(P.47)

TRUNK-OPEN INDICATOR IMMOBILIZER SYSTEM INDICATOR CRUISE CONTROL INDICATOR (P.47) MALFUNCTION INDICATOR LAMP

(P.47) (P.49)

(P.47, 219)

LOW OIL PRESSURE INDICATOR

(P.46, 218)

I n s t r u m e n t s a n d C o n t r o l s

SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR

(P.47)

CHARGING SYSTEM INDICATOR

(P.46, 218)

* *

The U.S. instrument panel is shown. Differences for the Canadian models are noted in the text.

1 : 2 : Only on CR models. CR models are not available in Canada.

45

2009 S2000 Instrument Panel Indicators

The instrument panel has many indicators to give you important information about your vehicle.

Seat Belt Reminder Indicator

This indicator comes on when you turn the ignition switch to the ON (II) position. It reminds you and your passenger to fasten your seat belts. A beeper also sounds if you and your passenger have not fastened your seat belts.

If you turn the ignition switch to the ON (II) position before fastening your seat belts, the beeper sounds, and the indicator flashes. If you do not fasten your seat belts before the beeper stops, the indicator stops flashing but remains on.

46

If your passenger does not fasten their seat belt, the indicator comes on about 6 seconds after the ignition switch is turned to the ON (II) position.

If either of you do not fasten your seat belt while driving, the beeper will sound and the indicator will flash again at regular intervals. For more information, see page

16

.

Low Oil Pressure Indicator

The engine can be severely damaged if this indicator flashes or stays on when the engine is running. For more information, see page 218

.

Charging System Indicator

If this indicator comes on when the engine is running, the battery is not being charged. For more information, see page

218

.

U.S.

Canada

Parking Brake and Brake System Indicator

This indicator has two functions:

1.

2.

It comes on when you turn the ignition switch to the ON (II) position. It is a reminder to check the parking brake. A beeper sounds if you drive with the parking brake not fully released. Driving with the parking brake not fully released can damage the brakes and tires.

If it stays on after you have fully released the parking brake while the engine is running, or if it comes on while driving, there could be a problem with the brake system. For more information, see page

220

.

2009 S2000 Supplemental Restraint System Indicator

This indicator comes on briefly when you turn the ignition switch to the ON (II) position. If it comes on at any other time, it indicates a potential problem with your airbags. This indicator will also alert you to a potential problem with your automatic seat belt tensioners, driver’s seat position sensor, or the passenger’s seat weight sensors. For more information, see page

.25

Anti-lock Brake System (ABS) Indicator

This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position, and when you push the START button. If it comes on at any other time, there is a problem with the ABS. If this happens, have your vehicle checked at a dealer. With this indicator on, your vehicle still has normal braking ability but no anti-lock function. For more . information, see page

150

Instrument Panel Indicators

See page

Malfunction Indicator Lamp 219

.

Trunk-open Indicator

This indicator comes on if the trunk lid is not closed tightly.

Door-open Indicator

This indicator comes on if either door is not closed tightly.

Cruise Control Indicator

This indicator comes on when you set the cruise control. See page 124 cruise control.

for information on operating the

I n s t r u m e n t s a n d C o n t r o l s

47

2009 S2000 ‘‘Daytime Running Lights’’ Indicator

If this indicator comes on when the ignition switch is turned to the ON (II) position and the parking brake is released, it means there is a problem in the high beam headlight’s circuit. Have your vehicle checked by your dealer.

Instrument Panel Indicators

Electric Power Steering (EPS) Indicator

This indicator normally comes on when you turn the ignition to the ON (II) position and goes off after the engine starts. If it comes on at any other time, there is a problem in the electric power steering system. If this happens, stop the vehicle in a safe place and turn off the engine. Reset the system by restarting the engine. The indicator will not turn off immediately. If it does not go off after driving a short distance, or comes on again while driving, take the vehicle to your dealer to have it checked. With the indicator on, the EPS may be turned off, making the vehicle harder to steer.

If the power steering system overheats while driving, the assist is reduced and steering may feel slightly harder.

48

Driving with the power steering system continuously overheating can cause system damage.

Turn Signal and Hazard Warning Indicators

The left or right turn signal indicator blinks when you signal a lane change or turn. If the indicator does not blink or blinks rapidly, it usually means one of the turn signal bulbs is burned out (see page ). Replace the bulb as soon as possible, since other drivers cannot see that you are signaling.

181

When you press the hazard warning button, both turn signal indicators blink. All turn signals on the outside of the vehicle should flash.

2009 S2000 High Beam Indicator

This indicator comes on with the high beam headlights. For more information, see page

59

.

When the daytime running lights (DRL) are on, this indicator comes on with reduced brightness.

Immobilizer System Indicator

This indicator comes on for a few seconds when you turn the ignition switch to the ON (II) position. It will then go off if you have inserted a properly coded ignition key. If it is not a properly coded key, the indicator will blink, and the engine will not start (see page

63

).

This indicator also blinks several times when you turn the ignition switch from the ON (II) position to the ACCESSORY (I) or LOCK (0) position.

Instrument Panel Indicators

Low Fuel Indicator

This indicator comes on as a reminder that you must refuel soon.

When the indicator comes on, there is about 2.22 US gal (8.4 ) of fuel remaining in the tank.

When the needle reaches E, there is a very small amount of fuel in the tank.

I n s t r u m e n t s a n d C o n t r o l s

49

2009 S2000 Instrument Panel Indicators

Vehicle Stability Assist (VSA) System Indicator

This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position.

If it comes on and stays on at any other time, or if it does not come on when you turn the ignition switch to the ON (II) position, there is a problem with the VSA system. Take your vehicle to a dealer to have it checked. Without VSA, your vehicle still has normal driving ability, but will not have VSA traction and stability enhancement. See page for more information on the 152 VSA system.

50

VSA Activation Indicator

This indicator has three functions:

It comes on as a reminder that you have turned off the vehicle stability assist (VSA) system.

It flashes when VSA is active (see page

152

).

Maintenance Minder Indicator

This indicator reminds you that it is time to take your vehicle in for scheduled maintenance. The maintenance main items and sub items will be displayed in the information display. See page more information on the maintenance minder.

161

for

It comes on along with the VSA system indicator if there is a problem with the VSA system.

This indicator goes off when your dealer resets it after completing the required maintenance service.

1.

2.

3.

This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. For more information, see page

152

.

2009 S2000 Low Tire Pressure Indicator

This indicator normally comes on for a few seconds when you turn the ignition to the ON (II) position. If it comes on while driving, it indicates that one or more of your vehicle’s tires are extremely low on pressure.

ExceptCRmodels If this happens, pull to the side of the road when it is safe, check which tire has lost the pressure, and determine the cause. If it is because of a flat tire, replace the flat tire with the compact spare (see page ), and have the flat tire repaired as soon as possible. If two or more tires are underinflated, call a professional towing service (see page 154

for more information.
