seat belt properly.


If the indicator comes on with no front seat passenger and no objects on the seat, or with an adult riding there, something may be interfering with the weight sensors. Look for and remove: ● Any items under the front


passenger's seat.


● Any object(s) hanging on the seat


or in the seat-back pocket.


● Any object(s) touching the rear of


the seat-back.


If no obstructions are found, have your vehicle checked by a dealer as soon as possible.


How the Passenger Airbag Off Indicator Works


PASSENGER AIRBAG OFF INDICATOR


This indicator alerts you that the passenger's front airbag has been shut off because weight sensors detect about 65 lbs (29 kg) or less (the weight of an infant or small child) on the front passenger's seat. It does notmeanthere is a problem with the airbag.


32


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Additional Information About Your Airbags


● Ifyourvehiclehasamoderateto


severeimpact.Even if your airbags do not inflate, your dealer should inspect the driver's seat position sensor, the front passenger's weight sensors, the front seat belt tensioners, and all seat belts and their anchors worn during a crash to make sure they are operating properly.


Additional Safety Precautions ● Donotattempttodeactivateyour


airbags.Together, airbags and seat belts provide the best protection.


● Donottamperwithairbag


componentsorwiringforany reason.Tampering could cause the airbags to deploy, possibly causing very serious injury.


● Donotexposethefront


passenger'sseat-backtoliquid.If water or another liquid soaks into the seat-back, it can prevent the side airbag cutoff system from working properly.


Airbag Service Your airbag systems are virtually maintenance free, and there are no parts you can safely service. However, you must have your vehicle serviced if: ● Anairbageverinflates.Any airbag


that has deployed must be replaced along with the control unit and other related parts. Any seat belt tensioner that activates must also be replaced. Do not try to remove or replace any airbag by yourself. This must be done by an authorized dealer or a knowledgeable body shop.


● TheSRSindicatoralertsyoutoa problem.Take your vehicle to an authorized dealer as soon as possible. If you ignore this indication, your airbags may not operate properly.


CONTINUED 33


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Additional Information About Your Airbags


● Donotremoveormodifyafront


seatwithoutconsultingyour dealer.This could make the driver's seat position sensor or the front passenger's weight sensors ineffective. If it is necessary to remove or modify a front seat to accommodate a person with disabilities, first contact Honda Automobile Customer Service at (800) 999-1009.


34


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Children - General Guidelines


All Children Must Be Restrained Each year, many children are injured or killed in vehicle crashes because they are either unrestrained or not properly restrained. In fact, traffic collisions are the number one cause of death of children age 12 and under. To reduce the number of child deaths and injuries, every state requires that infants and children be restrained when they ride in a vehicle. Infantsandsmallchildrenmustbe restrainedinanapprovedchildseat thatisproperlysecuredtothevehicle (see pages 40 - 48).


Children who are unrestrained or improperly restrained can be seriously injured or killed in a crash.


Any child too small for a seat belt should be properly restrained in a child seat. A larger child should be properly restrained with a seat belt and use a booster seat if necessary.


Largerchildrenmustberestrained withalap/shoulderbeltandrideona boosterseatuntiltheseatbeltfits themproperly(see pages 49 - 51).


35


Children depend on adults to protect them. However, despite their best intentions, many adults do not know how to properlyprotect child passengers. If you have children, or ever need to drive with a child in your vehicle, be sure to read this section. It begins with important general guidelines, then presents special information for infants, small children, and larger children.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Children - General Guidelines


All Children Should Sit in a Back Seat According to crash statistics, children of all ages and sizes are safer when they are restrained in a back seat. The National Highway Traffic Safety Administration recommends that all children aged 12 and under be properly restrained in a back seat. Some states have laws restricting where children may ride. Children who ride in back are less likely to be injured by striking interior vehicle parts during a collision or hard braking. Also, children cannot be injured by an inflating front airbag when they ride in the back.


The Passenger's Front Airbag Can Pose Serious Risks Front airbags have been designed to help protect adults in a moderate to severe frontal collision. To do this, the passenger's front airbag is quite large, and it can inflate with enough force to cause very serious injuries. Even though your vehicle has an advanced front airbag system that automatically turns the passenger's front airbag off under certain circumstances (see page 32), please follow these guidelines: Infants Neverputarear-facingchildseatin thefrontseatofavehicleequipped withapassenger'sfrontairbag.If the airbag inflates, it can hit the back of the child seat with enough force to kill or very seriously injure an infant.


SmallChildren Placingaforward-facingchildseatin thefrontseatofavehicleequipped withapassenger'sfrontairbagcanbe hazardous.If the vehicle seat is too far forward, or the child's head is thrown forward during a collision, an inflating front airbag can strike the child with enough force to kill or very seriously injure a small child. LargerChildren Childrenwhohaveoutgrownchild seatsarealsoatriskofbeinginjured orkilledbyaninflatingpassenger's frontairbag.Whenever possible, larger children should sit in the back seat, on a booster seat if needed, and be properly restrained with a seat belt (see page 49 for important information about protecting larger children).


