droppings, chemicals from industrial chimneys, etc., can damage your vehicle’s finish if they remain on painted surfaces. Wash the vehicle as soon as possible. If necessary, use non-abrasive cleaners that are marked safe for painted surfaces to remove foreign matter. Exterior painted surfaces are subject to aging, weather and chemical fallout that can take their toll over a period of years. You can help to keep the paint finish looking new by keeping your vehicle garaged or covered whenever possible.


6-56


Cleaning Aluminum or Chrome-Plated Wheels (If Equipped) Keep your wheels clean using a soft clean cloth with mild soap and water. Rinse with clean water. After rinsing thoroughly, dry with a soft clean towel. A wax may then be applied. The surface of these wheels is similar to the painted surface of your vehicle. Don’t use strong soaps, chemicals, abrasive polishes, abrasive cleaners, cleaners with acid or abrasive cleaning brushes on them because you could damage the surface. Do not use chrome polish on any wheels other than chrome-plated wheels. Use chrome polish only on chrome-plated wheels, but avoid any painted surface of the wheel, and buff off immediately after application. Don’t take your vehicle through an automatic car wash that has silicon carbide tire cleaning brushes. These brushes can also damage the surface of these wheels.


Cleaning Tires To clean your tires, use a stiff brush with a tire cleaner.


NOTICE:


When applying a tire dressing always take care to wipe off any overspray or splash from all painted surfaces on the body or wheels of the vehicle. Petroleum-based products may damage the paint finish and tires.


Sheet Metal Damage If your vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to the parts repaired or replaced to restore corrosion protection. Original manufacturer replacement parts will provide the corrosion protection while maintaining the warranty.


6-57


Chemical Paint Spotting Some weather and atmospheric conditions can create a chemical fallout. Airborne pollutants can fall upon and attack painted surfaces on your vehicle. This damage can take two forms: blotchy, ringlet-shaped discolorations, and small irregular dark spots etched into the paint surface. Although no defect in the paint job causes this, Pontiac will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km) of purchase, whichever occurs first.


Finish Damage Any stone chips, fractures or deep scratches in the finish should be repaired right away. Bare metal will corrode quickly and may develop into a major repair expense. Minor chips and scratches can be repaired with touch-up materials available from your dealer or other service outlets. Larger areas of finish damage can be corrected in your dealer’s body and paint shop. Underbody Maintenance Chemicals used for ice and snow removal and dust control can collect on the underbody. If these are not removed, accelerated corrosion (rust) can occur on the underbody parts such as fuel lines, frame, floor pan and exhaust system even though they have corrosion protection. At least every spring, flush these materials from the underbody with plain water. Clean any areas where mud and other debris can collect. Dirt packed in closed areas of the frame should be loosened before being flushed. Your dealer or an underbody car washing system can do this for you.


6-58


GM Vehicle Care/Appearance Materials


PART NUMBER


SIZE


DESCRIPTION


USAGE


994954
1050172
1050173
1050174
1050214
1050427


Polishing Cloth – Wax Treated


23 in. x 25 in. Tar and Road Oil Remover 16 oz. (0.473 L) Chrome Cleaner and Polish 16 oz. (0.473 L) 16 oz. (0.473 L) White Sidewall Tire Cleaner 32 oz. (0.946 L) 23 oz. (0.680 L)


Vinyl Cleaner Glass Cleaner


1052918**


8 oz. (0.237 L)


Armor Allt Protectant


Exterior polishing cloth


Removes tar, road oil and asphalt


Use on chrome, stainless steel, nickel, copper and brass


Removes soil and black marks from whitewalls Cleans vinyl tops, upholstery and convertible tops


Removes dirt, grime, smoke and fingerprints


Protects leather, wood, acrylics, Plexiglast, plastic,


rubber and vinyl


1052925


16 oz. (0.473 L) Multi-Purpose Interior Clean-


er


Cleans carpets, seats, interior trim, door panels


and floor mats


Capture Dry Spot Remover


2.5 sq. ft.


Wheel Cleaner


16 oz. (0.473 L) 8 oz. (0.237 L)


1052929
1052930
12345721
12345725
12377964* 12377966* 12377984* See your General Motors Parts Department for these products. See “Recommended Fluids and Lubricants” in the Index.


12 oz. (0.354 L) 16 oz. (0.473 L) 16 oz. (0.473 L) 16 oz. (0.473 L)


Synthetic Chamois Silicone Tire Shine


Finish Enhancer


Surface Cleaner


Cleaner Wax


Spray on and rinse with water


Attracts, absorbs and removes soils on fabric


Shines vehicle without scratching


Spray on tire shine


Removes dust, fingerprints and surface contaminants Removes light scratches and oxidation and protects finish


Removes contaminants, blemishes and swirl marks


* For exterior use only. **Not recommended for use on instrument panels.


