The twin trip odometer records the distance of individual trips.

Triple meter: 1. Trip computer 2. Engine oil pressure gauge 3. Volt meter

2-4 Instruments and controls

SIC1948

SIC1949A

쎻1 Speedometer 쎻2 Odometer 쎻3 Twin trip odometer 쎻4 Reset knob for trip odometer SPEEDOMETER AND ODOMETER Speedometer The speedometer indicates vehicle speed in miles per hour (MPH) and kilometers per hour (km/h). Odometer/Twin trip odometer The odometer/twin trip odometer are displayed when the ignition switch is in the ON position.

墌 07.7.25/Z33-D/V5.0 墍

Changing the display: Pushing the reset knob changes the display as follows: TRIP A → TRIP B → TRIP A Resetting the trip odometer: Pushing the reset knob for more than 1 second resets the trip odometer to zero.

SIC3328

TACHOMETER The tachometer indicates engine speed in revo- lutions per minute (rpm). Do not rev engine into the red zone 쎻A .

CAUTION

When engine speed approaches the red zone, shift to a higher gear or reduce engine speed. Operating the engine in the red zone may cause serious engine damage.

SIC2371A ENGINE COOLANT TEMPERATURE GAUGE The gauge indicates the engine coolant tem- perature. The engine coolant temperature is within the normal range 쎻A when the gauge needle points within the zone shown in the illustration. The engine coolant temperature will vary with the outside air temperature and driving conditions.

Instruments and controls 2-5

墌 07.7.25/Z33-D/V5.0 墍

CAUTION

If the gauge indicates a coolant tem- perature near the hot (H) end of the normal range, reduce vehicle speed to decrease the temperature. If the gauge is over the normal range, stop the ve- hicle as soon as safely possible. If the engine is overheated, continued opera- tion of the vehicle may seriously dam- age the engine. See “If your vehicle overheats” in the “6. In case of emer- gency” section for immediate action re- quired.

SIC2556

FUEL GAUGE The gauge indicates the approximate fuel level in the tank. The gauge may move slightly during braking, turning, acceleration, or going up or down hill. The gauge needle is designed to move to the E (Empty) position when the ignition key is turned to the OFF position. Refill the fuel tank before the gauge regis- ters the E (Empty) position.

The low fuel warning light comes on when the fuel tank is getting low. Refuel as soon as it is convenient, preferably before the gauge reaches the E position. There will be a small reserve of fuel in the tank when the fuel gauge needle reaches the E position. The the fuel-filler door is located on the passenger’s side of the vehicle.

indicates that

CAUTION

indicator

malfunction

쐌 If the vehicle runs out of fuel, the light (MIL) may come on. Refuel as soon as possible. After a few driving trips, light should turn off. If the the light remains on after a few driving trips, have the vehicle inspected by a NISSAN dealer.

쐌 For additional information, see “Mal- function indicator light (MIL)” later in this section.

2-6 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

operation in such a condition could cause serious damage to the engine.

SIC1954A

Type A

ENGINE OIL PRESSURE GAUGE The gauge indicates the engine lubrication sys- tem oil pressure while the engine is running. When the engine speed is high, the engine oil pressure is also high. When it is low, the gauge indicates the low oil pressure.

SIC1953A

Type B

CAUTION

쐌 This gauge is not designed to indi- cate low engine oil level. Use the dipstick to check the oil level. (See “Engine oil” in the “8. Maintenance and do-it-yourself” section.)

쐌 If the gauge needle does not move with the proper amount of engine oil, have the vehicle checked by a NISSAN dealer. Continued vehicle

Instruments and controls 2-7

墌 07.7.25/Z33-D/V5.0 墍

SIC1955

SIC3357

SIC2997

VOLT METER When the ignition switch is turned to the ON position, the volt meter indicates the battery voltage; while the engine is running, it indicates the alternator voltage of 11 - 15 volts (normal range 쎻A ). However, while cranking the engine, the volts drop below the normal range. If the needle is not in the normal range 쎻A while the engine is running, it may indicate that the charging system is not functioning properly. Have the system checked by a NISSAN dealer.