36


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


To remind you of the passenger's front airbag hazards, and that children must be properly restrained in a back seat, your vehicle has warning labels on the dashboard and on the front visors. Please read and follow the instructions on these labels.


Protecting Children - General Guidelines


SUN VISORS


DASHBOARD


37


If a child requires physical attention or frequent visual contact, we strongly recommend that another adult ride with the child in the back seat. The back seat is far safer for a child than the front.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Children - General Guidelines


If a Child Requires Close Attention Many parents say they prefer to put an infant or a small child in the front passenger seat so they can watch the child, or because the child requires attention. Placing a child in the front seat exposes the child to hazards in a frontal collision, and paying close attention to a child distracts the driver from the important tasks of driving, placing both of you at risk.


If You Must Drive with Several Children Your vehicle has two back seats where children can be properly restrained. If you ever have to carry a group of children, and a child must ride in front: ● Place the largest child in the front


seat, provided the child is large enough to wear the lap/shoulder belt properly (see page 49).


● Move the vehicle seat as far to the


rear as possible (see page 83).


● Have the child sit upright and well


back in the seat (see page 15).


● Make sure the seat belt is properly positioned and secured (see page 14).


38


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Children - General Guidelines


Additional Safety Precautions ● Neverholdaninfantorchildon yourlap.If you are not wearing a seat belt in a crash, you could be thrown forward and crush the child against the dashboard or a seat-back. If you are wearing a seat belt, the child can be torn from your arms and be seriously hurt or killed.


● Neverputaseatbeltoveryourself


andachild.During a crash, the belt could press deep into the child and cause serious or fatal injuries.


● Neverlettwochildrenusethe sameseatbelt.If they do, they could be very seriously injured in a crash.


● Makesureanyunusedseatbelt thatachildcanreachisbuckled, thelockableretractorisactivated, andthebeltisfullyretractedand locked.If a child wraps a loose seat belt around their neck, they can be seriously or fatally injured. (See page 46 for how to activate and deactivate the lockable retractor.)


● Donotleavechildrenaloneina vehicle.Leaving children without adult supervision is illegal in most states, and can be very hazardous. For example, infants and small children left in a vehicle on a hot day can die from heatstroke. A child left alone with the key in the ignition switch can accidentally set the vehicle in motion, possibly injuring themselves or others.


● Lockalldoors,thetailgateandthe


hatchwhenyourvehicleisnotin use.Children who play in vehicles can accidentally get trapped inside. Teach your children not to play in or around vehicles.


● Keepvehiclekeysandremote transmittersoutofthereachof children.Even very young children learn how to unlock vehicle doors, turn on the ignition, and open the tailgate or hatch, which can lead to accidental injury or death.


39


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Infants and Small Children


Protecting Infants


Two types of seats may be used: a seat designed exclusively for infants, or a convertible seat used in the rear- facing, reclining mode. Donotputarear-facingchildseatin aforward-facingposition.If placed facing forward, an infant could be very seriously injured during a frontal collision.


ChildSeatType An infant must be properly restrained in a rear-facing, reclining child seat until the child reaches the seat maker's weight or height limit for the seat, and the child is at least one year old. Only a rear-facing child seat provides proper support for a baby's head, neck, and back.


40


Rear-facingChildSeatPlacement A rear-facing child seat can be placed in any seating position in the back seat, but not in the front. Neverputa rear-facingchildseatinthefrontseat. If the passenger's front airbag inflates, it can hit the back of the child seat with enough force to kill or seriously injure an infant. When properly installed, a rear- facing child seat may prevent the driver or a front passenger from moving their seat as far back as recommended, or from locking their seat-back in the desired position. It could also interfere with proper operation of the passenger's advanced front airbag system.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


In any of these situations, we strongly recommend that you install the child seat directly behind the front passenger's seat, move the seat as far forward as needed, and leave it unoccupied. Or, you may wish to get a smaller rear-facing child seat.


Placing a rear-facing child seat in the front seat can result in serious injury or death during a crash.


Always place a rear-facing child seat in the back seat, not the front.


Protecting Infants and Small Children


Protecting Small Children


ChildSeatType Many states allow a child one year of age or older who also meets the minimum size and weight requirements to transition from a rear- facing child seat to a forward facing seat. Know the requirements where you are driving and follow the child seat instructions. Many experts recommend use of a rear-facing seat up to age two, if the child's height and weight are appropriate for a rear-facing seat.


