1995 Cadillac Deville Owners Manual

second or two, or even several seconds, for your eves to readjust to the dark. When YOU are faced with severe glare (as frim a driver who doesn’t lower the high beams, or a vehicle with misaimed headlamps), slow down a little. Avoid staring directly into the approaching lights. Keep your windshield and all the glass on your vehicle clean -- inside and out. Glare at night is made much worse by dirt on the glass. Even the inside of the glass can build up a film caused by dust. Dirty glass makes lights dazzle and flash more than clean glass would, making the pupils of your eyes contract repeatedly. Remember that your headlamps light up far less of a roadway when you are in a turn or curve. Keep your eyes moving; that way, it’s easier to pick out dimly lighted objects. Just as your headlamps should be checked regularly for proper aim, so should your eyes be examined regularly. Some drivers suffer from night blindness -- the inability to see in dim light -- and aren’t even aware of it.

4- 3.7

D M N G IN THE RAIN

b 4

Rain and wet roads can mean driving trouble. On a wet road you can't stop, accelerate or turn as well because your tire-to-road traction isn't as good as on dry roads. And, if your tires don't have much tread left, you'll get even less traction. It's d w a ~ s wise to go slower and be cautious if rain starts to fall while you are driving. The surface may get wet suddenly when your reflexes ;u'e tuned for driving on dry pavcment. The heavier the rain, the harder it is to see. Even if your windshield wiper blades are in good shape, a heavy rain can make it harder to see road signs and traffic signals, pavement markings, the edge of the road. and cven peoplc walking. It's wise to keep vour wiping quiptnent i n good shape and keep your windshield wash& tank filled. Replace your windshield wiper inserts when they show signs strips of rubber start to separatc from the inserts.

c. of streaking or missing areas on the windshield, or when

3- 18

4- 19

Hydrupluning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you’re going fast enough. When your vehicle is hydroplaning, it has little or no contact with the road. Hydroplaning doesn’t happen often. But it can if your tires haven‘t much tread or if the pressure in one or more is low. It can happen if a lot of water is standing on the road. If you can see reflections from trees, telephone poles, or other vehicles, and raindrops ‘‘dimple’‘ the water‘s surface, there could be hydroplaning. Hydroplaning usually happens at higher speeds. There just isn‘t a hard and fast rule about hydroplaning. The best advice is to slow down when it is raining. Some Other Rainy Weather Tips 0 Turn on your low beam headlamps -- not just your parking lamps -- to

help make you more visible to others. Besides slowing down, allow some extra following distance. And be especially careful when you pass another vehicle. Allow yourself more clear room ahead, and be prepared to have your view restricted by road spray. Have good tires with proper tread depth. (See “Tires” in the Index.)

4-20

CITYDRIVING

r I

One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving:

Know the best way to get to where you are going. Gct a city map and pian your trip into an unknown part of the city just as you would for a cross-country trip. Try to use the freeways that rim and crisscross most large cities. You’ll save time and energy. (See the next part, “Freeway Driving.”) Treat a green light as a warning signal. A traffic light is there because the corner is busy enough to need it. When a light turns green, and just before you start to move, check both ways for vehicles that have not cleared the intersection or may be running the red light.

4-21

FREEWAYDRM-NG

Mile for mile, freeways (also called thruways, parkways, expressways, turnpikes, or superhighways) are the safest of all roads. But they have their own special rules. The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving. Too-fast or too-slow driving breaks a smooth traffic flow. Treat the left lane on a freeway as a passing lane. At the entrance there is usually a ramp that leads to the freeway. If you have a clear view of the freeway as you drive along the entrance ramp, you should begin to check traffic. Try to determine where you expect to blend with the flow. Try to merge into the gap at close to the prevailing speed. Switch on your turn signal, check your mirrors and glance over your shoulder as often as necessary. Try to blend smoothly with the traffic flow. Once you are on the freeway, adjust your speed to the posted limit or to the prevailing rate if it’s slower. Stay in the right lane unless you want to pass. Before changing lanes, check your mirrors. Then use your turn signal. Just before you leave the lane, glance quickly over your shoulder to make sure there isn’t another vehicle in your “blind” spot.

4-22

Once you are moving on the freeway, make certain you allow a reasonable following distance. Expect to move slightly slower at night. When you want t o leave the freeway, move t o the proper lane well in advance. If vou miss your exit do not, under any circumstances, stop and back up. Dr& o n tolthe ncst exit. The exit ramp can be cuwed, sometimes quite sharply. The exit speed is usually posted.

BEFORE LEAUNG ON A LONG TRIP Make sure vou're ready. Try to be well rested. If vou must start when you're not iresh -- such as aftcr a day's work -- d6n.t plan to make too many miles that first part of the journey. Wear comfortable clothing and shoes you can easily driw in. Is vour vehicle ready for a long trip'! If you keep it stlnliced and miintained, it's ready t o go. I f it needs service, have it done before starting out. Of course, you'll find experienced and able service experts in Cadillac dealerships all across North America. They'll be ready and willing to help if you need it. Here are some things you can check before a trip:

Wirdd1ield Woslter Fluid: Is the reservoir full'? Are all windows clean inside and outside?

Tires: They are vitally important to a safe, trouble-free trip, Is the tread good enough for long-distancc driving? Are thc tires all inflated to the recornnxnded pressure'? Weather Fomusts: What's the weather outlook along your route? Should you delay your trip a short time to avoid a major storm system'? Mcq~s: Do you have up-to-date maps?

4-23

HIGmAY HYPNOSIS Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel‘? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy. Don’t let it happen to you! If it does, your vehicle can leave the road in less t l m n secmd, and you could crash and be injured. What can you do about highway hypnosis‘? First, be aware that it can happen. Then here are some tips: 0 Make sure your vehicle is well ventilated, with a comfortably cool

interior.

0 Keep your eyes moving. Scan the road ahead and to the sides. Check

your rearview mirrors and your instruments frequently. If you get sleepy, pull off the road into a rest, service, or parking area and take a nap, get some exercise, or both. For safety, treat drowsiness on the highway as an emergency.

4-24

-

HILL AND MOUNTMN ROADS

I.

Driving on steep hills or mountains is different from driving in flat or rolling terrain. If you drive regularly in steep country, or if you’re planning to visit there? here are some tips that can make your trips safer and more enjoyable. 0 Keep your vchicle in good shape. Check all fluid levels and also the

brake;. tires. cooling system and transaxle. These parts can work hard on mountain roads. Know how to go down hills. The most important thing to know is this: let your engine do some of the slowing down. Shift to a lower gear when you go down a steep or long hill.

4-25

c

. . . . . . . . . . . .

