2012 Hyundai Tucson Owners Manual

windows of your vehicle. Especially, with high-pressure water.Water may leak through the windows and wet the interior.

(cid:129) To prevent damage to the plastic parts and lamps, do not clean with chemical solvents or strong detergents.

Maintenance

APPEARANCE CARE Exterior care Exterior general caution It is very important to follow the label directions when using any chemical cleaner or polish. Read all warning and caution statements that appear on the label.

Finish maintenance Washing To help protect your vehicle’s finish from rust and deterioration, wash it thoroughly and frequently at least once a month with lukewarm or cold water. If you use your vehicle for off-road driv- ing, you should wash it after each off- road trip. Pay special attention to the removal of any accumulation of salt, dirt, mud, and other foreign materials. Make sure the drain holes in the lower edges of the doors and rocker panels are kept clear and clean. Insects, tar, tree sap, bird droppings, industrial pollution and similar deposits can damage your vehicle’s finish if not removed immediately.

66

Waxing A good coat of wax is a barrier between your paint and contaminate. Keeping a good coat of wax on your vehicle will help protect it. Wax the vehicle when water will no longer bead on the paint. Always wash and dry the vehicle before waxing. Use a good quality liquid or paste wax, and follow the manufacturer’s instructions. Wax all metal trim to protect it and to maintain its luster. Removing oil, tar, and similar materials with a spot remover will usually strip the wax from the finish. Be sure to re-wax these areas even if the rest of the vehicle does not yet need waxing.

CAUTION

(cid:129) Wiping dust or dirt off the body with a dry cloth will scratch the finish.

(cid:129) Do not use steel wool, abrasive cleaners, or strong detergents containing highly alkaline or caustic agents on chrome-plated or anodized aluminum parts.This may result in damage to the pro- tective coating and cause discol- oration or paint deterioration.

OJB037800

CAUTION

(cid:129) Water washing in the engine com- partment including high pressure water washing may cause the fail- ure of electrical circuits located in the engine compartment.

(cid:129) Never allow water or other liquids to come in contact with electri- cal/electronic components inside the vehicle as this may damage them.

Maintenance

Finish damage repair Deep scratches or stone chips in the painted surface must be repaired promptly. Exposed metal will quickly rust and may develop into a major repair expense.

✽✽ NOTICE If your vehicle is damaged and requires any metal repair or replacement, be sure the body shop applies anti-corrosion materials to the parts repaired or replaced.

7 67

Maintenance

Bright-metal maintenance (cid:129) To remove road tar and insects, use a tar remover, not a scraper or other sharp object.

(cid:129) To protect the surfaces of bright-metal parts from corrosion, apply a coating of wax or chrome preservative and rub to a high luster.

(cid:129) During winter weather or in coastal areas, cover the bright metal parts with a heavier coating of wax or preserva- tive. If necessary, coat the parts with non-corrosive petroleum jelly or other protective compound.

68

Aluminum wheel maintenance The aluminum wheels are coated with a clear protective finish. (cid:129) Do not use any abrasive cleaner, pol- ishing compound, solvent, or wire brushes on aluminum wheels. They may scratch or damage the finish.

(cid:129) Use only a mild soap or neutral deter- gent, and rinse thoroughly with water. Also, be sure to clean the wheels after driving on salted roads. This helps pre- vent corrosion.

(cid:129) Avoid washing the wheels with high-

speed car wash brushes.

(cid:129) Do not use any cleaners containing acid or acid detergents. It may damage and corrode the aluminum wheels coated with a clear protective finish.

Underbody maintenance Corrosive materials used for ice and snow removal and dust control may col- lect on the underbody. If these materials are not removed, accelerated rusting can occur on underbody parts such as the fuel lines, frame, floor pan and exhaust system, even though they have been treated with rust protection. Thoroughly flush the vehicle underbody and wheel openings with lukewarm or cold water once a month, after off-road driving and at the end of each winter. Pay special attention to these areas because it is difficult to see all the mud and dirt. It will do more harm than good to wet down the road grime without removing it. The lower edges of doors, rocker panels, and frame members have drain holes that should not be allowed to clog with dirt; trapped water in these areas can cause rusting.

WARNING

After washing the vehicle, test the brakes while driving slowly to see if they have been affected by water. If braking performance is impaired, dry the brakes by applying them lightly while maintaining a slow for- ward speed.

High-corrosion areas If you live in an area where your vehicle is regularly exposed to corrosive materi- als, corrosion protection is particularly important. Some of the common causes of accelerated corrosion are road salts, dust control chemicals, ocean air and industrial pollution.

Corrosion protection Protecting your vehicle from corrosion By using the most advanced design and construction practices to combat corro- sion, we produces cars of the highest quality. However, this is only part of the job. To achieve the long-term corrosion resistance your vehicle can deliver, the owner's cooperation and assistance is also required.

Common causes of corrosion The most common causes of corrosion on your car are: (cid:129) Road salt, dirt and moisture that is allowed to accumulate underneath the vehicle.

(cid:129) Removal of paint or protective coatings by stones, gravel, abrasion or minor scrapes and dents which leave unpro- tected metal exposed to corrosion.

Maintenance

Moisture breeds corrosion Moisture creates the conditions in which corrosion is most likely to occur. For example, corrosion is accelerated by high humidity, particularly when tempera- tures are just above freezing. In such conditions, the corrosive material is kept in contact with the car surfaces by mois- ture that is slow to evaporate. Mud is particularly corrosive because it is slow to dry and holds moisture in contact with the vehicle. Although the mud appears to be dry, it can still retain the moisture and promote corrosion. High temperatures can also accelerate corrosion of parts that are not properly ventilated so the moisture can be dis- persed. For all these reasons, it is par- ticularly important to keep your vehicle clean and free of mud or accumulations of other materials. This applies not only to the visible surfaces but particularly to the underside of the vehicle.

7 69

Maintenance

To help prevent corrosion You can help prevent corrosion from get- ting started by observing the following:

Keep your car clean The best way to prevent corrosion is to keep your vehicle clean and free of cor- rosive materials. Attention to the under- side of the vehicle is particularly impor- tant.