Of the different seats available, we recommend those that have a five-point harness system as shown. We also recommend that a small child use the child seat until the child reaches the weight or height limit for the seat. ChildSeatPlacement We strongly recommend placing a forward-facing child seat in a back seat, not the front. Placingaforward-facingchildseatin thefrontseatofavehicleequipped withapassenger'sairbagcanbe hazardous.If the vehicle seat is too far forward, or the child's head is thrown forward during a collision, an inflating airbag can strike the child with enough force to cause very serious or fatal injuries.


CONTINUED 41


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Protecting Infants and Small Children, Selecting a Child Seat


Selecting a Child Seat When buying a child seat, you need to choose either a conventional child seat, or one designed for use with the Lower Anchors and Tethers for CHildren (LATCH) system. Conventional child seats must be secured to a vehicle with a seat belt, whereas LATCH-compatible seats are secured by attaching the seat to hardware built into the rear seats. Since LATCH-compatible child seats are easier to install and reduce the possibility of improper installation, we recommend selecting this style.


In seating positions and vehicles not equipped with LATCH, a LATCH- compatible child seat can be installed using a seat belt. Whatever type of seat you choose, to provide proper protection, a child seat should meet three requirements: 1. ThechildseatshouldmeetFederal


MotorVehicleSafetyStandard 213.Look for FMVSS 213 on the box.


2. Thechildseatshouldbeofthe


propertypeandsizetofitthechild. Rear-facing for infants, forward- facing for small children.


Even with advanced front airbags that automatically turn the passenger's front airbag off (see page 32), a back seat is the safest place for a small child. If it is necessary to put a forward-facing child seat in the front, move the vehicle seat as far to the rear as possible, and be sure the child seat is firmly secured to the vehicle and the child is properly strapped in the seat.


Placing a forward-facing child seat in the front seat can result in serious injury or death if the front airbag inflates.


If you must place a forward-facing child seat in front, move the vehicle seat as far back as possible, and properly restrain the child.


42


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


3. Thechildseatshouldfitthevehicle


seatingposition(orpositions) whereitwillbeused.


Before purchasing a conventional child seat, or using a previously purchased one, we recommend that you test the seat in the specific vehicle seating position or positions where the seat will be used.


Selecting a Child Seat, Installing a Child Seat


Installing a Child Seat After selecting a proper child seat and a good place to install the seat, there are three main steps in installing the seat: 1. Properlysecurethechildseatto


thevehicle.All child seats must be secured to the vehicle with the lap part of a lap/shoulder belt or with the LATCH (Lower Anchors and Tethers for CHildren) system. A child whose seat is not properly secured to the vehicle can be endangered in a crash.


2. Makesurethechildseatisfirmly


secured.After installing a child seat, push and pull the seat forward and from side-to-side to verify that it is secure.


A child seat secured with a seat belt should be installed as firmly as possible. However, it does not need to be ‘‘rock solid.’’ Some side-to-side movement can be expected and should not reduce the child seat's effectiveness. If the child seat is not secure, try installing it in a different seating position, or use a different style of child seat that can be firmly secured. 3. Securethechildinthechildseat.


Make sure the child is properly strapped in the child seat according to the child seat maker's instructions. A child who is not properly secured in a child seat can be seriously injured in a crash.


The following pages provide guidelines on how to properly install a child seat. A forward-facing child seat is used in all examples, but the instructions are the same for rear- facing child seats.


43


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Installing a Child Seat


Installing a Child Seat with LATCH


MARKS


ANCHOR COVER


Rigid-type


To install a LATCH-compatible child seat: 1. Remove both anchor covers by


pulling forward.


2. Make sure there are no objects


near the anchors that could prevent a secure connection between the child seat and the anchors.


3. Place the child seat on the vehicle


seat, then attach the seat to the lower anchors according to the child seat maker's instructions. Some LATCH-compatible seats have a rigid-type connector as shown above.


LOWER ANCHORS


Your vehicle is equipped with LATCH (Lower Anchors and Tethers for CHildren) at the rear seats. The lower anchors are located between the seat-back and seat bottom, and are to be used only with a child seat designed for use with LATCH. The location of each lower anchor is indicated by a small button above the anchor point.


44


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Installing a Child Seat


TETHER ANCHOR


Flexible-type


Other LATCH-compatible seats have a flexible-type connector as shown above. 4. Whatever type you have, follow the child seat maker's instructions for adjusting or tightening the fit.


5. Remove the head restraint (see


page 85). Make sure the removed head restraints are secured in the cargo area, and reinstalled when the child seat is removed.


6. Route the tether strap over the top of the seat-back, making sure the strap is not twisted.


ANCHOR COVER


7. Slide the anchor cover open.


CONTINUED 45


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Installing a Child Seat with a Lap/ Shoulder Belt When not using the LATCH system, all child seats must be secured to the vehicle with the lap part of a lap/ shoulder belt. In addition, the lap/shoulder belts in all seating positions except the driver's have a lockable retractor that must be activated to secure a child seat.


