Pull the switch beyond the resistance


point. The window closes automatically. Pressing the switch stops the motion. Convenient operation, refer to page 34, via the remote control. Convenient closing, refer to page 39, with Com‐ fort Access. Pinch protection system If the closing force exceeds a specific value as a window closes, the closing action is interrupted. The window reopens slightly.


Danger of pinching even with pinch pro‐ tection


Even with the pinch protection system, check that the window's closing path is clear; other‐ wise, the closing action may not stop in certain situations, e.g., if thin objects are present.◀


No window accessories Do not install any accessories in the range


of movement of the windows; otherwise, the pinch protection system will be impaired.◀


Closing without the pinch protection system


Keep the closing path clear Monitor the closing process and make


sure that the closing path of the window is clear; otherwise, injuries may result.◀ For example, if there is an external danger or if ice on the windows prevents a window from closing normally, proceed as follows: 1. Pull the switch past the resistance point and


hold it there. Pinch protection is limited and the window reopens slightly if the closing force exceeds a certain value.


2. Pull the switch past the resistance point


again within approx. 4 seconds and hold it there. The window closes without pinch protec‐ tion.


Safety switch The safety switch in the driver's door can be used to prevent children, for example, from opening and closing the rear windows using the switches in the rear. Switching on and off Press the button. The LED lights up if the safety function


is switched on.


Safety switch for rear operation Press the safety switch when transporting children in the rear; otherwise, injury may result if the windows are closed without supervision.◀


42


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Roller sunblinds Roller sunblind for rear window General information If you are no longer able to move the roller sun‐ blind for the rear window after having activated it a number of times in a row, the system is blocked for a limited time to prevent overheat‐ ing. Let the system cool. The roller sunblind for the rear window cannot be moved at low interior temperatures. Extending or retracting roller blind for rear window


Press the button.


Roller sunblinds for the rear side windows Pull out the roller sunblind at the loop and hook it onto the bracket.


Do not open the window while the roller sunblind is raised.


Do not open the window while the roller sunblind is raised; otherwise, there is a risk of damage at high speeds that may result in personal injury.◀


Glass sunroof, powered General information The glass sunroof is operational when the igni‐ tion is switched on.


Keep the closing path clear Monitor the closing process and make


sure that the closing path of the glass sunroof is clear; otherwise, injuries may result.◀ Take the remote control with you Take the remote control with you when


leaving the vehicle so that children, for example, cannot operate the roof and injure themselves.◀


Opening and closing


Controls


Tilting the glass sunroof


Push switch upward briefly. ▷ Closed roof is tilted open. ▷ The opened roof closes until it is in its tilted position. The sliding visor stays completely open.


Opening/closing the glass sunroof and sliding visor together


▷ Slide switch back to the re‐


sistance point and hold. Glass sunroof and sliding vi‐ sor open together as long as the switch is held down.


▷ Press switch back past the resistance point. The glass sunroof and sliding visor open au‐ tomatically. Pressing the switch again stops the opening motion.


Analogously, the glass sunroof is closed by slid‐ ing the switch forward. The sliding visor remains open and can be closed by hand. Convenient operation, refer to page 34, via the remote control. Convenient closing, refer to page 39, with Com‐ fort Access. Comfort position Stops the roof in the comfort position if the roof is not fully open. This reduces wind noise in the passenger compartment.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


43


Initializing the system The system can be initialized when the vehicle is stationary and the engine is running. During the initialization, the roof closes without pinch protection.


Keep the closing path clear Monitor the closing process and make


sure that the closing path of the glass sunroof is clear; otherwise, injuries may result.◀


Press the switch up and hold it until the initialization is complete: ▷ Initialization begins within


15 seconds and is completed when the sunroof is com‐ pletely closed.


▷ The roof closes without pinch protection.


Controls


Opening and closing


If desired, continue the movement by pressing the switch. Pinch protection system If the closing force when closing the glass sun‐ roof exceeds a certain value, the closing move‐ ment is stopped, beginning at approximately the middle of the opening in the roof, or from the tilted position during closing. The glass sunroof opens again slightly.


Danger of pinching even with pinch pro‐ tection


Despite the pinch protection system, check that the roof's closing path is clear; otherwise, the closing action may not be interrupted in certain extreme situations, such as when thin objects are present.◀


Closing from the open position without pinch protection For example, if there is an external danger, pro‐ ceed as follows: 1. Press the switch forward beyond the resist‐


ance point and hold. Pinch protection is limited and the roof re‐ opens slightly if the closing force exceeds a certain value.


2. Press the switch forward again beyond the


resistance point and hold until the roof closes without pinch protection.


Closing from the raised position without pinch protection If there is an external danger, push the switch forward past the resistance point and hold it. The roof closes without pinch protection. Initializing after a power failure After a power failure during the opening or clos‐ ing process, the roof can only be operated to a limited extent.


44


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Adjusting Vehicle equipment All standard, country-specific and optional equipment that is offered in the model series is described in this chapter. Therefore, equipment is also described that is not available in a vehicle, e. g., because of the selected optional equip‐ ment or country variant. This also applies for safety-related functions and systems.


Sitting safely The ideal seating position can make a vital con‐ tribution to relaxed, fatigue-free driving. The seating position plays an important role in an accident in combination with: ▷ Safety belts, refer to page 48. ▷ Head restraints, refer to page 49. ▷ Airbags, refer to page 92.


Seats General information


Do not adjust the seat while driving Do not adjust the driver's seat while driv‐ ing, or the seat could respond with unexpected movement and the ensuing loss of vehicle con‐ trol could lead to an accident.◀


Do not incline the backrest too far to the rear


Also on the front passenger side, do not incline the backrest on the front passenger side too far to the rear during driving, or there is a risk of slipping under the safety belt in the event of an accident. This would eliminate the protection normally provided by the belt.◀


Adjusting


Controls


Manually adjustable seats At a glance


1 Forward/backward 2 Thigh support 3 Seat tilt 4 Backrest width 5 Lumbar support 6 Height 7 Backrest tilt


Forward/backward


Pull the lever and slide the seat in the desired direction. After releasing the lever, move the seat forward or back slightly to make sure it engages prop‐ erly.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


45


Controls


Adjusting


Height


Electrically adjustable seats At a glance


1 Seat and mirror memory 2 Backrest width 3 Lumbar support 4 Backrest tilt 5 Forward/backward, height, seat tilt


Note The seat setting for the driver's seat is stored for the remote control currently in use. When the vehicle is unlocked via the remote control, the position is automatically retrieved if the function, refer to page 35, is activated for this purpose. Adjustments in detail 1. Forward/back.


