6-2. Customization
Item
Function
Smart key system*1 (→P. 47)
Smart key sys- tem Number of per- missible times of continuous smart lock Wireless remote control
Wireless remote control (→P. 61)
Unlocking operation
Default set-
ting
Customized
setting
On
Off
Twice
Unlimited
On
Off
Driver's door unlocked in one step, all
doors
unlocked in two steps
All doors unlocked in one step.
Panic function
On
Off
520
6-2. Customization
Item
Function
Default set-
ting
Customized
setting
Unlocking using a key
Speed-detect-
ing automatic
door lock func-
tion*2
Opening
driver's door
unlocks all
doors
Shifting gears
to P unlocks all
doors.
Shifting gears
to position
other than P
locks all doors.
Daytime run-
ning light sys-
tem (except
Canada)
Door lock (→P. 65)
Lights (→P. 202)
Driver's door unlocked in one step, all
doors
unlocked in two steps
Off
Off
On
On
On
All doors unlocked in one step.
—
On
On
Off
Off
Off
—
521
6-2. Customization
Item
Function
Default set-
ting
Customized
setting
Time elapsed before lights turn off
Operation
when the doors
are unlocked
Operation after
the engine
switch is turned
to the “LOCK”
position*3
Operation after
the “POWER”
switch is turned
off*2
Operation
when you
approach the
vehicle with the
electronic key
on your per-
son*2
Vehicle speed
linked seat belt
reminder
buzzer
15 seconds
On
On
On
7.5 seconds —
30 seconds
Off
Off
—
—
—
Off
—
On
Off
—
On
Off
—
Illumination (→P. 319)
Seat belt reminder (→P. 435)
522
6-2. Customization
Item
Function
Default set-
ting
Customized
setting
Air condition- ing control of Eco drive mode
Automatic air condi- tioning sys- tem (→P. 236) *1: If equipped *2: Vehicles with a smart key system *3: Vehicles without a smart key system
On
Off
—
523
6-2. Customization Items to initialize
The following items must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or mainte- nance being performed on the vehicle:
Item
Maintenance data (except Canada)
When to initialize
Reference
After the maintenance is performed
P. 351
Tire pressure warning system
• When rotating the tires on vehicles with differing front and rear tire inflation pressures • When changing tire pressure (such as when changing traveling speed, load weight, etc.) • When changing the tire size
P. 383
524
Reporting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA can- not become involved in individual problems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.
526
Seat belt instructions for Canadian owners (in French)
The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.
Utilisation correcte des ceintures de sécurité
● Déroulez la sangle diagonale de telle sorte qu'elle passe bien sur l'épaule, sans pour autant être en contact avec le cou ou glisser de l'épaule.
● Placez la sangle abdominale le plus bas possible sur les hanches.
● Réglez la position du dossier de siège. Asseyez-vous le dos le plus droit possible et calez- vous bien dans le siège.
● Ne vrillez pas la ceinture de
sécurité.
527
ATTENTION
■ Lorsque vous utilisez ou rangez la ceinture de sécurité du siège
central arrière
●N’utilisez pas la ceinture de sécurité du siège arrière central lorsque l’une des boucles est détachée.
Si vous n’attachez qu’une des boucles, il y a risque de blessures graves voire mortelles en cas de freinage brusque ou de collision.
Entretien et soin
■ Ceintures de sécurité
Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez de l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées.
ATTENTION
■ Détérioration et usure des ceintures de sécurité
Inspectez les ceintures de sécurité périodiquement. Contrôlez qu'elles ne sont pas entaillées, effilochées, et que leurs ancrages ne sont pas desserrés. N'utilisez pas une ceinture de sécurité défectueuse avant qu'elle ne soit remplacée. Une ceinture de sécurité défectueuse n'apporte aucune garantie de protection de l'occupant en cas d'accident.
528
SRS airbag instructions for Canadian owners (in French)
The following is a French explanation of SRS airbag instructions
extracted from the SRS airbag section in this manual.
See the SRS airbag section for more detailed SRS airbag instructions in English.
Airbags SRS frontaux
Airbag conducteur/airbag passager avant SRS Participent à la protection de la tête et du thorax du conducteur et du passager avant contre les chocs avec les éléments de l'habitacle. Airbag SRS genoux du conducteur Participent à la protection du conducteur.
529
Airbags SRS latéraux et rideau
Airbags SRS latéraux avant Participent à la protection du haut du corps des occupants assis aux places avant. Airbags SRS rideau Participent principalement à la protection de la tête des occupants assis aux places extérieures.
Autres airbags SRS
Airbags SRS de coussin de siège Participent à la protection du conducteur et du passager avant.