1. With the child seat in the desired


seating position, route the belt through the child seat according to the seat maker's instructions, then insert the latch plate into the buckle and remove any slack from the lap portion of the belt.


Installing a Child Seat


TETHER ANCHOR


TETHER STRAP HOOK 8. Attach the tether strap hook to the


tether anchor, then tighten the strap as instructed by the child seat maker. If the tether strap is too long and cannot be tightened firmly, find a route where the strap can be tightened securely.


9. Push and pull the child seat


forward and from side-to-side to verify that it is secure.


46


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Installing a Child Seat


2. To activate the lockable retractor, slowly pull the shoulder part of the belt all the way out until it stops, then let the belt feed back into the retractor.


3. After the belt has retracted, tug on it. If the belt is locked, you will not be able to pull it out. If you can pull the belt out, it is not locked, and you will need to repeat these steps.


4. After confirming that the belt is locked, grab the shoulder part of the belt near the buckle, and pull up to remove any slack from the lap part of the belt. Remember, if the lap part of the belt is not tight, the child seat will not be secure. To remove slack, it may help to put weight on the child seat, or push on the back of the seat while pulling up on the belt.


5. Push and pull the child seat


forward and from side-to-side to verify that it is secure enough to stay upright during normal driving maneuvers. If the child seat is not secure, unlatch the belt, allow it to retract fully, then repeat these steps.


To deactivate the lockable retractor and remove a child seat, unlatch the buckle, unroute the seat belt, and let the belt fully retract.


47


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Installing a Child Seat


Installing a Child Seat with a Tether


TETHER ANCHORAGE POINTS


A child seat with a tether can be installed in either back seat, using one of the anchor points shown above. Since a tether can provide additional security to the lap/shoulder belt installation, we recommend using a tether whenever one is required or available.


48


TETHER ANCHOR


TETHER STRAP HOOK


ANCHOR COVER


1. After securing the child seat in the


desired position (see page 46), remove the head restraint (see page 85), then route the tether strap over the top of the seat-back.


2. Slide the anchor cover open as


shown.


TETHER ANCHOR


3. Attach the tether strap hook to the


anchor, making sure the strap is not twisted.


4. Tighten the strap according to the


seat maker's instructions. Make sure the removed head restraint is secured in the cargo area. Reinstall the head restraint in place when you remove the child seat.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Checking Seat Belt Fit


When a child reaches the recommended weight or height limit for a forward-facing child seat, the child should sit in a back seat on a booster seat and wear the lap/ shoulder belt. The following pages give instructions on how to check proper seat belt fit, what kind of booster seat to use if one is needed, and important precautions for a child who must sit in front.


Allowing a child age 12 or under to sit in front can result in injury or death if the passenger's front airbag inflates.


If a child must ride in front, move the vehicle seat as far back as possible, use a booster seat if needed, have the child sit up properly and wear the seat belt properly.


To determine if a lap/shoulder belt properly fits a child, have the child put on the seat belt, then ask yourself: 1. Does the child sit all the way back


against the seat?


2. Do the child's knees bend


comfortably over the edge of the seat?


Protecting Larger Children


3. Does the shoulder belt cross


between the child's neck and arm? 4. Is the lap part of the belt as low as


possible, touching the child's thighs?


5. Will the child be able to stay


seated like this for the whole trip?


If you answer yes to all these questions, the child is ready to wear the lap/shoulder belt correctly. If you answer no to any question, the child needs to ride on a booster seat.


49


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Booster seats can be high-back or low-back. Whichever style you select, make sure the booster meets federal safety standards and that you follow the booster seat maker's instructions. If a child who uses a booster seat must ride in front, move the vehicle seat as far back as possible and be sure the child is wearing the seat belt properly. A child may continue using a booster seat until the tops of their ears are even with the top of the vehicle's or booster's seat-back. A child of this height should be tall enough to use the lap/shoulder belt without a booster seat.


When Can a Larger Child Sit in Front The National Highway Traffic Safety Administration recommends that all children aged 12 and under be properly restrained in a back seat. If the passenger's front airbag inflates in a moderate to severe frontal collision, the airbag can cause serious injuries to a child who is unrestrained, improperly restrained, sitting too close to the airbag, or out of position. A side airbag also poses risks. If any part of a larger child's body is in the path of a deploying side airbag, the child could receive possibly serious injuries.


Protecting Larger Children


Using a Booster Seat


A child who has outgrown a forward- facing child seat should ride in a back seat and use a booster seat until the lap/shoulder belt fits them properly without the booster. Some states also require children to use a booster seat until they reach a given age or weight (e.g., 6 years or 60 lbs). Be sure to check current laws in the states where you intend to drive.