Pull the lever and apply your weight to the seat or lift it off, as necessary.


Backrest tilt


Pull the lever and apply your weight to the back‐ rest or lift it off, as necessary.


Seat tilt


Pull the lever and move the seat to the desired tilt. After releasing the lever, apply your weight to the seat or lift it off to make sure the seat en‐ gages properly.


46


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


2. Height.


Thigh support


Adjusting


Controls


3. Seat tilt.


4. Backrest tilt.


Pull the lever at the front of the seat and adjust the thigh support.


Lumbar support The curvature of the seat backrest can be ad‐ justed in such a way that it supports the lumbar region of the spine. The lower back and the spine are supported for upright posture.


▷ Press the front/rear section of


the switch. The curvature is increased/ decreased.


▷ Press the upper/lower sec‐


tion of the switch. The curvature is shifted up/ down.


Backrest width


Change the width of the backrest using the side wings to adjust the lateral support.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


47


Controls


Adjusting


Front seat heating


Switching on


Press the button once for each temper‐ ature level.


The maximum temperature is reached when three LEDs are lit. If the drive is continued within approx. 15 mi‐ nutes, the seat heating is activated automati‐ cally with the temperature selected last. When ECO PRO, refer to page 167, is activated, the heater output is reduced.


Switching off


Press the button longer. The LEDs go out.


Rear seat heating


Switching on


Press the button once for each temper‐ ature level.


The maximum temperature is reached when three LEDs are lit.


If the drive is continued within approx. 15 mi‐ nutes, the seat heating is activated automati‐ cally with the temperature selected last. When ECO PRO, refer to page 167, is activated, the heater output is reduced.


Switching off


Press the button longer. The LEDs go out.


Safety belts Seats with safety belt The vehicle has five seats, each of which is equipped with a safety belt. Number of safety belts Your vehicle has been fitted with five safety belts for the safety of you and your passengers. How‐ ever, they can only offer protection when ad‐ justed correctly. Notes Always make sure that safety belts are being worn by all occupants before driving away. Although airbags enhance safety by providing added protection, they are not a substitute for safety belts. ▷ The shoulder strap's anchorage point will be


correct for adult seat occupants of every build if the seat is correctly adjusted.


▷ The two outer safety belt buckles,


integrated into the rear seat, are for passen‐ gers sitting on the left and right.


▷ The center rear seat belt buckle is solely in‐


tended for the center passenger.


One person per safety belt Never allow more than one person to wear a single safety belt. Never allow infants or small children to ride on a passenger's lap.◀


48


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Adjusting


Controls


above approx. 5 mph/8 km/h. It can also be ac‐ tivated if objects are placed on the front pas‐ senger seat. Damage to safety belts In the case of strain caused by accidents or damage: Have the safety belts, including the safety belt tensioners, replaced and have the belt anchors checked.


Checking and replacing safety belts Have the work performed only by your


service center; otherwise, it cannot be ensured that this safety feature will function properly.◀


Front head restraints Correctly adjusted head restraint A correctly adjusted head restraint reduces the risk of injury to cervical vertebrae in the event of an accident.


Adjusting the head restraint Correctly adjust the head restraints of all occupied seats; otherwise, there is an increased risk of injury in an accident.◀


Height Adjust the head restraint so that its center is ap‐ proximately at ear level. Distance Adjust the distance so that the head restraint is as close as possible to the back of the head. If necessary, adjust the distance by adjusting the tilt of the backrest.


Putting on the belt Lay the belt, without twisting, snugly


across the lap and shoulders, as close to the body as possible. Make sure that the belt lies low around the hips in the lap area and does not press on the abdomen. Otherwise, the belt can slip over the hips in the lap area in a frontal im‐ pact and injure the abdomen. The safety belt must not lie across the neck, rub on sharp edges, be routed over solid or breaka‐ ble objects, or be pinched.◀


Reduction of restraining effect Avoid wearing clothing that prevents the belt from fitting properly, and pull the shoulder belt periodically to readjust the tension across your lap; otherwise, the retention effect of the safety belt may be reduced.◀


Buckling the belt


Make sure you hear the latch plate engage in the belt buckle.


Unbuckling the belt 1. Hold the belt firmly. 2. Press the red button in the belt buckle. 3. Guide the belt back into its reel. Safety belt reminder for driver's seat and front passenger seat


The indicator lamp flashes or lights up and a signal sounds. Make sure that the safety belts are positioned correctly. The safety belt reminder is active at speeds


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


49


Controls


Adjusting


Adjusting the height


▷ To raise: pull. ▷ To lower: press the button, arrow 1, and


push the head restraint down.


Tilt Three different tilt positions are available.


▷ Forward: pull the top edge of the head re‐


straint forward, arrow 1.


▷ Back: press the button, arrow 2. The head


restraint folds as far back as possible.


Removing Only remove the head restraint if no one will be sitting in the seat in question.


1. Pull the head restraint upward as far as pos‐


sible.


2. Press the button, arrow 1, and pull the head


restraint out completely.


Before transporting passengers Reinstall the head restraint before trans‐ porting anyone in the seat; otherwise, the pro‐ tective function of the head restraint is unavail‐ able.◀


Rear head restraints Correctly adjusted head restraint A correctly adjusted head restraint reduces the risk of injury to cervical vertebrae in the event of an accident.


Adjusting the head restraint Correctly adjust the head restraints of all occupied seats; otherwise, there is an increased risk of injury in an accident.◀


Height Adjust the head restraint so that its center is ap‐ proximately at ear level.


50


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Adjusting the height


Adjusting


Controls


▷ To raise: pull. ▷ To lower: press the button, arrow 1, and


push the head restraint down.


