2005 Hyundai Tucson Owners Manual

17

WARNING:

o Avoid high cornering speeds. o Do not make quick steering wheel move- ments, such as sharp lane charges or fast, sharp turns.

o The risk of rollover is greatly increased if you lose control of your vehicle at high- way speeds.

o In a collision, an unbelted person is signicantly more likely to be seriously injured or killed than a person wearing a seat belt.

o Loss of control may occurs if two or more wheels drop off the roadway and the driver oversteers to reenter the road- way.

o In the event your vehicle leaves the road- way, do not steer sharply. Instead, slow down before pulling back into the travel lanes.

(9)For a speedometer test or inspection/main- tenance (I/M) program of a Tucson 4WD vehicle, use a four wheel chassis dynamom- eter.

(10)When using tire chains, always attach them

to the front wheels.

(11)If the front or rear wheels get stuck in the mud, do not spin them recklessly. The 4WD system could be damaged.

CAUTION:

Never engage the parking brake while per- forming these tests.

o In rare cases when it's unavoidable that a 4WD vehicle is to be inspected on a 2WD roll tester, strictly follow the proce- dures. 1. Check the tire pressures recom-

mended for your vehicle.

2. Place the front wheels on the roll

tester as shown in the illustration.

3. Release the parking brake. 4. Place the rear wheels on the tempo- rary free roller as shown in the illustra- tion.

WARNING:

Keep away from the front of the vehicle while inspecting. This is very dangerous as the vehicle can jump forward and cause serious injury or death.

CAUTION:

o While the full-time 4WD vehicle is being raised on a jack, never start the engine or cause the tires to rotate. There is danger that rotating tires touch- ing the ground could cause the vehicle to go off the jack and to jump forward. o If one of the front or rear wheels begins to spin in mud, snow, etc., the vehicle can sometimes be driven out by de- pressing the accelerator pedal further; however, avoid running the engine con- tinuously at high rpm because doing so could damage the 4WD system.

2 DRIVING YOUR HYUNDAI 18

4WD LOCK SYSTEM

C360A01O-GAT (With Electronic Control 4WD) (If installed)

To release the 4WD lock function, press the 4WD lock button again. The 4WD lock indicator light in the instrument cluster should go off.

GOOD BRAKING PRACTICES

C130A01A-AAT

WARNING:

Nothing should be carried on top of the cargo area cover behind the rear seat. If there were an accident or a sudden stop, such objects could move forward and cause damage to the vehicle or injure the occu- pants.

C360A02JM 1) Pressing the 4WD lock button on the tough terrain, the driving power is equally distrib- uted to the front and rear. 4WD lock keeps activating when not ex- ceeding 40 km/h.

2) Release the 4WD lock button on the normal

driving conditions.

o After being parked, check to be sure the parking brake is not engaged and that the parking brake indicator light is out before driving away.

o Driving through water may get the brakes wet. They can also get wet when the car is washed. Wet brakes can be dangerous! Your car will not stop as quickly if the brakes are wet. Wet brakes may cause the car to pull to one side. To dry the brakes, apply the brakes lightly while driving slowly until the braking action returns to normal, taking care to keep the car under control at all times. If the braking action does not return to normal, stop as soon as it is safe to do so and call your Hyundai dealer for assistance.

C360A01JM-U This 4WD system is designed for dividing the power ratio automatically in normal driving con- ditions. During off-road or low-friction driving condi- tions, press the 4WD lock button to drive in full- time 4WD, dividing the power ratio to 50:50 in the front and rear wheels. The 4WD lock indicator light in the instrument cluster is illuminated. This setup begins to get cancelled when the vehicle speed exceeds 30 km/h, and the func- tion is completely released at a speed of 40 km/ h or higher. Conversely, the function is rerun when the speed again drops to 40 km/h or lower, and is fully established at speeds below 30 km/ h.

o Don't coast down hills with the car out of gear. This is extremely hazardous. Keep the car in gear at all times, use the brakes to slow down, then shift to a lower gear so that engine braking will help you maintain a safe speed. o Don't "ride" the brake pedal. Resting your foot on the brake pedal while driving can be dangerous because it can result in the brakes overheating and losing their effectiveness. It also increases the wear of the brake com- ponents.

o If a tire goes flat while you are driving, apply the brakes gently and keep the car pointed straight ahead while you slow down. When you are moving slowly enough for it to be safe to do so, pull off the road and stop in a safe place.

o If your car is equipped with an automatic transaxle, don't let your car creep forward. To avoid creeping forward, keep your foot firmly on the brake pedal when the car is stopped.

o Use caution when parking on a hill. Engage the parking brake and place the gear selec- tor lever in "P" (automatic transaxle) or in first or reverse gear (manual transaxle). If your car is facing downhill, turn the front wheels into the curb to help keep the car from rolling. If your car is facing uphill, turn the front wheels away from the curb to help keep the car from rolling. If there is no curb or if it is required by other conditions to keep the car from rolling, block the wheels.

o Under some conditions your parking brake can freeze in the engaged position. This is most likely to happen when there is an ac- cumulation of snow or ice around or near the rear brakes or if the brakes are wet. If there is a risk that the parking brake may freeze, apply it only temporarily while you put the gear selector lever in "P" (automatic) or in first or reverse gear (manual transaxle) and block the rear wheels so the car cannot roll. Then release the parking brake.

o Do not hold the vehicle on the upgrade with the accelerator pedal. This can cause the transaxle to overheat. Always use the brake pedal or parking brake.

DRIVING YOUR HYUNDAI

DRIVING FOR ECONOMY

19

C140A01A-AAT You can save fuel and get more miles from your car if you follow these suggestions:

o Drive smoothly. Accelerate at a moderate rate. Don't make "jack-rabbit" starts or full- throttle shifts and maintain a steady cruising speed. Don't race between stoplights. Try to adjust your speed to that of the other traffic so you don't have to change speeds unnec- essarily. Avoid heavy traffic whenever pos- sible. Always maintain a safe distance from other vehicles so you can avoid unneces- sary braking. This also reduces brake wear. o Drive at a moderate speed. The faster you drive, the more fuel your car uses. Driving at a moderate speed, especially on the high- way, is one of the most effective ways to reduce fuel consumption.

o Don't "ride" the brake or clutch pedal. This can increase fuel consumption and also increase wear on these components. In addition, driving with your foot resting on the brake pedal may cause the brakes to over- heat, which reduces their effectiveness and may lead to more serious consequences. o Take care of your tires. Keep them inflated to the recommended pressure. Incorrect inflation, either too much or too little, results in unnecessary tire wear. Check the tire pressures at least once a month.