(cid:129) If you live in a high-corrosion area — where road salts are used, near the ocean, areas with industrial pollution, acid rain, etc.—, you should take extra care to prevent corrosion. In winter, hose off the underside of your vehicle at least once a month and be sure to clean the underside thoroughly when winter is over.

70

(cid:129) When cleaning underneath the vehicle, give particular attention to the compo- nents under the fenders and other areas that are hidden from view. Do a thorough job; just dampening the accu- mulated mud rather than washing it away will accelerate corrosion rather than prevent it. Water under high pres- sure and steam are particularly effec- tive in removing accumulated mud and corrosive materials.

(cid:129) When cleaning lower door panels, rocker panels and frame members, be sure that drain holes are kept open so that moisture can escape and not be trapped inside to accelerate corrosion.

Keep your garage dry Don't park your car in a damp, poorly ventilated garage. This creates a favor- able environment for corrosion. This is particularly true if you wash your vehicle in the garage or drive it into the garage when it is still wet or covered with snow, ice or mud. Even a heated garage can contribute to corrosion unless it is well ventilated so moisture is dispersed.

Keep paint and trim in good condition Scratches or chips in the finish should be covered with "touch-up" paint as soon as possible to reduce the possibility of cor- rosion. If bare metal is showing through, the attention of a qualified body and paint shop is recommended.

Bird droppings : Bird droppings are high- ly corrosive and may damage painted surfaces in just a few hours. Always remove bird droppings as soon as possi- ble.

Don't neglect the interior Moisture can collect under the floor mats and carpeting to cause corrosion. Check under the mats periodically to be sure the carpeting is dry. Use particular care if you carry fertilizers, cleaning materials or chemicals in the vehicle. These should be carried only in proper containers and any spills or leaks should be cleaned up, flushed with clean water and thoroughly dried.

Interior care Interior general precautions Prevent caustic solutions such as per- fume and cosmetic oil from contacting the dashboard because they may cause damage or discoloration. If they do con- tact the dashboard, wipe them off imme- diately. See the instructions for the prop- er way to clean vinyl.

CAUTION

Never allow water or other liquids to come in contact with electrical/elec- tronic components inside the vehi- cle as this may damage them.

CAUTION

When cleaning leather products (steering wheel, seats etc.), use neutral detergents or low alcohol content solutions. If you use high alcohol content solutions or acid/alkaline detergents, the color of the leather may fade or the sur- face may get stripped off.

Cleaning the upholstery and interior trim Vinyl Remove dust and loose dirt from vinyl with a whisk broom or vacuum cleaner. Clean vinyl surfaces with a vinyl cleaner.

Fabric Remove dust and loose dirt from fabric with a whisk broom or vacuum cleaner. Clean with a mild soap solution recom- mended for upholstery or carpets. Remove fresh spots immediately with a fabric spot cleaner. If fresh spots do not receive immediate attention, the fabric can be stained and its color can be affected. Also, its fire-resistant properties can be reduced if the material is not properly maintained.

CAUTION

Using anything but recommended cleaners and procedures may affect the fabric’s appearance and fire- resistant properties.

Maintenance

Cleaning the lap/shoulder belt web- bing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet. Follow the instruc- tions provided with the soap. Do not bleach or re-dye the webbing because this may weaken it.

Cleaning the interior window glass If the interior glass surfaces of the vehi- cle become fogged (that is, covered with an oily, greasy or waxy film), they should be cleaned with glass cleaner. Follow the directions on the glass cleaner container.

CAUTION

Do not scrape or scratch the inside of the rear window.This may result in damage to the rear window defroster grid.

7 71

Maintenance

EMISSION CONTROL SYSTEM The emission control system of your vehicle is covered by a written limited warranty. Please see the warranty infor- mation contained the Owner’s Handbook & Warranty Information book- let in your vehicle. Your vehicle is equipped with an emis- sion control system to meet all applicable emission regulations. There are three emission control sys- tems, as follows.

in

(1) Crankcase emission control system (2) Evaporative emission control system (3) Exhaust emission control system

In order to assure the proper function of the emission control systems, it is rec- ommended that you have your vehicle inspected and maintained by an author- ized HYUNDAI dealer in accordance with the maintenance schedule in this manu- al.

72

for

the

Caution Inspection and Maintenance Test (With Electronic Stability Control (ESC) system) (cid:129) To prevent the vehicle from misfir- ing during dynamometer testing, turn the Electronic Stability Control (ESC) system off by pressing the ESC switch.

(cid:129) After dynamometer testing is com- pleted, turn the ESC system back on by pressing the ESC switch again.

1. Crankcase emission control

system

The positive crankcase ventilation sys- tem is employed to prevent air pollution caused by blow-by gases being emitted from the crankcase. This system supplies fresh filtered air to the crankcase through the air intake hose. Inside the crankcase, the fresh air mixes with blow-by gases, which then pass through the PCV valve into the induction system.

2. Evaporative emission control

(including ORVR: Onboard Refueling Vapor Recovery) system

The Evaporative Emission Control System is designed to prevent fuel vapors from escaping into the atmos- phere. (The ORVR system is designed to allow the vapors from the fuel tank to be loaded into a canister while refueling at the gas station, preventing the escape of fuel vapors into the atmosphere.)

Canister Fuel vapors generated inside the fuel tank are absorbed and stored in the onboard canister. When the engine is running, the fuel vapors absorbed in the canister are drawn into the surge tank through the purge control solenoid valve.

Purge Control Solenoid Valve (PCSV) The purge control solenoid valve is con- trolled by the Engine Control Module (ECM); when the engine coolant temper- ature is low during idling, the PCSV clos- es so that evaporated fuel is not taken into the engine. After the engine warms- up during ordinary driving, the PCSV opens to introduce evaporated fuel to the engine.

3. Exhaust emission control

system

The Exhaust Emission Control System is a highly effective system which controls exhaust emissions while maintaining good vehicle performance.

Vehicle modifications This vehicle should not be modified. Modification of your vehicle could affect its performance, safety or durability and may even violate governmental safety and emissions regulations. In addition, damage or performance problems resulting from any modification may not be covered under warranty. (cid:129) If you use unauthorized electronic devices, it may cause the vehicle to operate abnormally, wire damage, bat- tery discharge and fire. For your safety, be careful not to damage.

