voice commands*
General information You can enter a desired destination via the voice activation system. When entering the destination, it is possible to change between voice command and iDrive at any time. Reacti- vate the voice command function for this pur- pose if necessary.
You can have the possible commands read aloud via {Voice commands}.<
Saying the entries > Countries, towns and cities, streets and
intersections can be said as whole words or spelled in the system language, refer to page 82.
Entering a town/city The town/city can be spelled or entered as a complete word*.
The methods of entry depend on the nav- igation data in use and the country and
language settings.<
1.
{City} or {Spell city}.
2. Wait for the system to prompt you for the
town/city.
3. Say the name of the town/city, or name at
least the first three letters. Depending on the entry, up to 20 towns/cit- ies may be suggested. 4. Select town/city:
> Select a recommended town/city:
{Yes}
> Select other town/city: {New entry} > Select an entry, e.g., {Entry 2} > Spell an entry: {Spell city}
139
Identical-sounding towns/cities that can- not be distinguished by the system are
compiled in a separate list and shown as a town/ city followed by three dots. If necessary, select this entry with {Yes}. Then select the desired town/city from this list.< The town/city can also be selected from the list via iDrive: Turn the controller until the town/city is selected and press the controller.
Entering a street or intersection The street or intersection is entered in the same manner as the town/city.
Entering house number You can enter house numbers up to 999:
{House number}
1. 2. Say the house number. 3. 4.
{Yes} to confirm the house number. {Accept destination}
Starting destination guidance
{Start guidance}
Destination guidance starts immediately.
Adding further intermediate destinations
{Add as another destination}
Further intermediate destinations can be added.
Saving destination The destination is automatically added to the list of last destinations.
Planning a trip
New trip Various intermediate destinations can be entered for a trip. 1. "Navigation" 2. "Map" 3. Move the controller to the left, if necessary.
140
symbol.
4. Select the 5. "Enter new destination" 6. Select the type of destination entry and
enter the intermediate destination.
Entering further intermediate destinations A maximum of 30 intermediate destinations can be entered for one trip. 1. "Enter new destination" 2. Select the type of destination entry and
enter the intermediate destination.
3. Select "Add as another dest.". 4. Select the location where the intermediate
destination is to be inserted.
Starting the trip After all intermediate destinations have been entered: "Start guidance"
Storing a trip Up to 30 created trips can be stored in the trip list. 1. Open "Options". 2. "Store trip"
3. Enter the letters. 4. "OK" The trip is stored in the trip list under the entered name.
Starting a stored trip 1. "Navigation" 2. "Stored trips" 3. Select the desired trip. 4. "Start guidance"
Changing trips
Changing the trip direction Intermediate destinations can be displayed in reverse order after destination guidance is started. 1. "Map" 2. "Guidance" 3. Open "Options". 4. "Reverse order of trip dest."
Rearranging the intermediate destinations 1. "Map" 2. "Guidance" 3. "Display all trip dest." 4. Select an intermediate destination. 5. "Reposition dest. in the trip"
Deleting an intermediate destination 1. "Map" 2. "Guidance" 3. "Display all trip dest." 4. Select an intermediate destination. 5. "Delete dest. in the trip"
Deleting a trip 1. "Navigation" 2. "Stored trips" 3. Select the desired trip. 4. Open "Options".
5. "Delete all trips" or "Delete trip".
Word-matching principle The system supports the word matching princi- ple to make it easier for you to enter the names of streets or towns. The system runs ongoing checks, comparing your destination entries with the data stored in the vehicle as the basis for instant response. The user benefits include: > Names of specific locations can also vary from the official versions if you are using a spelling that is customary in another coun- try. Example: Instead of the German spelling "München" you can also enter the English spelling "Munich" or the Italian spelling "Monaco". > When you are entering the names of towns and streets the system will complete them automatically as soon as enough letters are available to ensure unambiguous identifica- tion.
> The system offers only those letters for
selection of name entries that are stored in the vehicle. The system will not accept non existent names and addresses.
141
Destination guidance
Starting destination guidance 1. "Navigation" 2. "Enter address" 3. Select the destination. 4. "Accept destination" 5. "Start guidance" The route is displayed on the Control Display after it is calculated.
Terminating destination guidance 1. "Navigation" 2. "Map" 3. Select the 4. "Stop guidance"
symbol.