The center head restraint cannot be adjusted in elevation.


Folding down head restraints


Extending/retracting head restraint Only fold down head restraint if no pas‐


sengers are in the rear. Fold out retracted headr‐ ests again if passengers are being carried in the rear; otherwise, there is increased risk of injury in the event of an accident.◀


1. Pull the head restraint upward as far as pos‐


sible.


2. Press the button, arrow 1, and pull the head


restraint out completely.


Before transporting passengers Reinstall the head restraint before trans‐ porting anyone in the seat; otherwise, the pro‐ tective function of the head restraint is unavail‐ able.◀


Seat and mirror memory General information


▷ To lower flaps: press the button, arrow 1,


and press down the head restraint.


▷ Fold back up: pull up head restraints.


Removing Only remove the head restraint if no one will be sitting in the seat in question.


Two different driver's seat and exterior mirror positions can be stored and retrieved for each remote control. Settings for the backrest width and lumbar support are not stored in memory. Storing 1. Switch on the ignition. 2. Set the desired position.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


51


Controls


Adjusting


3.


Press the button. The LED in the


button lights up.


4. Press the desired button 1 or 2. The LED


goes out.


If the M button is pressed accidentally:


Press the button again. The LED goes out.


Calling up settings


Do not retrieve the memory while driving Do not retrieve the memory setting while driving, as an unexpected movement of the seat or steering wheel could result in an accident.◀


Comfort function 1. Open the driver's door. 2. Switch off the ignition. 3. Briefly press the desired button 1 or 2. The corresponding seat position is performed automatically. The procedure stops when a switch for adjust‐ ing the seat or one of the buttons is pressed. Safety mode 1. Close the driver's door or switch on the ig‐


nition.


2. Press and hold the desired button 1 or 2 until


the adjustment procedure is completed.


Calling up of a seat position deactivated After a brief period, the calling up of stored seat positions is deactivated to save battery power. To reactivate calling up of a seat position: ▷ Open and close the door or trunk lid. ▷ Press a button on the remote control. ▷ Press the Start/Stop button.


Mirrors Exterior mirrors At a glance


1 Adjusting 2 Left/right, Automatic Curb Monitor 3 Fold in and out


General information The mirror on the passenger side is more curved than the driver's side mirror.


Estimating distances correctly Objects reflected in the mirror are closer than they appear. Do not estimate the distance to the traffic behind you based on what you see in the mirror, as this will increase your risk of an accident.◀ Depending on how the vehicle is equipped, the mirror setting is stored for the remote control in use. When the vehicle is unlocked via the remote control, the position is automatically retrieved if the setting for this function is active. Selecting a mirror


To change over to the other mirror: Slide the mirror changeover switch.


Adjusting electrically


The setting corresponds to the direction in which the button is pressed.


52


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Saving positions Seat and mirror memory, refer to page 51
Adjusting manually If an electrical malfunction occurs, for example, press the edges of the mirror glass. Automatic Curb Monitor When the reverse gear is engaged, the mirror glass tilts downward slightly on the front pas‐ senger side. This improves your view of the curb and other low-lying obstacles when parking, for example.


Activating


1.


Slide the mirror changeover switch


to the driver's side mirror position.


2. Engage transmission position R.


Deactivating Slide the mirror changeover switch to the pas‐ senger's side mirror position. Fold in and out


Press the button.


Possible up to approx. 15 mph/20 km/h. For example, this is advantageous ▷ In car washes. ▷ In narrow streets. ▷ For folding back mirrors that were folded


away manually.


Mirrors that were folded in are folded out auto‐ matically at a speed of approx. 25 mph/40 km/h.


Fold in the mirror in a car wash Before entering an automatic car wash, fold in the exterior mirrors by hand or with the button; otherwise, they could be damaged, de‐ pending on the width of the vehicle.◀


Adjusting


Controls


Automatic heating Both exterior mirrors are automatically heated whenever the engine is running. Automatic dimming feature Both exterior mirrors are automatically dimmed. Photocells are used for control in the Interior rear view mirror, refer to page 53. Interior rearview mirror Reducing the blinding effect


From behind when driving at night: turn the knob.


Interior rearview mirror, automatic dimming feature The concept


Photocells are used for control: ▷ In the mirror glass. ▷ On the back of the mirror.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


53


Controls


Adjusting


Functional requirement For proper operation: ▷ Keep the photocells clean. ▷ Do not cover the area between the inside


rearview mirror and the windshield.


Switching on/off


Press the button.


▷ On: the LED lights up. ▷ Off: the LED goes out.


Steering wheel General information


Do not adjust while driving Do not adjust the steering wheel while driving; otherwise, an unexpected movement could result in an accident.◀


Adjusting


1. Fold the lever down. 2. Move the steering wheel to the preferred height and angle to suit your seating posi‐ tion.


3. Fold the lever back. Steering wheel heating


54


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Transporting children safely


Controls


Transporting children safely Vehicle equipment All standard, country-specific and optional equipment that is offered in the model series is described in this chapter. Therefore, equipment is also described that is not available in a vehicle, e. g., because of the selected optional equip‐ ment or country variant. This also applies for safety-related functions and systems.


tomatic deactivation of front passenger airbags, refer to page 94.


Deactivating the front passenger airbags If a child restraint fixing system is used in the front passenger seat, the front passenger airbags must be deactivated; otherwise, there is an increased risk of injury to the child when the airbags are triggered, even with a child restraint fixing system.◀


The right place for children Note


Children in the vehicle Do not leave children unattended in the vehicle; otherwise, they could endanger them‐ selves and other persons, e.g., by opening the doors.◀


Children should always be in the rear Accident research shows that the safest place for children is in the back seat.