6-59


Vehicle Identification Number (VIN)


This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle. The VIN also appears on the Vehicle Certification and Service Parts labels and the certificates of title and registration. Engine Identification The 8th character in your VIN is the engine code. This code will help you identify your engine, specifications and replacement parts. Service Parts Identification Label You’ll find this label on your spare tire cover. It’s very helpful if you ever need to order parts. On this label is: D your VIN,


6-60


D the model designation, D paint information and D a list of all production options and


special equipment.


Be sure that this label is not removed from the vehicle. Electrical System Add-On Electrical Equipment


NOTICE:


Don’t add anything electrical to your vehicle unless you check with your dealer first. Some electrical equipment can damage your vehicle and the damage wouldn’t be covered by your warranty. Some add-on electrical equipment can keep other components from working as they should.


Your vehicle has an air bag system. Before attempting to add anything electrical to your vehicle, see “Servicing Your Air Bag-Equipped Vehicle” in the Index.


Headlamp Wiring The headlamp wiring is protected by an internal circuit breaker. An electrical overload will cause the lamps to go on and off, or in some cases to remain off. If this happens, have your headlamp system checked right away. Windshield Wipers The windshield wiper motor is protected by an internal circuit breaker and a fuse. If the motor overheats due to heavy snow, etc., the wiper will stop until the motor cools. If the overload is caused by some electrical problem, be sure to have it fixed. Power Windows and Other Power Options Circuit breakers in the rear electrical center protect the power windows and other power accessories. When the current load is too heavy, the circuit breaker opens and closes, protecting the circuit until the problem is fixed or goes away. Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses and circuit breakers. This greatly reduces the chance of damage caused by electrical problems.


Look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse. Be sure you replace a bad fuse with a new one of the identical size and rating. If you ever have a problem on the road and don’t have a spare fuse, you can borrow one that has the same amperage. Just pick some feature of your vehicle that you can get along without -- like the radio or cigarette lighter -- and use its fuse, if it is the correct amperage. Replace it as soon as you can. The MaxiFuses are located in two Bussed Electrical Centers (BEC), one located near the engine compartment on the passenger’s side and the other under the rear seat on the driver’s side. If a MaxiFuse should blow, have your vehicle serviced by your dealer immediately.


Removing Fuses You will find a fuse puller attached in both of the BEC. Snap the wide end of the fuse puller on to the fuse, at the side indentations holding the puller and pull the fuse out.


6-61


Engine Compartment Bussed Electrical Center (BEC)


As mentioned above, the front BEC is located in the front of the engine compartment on the passenger’s side. Lift the cover to gain access.


Fuse 22 or 23 can be moved to the outer position to enable the accessory power outlet or cigarette lighter when the ignition is not on. See your dealer for additional assistance, if needed.


6-62


Minifuse


Usage Not Used Accessory Windshield Wipers Not Used Headlamp Low Beam Left Headlamp Low Beam Right Spare Powertrain Control Module Battery


Minifuse 10
11
12
13
14
15
16
17
18
19


20
21
22
23
24


25
26


Usage Headlamp High Beam Right Headlamp High Beam Left Ignition 1
Not Used Transaxle Cruise Control DIS Injector Bank #2
Not Used Not Used Powertrain Control Module Ignition Oxygen Sensor Injector Bank #1
Auxiliary Power Cigar Lighter Fog Lamps/Daytime Running Lamps Horn Air Conditioning Clutch


Mirco Relay 27
28
29
30
31
32
33


Mini Relay 34
35
36
37
38
39
40


Usage Headlamp High Beam Headlamp Low Beam Fog Lamps Daytime Running Lamps Horn Air Conditioning Clutch HVAC Solenoid


Usage Accessory Air Pump Starter 1
Cooling Fan Secondary Ignition 1
Cooling Fan Series/Parallel Cooling Fan Primary


6-63


Maxibreaker 41


Usage Starter


Usage Air Antilock Brake System Not Used Not Used Cooling Fan Secondary Cooling Fan Primary Spare Spare Spare Spare Spare Fuse Puller


Maxifuse 42
43
44
45
46
47
48
49
50
51
52
53


6-64


Removing the Rear Seat Cushion


NOTICE:


The battery and main fuse boxes are located under the rear seat cushion. The battery’s ground terminal and some relay wires are exposed. To help avoid damage to the battery and wires, be careful when removing or reinstalling the seat cushion. Do not remove covers from covered parts. Do not store anything under the seat, as objects could touch exposed wires and cause a short.


To remove the rear seat cushion: 1. Pull up on the front of the cushion to release the


front hooks.


2. Pull the cushion up and out toward the front of


the vehicle.


To reinstall the rear seat cushion:


CAUTION:


A safety belt that isn’t properly routed through the seat cushion or is twisted won’t provide the protection needed in a crash. If the safety belt hasn’t been routed through the seat cushion at all, it won’t be there to work for the next passenger. The person sitting in that position could be badly injured. After reinstalling the seat cushion, always check to be sure that the safety belts are properly routed and are not twisted.