Engine exhaust gas precautions (carbon monoxide) (cid:129) Carbon monoxide can be present with other exhaust fumes. Therefore, if you smell exhaust fumes of any kind inside your vehicle, have it inspected and repaired immediately. If you ever sus- pect exhaust fumes are coming into your vehicle, drive it only with all the windows fully open. Have your vehicle checked and repaired immediately.

Maintenance

WARNING - Exhaust

Engine exhaust gases contain car- bon monoxide (CO). Though color- less and odorless, it is dangerous and could be lethal if inhaled. Follow the instructions on this page to avoid CO poisoning.

CALIFORNIA PROPOSI- TION 65 WARNING

Engine exhaust and a wide variety of automobile components and parts, including components found in the interior furnishings in a vehi- cle, contain or emit chemicals known to the State of California to cause cancer and birth defects and reproductive harm. In addition, cer- tain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

7 73

Maintenance

(cid:129) Do not operate the engine in confined or closed areas (such as garages) any more than what is necessary to move the vehicle in or out of the area.

(cid:129) When the vehicle is stopped in an open area for more than a short time with the engine running, adjust the ventilation system (as needed) to draw outside air into the vehicle.

(cid:129) Never sit in a parked or stopped vehi- cle for any extended time with the engine running.

(cid:129) When the engine stalls or fails to start, excessive attempts to restart the engine may cause damage to the emission control system.

74

Operating precautions for catalytic converters (if equipped)

WARNING - Fire

(cid:129) A hot exhaust system can ignite flammable items under your vehi- cle. Do not park, idle, or drive the vehicle over or near flammable objects, such as grass, vegeta- tion, paper, leaves, etc.

(cid:129) The exhaust system and catalytic system are very hot while the engine is running or immediately after the engine is turned off. Keep away from the exhaust system and catalytic, you may get burned. Also, do not remove the heat sink around the exhaust system, do not seal the bottom of the vehicle or do not coat the vehicle for cor- rosion control. It may present a fire risk under certain conditions.

Your vehicle is equipped with a catalytic converter emission control device. Therefore, the following precautions must be observed: (cid:129) Use only UNLEADED FUEL for gaso-

line engines.

(cid:129) Do not operate the vehicle when there are signs of engine malfunction, such as misfire or a noticeable loss of per- formance.

(cid:129) Do not misuse or abuse the engine. Examples of misuse are coasting with the ignition off and descending steep grades in gear with the ignition off.

(cid:129) Do not operate the engine at high idle speed for extended periods (5 minutes or more).

(cid:129) Do not modify or tamper with any part of the engine or emission control sys- tem. All inspections and adjustments must be made by an authorized HYUNDAI dealer.

(cid:129) Avoid driving with a extremely low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.

Failure to observe these precautions could result in damage to the catalytic converter vehicle. Additionally, such actions could void your warranties.

your

and

to

CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special handling may apply, See www.dtsc.ca.gov/haz- ardouswaste/perchlorate.

Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22
California Code of Regulations Section 67384.10 (a).

Maintenance

7 75

Dimensions / 8-2
Bulb wattage / 8-2
Tires and wheels / 8-3
Recommended lubricants and capacities / 8-4
Vehicle identification number (VIN) / 8-6
Vehicle certification label / 8-6
Tire specification and pressure label / 8-7
Engine number / 8-7
Consumer information / 8-8
Reporting safety defects / 8-9
Binding arbitration / 8-9

Specifications, Consumer information, Reporting safety defects

Specifications, Consumer information, Reporting safety defects

DIMENSIONS

Item

Overall length Overall width Overall height Front tread Rear tread Wheelbase

*1 : with roof rack

in (mm)

173.2 (4400) 71.7 (1820)

65.2 (1655) / 66.3 (1685)*1

62.4 (1585) 62.44 (1586) 103.9 (2640)

BULB WATTAGE

Light Bulb

Headlights (High/Low) Front turn signal lights Position lights Side repeater lights Front side marker lights Front fog lights* Stop and tail lights Rear turn signal lights Back-up lights Rear side marker lights* High mounted stop light License plate lights Map lamps Room lamps Luggage lamp* Glove box lamp Vanity mirror lamps

* : if equipped

Wattage

60/55
28/8

LED

27
28/8
27
16

LED

10
10

28

Specifications, Consumer information, Reporting safety defects

TIRES AND WHEELS

Item

Tire size

Wheel size

Inflation pressure

kPa (psi)

Wheel lug nut torque

lb•ft (kgf(cid:129)m, N(cid:129)m)

Full size tire

225/60R17
225/55R18

6.5J×17
6.5J×18

Compact spare tire

T155/90D16

4.0T×16

Front 230
(33)

420
(60)

Rear 230
(33)

420
(60)

65~79

(9~11 , 88~107)

✽✽ NOTICE It is permissible to add 3psi to the standard tire pressure specification if colder temperatures are expected soon. Tires typically loose 1psi for every 12°F temperature drop. If extreme temperature variations are expected, re-check your tire pressure as nec- essary to keep them properly inflated.

8 3

Specifications, Consumer information, Reporting safety defects

RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle.

Lubricant

Volume

Classification

Engine oil *1 *2 (drain and refill) Recommends

2.0 Engine

4.33 US qt. (4.1 l)

Manual transaxle fluid

2.4 Engine

4.86 US qt. (4.6 l)

2.0 Engine

2.4 Engine

2.22~2.32 US qt.

(2.1~2.2 l)

1.90~2.01 US qt.

(1.8~1.9 l)

Automatic transaxle fluid

7.50 US qt. (7.1 l)

Coolant

7.19 US qt. (6.8 l)

API Service SM*3,

ILSAC GF-4 or above

API GL-4, SAE 75W/85

MICHANG ATF SP-IV, SK ATF SP-IV

NOCA ATF SP-IV, HYUNDAI genuine ATF SP-IV or other

brands meeting the above specification approved by

Hyundai Motor Co.,

Mixture of antifreeze and water (Ethylene glycol base

coolant for aluminum radiator) FMVSS116 DOT-3 or DOT-4

0.7~0.8 US qt. (0.7~0.8 l)

Brake/clutch fluid Rear axle oil (AWD) Transfer case oil (AWD) Fuel *1 Refer to the recommended SAE viscosity numbers on the next page. *2 Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.