Continuing destination guidance If the destination was not reached during the last trip, destination guidance can be resumed. "Resume guidance"
Route criteria
General information You can influence the calculated route by choosing certain route criteria. You can change the route criteria as often as you like while entering the destination and whenever the des- tination guidance is active. The route is planned according to fixed rules. The type of road is taken into account, e.g., whether it is a highway or a winding road. As a result, the routes recommended by the naviga- tion system may not always be the same ones
142
that you would choose based on personal expe- rience. The settings are stored for the remote control currently in use.
Changing route criteria 1. "Navigation" 2. "Map" 3. "Route preference" 4. Selecting a criterion:
> "Fast route": time-optimized route,
which is a combination of the shortest possible route and the fastest roads
> "Efficient route": optimized combination
of the fastest and shortest roads
> "Short route": short distance, irrespec- tive of how fast or slow progress will be > "Alternative routes": other suggested
alternative routes while destination guidance is active
5. Select additional route criteria, if desired.
Where possible, the selected criteria will be avoided on the route. > Avoid highways where possible:
"Avoid highways"
> Avoid toll roads where possible:
"Avoid toll roads"
> Avoid ferries where possible:
"Avoid ferries"
The setting applies to the current route and to the planning of future routes.
Dynamic destination guidance "Dynamic guidance" is switched on: The route is automatically changed in the event of traffic obstructions. The system does not point out traffic obstructions along the original route. Depending on the type of road and the nature and length of the traffic obstruction, the route can also be calculated so that you travel through the traffic obstruction. 1. "Navigation" 2. Open "Options". 3. "Dynamic guidance"
If the "Avoid highways", "Avoid toll roads" or "Avoid ferries" route criteria are
selected, route calculation may take consider- ably longer.<
Route
General information Depending on the equipment in your vehicle, different views of the route are available during destination guidance: > List of streets and towns/cities > Map view, refer to page 144
> Arrow view in the Head-up Display*Displaying a list of the streets or towns/ cities on the route When destination guidance is started, a list of the streets and towns/cities on the route is dis- played. The driving distances and traffic bulle- tins are displayed for each route section. 1. "Navigation" 2. "Route information" 3. Highlight a section. The section is displayed in the preview map.
Bypassing a section of the route During destination guidance, you can revise the navigation system's route recommendations to avoid particular stretches of road. Enter the
number of miles/kilometers that you want to travel before returning to the original route. 1. "Navigation" 2. "Route information" 3. "New route for:"
4. Turn the controller: enter the desired num-
ber of miles.
5. Press the controller.
Resuming the original route If the route section should no longer be bypassed: 1. "Navigation" 2. "Route information" 3. "Remove blocking"
Gas station recommendations The remaining range is calculated and gas sta- tions along the route are recommended. 1. "Navigation" 2. "Route information" 3. "Recommended refuel"
A list of gas stations is displayed.
4. Select a gas station. 5. Select the symbol. 6. "Start guidance" or "Add as another dest.".
Destination guidance via voice instructions
Switching voice instructions on/off Voice instructions can be switched on or off during destination guidance.
143
1. "Navigation" 2. "Map" 3.
Select the
symbol.
Symbol
Meaning Voice instructions are switched on Voice instructions are switched off
For rapid access, the feature can be stored on a programmable memory key, refer to page 20.
Repeating a voice instruction 1. "Navigation" 2. "Map" 3. symbol. 4. Press the controller twice.
Highlight the
Adjusting the volume of voice instructions* The volume can be adjusted only while a voice instruction is being issued. 1. Repeat the last voice instruction, if neces-
sary.
2. Turn the knob during the voice instruction
to select the desired volume.
The setting is stored for the remote control cur- rently in use.
144
Map display
Displaying map view You can have your current position displayed on a map. After starting the destination guidance, the planned route is shown on the map. 1. "Navigation" 2. "Map" The following functions are directly available in the map view:
Symbol
Function Starting/stopping destina- tion guidance Switching voice instructions on/off Changing route criteria or selecting route alternatives
Special destinations
Displaying traffic bulletins
Interactive map
Map view settings
Changing scale
Information in the map view: > Time, entertainment source, sound output,
map orientation
> Distance from destination, estimated time of arrival, if destination guidance is active. > Any traffic obstructions are highlighted in
color.
To show/hide information on the map: Press the controller.
Viewing the map 1. Select the
2. Select a setting:
symbol.