1. Buckle the center passenger position safety belt, then


route the safety belts through the proper slots in the seat cushion. Don’t let the safety belts get twisted.


2. Slide the rear of the cushion up and under the


seatback so the rear-locating guides hook into the wire loops on the back frame.


6-65


3. With the seat cushion lowered, push rearward and


then press down on the seat cushion until the spring locks on both ends engage.


4. Check to make sure the safety belts are properly


routed and that no portion of any safety belt is trapped under the seat. Also make sure the seat cushion is secured.


Rear Underseat Bussed Electrical Center (BEC)


The rear BEC is located below the rear seat on the driver’s side. The rear seat cushion must be removed to access the BEC. See “Removing the Rear Seat Cushion” in the Index.


6-66


Minifuse


Usage Fuel Pump Heater, Ventilation, Air Conditioning Blower Memory Seat Assembly Line Diagnostic Link Not Used CD Driver Door Module Supplemental Inflatable Restraint


Minifuse 10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28


Usage Not Used Lamps Park Right Ventilation Solenoid Ignition 1
Lamps Park Left Interior Lamp Dimmer Module Not Used Heated Seat Left Front Not Used Rear Door Modules Stoplamps PARK (P) / REVERSE (R) Audio Retained Accessory Power Not Used Not Used Passenger Door Module Body Interior Lamps Not Used


Minifuse 29
30
31
32
33


34
35
36
37
38


Micro Relay 39
40
41
42
43
44
45


Usage Ignition Switch Instrument Panel Heated Seat Right Front Not Used Heating, Ventilation, Air Conditioning Ignition 3 Rear Antilock Brake System Turn Signal/Hazard HVAC Battery Dash Integration Module


Usage Fuel Pump Parking Lamps Ignition 1
Not Used Not Used Park Brake Reverse Lamps


6-67


Micro Relay 46
47
48
49
50
51
52
53
54
55


Usage Retained Accessory Power Fuel Tank Door Lock Not Used Ignition 3
Fuel Tank Door Release Interior Lamps Trunk Release Front Courtesy Lamps Not Used Electronic Level Control Compressor


Circuit Breaker Usage 56
57


Power Seats Power Windows


Mini Relay 58
59


6-68


Usage Cigarette Lighter Rear Defog


Maxifuse 60
61
62
63
64


65
66
67
68
69
70
71
72
73
74
75


Usage Not Used Rear Defog Not Used Audio Amplifier Electronic Level Control Compressor/Exhaust Cigarette Lighter Not Used Spare Spare Spare Spare Spare Spare Spare Spare Fuse Puller


Replacement Bulbs If your vehicle is equipped with the Driver Information Center, the messages will also appear on the Lamp Monitor to alert you that a bulb needs to be replaced.


Exterior Lamps Front Parking/Turn Lamps Halogen Headlamps


Low Beam High Beam


Rear Taillamps Back-up Lamps Stoplamps Turn


Bulb


3157NA


9006
9005


3057
3057
3057
3157


For service information on other bulbs, contact your dealer’s service department.


. . . . . . . . . . . . . . . . . . . . . . . . .


Capacities and Specifications The following approximate capacities are given in English and metric conversions. Please refer to “Recommended Fluids and Lubricants” in the Index for more information. Engine Specifications 3800 V6 Series II Engine (L36) VIN Engine Code Displacement Horsepower Firing Order Thermostat Temperature 3800 V6 Series II Supercharged Engine (L67) VIN Engine Code Displacement Horsepower Firing Order Thermostat Temperature Tire Pressures


3.8 Liters 240-hp 1-6-5-4-3-2
195_F (91_C) See Tire-Loading Information label on the driver’s door.


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


3.8 Liters 205-hp 1-6-5-4-3-2
195_F (91_C)


. . . . . . . . . . . . . . . . . . . . . . . . . .


. . . . .


6-69


AC Type A-1096C


Normal Maintenance Replacement Parts Air Cleaner Filter . . . . . . . . . . . . . Passenger Compartment Air Filter


(HVAC Air Filter)


. . . . . . . .


. . . . . . . . . . . . . . . .


Engine Oil Filter Fuel Filter Transaxle Filter Spark Plugs


. . . . . . . . . . . . . . . . . . . .


. . . . . . . . . . . .


. . . . . . . . . . . . . . . . .


GM Part No. 25654414
AC Type PF-47
AC Type GF-627
GM Part No. 8651909
AC Type 41-921* Gap: 0.060 inch (1.52 mm)


Windshield Wiper Blades


Type Length


. . . . . . . . . . . . . . . . . . . . . . . . .


. . . . . . . . . . . . . . . . . . . . .


