67


FUEL GAUGE


COOLANT TEMPERATURE GAUGE


Drive with moderation and at low engine speeds. If necessary, switch off the engine and allow it to cool down. Checking coolant level, refer to page 122.


Temperature warning LED 1 comes on while the vehicle is in motion: engine is too hot. Switch off the engine immediately and allow it to cool down. When you switch on the ignition, the LED 1 lights up briefly to confirm that the system is operational.


Equipment with navigation system* or Cockpit Chrono Pack*


Coolant temperature warning lamp 2 comes on while the vehicle is in motion: engine is too hot. Switch off the engine immediately and allow it to cool down.


In the navigation system*


Please also comply with the instruc- tions in the previous section.<


If the LED changes from orange to red, there are approx. 2.1 gallons/8 liters of fuel left in the tank.


Coolant temperature gauge Depending on the equipment version, a coolant temperature gauge is located in the speedometer or the Cockpit Chrono Pack.


Low temperature: The engine is still cold. Drive at moderate engine and vehicle speeds.


Center position: Normal operating temperature of the engine.


High temperature: As soon as there is a deviation from the center position upwards or to the left:


68


TACHOMETER


SERVICE INTERVAL DISPLAY


Do not operate the engine with the needle in the red overspeed zone of the gauge. To protect the engine, the power is reduced when you approach a certain engine speed in this sector.


Remaining distance for service With the ignition key in position 1 or higher, the distance remaining before the next scheduled service is displayed in miles for a short period. The display also indicates whether an engine oil service and/or an inspection is due.


The remaining distance is calculated on the basis of the preceding driving style. The dis- play counts backwards in steps of 35 miles/ 50 km to the next service. A flashing mes- sage and a minus sign in front of the dis- play that again begins counting forwards mean that the service interval has been exceeded. Please schedule an appointment with your MINI Dealer or a workshop that has spe- cially trained personnel working in accor- dance with the specifications of your MINI manufacturer. For more information on the service inter- val display, refer to page 125.


69


ONBOARD COMPUTER*


Black ice can occur at temperatures above +36/377 as well. You


should therefore drive carefully on bridges and shaded roads, for example; otherwise there is an increased risk of an accident.<


With navigation system: The temperature is displayed in the status line of the navigation system, refer to the Owner's Manual for Navigation System.


Current vehicle speed If the vehicle is not equipped with an onboard computer, only the current speed is displayed. Press the button in the turn indicator lever to switch the display from outside temper- ature to current speed and vice versa.


Range The display shows a range estimate based on the available fuel. The amount of fuel remaining in the tank is measured, and the range is estimated from your driving style over the last 20 miles/30 km.


If the range displayed is less than 35 miles/50 km, be sure to refuel;


otherwise engine functions are not guaran- teed and damage could occur.<


Mode selection You can use the button in the turn signal indicator lever to retrieve information from the onboard computer for display in the tachometer. By pressing the button briefly, you can call up a new function for display. The order of the displays: Outside temperature, range, average con- sumption and current consumption, aver- age speed and current speed.


If the vehicle is equipped with a navi- gation system, you will find more


information on the onboard computer in the Owner's Manual for Navigation Sys- tem.<


Outside temperature If the vehicle is not equipped with an onboard computer, only the outside tem- perature is displayed. Press the button in the turn indicator lever to switch the display from outside temper- ature to current speed and vice versa.


You can have the unit of measure set to7 or6.<


Outside temperature warning If the temperature falls to approx. +36/ 377, the onboard computer automati- cally switches to the outside temperature display. In addition, a signal sounds and the display flashes.


70


ONBOARD COMPUTER*


Average speed, average fuel consumption To reset average consumption, average speed: Press the button in the turn signal indicator lever for a long time. The average consumption is determined for the time during which the engine is run- ning.


If the vehicle is equipped with a navi- gation system, the displays are


shown in the area of the navigation sys- tem.<


You can have a different unit of mea- sure set.<


Current fuel consumption Shows the current fuel consumption. You can check how economically and environ- mentally friendly you are currently driving.


You can have a different unit of mea- sure set.<


71


DRIVING STABILITY CONTROL SYSTEMS


tions, such as fishtailing or nose-diving. In these cases, and subject to physical limits, ASC helps to keep the vehicle on a steady course by reducing engine speed and by applying brakes at individual wheels. This system optimizes driving stability and trac- tion, especially when just starting off, when accelerating or when cornering. The ASC is operational each time you start the engine. It integrates the Antilock Brake System (ABS) and Electronic Brake Force Distribution (EBD).