Know how to go uphill. You n w want to shift down to a lower gear. The lower gears help cool your cnginc and transaxle, and you can climb the hill better. Stay in your own lane when driving on two-lane roads i n hills or mountains. Don't swing wide or cut across the ccnter of thc road. Drive at speeds that let you stay in your own lanc. As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident. You may see highway signs on mountains that warn of special problems. Examples are long grades, passing or no-passing zoncs, a failing rocks area, or winding roads. Be alcrt to these and take appropriate action.

4-26

WINTER D W N G Here are some tips for winter driving:

r-

a Have vour

Cadiliac in good shape for winter. Be sure your engine coolant mix is correct.

You may want to put winter emergency supplies in your trunk.

f-

Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth, and a couple of reflective warning triangles. And, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet or a couple of burlap bags to help provide traction. Be sure you properly secure these items in your vehicle.

4-27

Driving on Snow or Ice Most of the time, those places where your tires meet the road probably have good traction. However, if there is snow or ice between your tires and the road, you can have a very slippery situation. Youll have a lot less traction or “giip” and will need to be very careful.

What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get “wet ice” when it’s about freezing (32” F; 0” C) and freezing rain begins to fall. Try to avoid driving- on wet ice until salt and sand crews can get there. Whatever the condition -- smooth ice, packed, blowing or loose snow -- drive with caution.

4-28

e

4-29

If You’re Caught in a Blizzard

If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow. Here are some things to do to summon help and keep yourself and your passengers safe: Turn on your hazard flashers. Tie a red cloth to your vehicle to alert police that you’ve been stopped by the snow. Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats -- anything you can wrap around yourself or tuck under your clothing to keep warm. You can run the engine to keep warm, but be careful.

- -

.-

. . . . . , . .

...

:. . .

Run your engine only as long as you must. This saves fuel. When vou run the engine, make it go a little faster than just idle. That is, push the accelerator slightlv. This uses less fuel for the heat that you get and it keeps the battew charged. You will need a well-charged battery to restart the vehicle, and possibly for signaling later on with your headlamps. Let the heater run for awhile.

4-3 1

Then, shut the engine off' and close the window almost all the way t o preserve the heat. Start the engine again and repeat this only when you feel reallv u~~comfortable Presewe'the fuel as long as you can. 'To help keep warm, vou can get out of the vehicle and do some fairly vigorous exercises eve1i half hour or so until hclp comes. LOADING YOUR VEHICLE

from the cold. But do it as little as possible.

TIRE-LOADING INFORMATION

OCCUPANTS

FRT. CTR. RR. TOTAL

VEHICLE CAP. WT. LBS. KG

MAX. LOADING & GVWR SAME AS VEHICLE COLD TIRE XXX CAPACITY WEIGHT SPEED PRESSURE RTG PSVKPa

TIRE SIZE

FRT. RR. SPA. IF TIRES ARE HOT. ADD 4PSV28KPa SEE OWNER'S MANUAL FOR ADDITIONAL INFORMATION

TLVO labels on your vehicle show how nwch wcight it may properly carry. The Tire-Loading Information label found on the driver's door tells you the proper size? speed rating and recommended inflation pressures for the tires on your vehicle. It also gives you important information about the number of people that can be in your vehicle and the total weight that you can carry. This weight is called the Vehicle Capacity Weight and includes the weight of all occupants, cargo and all non-factory installed options.

4-32

MFD BY GENERAL MOTORS CORP DATE GVWR GAWR FRT GAWR RR

THIS VEHICLE CONFORMS TO ALL APPLI- CABLE U.S. FEDERAL MOTOR VEHICLE SAFETY, BUMPER, AND THEFT PREVEN- TION STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.

GEN GME ,

The other label is the Certification label. found on the rear edge of the driver's door. It tells you the gross weight capacilv of vour vehicle, called the GVWK (Gross Vel~icle Weight Rating). The GVWR includes the weight of the vehicle, all occupants, fuel and cargo. Never exceed the GVWR for your vehicle or the Gross Axle Weight either the front or rear axie.

Rating (GAWR) €or

L,

If you put things inside your vehicle -- like suitcases, tools, packages or anything else -- they will go as fast as the vehiclc goes. If you have to stop or turn quickly, or if there is a crash, they'll keep going.

4-33

TOWING A T M L E R

3-34

NOTICE: Pulling a trailer improperly can damage your vehicle and result in costly repairs not covered by your warranty. To pull a trailer correctly, follow the advice in this part, and see your Cadillac dealer for important information about towing a trailer with your vehicle.

Load-pulling conlponents such as the engine, transaxle, wheel assemblies, and tires are forced to work harder against the drag of the added weight. Thc engine is required to opcrate at relatively higher speeds and under greater loads, generating extra heat. What's morc, the trailer adds considerably to wind resistance, increasing thc pulling requirements. If You Do Decide To Pull A Trailer If you do, here are surne important points.

There are ~nar~y different laws, including speed limit restrictions, having to do with trailering. Makc sure your rig will be legal. not only where \;ou live hut also where you'll be driving. A good source for this infurmition can IX state or provincial police.

4-35

c

You can ask a hitch dealer about sway controls.

Don’t tow a trailer at all during the first 1,000 miles ( 1 600 krn) your new vehicle is driven. Your engine, axle or other parts could be damaged.

0 Then, during the first 500 miles (800 km) that you tow a trailcr, don’t

drive over 50 mph (80 km/h) and don’t make starts at full throttle. This helps your engine and other parts of your vehicle wear in at the heavier loads. Obey speed limit restrictions when towing a trailer. Don’t drive faster than the maximum posted speed for trailers (or no more than 55 mph (90 kndh)) to save wear on your vehicle’s parts.

Three important considerations have to do with weight: Weight of the Trailer How heavy can a trailer safely bc? It should never weigh more than 1.000 pounds (450 kg) total, including the load. But even that can be too hcavy. It depends 011 how you plan to use your rig. For example, speed, altitude, road grades, outsidc tcmperature and how mrrch your vehicle is used to pull a trailer are all important. And, it can also depend on any spccial equipment that you have on your vehicle.

In Canada, write to General Motors of Canada Limited, Cilstomer Assistance Center, 1908 Colonel Sam Drive. Ochawa, Ontario LlH SP7. Weight of the frailer Tongue The tongue load (A) o f any trailer is a n important weight to measure because it affects the total capacity weight of your vehiclc. The capacity weight includes the curb weight of the vehicle, any cargo you may carry in it, and the people who w i l l be riding it1 the vehicle. And if you will tow a trailer: you must subtract the tongue load from your vehicle‘s capacity weight because your vehicle will be carrying that weight, too. See “Loading Your Vehicle” in the Index for more information about your vehicle’s maximum load capacity.