2-8 Instruments and controls

TRIP COMPUTER The display of the trip computer is situated in the triple meter. When the ignition switch is turned to ON, the display scrolls all the modes of the trip computer and then shows the mode chosen before the ignition switch is turned OFF.

Switches for the trip computer are located on the side of the combination meter panel. To operate the trip computer, push the side of the switches as shown above. 쎻A : Trip computer mode switch 쎻B : Trip computer setting switch When the ignition switch is turned to ON, modes of the trip computer can be selected by pushing the trip computer mode switch 쎻A . Each time the mode switch 쎻A is pushed, the display will change as follows: Speed indicator → Outside air temperature (ICY) → Distance to empty (dte) → Average fuel

墌 07.7.25/Z33-D/V5.0 墍

consumption and speed → Elapsed time and trip odometer → Stopwatch → Up-shift indica- tor setting (for M/T models) → Speed indicator Speed indicator (mph or km/h) The vehicle speed is displayed in MPH or km/h while driving. The speed indicator in the trip computer indicates the reference speed. The actual speed indicated by the speedometer (com- bination meter) may differ from the one in the trip computer. Outside air temperature (ICY — °F or °C) The outside air temperature is displayed in °F or °C in the range of −22 to 131°F (−30 to 55°C). The outside air temperature mode includes a low temperature warning feature: below 37°F (3°C), the outside air temperature mode is automati- cally selected and the ICY indicator will illumi- nate in order to draw the driver’s attention. Push the mode switch 쎻A if you wish to return to the mode that was selected before the warning occurred. The ICY indicator will continue blink- ing as long as the temperature remains below 39°F (4°C). The ambient temperature sensor is located in front of the radiator. The sensor may be affected

temperature or

by road or engine heat, wind directions and other driving conditions. The display may differ from the actual ambient the temperature displayed on various signs or bill- boards. Distance to empty (dte — mls or km) The distance to empty (dte) mode provides you with an estimation of the distance that can be driven before refueling. The dte is constantly being calculated, based on the amount of fuel in the fuel tank and the actual fuel consumption.

The display is updated every 30 seconds.

The dte mode includes a low range warning feature: when the fuel level is low, the dte mode is automatically selected and the digits blink in order to draw the driver’s attention. Press the mode switch 쎻A if you wish to return to the mode that was selected before the warning occurred. The dte indicator will remain blinking until the vehicle is refueled.

level drops even lower, the dte

When the fuel display will change to (----). NOTE: 쐌 If the amount of fuel added while the ignition switch is OFF is small, the dis- play just before the ignition switch is

turned OFF may continue to be dis- played.

쐌 When driving uphill or rounding curves, the fuel in the tank shifts, which may momentarily change the display.

Average fuel consumption (mpg or l (liter)/100 km) and speed (av. mph or av. km/h) Fuel consumption:

The average fuel consumption mode shows the average fuel consumption since the last reset. Resetting is done by pushing the trip computer setting switch 쎻B for more than approximately 1
second. (The average speed is also reset at the same time.)

The display is updated every 30 seconds. At about the first 1/3 miles (500 m) after a reset, the display shows (----). Speed:

The average speed mode shows the average vehicle speed since the last reset. Resetting is done by pushing the setting switch 쎻B for more than approximately 1 second. (The average fuel consumption is also reset at the same time.)