0.69 US qt. (0.65 l) 0.63 US qt. (0.6 l) 15.3 US gal. (58 l)

Hypoid gear oil API GL-5, SAE 75W/90

(SHELL SPIRAX X or equivalent)

*3 If the API service SM engine oil is not available in your country, you are able to use API service SL.

48

Recommended SAE viscosity number

CAUTION

Always be sure to clean the area around any filler plug,drain plug,or dipstick before checking or drain- ing any lubricant.This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.

Specifications, Consumer information, Reporting safety defects

Engine oil viscosity (thickness) has an effect on fuel economy and cold weather operating (engine start and engine oil flowability). Lower viscosity engine oils can provide better fuel economy and cold weather performance, however, higher viscosity engine oils are required for sat- isfactory lubrication in hot weather. Using oils of any viscosity other than those rec- ommended could result in engine dam- age.

When choosing an oil, consider the range of temperature your vehicle will be oper- ated in before the next oil change. Proceed to select the recommended oil viscosity from the chart.

Temperature

Gasoline Engine Oil *1

Temperature Range for SAE Viscosity Numbers °C (°F)

-30 -20 -10 0 10 20 30 40 50
-10 0 20 40 60 80 100 120

10W-30

5W-20, 5W-30

*1 For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE 5W-20 (API SM / ILSAC GF-4). However, if the engine oil is not available in your country, select the proper engine oil using the engine oil viscosity chart.

8 5

Specifications, Consumer information, Reporting safety defects

VEHICLE IDENTIFICATION NUMBER (VIN) Frame number

VIN label

VEHICLE CERTIFICATION LABEL

OLM089001

The vehicle identification number (VIN) is the number used in registering your car and in all legal matters pertaining to its ownership, etc. The number is punched on the floor under the passenger seat. To check the number, open the cover.

OLM089006N The VIN is also on a plate attached to the top of the dashboard. The number on the plate can easily be seen through the windshield from outside.

OLM089002N The vehicle certification label attached on the driver’s side center pillar gives the vehicle identification number (VIN).

68

TIRE SPECIFICATION AND PRESSURE LABEL

ENGINE NUMBER

Specifications, Consumer information, Reporting safety defects

OLM089003
The engine number is stamped on the engine block as shown in the drawing.

OLM089008N

The tires supplied on your new vehicle are chosen to provide the best perform- ance for normal driving. The tire label located on the driver's side center pillar gives the tire pressures rec- ommended for your car.

8 7

Specifications, Consumer information, Reporting safety defects

CONSUMER INFORMATION This consumer information has been pre- pared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation. Your Hyundai dealer will help answer any questions you may have as you read this information.

Hyundai motor vehicles are designed and manufactured to meet or exceed all applicable safety standards.

For your safety, however, we strongly urge you to read and follow all directions in this Owner's Manual, particularly the information headings "NOTICE", "CAUTION" and "WARN- ING".

under

the

If, after reading this manual, you have any questions regarding the operation of your vehicle, please contact your nearest Hyundai Motor America Regional Office as listed in the following:

88

Eastern Region: Connecticut, Delaware, Maine, Massachusetts, New Hampshire, New Jersey, New York, Pennsylvania, Rhode Island, Vermont.

Central Region: Illinois, Indiana, lowa, Kentucky, Minnesota, Nebraska, North Dakota, South Dakota, Ohio, Wisconsin, Kansas, Missouri.

Michigan,

Eastern Region 1100 Cranbury South River Road Jamesburg, NJ 08831
(800) 633-5151

Central Region 1705 Sequoia Drive Aurora, Illinois 60506
(800) 633-5151

Southern Region: Florida, Georgia, Maryland, North Carolina, South Carolina, Virginia, West Virginia.

Western Region: Alaska, Hawaii, Arizona, California, Colorado, ldaho, Montana, Nevada, Oregon, Utah, Washington, Wyoming.

Western Region 10550 Talbert Avenue P.O.Box 20850
Fountain Valley, California 92728-0850
(800) 633-5151

Southern Region 270 Riverside Parkway, Suite A Austell, GA 30168
(800) 633-5151

South Central Region: Alabama, Arkansas, Louisiana, Mississippi, New Mexico, Oklahoma, Tennessee, Texas.

South Central Region 1421 South Beltline Road, Suite 400
Coppell, TX 75019
(800) 633-5151

Specifications, Consumer information, Reporting safety defects

REPORTING SAFETY DEFECTS BINDING ARBITRATION (U.S.A ONLY) If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying HYUNDAI MOTOR AMERICA. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or HYUNDAI MOTOR AMERICA. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888- 327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA 1200 New Jersey Ave SE West Building Washington, D.C. 20590. You can also obtain other informa- tion about motor vehicle safety from http://www.safercar.gov.

Any claim or dispute you may have relat- ed to your vehicle's warranty or the duties contemplated under the warranty, includ- ing claims related to the refund or partial refund of your vehicle's purchase price (excluding personal injury or product lia- bility claims), shall be resolved by binding arbitration. Binding arbitration shall be administered by and the American Arbitration Association (AAA). You will not be responsible for paying fil- ing and hearing fees above $275.00. All other arbitration costs shall be borne by Hyundai Motor America. You are not responsible to pay any of the costs Hyundai incurs. This Binding Arbitration Agreement shall not deprive you of any remedies avail- able to you under applicable law. The parties are waiving their right to seek remedies in court, including the right to a jury trial.

through

revoke

This Binding Arbitration Agreement shall be governed by and interpreted under the Federal Arbitration Act, 9 U.S.C. sec- tions 1-16. Judgment upon any award may be entered in any court having juris- diction. this Arbitration You may Agreement by (1) written notice or (2) electronic notice. Written notice must be delivered (via certified mail) to Hyundai Motor America, Attn: Consumer Affairs, 10550 Talbert Avenue, P.O. Box 20849, Fountain Valley, CA 92728-0849. Electronic notice must be submitted at the following website address: http://war- ranty-arbitration.hyundaiUSA.com. Notice must be received within 90 days after you purchase your vehicle.