4-36

A

L,

simply by moving sonx items around i n the trailer.

If you’re using a “dead-weight” hitch, the trailcr tongue (A) should weigh 1 0 % of thc total loaded trailer weight (B). If you have a “weight-dist~-ibut.ing’? hitch, the trailer tongue (A) should weigh 12$+ of the total loaded trailer weight (B). After Vou‘ve loaded your trailer. weigh the trailer and then the tongue, separately, t o see if the weights arc proper. If they aren’t, you may be able t o get them right Total Weight on Your Vehicle’s Tires Be sure vow vehicle’s tires are infiatcd to the 1-ccomrnendec1 pressure for cold tir& Yt~~’l1 find these numbers on the Certification label at the rear edge of the driver’s door or sce “Loading Your Vehicle” i n the Index. Then be sure you don‘t go over the GVW limit for your vehicle, including the weight of the trailer tonguc. The gross combined vehicle weight (GCVW)=curb weight + passcnger’s weight + cargo + trailer weight, should never weigh more than 6,300 pounds (2 772 kg) total loaded vehicle and trailer.

4-37

It's important to have the correct hitch equipment. Crosswinds, large trucks going by, and rough roads are a few reasons why you'll need the right hitch. Here are some rules to follow:

Will you have to make any holes in the body of your vehicle when you install a trailer hitch? If you do, then be sure t o k a l the holes later when you remove the hitch. If you don't seal them? deadly carbon monoxide (CO) from your exhaust can get into your vehicle (see "Carbon Monoxide'? i n the Index). Dirt a l ~ d water can, too. The bumpers on your vehicle are not intended for hitches. Do not attach rental hitches or other bumper-type hitches t o them. Use only a frame-nwuntcd hitch that does not attach to the bumper.

Safety Chains You should always attach chains between your vehicle and your trailer. Cross the safety chains under the tongue of the trailer so that the tongue will not drop to the road if it becomes separated from the hitch. Instructions about safety chains may be provided by thc hitch manufacturer or by the trai1c1- manufacturer. Follow the manufacturer's recommendation for attaching safety chains and do not attach them t o the bumper. Always 1e;we just enough slack so VOLI can turn with your rig. And, never allow safety chains to drag OII the ground. Trailer Brakes

4-38

Driving with a Trailer Towing a trailer requires a certain amount of experience. Before setting out for the open road, you’ll want to get to know your rig. Acquaint yourself with the feel of Ilandling and braking with the added weight of the trailer. And always keep i n mind that thc vehicle you are driving is now a good deal longer and not nearly as responsivs as your vehicle is by itself. Before you start, check thc trailer hitch and platform (and attachments), safety chains, electrical connector, lamps, tires and mirror adjustment. If the trailer has electric brakes, start your vehicle and trailer moving and then apply the trailer brake controlier by hand to be sure the brakes are working. This lets you check your electrical connection at the same time. During \Tour trip, check occasionally to be sure that the load is secure, and that the’lights and any trailer brakes are still working. Following Distance Stay at least twice as far behind the vehicle ahead as you would when driving your vehicle without a trailer. This can help you avoid situations that require heavy braking and sudden turns. Passing You’ll need more passing distance up ahead when you’re towing a trailer. And, because you‘re a good deal longer, you’ll need to go much farther beyond the passed vehicle before you can return to your lane. Bucking Up Hold the bottom of the steering wheel with one hand. Then, to move the trailer to the left, just move that hand to the left. To move the trailer to the right, move your hand to the right. Always back up slowly and, if possible, havc someone guide you.

4-39

NOTICE: Making very sharp turns while trailering coulcl cause the trailer to come in contact with the vehicle. Your whicle could be damagecl. Avoid making very sharp turns while trailering.

When towing a trailer? the green arrows on your instrument panel will flash for turns even if the bulbs on the trailcr are burned out. T h , you may think drivers behind you are seeing your signal when they are not. It's important to check occasionally to be sure the trailer bulbs are still working. Driving On Grades Reduce speed and shift to a lowcr gear bcfow VOLI start clown a long or steep downgrade. If you don't shift down. youkight have to use your brakes so much that they would get hot and no longer work well. On a long uphill grade. shift down ; 1 n d reduce your speed to u-ound 45 mph (70 km/h) or less to reduce the possibility of engine and transaxle overheating.

c-

. c

4-4:)

Parking on Hills You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, y&r riq could start t o move. People can be injured, and both your vel;icle and the trailer can be darnagecl. But if you ever have to park your rig on a hill, here‘s how to do it: 1. Apply your regular brakes, but do not shift into PARK (P). 2. ILiave sonleone place chocks under the trailer whecls.

L.

Wzen You Are Ready to Leave A@r Parking on n Hill

2. Let up on the brake pedal. 3. Drivc slowly until the trailer is clear of the chocks. 4. Stop and have someone pick up and store the chocks. Maintenance when Trailer Towing Your vehicle will need service more often when you’re pulling a trailer. See the Maintenance Schedule for more on this. Things that are especially important in trailer operation are automatic transaxle fluid (don’t overfill), engine oil, belt, cooling system, and brake adjustment. Each of these is covered in this manual, and the Index will help you find them quickly. If you’re trailering, it’s a good idea to review these sections before you start your trip. Check periodically to see that all hitch nuts and bolts are tight.

4-4 1

Engine Cooling When Trailering Your cooling system may temporarily overheat during severe operating conditions such as: e Climbing grades steeper than 4% at ambient temperatures above

90' F (32" C) with a loaded vehicle and trailer. Stopping after high-speed driving.

e Idling for long periods in stop and go traffic. If the ENGINE HOT-A/C COMPRESSOR OFF message appears on the Driver Information Center, do no be alarmed. This is a normal function designed to reduce the load on the engine and cooling system. You can continue to drive your vehicle. if the ENGINE COOLANT HOT-IDLE ENGINE message appears on the Driver Information Center, pull off to the side of the road as soon as it is safe to do so. When the vehicle is at a complete stop, shift the transaxle selector to PARK (P) and allow the engine to idle. Do not turn off the engine or increase engine speed above a normal idle. After several minutes resume driving at a reduced speed. Return to normal driving after 10 minutes if the ENGINE COOLANT HOT-IDLE ENGINE message is not displayed.

4-42

PROBLEMS ON THE ROAD

HAZARD WARNING FLASHERS

Your hazard warning flashers let you warn others. They also let police know WLI have a problem. Your front and rcar turn signal lamps will flash on a n i off.

s- 1

Press the button in to make your front and rear turn signal lamps flash on and off.

c’ .?:

. . .. .: ... .:

The light on your instrument panel will flash indicating that the hazard warning flashers are on.