Transporting children in the rear Only transport children younger than


13 years of age or shorter than 5 ft/150 cm in the rear in child restraint fixing systems provided in accordance with the age, weight and size of the child; otherwise, there is an increased risk of in‐ jury in an accident. Children 13 years of age or older must wear a safety belt as soon as a suitable child restraint fixing system can no longer be used, due to their age, weight and size.◀


Children on the front passenger seat Should it ever be necessary to use a child re‐ straint fixing system in the front passenger seat, make sure that the front, knee and side airbags on the front passenger side are deactivated. Au‐


Installing child restraint fixing systems Before mounting Before mounting child restraint fixing systems, ensure that the rear seat backrests are locked. Notes


Manufacturer's information for child re‐ straint fixing systems


To select, mount and use child restraint fixing systems, observe the information provided by the system manufacturer; otherwise, the pro‐ tective effect can be impaired.◀


On the front passenger seat Deactivating airbags After installing a child restraint fixing system in the front passenger seat, make sure that the front, knee and side airbags on the front pas‐ senger side are deactivated. Deactivate the front passenger airbags auto‐ matically, refer to page 94


Deactivating the front passenger airbags If a child restraint fixing system is used in the front passenger seat, the front passenger airbags must be deactivated; otherwise, there is


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


55


Controls


Transporting children safely


an increased risk of injury to the child when the airbags are triggered, even with a child restraint fixing system.◀


Seat position and height Before installing a child restraint fixing system, move the front passenger seat as far back as possible and adjust its height to the highest po‐ sition to obtain the best possible position for the belt and to offer optimal protection in the event of an accident. Do not change the seat position and height after this. Backrest width Adjustable backrest width: before installing a child restraint fixing system in the front passen‐ ger seat, open the backrest width completely. Do not change the backrest width again and do not call up a memory position.


Backrest width for the child seat Before installing a child restraint fixing


system in the front passenger seat, the backrest width must be opened completely. Do not change the adjustment after this; otherwise, the stability of the child seat will be reduced.◀


Child seat security


The rear safety belts and the front passenger safety belt can be locked against pulling out for mounting the child restraint fixing systems.


Locking the safety belt 1. Pull out the belt webbing completely. 2. Secure the child restraint fixing system with


the belt.


3. Allow the belt webbing to be pulled in and pull it taut against the child restraint fixing system. The safety belt is locked.


Unlocking the safety belt 1. Unbuckle the belt buckle. 2. Remove the child restraint fixing system. 3. Allow the belt webbing to be pulled in com‐


pletely.


LATCH child restraint fixing system LATCH: Lower Anchors and Tether for Children. Note


Manufacturer's information for LATCH child restraint fixing systems


To mount and use the LATCH child restraint fix‐ ing systems, observe the operating and safety information from the system manufacturer; oth‐ erwise, the level of protection may be reduced.◀


Mounts for the lower LATCH anchors Correctly engage the lower LATCH an‐ chors


Make sure that the lower LATCH anchors have properly engaged and that the child restraint fix‐ ing system is resting snugly against the back‐ rest; otherwise, the degree of protection offered may be reduced.◀ Before mounting the LATCH child restraint fix‐ ing system, pull the belt away from the child re‐ straint fixing system.


56


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Transporting children safely


Controls


Without a through-loading system: Position


Mounts for the lower LATCH anchors are lo‐ cated in the gap between the seat and backrest.


With a through-loading system: Position


Child restraint fixing system with a tether strap Note


LATCH mounting eyes Only use the mounting eyes for the upper LATCH retaining strap to secure child restraint fixing systems; otherwise, the mounting eyes could be damaged.◀


Mounting points


Depending on the vehicle equipment, there are two outer or three mounting points for child re‐ straint fixing systems with a tether strap.


Retaining strap guide


Retaining strap Make sure that the upper retaining strap is


not routed over the head restraints or sharp edges and is free of twisting on its way to the upper mounting point; otherwise, the belt can‐ not properly secure the child restraint fixing sys‐ tem in an accident.◀


Mounts for the lower LATCH anchors are lo‐ cated behind the indicated covers.


Mounting LATCH child restraint fixing systems 1. Mount the child restraint fixing system; refer to the operating instructions of the system. 2. Ensure that both LATCH anchors are prop‐


erly connected.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


57


Controls


Transporting children safely


Locking the doors and windows Rear doors


1 Direction of travel 2 Head restraint. 3 Hook for upper retaining strap 4 Mounting point/eye 5 Rear window shelf 6 Seat backrest 7 Upper retaining strap


Attaching the upper retaining strap to the mounting point 1. Remove the mounting point cover. 2. Raise or remove head restraints. 3. Guide the upper retaining strap between the


supports of the head restraint.


4. Attach the hook of the retaining strap to the


mounting eye.


5. Tighten the retaining strap by pulling it


down.


6. Lower and lock head restraints as needed.


Push the locking lever on the rear doors down. The door can now be opened from the outside only.


Safety switch for the rear


Press the button on the driver's door if children are being transported in the


rear. This locks various functions so that they cannot be operated from the rear: safety switch, refer to page 42.


58


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Driving Vehicle equipment All standard, country-specific and optional equipment that is offered in the model series is described in this chapter. Therefore, equipment is also described that is not available in a vehicle, e. g., because of the selected optional equip‐ ment or country variant. This also applies for safety-related functions and systems.


Start/Stop button The concept


Pressing the Start/Stop button switches the ignition on or off and starts the engine. Automatic transmission: The en‐ gine starts if the brake is de‐


pressed while pressing the Start/Stop button. Manual transmission: the engine starts if the clutch pedal is depressed when the Start/Stop button is pressed.


Ignition on Automatic transmission: Press the Start/Stop button but do not depress the brake. Manual-shift transmission: press the Start/Stop button, and do not press on the clutch pedal at the same time. All vehicle systems are ready for operation. Most of the indicator and warning lamps in the instrument cluster light up for varying lengths of time. To save battery power when the engine is off, switch off the ignition and any unnecessary electronic systems/power consumers. The ignition switches off automatically: ▷ When the vehicle is locked, if the low beams


are switched on.


Driving


Controls


▷ Shortly before the battery is discharged


completely, so that the engine can still be started.


▷ If the engine is switched off and the ignition


is switched on, the system automatically switches to the radio ready state when the door is opened if the lights are switched off or the daytime running lights are switched on. If the engine is switched off and the ignition is switched on, the system automatically switches to the radio ready state when the door is opened if the lights are switched off.