530
Composition du système d’airbag SRS
latéral
indicateurs
Airbags rideau Témoin d’alerte SRS et témoins “AIR BAG ON” et “AIR BAG OFF” Airbags latéraux Capteurs d'impact (arrière) Airbag coussin de siège du passager avant Contacteur de boucle de ceinture de sécurité passager avant Airbag conducteur Contacteur de boucle de ceinture sécurité conducteur Airbag coussin de siège du conducteur
de
latéral
latéral
Capteurs d'impact (avant) Prétensionneurs de ceinture de sécurité et limiteurs d’effort Capteurs d'impact (porte avant) Airbag de genoux du conducteur Système de classification de l'occupant du siège passager avant (ECU et capteurs) Boîtier d'airbag Capteurs d'impact avant Airbag passager avant
électronique
531
Votre véhicule est équipé de SACS DE SÉCURITÉ GONFLABLES INTELLIGENTS (ADVANCED AIRBAGS) conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des sacs de sécurité gonflables régule le déploiement de ces derniers sur la base des informations qu'il reçoit des capteurs, etc., indiqués ci-dessus dans le schéma les composants du système. Parmi ces informations figurent la gravité du choc et l'occupation du véhicule par les passagers. Le déploiement rapide des sacs de sécurité gonflables est obtenu au moyen d'une réaction chimique dans les dispositifs pyrotechniques, qui produit un gaz inoffensif permettant d'amortir le mouvement des occupants.
illustrant
532
ATTENTION
■ Précautions avec les airbag SRS
Respectez les précautions suivantes concernant les airbags SRS. Autrement, des blessures graves, voire mortelles, pourraient s'ensuivre. ●Le conducteur et tous les passagers à bord du véhicule doivent porter leur
ceinture de sécurité correctement. Les airbags SRS sont des dispositifs de protection complémentaires aux ceintures de sécurité.
●L'airbag SRS conducteur se déploie avec une violence considérable, qui peut être très dangereuse voire mortelle si le conducteur se trouve très près de l'airbag. L'autorité fédérale chargée de la sécurité routière aux États-Unis, la NHTSA (National Highway Traffic Safety Administration) conseille:
Sachant que la zone de danger pour l’airbag conducteur se trouve dans les premiers 2 à 3 in. (50 à 75 mm) de déploiement, vous disposez d’une marge de sécurité confortable en vous plaçant à 10 in. (250 mm) de votre airbag conducteur. Cette distance est à mesurer entre le moyeu du volant et le sternum. Si vous êtes assis à moins de 10 in. (250 mm), vous pouvez changer votre position de conduite de différentes façons:
• Reculez votre siège le plus possible, de manière à pouvoir encore
atteindre confortablement les pédales.
• Inclinez légèrement le dossier du siège. Bien que les véhicules puissent être différents les uns des autres, la plupart des conducteurs peuvent s'asseoir à une distance de 10 in. (250 mm), même avec le siège conducteur complètement avancé, simplement en inclinant un peu le dossier de siège. Si vous avez des difficultés à voir la route après avoir ferme et antidérapant pour vous rehausser ou, si votre véhicule est équipé du réglage en hauteur du siège, remontez-le.
incliné votre siège, utilisez un coussin
• Si votre volant est réglable, inclinez-le vers le bas. Cela a pour effet d'orienter l'airbag en direction de votre poitrine plutôt que de votre tête et de votre cou.
Réglez votre siège selon ces recommandations de la NHTSA, tout en conservant le contrôle des pédales, du volant et la vue des commandes du tableau de bord.
533
ATTENTION
■ Précautions avec les airbag SRS
●Si vous attachez une rallonge de ceinture de sécurité aux boucles de ceinture de sécurité avant, mais pas au pêne de la ceinture de sécurité, les airbags SRS frontaux détectent que le conducteur et le passager avant ont attaché leur ceinture de sécurité, alors même que ce n'est pas le cas. Dans ce cas, il se peut que les airbags SRS frontaux pas correctement en cas d'accident, et vous risquez d'être tué ou grièvement blessé. Veillez à porter la ceinture de sécurité avec la rallonge de ceinture de sécurité.
déploient
ne
se
●L'airbag SRS passager avant se déploie également avec une violence considérable, qui peut être très dangereuse voire mortelle si le passager avant se trouve très près de l'airbag. Éloignez le siège passager avant au maximum de l'airbag et réglez le dossier de siège de sorte à être assis bien droit dans le siège.
●Les nourrissons et les enfants qui ne sont pas correctement assis et/ou protégés peuvent être grièvement blessés ou tués par le déploiement d'un airbag. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés. Les sièges arrière sont plus sûrs pour les nourrissons et les enfants que le siège passager avant. ●N’installez jamais un siège de sécurité enfant type dos à la route sur le siège passager avant, même si le témoin indicateur “AIR BAG OFF” est allumé. En cas d'accident, le déploiement de l'airbag passager avant et de l’airbag de coussin de siège du côté passager avant est si rapide et violent que l'enfant risquerait d'être blessé grièvement, voire mortellement, si le siège de sécurité enfant type dos à la route est installé sur le siège passager avant.
534
ATTENTION
■ Précautions avec les airbag SRS
●Ne pas s'asseoir sur le bord du siège et ne pas s'appuyer contre la planche de bord.
●Ne laissez pas un enfant rester debout devant l'airbag SRS passager avant ou bien s'asseoir sur les genoux du passager avant.
●Ne laissez pas
les occupants des sièges avant voyager avec un objet sur les genoux.