Dynamic Stability Control (DSC)* DSC prevents slip at the drive wheels while starting off and accelerating the vehicle. DSC also recognizes unstable vehicle condi- tions, such as fishtailing or nose-diving. In these cases, and subject to physical limits, DSC helps to keep the vehicle on a steady course by reducing engine speed and by applying brakes at individual wheels. The DSC is operational every time you start the engine. It integrates All Season traction Control (ASC).


The laws of physics cannot be repealed, even with ASC. An appropri-


ate driving style always remains the responsibility of the driver. Avoid using the additional safety margin provided by the system as an excuse for taking unnecessary risks. Do not make any modifications to the ASC system. Allow only authorized technicians to perform service procedures on the ASC.<


The laws of physics cannot be repealed, even with DSC. An appro-


priate driving style always remains the responsibility of the driver. Avoid using the additional safety margin provided by the system as an excuse for taking unnecessary risks. Do not make any modifications to the DSC system. Allow only authorized technicians to perform service procedures on the DSC.<


Your MINI or MINI Convertible is equipped with a series of systems that help maintain driving stability even in adverse driving sit- uations.


Antilock Brake System (ABS) ABS keeps the wheels from locking during braking. Steering stability is maintained even during full brake applications. In this way, active safety is enhanced. ABS is operational each time the engine is started. Braking safely, refer to page 103.


Cornering Brake Control CBC Driving stability and steering characteris- tics are further enhanced while braking in turns or during a lane change.


Electronic Brake Force Distribution (EBD) The system controls brake-force applica- tion at the rear wheels in order to obtain increased stability in the vehicle's braking response.


All Season traction Control (ASC)* ASC prevents slip at the drive wheels while starting off and accelerating the vehicle. ASC also recognizes unstable vehicle condi-


72


DRIVING STABILITY CONTROL SYSTEMS


Switching the ASC or DSC on again Briefly press the switch once again. The indicator lamp goes out.


Indicator lamp


The indicator lamp will go out shortly after the ignition has been switched on, refer to pages 17, 18.


The indicator lamp flashes: ASC or DSC is regulating drive torque and braking forces. The indicator lamp lights up continuously: the system is malfunctioning or has been switched off at the button. Have the sys- tem checked as soon as possible.


Switching off the ASC or DSC Briefly press the switch. The indicator lamp stays lit. When driving with snow chains or to 'rock free' in snow, it can be helpful to switch off the ASC/DSC for a brief period.


To maintain vehicle stability, always drive with the ASC or DSC switched


on whenever possible.<


73


FLAT TIRE MONITOR


The concept As you drive, the Flat Tire Monitor keeps track of the tire inflation pressure in all four tires. The system alerts you when there is a substantial pressure loss in one of the tires relative to another. In the event of tire pressure loss, the rolling radius of the tire changes, thereby affect- ing the rotational speed of the wheels. This change is detected, and a flat tire warning is issued to the driver.


System requirements To ensure the reliability of flat tire warn- ings, the system must be initialized with the correct tire inflation pressures.


Each time you correct the pressure in a tire, or change a wheel or tire, the


system must be reinitialized.<


System limitations


The Flat Tire Monitor cannot alert you to severe and sudden tire damage


caused by external factors, nor does it detect the gradual and minor loss of pres- sure in all four tires.<


The system could issue a false warning or function in a delayed manner in the follow- ing situations: >System was not initialized >You are driving on a snow-covered or


slippery road surface


>Sporty driving style: slip at the drive


wheels, high lateral acceleration >You are driving with snow chains. When driving with a space-saver spare tire, the Flat Tire Monitor cannot function.


74


Initializing the system


Initialization is completed while you are driving, but you can stop the car at any time. Initialization is automatically continued when you continue driving. Do not initialize the system if you are driving with snow chains or a space-saver spare tire.<


1. Before a journey, start the engine, but do


not start driving.


2. Press the button until the indicator lamp


in the display elements lights up in yel- low for several seconds.


3. Drive off.


Initialization is completed during the drive, without any feedback issued.


Malfunction


The warning lamp lights up in yel- low. There is a malfunction in the Flat Tire Monitor or the system has failed. Have the system checked as soon as possible.


FLAT TIRE MONITOR


Flat tire warning


The warning lamp lights up in yel- low. An acoustic signal also sounds. There is a flat tire or a significant


loss of pressure in a tire. 1. Reduce speed and stop the vehicle with caution. Avoid hard brake applications and steering maneuvers.


2. Determine which tire is damaged.


If this cannot be determined, con- tact your MINI Dealer.<


3. Repair the flat tire, refer to page 137. Vehicles with Run-Flat Tires: 1. Reduce vehicle speed carefully to under


50 mph / 80 km/h. Avoid hard brake applications and steering maneuvers. Do not exceed a speed of 50 mph / 80 km/h.


Do not continue driving if the vehi- cle is not equipped with Run-Flat Tires, refer to page 115. If you continue to drive with a flat tire, a serious acci- dent could result.<


2. Check the tire inflation pressure in all


four tires at the earliest opportunity.