Your hazard warning flashers will work once the button is pressed in regardless of the key position.

5-2

0THE.R WARNING DEVICES

JUMP STARTING

5-3

I NOTICE:

Ignoring these steps could result in costly damage to your vehicle that wouldn’t be covered by your warranty. Trying to start your Cadillac by pushing or pulling it won’t work and it could damage your vehicle.

TO JUMP START YOUR CADILLAC: 1. Check the other vehicle. It must have a 12-volt battery with a negative

ground system.

I NOTICE:

If the other system isn’t a 12-volt system with a negative ground, both vehicles can be damaged.

2.

3.

4.

Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other. If they are, it could cause a ground connection you don’t want. You wouldn’t be able to start your Cadillac and the bad grounding could damage the electrical systems. Turn off the ignition on both vehicles. Turn off all lamps, radio or any accessorie.s that are in use on both vehicles. This will avoid sparks arld help save both batteries as well as avoid damage to any of the accessories. Open the hoods and locate the batteries.

5 -4

Find the positive (+) and negative (-) terminals on cach battery.

5. Start by removing the red positive (+) terminal cover.

I i

5-5

6. Check that the jumper cables don't have loose or missing insulation. If

they do, you could get a shock. The vehicles could be damaged too. Before you connect the cables, here are some things you should know. Positive (+) will go to positive (t) and negative (-) will go to negative (-) or a metal engine part. Don't connect positive (+) to negative (-) or you'll get a short that could damage the battery and maybe other parts too.

7. Connect the red positive (+) cable to the positive (+) terminal o f the

vehicle with the dead battery.

8. Don't let the other end of the positive cable touch metal. Connect it to

the positive (+) terminal of the good battay.

9. Now connect the black negative (-) cable t o the good battery's

negative (-) terminal.

10. Don't let the other end of the negative cable touch anything until the next step. The other end of the negative cable cloesn 't go to the dead battery. It goes to a heavy unpainted metal part on the engine of the vehicle with the dead battely. Attach the cable at least 18 inches (45 cm) away from the dead batterv, but not near engine parts that move. The electrical connection is just as good there. but the chance o f sparks getting back to the battery icrnuch less.

1 1. Now start the vehicle with the good battery and run the enqine for

awhile.

12. Try t o start the vehicle with the dead battery.

If it won't start after a few tries, it probably needs service.

5-7

13. Remove the cables in reverse order to prevent electrical shorting.

Xke care that they don't touch each other or any other metal.

A-

5-8

TOWING YOUR VEHICLE Ti-y to have a GM dealer or a professional towmg service tow your Cadillac. The usual towing equipment is :

Sling Type

0 Wheel Lift

8 Car Carrier

If your vehicle has been changed or modified since it was factory-new by adding aftermarket items like fog lamps, aero skirting or speciai tires and wheels, these instructions and illustrations may not be correct. Before you do anything, turn on the hazard warning flashers. When you call, tell the towing service:

That your vehicle cannot be towed from the front or rear with sling-type equipment. That your vehicle has front-wheel drive.

8 The makc, model and year of your whicie. Whether you can still move the shift lever.

0 If thcre was an accident., wha1 was damaged.

When the towing service arrives, let the tow operator know that this manual contains detailed towing instructions and illustrations. The operator may want to see them.

. .

. , . . . . . . . . . . . . . . . . . . . . .

........ . .

. .

5- 10

When your vehicle is being towed, have the ignition key off. The steering wheel should be clamped in a straight-ahead position with a clamping device designed for towing selvicc. Do not use the whicle's steering colunln lock for this. The trallsaxlc should he i n NEUTRAL (N) and the parking hrake relc;lsd.

ENGINE OVERHEATING TIIC Driver Information Center will displav either ENGINE COOL.ANT HOT-IDLE ENGINE 01 STOP ENGINEdENGINE OVERHEATING. In addition you will find the warning light about a hot engine on your instrument panel on Canadian vehiclcs.

If Steam Is Coming From Your Engine

NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty.

5- 12

IfNo Steam Is Coming From Your Engine If you get the overheat warning but see or hear no steam, the problem may not be t o o serious. Sonletimes the engine can get a little too hot when you:

Climb a long hill on a hot day. Stop after high speed driving. Idle for long periods in traffic.

0 Tow a trailer. If you get the overheat warning with no sign of steam, or so: 1. Turn off your air conditioner. 2. Dial temperature control to the highest heat setting and open the

try this for a minute

3. If you’re in a traffic jam, shift to NEUTRAL (N); otherwise, shift to

window, as necessary. t h i highest gear while driving -- AUTOMATIC OVERDRIVE (0) or THIRD (3).

If you no longer have the overheat warning, you can drive. Just to be safe, drive slower for about 10 minutes. If the warning doesn’t come back on, you can drive normally. If the warning continues, pull over, stop, and park your vehicle right away. If there’s still no sign of steam, you can idle the engine for two or three minutes while you‘re parked, to see if the warning stops. But then, if you still have the warning, turx off the cwgillc alzdgct c‘wyouc out of [he vehicle until it cools down. You may decide not to lift the hood but t o get service help right away.

5-1 3

COOLING SYSTEM

L- *

When you decide it's safe t o lift the hood. Ilere's w h a t you will see.

Coolant recovery tank. Radiator pressure cap. Electric engine fans.

If the coolant inside the coolant recovery tank is boiling, don't do anything else until it cools down.

NOTICE: Engine damage from running your engine without coolant isn't covered by your warranty.

If there seems to be no leak, with the engine on check to see if the electric engine fans are running. If the engine is overheating, both fans should be running. If they aren't. your vehicle needs service.

5-15

How to Add Coolant to the Coolant Recovery Tank If you haven’t found a problem yet, but the coolant level isn’t at or near recovery tank, add a 50/50 mixture the FULL COLD mark on the &ant of clenu water (preferably distilled) and a proper antifreeze at the coolant recovery tank. (See “Engine Coolant” in the Index for more information about the proper coolant mix.)

NOTICE: In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use the recommended coolant.

5-16

If the overheat warning continues, there’s one more You can add the proper coolant mix directly to the coolant recovery tank, but be sure the cooling system is cool before you do it.

thing you can try.

5-18

How to Add Coolant to the Rodiator

1.

c r

r-

2. Fill the radiator with the proper mix, up to the base of the filler neck.

. . . .

. . . . .

5, Put the cap back

on the coolant recovery tank, but leave the radiator pressurc cap off.

, ,&

.i.