SMOOTH CORNERING

C150A01A-AAT

Avoid braking or gear changing in corners, especially when roads are wet. Ideally, corners should always be taken under gentle accelera- tion. If you follow these suggestions, tire wear will be held to a minimum.

o Remember, your Hyundai does not require extended warm-up. As soon as the engine is running smoothly, you can drive away. In very cold weather, however, give your en- gine a slightly longer warm-up period.

o Don't "lug" or "over-rev" the engine. Lugging is driving too slowly in too high a gear result- ing in the engine bucking. If this happens, shift to a lower gear. Over-revving is racing the engine beyond its safe limit. This can be avoided by shifting at the recommended speeds.

o Use your air conditioning sparingly. The air conditioning system is operated by engine power so your fuel economy is reduced when you use it.

2 DRIVING YOUR HYUNDAI 20

o Be sure that the wheels are aligned cor- rectly. Improper alignment can result from hitting curbs or driving too fast over irregular surfaces. Poor alignment causes faster tire wear and may also result in other problems as well as greater fuel consumption.

o Keep your car in good condition. For better fuel economy and reduced maintenance costs, maintain your car in accordance with the maintenance schedule in Section 5. If you drive your car in severe conditions, more frequent maintenance is required (see Section 5 for details).

o Keep your car clean. For maximum service, your Hyundai should be kept clean and free of corrosive materials. It is especially impor- tant that mud, dirt, ice, etc. not be allowed to accumulate on the underside of the car. This extra weight can result in increased fuel consumption and also contribute to corro- sion.

o Travel lightly. Don't carry unnecessary weight in your car. Weight reduces fuel economy.

o Don't let the engine idle longer than neces- sary. If you are waiting (and not in traffic), turn off your engine and restart only when you're ready to go.

DRIVING YOUR HYUNDAI

21

C160E01A-AAT Change to "Winter Weight" Oil if Necessary

In some climates it is recommended that a lower viscosity "winter weight" oil be used during cold weather. See Section 9 for recommendations. If you aren't sure what weight oil you should use, consult your Hyundai dealer.

C160F01A-AAT Check Spark Plugs and Ignition System

Inspect your spark plugs as described in Sec- tion 6 and replace them if necessary. Also check all ignition wiring and components to be sure they are not cracked, worn or damaged in any way.

WINTER DRIVING

C160A01A-AAT The more severe weather conditions of winter result in greater wear and other problems. To minimize the problems of winter driving, you should follow these suggestions:

C160B01JM-AAT Snowy or Icy Conditions

To drive your vehicle in deep snow, it may be necessary to use snow tires or to install tire chains on your tires. If snow tires are needed, it is necessary to select tires equivalent in size and type of the original equipment tires. Failure to do so may adversely affect the safety and handling of your car. Furthermore, speeding, rapid acceleration, sudden brake applications, and sharp turns are potentially very hazardous practices. During deceleration, use engine braking to the fullest extent. Sudden brake applications on snowy or icy roads may cause skids to occur. You need to keep sufficient distance between the vehicle in operation in front and your vehicle. Also, apply the brake gently. It should be noted that installing tire chains on the tire will provide a greater driving force, but will not prevent side skids.

NOTE: o Tire chains are not legal in all states. Check state laws before fitting tire chains.

o Tire chains are to be used on front tires

only.

C160C01A-AAT Use High Quality Ethylene Glycol Coolant

Your Hyundai is delivered with high quality ethylene glycol coolant in the cooling system. It is the only type of coolant that should be used because it helps prevent corrosion in the cool- ing system, lubricates the water pump and prevents freezing. Be sure to replace or replen- ish your coolant in accordance with the main- tenance schedule in Section 5. Before winter, have your coolant tested to assure that its freezing point is sufficient for the temperatures anticipated during the winter.

C160D01A-AAT Check Battery and Cables

Winter puts additional burdens on the battery system. Visually inspect the battery and cables as described in Section 6. The level of charge in your battery can be checked by your Hyundai dealer or a service station.

2 DRIVING YOUR HYUNDAI 22

C160G01A-AAT To Keep Locks from Freezing

C160I01A-AAT Don't Let Your Parking Brake Freeze

C160K01A-AAT Carry Emergency Equipment

Depending on the severity of the weather where you drive your car, you should carry appropri- ate emergency equipment. Some of the items you may want to carry include tire chains, tow straps or chains, flashlight, emergency flares, sand, a shovel, jumper cables, a window scraper, gloves, ground cloth, coveralls, a blanket, etc.

To keep the locks from freezing, squirt an approved de-icer fluid or glycerine into the key opening. If a lock is covered with ice, squirt it with an approved de-icing fluid to remove the ice. If the lock is frozen internally, you may be able to thaw it out by using a heated key. Handle the heated key with care to avoid injury.

C160H02A-AAT Use Approved Window Washer Anti- Freeze in System

To keep the water in the window washer system from freezing, add an approved window washer anti-freeze solution in accordance with instruc- tions on the container. Window washer anti- freeze is available from Hyundai dealers and most auto parts outlets. Do not use engine coolant or other types of anti-freeze as these may damage the paint finish.

Under some conditions your parking brake can freeze in the engaged position. This is most likely to happen when there is an accumulation of snow or ice around or near the rear brakes or if the brakes are wet. If there is a risk the parking brake may freeze, apply it only tempo- rarily while you put the gear selector lever in "P" (automatic) or in first or reverse gear (manual transaxle) and block the rear wheels so the car cannot roll. Then release the parking brake.

C160J01A-AAT Don't Let Ice and Snow Accumulate Underneath

Under some conditions, snow and ice can build up under the fenders and interfere with the steering. When driving in severe winter condi- tions where this may happen, you should peri- odically check underneath the car to be sure the movement of the front wheels and the steering components is not obstructed.

HIGHER SPEED MOTORING

USE OF LIGHTS

TRAILER OR VEHICLE TOWING

DRIVING YOUR HYUNDAI

23

C170A01A-AAT Pre-Trip Inspections

1. Tires: Adjust the tire inflation pressures to specifica- tion. Low tire inflation pressures will result in overheating and possible failure of the tires. Avoid using worn or damaged tires which may result in reduced traction or tire failure.

NOTE: Never exceed the maximum tire inflation pressure shown on the tires.

2. Fuel, engine coolant and engine oil: High speed travel consumes more fuel than urban motoring. Do not forget to check both engine coolant and engine oil.

3. Drive belt: A loose or damaged drive belt may result in overheating of the engine.

C180A01A-AAT Check your lights regularly for correct opera- tion and always keep them clean. When driving during the day in conditions of poor visibility, it is helpful to drive with headlights on low beam. This enables you to be seen as well as to see.

C190A01S-AAT If you are considering towing with your car, you should first check with your State's Department of Motor Vehicles to determine their legal re- quirements. Since laws vary from State to State the require- ments for towing trailers, cars, or other types of vehicles or apparatus may differ. Ask your Hyundai dealer for further details before towing.

CAUTION:

Do not do any towing with your car during its first 1,200 miles (2,000 km) in order to allow the engine to properly break in. Fail- ure to heed this caution may result in seri- ous engine or transaxle damage.