Shepard’s Hook 22 inches (56 cm)


*On 3800 V6 Supercharged Engine (Code 1) only, this replaces original spark plug NGK Type PTR4B-15.


Wheel Nut Torque 100 lb-ft (140 N·m) Capacities Automatic Transaxle (Overdrive)


Pan Removal and


Replacement


Complete Overhaul


. . . . . . . . . . . . . . . . . . . . .


7.4 quarts (7.0 L) 10.0 quarts (9.5 L)


When draining or replacing torque converter, more fluid may be needed. Cooling System Engine Crankcase Oil change with filter change Fuel Tank . . . . . . . . . . . . . . . Air Conditioning Refrigerant


. . . . . . . . . . . . . . . . . . . . . . . .


10.0 quarts (9.5 L) 4.5 quarts (4.3L)


18.5 gallons (70.0 L) . . . . See refrigerant charge label under the hood.


All capacities are approximate. When adding, be sure to fill to the appropriate level, as recommended in this manual.


6-70


Vehicle Dimensions Wheelbase Tread Width


. . . . . . . . . . . . . .


112.2 inches (285.0 cm)


Front Rear Length Width Height


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


62.4 inches (158.5 cm) 62.3 inches (158.2 cm) 202.6 inches (514.6 cm) 73.8 inches (187.5 cm) 56.0 inches (142.2 cm)


L36 Engine Accessory Belt The 3800 V6 (L36) engine uses an engine accessory belt. This diagram shows the features connected and the routing. See “Maintenance Schedule” in the Index for when to check the belt.


A. Power Steering B. Generator C. Air Conditioning


D. Crank E. Coolant Pump F.


Idler


6-71


L67 Engine Accessory Belt The Supercharged 3800 V6 (L67) engine uses two accessory drive belts. The inner belt drives the generator, power steering pump, coolant pump and air conditioning. The outer belt drives the supercharger. Each belt has its own tensioner and idler pulley. See “Maintenance Schedule” in the Index for when to check the accessory drive belts and the supercharger oil level. Have your dealer check the oil level in the supercharger.


6-72


1. Front Belt 2. Back Belt A. Generator B. Power Steering Pump


C. Crank D. Supercharger E. Coolant Pump F. Air Conditioning


Section 7 Maintenance Schedule


This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety, dependability and emission control performance.


7-2
7-4
7-7
7-20


Introduction Part A: Scheduled Maintenance Services Short Trip/City Scheduled Maintenance Long Trip/Highway Scheduled Maintenance


7-28
7-32
7-34
7-36


Part B: Owner Checks and Services Part C: Periodic Maintenance Inspections Part D: Recommended Fluids and Lubricants Part E: Maintenance Record


7-


7-1


Introduction Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also helps the environment. All recommended maintenance procedures are important. Improper vehicle maintenance can even affect the quality of the air we breathe. Improper fluid levels or the wrong tire inflation can increase the level of emissions from your vehicle. To help protect our environment, and to keep your vehicle in good condition, please maintain your vehicle properly. Maintenance Requirements Maintenance intervals, checks, inspections and recommended fluids and lubricants as prescribed in this manual are necessary to keep your vehicle in good working condition. Any damage caused by failure to follow recommended maintenance may not be covered by warranty.


Have you purchased the GM Protection Plan? The Plan supplements your new vehicle warranties. See your Warranty and Owner Assistance booklet, or your dealer for details.


7-2


How This Section is Organized This maintenance schedule is divided into five parts: “Part A: Scheduled Maintenance Services” shows what to have done and how often. Some of these services can be complex, so unless you are technically qualified and have the necessary equipment, you should let your dealer’s service department or another qualified service center do these jobs.


CAUTION:


Performing maintenance work on a vehicle can be dangerous. In trying to do some jobs, you can be seriously injured. Do your own maintenance work only if you have the required know-how and the proper tools and equipment for the job. If you have any doubt, have a qualified technician do the work.


If you want to get the service information, see “Service and Owner Publications” in the Index.


“Part B: Owner Checks and Services” tells you what should be checked and when. It also explains what you can easily do to help keep your vehicle in good condition. “Part C: Periodic Maintenance Inspections” explains important inspections that your dealer’s service department or another qualified service center should perform. “Part D: Recommended Fluids and Lubricants” lists some recommended products necessary to help keep your vehicle properly maintained. These products, or their equivalents, should be used whether you do the work yourself or have it done. “Part E: Maintenance Record” is a place for you to record and keep track of the maintenance performed on your vehicle. Keep your maintenance receipts. They may be needed to qualify your vehicle for warranty repairs.


7-3


The proper fluids and lubricants to use are listed in Part D. Make sure whoever services your vehicle uses these. All parts should be replaced and all necessary repairs done before you or anyone else drives the vehicle. These schedules are for vehicles that: D carry passengers and cargo within recommended limits. You will find these limits on your vehicle’s Tire-Loading Information label. See “Loading Your Vehicle” in the Index.