.:A

7. By this time the coolant level inside the radiator filler neck may be 16wer. If the level is lower, add more of the proper mix through the filler neck until the level reaches the base of the filler neck.

5-2 1

8.

5-22

IF A TIRE GOES FLAT

5 -23

C M G I N G A FLAT TIRE

'ly to 1

...

. .

. . . . . .

. . . . . . . . . . . . . . . .

The following steps will tell you how to use the jack and change a tire.

5-34

r 1 . r

, ,

l e The equipment

you'll nesd is in the trunk under the spare tire cover.

..d ,

5-25

,.. .

5-26

V0TIC.E:

3 ,

6.

5-27

I

. . .

::

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . .

. . . . ':

7. Position the jack under the vehicle. Your vehicle has a notch 011 the

frame near each of the wheels. Fit the lift head into the notch nearest the wheel with the flat tire.

. . . . . . . . . .

I,

. . . . .

Rear

5-18

P

pl

r-

I.

9. Remove all of the wheel nuts and take off the flat tire.

10. Remove any rust or dirt from the wheel bolts, mounting surfaces and spare wheel. Place the spare on the wheel mounting surface.

5-29

-.

12. Lower the vehicle

by rotating the wheel wrench counterclockwise. Lower the jack completely.

. . .. .

5-3 I

.

. . . . .. , .

. . . . . . . ,

. . ,

. . .

. .

Don't try to put a wheel cover on your compact spare tire. It won't fit. Store the wheel cover in the trunk until you have the flat tire repaired or replaced.

I NOTICE:

Wheel covers won't fit on your compact spare. If you try to put a wheel cover on your compact spare, you could damage the cover or the spare.

COMPACT SPARE TIRE

I NOTICE:

Don't take your compact spare through an automatic car wash with guide rails. The compact spare can get caught on the rails. That can damage the tire and wheel. and maybe other parts of your vehicle.

--

Don't use your compact spare on some other vehicle. And don't mix your compact spare or wheel with other wheels or tires. They won't fit. Keep your spare and its wheel together.

NOTICE: Tire chains won't fit your compact spare. Using them will damage your vehicle and destroy the chains too. Don't use tire chains on pour compact spare.

IF Y0UX.E STUCK: IN SAND, MUD, ICE OR SNOW What you don't want to do when your vehicle is stuck is to spin your wheels too fast. The method known as .*rocking" can help you get out when you're stuck, but you must use caution.

NOTICE: Spinning your wheels can destroy parts of your vehicle as well as the tires. If you spin the wheels too Fast while shifting your transaxle back and forth, you can destroy your transaxle.

For information about using tire chains on your vehicle, see "Tire Chains" in the Index. Rocking your vehicle to get it out: First, turn your steering wheel left and right. That will clear the area around your front wheels. You should turn your traction control system off. (See "Traction Control System" in the Index.) Then shift back and forth between REVERSE (R) and a forward gear, spinning the wheels as little as possible. Release the accelerator pedal while you shift, and press lightly on the accelerator pedal when the transaxle is in gear. if that doesn't get you out after a few tries, you may need to be towed out. If you do need to be towed aut, see '*Towing Your Vehicle" in the Index.

- .

5-34

3

If you try to do your own service work without knowing enough about it, your vehicle could be damaged.

FUEL

What about gasoline with blending materials that contain oxygen (oxygenates). such a s MTBE or alcohol? ., MTBE is ”nlethyl tcl-tiary-butyl ether. Fuel that is 11o more ttlan 15% MTRE is fine for your vehicle. Etimol is ethyl or grain alcohol. Propcriy-blended fuel that is no more than 10% ctizwtol is fine for your velliclc. “ c l u r m d is methyl or wood alcohol.

Fuel that is more than 5% methanol is bad for your vehicle. Don’t use it. It can corrode metal parts in your fuel system and also damage plastic and rubber parts. That damage wouldn’t be covered under your warranty And even at 5% or less, there must be “cosolvents” and corrosion preventers in this fuel to help avoid these problems.

L.

L r

L-

G~lsoiines for Cleaner Air Your use of gasoline with deposit control additives will help prevent deposits from forming ill vour engine and fuel s\jstern. That helps keep your engine i n tune a11d your emission control $stem working properly. It‘s good for your vehicle. and you‘ll bc doing vour part for cleaner air. Many gasolines are now blended with oxygenates. General Motors recommends that YOU us2 gasolines with these blending materials. such as MTBE and ethanol. By doing so. you can help clean the air, especially in those parts of the county that have high carbon monoxide levels. In addition. some gasoline suppliers are m v producing reformulated gasolines. These gasoiirm are speciallv designed to reduce vehicle emissions. General Motors recornrnshs that you use reformulated gasoline. By doing so, you can help clean the air, especially in those parts of the country that have high ozone levels. You should ask your service station operators if their gasolines contain deposit control additives and oxygenates, and if they have been reformulated to reduce vehicle emissions.

6-3

FUELS ..IN FOREIGN GOUNTHES

L.

. . ....

F

6-5

NOTICE: If you need a new cap, be sure to get the right type. b u r dealer can get one for you. If you get the wrong type, it may not fit or have proper venting, and your fuel tank and emissions system might be damaged.

0 4 :

6-7

Hood Release

ENGINE OIL If the CHECK OIL light on the instrument panel comes on, it means you need to check your engine oil level right away. For more information, see “Check Oil Light” in the Index. You should check your engine oil level regularly; this is an added reminder. It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground.

Turn off the engine and give the oil a few minutes to drain back into the oil pan. If you don‘t, the oil dipstick might not show the actual level.

. .

. . ... . X . .

Tu Check Engine Oil Puli out the dipstick and clean it with a paper towel or cloth, then push it back in all the way. Remove it again, keeping the tip down, and check thc level.

6- 10

c

..

, .

. . I

. . .

NOTICE: Don’t add too much oil. If your engine uas so much oil that the oil level gets above the cross-hatched area that slmw the proper operating range, your engine could be damaged.

6-1 1

L A A A

If you change your own oil, be sure you use oil that has the "Starburst" symbol on the front of the oil container. If you have your oil changed for you, be sure the oil put into your engine is American Petroleum Institute certified for gasoline engines.

RECOMMEWDED !9€ YISCOSITV GRADE ENGINE OILS

FOR %Sf FUEL ECONOMV AND COLD STARTING, SELECT THE LOWEST SAL YlSCOSlN GRADE OIL fOR THE fXPECT€D TEMPERATURE R A W .