If the tire inflation pressure is cor- rect in all four tires, it is possible


that the Flat Tire Monitor was not initial- ized. In this case, initialize the system.<


3. If there is a total loss of tire inflation pressure, 0 psi/0 kPa, or obvious tire damage, you can gauge the mileage for continued driving on the basis of the fol- lowing indications:


>With a light load:


1 to 2 persons without luggage: approx. 155 miles/250 km


>With a medium load:


2 persons, luggage compartment full, or 4 persons without luggage: approx. 90 miles/150 km


>With a full load:


4 or more persons, luggage compart- ment full: approx. 30 miles/50 km.


Drive cautiously. Do not exceed a speed of 50 mph / 80 km/h. In case of tire pressure loss you must expect changes in vehicle handling such as lower track sta- bility during braking, longer braking dis- tances and changes in self-steering proper- ties when close to the handling limit. For safety reasons, the manufacturer of your MINI recommends not having dam- aged Run-Flat Tires repaired, but to consult a MINI Dealer in such cases.<


75


TIRE PRESSURE MONITOR*


The concept TPM checks the inflation pressures of the four mounted tires. The system notifies you if there is a significant loss of pressure in one or more tires.


System requirements In order to assure the reliable reporting of a flat tire, the system must be reset while all tire inflation pressures are correct. Always use wheels with TPM electronics and a metal valve. Otherwise, the system may malfunction.


Each time a tire inflation pressure has been corrected or a wheel or tire has


been changed, reset the system.<


System limitations


TPM cannot warn you in advance of sudden severe tire damage caused by


outside influences.<


The system does not work correctly if it has not been reset; for example, a flat tire may be indicated even though the tire inflation pressures are correct. The system is inactive and cannot indicate a flat tire if a wheel without TPM electron- ics, such as a compact spare wheel, has been mounted, or if TPM is temporarily malfunctioning due to other systems or de- vices using the same radio frequency.


76


Resetting the system


Each time a tire inflation pressure has been corrected or a wheel or tire has


been changed, reset the system.<


1. Start the engine, but do not start driving. 2. Press the button until the yellow warn- ing lamp in the display elements lights up yellow for several seconds.


3. Drive off.


After driving a few minutes, the set inflation pressures in the tires are accepted as the target values to be mon- itored. The system reset is completed without notification during your drive, which can be interrupted at any time. When driving resumes, the reset is con- tinued automatically.


TIRE PRESSURE MONITOR*


Message for low tire inflation pressure The warning lamp lights up in yel- low. An acoustic signal also sounds. A flat tire or a severe loss in pres-


sure has occurred in one or more tires. 1. Reduce speed and stop the vehicle with caution. Avoid hard brake applications and steering maneuvers.


2. Identify the damaged wheel or wheels. If this cannot be determined, con- tact your MINI Dealer.<


3. Replace the damaged wheel, refer to


Wheel change on page 139.


4. Check the tire inflation pressure and cor-


rect it if necessary.


The compact wheel is not equipped with the necessary TPM electronics and is not monitored after it is mounted. When driv- ing with a compact wheel, the system indi- cates that a malfunction is occurring.


Vehicles with Run Flat tires: 1. Reduce vehicle speed carefully to under


50 mph / 80 km/h. Avoid hard brake applications and steering maneuvers. Do not exceed a speed of 50 mph / 80 km/h.


Do not continue driving if the vehi- cle is not equipped with Run Flat tires, refer to page 115. If you continue to drive with a flat tire, a serious acci- dent could result.<


2. Check the tire inflation pressure in all four tires at the earliest opportunity.


If the tire inflation pressure is cor- rect in all four tires, it is possible that the Tire Pressure Monitor was not initialized. In this case, initialize the sys- tem.<


3. If there is a total loss of tire inflation pressure, 0 psi/0 kPa, or obvious tire damage, you can gauge the mileage for continued driving on the basis of the fol- lowing indications:


>With a light load:


1 to 2 persons without luggage: approx. 155 miles/250 km


>With a medium load:


2 persons, luggage compartment full, or


4 persons without luggage: approx. 90 miles/150 km


>With a full load:


4 or more persons, luggage compart- ment full: ca. 30 miles/50 km.


Drive cautiously. Do not exceed a speed of 50 mph / 80 km/h. In case of tire pressure loss you must expect changes in vehicle handling such as lower track sta- bility during braking, longer braking dis- tances and changes in self-steering proper- ties when close to the handling limit. For safety reasons, the manufacturer of your MINI recommends not having dam- aged Run Flat tires repaired, but to consult a MINI Dealer in such cases.<


Malfunction


The yellow warning lamp flashes and then lights up permanently. No punctures can be detected.