2 DRIVING YOUR HYUNDAI 24

C190B01S-AAT Trailer Hitches

Select the proper hitch and ball combination, making sure that its location is compatible with that of the trailer or vehicle being towed. Use a quality non-equalizing hitch which distrib- utes the tongue load uniformly throughout the chassis.

The hitch should be bolted securely to the car and installed by a qualified technician. DO NOT USE A HITCH DESIGNED FOR TEMPORARY INSTALLATION AND NEVER USE ONE THAT ATTACHES ONLY TO THE BUMPER.

C190C01Y-AAT Trailer Brakes

If your trailer is equipped with a braking system, make sure it conforms to federal and/or local regulations and that it is properly installed and operating correctly.

NOTE: If you tow a trailer or vehicle, your car will require more frequent maintenance due to the additional load. See Maintenance Under Severe Usage Conditions" on page 5-6.

CAUTION:

o Never connect a trailer brake system

directly to the vehicle brake system.

o When towing a trailer on steep grades (in excess of 12%) pay close attention to the engine coolant temperature gauge to ensure the engine does not overheat. If the needle of the coolant temperature gauge moves across the dial towards "H" (HOT), pull over and stop as soon as it is safe to do so, and allow the engine to idle until it cools down. You may proceed once the engine has cooled sufficiently.

C190E01JM-AAT Trailer Weight Limit

Tongue load

Total trailer weight

C190E01JM

C190D01S-AAT Safety Chains

Should the hitch connection between your ve- hicle and the trailer or vehicle you are towing fail, the trailer or vehicle could wander dangerously across other lanes of traffic and ultimately leave the roadway. To eliminate this potentially dan- gerous situation, safety chains, attached be- tween your car and the trailer or towed vehicle, are required in most states.

o Keep the tongue load 10% of the total trailer

load.

o Tongue load

Total trailer weight

x 100 = 10% (MAX)

o Tongue loads can be increased or de- creased by re-distributing the load in the trailer. This can be verified by checking the total weight of the loaded trailer and then checking the load on the tongue.

!

CAUTION:

The following specifications are recom- mended when towing a trailer. The loaded trailer weight cannot safely exceed the val- ues in the chart.

Lbs. (kg)

Maximum Towable Weight Tongue

Trailer

1500(680) 2,000(907)

1,000(454)

150 (68)

Engine

2.0L 2.7L 2.0L 2.7L

With Brake Without Brake

NOTE: 1. Never load the trailer with more weight in the back than in the front. About 60% of the trailer load should be in the front half on the trailer and the remaining 40% in the rear.

2. The total gross vehicle weight with trailer must not exceed the Gross Vehicle Weight Rating (GVWR) shown on the vehicle identification plate (see page 8- 2). The total gross vehicle weight is the combined weight of the vehicle, driver, all passengers and their luggage, cargo, hitch, trailer tongue load and other op- tional equipment.

3. The front or rear axle weight must not exceed the Gross Axle Weight Rating (GAWR) shown on the vehicle identifi- cation plate (see page 8-2). It is possible that your towing package does not ex- ceed the GVWR but exceeds the GAWR. Improper trailer loading and/or too much luggage in the cargo area can overload the rear axle. Redistribute the load and check the axle weight again.

DRIVING YOUR HYUNDAI

25

WARNING:

o Improperly loading your vehicle and trailer can seriously affect its steering and braking performance causing a crash which could cause serious injury or death.

o Towing a trailer affected vehicle han-

dling and braking.

o Drive more slowly when towing a trailer and allow more distance when braking. o Be careful when driving in slippery and

windy conditions.

o Be careful when turning and while driv-

ing up and down hills.

o Do not exceed 45 mph or the posted towing speed limit, whichever is lower.

2 DRIVING YOUR HYUNDAI 26

C190F01O-AAT Trailer or Vehicle Towing Tips

1. Before towing, check hitch and safety chain connections as well as proper operation of the trailer running lights, brake lights, and turn signals.

2. Trailer towing requires more fuel than normal

conditions.

3. To maintain engine braking efficiency, do not tow a trailer with the transaxle in fifth gear (manual transaxle) or overdrive (automatic transaxle).

4. Always secure items in the trailer to prevent

load shift while driving.

5. Check the condition and air pressure of all tires on the trailer and your car. Low tire pressure can seriously affect the handling. Also check the spare tire.

6. The vehicle/trailer combination is more af-

fected by crosswind and buffeting. When being passed by a large vehicle, keep a constant speed and steer straight ahead. If there is too much wind buffeting, slow down to get out of the other vehicle's air turbulence. 7. When parking your car and trailer, especially on a hill, be sure to follow all the normal precautions. Turn your front wheel into the curb, set the parking brake firmly, and put the transaxle in 1st or Reverse (manual) or Park (automatic). In addition, place wheel chocks at each of the trailer's tires.

CAUTION:

If overheating should occur when towing, (the temperature gauge reads near the red zone), taking the following actions may reduce or eliminate the problem.

1. Turn off the air conditioner. 2. Reduce highway speed. 3. Select a lower gear when going uphill. 4. While in stop and go traffic, place the gear selector in park or neutral and idle the engine at a higher speed.

8.

If the trailer has electric brakes, start your vehicle and trailer moving, and then apply the trailer brake controller by hand to be sure the brakes are working. This lets you check your electrical connection at the same time. 9. During your trip, check occasionally to be sure that the load is secure, and that the lights and any trailer brakes are still working. 10.Avoid jerky starts, sudden acceleration or

sudden stops.

11.Avoid sharp turns and rapid lane changes. 12.Avoid holding the brake pedal down too long or too frequently. This could cause the brakes to overheat, resulting in reduced braking efficiency.

13.When going down a hill, shift into a lower gear

and use the engine braking effect. When ascending a long grade, downshift the transaxle to a lower gear and reduce speed to reduce chances of engine overloading and/or overheating.

14.If you have to stop while going uphill, do not hold the vehicle in place by pressing on the accelerator. This can cause the automatic transaxle to overheat. Use the parking brake or footbrake.

15.If the transaxle shifts frequently while going

up a hill, shift down one gear.

NOTE: When towing check transaxle fluid more frequently.

DRIVING YOUR HYUNDAI

27

(5)Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calcu- lated in Step 4.

(6)If your vehicle will be towing a trailer, load from your trailer will be trans- ferred to your vehicle. Consult this manual to determine how this re- duces the available cargo and lug- gage load capacity of your vehicle.

VEHICLE LOAD LIMIT

C190F02JM-AAT Tire and Loading Information Label

I030B01JM The tire label located on the driver's side of the center pillar outer panel gives the original tire size, cold tire pressures recommended for your ve- hicle, the number of people that can be in your vehicle and vehicle capacity weight.

Steps for Determining Correct Load Limit (1)Locate the statement "The combined weight of occupants and cargo should never exceed XXX pounds'' on your vehicle's placard.

(2)Determine the combined weight of the driver and passengers that will be riding in your vehicle.