8 9

OOWWNNEERR''SS MMAANNUUAALL

Operation Maintenance Specifications

All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out.

This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment. As a result, you may find material in this manual that does not apply to your specific vehicle.

Introduction

How to use this manual / 1-2
Fuel requirements / 1-3
Vehicle handling instructions / 1-5
Vehicle break-in process / 1-5
Vehicle data collection and event data recorders / 1-6
Indicator symbols on the instrument cluster / 1-7

Introduction

HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehi- cle. Your Owner’s Manual can assist you in many ways. We strongly recommend that you read the entire manual. In order to minimize the chance of death or injury, you must read the WARNING and CAU- TION sections in the manual. Illustrations complement the words in this manual to best explain how to enjoy your vehicle. By reading your manual, you will learn about features, important safety information, and driving tips under vari- ous road conditions.

The general layout of the manual is pro- vided in the Table of Contents. A good place to start is the index; it has an alpha- betical listing of all information in your manual. Sections: This manual has eight sections plus an index. Each section begins with a brief list of contents so you can tell at a glance if that section has the information you want.

You will find various WARNINGs, CAUTIONs, and NOTICEs in this manu- al. These WARNINGs were prepared to enhance your personal safety.You should carefully read and follow ALL procedures and recommendations provided in these WARNINGS, CAUTIONS and NOTICES.

WARNING

A WARNING indicates a situation in which harm, serious bodily injury or death could result if the warning is ignored.

CAUTION

A CAUTION indicates a situation in which damage to your vehicle could result if the caution is ignored.

✽✽ NOTICE A NOTICE indicates interesting or help- ful information is being provided.

21

FUEL REQUIREMENTS Your new vehicle is designed to use only unleaded fuel having a pump octane number ((R+M)/2) of 87 or higher.

Your new vehicle is designed to obtain maximum performance with UNLEADED FUEL, as well as minimize exhaust emis- sions and spark plug fouling.

CAUTION

Never add any fuel system cleaning agents to the fuel tank other than what has been specified. (Consult an authorized HYUNDAI dealer for details.)

WARNING

• Do not "top off" after the nozzle automatically shuts off when refueling.

(cid:129) Tighten the cap until it clicks one time, otherwise the Check Engine

light will illuminate.

(cid:129) Always check that the fuel cap is installed securely to prevent fuel spillage in the event of an acci- dent.

Introduction

Gasoline containing alcohol and methanol Gasohol, a mixture of gasoline and ethanol (also known as grain alcohol), and gasoline or gasohol containing methanol (also known as wood alcohol) are being marketed along with or instead of leaded or unleaded gasoline. Do not use gasohol containing more than 10% ethanol, and do not use gasoline or gasohol containing any methanol. Either of these fuels may cause drivability prob- lems and damage to the fuel system. Discontinue using gasohol of any kind if drivability problems occur. Vehicle damage or drivability problems may not be covered by the manufactur- er’s warranty if they result from the use of: 1. Gasohol containing more than 10%

ethanol.

2. Gasoline or gasohol containing

methanol.

3. Leaded fuel or leaded gasohol.

1 3

Do not use methanol Fuels containing methanol (wood alco- hol) should not be used in your vehicle. This type of fuel can reduce vehicle per- formance and damage components of the fuel system.

CAUTION

Your New Vehicle Limited Warranty may not cover damage to the fuel system and any performance prob- lems that are caused by the use of fuels containing methanol.

Gasolines for cleaner air To help contribute to cleaner air, HYUNDAI recommends you use gaso- lines treated with detergent additives, which help prevent deposit formation in the engine. These gasolines will help the engine run cleaner and enhance per- formance of the Emission Control System.

Operation in foreign countries If you are going to drive your vehicle in another country, be sure to: (cid:129) Observe all regulations regarding reg-

istration and insurance.

(cid:129) Determine that acceptable fuel is avail-

able.

Introduction

"E85" fuel is an alternative fuel com- prised of 85 percent ethanol and 15 per- cent gasoline, and is manufactured exclusively for use in Flexible Fuel Vehicles. “E85” is not compatible with your vehicle. Use of “E85” may result in poor engine performance and damage to your vehicle's engine and fuel system. HYUNDAI recommends that customers do not use fuel with an ethanol content exceeding 10 percent.

CAUTION

Your New Vehicle Limited Warranty does not cover damage to the fuel system or any performance prob- lems caused by the use of “E85”fuel.

CAUTION

Never use gasohol which contains methanol. Discontinue use of any gasohol product which impairs dri- vability.

41

VEHICLE HANDLING INSTRUCTIONS As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control, an accident or vehicle rollover. Specific design characteristics (higher ground clearance, track, etc.) give this vehicle a higher center of gravity than other types of vehicles. It is not designed for cornering at the same speeds as a conventional 2-wheel drive sedans or sports coupe. Avoid sharp turns or abrupt maneuvers. Failure to operate this vehi- cle correctly may result in loss of control, an accident or vehicle rollover. Be sure to read the “Reducing the risk of a rollover” driving guidelines, in section 5 of this manual.

VEHICLE BREAK-IN PROCESS No special break-in period is needed. By following a few simple precautions for the first 600 miles (1,000 km) you may add to the performance, economy and life of your vehicle. (cid:129) Do not race the engine. (cid:129) While driving, keep your engine speed (rpm, or revolutions per minute) between 2,000 rpm and 4,000 rpm.

(cid:129) Do not maintain a single speed for long periods of time, either fast or slow. Varying engine speed is needed to properly break-in the engine.

(cid:129) Avoid hard stops, except in emergen- cies, to allow the brakes to seat prop- erly.

(cid:129) Don't let the engine idle longer than 3

minutes at one time.

(cid:129) Don't tow a trailer during the first 1,200

miles (2,000 km) of operation.

Introduction

1 5

Introduction

VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hit- ting a road obstacle, data that will assist in understanding how a vehi- cle's systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30
seconds or less. The EDR in this vehi- cle is designed to record such data as: * How various systems in your vehicle

These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a nontrivial crash situa- tion occurs; no data are recorded by the EDR under normal driving condi- tions and no personal data (e.g., name, gender, age, and crash loca- tion) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

were operating:

To read data recorded by an EDR, spe- cial equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufactur- er, other parties, such as law enforce- ment, that have the special equip- ment, can read the information if they have access to the vehicle or the EDR.