> "View facing north" > "View in dir. of travel" > "Perspective view" > "Arrow display"
3. Press the controller.
Changing the map section
Select the interactive map.
> To shift the map: move the controller in the
required direction.
> To shift the map diagonally: move the con- troller in the required direction and turn it.
Changing scale 1. Select the 2. Turn the controller to adjust the scale.
symbol.
Automatic scaling of the map In the map view facing north, turn the controller in any direction until AUTO is displayed as the map scale. The map shows the entire range from your loca- tion to the destination.
Settings for the map view The map is shown on the Control Display. 1. Open "Options". 2. "Settings" 3. Set the optimized map view.
> "Day/night mode"
Select and create the necessary settings depending on the light conditions. When the traffic bulletin map is activated, this setting is disregarded.
> "Satellite images"
Satellite images* are displayed depend- ing on availability and resolution.
> "Perspective view in 3D"
Displays a spatial view. Prominent areas that are contained in the navigation data are displayed on the map in 3D.
> "Traffic Info map"
The map is optimized for displaying traf- fic bulletins. Symbols for the special destinations are no longer displayed.
Map view for the split screen display The map view for the split screen can be selected separately from the main screen.
1. Open "Options". 2. "Split screen"
The split screen is switched on.
3. Move the controller to the right repeatedly
until the split screen content is selected.
4. Select the map view:
> "Arrow display" > "Map facing north" > "Map direction of travel" > "Map view with perspective" > "Exit ramp view"
Changing scale 1. Move the controller to the right until the
split screen is selected. turn the controller.
2.
Traffic information* You can display the traffic bulletins from radio stations that broadcast the TMC (Traffic Mes- sage Channel) of a traffic information service. This information from the traffic information service is continuously updated on the basis of measurement data from traffic control centers and information on traffic congestion. During destination guidance, traffic bulletins that are relevant to areas along the route are automatically displayed and taken into account in the route planning. You can open all traffic bulletins manually via iDrive. The traffic bulletins are shown in the map view.
Real Time Traffic Information End-User Provisions Certain BMW models equipped with navigation have the capability to display real-time traffic information. If your system has this capability the following additional terms and conditions apply: An End-User shall no longer have the right to use the Traffic Data in the event that the End- User is in material breach of the terms and con- ditions contained herein.
145
A. Total Traffic Network, a division of Clear Channel Broadcasting, Inc. ("Total Traffic Net- work") holds the rights to the traffic incident data and RDS-TMC network through which it is delivered. You may not modify, copy, scan or use any other method to reproduce, duplicate, republish, transmit or distribute in any way any portion of traffic incident data. You agree to indemnify, defend and hold harmless BMW of North America, LLC. ("BMW NA") and Total Traffic Network, Inrix, Inc (and their affiliates) against any and all claims, damages, costs or other expenses that arise directly or indirectly out of (a) your unauthorized use of the traffic incident data or the RDS-TMC network, (b) your violation of this directive and/or (c) any unautho- rized or unlawful activities by you in connection herewith. B. Total Traffic Network traffic data is informa- tional only. User assumes all risk of use. Total Traffic Network, BMW NA, and their suppliers make no representations about content, traffic and road conditions, route usability, or speed. C. The licensed material is provided to license "as is," and "where is". Total Traffic Network, including, but not limited to, any and all third party providers of any of the licensed material, expressly disclaims, to the fullest extent permit- ted by law, all warranties or representations with respect to the licensed material (including, without limitation, that the licensed material will be error-free, will operate without interruption or that the traffic data will be accurate), express, implied or statutory, including, without limita- tion, the implied warranties of merchantability, non-infringement fitness for a particular pur- pose, or those arising from a course of dealing or usage of trade. D. Neither Total Traffic Network, Inrix, Inc. nor BMW NA will be liable to you for any indirect, special, consequential, exemplary, or incidental damages (including, without limitation, lost rev- enues, anticipated revenues, or profits relating to the same) arising from any claim relating directly or indirectly to use of the traffic data, and even if Total Traffic Network, Inrix, Inc., or BMW NA are aware of the possibility of such damages. These limitations apply to all claims,
146
including, without limitation, claims in contract and tort (such as negligence, product liability and strict liability). Some states do not allow the exclusion or limitation of incidental or conse- quential damages, so those particular limita- tions may not apply to you.