(3)Subtract the combined weight of the driver and passengers from XXX kilograms or XXX pounds.

(4)The resulting figure equals the avail- able amount of cargo and luggage load capacity. For example, if the "XXX" amount equals 1400 lbs, and there will be five 150 lb. passengers in your vehicle, the amount of avail- able cargo and luggage load capac- ity is 650 lbs. (1400-750 (5 x 150) = 650 lbs.)

2 DRIVING YOUR HYUNDAI 28

Example 1

Example 2

Example 3

Item

Description

Vehicle Capacity Weight

C190F01JM

Total

1400 lbs

(635 kg)

Item

Description

Vehicle Capacity Weight

C190F02JM

Total

1400 lbs

(635 kg)

Item

Description

Vehicle Capacity Weight

C190F03JM

Total

1400 lbs

(635 kg)

Subtract Occupant Weight

300 lbs

150 lbs (68 kg) × 2

Available Cargo and

Luggage weight

(136 kg)

1100 lbs

(498 kg)

Subtract Occupant Weight

750 lbs

150 lbs (68 kg) x 5

Available Cargo and

Luggage Weight

(340 kg)

650 lbs

(295 kg)

Subtract Occupant Weight

860 lbs

172 lbs (78 kg) x 5

Available Cargo Weight

(390 kg)

540 lbs

(245 kg)

C190G01JM-AAT Compliance Label

Refer to your vehicle's tire and loading information label for specific informa- tion about your vehicle's capacity weight and seating positions. The combined weight of the driver, passengers and cargo should never exceed your vehicle's capacity weight.

C190G01JM The compliance label is located on the driver's side of the center piller outer panel.

The label shows the size of your original tires and the inflation pressures needed to obtain the gross weight capacity of your vehicle. This is called the GVWR (Gross Vehicle Weight Rating). The GVWR includes the weight of the ve- hicle, all occupants, fuel and cargo.

DRIVING YOUR HYUNDAI

29

This label also tells you the maximum weights that can be supported by the front and rear axles, called Gross Axle Weight Rating (GAWR). To find out the actual loads on your front and rear axles, you need to go to a weigh station and weigh your vehicle. Your dealer can help you with this. Be sure to spread out your load equally on both sides of the centerline.

WARNING:

o Never exceed the GVWR for your vehicle, or the GAWR for either the front or rear axle.

o Do not load your vehicle any heavier than the GVWR, or either the maximum front or rear GAWR. If you do, parts on your vehicle can break, and it can change the way your vehicle handles. This could cause you to lose control and crash. Also, overloading can shorten the life of your vehicle.

2 DRIVING YOUR HYUNDAI 30

NOTE: o Overloading your vehicle may cause damage. Repairs would not be covered by your warranty. Do not overload your vehicle.

o Using heavier suspension com- ponents to get added durability might not change your weight rat- ings. Ask your dealer to help you load your vehicle the right way.

The label will help you decide how much cargo and installed equipment your vehicle can carry.

If you carry items inside your vehicle – like suitcases, tools, packages, or any- thing else – they more as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, the items will keep going and can cause an injury if they strikes the driver or a passenger.

! WARNING:

Items you carry inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash.

o Put things in the cargo area of your vehicle. Try to spread the weight evenly.

o Never stack items, like suitcases, inside the vehicle above the tops of the seats.

o Do not leave an unsecured child

restraint in your vehicle.

o When you carry something inside

the vehicle, secure it.

o Do not drive with a seat folded

down unless necessary.

WHAT TO DO IN AN EMERGENCY

If the Engine will not Start .............................................. 3-2
Jump Starting ................................................................ 3-3
If the Engine Overheats ................................................ 3-4
Spare Tire ..................................................................... 3-5
If You Have a Flat Tire .................................................. 3-6
Changing a Flat Tire ...................................................... 3-7
If Your Car Must be Towed ......................................... 3-12
Emergency Towing ..................................................... 3-14

If You Lose Your Keys ................................................ 3-15 33

3

WHAT TO DO IN AN EMERGENCY

IF THE ENGINE WILL NOT START

D010A01A-AAT

WARNING:

If the engine will not start, do not push or pull the car to start it. This could result in a collision or cause other damage. In addi- tion, push or pull starting may cause the catalytic converter to be overloaded and create a fire hazard.

D010B02A-AAT If Engine Doesn't Turn Over or Turns Over Slowly

D010C02Y-AAT If Engine Turns Over Normally but Does Not Start

1. Check fuel level. 2. With the key in the "OFF" position, check all connectors at ignition, coil and spark plugs. Reconnect any that may be disconnected or loose.

3. Check the fuel line in the engine compart-

4.

ment. If the engine still does not start, call a Hyundai dealer or seek other qualified assistance.

D010D01A-AAT If Engine Stalls While Driving

1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place.

2. Turn on your emergency flashers. 3. Try to start the engine again. If your vehicle will not start, contact a Hyundai dealer or seek other qualified assistance.

1.

HJM5008
If your car has an automatic transaxle, be sure the gear selector lever is in "N" or "P" and the emergency brake is set.

2. Check the battery connections to be sure

they are clean and tight.

3. Turn on the interior light. If the light dims or goes out when you operate the starter, the battery is discharged.

4. Check the starter connections to be sure

they are securely tightened.

5. Do not push or pull the vehicle to start it. See

instructions for "Jump Starting".

JUMP STARTING

D020A03A-AAT

Discharged battery

Booster battery

HJM4001

WARNING:

The gas produced by the battery during the jump-start operation is highly explosive. If these instructions are not followed exactly, serious personal injury and damage to the vehicle may occur! If you are not sure how to follow this procedure, seek qualified assistance. Automobile batteries contain sulfuric acid. This is poisonous and highly corrosive. When jump starting, wear pro- tective glasses and be careful not to get acid on yourself, your clothing or on the car.

o If you should accidentally get acid on your skin or in your eyes, immediately remove any contaminated clothing and flush the area with clear water for at least 15 minutes. Then promptly obtain medical attention. If you must be transported to an emergency facil- ity, continue to apply water to the affected area with a sponge or cloth.

o The gas produced by the battery during the jump-start operation is highly explosive. Do not smoke or allow a spark or an open flame in the vicinity.

o The battery being used to provide the jump start must be 12-volt. If you cannot deter- mine that it is a 12-volt battery, do not attempt to use it for the jump start.

o To jump start a car with a discharged battery,

follow this procedure exactly:

1.

If the booster battery is installed in another vehicle, be sure the two vehicles are not touching.

2. Turn off all unnecessary lights and acces-

sories in both vehicles.

3. Attach the clamps of the jumper cable in the exact location shown on the illustration. First, attach one clamp of the jumper cable to the positive (+) post or cable of the discharged battery.