HOT

WEATHER

-. COLD WEATHER

DO MOT USE SA€ 2OW-50 OR ANY OTHER GRADE OIL NOT RECOMMENDED

As shown in the chart, SAE ]OW-30 is best for your vehicle. However, you can use SAE 5W-30 if it's going to be colder than 60' F (16' C) before your next oil change. When it's very cold, you should use SAE 5W-30. These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils, such as SAE 2OW-SO.

6- 13

I

NOTICE: Use only engine oil with the American Petroleum Institute Certified For Gasoline Engines “Starburst” symbol. Failure to use the proper oil can result in engine damage not covered by your warranty.

Oil) meets all the

GM Goodwrench‘:” oil (in Canada, GM Enginc requirements for your vehicle. Engine Oil Additives Don‘t add anything to vour oil. Your Cadillac dealer is ready to advise if you think something should be added. When to Charzge Engine Oil Your Cadillac has an *‘Oil Life Indicator.” This feature will k t you know when to change your oil and filter -- usually between 3,000 miles (5 000 km) and 7.500 miles (12 SOU km) since your last oil change. Under severe conditions, the indicator may come o n before 3:OOO miles (5 000 km). Never drive your vehicle more than 7:500 miles (12 500 km) or 12 months without an oil change. The system won‘t detect dust in the oil. So. if you drive in a dusty area? be sure to change your oil everv 3,000 miles (5 000 krn) or sooner if the CHANGE OIL SOON lighi comes on. Remember to reset the Oil Life Indicator when thc oil has been changed. For more information. see “Oil Life Indicator” in the Index.

How to Reset the Oil Lye Indicator After the o i l has been changed, display the 01L LIFE LEFT message by pressing the INFORMATION button. Then press and hold the RESET button until the display shows "100." This resets the oil life index. The message will remain off until the next oil change is needed. The percentage of oil life remaining may be checked at any time bv pressing the INFORMATION button several times until the OIL LIFk LEFT message appears. For more information on the Oil Life Index feature. see *'Oil Life Index'' in the Index. Engine Coolant Heater An engine coolant heater can be a big help if vou have to park outside in very cold weather. 0' F (- 18' C) or colder. Ifyour vehicle has this option, see-*.Engine Coolant Heater" in the Index. What to Do with, Used Oil Did vou know that used engine oil contains certain elements that may be unhealthy for vour skin and could even cause cancer'! Don't let used oil stav on your skin for. very long. Clean your skin and nails with soap and waier, or a good hand cleaner. Wash or properly throw away clothing or rags containing used engine oil. (See the manufacturer's warnings about the use and disposal of oil products.) Used oil can be a real threat to the environment. If vou change your own oil. be sure to drain all free-flowing oil from the filtdr before disposal. Don't ever dispose of oil by putting it in the trash. pouring it on the 2 Oround, into sewers. or into streams or bodies o f water. Instead, recycle it hy taking it to a place that collects used oil. If you have a problcm propcrly disposing o f your used oil, ask your dealer. a scrvicc station or a local recycling center ior hclp.

AIR CLEANER

I.

NOTICE: If the air cleaner is off, a backfire can cause a damaging engine fire, And, dirt can easily get into your engine, which will damage it. Always have the air cleaner in place when you're driving.

6-16

AUTOMATIC TRRNSRXLE FLUID Wzen to Check and Change

How to Check

'Too much or too little fluid can damage yow transaxle. 'Too much can mean that some of the fluid couid come out and fall on hot engine parts or exhaust system parts, starting a fire. Be sure to get an accurate reading if you check your transaxle fluid.

6-17

3. Check both sides

of the dipstick, and read the lower level. The fluid level must be in the cross-hatched i! rc2 *

4.

r i

I i

i Ir

How to Add Fluid

i . 2.

Pull out the dipstick. Using a long-neck funne'l. add enough fluid at the dipstick hole, tc briniit to tie proper level. It doesn't take much fluid, generally less than a pint (0.X). Do11 'r 01~~1fill. We recommend you ise only fluid labeled DEXRON."-III. because fluid with that label is ma& especially for your automatic transaxle. Damage caused bv fluid other than D E ~ R O N ' ~ - I I I

is not covered by your nLw v e ~ e wdarrantp.

0 After adding fluid, recheck the fluid level as described under "How to

Check." When the correct fluid level is obtained, push the dipstick back in all the way.

6-19

How to Reset Transaxle Fluid Change Indicator

.

. .

RADIATOR .PRESSURE CAP

NOTICE: Your radiator pressure cap is a 15 psi (105 kpa) pressure-type cap and must be tightly installed to prevent coolant loss and possible engine damage from overheating. Be sure the arrows on the cap line up with the overflow tube on the radiator filler neck.

L.

coolant temperature is controlled by a thermostat in the engine

THERMOSTAT Engine coolant system. The thermostat stops the flow of coolant through the radiator until the coolant reaches a preset temperature. I f vour thermostat needs to be replaced an AC'"' thermostat is re&m-nended. POWER STEERING FLUID

P I! c

6-23

What to Add

NOTICE: When adding power steering fluid or making a complete fluid change, always use the proper fluid. Failure to use the propor fluid can cause leaks and damage hoses and seals.

I I

WINDSHIELD WASHER FLUID

TQ Add

When using concentrated washer fluid, follow the manufacturer’s instructions for adding water.

e Don’t mix water with ready-to-use washer fluid. Water can

cause the solution to freeze and damage your washer fluid tank and other parts of the washer system. Also, water doesn’t clean as well as washer fluid. Fill your washer fluid tank only 314 full when it’s very cold. This allows for expansion, which could damage the tank if it is completely full. Don’t use radiator antifreeze in your windshield washer. It can damage your washer system and paint.

6-25

BRAKES

r

r-

I .

To Check Brake Fjzlid

The fluid level must be to the maximum fill line at the base of the neck as i;hown. When your brake fluid fdls to a low level, your brake warning light will come on. See “Brake System Warning Light” in the Index.

Wzat to Add When you do need brake fluid, use only DOT-3 brake fluid -- such as Delco Supreme 1 l @ (GM Part No. 1052535). LJse new brake fluid from a sealed container only, and always clean the hake fluid resetvoir cap before removing it.

6-27

NOTICE:

Don't let someone put in the wrong kind of fluid. For example? just a few drops of mineral-based oil, such as engine oil, in your brake system can damage brake system parts so badIy that they'll have to be replaced. Brake fluid can damage paint, so be careful not to spill brake fluid on your vehicle. If you do, wash it off immediately. See "Appearance Care" in the Index.

Brake Wear Your Cadillac has four-tvhecl disc brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed. The sound may come and go or be heard all the time your vehicle is moving (except when you are pushing on the brake pedal firmly).

NOTICE: Continuing to drive with worn-out brake pads could result in costly brake repair.