●Ne vous appuyez pas contre la porte, contre le rail latéral de toit ou contre les montants avant, latéraux et arrière.
●Interdisez à quiconque de s'agenouiller sur le siège passager en appui contre la porte ou de sortir la tête ou les mains à l'extérieur du véhicule.
535
ATTENTION
■ Précautions avec les airbag SRS
●Ne fixez ni ne posez aucun objet sur la planche de bord, la garniture du volant de direction et la partie inférieure du tableau de bord. Au déploiement des airbags SRS conducteur et passager avant et de l’airbag de genoux du conducteur, ces objets risquent de se transformer en projectiles.
●Ne rien fixer aux portes, à la vitre de pare-brise, aux vitres latérales, aux montants avant et arrière, au rail latéral de toit et à la poignée de maintien.
●Véhicules dépourvus de système d'accès et de démarrage “mains libres”: Évitez d'attacher au porte-clés de la clé de contact des objets lourds, pointus ou très durs, comme d'autres clés par exemple. Ces objets risquent d’entraver le déploiement de l’airbag SRS de genoux du conducteur ou d’être projetés vers le siège conducteur par la force de déploiement, constituant ainsi un danger potentiel.
●Ne suspendez aux crochets à vêtements aucun cintre nu ni aucun objet dur. En cas de déploiement des airbags rideau SRS, tous ces objets pourraient se transformer en projectiles et causer des blessures graves, voire mortelles.
●Si un cache en vinyle recouvre la partie où l’airbag SRS de genoux du
conducteur se déploie, veillez à l'enlever.
536
ATTENTION
■ Précautions avec les airbag SRS
●N'utilisez aucun accessoire de siège venant recouvrir les zones de déploiement des airbags SRS latéraux et des airbags SRS de coussin de siège, car il risquerait d'en gêner le déploiement. De tels accessoires peuvent empêcher les airbags latéraux et airbags de coussin de siège de fonctionner correctement, désactiver le déploiement accidentel des airbags latéraux et de coussin de siège, entraînant la mort ou des blessures graves.
le dispositif ou entraîner
●Évitez de faire subir des chocs ou des pressions excessives aux zones
renfermant les composants des airbag SRS. En effet, cela pourrait entraîner un fonctionnement anormal des airbags SRS.
●Ne touchez aucun composant du système immédiatement après le déclenchement (gonflage) des airbags SRS, car ils sont alors encore très chauds.
●Si vous avez des difficultés à respirer après le déploiement des airbags SRS, ouvrez une porte ou une vitre pour faire entrer de l'air frais, ou bien descendez du véhicule si cela ne présente pas de danger. Essuyez tout résidu dès que possible afin d'éviter d'éventuelles irritations de la peau.
●Si les parties renfermant les airbags SRS, telles que la garniture du volant et les garnitures de montants avant et arrière, sont abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
●Ne rien disposer sur le siège du passager avant, comme par exemple un coussin. Cela a pour conséquence de répartir le poids du passager sur toute la surface du siège, ce qui empêche le capteur de détecter correctement le poids du passager. Il en résulte que l’airbags SRS frontal du passager avant risque de ne pas se déployer en cas d'accident.
537
ATTENTION
■ Modification et mise au rebut des éléments du système d'airbag SRS
Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes. Les airbags SRS risquent de ne pas fonctionner correctement ou de se déployer (gonfler) accidentellement, provoquant ainsi des blessures graves, voire mortelles. ●Installation, dépose, démontage et réparations des airbags SRS. ●Réparations, modifications, démontage ou remplacement du volant, du tableau de bord, de la planche de bord, des sièges ou de leur garniture, des montants avant, latéraux et arrière ou des rails latéraux de toit.
●Réparations ou modifications des ailes avant, du pare-choc avant ou des
flancs de l'habitacle.
●Installation de chasse-neige, de treuils, etc., sur la calandre (pare-buffle
ou pare-kangourou, etc.).
●Modification du système de suspension du véhicule. ●Installation d'appareils électroniques, tels qu'un radioémetteur/récepteur
ou d'un lecteur CD.
●Aménagements du véhicule visant à permettre sa conduite par une
personne atteinte d'un handicap physique.
538
Abbreviation list Abbreviation/Acronym list
ABBREVIATIONS A/C ABS ACC ALR CRS DISP ECU EDR ELR EPS EV GAWR GVWR I/M LATCH LED M + S MMT MTBE OBD SRS
MEANING
Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Display Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Electric Vehicle Gross Axle Weight Ratings Gross Vehicle Weight Rating Emission inspection and maintenance Lower Anchors and Tethers for Children Light Emitting Diode Mud + Snow Methylcyclopentadienyl Manganese Tricarbonyl Methyl Tertiary Butyl Ether On Board Diagnostics Supplemental Restraint System
540
Abbreviation list
ABBREVIATIONS TIN TPMS TRAC TWI VIN VSC
MEANING
Tire Identification Number Tire Pressure Warning System Traction Control Treadwear Indicators Vehicle Identification Number Vehicle Stability Control
541