WHAT TO DO IN AN EMERGENCY

Then attach the other end of the same cable to the positive (+) post or cable of the booster battery. Next, using the other cable, attach one clamp to the negative (-) post or cable of the booster battery. Then attach the other end of that cable to a solid metal part of the engine of the vehicle with the discharged battery away from the battery. Do not con- nect the cable to any moving part.

4. Start the engine in the car with the booster battery and let it run for a few minutes. This will help to assure that the booster battery is fully charged. During the jumping operation, run the engine in this vehicle at about 2,000
rpm.

5. Start the engine in the car with the dis- charged battery using the normal starting procedure. After the engine starts, leave the jumper cables connected and let the engine run at fast idle or about 2,000 rpm for several minutes.

6. Carefully remove the jumper cables in the

reverse order of attachment.

If you do not know why your battery became discharged (because the lights were left on, etc.), have the charging system checked by your Hyundai dealer.

3

WHAT TO DO IN AN EMERGENCY

IF THE ENGINE OVERHEATS

D030A02A-AAT If your temperature gauge indicates overheat- ing, you experience a loss of power, or hear loud pinging or knocking, the engine is probably too hot. If this happens, you should:

1. Pull off the road and stop as soon as it is safe

to do so.

3.

2. Place the gear selector lever in "P" (auto- matic), or neutral (manual transaxle) and set the parking brake. If the air conditioning is on, turn it off. If engine coolant is running out under the car or steam is coming out from the hood, stop the engine. Do not open the hood until the coolant has stopped running or the steaming has stopped. If there is no visible loss of engine coolant and no steam, leave the engine running and check to be sure the engine cooling fan is operating. If the fan is not running, turn the engine off.

4. Check to see if the water pump drive belt is missing. If it is not missing, check to see that it is tight. If the drive belt seems to be satisfactory, check for coolant leaking from the radiator, hoses or under the car. (If the air conditioning had been in use, it is normal for cold water to be draining from it when you stop).

WARNING:

While the engine is running, keep hair, hands and clothing away from moving parts such as the fan and drive belts to prevent injury.

5.

If the water pump drive belt is broken or engine coolant is leaking out, stop the engine immediately and call the nearest Hyundai dealer for assistance.

WARNING:

Do not remove the radiator cap when the engine is hot. This can allow coolant to be blown out of the opening and cause seri- ous burns.

6.

If you cannot find the cause of the overheat- ing, wait until the engine temperature has returned to normal. Then, if coolant has been lost, carefully add coolant to the reservoir (page 6-9) to bring the fluid level in the reservoir up to the halfway mark.

7. Proceed with caution, keeping alert for fur- ther signs of overheating. If overheating happens again, call a Hyundai dealer for assistance.

CAUTION:

Serious loss of coolant indicates there is a leak in the cooling system and this should be checked as soon as possible by a Hyundai dealer.

SPARE TIRE

D040A01JM-AAT

TEMPORARY SPARE TIRE The following instructions for the tem- porary spare tire should be observed:

1. Check inflation pressure as soon as practical after installing the spare tire, and adjust to the specified pres- sure. The tire pressure should be periodically checked and maintained at the specified pressure while the tire is stored.

Spare Tire Pressure

Tire Size

T155/90R16

Inflation Pressure

60 psi (420 kPa)

2. The spare tire should only be used temporarily and should be returned to the luggage compartment as soon as the original tire can be repaired or replaced.

3. Continuous use at speeds of over 50
mph (80 km/h) is not recommended.

4. As the temporary spare tire is spe- cifically designed for your vehicle, it should not be used on any other vehicle.

5. The temporary spare tire should not be used on any other wheels, nor should standard tires, snow tires, wheel covers or trim rings be used with the temporary spare wheel. If such use is attempted, damage to these items or other car components may occur.

6. The temporary spare tire pressure should be checked once a month while the tire is stored.

CAUTION:

o Do not use snow chains with your

temporary spare tire.

o Do not use more than one tempo-

rary spare tire at a time.

o Do not tow a trailer while the tem-

porary spare tire is installed.

WHAT TO DO IN AN EMERGENCY

D040B01JM-GAT

Handling the Spare Tire

To remove the spare tire

HJM2167

1. Open the tail gate. 2. Remove the luggage mat. 3. Remove the luggage under tray cover to turn the lever toward "UNLOCK".

4. Remove the luggage under tray.

3. Have all passengers get out of the vehicle. Be sure they all get out on the side of the vehicle that is away from traffic.

4. Change the tire following the instruc- tions provided on the following pages.

WHAT TO DO IN AN EMERGENCY

HJM4008

5. Turn the installation bolt counter- clockwise with a wheel nut wrench to remove the spare tire. After replac- ing the spare tire, install and tighten the bolt firmly with your fingers until there is no more play in the spare tire.

IF YOU HAVE A FLAT TIRE

D050A02A-AAT If a tire goes flat while you are driving:

1. Take your foot off the accelerator pedal and let the car slow down while driving straight ahead. Do not apply the brakes immediately or attempt to pull off the road as this may cause a loss of control. When the vehicle has slowed to such a speed that it is safe to do so, brake carefully and pull off the road. Drive off the road as far as possible and park on firm, level ground. If you are on a divided high- way, do not park in the median area between the two traffic lanes.

2. When the car is stopped, turn on your emergency hazard flashers, set the parking brake and put the transaxle in "P" (automatic) or reverse (manual transaxle).

CHANGING A FLAT TIRE

D060A02HP-AAT

D060A01JM The procedure described on the follow- ing pages can be used to rotate tires as well as to change a flat tire. When preparing to change a flat tire, check to be sure the gear selector lever is in "P" (automatic) or reverse gear (manual transaxle) and that the parking brake is set, then:

! WARNING:

Your vehicle is equipped with tires designed to provide for safe ride and handling capability. Do not use a size and type of tire and wheel that is different from the one that is originally installed on your vehicle. It can affect the safety and performance of your vehicle, which could lead to handling failure or rollover and serious injury. When replacing the tires, be sure to equip all four tires with the tire and wheel of the same size, type, tread, brand and load-carrying capacity. If you nevertheless decide to equip your vehicle with any tire/wheel com- bination not recommended by Hyundai for off-road driving, you should not use these tires for high- way driving.

WHAT TO DO IN AN EMERGENCY

D060B01JM-AAT

1. Obtain Spare Tire and Tool

HJM4007
Remove the spare tire and remove the jack and tool bag from the luggage compartment.

NOTE: The spare tire is located under the luggage compartment floor.

WHAT TO DO IN AN EMERGENCY

D060C02A-AAT

2. Block the Wheel

Flat tire

D060D01A-AAT

3. Loosen Wheel Nuts

D060E01A-AAT

4. Put the Jack in Place

HJM4009
Block the wheel that is diagonally oppo- site from the flat to keep the vehicle from rolling when the vehicle is raised on the jack.