Ignition off Automatic transmission: Press the Start/Stop button again, but do not depress the brake. Manual-shift transmission: press the Start/Stop button again, and do not press on the clutch pedal at the same time. All indicator lamps in the instrument cluster go out. To save battery power when the engine is off, switch off the ignition and any unnecessary electronic systems/power consumers.


Transmission position P with the ignition off


When the ignition is switched off, position P is engaged automatically. When in an automatic car wash, for example, ensure that the ignition is not switched off accidentally.◀ Ignition automatically cuts off while the vehicle is stationary and the engine is stopped: ▷ During locking, also with the low beams ac‐


tivated.


▷ Shortly before the battery is discharged


completely, so that the engine can still be started. This function is only available when the low beams are switched off.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


59


Controls


Driving


▷ When opening and closing the driver door, if the driver's seat belt is unbuckled and the low beams are switched off.


▷ While the driver's seat belt is unbuckled, if the driver's door is open and the low beams are switched off.


When the ignition is switched off, by opening or closing the driver's door or unbuckling the driv‐ er's seat belt, the radio ready state remains ac‐ tive. Radio ready state Activate radio ready state: ▷ When the ignition is switched off: press ON/


OFF button on the radio.


▷ When the engine is running: press the Start/


Stop button.


Some electronic systems/power consumers re‐ main ready for operation. Radio ready state switches off automatically: ▷ After approx. 8 minutes. ▷ When the vehicle is locked using the central


locking system.


▷ Shortly before the battery is discharged


completely, so that the engine can still be started.


Starting the engine General information


Enclosed areas Do not let the engine run in enclosed


areas; otherwise, breathing of exhaust fumes may lead to loss of consciousness and death. The exhaust gases contain carbon monoxide, an odorless and colorless but highly toxic gas.◀


Unattended vehicle Do not leave the vehicle unattended with the engine running; doing so poses a risk of dan‐ ger.


Before leaving the vehicle with the engine run‐ ning, set the parking brake and place the trans‐ mission in position P or neutral to prevent the vehicle from moving.◀


Repeated starting in quick succession Avoid repeated unsuccessful attempts to start the vehicle or starting the vehicle several times in quick succession. Otherwise, the fuel is not burned or is inadequately burned, posing a risk of overheating and damage to the catalytic converter.◀ Do not wait for the engine to warm up while the vehicle remains stationary. Start driving at mod‐ erate engine speeds. Manual transmission Starting the engine 1. Depress the brake pedal. 2. Press on the clutch and shift to neutral. 3. Press the Start/Stop button. The ignition is activated automatically for a cer‐ tain time and is stopped as soon as the engine starts. Automatic transmission Starting the engine 1. Depress the brake pedal. 2. Press the Start/Stop button. The ignition is activated automatically for a cer‐ tain time and is stopped as soon as the engine starts.


Engine stop General information


Take the remote control with you Take the remote control with you when


leaving the vehicle so that children, for example, cannot start the engine.◀


60


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Set the parking brake and further secure the vehicle as required


Set the parking brake firmly when parking; oth‐ erwise, the vehicle could roll. On steep upward and downward inclines, further secure the vehi‐ cle, for example, by turning the steering wheel in the direction of the curb. ◀


Before driving into a car wash In order for the vehicle to be able to roll into a car wash, heed the information regarding Washing in automatic car washes, refer to page 213. Manual transmission Switching off the engine 1. With the vehicle at a standstill, press the


Start/Stop button.


2. Shift into first gear or reverse. 3. Set the parking brake. Automatic transmission Switching off the engine 1. Engage transmission position P with the ve‐


hicle stopped.


2. Press the Start/Stop button. The engine is switched off. The radio ready state is switched on.


3. Set the parking brake.


Auto Start/Stop function The concept The Auto Start/Stop function helps save fuel. The system switches off the engine during a stop, e.g., in a traffic congestion or at traffic lights. The ignition remains switched on. The engine starts again automatically for driving off. Certain vehicle components may experience additional wear as a result of this system.


Driving


Controls


Automatic mode The Auto Start/Stop function is operational after each engine start. This function is activated at speeds faster than about 3 mph, approx. 5 km/h. Engine stop The engine is switched off automatically during a stop under the following conditions: Manual transmission: ▷ Neutral is engaged and the clutch pedal is


not pressed.


▷ The driver's safety belt is buckled or the


driver's door is closed.


Automatic transmission: ▷ The selector lever is in transmission position


D.


▷ Brake pedal remains depressed while the


vehicle is stopped.


▷ The driver's safety belt is buckled or the


driver's door is closed.


The air flow of the air conditioner is reduced when the engine is switched off. Displays in the instrument cluster


The READY display in the tach‐ ometer signals that the Auto Start/Stop function is ready to start the engine automatically.


The display indicates that the conditions for an automatic en‐ gine stop have not been satisfied.


Note The engine is not switched off automatically in the following situations: ▷ External temperature below approx.


+37 ℉/+3 ℃.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


61


Controls


Driving


▷ The external temperature is high and auto‐


matic climate control is running.


▷ The passenger compartment has not yet


been heated or cooled to the required level. ▷ The engine is not yet at operating tempera‐


ture.


▷ The wheels are at a sharp angle or the steer‐


ing wheel is being turned.


▷ After driving in reverse. ▷ Fogging of the windows when the automatic


climate control is switched on.


▷ The vehicle battery charge is very low. ▷ The engine compartment lid is unlocked. ▷ The parking assistant is activated. ▷ Stop-and-go traffic. ▷ The transmission selector lever is in position


N or S/M.


Starting the engine The engine starts automatically under the fol‐ lowing conditions: ▷ Manual transmission:


The clutch pedal is pressed.


▷ Automatic transmission:


By releasing the brake pedal.


After the engine starts, accelerate as usual. Safety mode After the engine switches off automatically, it will not start again automatically if any one of the following conditions are met. ▷ The driver's safety belt is unbuckled and the


driver's door is open.


▷ The hood was unlocked. Some indicator lamps light up for varying lengths of time. The engine can only be started via the Start/ Stop button.


Note Even if driving away was not intended, the de‐ activated engine starts up automatically in the following situations: ▷ Excessive warming of the passenger com‐


partment when the cooling function is switched on.