6-28

Brake .Pedal Travel

6rake Adjrrstment

BATTERY Every new Cadillac has a DcIco Freedom'' battery. You never have to add water to one of these. When it's time for a new battery, we recommend a Delco Freedom". batterv. Get one that has the replacement number shown on the original bkery's label. Vehicle Storage If you're not going to drive your vehicle for 25 davs or more, take off the black: negative (-) cable from the battery. This wiil help keep your battery from running down.

..

L .1

Contact your dealer to learn how to prepare your vehicle for longer storage periods. Battery Power Loss If you lose battery power or the battery is disconnected, vour car's computer must be programmed. It takes just over 20 miiutes to do it. If you want to do it yourself? here's how: 1. Apply the parking brake. 2. Make sure the front wheels are straight. 3. Turn off the Electronic Climate Control.

4. 3. c

6.

7 . Now your computer is programmed. H A O G E N BULBS

EXTERIOR LAMP HOUSINGS

6-3 1

H E A D M P BULB RElMOVAL Here is how to change the halogen the access cover.

L.

headlamp bulb. Begin by lifting up on

. . .. . .. . . . .

. . . . , .. . . . . . . .., . .. .... . . , ...,.. .. . .. ... .. - ..

. .

.. ...

2. Disconnect thc socket from the harness by separating the 1ocking

clip.

NOTICE: Do not touch the glass portion of the new haiogen bulb! The oil from your fingers will shorten the life of your new halogen bulb.

. -

-- -

6-33

CORlVEMNG L M P .BULB REPLACEMENT

6-33

3. Gently pull out cornering lamp assembly.

the

6-34

TMLLAMP BULB REPLACEMENT

4. Replace the bulb by

pressing at~d twisting it counterclockwise.

i...:..

:.

- ...........

Center .High Mounted Stop Lump Bulb Replacement

C

.....

-'

1 I

WIPER BLADE REPLACEMENT

If you only want to rcplacc the wiper insert. follow these steps: 1.

3.

3.

1.

5. 6.

7.

TIRES We don't make tires. Your Cadillac comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your Cadillac Warranty booklet for details.

L,

P

Inflution - Tire Pressure The Tire-Loading Information label which is located on the driver's door shows the correct inflation prcssutes for your tires, when they're cold. "Cold" means your vehicle has been sitting for at least three hours or driven no more than a mile.

.

, ..

. .... . .. .

. .

L1

6-43

The following information relates t o the system developed by the United Traffic Safety Administration which grades tires States National Highway by treadwear, traction and temperature performance. (This applies only t o vehiclcs sold i n the United States.)

Treudwenr

Wheel Replacement

If you need to replace any of your wheels, wheel bolts. or wheel nuts. replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, and wheel nuts for your Cadillac model.

...

. ,

NOTICE: The wrong wheel can also cause problems with bearing life, brake cooling, speedometer/odometer calibration, headlamp aim, bumper height, vehicle ground clearance. and tire or tire chain clearance to the body and chassis.

6-46

Used Replacement Wzeels

Tire Chains

NOTICE: Use tire chains only where legal and only when you must. Use only SAE Class ‘(S” type chains that are the proper size for your tires. Install them on the front tires and tighten them as tightly as possible with the ends securely fastened. Drive slowly and follow the chain manufacturer’s instructions. If you can hear the chains contacting your vehicle, stop and retighten them. If the contact continues, slow down until it stops. Driving too fast or spinning the wheels with chains on will damage your vehicle.

6-47

A P P E M C E CARE Remember, cleaning products can be hazardous. Some are toxic. Others can burst into flame if you strike a match or get them on a hot part of the vehicle. Some are dangerous if you breathe their fumes in a closed space. When you use anything from a container to clean your Cadillac, be sure to follow the manufacturer’s warnings and instructions. And always opcn your doors or windows when you’re cleaning the inside. Never. use these to clean your vehicle:

Gasoline Benzene 0 Naphtha 0 Carbon Tetrachloride 0 Acetone 0 Paint Thinner 0 Turpentine

Lacquer Thinner

0 Nail Polish Remover They can all be hazardous -- some more than others -- and they can all damage your vehicle, too. Don’t use any of these unless this manual says you can. In many uses. these will darnagc your vehicle: 0 Alcohol

LaundIy Soap Bleach

0 Reducing Agents

- -

CLEANING THE INSIDE OF YOUR CADILLAC

Here are some cleaning tips:

Always read thc instructions on thc cleaner label. Clean up stains a s soon as you can -- before they set. Usc a clean cloth or sponge, and change to a clean area often. A soft brush may be used if stains are stubborn. Use solvent-type cleaners i n a well-ventilated area only. If you use them, don't saturate the stained area. If a rinq L forms after spot cleaning, clean the ontire area immediately or it will set.

Using Foam-Type Cleaner on Fabric 0 Vmum and brush the area to retmvc any loose dirt.

Always clean a whole trim panel or section. Mask surrounding trim along stitch or welt lines. Mix Multi-Purpose Po\.trdered Cleaner following the directions on the container label.

Rinse the section with a clean, wet sponge.

6-49

0 Wipe offwhat's left with a slightly damp paper towel or cloth.

Then dry it immediately with a blow dryer or a heat lamp.

NOTICE: Be carefill. A blow dryer may scorch the fabric.

Wipe with clean cloth.

Using Solve~~t-Type Cleaner on Fabric

Special Cleaning Prublems

R'on-Greasy Stains

Cleaning Vinyl

Cleaning Leather

~

Cleaning the Top of the Instrument Punel Use only mild soap and water to clean the top surfaces of the instrument panel. Sprays containing silicones or waxes may cause annoying refections in the windshield and eve11 make it difficult t o sce through the windshield under certain conditions. Cleuning Speaker Covers Vacuum around a speaker cover gently, so that the speaksr won't be damaged. If something gets 011 one of them, follow the steps earlier under "Using Solvent-Tppc Cleaner on Fabric." Use as little solvent as you can. Care of Wood Panels Use a clean cloth moistened in warm soapv water (use mild dish washing soap). Dry the \vood immediately with a cfean cloth. CARE OF SAFETYBELTS Keep belts clean and dry. I -

. . .

. .

. .

. .

. .