HJM4015
The wheel nuts should be loosened slightly before raising the car. To loosen the nuts, turn the wrench handle coun- terclockwise. When doing this, be sure that the socket is seated completely over the nut so it cannot slip off. For maximum leverage, position the wrench so the handle is to the left as shown in the drawing. Then, while holding the wrench near the end of the handle, push down on it with steady pressure. Do not remove the nuts at this time. Just loosen them about one-half turn.

HJM4010
The base of the jack should be placed on firm, level ground. The jack should be positioned as shown in the drawing.

Raise the car high enough so that the fully inflated spare tire can be installed. To do this, you will need more ground clearance than is required to remove the flat tire.

WARNING:

Do not get under the vehicle when it is supported by the jack! This is very dangerous as the vehicle could fall and cause serious injury or death. No one should stay in the vehicle while the jack is being used.

D060F03E-AAT

5. Raising the vehicle

Wrench bar

Wheel nut wrench

HFC4022
After inserting the wrench bar into the wheel nut wrench, install the wrench bar into the jack as shown in the drawing. To raise the vehicle, turn the wheel nut wrench clockwise. As the jack begins to raise the vehicle, double check that it is properly positioned and will not slip. If the jack is on soft ground or sand, place a board, brick, flat stone or other object under the base of the jack to keep it from sinking.

WHAT TO DO IN AN EMERGENCY

D060G01JM-AAT

6. Changing Wheels

D060G01JM Loosen the wheel nuts and remove them. Slide the wheel off the studs and lay it flat so it cannot roll away. To put the wheel on the hub, pick up the spare tire, line up the holes with the studs and slide the wheel onto them. If this is difficult, tip the wheel slightly and get the top hole in the wheel lined up with the top stud. Then jiggle the wheel back and forth until the wheel can be slid over the other studs.

WHAT TO DO IN AN EMERGENCY

10

D060G02JM

! WARNING:

If the vehicle has been driven re- cently, some pieces may be very hot. Use caution.

WARNING:

Wheels and wheel covers may have sharp edges. Handle them carefully to avoid possible severe injury. Be- fore putting the wheel into place, be sure that there is nothing on the hub or wheel (such as mud, tar, gravel, etc.) that interferes with the wheel from fitting solidly against the hub. If there is, remove it. If there is not good contact on the mounting sur- face between the wheel and hub, the wheel nuts could come loose and cause the loss of a wheel. Loss of a wheel may result in loss of control of the vehicle. This may cause serious injury or death.

D060H02O-AAT

7. Reinstall Wheel Nuts

D060H01JM To reinstall the wheel, hold it on the studs, put the wheel nuts on the studs and tighten them finger tight. The nuts should be installed with their small di- ameter ends directed inward. Jiggle the tire to be sure it is completely seated, then tighten the nuts as much as pos- sible with your fingers again.

D060I01E-AAT

8. Lower Vehicle and Tighten Nuts

HJM4016

Lower the car to the ground by turning the wheel nut wrench counterclock- wise. Then position the wrench as shown in the drawing and tighten the wheel nuts. Be sure the socket is seated completely over the nut. Do not stand on the wrench handle or use an exten- sion pipe over the wrench handle. Go around the wheel tightening every other nut until they are all tight. Then double-check each nut for tightness.

After changing wheels, have a techni- cian tighten the wheel nuts to their proper torque as soon as possible.

Wheel nut tightening torque: Steel wheel & aluminium alloy wheel: 65-80 lb.ft (900-1,100 kg.cm)

D060J02O-AAT

After Changing Wheels

WHAT TO DO IN AN EMERGENCY

11

mended, drive slowly to the nearest service station and inflate to the correct pressure. If it is too high, adjust it until it is correct. Always reinstall the valve cap after checking or adjusting tire pressure. If the cap is not replaced, air may leak from the tire. If you lose a valve cap, buy another and install it as soon as possible. After you have changed wheels, al- ways secure the flat tire in its place and return the jack and tools to their proper storage locations.

D060J01JM

If you have a tire gauge, remove the valve cap and check the air pressure. If the pressure is lower than recom-

3
12

WHAT TO DO IN AN EMERGENCY

IF YOUR VEHICLE MUST BE TOWED D080A01O-GAT If your vehicle has to be towed, it should be done by your Hyundai dealer or a commercial tow truck service. This will help assure that your vehicle is not damaged in towing. Also, profes- sionals are generally aware of local laws gov- erning towing. In any case, rather than risk damage to your car, it is suggested that you show this information to the tow truck operator. Be sure that a safety chain system is used and that all local laws are observed. It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment with all the wheels off the ground.

CAUTION:

o When towing the vehicle, take care not to cause damage to the bumper or under- body of the vehicle.

CAUTION:

incorrectly!

o Your vehicle can be damaged if towed

o Be sure the transaxle is in neutral. o When the engine will not start, be sure the steering is unlocked by placing the key in the "ACC" position.

D080B02O-AAT Towing the 2 Wheel Drive Vehicle

1)

2)

3)

dolly

D080A01JM

o Do not tow with sling type truck as this may cause damage to the bumper or underbody of the vehicle.

Your vehicle can be towed by wheel lift type truck (1), (2) or flatbed equipment (3).

D080B03JM

1) If the vehicle is being towed with the rear wheels on the ground, be sure the parking brake is released.

CAUTION:

D080B02O-AAT Towing the 4 Wheel Drive Vehicle

WHAT TO DO IN AN EMERGENCY

13

NOTE: Before towing, check the level of the auto- matic transaxle fluid. If it is below the "HOT" range on the dipstick, add fluid. If you cannot add fluid, a towing dolly must be used.

2) If any of the loaded wheels or suspension components are damaged or the vehicle is being towed with the front wheels on the ground, use a towing dolly under the front wheels.

dolly

dolly

When towing the 4WD vehicle, it must be towed by lifting all 4 wheels or using the towing dolly.

D080C04JM

HJM4019

A vehicle with an automatic transaxle should never be towed from the rear with the front wheels on the ground. This can cause se- rious damage to the transaxle. Be sure to use a towing dolly under the front wheels.

3) It is recommended that your vehicle be

towed with all the wheels off the ground.

WHAT TO DO IN AN EMERGENCY

14

CAUTION:

o The 4WD vehicle should never be towed with the wheels on the ground. This can cause serious damage to the transaxle or the 4WD system.

o When towing the vehicle, take care not to cause damage to the bumper or under- body of the vehicle.

D080D02O-AAT EMERGENCY TOWING

Towing Hooks

HJM4022

For emergency towing when no commercial tow vehicle is available, attach a tow cable, chain or strap to one of the towing hooks under the front/rear of your vehicle. Be very careful when attempting this procedure when the ve- hicle is on any unpaved surface to avoid dam- age to your vehicle. Nor should towing be attempted if the wheels, drive train, axles, steering or brakes are dam- aged. Before towing, be sure the transaxle is in neutral and the key is in "ACC" (with the engine off) or in the "ON" position (with the engine running). A driver must be in the towed vehicle to steer it and operate the brakes.