▷ The steering wheel is turned. ▷ Automatic transmission: the transmission position is changed from D to N, R, or M/S. ▷ Automatic transmission: the transmission position is changed from P to N, D, R, or M/ S.


▷ The vehicle begins rolling. ▷ Fogging of the windows when the automatic


climate control is switched on.


▷ The vehicle battery charge is very low. ▷ Excessive cooling of the passenger com‐ partment when the heating is switched on. ▷ Low brake vacuum pressure; this can occur, for example, if the brake pedal is depressed a number of times in succession.


Activating/deactivating the system manually Using the button


Press the button.


▷ LED comes on: Auto Start Stop function is


deactivated. The engine is started during an automatic engine stop.


62


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


The engine can only be stopped or started via the Start/Stop button.


Releasing


Driving


Controls


▷ LED goes out: Auto Start Stop function is


activated.


Switching off the vehicle during an automatic engine stop During an automatic engine stop, the vehicle can be switched off permanently, e.g., when leaving it. 1. Press the Start/Stop button. The ignition is switched off. The Auto Start/Stop function is deactivated. Automatic transmission: the transmission position P is engaged automatically.


2. Set the parking brake. Engine start as usual via Start/Stop button. Automatic deactivation In certain situations, the Auto Start/Stop func‐ tion is deactivated automatically for safety rea‐ sons, such as when the driver is detected to be absent. Malfunction The Auto Start/Stop function no longer switches of the engine automatically. A Check Control message is displayed. It is possible to continue driving. Have the system checked.


Parking brake Applying The lever automatically engages after being pulled up.


The indicator lamp lights up red. The parking brake is set. Lower lamp: indicator lamp in Canadian models


Raise lever slightly, press the button and guide the lever down. Notes


Use while driving If on a rare occasion it is necessary to use the parking brake while driving, do not use ex‐ cessive force when applying it. When using it, keep the button on the lever depressed. Otherwise, using excessive force when applying the parking brake may cause the rear wheels to lock, resulting in fishtailing.◀ To prevent corrosion and braking control on one side only, lightly apply the parking brake period‐ ically while coasting, if traffic conditions permit. The brake lamps will not light up if the parking brake is engaged.


Turn signal, high beams, headlamp flasher Turn signal


Do not fold in the exterior mirrors During driving and during the operation of the turn signals/warning flashers, do not fold in the exterior mirror, or else the additional flasher lights in the exterior mirror do not have the pre‐ scribed position and can only be poorly de‐ tected.◀


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


63


Controls


Driving


Using turn signals


High beams, headlamp flasher


Press the lever beyond the resistance point. To switch off manually, press the lever to the re‐ sistance point. Unusually rapid flashing of the indicator lamp in‐ dicates that a turn signal bulb has failed. Triple turn signal activation Press the lever to the resistance point. The turn signal flashes three times. The function can be activated or deactivated: 1. "Settings" 2. "Lighting" 3. "Triple turn signal"


▷ High beams, arrow 1. ▷ Headlamp flasher, arrow 2.


Washer/wiper system Switching the wipers on/off and brief wipe


Do not switch on the wipers if frozen Do not switch on the wipers if they are fro‐


zen onto the windshield; otherwise, the wiper blades and the windshield wiper motor may be damaged.◀


No wiper operation on dry windshield Do not use the windshield wipers if the


windshield is dry, as this may damage the wiper blades or cause them to become worn more quickly.◀


Switching on


Signaling briefly Press the lever to the resistance point and hold it there for as long as you want the turn signal to flash.


Press the wiper levers up. The lever automatically returns to its initial po‐ sition when released.


64


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


▷ Normal wiping speed: press up once.


The wipers switch to intermittent operation when the vehicle is stationary.


▷ Fast wiping speed: press up twice or press


once beyond the resistance point. The wipers switch to normal speed when the vehicle is stationary.


Switching off and brief wipe


Press the wiper levers down. The lever automatically returns to its initial po‐ sition when released. ▷ Brief wipe: press down once. ▷ To switch off normal wipe: press down once. ▷ To switch off fast wipe: press down twice. Intermittent operation or rain sensor The concept The rain sensor automatically controls the time between wipes depending on the intensity of the rainfall. The sensor is located on the wind‐ shield, directly behind the interior rearview mir‐ ror.


Driving


Controls


Activating/deactivating


Press the button on the wiper lever. The LED in the steering column stalk lights up.


Deactivate the rain sensor in car washes Deactivate the rain sensor when passing through an automatic car wash; otherwise, dam‐ age could be caused by undesired wiper activa‐ tion.◀


Setting the frequency or sensitivity of the rain sensor


Turn the thumbwheel.


Clean the windshield, headlamps


Pull the lever.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


65


Controls


Driving


The system sprays washer fluid on the wind‐ shield and activates the wipers briefly. In addition, the headlamps are cleaned at regular intervals when the vehicle lights are switched on.


Do not use the washer system at freezing temperatures


Do not use the washers if there is any danger that the fluid will freeze on the windshield; oth‐ erwise, your vision could be obscured. For this reason, use antifreeze. Avoid using the washer when the reservoir is empty; otherwise, you could damage the pump.◀


Windshield washer nozzles The windshield washer nozzles are automati‐ cally heated while the ignition is switched on. Fold-out position of the wipers Required when changing the wiper blades or under frosty conditions, for example. 1. Switch off the ignition. 2. Under frosty conditions, ensure that the


wiper blades are not frozen onto the wind‐ shield.


3. Press the wiper lever up beyond the point of resistance and hold it for approx. 3 seconds, until the wiper remains in a nearly vertical position.


After the wipers are folded back down, the wiper system must be reactivated.


Fold the wipers back down Before switching the ignition on, fold the wipers back down to the windshield; otherwise, the wipers may become damaged when they are switched on.◀ 1. Switch on the ignition. 2. Press the wiper levers down. The wipers


move to their resting position and are ready for operation.