The display is updated every 30 seconds. The

Instruments and controls 2-9

墌 07.7.25/Z33-D/V5.0 墍

Display priority If a low outside air temperature warning, low dte (distance to empty) range warning and low tire pressure warning occur simul- taneously, other display modes switch au- tomatically to the outside air temperature display. When trip computer mode switch 쎻A is pressed, the display switches to the mode chosen before the warning display, but the ICY indicator will continue blinking.

first 30 seconds after a reset, the display shows (----). Elapsed time (h:m:s) and trip odometer (mls or km) Elapsed time:

The elapsed time mode shows the time since the last reset. The displayed time can be reset by pushing the trip computer setting switch 쎻B for more than approximately 1 second. (The trip odometer is also reset at the same time.) Trip odometer: The trip odometer mode shows the total dis- tance the vehicle has been driven since the last reset. Resetting is done by pushing the setting switch 쎻B for more than approximately 1 second. (The elapsed time is also reset at the same time.) Stopwatch (h:m:s) You can use the trip computer as a stopwatch. Each time the trip computer setting switch 쎻B is pushed, the stopwatch will be operated as fol- lows:

After 100 hours, the time will start from the reset display again. 2-10 Instruments and controls

Even if the display is switched to the other mode while the time is starting, the stopwatch contin- ues to advance until you stop the time in the stopwatch mode. When the ignition switch is turned to the OFF position, the time is reset. Up-shift indicator setting (rpm) (for manual transmission models) The up-shift indicator setting mode is used to set the desired engine speed (rpm) for the up-shift indicator (situated in the tachometer) to illuminate. When the engine speed approaches or reaches the set figure, the up-shift indicator will flash or illuminate to show the driver the timing for shifting into a higher gear. See “Driving the vehicle” in the “5. Starting and driving” section for the use of the up-shift indicator. When the up-shift indicator setting mode is selected, the rpm indicator blinks and the engine speed currently set (The initial factory setting is 7,500 rpm.) The figure can be changed between 2,000 and 9,000 rpm by pushing trip computer setting switch 쎻B . Press- ing the switch for less than approximately 1
second will add the figure by 100 rpm. If pushing for more than approximately 1 second, the figure will increase by 500 rpm. If the battery cable is disconnected, the set engine speed will be returned to the initial figure (7,500 rpm).

is displayed.

墌 07.7.25/Z33-D/V5.0 墍

WARNING/INDICATOR LIGHTS AND AUDIBLE REMINDERS

Anti-lock Braking System (ABS) warning light

Automatic transmission check warning light (A/T models)

Low washer fluid warning light

High beam indicator light (Blue)

Seat belt warning light

Malfunction Indicator Light (MIL)

Brake warning light

Supplemental air bag warning light

Slip indicator light

or

or

Charge warning light

Door open warning light

Engine oil pressure warning light

Automatic transmission position indicator light (A/T models) Cruise main switch indicator light (if so equipped) Cruise set switch indicator light (if so equipped)

Traction Control System (TCS) off indica- tor light (if so equipped) Vehicle Dynamic Control (VDC) off indi- cator light (if so equipped)

Soft top indicator light (Roadster models)

Low tire pressure warning light

Front passenger air bag status light

Turn signal/hazard indicator lights

CHECKING BULBS Apply the parking brake and turn the ignition key to ON without starting the engine. The following lights will come on:

or

The following lights come on briefly and then go off:

or

If any light fails to come on, it may indicate a burned-out bulb or an open circuit in the elec-

system. Have the system repaired

trical promptly. WARNING LIGHTS

or

Anti-lock Braking System (ABS) warning light

When the ignition switch is in the ON position, the Anti-lock Braking System (ABS) warning light illuminates and then turns off. This indicates the ABS is operational.

If the ABS warning light illuminates while the engine is running, or while driving, it may indicate the ABS is not functioning properly. Have the system checked by a NISSAN dealer. If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally, but without anti-lock assis- tance. See “Brake system” in the “5. Starting and driving” section.