Activating/deactivating reception 1. "Navigation" 2. Open "Options". 3. Activate/deactivate "Receive Traffic Info". In many metropolitan areas you can receive traffic information broadcast by radio stations. The traffic conditions are monitored by traffic management centers and the traffic information is periodically updated. During destination guidance, the traffic infor- mation relevant to your planned route is auto- matically displayed. Whether destination guid- ance is active or not, you can have the traffic bulletins displayed in the map view or in the traf- fic info list.
Traffic bulletins in a list A list of the traffic bulletins can be opened via the menu or map view.
Opening the traffic bulletins 1. "Navigation" 2. "Map" 3. Move the controller to the left, if necessary. 4. Select the
symbol: "Traffic Info"
First, the traffic bulletins on the planned route are displayed. The traffic bulletins are sorted in the order of their distance from the current vehicle position. 5. Select a traffic bulletin. Additional information can be displayed for some traffic bulletins: 1. Select the 2. Additional information is displayed. 3. Exit from the menu:
symbol.
Move the controller to the left.
Traffic bulletins on the map When the traffic bulletin map is activated, the Control Display changes to a black and white display. This enables a better view of the traffic bulletins. The day/night mode is disregarded in this setting. The symbols for the special desti- nations are no longer displayed. 1. "Navigation" 2. "Map" 3. Open "Options". 4. "Settings" 5. "Traffic Info map"
Symbols in the map view Depending on the scale of the map and the location of the traffic obstruction along the route, the symbols for the traffic obstructions are displayed.
Additional information in the map view Depending on the map scale, a traffic obstruc- tion's length, direction and impact are displayed on the map using triangles or gray bars along the calculated route.
Filtering of traffic bulletins You can filter which traffic bulletins are to be displayed by the system: 1. "Navigation" 2. "Map" 3. Open "Options". 4. "Traffic Info categories" 5. Select the desired categories.
Traffic bulletins of the selected categories are displayed.
> Traffic bulletins on incidents along the route
are always displayed.
> For your own safety, traffic bulletins that notify you of potentially dangerous situa- tions, such as wrong-way drivers, cannot be hidden.
Traffic bulletins during destination guidance System response will vary depending on whether or not "Dynamic guidance" is selected, refer to page 143. During destination guidance, traffic obstruc- tions on the route are taken into consideration. Information on sources of great danger, such as wrong-way drivers, is displayed regardless of the setting.
Displaying traffic obstructions When the navigation system receives a traffic obstruction message and "Dynamic guidance" is not selected, you will be shown certain infor- mation, such as the length of the traffic conges- tion, when you are approx. 30 miles/50 km away from the traffic obstruction. The last possible detour exit is indicated just before you reach it. This information is displayed even if you have called up another application on the Control Display.
Selecting a detour Select the "Dynamic guidance" is activated for the current destination guidance.
symbol: "Detour".
Dynamic route planning When "Dynamic guidance" is selected, the route will be changed automatically in the event of a traffic obstruction. The system will not point out traffic obstructions on the original route. Depending on the road type and the kind and extent of the traffic obstruction, the newly cal- culated route may lead through the traffic obstruction.
147
.
What to do if...
What to do if… > The current position cannot be displayed? The position is in an unrecognized region, in a poor reception area, or the system is in the process of determining the position. Reception is best when you have an unob- structed view to the sky.
> The destination guidance does not accept
an address without the street name? A downtown area cannot be determined for the town or city that has been entered. Input any street in the selected town/city and start destination guidance.
> the destination guidance does not accept a
destination? The destination data is not contained in the navigation data. Select a destination that is as close as possible to the original.
> The letters for a destination cannot be
selected during destination entry? The stored data do not contain the data of the destination. Select a destination that is as close as possible to the original.
> The map view is displayed in black and
white? When the traffic bulletin map is activated, the Control Display changes to a black and white display. This enables a better view of the traffic bulletins.
> Voice instructions are no longer issued before intersections during destination guidance? The area has not yet been fully recorded, or you have left the recommended route and the system requires a few seconds to calcu- late a new route suggestion.