This type of message is shown in the fol- lowing situations: >If there is a malfunction


Have the system checked.


>If a wheel without TPM electronics is


mounted, e.g. a compact wheel.


77


TIRE PRESSURE MONITOR*


>If TPM is temporarily malfunctioning due


to other systems or devices using the same radio frequency.


has not reached the level at which the TPMS low tire pressure telltale illuminates. The TPMS malfunction indicator is com- bined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously lit. This sequence will continue upon subse- quent vehicle startups as long as the mal- function exists. When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pres- sure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction tell- tale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly.


Declaration according to NHTSA/ FMVSS 138 Tire Pressure Monitoring System Each tire should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pres- sure label. If your vehicle has tires of a dif- ferent size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires. As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system, TPMS, that illuminates a low tire pressure telltale when one or more of your tires are significantly under-inflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly underinflated tire causes the tire to overheat and can lead to tire fail- ure. Underinflation also reduces fuel effi- ciency and tire tread life, and may affect the vehicle's handling and stopping ability. Please note that the TPMS is not a substi- tute for proper tire maintenance, and it is the driver's responsibility to maintain cor- rect tire pressure, even if underinflation


78


AIRBAGS


The following airbags are located under the marked covers:


MINI 1 Side airbags in the backrests 2 Head airbags 3 Front airbags


MINI Convertible 1 Side/head airbags in the backrests 3 Front airbags


Protective effect


Comply with the instructions on page 42, or the occupants' personal


safety will be diminished.<


The front airbags supplement the safety belts by providing additional protection for the driver and front passenger in the event of a frontal collision in which the protec- tion afforded by the belts alone may no longer be sufficient. When needed, the head and side airbags help to furnish pro- tection in the event of side impact. Each of the side airbags is designed to help support the seat occupant's upper body. The corre- sponding side/head airbag in the MINI Con- vertible or the head airbag in the MINI sup- ports the head. The airbags are designed to not be trig- gered in certain types of collisions, e.g. not in minor accidents or rear impacts. For information on the ideal seating posi- tion, refer to page 42.


Do not apply adhesive materials to the cover panels of the airbags, cover them or modify them in any other way. Do not fit covers, cushions or other items to the front seats that have not been specially approved for seats with integrated side air- bags. Do not hang clothing, e.g. jackets, over the backrests. Do not attempt to remove the airbag restraint system from the vehicle. Do not touch the individual components directly


after the system has been triggered; other- wise there is a danger of burns. In the event of malfunctions, deactivation or deploy- ment of the airbag restraint system, have the system checked, repaired or disassem- bled only by a MINI Dealer or a workshop with specially trained personnel working in accordance with the specifications of the MINI manufacturer and having the neces- sary permits for handling explosive devices. Unprofessional attempts to service the sys- tem could lead to failure in an emergency or undesired airbag activation, either of which could result in personal injury.<


Warning notices and information regard- ing airbags can also be found on the sun visors.


Automatic deactivation of the front passenger airbags An analysis of the impression in the front passenger seat cushion determines whether and how the seat is occupied. The system correspondingly activates or deacti- vates the front and side airbags for the front passenger.


The indicator lamp above the interior rearview mirror shows the current


status of the front passenger airbags, deac-


79


AIRBAGS


tivated or activated, refer to Functional sta- tus of the front passenger airbags below. <


Before transporting a child on the front passenger seat, read the safety notes and instructions under Transporting children safely, refer to page 50. Adolescents and adults sitting in certain positions could also deactivate the front and side airbags for the front passenger; the indicator lamp for the front passenger airbags comes on. In such cases, the occu- pant should change his or her sitting posi- tion so that the front passenger airbags are activated and the indicator lamp goes out. If the airbags are not activated although the seat occupant has changed his or her position, have the occupant sit on a rear seat. Do not attach covers, cushions, ball mats or other items to the front passenger seat unless they are specifically recom- mended by the manufacturer of your MINI. Do not place any objects under the seat which could press against the seat from below. Otherwise, a correct analysis of the seat cushion is not ensured.<


80


The front and side airbags for the front passenger are not activated.


>The indicator lamp does not come on


when the system detects a person of suf- ficient size sitting correctly on the seat, for example. The front and side airbags for the front passenger are activated. >The indicator lamp does not come on when the seat is empty. However, the front and side airbags for the front pas- senger are not activated.


Operational readiness of the airbag system


Starting from ignition key position 1, the warning lamp in the display elements lights up briefly for confirmation that the entire airbag sys- tem and the seat belt tensioners are opera- tional.


Airbag system malfunctioning >The warning lamp does not come on


along with ignition key position 1


>The warning lamp stays lit continuously.