Instruments and controls 2-11

墌 07.7.25/Z33-D/V5.0 墍

Automatic transmission check warning light (A/T models)

When the ignition switch is turned to the ON position, the automatic transmission check warning light comes on and then turns off. This indicates that the automatic transmission system is operational. If the light comes on while the engine is running or while driving, it may indicate that the auto- matic transmission system is not functioning properly. Have a NISSAN dealer check and repair the transmission.

or

Brake warning light

This light functions for both the parking brake and the foot brake systems. Parking brake indicator: When the ignition switch is in the ON position, the light comes on when the parking brake is applied. Low brake fluid warning light: The light warns of a low brake fluid level. If the light comes on while the engine is running with the parking brake not applied, stop the vehicle and perform the following: 1. Check the brake fluid level. Add brake fluid as necessary. See “Brake and clutch fluid” in the “8. Maintenance and do-it-yourself” section.

2-12 Instruments and controls

WARNING

쐌 Your brake system may not be work- ing properly if the warning light is on. Driving could be dangerous. If you judge it to be safe, drive carefully to the nearest service station for re- pairs. Otherwise, have your vehicle towed because driving it could be dangerous.

쐌 Pressing the brake pedal with the engine stopped and/or a low brake fluid level may increase your stop- ping distance and braking will re- quire greater pedal effort as well as pedal travel.

쐌 If the brake fluid level is below the MINIMUM or MIN mark on the brake fluid reservoir, do not drive until the brake system has been checked at a NISSAN dealer.

2.

If the brake fluid level is correct, have the warning system checked by a NISSAN dealer.

Anti-lock Braking System (ABS) warning indicator:

When the parking brake is released and the brake fluid level is sufficient, if both the brake warning light and the ABS warning light illumi- nate, it may indicate the ABS is not functioning properly. Have the brake system checked by a NISSAN dealer. See “Anti-lock Braking System (ABS) warning light” earlier in this section.

Charge warning light

If the light comes on while the engine is running, it may indicate that the charging system is not functioning properly. Turn the engine off and check the alternator belt. If the belt is loose, broken, missing or if the light remains on, see a NISSAN dealer immediately.

CAUTION

Do not continue driving if the belt is loose, broken or missing.

Door open warning light

This light comes on when any of the doors and/or rear hatch are not closed securely while the ignition switch is in the ON position.

墌 07.7.25/Z33-D/V5.0 墍

Engine oil pressure warning light

This light warns of low engine oil pressure. If the light flickers or comes on during normal driving, pull off the road in a safe area, stop the engine immediately and call a NISSAN dealer or other authorized repair shop. The engine oil pressure warning light is not designed to indicate a low oil level. Use the dipstick to check the oil level. See “Engine oil” in the “8. Maintenance and do-it-yourself” section.

CAUTION

Running the engine with the engine oil pressure warning light on could cause serious damage to the engine almost immediately. Turn off the engine as soon as it is safe to do so.

Low tire pressure warning light Your vehicle is equipped with a Tire Pressure Monitoring System (TPMS) that monitors the tire pressure of all tires except the spare.

The low tire pressure warning light warns of low

tire pressure or indicates that the TPMS is not functioning properly.

After the ignition switch is turned ON, this light illuminates for about 1 second and turns off. Low tire pressure warning:

If the vehicle is being driven with low tire pres- sure, the warning light will illuminate.

When the low tire pressure warning light illumi- nates, you should stop and adjust the tire pres- sure to the recommended COLD tire pressure shown on the Tire and Loading Information label. The low tire pressure warning light does not automatically turn off when the tire pressure is adjusted. After the tire is inflated to the recom- mended pressure, the vehicle must be driven at speeds above 16 MPH (25 km/h) to activate the TPMS and turn off the low tire pressure warning light. Use a tire pressure gauge to check the tire pressure. For additional information, see “Tire pressure monitoring system (TPMS)” in the “5. Starting and driving” section and in the “6. In case of emergency” section. TPMS malfunction: If the TPMS is not functioning properly, the low tire pressure warning light will flash for approxi- mately 1 minute when the ignition switch is

turned ON. The light will remain on after the 1
minute. Have the system checked by a NISSAN dealer.

For additional information, see “Tire pressure monitoring system (TPMS)” in the “5. Starting and driving” section.