D are driven on reasonable road surfaces within legal


driving limits.


D use the recommended fuel. See “Fuel” in the Index. Selecting the Right Schedule First you’ll need to decide which of the two schedules is right for your vehicle. Here’s how to decide which schedule to follow:


Part A: Scheduled Maintenance Services Using Your Maintenance Schedule We at General Motors want to help you keep your vehicle in good working condition. But we don’t know exactly how you’ll drive it. You may drive very short distances only a few times a week. Or you may drive long distances all the time in very hot, dusty weather. You may use your vehicle in making deliveries. Or you may drive it to work, to do errands or in many other ways. Because of all the different ways people use their vehicles, maintenance needs vary. You may need more frequent checks and replacements. So please read the following and note how you drive. If you have any questions on how to keep your vehicle in good condition, see your dealer. This part tells you the maintenance services you should have done and when you should schedule them. If you go to your dealer for your service needs, you’ll know that GM-trained and supported service people will perform the work using genuine GM parts.


7-4


Scheduled Maintenance


Short Trip/City Definition


Short Trip/City Intervals


Follow the Short Trip/City Scheduled Maintenance if any one of these conditions is true for your vehicle: D Most trips are less than 5 to 10 miles (8 to 16 km).


This is particularly important when outside temperatures are below freezing.


D Most trips include extensive idling (such as frequent


driving in stop-and-go traffic).


D Most trips are through dusty areas. D You frequently tow a trailer or use a carrier on top of


your vehicle.


D If the vehicle is used for delivery service, police, taxi


or other commercial application.


One of the reasons you should follow this schedule if you operate your vehicle under any of these conditions is that these conditions cause engine oil to break down sooner.


Every 3,000 Miles (5 000 km): Engine Oil and Filter


Change (or 3 months, whichever occurs first). Every 6,000 Miles (10 000 km): Tire Rotation. Every 12,000 Miles (20 000 km): Passenger


Compartment Air Filter Replacement (if equipped). Every 15,000 Miles (25 000 km): Engine Air Cleaner


Filter Inspection, if driving in dusty conditions.


Every 30,000 Miles (50 000 km): Engine Air Cleaner


Filter Replacement. Supercharger Oil Check (or every 36 months, whichever occurs first) (3800 Code 1 V6 engine only).


Every 50,000 Miles (83 000 km): Automatic Transaxle


Service (severe conditions only).


Every 60,000 Miles (100 000 km): Engine Accessory


Drive Belt Inspection.


(Continued)


7-5


Scheduled Maintenance


Short Trip/City Intervals


Long Trip/Highway Intervals


Every 100,000 Miles (166 000 km): Spark Plug Wire


Inspection. Spark Plug Replacement. Automatic Transaxle Service (normal conditions).


Every 7,500 Miles (12 500 km): Engine Oil and Filter Change (or every 12 months, whichever occurs first). Tire Rotation.


Every 150,000 Miles (240 000 km): Cooling System


Service (or every 60 months, whichever occurs first).


These intervals only summarize maintenance services. Be sure to follow the complete scheduled maintenance on the following pages.


Long Trip/Highway Definition


Follow this scheduled maintenance only if none of the conditions from the Short Trip/City Scheduled Maintenance are true. Do not use this schedule if the vehicle is used for trailer towing, driven in a dusty area or used off paved roads. Use the Short Trip/City schedule for these conditions. Driving a vehicle with a fully warmed engine under highway conditions causes engine oil to break down slower.


7-6


Every 30,000 Miles (50 000 km): Supercharger Oil


Check (or every 36 months, whichever occurs first) (3800 Code 1 V6 engine only). Engine Air Cleaner Filter Replacement.


Every 50,000 Miles (83 000 km): Automatic Transaxle


Service (severe conditions only).


Every 60,000 Miles (100 000 km): Engine Accessory


Drive Belt Inspection.


Every 100,000 Miles (166 000 km): Spark Plug Wire


Inspection. Spark Plug Replacement. Automatic Transaxle Service (normal conditions).


Every 150,000 Miles (240 000 km): Cooling System


Service (or every 60 months, whichever occurs first).


These intervals only summarize maintenance services. Be sure to follow the complete scheduled maintenance on the following pages.


Short Trip/City Scheduled Maintenance


The services shown in this schedule up to 100,000 miles (166 000 km) should be performed after 100,000 miles (166 000 km) at the same intervals. The services shown at 150,000 miles (240 000 km) should be performed at the same interval after 150,000 miles (240 000 km). See “Owner Checks and Services” and “Periodic Maintenance Inspections” following. Footnotes [ The U.S. Environmental Protection Agency or the California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the maintenance be recorded.