* Whether or not the driver and pas- senger safety belts were buckled/ fastened;

* How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

* How fast the vehicle was traveling.

61

INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER

ECO indicator*

Engine oil pressure warning light

ESC OFF indicator*

Air bag warning light

Shift pattern indicator*

DBC indicator*

Introduction

ABS warning light

Manual transaxle shift indicator*

AWD system warning light*

Parking brake & Brake fluid warning light

Charging system warning light

AWD LOCK indicator*

Seat belt warning light

Door ajar warning light

Turn signal indicator

Tailgate open warning light

Light on indicator

Low fuel level warning light

Low tire pressure telltale /TPMS malfunction indicator

Engine coolant temperature warning light

Electric power steering (EPS) system warning light

High beam indicator

Malfunction indicator

Cruise indicator*

Front fog light indicator*

ESC indicator*

Cruise SET indicator*

* : if equipped

❈ For more detailed explanations, refer to “Instrument cluster” in section 4.

1 7

CAUTION: MODIFICATIONS TO YOUR HYUNDAI

Your Hyundai should not be modified in any way. Such modifications may adversely affect the per- formance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations estab- lished by the U.S. Department of Transportation and other federal or state agencies.

TWO-WAY RADIO OR CELLULAR TELEPHONE INSTALLATION

Your vehicle is equipped with electronic fuel injection and other electronic components. It is possible for an improperly installed/adjusted two-way radio or cellular telephone to adversely affect electronic systems. For this reason, we recommend that you carefully follow the radio manufacturer's instruc- tions or consult your Hyundai dealer for precautionary measures or special instructions if you choose to install one of these devices.

F2

SAFETY AND VEHICLE DAMAGE WARNING

This manual includes information titled as WARNING, CAUTION and NOTICE. These titles indicate the following:

WARNING

This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning.

CAUTION

This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded.Follow the advice provided with the caution.

✽✽ NOTICE This indicates that interesting or helpful information is being provided.

F3

FOREWORD

Thank you for choosing Hyundai. We are pleased to welcome you to the growing number of discriminating people who drive Hyundais. The advanced engineering and high-quality construction of each Hyundai we build is something of which we're very proud.

Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it care- fully because the information it contains can contribute greatly to the satisfaction you receive from your new car.

The manufacturer also recommends that all service and maintenance on your car be performed by an authorized Hyundai dealer. Hyundai dealers are prepared to provide high-quality service, maintenance and any other assistance that may be required.

HYUNDAI MOTOR AMERICA

Note : Because future owners will also need the information included in this manual, if you sell this Hyundai, please leave the man-

ual in the vehicle for their use. Thank you.

CAUTION

Severe engine and transaxle damage may result from the use of poor quality fuels and lubricants that do not meet Hyundai specifications.You must always use high quality fuels and lubricants that meet the specifications listed on Page 8-4 in the Vehicle Specifications section of the Owner's Manual.

Copyright 2011 Hyundai Motor America. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Hyundai Motor America.

F4

Guide to Hyundai Genuine Parts 1. What are Hyundai Genuine Parts?

Hyundai Genuine Parts are the same parts used by Hyundai Motor Company to manufacture vehicles. They are designed and tested for the optimum safety, performance, and reli- ability to our customers.

2. Why should you use genuine parts? Hyundai Genuine Parts are engi- neered and built to meet rigid manu- facturing requirements. Using imita- tion, counterfeit or used salvage parts is not covered under the Hyundai New Vehicle Limited Warranty or any other Hyundai warranty.

In addition, any damage to or failure of Hyundai Genuine Parts caused by the installation or failure of an imitation, counterfeit or used salvage part is not covered by any Hyundai Warranty.

3. How can you tell if you are purchas-

ing Hyundai Genuine Parts? Look for the Hyundai Genuine Parts Logo on the package (see below). Hyundai Genuine Parts exported to are packaged with labels written only in English. Hyundai Genuine Parts are only sold through authorized Hyundai Dealerships.

A100A03L

A100A01L

A100A02L

A100A04L

F5

table of contents

Introduction

Your vehicle at a glance

Safety features of your vehicle

Features of your vehicle

Driving your vehicle

What to do in an emergency

Maintenance Specifications, Consumer information, Reporting safety defects Index

Your vehicle at a glance

Interior overview / 2-2
Instrument panel overview / 2-3
Engine compartment / 2-4

Your vehicle at a glance

INTERIOR OVERVIEW

22

1. Door lock/unlock button ....................4-10
2. Power window switches ....................4-15
3. Central door lock switch....................4-10
4. Power window lock button ................4-18
5. Outside rearview mirror control

switch ................................................4-32
6. Fuel filler door release lever .............4-21
7. Instrument panel illumination control

switch ................................................4-34
8. AWD LOCK button* ..........................5-18
9. DBC button* .....................................5-33
10. ESC OFF button*............................5-30
11. Fuse box .........................................7-51
12. Steering wheel ................................4-28
13. Steering wheel tilt/telescope*

control .............................................4-28
14. Seat...................................................3-2
15. Hood release lever..........................4-19
16. Parking brake pedal (A/T only)*......5-25
17. Brake pedal.....................................5-24
18. Accelerator pedal..............................5-6
* : if equipped

OLM019001N

INSTRUMENT PANEL OVERVIEW

Your vehicle at a glance

1. Light control / Turn signals..................4-50
2. Steering wheel audio controls*...........4-89
3. Bluetooth phone controls* ................4-110
4. Instrument cluster ...............................4-33
5. Horn....................................................4-29
6. Driver’s front air bag ...........................3-49
7. Wiper/Washer (Front and Rear)* ........4-54
8. Auto cruise controls switches*............5-36
9. Ignition switch ......................................5-5
10. Digital clock and Audio*....................4-85
11. Hazard warning flasher switch ...4-49/6-2
12. PASSENGER AIR BAG OFF indicator