WARNING

쐌 If the light does not illuminate with the ignition switch turned ON, have the vehicle checked by a NISSAN dealer as soon as possible.

쐌 If the light illuminates while driving, avoid sudden steering maneuvers or abrupt braking, reduce vehicle speed, pull off the road to a safe location and stop the vehicle as soon as pos- sible. Driving with under-inflated tires may permanently damage the tires and increase the likelihood of tire failure. Serious vehicle damage could occur and may lead to an acci- dent and could result in serious per- sonal injury. Check the tire pressure for all four tires. Adjust the tire pres-

Instruments and controls 2-13

墌 07.7.25/Z33-D/V5.0 墍

sure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light OFF. If the light stays on after adjusting the tire pressure and driving over 16
MPH (25 km/h), have the system checked by a NISSAN dealer. If you have a flat tire, replace it with a spare tire as soon as possible.

쐌 When a spare tire is mounted or a wheel is replaced, the TPMS will not function and the low tire pressure warning light will flash for approxi- mately 1 minute. The light will remain on after 1 minute. Contact your NISSAN dealer as soon as possible for tire replacement and/or system resetting.

쐌 Replacing tires with those not origi- nally specified by NISSAN could af- fect the TPMS.

the proper operation of

2-14 Instruments and controls

CAUTION

쐌 The TPMS is not a substitute for the regular tire pressure check. Be sure to check the tire pressure regularly.

쐌 If

the vehicle is being driven at speeds of less than 16 MPH (25
km/h), the TPMS may not operate correctly.

쐌 Be sure to install the specified size of

tires to the front and rear.

Low washer fluid warning light This light comes on when the washer fluid is at a low level. Add washer fluid as necessary. See “Window washer fluid” in the “8. Maintenance and do-it-yourself” section.

Seat belt warning light

The seat belt warning light and chime remind you to fasten seat belts. The light illuminates when- ever the ignition key is turned to ON, and will remain illuminated until the driver’s seat belt is fastened.

The seat belt warning light may also illuminate if

the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied. For 5 seconds after the ignition switch is in the ON position, the system does not activate the warn- ing light for the front passenger.

See “Seat belts” in the “1. Safety — Seats, seat belts and supplemental restraint system” section for precautions on seat belt usage.

Supplemental air bag warning light

After turning the ignition key to the ON position, the supplemental air bag warning light will illu- minate. The supplemental air bag warning light will turn off after about 7 seconds if the system is operational.

If any of the following conditions occur, the front air bag, side air bag (if so equipped) and curtain air bag (if so equipped), and pretensioner sys- tems need servicing and your vehicle must be taken to a NISSAN dealer. 쐌 The supplemental air bag warning light re-

mains on after approximately 7 seconds.

쐌 The supplemental air bag warning light

flashes intermittently.

쐌 The supplemental air bag warning light does

not come on at all.

墌 07.7.25/Z33-D/V5.0 墍

Unless checked and repaired, the supplemental restraint system (air bag system) and/or the pretensioners may not function properly. For additional information, see “Supplemental re- straint system” in the “1. Safety — Seats, seat belts and supplemental restraint system” sec- tion.

WARNING

If the supplemental air bag warning light is on, it could mean that the front air bag, side air bag, curtain air bag and/or pretensioner systems will not operate in an accident. To help avoid injury to yourself or others, have your vehicle checked by a NISSAN dealer as soon as possible.

INDICATOR LIGHTS

Automatic transmission position indicator light (A/T models)

When the ignition key is turned to the ON position, the indicator in the tachometer shows the automatic transmission selector lever posi- tion. See “Driving the vehicle” (automatic trans-

mission) in the “5. Starting and driving” section.

Cruise main switch indicator light (if so equipped)

The light comes on when the cruise control main switch is pushed. The light goes out when the main switch is pushed again. When the cruise main switch indicator light comes on, the cruise control system is operational.

Cruise set switch indicator light (if so equipped)

The light comes on while the vehicle speed is controlled by the cruise control system. If the light blinks while the engine is running, it may indicate the cruise control system is not func- tioning properly. Have the system checked by a NISSAN dealer.