In the event of a malfunction, have the airbag system checked immedi-


ately. Otherwise, there is a risk that the sys- tem will not function as intended in an accident of sufficient severity.<


Functional status of the front passenger airbags As an example, the illustration shows the indicator lamp for front passenger airbags in the MINI Convertible. In accordance with whether and how the front passenger seat is occupied, the indi- cator lamp for the front passenger airbags shows the functional status of the front and side airbags for the front passenger. The indicator lamp shows whether the front passenger airbags are activated or deactivated. >The indicator lamp comes on as intended


when a child in a specially designated child-restraint system is detected on the front passenger's seat.


PARK DISTANCE CONTROL (PDC)*


The concept The PDC assists you when you back into a parking space. A signal tone tells you the current distance to an object behind your vehicle. To do this, four ultrasonic sensors in the rear bumper measure the distance to the nearest object. The sensors on each side have a range of approx. 2 ft/60 cm, the middle sensors one of approx. 5 ft/1.5 m.


PDC is a parking aid that can identify objects if they are approached slowly,


as is generally the case when parking. Avoid driving towards objects rapidly; due to underlying physical principles, the sys- tem may otherwise alert you too late for you to take evasive steps.<


Automatic function With the ignition key in position 2, the sys- tem starts to operate automatically about one second after you select reverse gear or place the selector lever in position R.


Wait for this one second before you drive backwards.<


You can have a signal tone set as a confirmation that PDC has been acti-


vated.<


Acoustical signals The distance to an object is indicated by a tone sounding at intervals. As the distance between vehicle and object decreases, the intervals between the tones become shorter. A continuous tone indicates the presence of an object less than 12 in/30 cm away. The warning signal is canceled after approx. three seconds if the distance to the object remains constant during this time, for instance if you are moving parallel to a wall.


Malfunction A continuous high-pitched tone will sound during initial activation. The system is mal- functioning. Have the system checked.


Volume control The volume of the Park Distance Control signal can be adjusted from level 1, soft, to level 6, loud.


The system is deactivated when you shift away from Reverse.


You can have this function set.<


System limitations


Even with PDC, final responsibility for estimating the distance between the


vehicle and any objects always remains with the driver. Even when sensors are involved, there is a blind spot in which objects cannot be detected. Recognition of some objects can be beyond the limits of physical ultrasonic measurement, for example with towing bars or hitches or with thin or wedge- shaped objects. It is also possible that low objects already detected, such as a curb edge, can disappear in the blind spot of the sensors before a continuous tone is sounded, or that protruding objects higher above the ground, such as ledges, are not detected. Loud sources of sound outside and inside your vehicle can drown the PDC signal tone.<


Keep the sensors clean and free of ice or snow in order to ensure that they


will continue to operate effectively. Do not apply high pressure spray to the sensors for a prolonged period of time. Always maintain a distance which is greater than 4 in/10 cm.<


81


AIR CONDITIONING SYSTEM


1 Air onto the windshield and onto the


side windows


2 Air for the upper body area 84
3 Air for the front and rear footwells


4 Temperature 83
5 Windshield heating* 83
6 Air volume/Blower 83
7 Cooling function 83


8 Air distribution 83
9 Recirculated air mode 83
10 Rear window defroster 83


82


AIR CONDITIONING SYSTEM


Air volume/Blower


Rear window defroster


Recirculated air mode


You can select blower speeds from 1 to 4. Position 0: blower is switched off. The heating, ventilation and air


conditioning operate in position 1 or higher.


Temperature


Turn to the right, red, to increase the temperature. Turn to the left, blue, to decrease the temperature.


Air distribution


Air distribution towards upper body region region and footwell


, upper body


, footwell and windows


, footwell


and windows Intermediate positions are possible, refer to illustration and overview on page 82.


The LED is lit when the recircu- lated air mode is on. Supply of outside air into the vehicle is


blocked. The air within the vehicle is recirculated.


If the windows fog up in the recircu- lated air mode, turn the recirculated air mode off and, if necessary, increase the air supply. The recirculated air mode should not be used constantly over a longer period of time; otherwise the air quality in the vehicle's interior will gradually deterio- rate.<


The LED is lit when the rear win- dow defroster is on. The heater switches off auto-


matically after a short time.


Windshield heating*


The LED is lit when the wind- shield heating is on. The windshield heating switches


off automatically after a short time.


Cooling function


The LED is lit when the cooling function is on. The air is cooled and dehumidi- fied and, depending on the temperature setting, rewarmed. Depending on the weather, the windshield can fog up temporarily after the engine is started.


When the cooling function is on, con- densation forms which then exits under the vehicle. Traces of condensed water on the ground are therefore nor- mal.<


83


Microfilter The integrated microfilter removes dust and pollen from the incoming or recircu- lated air. Your MINI Dealer will replace it during rou- tine maintenance. A substantial reduction in the air supply indicates that the filter must be replaced before scheduled mainte- nance.