* If your vehicle has a GM Oil Life Systemt, the system will show you when to change the oil -- usually between 3,000 miles (5 000 km) and 7,500 miles (12 500 km) since your last oil change. Under severe conditions, the indicator may come on before 3,000 miles (5 000 km). Never drive your vehicle more than 7,500 miles (12 500 km) or 12 months, (whichever occurs first), without an oil and filter change. The system won’t detect dust in the oil. So if you drive in a dusty area be sure to change your oil every 3,000 miles (5 000 km) or sooner if the ENGINE OIL CHANGE SOON message appears on the Driver Information Center (DIC). Remember to reset the Oil Life System whenever the oil is changed. For more information, see “Oil Life System” in the Index. + A good time to check your brakes is during tire rotation. See “Brake System Inspection” under “Periodic Maintenance Inspections” in Part C of this schedule.


7-7


Short Trip/City Scheduled Maintenance


3,000 Miles (5 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


6,000 Miles (10 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


9,000 Miles (15 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


12,000 Miles (20 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


7-8


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


SERVICED BY:


SERVICED BY:


Short Trip/City Scheduled Maintenance


15,000 Miles (25 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Inspect engine air cleaner filter if you are driving in dusty conditions.


Replace filter if necessary. An Emission Control Service. (See footnote [.)


18,000 Miles (30 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


21,000 Miles (35 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-9


Short Trip/City Scheduled Maintenance


24,000 Miles (40 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


27,000 Miles (45 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


30,000 Miles (50 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Replace engine air cleaner filter.


An Emission Control Service.


j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote [.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


7-10


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


Short Trip/City Scheduled Maintenance


33,000 Miles (55 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


36,000 Miles (60 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


39,000 Miles (65 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-11


Short Trip/City Scheduled Maintenance


42,000 Miles (70 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


45,000 Miles (75 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Inspect engine air cleaner filter if you are driving in dusty conditions.


Replace filter if necessary. An Emission Control Service. (See footnote [.)


48,000 Miles (80 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-12


Short Trip/City Scheduled Maintenance


50,000 Miles (83 000 km) j Change automatic transaxle fluid and filter if the vehicle is mainly driven


under one or more of these conditions: – In heavy city traffic where the outside temperature regularly reaches


90_F (32_C) or higher.


– In hilly or mountainous terrain. – When doing frequent trailer towing. – Uses such as found in taxi, police or delivery service. If you do not use your vehicle under any of these conditions, change the fluid and filter at 100,000 miles (166 000 km).


51,000 Miles (85 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


54,000 Miles (90 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


7-13


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


Short Trip/City Scheduled Maintenance


57,000 Miles (95 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


60,000 Miles (100 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Inspect engine accessory drive belt.


An Emission Control Service.


j Replace engine air cleaner filter.


An Emission Control Service.


j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote [.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


7-14


Short Trip/City Scheduled Maintenance


63,000 Miles (105 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


66,000 Miles (110 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


69,000 Miles (115 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


72,000 Miles (120 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


SERVICED BY:


SERVICED BY:


7-15


Short Trip/City Scheduled Maintenance


75,000 Miles (125 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Inspect engine air cleaner filter if you are driving in dusty conditions.


Replace filter if necessary. An Emission Control Service. (See footnote [.)


78,000 Miles (130 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


81,000 Miles (135 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-16


Short Trip/City Scheduled Maintenance


84,000 Miles (140 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


87,000 Miles (145 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


90,000 Miles (150 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Replace engine air cleaner filter.


An Emission Control Service.


j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote [.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


7-17


Short Trip/City Scheduled Maintenance


93,000 Miles (155 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


96,000 Miles (160 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


99,000 Miles (165 000 km) j Change engine oil and filter (or every 3 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


100,000 Miles (166 000 km) j Inspect spark plug wires.


An Emission Control Service.


j Replace spark plugs.


An Emission Control Service.


7-18


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


DATE


ACTUAL MILEAGE


SERVICED BY:


SERVICED BY:


SERVICED BY:


SERVICED BY:


Short Trip/City Scheduled Maintenance


j Change automatic transaxle fluid and filter if the vehicle is mainly driven


under one or more of these conditions: – In heavy city traffic where the outside temperature regularly reaches


90_F (32_C) or higher.


– In hilly or mountainous terrain. – When doing frequent trailer towing. – Uses such as found in taxi, police or delivery service.


j If you haven’t used your vehicle under severe service conditions listed


previously and, therefore, haven’t changed your automatic transaxle fluid, change both the fluid and filter.


150,000 Miles (240 000 km) j Drain, flush and refill cooling system (or every 60 months since last service, whichever occurs first). See “Engine Coolant” in the Index for what to use. Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test cooling system and pressure cap. An Emission Control Service.