Front passenger air bag status light

The front passenger air bag status light ) will be lit and the passenger front air bag will be OFF depending on how the front passen- ger seat is being used. For front passenger air bag status light opera- tion, see “NISSAN Advanced Air Bag System” in the “1. Safety — Seats, seat belts and supple- mental restraint system” section of this manual.

High beam indicator light (Blue)

This light comes on when the headlight high beam is on and goes out when the low beam is selected.

Malfunction Indicator Light (MIL)

If the Malfunction Indicator Light (MIL) comes on steady or blinks while the engine is running, it may indicate a potential emission control mal- function. The malfunction indicator light may also come on steady if the fuel-filler cap is loose or missing, or if the vehicle runs out of fuel. Check to make sure the fuel-filler cap is installed and closed tightly, and that the vehicle has at least 3 US gallons (14
liters) of fuel in the fuel tank. After a few driving trips, the light should turn off if no other potential emission control system malfunction exists. If this indicator light comes on steady for 20
seconds and then blinks for 10 seconds when the engine is not running, it indicates that the vehicle is not ready for an emission control system inspection/maintenance test. See “Readiness for inspection/maintenance (I/M) test” in the “9. Technical and consumer informa- Instruments and controls 2-15

墌 07.7.25/Z33-D/V5.0 墍

tion” section of this manual. Operation

The malfunction indicator light will come on in one of two ways: 쐌 Malfunction indicator light on steady — An emission control system malfunction has been detected. Check the fuel-filler cap. If the fuel-filler cap is loose or missing, tighten or the cap and continue to drive the install vehicle. The light should turn off after a few driving trips. If the light does not turn off after a few driving trips, have the vehicle inspected by a NISSAN dealer. You do not need to have your vehicle towed to the dealer.

쐌 Malfunction indicator light blinking — An en- gine misfire has been detected which may damage the emission control system. To re- duce or avoid emission control system dam- age: a) Do not drive at speeds above 45 MPH

(72 km/h).

b) Avoid hard acceleration or deceleration. c) Avoid steep uphill grades. d) If possible, reduce the amount of cargo

being hauled or towed. The malfunction indicator blinking and come on steady. 2-16 Instruments and controls

light may stop

Have the vehicle inspected by a NISSAN dealer. You do not need to have your vehicle towed to the dealer.

CAUTION

Continued vehicle operation without having the emission control system checked and repaired as necessary could lead to poor driveability, reduced fuel economy, and possible damage to the emission control system.

Slip indicator light

The light will blink when the Vehicle Dynamic Control (VDC) system or the Traction Control System (TCS) is operating, thus alerting the driver to the fact that the road surface is slippery and the vehicle is nearing its traction limits. This light also comes on when the ignition switch is turned to the ON position. The light will turn off if the VDC or TCS is operational.

Traction Control System (TCS) off indicator light (if so equipped)

The light comes on when the Traction Control System (TCS) off switch is pushed to OFF. This indicates the TCS is not operating.

This light also comes on when the ignition switch is turned to the ON position. The light will turn off if the TCS is operational.

When the TCS off indicator light and slip indi- cator light come on with the TCS turned on, this light alerts the driver to the fact that the system’s fail-safe mode is operating, that is the TCS may not be functioning properly. Have the system checked by a NISSAN dealer. If a malfunction occurs in the system, the traction control func- tion will be canceled but the vehicle is still driveable. For additional information, see “Trac- tion Control System (TCS)” in the “5. Starting and driving” section of this manual.

Vehicle Dynamic Control (VDC) off indicator light (if so equipped)

The light comes on when the Vehicle Dynamic Control (VDC) off switch is pushed to OFF. This indicates the VDC system and Traction Control System (TCS) are not operating.