AIR CONDITIONING SYSTEM


Draft-free ventilation Button 1: air outlets can be opened and closed by turning. The points indicate the position in each case. Nozzle 2: change the direction of the air flow by swiveling.


Defrosting and demisting windows 1. Set the rotary blower speed control for


the airflow rate to position 4


2. Turn the rotary temperature control


completely to the right, red


3. Turn the rotary switch for air distribu-


tion to position By activating the cooling function, the windows are demisted more quickly


4. Turn on windshield heating if necessary 5. To defrost the rear window: switch on


the rear window defroster.


84


AUTOMATIC CLIMATE CONTROL*


1 Air onto the windshield and onto the


5 Interior temperature sensor, please keep


side windows


2 Air for the upper body area 87
3 Air for the front and rear footwells 4 Rear window defroster and windshield


heating* 86


clear and unobstructed


6 Recirculated air mode 86
7 Cooling function 86
8 Automatic air distribution and


volume 86


10 Temperature 86
11 Display for air temperature and air


volume 86


12 Air volume/Blower, switching air con-


ditioner on/off 86


13 Individual air distribution 87


9 Defrosting and demisting the windshield


and side windows 87


85


AUTOMATIC CLIMATE CONTROL*


Automatic air distribution and volume The LED is lit when the AUTO pro- gram is on.


Automatic adjustment of the air distribu- tion and volume, and adaptation of the specified temperatures to external influ- ences, e.g. outside temperature and insola- tion. In the automatic program (AUTO), the air conditioning is activated automatically. To create a pleasant air climate, the air tem- perature coming from the vents in the upper body area is lower than the air tem- perature in the footwell.


Cooling function


The LED is lit when the cooling function is on.


The air is cooled and dehumidified and, depending on the temperature setting, rewarmed. The cooling function is automatically acti- vated in the AUTO program.


Depending on the weather, the windshield can fog up temporarily after the engine is started.


When the air conditioning is on, con- densation is formed which then exits


Air volume/Blower Switching automatic climate control off/on


under the vehicle. Traces of condensed water on the ground are therefore nor- mal.<


Press the left or right half of the button to vary the air volume.


Automatic adjustment of the air volume is deactivated. Switching air conditioner on/off. Press the left half of the button while the blower is at the lowest setting. The blower, heating and air conditioning are switched off. All displays go out. Switch the automatic climate control back on by pressing any button.


Recirculated air mode


The LED is lit when the recirculated air mode is on. Supply of outside air


into the vehicle is blocked. The air within the vehicle is recirculated. In the automatic program (AUTO) in hot weather conditions, the recirculated air mode is activated temporarily to enable faster cooling. The LED for the recirculated air button is not lit.


The recirculated air mode should not be used constantly over a longer


period of time; otherwise the air quality in the vehicle's interior will gradually deterio- rate. If the windows fog up in the recircu- lated air mode, turn the recirculated air mode off and, if necessary, increase the air supply.<


Rear window defroster and windshield heating*


The LED comes on when the rear window/windshield heating is on. The heater switches off automatically after a short time.


Temperature


Tap or turn the wheel in the appropriate direction to change the temperature step by step. The figures in the display provide


a general indication of interior tempera- ture. When you start the vehicle, the sys- tem ensures that the selected temperature is achieved as quickly as possible and then maintained.


Permanent heating with maximum power output at temperature selec- tion HI. Permanent cooling at LO. With the


86


AUTOMATIC CLIMATE CONTROL*


You can switch the unit from 6 to 7 by pressing the buttons for the


cooling function and air distribution toward the footwell at the same time.<


Microfilter/Activated-charcoal filter The microfilter removes dust and pollen from the incoming or recirculated air. The activated-charcoal filter provides addi- tional protection by filtering gaseous pol- lutants from the outside air. Your MINI Dealer replaces this combined filter as a standard part of your scheduled maintenance. A substantial reduction in the air supply indicates that the filter must be replaced before scheduled maintenance.


setting at HI, the recirculated air mode can- not be switched on.<


Defrosting and demisting windows


The LED is lit when the function is on.


Ice and condensation are rapidly removed from the rear window, windshield and side windows. Condensation is removed from the win- dows more quickly when the cooling func- tion is also activated. The rear window defroster/windshield heating are switched on automatically. They can be switched off again via the respective button.


Individual air distribution


Combine the air distribution your- self. Automatic adjustment of the air distribution is deactivated. It is not possible to distribute air simultaneously toward the win-


dows and toward the upper body area.


Draft-free ventilation Button 1: air outlets can be opened and closed by turning. The points indicate the position in each case. Nozzle 2: change the direction of the air flow by swiveling.