148
e
149
Entertainment Entertainment
Operation of the radio, CD equipment and external audio devices as well as their tone settings are described in this chapter.
e
On/off and tone
The following audio and video sources share the same control elements and adjustments: > Radio > CD/DVD player > CD changer* > Video* > External devices, e.g., MP3 player
Controls The audio and video sources can be controlled using the: > Buttons in the area of the CD/DVD player > iDrive > Buttons on the steering wheel; refer to
page 11
> Programmable memory buttons, refer to
page 20
> Voice activation system
Buttons in the area of the CD/DVD player
1 Sound output for entertainment on/off, vol-
ume > Press: switch on/off
When the system is switched on, the most recently selected radio station or track is played.
> Turn: adjusting volume
152
Station scan/track search
> Change the radio station > Select the track for the CD/DVD player,
CD changer and certain multimedia devices Eject the CD/DVD
4 CD/DVD drive* 5 MODE: change the audio and video
sources
6 FM/AM: change the radio station wave-
band
Switching on/off To switch the entertainment sound output on and off: Press knob 1 next to the CD/DVD player.
This symbol on the Control Display indicates
that sound output is switched off. Sound output is available for approx. 20 minutes after the ignition is switched off. Switch on the sound output again for this pur- pose.
Adjusting volume Turn knob 1 next to the CD/DVD player until the desired volume is set. You can also adjust the volume with the buttons on the steering wheel, refer to page 11.
Tone control You can alter various tone settings, e.g., treble and bass or the speed-dependent volume increase. The tone settings are set for all audio sources at once. The settings are stored for the remote key cur- rently in use.
4. Select the desired setting.
Treble, bass, balance, fader > "Balance": left/right volume distribution > "Fader": front/rear volume distribution
Adjustments 1. "CD/Multimedia", "Radio" or "Settings". 2. "Tone"
3. Select the desired tone setting.
4. To adjust: turn the controller. 5. To store: press the controller.
Equalizer* You can set individual sound frequency ranges. 1. "CD/Multimedia", "Radio" or "Settings". 2. "Tone" 3. "Equalizer"
5. To adjust: turn the controller. 6. To store: press the controller.
Multi-channel playback, Surround* You can select between stereo and multi-chan- nel playback, Surround. 1. "CD/Multimedia", "Radio" or "Settings". 2. "Tone" 3. "L7 Surround"
Multi-channel playback, Surround, is simulated when playing back an audio track in stereo. Surround is automatically activated or deacti- vated, depending on the audio track selected. LOGIC7 and the LOGIC7 logo are registered trade marks of Lexicon, Inc., a company of the Harman International Group.
Volume > "Speed volume": speed-dependent volume
control
> "PDC"*: volume of the PDC signal tone rel-
ative to the entertainment sound output
> "Gong": volume of the signal tone, e.g., for the "Fasten safety belt" reminder, relative to the entertainment sound output
153
Adjustments 1. "CD/Multimedia", "Radio" or "Settings". 2. "Tone" 3. "Volume settings" 4. Select the desired volume setting.
5. To adjust: turn the controller. 6. To store: press the controller.
Resetting tone settings You can reset all tone settings to the default settings. 1. "CD/Multimedia", "Radio" or "Settings". 2. "Tone" 3. "Reset"
154
Radio
Your radio is designed for reception of the fol- lowing stations: > FM and AM > HD Radio* > Weather Band* > Satellite radio*
Selecting a station
3. Select the desired station.
Press the knob if the sound output is switched off. 1. "Radio"
2. "FM" or "AM"
The selected station is stored for the remote control currently in use.
Changing stations Turn and press the controller or Press the direction or Press the buttons on the steering wheel, refer to page 11.
button for the corresponding
Selecting a station manually Station selection using the frequency. 1. "Radio" 2. "FM" or "AM" 3. "Manual" 4. Select the frequency: turn the controller.
To store the station: press the controller for an extended period.
155
i
Storing stations
Via iDrive 1. "Radio" 2. "FM" or "AM" 3. Select the desired station.
4. "RDS"
The setting is stored for the remote control cur- rently in use.
HD Radio* Many stations broadcast both analog and digi- tal signals. If a digital radio network is available, these stations can be received digitally and thus with better sound quality. License conditions HD Radio™ technology manufactured under license from iBiquity Digital Corp. U.S. and For- eign Patents. HD Radio™ and the HD and HD Radio logos are proprietary trademarks of iBiq- uity Digital Corp.
Activating/deactivating digital radio reception 1. "Radio" 2. "FM" or "AM" 3. Open "Options". 4. "HD Radio" The setting is stored for the remote control cur- rently in use.