墌 07.7.25/Z33-D/V5.0 墍

This light also comes on when the ignition switch is turned to the ON position. The light will turn off if the VDC system is operational. When the VDC off indicator light and slip indi- cator light come on with the VDC system turned on, this light alerts the driver to the fact that the system’s fail-safe mode is operating, that is the VDC system may not be functioning properly. Have the system checked by a NISSAN dealer. If a malfunction occurs in the system, the VDC system function will be canceled but the vehicle is still driveable. For additional information, see “Vehicle Dynamic Control (VDC) system” in the “5. Starting and driving” section of this manual.

Soft top indicator light (Roadster models)

This light illuminates when the soft top is being operated or it is stopped before reaching a full open/close state. When the top is fully opened, the light will turn off. When the top is fully closed, the light will flash. The soft top can be moved with the soft top operating switch only under all of the following conditions: 쐌 When the vehicle is stopped. 쐌 When the foot brake pedal is depressed. 쐌 When the ignition switch is ON.

CAUTION

Operate the soft top with the engine running to prevent a discharged battery.

When the soft top is in motion, and any of the above conditions are discontinued or the pas- senger power seat switches (on the cushion or the seatback) are operated, the top will stop moving. Remove your hand from the operating switch, and push it again under the above conditions until the top is fully opened or closed. The soft top indicator light will turn off when the top open operation is completely finished. When closing the top, the light, which is illuminated, will begin to flash when the top close operation is completely finished. Securely engage the top to the vehicle by operating the top latch lever. The light will turn off. If the soft top indicator light flashes with the ignition switch ON (whether the top is operated or not, and when the top is engaged), it may indicate the electric soft top control unit is not functioning properly. Have your vehicle checked by a NISSAN dealer as soon as possible. For more details about top the electric soft operation, see “Soft top” in the “3. Pre-driving checks and adjustments” section.

Turn signal/hazard indicator lights

The light flashes when the turn signal switch lever or hazard switch is turned on. AUDIBLE REMINDERS Key reminder chime The chime will sound if the driver’s side door is opened while the key is left in the ignition switch (ignition switch is turned off). Remove the key and take it with you when leaving the vehicle. Light reminder chime The chime will sound when the driver’s door is opened with the headlight switch on unless the key is in the ignition switch. Make sure to turn the light switch off when you leave the vehicle. Seat belt warning chime The chime will sound for about 6 seconds unless the driver’s seat belt is securely fastened. Brake pad wear warning The disc brake pads have audible wear warn- ings. When a brake pad requires replacement, it will make a high pitched scraping sound when the vehicle is in motion whether or not the brake pedal is depressed. Have the brakes checked as Instruments and controls 2-17

墌 07.7.25/Z33-D/V5.0 墍

soon as possible if the warning sound is heard.

SECURITY SYSTEMS

SIC2132

Your vehicle has two types of security systems, as follows: 쐌 Vehicle Security System 쐌 NISSAN Vehicle Immobilizer System The security condition will be shown by the security indicator light. VEHICLE SECURITY SYSTEM The vehicle security system provides visual and audible alarm signals if someone opens the doors or rear hatch/trunk lid when the system is armed. It is not, however, a motion detection type system that activates when a vehicle is

moved or when a vibration occurs. The system helps deter vehicle theft but cannot prevent it, nor can it prevent the theft of interior or exterior vehicle components in all situations. Always secure your vehicle even if parking for a brief period. Never leave your keys in the vehicle, and always lock the vehicle when unattended. Be aware of your surroundings, and park in secure, well-lit areas whenever possible. Many devices offering additional protection, such as component locks, identification markers, and tracking systems, are available at auto sup- ply stores and specialty shops. A NISSAN dealer may also offer such equipment. Check with your insurance company to see if you may be eligible for discounts for various theft protection fea- tures.

2-18 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

SIC1699A

Security indicator light This light 쎻A blinks whenever the ignition switch is in the LOCK, OFF or ACC position. This is normal. How to arm the vehicle security system 1. Close all windows. The system can be activated even if the windows are open.