87


GLOVE COMPARTMENT


To open Pull the handle. The light goes on.


To close Fold the door up.


To prevent injury in the event of an accident, close the glove compart-


ment immediately after use.<


Ventilation To allow ventilation: Turn the rotary switch to the horizontal position. To shut off ventilation: Turn the rotary switch to the vertical posi- tion, see arrow.


Depending on the temperature set- ting of the air conditioning or the


automatic climate control, high tempera- tures may result in the glove compart- ment.<


Connection for external audio device* 1 Cigarette lighter socket for power supply 2 Socket for sound output You can connect an external audio device such as a CD or MP3 player and play audio recordings over the vehicle loudspeakers. To do so, open the glove compartment and connect the device's headphones or line- out terminal to socket 2. The volume and tone settings are adjusted over the car radio, refer to the Owner's Manual for Radio.


Shut off ventilation to the glove com- partment while an audio device is connected. Otherwise the device may be damaged due to thermal exposure.<


88


CENTER ARMREST*


DRINKS HOLDERS, ASHTRAY


Storage compartments Depending on the equipment version*, the center armrest between the front seats contains a compartment or a base plate for a mobile phone.


To open: Slide the cover backwards.


The cover slides along guide rails and can be opened fully by pushing it


back and lifting it slightly.<


Beverage holders Beverage holders are at the front or top of the center console. Another is located at the end of the center console in the rear.


Do not place any glass containers in the beverage holders, as this


increases the risk of injury in the event of an accident.<


Ashtray The ashtray is located in one of the bever- age holders in the center console.


To close: Push the cover forwards.


89


CIGARETTE LIGHTER, 12 V POWER SUPPLY


12 V socket in the luggage compartment* of the MINI Convertible The socket is located in the luggage com- partment on the left-hand side of the rear panel, arrow.


Lighter Press the cigarette lighter in. Remove as soon as the lighter jumps back out.


Hold or touch the hot cigarette lighter by the knob only. Holding or touching it


in other areas could result in burns.<


Cigarette lighter socket, 12 V power supply Suitable as a power socket for flashlights, car vacuum cleaners, etc., up to a rating of approx. 200 watts at 12 volts. Avoid damaging the socket with plugs of different shapes or sizes. If the vehicle is equipped with a MINI Mobility System, the 12 V socket is also for supplying the compressor.


90


INTEGRATED UNIVERSAL REMOTE CONTROL*


Checking compatibility


If this symbol is shown on the pack- aging or in the operating instruc- tions of the original control device,


it is safe to assume that the remote-con- trolled system is compatible with the inte- grated universal remote control.


If you have any additional question, please contact your MINI Dealer or


call: 1-800-355-3515. You can find more information on the Internet at: www.miniusa.com or www.homelink.com. HomeLink is a registered trademark of Johnson Controls, Inc.<


The concept The integrated universal remote control takes the place of up to three different con- trol devices for different radio-remote-con- trolled systems such as gate openers and household alarm systems. The integrated universal remote control detects and learns the signal transmitted by the original con- trol device. The signal of an original control device can be programmed onto one of the three memory buttons 1. The system in question can then be operated by means of the pro- grammed memory button 1. Signal trans- mission is indicated by LED 2. If you decide to sell your vehicle one day, in the interest of your own security, remem- ber to delete the programs before the vehi- cle leaves your possession, refer to page 92.


While programming is in progress and before operating any pro-


grammed system by remote control using the integrated universal remote control, make sure that the movement area of the system in question is clear of people, ani- mals and inanimate obstructions, in order to avoid possible injury or damage. Also comply with the safety precautions issued for the original control device.<


Programming 1 Memory buttons 2 LED


Fixed-code control device 1. Switch on the ignition 2. For first-time start-up: press both outer


buttons 1 for approx. 20 seconds until LED 2 flashes. This clears all three mem- ory buttons 1


3. Hold the original control device approx. 2 to 8 in/5 to 20 cm away from memory buttons 1.


The required distance between the control device and memory


buttons 1 may vary, depending on the system of the original control device in question.<


91


step 4, you have approx. 30 seconds to complete step 5


5. Press the programmed memory


button 1 of the integrated universal remote control three times.


The corresponding memory button 1 is now programmed with the signal of the original control device.


Consult your MINI Dealer if you have any questions.<


Deleting memory buttons Press both outer buttons 1 for approx. 20 seconds until LED 2 flashes: all memory buttons are cleared. It is not possible to delete individual mem- ory buttons 1.


INTEGRATED UNIVERSAL REMOTE CONTROL*


4. Simultaneously press the command but- ton of the original control device and the desired memory button 1 on the inte- grated universal remote control. The LED 2 begins to flash slowly. Release both buttons when LED 2 starts flashing rap- idly. If LED 2 does not start to flash rap- idly after approx. 15 seconds, change the distance between the two devices


5. Repeat steps 3 and 4 to program other


original control devices.