50


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Of course, children vary widely. And while age may be one indicator of when a child can safely ride in front, there are other important factors you should consider. Maturity To safely ride in front, a child must be able to follow the rules, including sitting properly, and wearing the seat belt properly throughout a ride. PhysicalSize Physically, a child must be large enough for the lap/shoulder belt to properly fit (see pages 14 and 49). If the seat belt does not fit properly, with or without the child sitting on a booster seat, the child should not sit in front.


If you decide that a child can safely ride up front, be sure to: ● Carefully read the owner's manual, and make sure you understand all seat belt instructions and all safety information.


● Move the vehicle seat to the rear-


most position.


● Have the child sit up straight, back


against the seat, and feet on or near the floor.


● Check that the child's seat belt is properly and securely positioned. ● Supervise the child. Even mature


children sometimes need to be reminded to fasten the seat belts or sit properly.


Protecting Larger Children


Additional Safety Precautions ● Donotletachildwearaseatbelt acrosstheneck.This could result in serious neck injuries during a crash.


● Donotletachildputtheshoulder partofaseatbeltbehindtheback orunderthearm.This could cause very serious injuries during a crash. It also increases the chance that the child will slide under the belt in a crash and be injured.


● Twochildrenshouldneverusethe


sameseatbelt.If they do, they could be very seriously injured in a crash.


● Donotputanyaccessoriesona


seatbelt.Devices intended to improve a child's comfort or reposition the shoulder part of a seat belt can make the belt less effective and increase the chance of serious injury in a crash.


51


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Carbon Monoxide Hazard


Your vehicle's exhaust contains carbon monoxide gas. Carbon monoxide should not enter the vehicle in normal driving if you maintain your vehicle properly and follow the information on this page. Have the exhaust system inspected for leaks whenever: ● The vehicle is raised for an oil


change.


● You notice a change in the sound


of the exhaust.


● The vehicle was in a collision that may have damaged the underside.


Carbon monoxide gas is toxic. Breathing it can cause unconsciousness and even kill you.


Avoid any enclosed areas or activities that expose you to carbon monoxide.


High levels of carbon monoxide can collect rapidly in enclosed areas, such as a garage. Do not run the engine with the garage door closed. Even with the door open, run the engine only long enough to move the vehicle out of the garage.


52


With the tailgate or hatch open, air flow can pull exhaust gas into your vehicle's interior and create a hazardous condition. If you must drive with the tailgate or hatch open, open all the windows and set the heating and cooling system as shown below. If you must sit in your parked vehicle with the engine running, even in an unconfined area, adjust the heating and cooling system as follows: 1. Select the fresh air mode. 2. Select the 3. Turn the fan on high speed. 4. Set the temperature control to a


mode.


comfortable setting.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


These labels are in the locations shown. They warn you of potential hazards that could cause serious injury or death. Read these labels carefully. If a label comes off or becomes hard to read (except for the dashboard label which may be removed by the owner), contact your dealer for a replacement.


DASHBOARD


SUN VISOR


Safety Labels


CONTINUED 53


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Safety Labels


RADIATOR CAP


DOORJAMBS


54


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


This section gives information about the controls and displays that contribute to the daily operation of your vehicle. All the essential controls are within easy reach.


Control Locations.......................... 56
Instrument Panel .......................... 57
Instrument Panel Indicators.......... 58
Gauges.......................................... 64
Information Display .................. 65
Odometer.................................. 65
Trip Meter ................................ 66
Fuel Gauge ............................... 66
Check Fuel Cap Message ......... 66
Temperature Gauge.................. 67
Maintenance Minder™.............. 67


Outside Temperature


Indicator ............................... 68


Controls Near the Steering


Wheel ....................................... 69


Windshield Wipers and


Washers.................................... 70
Turn Signals and Headlights......... 71
Instrument Panel Brightness ........ 72
Hazard Warning Button ................ 73
Rear Window Defogger................. 74
Steering Wheel Adjustment .......... 74
Keys and Locks............................. 75
Immobilizer System ...................... 76
Remote Transmitter ...................... 77
Ignition Switch.............................. 79
Door Locks ................................... 80
Power Door Locks .................... 80
Rear Doors................................ 81
Hatch ........................................ 81
Tailgate..................................... 82
Seats ............................................. 83
Seat Adjustments ...................... 83
Driver's Seat Height


Adjustment ........................... 84


Instruments and Controls


Front Seat Armrests.................. 85
Head Restraints......................... 85
Reclining the Front Seats .......... 87
Folding the Rear Seats .............. 88
Removing the Rear Seats .......... 90
Power Windows ............................ 92
Mirrors ......................................... 93
Adjusting the Power Mirrors..... 93
Rear Windows............................... 94
Parking Brake............................... 94
Interior Lights............................... 95
Light Control Switch ................. 95
Individual Map Lights ............... 95
Ceiling Light ............................. 96
Cargo Area Light....................... 96
Ignition Switch Light................. 96
Interior Convenience Items........... 97
Cooler Box................................ 98
Beverage Holders ..................... 99
Accessory Power Sockets ....... 100
Glove Box ............................... 100
Sun Visor ................................ 100
Vanity Mirror.......................... 101
Overhead Console .................. 101


55


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Control Locations


INSTRUMENT PANEL (P. 57) GAUGES (P. 64)


POWER DOOR LOCK SWITCH (P. 80)


MIRROR CONTROLS (P. 93)


POWER WINDOW SWITCHES (P. 92)


VEHICLE STABILITY ASSIST (VSA) OFF SWITCH (P. 173)


HOOD RELEASE HANDLE (P. 144)


Ex model is shown.