NOTE: To avoid serious damage to your 4WD ve- hicle, limit the towing to 10 mph and not for more than 1 mile at ANY TIME.

D080C03JM

o Do not tow with sling type truck as this may cause damage to the bumper or underbody of the vehicle.

Towing Hook

HJM4023

IF YOU LOSE YOUR KEYS

D120A01A-AAT If you lose your keys, many Hyundai dealers can make you a new key if you have your key number. If you lock the keys inside your car and you cannot obtain a new key, many Hyundai dealers can use special tools to open the door for you.

WHAT TO DO IN AN EMERGENCY

15

CORROSION PREVENTION & APPEARANCE CARE

Corrosion Protection ..................................................... 4-2
To Help Prevent Corrosion ........................................... 4-2
Washing and Waxing .................................................... 4-3
Cleaning the Interior ...................................................... 4-5

4 CORROSION PREVENTION AND APPEARANCE CARE

CORROSION PROTECTION

E010A01A-AAT Protecting Your Hyundai from Corro- sion

By using the most advanced design and con- struction practices to combat corrosion, Hyundai produces cars of the highest quality. However, this is only part of the job. To achieve the long-term corrosion resistance your Hyundai can deliver, the owner's cooperation and assistance is also required.

E010B01A-AAT Common Causes of Corrosion

The most common causes of corrosion on your car are:

o Road salt, dirt and moisture that is allowed to

accumulate underneath the car.

o Removal of paint or protective coatings by stones, gravel, abrasion or minor scrapes and dents which leave unprotected metal exposed to corrosion.

E010C01A-AAT High-Corrosion Areas

If you live in an area where your car is regularly exposed to corrosive materials, corrosion pro- tection is particularly important. Some of the common causes of accelerated corrosion are road salts, dust control chemicals, ocean air and industrial pollution.

E010D01A-AAT Moisture Breeds Corrosion

Moisture creates the conditions in which corro- sion is most likely to occur. For example, cor- rosion is accelerated by high humidity, particu- larly when temperatures are just above freez- ing. In such conditions, the corrosive material is kept in contact with the car surfaces by mois- ture that is slow to evaporate. Mud is particularly corrosive because it is slow to dry and holds moisture in contact with the vehicle. Although the mud appears to be dry, it can still retain the moisture and promote corro- sion. High temperatures can also accelerate corro- sion of parts that are not properly ventilated so the moisture can be dispersed. For all these reasons, it is particularly important to keep your car clean and free of mud or accumulations of other materials. This applies not only to the visible surfaces but particularly to the underside of the car.

TO HELP PREVENT CORROSION

E020A01A-AAT You can help prevent corrosion from getting started by observing the following:

E020B01A-AAT Keep Your Car Clean

The best way to prevent corrosion is to keep your car clean and free of corrosive materials. Attention to the underside of the car is particu- larly important.

o If you live in a high-corrosion area — where road salts are used, near the ocean, areas with industrial pollution, acid rain, etc.—, you should take extra care to prevent corrosion. In winter, hose off the underside of your car at least once a month and be sure to clean the underside thoroughly when winter is over.

o When cleaning underneath the car, give particular attention to the components under the fenders and other areas that are hidden from view. Do a thorough job; just dampening the accumulated mud rather than washing it away will accelerate corrosion rather than prevent it. Water under high pressure and steam are particularly effective in removing accumulated mud and corrosive materials.

o When cleaning lower door panels, rocker panels and frame members, be sure that drain holes are kept open so that moisture can escape and not be trapped inside to ac- celerate corrosion.

E020C02A-AAT Keep Your Garage Dry

Don't park your car in a damp, poorly ventilated garage. This creates a favorable environment for corrosion. This is particularly true if you wash your car in the garage or drive it into the garage when it is still wet or covered with snow, ice or mud. Even a heated garage can contrib- ute to corrosion unless it is well ventilated so moisture is dispersed.

CORROSION PREVENTION AND APPEARANCE CARE

WASHING AND WAXING

E020D02A-AAT Keep Paint and Trim in Good Condition

E030A01A-AAT Washing Your Hyundai

Scratches or chips in the finish should be covered with "touch-up" paint as soon as pos- sible to reduce the possibility of corrosion. If bare metal is showing through, the attention of a qualified body and paint shop is recommended.

Bird droppings : Bird droppings are highly cor- rosive and may damage painted surfaces in just a few hours. Always remove bird droppings as soon as possible.

E020E01A-AAT Don't Neglect the Interior

Moisture can collect under the floor mats and carpeting to cause corrosion. Check under the mats periodically to be sure the carpeting is dry. Use particular care if you carry fertilizers, clean- ing materials or chemicals in the car. These should be carried only in proper contain- ers and any spills or leaks should be cleaned up, flushed with clear water and thoroughly dried.

Never wash your car when the surface is hot from being in the sun. Always wash your car in the shade.

Wash your car frequently. Dirt is abrasive and can scratch the paint if it is not removed. Air pollution or acid rain may damage the paint and trim through chemical action if pollutants are allowed to remain in contact with the surface. If you live near the ocean or in an area where road salts or dust control chemicals are used, you should pay particular attention to the underside of the car. Start by rinsing the car to remove dust and loose dirt. In winter, or if you have driven through mud or muddy water, be sure to thor- oughly clean the underside as well. Use a hard direct stream of water to remove accumulations of mud or corrosive materials. Use a good quality car-washing solution and follow the manufacturer's directions on the package. These are available at your Hyundai dealer or auto parts outlet. Don't use strong household detergents, gasoline, strong solvents or abra- sive cleaning powders as these may damage the finish. Use a clean sponge or cloth, rinse it frequently and don't damage the finish by rubbing too hard. For stubborn spots, dampen them frequently and remove them a little at a time.

4 CORROSION PREVENTION AND APPEARANCE CARE

To clean whitewall tires, use a stiff brush or soapy steel-wool scouring pad.

To clean plastic wheel covers, use a clean sponge or soft cloth and water.

To clean cast aluminum alloy wheels, use a mild soap or neutral detergent. Do not use abrasive cleaners. Protect the bare-metal surfaces by cleaning, polishing and waxing. Because alumi- num is subject to corrosion, be sure to give aluminum alloy wheels special attention in win- ter. If you drive on salted roads, clean the wheels thoroughly afterwards.

After washing, be sure to rinse thoroughly. If soapy water dries on the finish, streaking will result.

When the weather is warm and the humidity low, you may find it necessary to rinse each section immediately after washing to avoid streaking.

After rinsing, dry the car using a damp chamois or soft, absorbent cloth. The reason for drying the car is to remove water from the car so it will dry without water spots. Don't rub, this can damage the finish.