The corresponding memory button 1 is now programmed with the signal of the original control device. You can operate the system with the igni- tion key in position 2 or 3.


If the system cannot be operated after repeated attempts at program-


ming, check whether the original control device is equipped with an alternating- code system. You can either check the oper- ating instructions of the original control device for this information, or you can press and hold down the programmed memory button 1 of the integrated univer- sal remote control. If LED 2 of the inte- grated universal remote control flashes rapidly for a brief period and then remains on for approx. two seconds, the original


control device is equipped with an alternat- ing-code system. In this case, the memory buttons 1 are programmed as described for an alternating-code control device.<


Alternating-code control device You will need to refer to the operating instructions of the system in question in order to program the integrated universal remote control. Read through the operat- ing instructions for information on syn- chronization. Observe the following additional instruc- tions when you program an alternating- code control device:


You will find programming easier if you have the assistance of a second


person.<


1. Park your vehicle within range of the


radio-remote-controlled device


2. Program the integrated universal


remote control as described above in the section on fixed-code programming


3. Locate the button on the receiver of the target device, for example on the upper part of the drive


4. Press the button on the receiver of the


target device. Once you have completed


92


LUGGAGE COMPARTMENT IN THE MINI


Luggage compartment cover When the tailgate is opened, the luggage compartment cover is also raised.


Never place any heavy or hard objects on the luggage compartment cover; otherwise occupants could be injured dur- ing braking maneuvers.<


Removal To load bulky luggage, the compartment cover can be removed. 1. Remove the retaining straps on the tail-


gate


2. Pull the luggage compartment cover out


towards the rear.


Foldable rear backrest 1. Pull lever 2. Fold the rear backrest forwards.


When folding the backrest back into its original position, always ensure that the catch engages securely. A loose backrest might fail to prevent cargo from entering the passenger compartment dur- ing sudden braking or evasive maneuvers, posing a potential hazard to occupants.<


93


LUGGAGE COMPARTMENT IN THE MINI CONVERTIBLE


Loading aid When the convertible top is closed, you can load the vehicle more easily by releasing the convertible top and folding it up. 1. Release the convertible top using the


Expanding the luggage compartment volume You can enlarge the luggage compartment volume when the convertible top is closed. 1. Fold the convertible top upwards, refer


Through-loading system To be able to transport larger objects, the rear backrest can be folded down. 1. Unlock the catch for the rear backrest


with an ignition key or master key


handles, see arrows 1


to Loading aid


2. Lift the convertible top, see arrow 2
3. Fold back the handles and place them on


holders 3.


After folding the loading aid back down, lock the handles in place again


completely to operate the convertible top.<


2. Detach the luggage compartment cover


from the brackets, see arrow 1, and engage it on the upper support pins, see arrow 2


3. Place the luggage compartment cover


into a horizontal position.


To operate the convertible top, move the luggage compartment cover back


to its lower position.<


94


LUGGAGE COMPARTMENT IN THE MINI CONVERTIBLE


LOADING CARGO


Avoid overloading the vehicle so that the permissible carrying capacity of the tires is not exceeded. Overloading can lead to overheating and damage inside the tires. Depending on the circumstances, this can result in sudden air loss.<


2. Pull the lever to release the catch 3. Fold the backrest forward.


When folding the backrest back into its original position, always ensure that the catch engages securely. A loose backrest might fail to prevent cargo from entering the passenger compartment dur- ing sudden braking or evasive maneuvers, posing a potential hazard to occupants.<


95


4. The resulting figure equals the available


amount of cargo and luggage load capacity. For example, if the YYY amount equals 1,400 lbs. and there will be four 150-lbs. passengers in your vehicle, the amount of available cargo and luggage load capacity is 800 lbs.: 1,400 lbs. minus 600 lbs. = 800 lbs.


5. Determine the combined weight of lug-


gage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4


6. If your vehicle will be towing a trailer,


load from your trailer will be transferred to your vehicle. Consult the manual for transporting a trailer to determine how this may reduce the available cargo and luggage load capacity of your vehicle.


Cargo and luggage load capacity The permissible load is the sum of the occu- pants' weights and the weight of the cargo. The greater the weight of the occupants, the less cargo can be transported.


LOADING CARGO


Determining cargo limit 1. Locate the following statement on your


vehicle's placard:


The combined weight of occu- pants and cargo should never


exceed XXX kg or YYY lbs, as this could otherwise result in damage to the vehi- cle and unstable driving conditions.<


2. Determine the combined weight of the driver and passengers that will be riding in your vehicle


Loading...
x