56


AUDIO SYSTEM (P. 109)


HEATING/COOLING CONTROLS (P. 104)


AUTOMATIC TRANSMISSION (P. 161)


PARKING BRAKE (P. 94)


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Instrument Panel


DAYTIME RUNNING LIGHTS INDICATOR (P. 60)


MALFUNCTION INDICATOR LAMP (P. 58, 236)


HIGH BEAM INDICATOR (P. 61)


CHARGING SYSTEM INDICATOR (P. 58, 235)


VEHICLE STABILITY ASSIST (VSA) INDICATOR (P. 62)


VSA OFF INDICATOR (P. 62)


LOW TIRE PRESSURE INDICATOR (P. 62) ANTI-LOCK BRAKE SYSTEM (ABS) INDICATOR (P. 59)


CRUISE MAIN INDICATOR (P. 60)


CRUISE CONTROL INDICATOR (P. 60)


PARKING BRAKE AND BRAKE SYSTEM INDICATOR (P. 58, 237)


LIGHTS ON INDICATOR (P. 61)


SEAT BELT REMINDER INDICATOR (P. 58)


MAINTENANCE MINDER INDICATOR (P. 59)


DRL


LOW OIL PRESSURE INDICATOR (P. 58, 235)


SIDE AIRBAG OFF INDICATOR (P. 59)


LOW FUEL INDICATOR (P. 61)


SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR (P. 59)


TPMS INDICATOR (P. 63)


DOOR AND TAILGATE OPEN INDICATOR (P. 61)


IMMOBILIZER SYSTEM INDICATOR (P. 60)


57


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Instrument Panel Indicators


The instrument panel has many indicators that give you important information about your vehicle.


Malfunction Indicator Lamp


For more information, see page 236.


Low Oil Pressure Indicator


The engine can be severely damaged if this indicator flashes or stays on when the engine is running. For more information, see page 235.


Charging System Indicator


If this indicator comes on when the engine is running, the battery is not being charged. For more information, see page 235.


58


Parking Brake and Brake System Indicator (Red)


This indicator has two functions: 1. It comes on when you turn the ignition switch to the ON (II) position. It is a reminder to check the parking brake. A beeper sounds if you drive with the parking brake not fully released. Driving with the parking brake not fully released can damage the brakes and tires.


2. If it remains on after you have fully


released the parking brake while the engine is running, or if it comes on while driving, there could be a problem with the brake system. For more information, see page 237.


Seat Belt Reminder Indicator


This indicator comes on when you turn the ignition switch to the ON (II) position. It reminds you and your passengers to fasten your seat belts. A beeper also sounds if you have not fastened your seat belt. If you turn the ignition switch to the ON (II) position before fastening your seat belt, the beeper sounds and the indicator flashes. If you do not fasten your seat belt before the beeper stops, the indicator stops flashing but remains on. If your front passenger does not fasten their seat belt, the indicator comes on about 6 seconds after the ignition switch is turned to the ON (II) position.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


If either of you do not fasten your seat belt while driving, the beeper will sound and the indicator will flash again at regular intervals. For more information, see page 18.


Supplemental Restraint System Indicator


This indicator comes on briefly when you turn the ignition switch to the ON (II) position. If it comes on at any other time, it indicates a potential problem with your front airbags. This indicator will also alert you to a potential problem with your airbag system components. For more information, see page 30.


Side Airbag Off Indicator


This indicator comes on briefly when you turn the ignition switch to the ON (II) position. If it comes on at any other time, it indicates that the passenger's side airbag has automatically shut off. For more information, see page 31.


Anti-lock Brake System (ABS) Indicator


This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. If it comes on at any other time, there is a problem with the ABS. If this happens, have your vehicle checked at a dealer. With this indicator on, your vehicle still has normal braking ability but no anti- lock function. For more information, see page 168.


Instrument Panel Indicators


Maintenance Minder Indicator


This indicator comes on for a few seconds when you turn the ignition switch to the ON (II) position. It reminds you that it is time to take your vehicle in for scheduled maintenance. The maintenance main items and sub items will be displayed in the information display. See page 185 for more information on the Maintenance Minder™. This indicator goes off when your dealer resets it after completing the required maintenance service.