If you find any nicks or scratches in the paint, use touch-up paint to cover them to prevent corrosion. To protect the paintwork of the car against corrosion, you must clean your Hyundai (at least once a month). Give special attention to the removal of salt, mud and other sub- stances on the underside of the splashboards of the car. Make sure that the outlets and the underside of the doors are open. Paint damage can be caused by small accumulation of tar, industrial precipitation, tree resin, insects and bird droppings, when not removed immediately. If water alone is not strong enough to remove the accumulated dirt, use a mild car washing solu- tion. Be sure to rinse the surface after washing to remove the solution. Never allow the solution to dry on the painted surfaces.

E030B01A-AAT Spot Cleaning

Don't use gasoline, strong solvents or corro- sive cleaning agents. These can damage the finish of the car. To remove road tar, use turpentine on a clean, soft cloth. Be gentle. To remove dead insects or tree sap, use warm water and mild soap or car-washing solution. Soak the spot and rub gently. If the paint has lost its luster, use a commercial car-cleaning polish.

E030C01A-AAT Polishing and Waxing

Always wash and dry the car before polishing or waxing or using a combination cleaner and wax. Use a good quality commercial product and follow the manufacturer's directions on the container. Polish and wax the bright trim pieces as well as the paint.

E030D01A-AAT When to Wax Again

You should polish and wax the car again when water no longer beads on a clean surface but spreads out over a larger area.

CLEANING THE INTERIOR

E040A01A-AAT To Clean the Vinyl Upholstery

To clean the vinyl upholstery, first remove loose dirt and dust with a vacuum cleaner. Then apply a solution of mild soap or detergent and water using a clean sponge or soft cloth. Allow this to stay on the surface to loosen the dirt, then wipe with a clean damp sponge or cloth. If all the dirt stains are not removed, repeat this procedure until the upholstery is clean. Do not use gaso- line, solvent, paint thinner or other strong clean- ers.

E030E01A-AAT Maintaining Bumpers

Special precautions must be observed to pre- serve the appearance of the bumpers on your Hyundai. They are:

o Be careful not to spill battery electrolyte or hydraulic brake fluid on the bumpers. If you do, wash it off immediately with clear water. o Be gentle when cleaning the bumper sur- faces. They are made of soft plastic and the surface can be damaged if mistreated. Do not use abrasive cleaners. Use warm water and mild soap or car-washing solution.

o Do not expose the bumpers to high tem- peratures. For example, if you have your car repainted, do not leave the bumpers on the car if the car is going to be placed in a high- temperature paint booth.

CORROSION PREVENTION AND APPEARANCE CARE

E040B01A-AAT To Clean the Leather Upholstery (If installed)

In the normal course of use, leather upholstered surfaces will, like any material, pick-up dust and dirt. This dust and dirt must be cleaned off or it may work into the surface of the leather, caus- ing damage.

Fine leather needs care, and should be cleaned when necessary. Washing leather thoroughly with soap and water will keep your leather lustrous, beautiful and ensure you have many years of wear. Take a piece of cheese cloth and using any mild soap and lukewarm water, work up a good lather. Thoroughly wash the leather. Wipe clean with a slightly damp cloth and dry with soft cloth. Do this as often as the leather becomes soiled.

During tanning operations, sufficient oils are incorporated through processing that none need be applied during the life of the leather. Oil applied to the finished surface will in no way help the leather and may do more harm than good. Varnishes and furniture polishes should never be used under any conditions.

ANY QUESTIONS?

E050A01A-AAT If you have any questions about the care of your car, consult your Hyundai dealer.

4 CORROSION PREVENTION AND APPEARANCE CARE

E040C01A-AAT Cleaning the Carpets

E040E01A-AAT Cleaning the Windows

You may use any household window cleaner on the windows. However, when cleaning the in- side of the rear window be careful not to damage the rear window defroster wiring.

Use a foam-type carpet cleaner. Cleaners of this type are available in aerosol cans in liquid form or powder. Read the instructions and follow them exactly. Using a vacuum cleaner with the appropriate attachment, remove as much dirt from the carpets as possible. Apply the foam following the manufacturer's direc- tions, then rub in overlapping circles. Do not add water. These cleaners work best when the carpet is kept as dry as possible.

E040D01A-AAT Cleaning the Seat Belts

To clean the seat belts, use a cloth or sponge with mild soap or detergent and warm water. Do not use strong detergents, dye, bleach or abra- sive materials on the seat belts as this may weaken the fabric. While cleaning the belts, inspect them for ex- cessive wear, cuts, fraying or other signs of damage and replace them if necessary.

VEHICLE MAINTENANCE REQUIREMENTS

Maintenance Intervals ................................................... 5-2
Scheduled Maintenance ................................................ 5-4
Maintenance under Severe Usage Conditions ............. 5-6
Explanation of Scheduled Maintenance Items .............. 5-7

5 VEHICLE MAINTENANCE REQUIREMENTS MAINTENANCE INTERVALS

F010A01A-AAT Service Requirements

F010B01A-AAT Maintenance Requirements

F010C01A-AAT Specified Scheduled Procedures

To ensure that you receive the greatest number of miles of satisfying operation from your Hyundai, certain maintenance procedures must be per- formed. Although careful design and engineer- ing have reduced these to a minimum, those that are required are of the utmost importance. It is your responsibility to have these mainte- nance procedures performed to comply with the terms of the warranties covering your new Hyundai. The Owner's Handbook supplied with your new vehicle provides further information about these warranties.

The maintenance required for your Hyundai can be divided into three main areas:

o Specified scheduled procedures o General checks o Do-it-yourself maintenance

These are the procedures such as inspections, adjustments and replacements that are listed in the maintenance charts starting on page 5-4. These procedures must be performed at the intervals shown in the maintenance schedule to assure that your warranty remains in effect. Although it is strongly recommended that they be performed by the trained technicians at your Hyundai dealer, these procedures may be per- formed at any qualified service facility. It is suggested that genuine Hyundai service parts be used for any required repairs or re- placements. Other parts of equivalent quality such as engine oil, engine coolant, manual or auto transaxle oil, brake fluid and so on which are not supplied by Hyundai Motor Company or its distributor may be used without affecting your warranty coverage but you should always be sure these are equivalent to the quality of the original Hyundai parts. Your Owner's Hand- book provides further information about your warranty coverage.

F010D02A-AAT General Checks

F010F01A-AAT A Few Tips

These are the regular checks you should per- form when you drive your Hyundai or you fill the fuel tank. A list of these items will be found on page 6-4.

F010E01A-AAT Do-It-Yourself Maintenance

If you are mechanically inclined, own a few tools that are required and want to take the time to do so, you can inspect and service a number of items. For more information about doing it your- self, see Section 6.

o Whenever you have your Hyundai serviced, keep copies of the service records in your glovebox. This will help ensure that you can document that the required procedures have been performed to keep your warranties in effect. This is especially important when service is not performed by an authorized Hyundai dealer.

o If you choose to do your own maintenance and repairs, you may find it helpful to have an official Hyundai Shop Manual. A copy of this publication may be purchased at your Hyundai dealer's parts department.

VEHICLE MAINTENANCE REQUIREMENTS