6-52

GLASS Glass should be clcaned often. GM Glass Clcaner (GM Part No. 1050427) or a liquid household glass cleaner will remove normal tobacco smoke and dust films. Don't use abrasive cleaners on glass, because they may cause scratches. Avoid placing decals on the inside rear window, since they may have to be scraped off later. If abrasive cleaners are used on the inside of the rear window, an electric defogger element may be damaged. Any temporary license should not be attached across the defogger grid. CLEANING THE OUTSIDE OF THE WINDSHIELD AND WIPER BLADES If the windshield is not clear after using thc windshield washer? or if the wiper blade chatters when running, wax or other material may be on the blade or windshield. Clean the outside of the windshield with GM Windshield Cleaner, Bon-Ami Powder'" (GM Part No. 105001 I). The windshield is clean if beads do not form whcn you rinse it with water. Clean the blade by wiping vigorously with a cloth soaked in full strength windshield washer solvent. Then rinse the bladc with water. Wiper blades sl~outd be checked 011 a regular basis and replaced when worn. WEATHERSTRIPS Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth at least evczy six months. During very cold, damp weather more frequent application may be required.

ti-53

U

CLEANING THE OUTSIDE OF YOUR CADILLLAC The paint finish on your vehicle provides beauty, depth of color, gloss retention and durability. Washing Your Vehicle The best way to preserve your vehicle’s finish is to keep it clean by washing it often with lukewarm or cold water. Don’t wash your vehicle in the direct ram of the sun. Dodt use strong soaps or chemical detergents. Use liquid hand, dish or car washing (mild detergent) soaps. Don‘t use cleaning agents that are petroleum based, or that contain acid or abrasives. All cleaning agents should be flushed promptly and not allowed to dry on the surface, or they could stain. Dry the finish with a soft, clean chamois or a 100% cotton towel to avoid surface scratches and watcr spotting. High pressurc car washes may cause water t o entcr your vehicle. Finish Care Occasional waxing or mild polishing of your Cadillac by hand may be llezessary t o remove residue from the paint finish. You can get GM approved cleaning products from your dcaler. (See “Appearance Care and Materials” in the Index.) Your Cadillac has a “baseCo;tt/cl~~lrco~t” more depth and gloss to the colored basecoat. Always use waxes and polishes that are non-abrasive and made for a basecoatlclearcoat paint finish.

paint finish. The clearcoat gives

NOTICE: Machine compounding or aggressive polishing on a basecoat/clearcoat paint finish may dull the finish or leave swirl marks.

6-54

Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from industrial chimneys, etc. can damage vow vehicle's finish if they remain on painted surfaces. Wash the vehicleas soon as possible. If necessary, use non-abrasive cleaners that arc marked safe for painted surfaces to remove foreign matter. Exterior painted surfaces are subject to aging, wcather and chemical fallout that can take their toll over a period of years. You can help to keep the paint finish looking ncw by kceping your Cadillac garaged or covered wlxmcver possible. ALUMINUM WHEELS

NOTICE: Don't use an automatic car wash that has hard silicon carbide cleaning brushes. These brushes can take the protective coating off your aluminum wheels.

TIRES To clean your tires, use a stiff brush with a tire cleancr. When applying a tire dressing always take carc to wipe off any overspray or splash from painted surfaces. Petrolcum-based products 1;ay damage the paint finish.

6-55

SHEETMETAL DAIMAGE If your vehicle is damaged and requires sheet mctal repair or replacement, make sure the body repair shop applies anti-corrosion material to the parts repaired or replaced to restore corrosion protection. FINISH D M G E Any stone chips, fractures or deep scratches in the finish should be repaired right away. Bare mctal will corrode quickly and may develop intc - a major repair expense. Minor chips and scratches can be repaired with touch-up materials available from your dealcr or other service outlets. Larger areas of finish damage can be corrected in your dealer's body and paint shop.

Chemicals used for ice and snow removal and dust control can collect on the underbody. If these are not removed, accelerated corrosion (rust) can occur on the underbody parts such as fuel lines, frame, floor pan, and exhaust system even though they have corrosion protection. At least every spring, flush these materials from the underbody with plain water. Clean anv areas wherc mud and other debris can collect. Dirt packed in closed areas of the frame should be loosened before being flushed. Your dealer or an underbody car washing system can do this for you.

CHEMICAL PAINT SPOTTING

6-57

APPEARANCE CARE IMATERI;4LS CHART

GM PART

NUMBER

SIZE

DESCKIPTION

USAGE

KEHICLE IDENTIFICATION NUMBER

1 G 6 M y 5 2 9 X S U 8 0 0 0 0 1

-r r -l--

- --.-r---

I I

i I.

I '.- PRODUCTION

SEQUENCE NUMBER

.. ASSEMBLY PUUT

HAMTRAMCK. MICH,

NATION OF 1 '

ORIGIN 1 = USA

MANUFACTURER G = GENERAL MOTORS

MAKE 6 = CADlLLAC

l- I !

I I

V1N BODY CODE = BODY TYPE 5 = 69 SEDAN 4 DOOR

-. - CHECK DIGIT

. RESTRAINT SYSTEM:

.?

ACTiVE (MANUAL! BELTS WITH DRIVER A m PASSENGERS INFLATABLE RESTRAINT SVSTEM

Engine Identification The eighth character in your VIN is the engine code. This code will help you identi@ your enginc, specifications, and replacement parts. SERVCE PARTS IDENTIFICATION LABEL You'll find this label on the spare tire cover. It's very helpful if you ever need to order parts. On this label is: 0 your VIN,

the model designation. paint information, and

0 a list of all production options and spccial cquipmcnt. Be sure that this label is not rcmowd from the vehicle.

c

4DD-ON ELECTMCX, EQUIPMENT

NOTICE: Don’t add anything electrical to your Cadillac unless you check with your dealer first. Some electrical equipment can damage your vehicle and the damage wouldn’t be covered by your warranty. Some add-on electrical equipment can keep other components from working as they should,

Your vehicle has an air bag svsttlnl. Bcforc attempting to add anything electrical to vour Cadiliac, sic b‘Sewicing Your Air Bag-Equipped Cadillac” in ihe Index. Retained Accessory Power When you stop vour Cadillac and turn thc kcy to OFF? you c a l ~ use these accessories for io more minutes:

Radio Power Windows Astroroof Windshield Wipers Fuel Door Release Trunk Release

Everything will go off after 1 0 minutes or if you open a door. If you want power for another 10 minutes, just turn the key to RUN and then back to OFF.

FUSES AND CIRCUIT BREAKERS The wiring circuits in your vehicle are protected from short circuits by a combination of Mini Fuses, Circuit Breakers and MAXI"' fuses. This greatly reduces the chance of fircs caused by electrical problems.

Engine Compartment Fuse Block

To gain access? lift the coves.

6-02

n M M

ii. FuseslRelay Center

nnn~r==3un

HTD Wls

LHDLPLO

R HDLPLO

LHDLPHI

RHOLPHI

E CENTER IDENTIFICATION

Engine Compartment Fuse Block

~~

~~~~

FUSE

DlSTR
