flip the handle down to lock the dipstick in place.


How to Add Fluid Refer to the Maintenance Schedule to determine what kind of transmission fluid to use. See “Recommended Fluids and Lubricants” in the Index.


Add fluid only after checking the transmission fluid while it is hot. (A cold check is used only as a reference.) If the fluid level is low, add only enough of the proper fluid to bring the level up to the HOT area for a hot check. It doesn’t take much fluid, generally less than one pint (0.5 L). Don’t overfill.


NOTICE:


We recommend you use only fluid labeled DEXRONR-III, because fluid with that label is made especially for your automatic transmission. Damage caused by fluid other than DEXRONR-III is not covered by your new vehicle warranty.


D After adding fluid, recheck the fluid level as


described under “How to Check.”


D When the correct fluid level is obtained, push the dipstick back in all the way; then flip the handle down to lock the dipstick in place.


6-23


Manual Transmission Fluid When to Check A good time to have it checked is when the engine oil is changed. However, the fluid in your manual transmission doesn’t require changing. How to Check Because this operation can be difficult, you may choose to have this done at your Pontiac dealership service department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading.


NOTICE:


Too much or too little fluid can damage your transmission. Too much can mean that some of the fluid could come out and fall on hot engine parts or exhaust system parts, starting a fire. Be sure to get an accurate reading if you check your transmission fluid.


6-24


Check the fluid level only when your engine is off, the vehicle is parked on a level place and the transmission is cool enough for you to rest your fingers on the transmission case. Then, follow these steps:


6-Speed (5-Speed Similar)


1. Remove the filler plug. 2. Check that the lubricant level is up to the bottom of


the filler plug hole.


3. If the fluid level is good, install the plug and be sure


it is fully seated. If the fluid level is low, add more fluid as described in the next steps.


How to Add Fluid Here’s how to add fluid. Refer to the Maintenance Schedule to determine what kind of fluid to use. See “Recommended Fluids and Lubricants” in the Index. 1. Remove the filler plug. 2. Add fluid at the filler plug hole. Add only enough fluid to bring the fluid level up to the bottom of the filler plug hole.


3. Install the filler plug. Be sure the plug is fully seated. Hydraulic Clutch The hydraulic clutch linkage in your vehicle is self-adjusting. The clutch master cylinder reservoir is filled with hydraulic clutch fluid. It is not necessary to regularly check clutch fluid unless you suspect there is a leak in the system. Adding fluid won’t correct a leak. A fluid loss in this system could indicate a problem. Have the system inspected and repaired.


When to Check and What to Use


Refer to the Maintenance Schedule to determine how often you should check the fluid level in your clutch master cylinder reservoir and for the proper fluid. See “Owner Checks and Services” and “Recommended Fluids and Lubricants” in the Index. How to Check and Add Fluid The proper fluid should be added if the level is below the plastic step on the reservoir. See the instructions on the reservoir cap.


6-25


Engine Coolant The cooling system in your vehicle is filled with DEX-COOLR engine coolant. This coolant is designed to remain in your vehicle for 5 years or 150,000 miles (240 000 km), whichever occurs first, if you add only DEX-COOLR extended life coolant. The following explains your cooling system and how to add coolant when it is low. If you have a problem with engine overheating or if you need to add coolant to your radiator, see “Engine Overheating” in the Index. A 50/50 mixture of clean, drinkable water and DEX-COOLR coolant will: D Give freezing protection down to -34_F (-37_C). D Give boiling protection up to 265_F (129_C). D Protect against rust and corrosion. D Help keep the proper engine temperature. D Let the warning lights and gages work as


they should.


Rear Axle When to Check and Change Lubricant Refer to the Maintenance Schedule to determine how often to check the lubricant and when to change it. See “Scheduled Maintenance Services” in the Index. How to Check Lubricant If the level is below the bottom of the filler plug hole, you’ll need to add some lubricant. Add enough lubricant to raise the level to the bottom of the filler plug hole. What to Use


Standard Differential Use SAE 75W-90 Synthetic Gear Lubricant (GM Part No. 12378261) or equivalent meeting GM Specification 9986115. Limited-Slip Differential To add lubricant when the level is low, use SAE 75W-90
Synthetic Gear Lubricant (GM Part No. 12378261) or equivalent meeting GM Specification 9986115. To completely refill after draining, add 4 ounces (118 ml) of Limited-Slip Differential Lubricant Additive (GM Part No. 1052358) or equivalent. Then fill to the bottom of the filler plug hole with the Synthetic Gear Lubricant. 6-26


NOTICE:


CAUTION:


When adding coolant, it is important that you use only DEX-COOLR (silicate-free) coolant. If coolant other than DEX-COOL is added to the system, premature engine, heater core or radiator corrosion may result. In addition, the engine coolant will require change sooner -- at 30,000 miles (50 000 km) or 24 months, whichever occurs first. Damage caused by the use of coolant other than DEX-COOLR is not covered by your new vehicle warranty.


What to Use Use a mixture of one-half clean, drinkable water and one-half DEX-COOLR coolant which won’t damage aluminum parts. If you use this coolant mixture, you don’t need to add anything else.


Adding only plain water to your cooling system can be dangerous. Plain water, or some other liquid like alcohol, can boil before the proper coolant mixture will. Your vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture,

Loading...
x