Washer fluid General information


Antifreeze for washer fluid Antifreeze is flammable. Therefore, keep


it away from sources of ignition. Only keep it in the closed original container and inaccessible to children. Follow the instructions on the container.◀


Washer fluid reservoir Adding washer fluid Only add washer fluid when the engine is


cool, and then close the cover completely to avoid contact between the washer fluid and hot engine parts. Otherwise, there is the danger of fire and a risk to personal safety if the fluid is spilled.◀


All washer nozzles are supplied from one reser‐ voir. Fill with water and – if required – with a washer antifreeze, according to the manufacturer's rec‐ ommendations. Mix the washer fluid before adding to maintain the correct mixing ratio. For the capacity, refer to technical data.


66


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Manual transmission Shifting


Shifting into 5th or 6th gear When shifting into 5th or 6th gear, push the gearshift lever to the right; otherwise inad‐ vertent shifting into the 3rd or 4th gear could lead to engine damage.◀


Reverse gear Select only when the vehicle is stationary. When the gearshift lever is pressed to the left, a slight resistance needs to be overcome.


Automatic transmission with Steptronic Transmission positions D Drive, automatic position Position for normal vehicle operation. All for‐ ward gears are available. R is Reverse Select only when the vehicle is stationary. N is Neutral Use in automatic car washes, for example. The vehicle can roll. When the ignition is switched off, refer to page 59, position P is engaged automatically. P Park Select only when the vehicle is stationary. The drive wheels are blocked. P is engaged automatically: ▷ After the engine is switched off when the


vehicle is in radio ready state, refer to page 60, or when the ignition is switched off, refer to page 59, and when position R or D is engaged.


Driving


Controls


▷ With the ignition is off, if position N is en‐


gaged.


▷ If the safety belt is unbuckled, the driver's door is opened, and the brake pedal is not pressed while the vehicle is stationary and transmission position R or D is engaged.


Before exiting the vehicle, make sure that posi‐ tion P of the automatic transmission is engaged. Otherwise, the vehicle may begin to roll. Kickdown Kickdown is used to achieve maximum driving performance. Press on the gas pedal beyond the resistance point at the full throttle position. Engaging the transmission position ▷ Transmission position P can only be disen‐ gaged if the engine is running and the brake pedal is pressed.


▷ With the vehicle stationary, press on the brake pedal before shifting out of P or N; otherwise, the shift command will not be executed: shift lock.


Depress the brake until you start driv‐ ing


To prevent the vehicle from creeping after you select a driving position, maintain pres‐ sure on the brake pedal until you are ready to start.◀


Engaging D, R and N


Briefly push the selector lever in the desired di‐ rection, beyond a resistance point if necessary.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


67


Controls


Driving


After releasing the selector lever, it returns to its center position.


Press unlock button, in order to: ▷ Engage R. ▷ Shift out of P.


Engaging P


Press button P.


Sport program DS and manual mode M/ Activating the sport program


Push the selector lever to the left out of trans‐ mission position D.


DS is displayed in the instrument cluster. The sport program of the transmission is acti‐ vated.


Activating the M/S manual mode 1. Push the selector lever to the left out of


transmission position D.


2. Push the selector lever forward or backward. Manual mode becomes active and the gear is changed. The engaged gear is displayed in the instrument cluster, e.g., M1. Once maximum engine speed is attained, M/S manual mode is automatically upshifted as needed. Switching to manual mode ▷ To shift down: press the selector lever for‐


ward.


▷ To shift up: pull the selector lever rearwards. Gears will only be shifted at appropriate engine and road speeds, e.g., downshifting is not pos‐ sible if the engine speed is too high. The selected gear is briefly displayed in the in‐ strument cluster, followed by the current gear. Sport automatic transmission: prevent automatic upshifting in M/S manual mode For vehicles with Sport automatic transmis‐ sions, automatic shift operations are not per‐ formed, at maximum engine speed for example, if one of the following conditions is met: ▷ DSC deactivated. ▷ TRACTION activated. ▷ SPORT+ activated. In addition, the kickdown is deactivated. Ending the sport program/manual mode Push the selector lever to the right.


68


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Driving


Controls


D is displayed in the instrument cluster. Shift paddles for Sport automatic transmission


The shift paddles on the steering wheel allow you to shift gears quickly while keeping both hands on the steering wheel. If the shift paddles on the steering wheel are used to shift gears in automatic mode, the trans‐ mission temporarily switches to manual mode. If the shift paddles are not used and the vehicle is not accelerated for a certain time, the system switches back into automatic mode if the selec‐ tor lever is in transmission position D. ▷ Shift up: pull right shift paddle. ▷ Shift down: pull left shift paddle. The vehicle only shifts up or down at appropriate engine and road speeds, e.g., it does not shift down if the engine speed is too high. The selected gear is briefly displayed in the in‐ strument cluster, followed by the current gear.


Displays in the instrument cluster


The transmission position is dis‐ played, e.g.: P.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


69


Controls


Displays


Displays Vehicle equipment All standard, country-specific and optional equipment that is offered in the model series is described in this chapter. Therefore, equipment


Instrument cluster Overview, instrument cluster


is also described that is not available in a vehicle, e. g., because of the selected optional equip‐ ment or country variant. This also applies for safety-related functions and systems.


1 Fuel gauge  76
2 Speedometer 3 Indicator/warning lamps  74
4 Tachometer  76


5 Engine oil temperature  76
6 Current fuel consumption  77
7 Electronic displays  72
8 Display/reset miles  76


70


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Overview, instrument cluster with enhanced features


Displays


Controls


1 Fuel gauge  76
2 Speedometer 3 Indicator/warning lamps  74
4 Tachometer  76


5 Engine oil temperature  76
6 Current fuel consumption  77
7 Electronic displays  72
8 Display/reset miles  76


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


71


Controls


Displays


Electronic displays Overview, instrument cluster


1 Messages, e.g. Check Control  73


Time  76
Date  76
External temperature  76
Selection lists  81
Service requirements  77


Miles/trip miles  76
Computer  81


2 Transmission display  69


Gear shift indicator  79


3 Status, Driving Experience Switch  113


72


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Overview, instrument cluster with enhanced features


Displays


Controls


Navigation display, see user's manual for Navigation, Entertainment and Communi‐ cation.


2 Energy recovery  77


Transmission display  69
Current fuel consumption  77
ECO PRO  167


3 Messages, e.g. Check Control  73


Service requirements  77


In addition, an acoustic signal may be output and a text message may appear on the Control Dis‐ play.