DATE


ACTUAL MILEAGE


SERVICED BY:


7-19


Long Trip/Highway Scheduled Maintenance


The services shown in this schedule up to 100,000 miles (166 000 km) should be performed after 100,000 miles (166 000 km) at the same intervals. The services shown at 150,000 miles (240 000 km) should be performed at the same interval after 150,000 miles (240 000 km). See “Owner Checks and Services” and “Periodic Maintenance Inspections” following. Footnotes [ The U.S. Environmental Protection Agency or the California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the maintenance be recorded.


* If your vehicle has the GM Oil Life Systemt, the system will show you when to change the engine oil and filter -- usually between 3,000 miles (5 000 km) and 7,500 miles (12 500 km) since your last oil change. Under severe conditions, the indicator may come on before 3,000 miles (5 000 km). Never drive your vehicle more than 7,500 miles (12 500 km) or 12 months without an oil and filter change. The system won’t detect dust in the oil. So if you drive in a dusty area, be sure to change your oil and filter every 3,000 miles (5 000 km) or sooner if the ENGINE OIL CHANGE SOON message appears on the Driver Information Center (DIC). Remember to reset the Oil Life System whenever the oil is changed. For more information, see “Oil Life System” in the Index. + A good time to check your brakes is during tire rotation. See “Brake System Inspection” under “Periodic Maintenance Inspections” in Part C of this schedule.


7-20


Long Trip/Highway Scheduled Maintenance


7,500 Miles (12 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


15,000 Miles (25 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


22,500 Miles (37 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-21


Long Trip/Highway Scheduled Maintenance


30,000 Miles (50 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


j Replace engine air cleaner filter.


An Emission Control Service.


j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote[.)


37,500 Miles (62 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-22


Long Trip/Highway Scheduled Maintenance


45,000 Miles (75 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


50,000 Miles (83 000 km) j Change automatic transaxle fluid and filter if the vehicle is mainly driven


under one or more of these conditions: – In heavy city traffic where the outside temperature regularly reaches


90_F (32_C) or higher.


– In hilly or mountainous terrain. – When doing frequent trailer towing. – Uses such as found in taxi, police or delivery service. If you do not use your vehicle under any of these conditions, change the fluid and filter at 100,000 miles (166 000 km).


52,500 Miles (87 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-23


Long Trip/Highway Scheduled Maintenance


60,000 Miles (100 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote[.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


j Inspect engine accessory drive belt.


An Emission Control Service.


j Replace engine air cleaner filter.


An Emission Control Service.


DATE


ACTUAL MILEAGE


SERVICED BY:


67,500 Miles (112 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


DATE


ACTUAL MILEAGE


SERVICED BY:


7-24


Long Trip/Highway Scheduled Maintenance


75,000 Miles (125 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


82,500 Miles (137 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


90,000 Miles (150 000 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j If Equipped: Replace passenger compartment air filter. j Replace engine air cleaner filter.


An Emission Control Service.


(Continued)


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


7-25


Long Trip/Highway Scheduled Maintenance


90,000 Miles (150 000 km) (Continued) j For supercharged engines only: Check the supercharger oil level and add oil as


needed (or every 36 months, whichever occurs first). See “Recommended Fluids and Lubricants” in this section. An Emission Control Service. (See footnote[.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


97,500 Miles (162 500 km) j Change engine oil and filter (or every 12 months, whichever occurs first).


An Emission Control Service. (See footnote *.)


j Rotate tires. See “Tire Inspection and Rotation” in the Index for proper


rotation pattern and additional information. (See footnote +.)


100,000 Miles (166 000 km) j Inspect spark plug wires.


An Emission Control Service.


j Replace spark plugs.


An Emission Control Service.


7-26


DATE


ACTUAL MILEAGE


SERVICED BY:


DATE


ACTUAL MILEAGE


SERVICED BY:


Long Trip/Highway Scheduled Maintenance


j Change automatic transaxle fluid and filter if the vehicle is mainly driven


under one or more of these conditions: – In heavy city traffic where the outside temperature regularly reaches


90_F (32_C) or higher.


– In hilly or mountainous terrain. – When doing frequent trailer towing. – Uses such as found in taxi, police or delivery service.


j If you haven’t used your vehicle under severe service conditions listed


previously and, therefore, haven’t changed your automatic transaxle fluid, change both the fluid and filter.


150,000 Miles (240 000 km) j Drain, flush and refill cooling system (or every 60 months since last service, whichever occurs first). See “Engine Coolant” in the Index for what to use. Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test the cooling system and pressure cap. An Emission Control Service.


DATE


ACTUAL MILEAGE


SERVICED BY:


7-27


Part B: Owner Checks and Services Listed in this part are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Part D. At Each Fuel Fill It is important for you or a service station attendant to perform these underhood checks at each fuel fill.


Engine Oil Level Check Check the engine oil level and add the proper oil if necessary. See “Engine Oil” in the Index for further details.