CONTINUED 59


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Instrument Panel Indicators


Immobilizer System Indicator


This indicator comes on for a few seconds when you turn the ignition switch to the ON (II) position. It will then go off if you have inserted a properly coded ignition key. If it is not a properly coded key, the indicator will blink, and the engine will not start (see page 76). This indicator also blinks several times when you turn the ignition switch from the ON (II) position to the ACCESSORY (I) or LOCK (0) position.


Turn Signal and Hazard Warning Indicators


The left or right turn signal indicator blinks when you signal a lane change or turn. If the indicators do not blink or they blink rapidly, it usually means one of the turn signal bulbs is burned out (see page 204). Replace the bulb as soon as possible, since other drivers cannot see that you are signaling. When you press the hazard warning button, both turn signal indicators and all turn signals on the outside of the vehicle flash.


Daytime Running Lights Indicator


If this indicator comes on when the ignition switch is turned to the ON (II) position and the parking brake is released, it means there is a problem with a circuit. Have your vehicle checked by your dealer.


Cruise Control Indicator


This indicator comes on when you set the cruise control. See page 137
for information on operating the cruise control.


Cruise Main Indicator


This indicator comes on when you turn on the cruise control system by pressing the CRUISE button on the steering wheel (see page 137).


60


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Lights On Indicator


Low Fuel Indicator


Door and Tailgate Open Indicator


Instrument Panel Indicators


or


This indicator reminds you that the exterior lights are on. It comes on when the light switch is in either the


position. If you turn the ignition switch to the ACCESSORY (I) or LOCK (0) position without turning off the light switch, this indicator will stay on. A reminder chime will also sound when you open the driver's door.


High Beam Indicator


This indicator comes on with the high beam headlights. For more information, see page 71.


LOW FUEL INDICATOR


This indicator comes on as a reminder that you must refuel soon. When the indicator comes on, there is about 2.8 U.S. gal (10.5 L) of fuel remaining in the tank before the needle reaches E. There is a small reserve of fuel remaining in the tank when the needle does reach E.


The appropriate indicator comes on in this display if the hatch, the tailgate, or any door is not closed tightly.


CONTINUED 61


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Instrument Panel Indicators


Vehicle Stability Assist (VSA) System Indicator


This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. It flashes when VSA is active (see page 172). If it comes on and stays on at any other time, there is a problem with the VSA system. Take your vehicle to a dealer to have it checked. Without VSA, your vehicle still has normal driving ability, but will not have VSA traction and stability enhancement. See page 172 for more information on the VSA system.


62


VSA OFF Indicator


It comes on as a reminder that you have turned off the vehicle stability assist (VSA) system. This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. See page 172 for more information on the VSA system.


Low Tire Pressure Indicator


This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. If it comes on while driving, it indicates that one or more of your vehicle's tires are significantly low on pressure.


If this happens, pull to the side of the road when it is safe, check which tire has lost pressure, and determine the cause. If it is because of a flat tire, replace the flat tire with the compact spare (see page 222), and have the flat tire repaired as soon as possible. If two or more tires are underinflated, call a professional towing service (see page 244). For more information, see page 169.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Instrument Panel Indicators


Tire Pressure Monitoring System (TPMS) Indicator This indicator normally comes on for a few seconds when you turn the ignition switch to the ON (II) position. If this indicator comes on and stays on at any other time, or if it does not come on when you turn the ignition switch to the ON (II) position, there is a problem with the TPMS; the system that monitors tire pressure. With this indicator on, the low tire pressure indicator will not come on when a tire loses pressure. Take the vehicle to your dealer to have the system checked. For more information, see page 170.


63


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Gauges


SPEEDOMETER


TACHOMETER


FUEL GAUGE


DRL


INFORMATION DISPLAY


ODOMETER/TRIP METER/ CHECK FUEL CAP MESSAGE


OUTSIDE TEMPERATURE INDICATORꭧ


TEMPERATURE GAUGE


SELECT/RESET KNOB


ꭧ: If equipped.


64


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


ODOMETER


TRIP METER A


ENGINE OIL LIFE


TRIP METER B


OUTSIDE TEMPERATURE INDICATOR


Gauges


Odometer The odometer shows the total distance your vehicle has been driven. It measures miles. It is illegal under U.S. federal law to disconnect, reset, or alter the odometer with the intent to change the number of miles indicated.


Information Display The information display shows the odometer, trip meter, engine oil life, outside temperature (if equipped), and maintenance item code(s).


To switch the display, press and release the select/reset knob repeatedly. When you turn the ignition switch to the ON (II) position, your last selection is displayed.