..........................................................3-44
13. Climate control system*............4-61/4-70
14. Seat warmer*....................................3-10
15. Cigar lighter*.....................................4-82
16. Aux, USB and iPod port* ..................4-90
17. Power outlet ......................................4-84
18. Ashtray* ............................................4-82
19. Cup holder ........................................4-83
20. Center console box...........................4-80
21. Shift lever..........................................5-10
22. Passenger’s front air bag..................3-49
23. Air vent..............................................4-64
24. Glove box..........................................4-80
* : if equipped

OLM019002N

2 3

Your vehicle at a glance

ENGINE COMPARTMENT

1. Engine coolant reservoir...................7-22
2. Engine oil filler cap ...........................7-21
3. Brake/Clutch* fluid reservoir .............7-25
4. Air cleaner.........................................7-28
5. Fuse box ...........................................7-52
6. Negative battery terminal..................7-34
7. Positive battery terminal ...................7-34
8. Radiator cap .....................................7-24
9. Engine oil dipstick .............................7-21
10. Windshield washer fluid reservoir ...7-26
* : if equipped

* The actual engine compartment in the vehicle may differ from the illustration.

OLM079001

42

Seats / 3-2
Seat belts / 3-16
Child restraint system / 3-30
Air bag - advanced supplemental restraint system / 3-38

Safety features of your vehicle

Safety features of your vehicle

SEATS

Power seat

Manual seat

23

Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (Driver’s seat)* (4) Lumbar support (Driver’s seat)* (5) Seat warmer* (6) Headrest

Rear seat (7) Seatback folding (8) Headrest (9) Armrest

*: if equipped

OLM031001L

WARNING - Loose objects Loose objects in the driver’s foot area could interfere with the opera- tion of the foot pedals, possibly causing an accident. Do not place anything under the front seats.

WARNING - Uprighting

seat

When you return the seatback to its upright position, hold the seatback and return it slowly and be sure there are no other occupants around the seat. If the seatback is returned without being held and controlled, the back of the seat could spring forward resulting in accidental injury to a person struck by the seatback.

WARNING - Driver respon- sibility for passengers

Riding in a vehicle with the seat- back reclined could lead to serious or fatal injury in an accident. If a seat is reclined during an accident, the occupant’s hips may slide under the lap portion of the seat belt applying great force to the unprotected abdomen. Serious or fatal internal injuries could result. The driver must advise the passen- ger to keep the seatback in an upright position whenever the vehi- cle is in motion.

WARNING

Do not use a sitting cushion that reduces friction between the seat and passenger. The passenger's hips may slide under the lap por- tion of the seat belt during an acci- dent or a sudden stop. Serious or fatal internal injuries could result because the seat belt can't operate normally.

Safety features of your vehicle

WARNING - Driver’s seat

(cid:129) Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control, and an accident causing death, serious injury, or property dam- age.

(cid:129) Do not allow anything to interfere with the normal position of the seatback. Storing items against a seatback or in any other way interfering with proper locking of a seatback could result in serious or fatal injury in a sudden stop or collision.

(cid:129) Always drive and ride with your seatback upright and the lap por- tion of the seat belt snug and low across the hips. This is the best position to protect you in case of an accident.

(cid:129) In order to avoid unnecessary and perhaps severe air bag injuries, always sit as far back as possible from the steering wheel while maintaining comfortable control of the vehicle. We recom- mend that your chest be at least 10 inches (250 mm) away from the steering wheel.

3 3

Safety features of your vehicle

WARNING - Rear seatbacks (cid:129) The rear seatback must be securely latched. If not, passen- gers and objects could be thrown forward resulting in serious injury or death in the event of a sudden stop or collision.

(cid:129) Luggage and other cargo should be laid flat in the cargo area. If objects are large, heavy, or must be piled, they must be secured. Under no circumstances should cargo be piled higher than the seatbacks. Failure to follow these warnings could result in serious injury or death in the event of a sudden stop, collision or rollover. (cid:129) No passenger should ride in the cargo area or sit or lie on folded seatbacks while the vehicle is moving. All passengers must be properly seated in seats and restrained properly while riding. (Continued)

43

(Continued) (cid:129) When resetting the seatback to the upright position, make sure it is securely latched by pushing it forward and rearward.

(cid:129) To avoid the possibility of burns, from a hot rear floor surface do not remove the carpet in the cargo area. Emission control devices beneath this floor gener- ate high temperatures.

WARNING

WARNING

(cid:129) Use extreme caution so that hands or other objects are not caught in the seat mechanisms while the seat is moving.

(cid:129) Do not put a cigarette lighter on the floor or seat. When you oper- ate the seat, gas may gush out of the lighter and cause fire.

After adjusting the seat, always check that it is securely locked into place by attempting to move the seat forward or rearward without using lever. Sudden or unexpected movement of the driver's seat could cause you to lose control of the vehicle result- ing in an accident.

lock release

the

Safety features of your vehicle

OLM039002

OLM039003

Front seat adjustment - manual Forward and rearward To move the seat forward or rearward: 1. Pull the seat slide adjustment lever under the front edge of the seat cush- ion up and hold it.

2. Slide the seat to the position you

desire.

3. Release the lever and make sure the

seat is locked in place.

Adjust the seat before driving, and make sure the seat is locked securely by trying to move forward and rearward without using the lever. If the seat moves, it is not locked properly.

Seatback angle To recline the seatback: 1. Lean forward slightly and lift up on the seatback recline lever located on the outside of the seat at the rear.

2. Carefully lean back on the seat and adjust the seatback of the seat to the position you desire.

3. Release the lever and make sure the seatback is locked in place. (The lever MUST return to its original position for the seatback to lock.)

OLM039004
Seat cushion height (for driver’s seat) To change the height of the seat cushion, push the lever that is located on the out- side of the seat cushion upwards or downwards. (cid:129) To lower the seat cushion, push the

lever down several times.

(cid:129) To raise the seat cushion, pull the lever

up several times.

3 5

Safety features of your vehicle

Front seat adjustment - power (if equipped) The front seat can be adjusted by using the control knob located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so as to easily control the steering wheel, pedals and switches on the instrument panel.

WARNING

The power seat is operable with the ignition OFF. Therefore, children should never be left unattended in the car.