Engine Coolant Level Check Check the engine coolant level and add DEX-COOLR coolant mixture if necessary. See “Engine Coolant” in the Index for further details.


Windshield Washer Fluid Level Check Check the windshield washer fluid level in the windshield washer tank and add the proper fluid if necessary. See “Windshield Washer Fluid” in the Index for further details. At Least Once a Month


Tire Inflation Check Make sure tires are inflated to the correct pressures. Don’t forget to check your spare tire. See “Tires” in the Index for further details.


Cassette Deck Service Clean cassette deck. Cleaning should be done every 50 hours of tape play. See “Audio Systems” in the Index for further details.


7-28


Automatic Transaxle Check Check the transaxle fluid level; add if needed. See “Automatic Transaxle Fluid” in the Index. A fluid loss may indicate a problem. Check the system and repair if needed. At Least Once a Year


Key Lock Cylinders Service Lubricate the key lock cylinders with the lubricant specified in Part D.


Body Lubrication Service Lubricate all hinges and latches, including those for the hood, rear compartment, glove box door, console door and any folding seat hardware. Part D tells you what to use. More frequent lubrication may be required when exposed to a corrosive environment.


At Least Twice a Year


Restraint System Check Make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired. Have any torn or frayed safety belts replaced. Also look for any opened or broken air bag coverings, and have them repaired or replaced. (The air bag system does not need regular maintenance.)


Wiper Blade Check Inspect wiper blades for wear or cracking. Replace blade inserts that appear worn or damaged or that streak or miss areas of the windshield. Also see “Wiper Blades, Cleaning” in the Index.


Weatherstrip Lubrication Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth. During very cold, damp weather more frequent application may be required. (See “Recommended Fluids and Lubricants” in the Index.)


7-29


Starter Switch Check


CAUTION:


When you are doing this check, the vehicle could move suddenly. If it does, you or others could be injured. Follow the steps below.


1. Before you start, be sure you have enough room


around the vehicle.


2. Firmly apply both the parking brake (see “Parking


Brake” in the Index if necessary) and the regular brake. NOTE: Do not use the accelerator pedal, and be ready to turn off the engine immediately if it starts.


3. Try to start the engine in each gear. The starter


should work only in PARK (P) or NEUTRAL (N). If the starter works in any other position, your vehicle needs service.


Automatic Transaxle Shift Lock Control System Check


CAUTION:


When you are doing this check, the vehicle could move suddenly. If it does, you or others could be injured. Follow the steps below.


1. Before you start, be sure you have enough room


around the vehicle. It should be parked on a level surface.


2. Firmly apply the parking brake (see “Parking Brake”


in the Index if necessary). NOTE: Be ready to apply the regular brake immediately if the vehicle begins to move.


3. With the engine off, turn the key to the RUN


position, but don’t start the engine. Without applying the regular brake, try to move the shift lever out of PARK (P) with normal effort. If the shift lever moves out of PARK (P), your vehicle needs service.


7-30


Ignition Transaxle Lock Check While parked, and with the parking brake set, try to turn the ignition key to LOCK in each shift lever position. D The key should turn to LOCK only when the shift


lever is in PARK (P).


D The key should come out only in LOCK.


Parking Brake and Automatic Transaxle PARK (P) Mechanism Check


CAUTION:


When you are doing this check, your vehicle could begin to move. You or others could be injured and property could be damaged. Make sure there is room in front of your vehicle in case it begins to roll. Be ready to apply the regular brake at once should the vehicle begin to move.


Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot on the regular brake, set the parking brake. D To check the parking brake’s holding ability: With


the engine running and transaxle in NEUTRAL (N), slowly remove foot pressure from the regular brake pedal. Do this until the vehicle is held by the parking brake only.


D To check the PARK (P) mechanism’s holding ability:


With the engine running, shift to PARK (P). Then release the parking brake followed by the regular brake.


Underbody Flushing Service At least every spring, use plain water to flush any corrosive materials from the underbody. Take care to clean thoroughly any areas where mud and other debris can collect.


7-31


Exhaust System Inspection Inspect the complete exhaust system. Inspect the body near the exhaust system. Look for broken, damaged, missing or out-of-position parts as well as open seams, holes, loose connections or other conditions which could cause a heat build-up in the floor pan or could let exhaust fumes into the vehicle. See “Engine Exhaust” in the Index. Engine Cooling System Inspection Inspect the hoses and have them replaced if they are cracked, swollen or deteriorated. Inspect all pipes, fittings and clamps; replace as needed. Clean the outside of the radiator and air conditioning condenser. To help ensure proper operation, a pressure test of the cooling system and pressure cap is recommended at least once a year.


Part C: Periodic Maintenance Inspections Listed in this part are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your dealer’s service department or other qualified service center do these jobs. Make sure any necessary repairs are completed at once. Proper procedures to perform these services may be found in a service manual. See “Service and Owner

Loading...
x