This symbol is displayed when a station is
being received digitally. In areas in which the station is not continuously received in digital mode, the playback switches between analog and digital reception. Due to time delayed broadcasting, there may be repe- titions or interruptions. In this case, switch off digital radio reception.
4. Press the controller for an extended period. 5. Select the desired memory location. The stations are stored for the remote control currently in use.
About programmable memory buttons You can also store a station on the programma- ble memory buttons, refer to page 20. 1. Select a station. 2.
Press the desired button
...
for a longer period.
Radio Data System RDS* In the FM waveband, additional information is transmitted via RDS. If the reception conditions are good, the station names are shown on the Control Display. If the reception is weak or dis- rupted, it can take some time before the station names are displayed.
Switching RDS on/off 1. "Radio" 2. "FM" 3. Open "Options".
156
Displaying additional information Some stations broadcast additional information on the current track, such as the name of the artist. 1. Select the desired station. 2. Open "Options". 3. "Station info"
Deleting a station 1. "Radio" 2. "Presets" 3. Select the desired station. 4. Open "Options". 5. "Delete entry"
Selecting a substation 1. Select the desired station. 2. Press the controller. 3. Select the substation.
Presets It is possible to store up to 40 stations.
Calling up a station 1. "Radio" 2. "Presets" 3. Select the desired station.
Storing a station The station currently selected is stored. 1. "Radio" 2. "Presets" 3. "Store station"
Weather Band* Weather Radio is a service of the National Oce- anic and Atmospheric Administration (NOAA) of the US Department of Trade. Weather news flashes are repeated every 4 to 6 minutes and are routinely updated at intervals of 1 to 3 hours, and more often when necessary. Most stations operate 24 hours a day. In case of a storm, the National Weather Service interrupts the routine weather news and transmits special warning messages instead. If you have a ques- tion about NOAA Weather Radio, please con- tact the nearest office of the National Weather Service. Details are also provided on the Inter- net at www.nws.noaa.gov.
Calling up weather news flashes To operate via the iDrive: 1. Switch on the radio. 2. "Weather band" 3. Select the desired channel. The station for weather news flashes may be unavailable in some regions.
4. Select the desired memory location. The list of stored stations is stored for the remote control currently in use. The stations can also be stored on the pro- grammable memory buttons, refer to page 20.
157
i
Satellite radio
You can receive over 100 different channels with high sound quality. The channels are offered to you in predefined packages. To receive the channels of your choice, you must have this package enabled.
With this new technology the signal may fail, causing interruptions in reception.<
Enabling or disabling channels
Enabling channels 1. Ensure that reception is reliable. Reception
is usually best when you have an unob- structed view to the sky.
2. "Radio" 3. "Satellite radio" 4. Open "All Channels" or the desired cate-
gory.
5. Select the channel.
158
If the channel has not yet been enabled, then a phone number and the ESN electronic serial number are displayed.
6. Call the phone number to have the channel
enabled.
The channels can be disabled again via this phone number.
Disabling channels The channels can be disabled by phone. To do so, have the electronic serial number ESN ready. 1. "Radio" 2. "Satellite radio". 3. Open "All Channels" or the desired cate-
gory.
4. Open "Options". 5. The electronic serial number is displayed. 6. Call Sirius to have the channel disabled.
Selecting a channel
3. "Channel info"
Selecting a channel 1. "Radio" 2. "Satellite radio" 3. Select "All Channels" or the desired cate-
gory.
4. Select desired channel.
Storing a channel 1. "Radio" 2. "Satellite radio" 3. Open "All Channels" or the desired cate-
gory.
4. Open "Options". 5. "Store Channel" 6. Call up the desired memory location. The channel is stored. The channels of the last selection criterion are displayed once again after a short time.
Displaying information about another channel Information can be displayed about a channel that is not being played. 1. Highlight the channel about which you wish
to display information.
2. Open "Options".
Changing the channel using the button next to the CD/DVD drive Press the direction. The system changes to the next enabled chan- nel.
button for the corresponding
Notes If no signal can be received for more than 4 sec- onds, a message is displayed on the Control Display.
Reception may not be possible for certain reasons, e.g., environmental influences or
topographical conditions. The satellite radio has no influence on this. The signal may not be available in tunnels or underground garages, next to tall buildings, near trees, mountains or other sources of radio interference. Reception is usually possible again as soon as the signal is available again.<
159