CAUTION

(cid:129) The power seat is driven by an electric motor. Stop operating once the adjustment is complet- ed. Excessive operation may damage the electrical equipment. (cid:129) When in operation, the power seat consumes a large amount of electrical power. To prevent unnecessary charging system drain,don’t adjust the power seat longer than necessary while the engine is not running.

(cid:129) Do not operate two or more power seat control knobs at the same time. Doing so may result in power seat motor or electrical component malfunction.

OLM039006

Forward and rearward Push the control knob forward or rear- ward to move the seat to the desired position. Release the knob once the seat reaches the desired position.

63

Safety features of your vehicle

OLM039007

Seatback angle Push the control knob forward or rear- ward to move the seatback to the desired angle. Release the knob once the seat reaches the desired position.

OLM039008
Seat cushion height (for driver’s seat) Pull the control knob up to raise or down to lower the seat cushion. Release the knob once the seat reaches the desired position.

OLM039009

Lumbar support (for driver’s seat) The lumbar support can be adjusted by pressing the button.

3 7

Safety features of your vehicle

OLM039303N

Headrest The driver's and front passenger's seats are equipped with a headrest for the occupant's safety and comfort. The headrest not only provides comfort for the driver and front passenger, but also helps to protect the head and neck in the event of a collision.

83

WARNING

(cid:129) For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes. Also, adjust the headrest as close to your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended.

(cid:129) Do not operate the vehicle with the headrests removed as severe injury to the occupants may occur in the event of an accident. Headrests may provide protec- tion against neck injuries when properly adjusted.

(cid:129) Do not adjust the headrest posi- tion of the driver's seat while the vehicle is in motion.

OLM039010

Forward and rearward adjustment The headrest may be adjusted forward to 3 different positions by pulling the head- rest forward to the desired detent. To adjust the headrest to it’s furthest rear- ward position, pull it fully forward to the farthest position and release it. Adjust the headrest so that it properly supports the head and neck.

Safety features of your vehicle

OLM039011

OLM039012

HNF2041-1

Adjusting the height up and down To raise the headrest, pull it up to the desired position (1). To lower the head- rest, push and hold the release button (2) on the headrest support and lower the headrest to the desired position (3).

Removal and installation To remove the headrest, raise it as far as it can go then press the release button (1) while pulling upward (2). To reinstall the headrest, put the head- rest poles (3) into the holes while press- ing the release button (1). Then adjust it to the appropriate height.

WARNING

Make sure the headrest locks in position after adjusting it to proper- ly protects the occupants.

Active headrest The active headrest is designed to move forward and upward during a rear impact. This helps to prevent the driver's and front passenger’s heads from moving backward and thus helps minimize neck injuries.

WARNING

A gap between the seat and the headrest release button may appear when seating on the seat or when you push or pull the seat. Be careful not to get your finger, etc. caught in the gap.

3 9

(cid:129) Each time you push the button, the temperature setting of the seat is changed as follows : OFF → HIGH ( →

) → LOW (

(cid:129) The seat warmer defaults to the OFF position whenever the ignition switch is turned on.

✽✽ NOTICE With the seat warmer switch in the ON position, the heating system in the seat turns off or on automatically depending on the seat temperature.

CAUTION

(cid:129) When cleaning the seats, do not use an organic solvent such as paint thinner, benzene, alcohol and gasoline.Doing so may dam- age the surface of the heater or seats.

(cid:129) To prevent overheating the seat warmer, do not place blankets, cushions or seat covers on the seats while the seat warmer is in operation.

(cid:129) Do not place heavy or sharp objects on seats equipped with seat warmers.Damage to the seat warming components could occur.

Safety features of your vehicle

OLM039013

Seat warmer (if equipped) The seat warmer is provided to warm the front seats during cold weather. With the ignition switch in the ON position, push either of the switches to warm the driver's seat or the front passenger's seat. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the switches in the OFF position.

10

WARNING - Seat warmer

burns

Passengers should use extreme caution when using seat warmers due to the possibility of excess heating or burns. The occupants must be able to feel if the seat is becoming too warm and to turn the seat warmer off. In particular, the driver must exercise extreme care for the following types of passen- gers: 1. Infants, children, elderly or dis- abled persons, or hospital outpa- tients

2. Persons with sensitive skin or

those that burn easily

3. Fatigued individuals 4. Intoxicated individuals 5. Individuals taking medication that can cause drowsiness or sleepiness (sleeping pills, cold tablets, etc.)

OLM039015

Seatback pocket The seatback pocket is provided on the back of the front passenger’s and driver’s seatbacks.

WARNING - Seatback pockets

Do not put heavy or sharp objects in the seatback pockets. In an acci- dent they could come loose from the pocket and injure vehicle occu- pants.

Safety features of your vehicle

WARNING

For proper operation of the occu- pant classification system: (cid:129) Do not place any items cumula- tively weighing over 2.2 lbs (1 kg) in the passenger’s seatback pocket or on the passenger’s seat.

(cid:129) Do not hang onto the front pas-

senger seatback.

3 11

WARNING

(cid:129) For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes. Also, adjust the headrest as close to your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended.

(cid:129) Do not operate the vehicle with the headrests removed as severe injury to an occupant may occur in the event of an accident. Headrests may provide protec- tion against severe neck injuries when properly adjusted.

OLM039017

Adjusting the height up and down To raise the headrest, pull it up to the desired position (1). To lower the head- rest, push and hold the release button (2) on the headrest support and lower the headrest to the desired position (3).

Safety features of your vehicle

OLM039304N

Rear seat adjustment Headrest The rear seat(s) is equipped with head- rests in all the seating positions for the occupant's safety and comfort. The headrest not only provides comfort for passengers, but also helps to protect the head and neck in the event of a colli- sion.

12

OLM039018

OLM039019

Armrest To use the armrest, pull it forward from the seatback.

Removal and installation To remove the headrest, raise it as far as it can go then press the release button (1) while pulling upward (2). To reinstall the headrest, put the head- rest poles (3) into the holes while press- ing the release button (1). Then adjust it to the appropriate height.

WARNING

Make sure the headrest locks in position after adjusting it to proper- ly protect the occupants.

Safety features of your vehicle