1 Time  76


External temperature  76
Date  76
Selection list, such as for the radio  81
Speed limit detection  79
Computer  81
Miles/trip miles  76


Check Control The concept The Check Control system monitors functions in the vehicle and notifies you of malfunctions in the monitored systems. A Check Control message is displayed as a combination of indicator or warning lamps and text messages in the instrument cluster and in the Head-up Display.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


73


Controls


Displays


Indicator/warning lamps


The indicator and warning lamps can light up in a variety of combinations and colors. Several of the lamps are checked for proper functioning and light up temporarily when the engine is started or the ignition is switched on.


Overview: indicator/warning lamps


Symbol Function or system


Turn signal


Front fog lamps


Rear fog lamp


High beams


High-beam Assistant


Parking lamps, headlamp control


Active Cruise Control


Vehicle detection, Active Cruise Control


Symbol Function or system


Collision warning


Adjustable speed limit


Cruise control


Lane departure warning


DSC Dynamic Stability Control


DSC Dynamic Stability Control is de‐ activated or DTC Dynamic Traction Control is activated Tire Pressure Monitor Flat Tire Monitor Safety belts


Airbag system


Steering system


Emissions


Parking brake Brake system In Canadian models Parking brake Brake system ABS Antilock Brake System


74


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Symbol Function or system


Hiding Check Control messages


Displays


Controls


ABS Antilock Brake System in Cana‐ dian models


At least one Check Control message is displayed or is stored (symbol in display)


Text messages Text messages in combination with a symbol in the instrument cluster explain a Check Control message and the meaning of the indicator and warning lamps. Supplementary text messages Addition information, such as on the cause of a fault or the required action, can be called up via Check Control. The supplementary text of urgent messages is displayed on the Control Display automatically. Symbols Depending on the Check Control message, the following functions can be selected. ▷


"Owner's Manual"


Display additional information about the Check Control message in the integrated owner's manual.




"Service request"


Contact the service partner. "Roadside Assistance"


Contact Roadside Assistance.


Press the computer button on the turn signal lever. ▷ Some Check Control messages are dis‐


played continuously and are not cleared un‐ til the malfunction is eliminated. If several malfunctions occur at once, the messages are displayed consecutively. These messages can be hidden for approx. 8 seconds. After this time, they are dis‐ played again automatically.


▷ Other Check Control messages are hidden


automatically after approx. 20 seconds. They are stored and can be displayed again later.


"Check Control"


Displaying stored Check Control messages 1. "Vehicle Info" 2. "Vehicle status" 3. 4. Select the text message. Messages after trip completion Special messages that are displayed during driving are displayed again after the ignition is switched off.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


75


Controls


Displays


Fuel gauge


The vehicle inclination may cause the display to vary. Notes on refueling, refer to page 172.


Tachometer Always avoid engine speeds in the red warning field. In this range, the fuel supply is interrupted to protect the engine.


Engine oil temperature


▷ Cold engine: the pointer is at


the low temperature end. Drive at moderate engine and vehicle speeds.


▷ Normal operating tempera‐ ture: the pointer is in the mid‐ dle or in the left half of the temperature display.


▷ Hot engine: the pointer is at the high tem‐ perature end. A Check Control message is displayed in addition.


Display/reset miles


Press the knob. ▷ When the ignition is switched off, the time, external temper‐ ature and odometer are dis‐ played.


▷ When the ignition is switched on, the trip


odometer is reset.


External temperature External temperature warning If the indicator drops to +37 ℉/+3 ℃, a signal sounds. A Check Control message is dis‐ played. There is an increased risk of ice


on roads.


Ice on roads Even at temperatures above +37 ℉/+3 ℃,


there can be a risk of ice on roads. Therefore, drive carefully on bridges and shaded roads, for example, to avoid the increased risk of an accident.◀


Coolant temperature If the coolant along with the engine becomes too hot, a Check Control message is displayed. Check the coolant level, refer to page 192.


Odometer and trip odometer


▷ Odometer, arrow 1. ▷ Trip odometer, arrow 2.


Time


Date


The time is displayed at the bot‐ tom of the instrument cluster. Setting the time and time format, refer to page 84.


The date is displayed in the in‐ strument cluster. Setting the date and date format, refer to page 84.


76


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


Range


After the reserve range is reached: ▷ A Check Control message is


displayed briefly.


▷ The remaining range is


shown on the onboard com‐ puter.


▷ When a dynamic driving style is used, such as when cornering quickly, operation of the engine is not always ensured.


The Check Control message appears continu‐ ously below a range of approx. 30 miles/50 km.


Refuel promptly Refuel no later than at a range of


30 miles/50 km, or operation of the engine is not ensured and damage may occur.◀


Displaying the cruising range 1. "Settings" 2. "Info display" 3. "Additional indicators" The range is displayed in the instrument cluster.


Current fuel consumption Instrument cluster


Displays the current fuel con‐ sumption. You can check whether you are currently driving in an efficient and environmen‐ tally-friendly manner.


Instrument cluster with enhanced features


Displays the current fuel con‐ sumption. You can check whether you are currently driving


Displays


Controls


in an efficient and environmentally-friendly manner.


Displaying the current fuel consumption 1. "Settings" 2. "Info display" 3. "Additional indicators" The bar display for the current fuel consumption is displayed in the instrument cluster.


Energy recovery


The kinetic energy of the vehicle is converted to electrical energy while coasting. The vehicle bat‐ tery is partially charged and fuel consumption can be reduced.


Service requirements The concept The driving distance or the time to the next serv‐ ice is displayed briefly after the ignition is switched on. The current service requirements can be read out from the remote control by the service spe‐ cialist. Display Data regarding the service status or legally man‐ dated inspections of the vehicle are automati‐ cally transmitted to your service center before a service due date. Instrument cluster


Display in the instrument cluster.


Online Edition for Part no. 01 40 2 903 880 - 07 12 490


77


Controls


Displays


Instrument cluster with enhanced features


Display in the instrument cluster with expanded scope.


5. "Date:"

Loading...
x