65


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Gauges


Trip Meter This shows the number of miles driven since you last reset it. There are two trip meters: Trip A and Trip B. Switch between these displays by pressing the select/reset knob repeatedly. Each trip meter works independently, so you can keep track of two different distances. When you turn the ignition switch to the ON (II) position, the last selection is displayed. To reset a trip meter, display it, and then press and hold the select/reset knob until the number resets to ‘‘0.0’’.


66


Fuel Gauge This shows how much fuel you have. It may show slightly more or less than the actual amount. The needle returns to the bottom after you turn off the ignition.


Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.


Check Fuel Cap Message Your vehicle's onboard diagnostic system will detect a loose or missing fuel fill cap as an evaporative system leak. The first time a leak is detected a ‘‘CHECK FUEL CAP’’ message appears on the information display. Turn the engine off, and confirm the fuel fill cap is installed. If it is, loosen it, then retighten it until it clicks at least once. The message should go off after several days of normal driving once you tighten or replace the fuel fill cap. To scroll to another display, press the select/reset knob. The ‘‘CHECK FUEL CAP’’ message will appear each time you restart the engine until the system turns the message off.


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Gauges


If the system still detects a leak in your vehicle's evaporative emissions system, the malfunction indicator lamp (MIL) comes on. If the fuel fill cap was not already tightened, turn the engine off, and check or retighten the fuel fill cap until it clicks at least once. The MIL should go off after several days of normal driving once the cap is tightened or replaced. If the MIL does not go off, have your vehicle inspected by a dealer. For more information, see page 236.


Temperature Gauge This shows the temperature of the engine's coolant. During normal operation, the pointer should rise to about the middle of the gauge. In severe driving conditions, the pointer may rise to the upper zone. If it reaches the red (hot) mark, pull safely to the side of the road. Turn to page 233 for instructions and precautions on checking the engine's cooling system.


Maintenance Minder™ The information display in the instrument panel shows you the engine oil life and maintenance service items when the ignition switch is in the ON (II) position. This information helps to keep you aware of the periodic maintenance your vehicle needs for continued trouble- free driving. Refer to page 185 for more information.


67


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


In certain weather conditions, temperature readings near freezing (32°F, 0°C) could mean that ice is forming on the road surface. If the outside temperature is incorrectly displayed, you can adjust it up to ꭗ5°F warmer or cooler. NOTE: The temperature must be stabilized before doing this procedure.


To adjust the outside temperature indicator, make sure the odometer is shown in the display, then press and hold the select/reset knob for 10
seconds. The following sequence will appear for 1 second each: 0, 1, 2, 3, 4, 5, -5, -4, -3, -2, -1, 0. When the temperature reaches the desired value, release the select/ reset knob. You should see the new outside temperature displayed.


Gauges


Outside Temperature Indicator OnEXmodel This indicator displays the outside temperature in Fahrenheit. The temperature sensor is in the front bumper. The temperature reading can be affected by heat reflection from the road surface, engine heat, and the exhaust from surrounding traffic. This can cause an incorrect temperature reading when your vehicle speed is under 19
mph (30 km/h). When you start your trip, the sensor is not fully acclimatized, therefore it may take several minutes until the proper temperature is displayed.


68


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Controls Near the Steering Wheel


HEADLIGHTS/TURN SIGNALS (P. 71)


WINDSHIELD WIPERS/WASHERS (P. 70)


REMOTE AUDIO CONTROLSꭧ2
(P. 135)


VSA OFF SWITCH (P. 173)


HORNꭧ1


AUTOMATIC TRANSMISSION (P. 161)


ACCESSORY POWER SOCKET (P. 100)


REAR WINDOW DEFOGGER BUTTON (P. 74)


STEERING WHEEL ADJUSTMENT (P. 74)


Ex model is shown.


CRUISE CONTROL BUTTONS (P. 137)


HAZARD WARNING BUTTON (P. 73)


ꭧ1: To use the horn, press the center pad of the steering wheel. ꭧ2: If equipped


69


10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu


Windshield Wipers and Washers


Windshield Wiper


(cid:19)


(cid:20) (cid:21)


(cid:22)


(cid:23)


(cid:24)


ADJUSTMENT RING


1. MIST 2. OFF 3. INT - Intermittent 3. LO - Low speed 5. HI - High speed 6. Windshield washers


70


Push the right lever up or down to select a position. MIST - The wipers run at high speed until you release the lever. OFF - The wipers are not activated. INT - The length of the wipe interval is varied automatically according to vehicle's speed. Vary the delay by turning the adjustment ring. If you turn it to the shortest delay ( wipers change to low speed operation when the vehicle speed exceeds 12 mph (20 km/h). LO - The wipers run at low speed. HI - The wipers run at high speed. Windshield Washer - Pull the wiper control lever toward you, and hold it. The washers spray until you release the lever. The wipers run at low speed, then complete one more sweep after you release the lever.


position), the


Rear Window Wiper and Washer


(cid:20)


(cid:19)


(cid:21)


(cid:22)


Loading...
x