2. Remove the key from the ignition switch.

3. Close and lock all doors and rear hatch/trunk

UNLOCK

button on the keyfob.

lid.

Lock all doors by using the key or the keyfob. When using the keyfob, the hazard indicators flash twice to indicate all doors are locked.

4. Confirm that

the security indicator

light comes on. The security indicator light glows for about 30 seconds and then blinks. The system is now activated. If, during this 30
second time period, the door is unlocked by the key or the keyfob, or the ignition key is turned to ACC or ON, the system will not activate.

Even when the driver and/or passengers are in the vehicle, the system will activate with all doors and rear hatch/trunk lid locked and ignition key off. Turn the igni- tion key to ACC to turn the system off. Vehicle security system activation The security system will give the following alarm: 쐌 The headlights blink and the horn sounds

intermittently.

쐌 The alarm automatically turns off after ap- proximately 50 seconds. However, the alarm reactivates if the vehicle is tampered with again. The alarm can be shut off by unlocking a door with the key, or by pushing the

The alarm is activated by: 쐌 Opening the door without using the key or

keyfob.

쐌 Opening the rear hatch or the trunk lid with-

out using the keyfob.

How to stop an activated alarm The alarm will stop only by unlocking a door with but- the key, or by pushing the UNLOCK ton on keyfob. The alarm will not stop if the ignition key is turned to ACC or ON. If the system does not operate as de- scribed above, have it checked by a NISSAN dealer. NISSAN VEHICLE IMMOBILIZER SYSTEM The NISSAN Vehicle Immobilizer System will not allow the engine to start without the use of the registered key.

If the engine fails to start using the registered key (for example, when interference is caused by another registered key, an automated toll road device or automated payment device on the key ring), restart the engine using the following procedures:

Instruments and controls 2-19

墌 07.7.25/Z33-D/V5.0 墍

1. Leave the ignition switch in the ON position

for approximately 5 seconds.

2. Turn the ignition switch to the OFF or LOCK position and wait approximately 10 seconds.

3. Repeat steps 1 and 2.

4. Restart the engine while holding the device (which may have caused the interference) separate from the registered key. If this procedure allows the engine to start, NISSAN recommends placing the registered key on a separate key ring to avoid interfer- ence from other devices.

Statement related to section 15 of FCC rules for NISSAN Vehicle Immobilizer Sys- tem (CONT ASSY-BCM, ANT ASSY- IMMOBILISER) This device complies with part 15 of the FCC Rules and RSS-210 of Industry Canada. Operation is subject to the follow- ing two conditions; (1) This device may not cause harmful in- terference, and (2) this device must accept any interference received, including inter- ference that may cause undesired opera- tion of the device. CHANGES OR MODIFICATIONS NOT EX- PRESSLY APPROVED BY THE PARTY RE- 2-20 Instruments and controls

SPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPER- ATE THE EQUIPMENT.

SIC1699A

Security indicator light This light 쎻A blinks whenever the ignition switch is in the LOCK, OFF or ACC position. This function indicates the security system equipped on the vehicle is operational.

If the NISSAN Vehicle Immobilizer System is malfunctioning, this light will remain on while the ignition switch is in the ON position. If the light still remains on and/or the engine will not start, see a NISSAN dealer for NISSAN Vehicle Immobilizer System service as soon as possible. Bring all reg- istered keys that you have when visiting a

墌 07.7.25/Z33-D/V5.0 墍

NISSAN dealer for service.

WINDSHIELD WIPER AND WASHER SWITCH

SIC2998

The windshield wiper and washer operates when the ignition switch is in the ON position.

Push the lever down to operate the wiper at the following speed: 쎻1 Intermittent (INT) — intermittent operation can be adjusted by turning the knob toward 쎻A (Slower) or 쎻B (Faster).

쎻2 Low (LO) — continuous low speed operation 쎻3 High (HI) — continuous high speed operation Push the lever up 쎻4
to have one sweep operation (MIST) of the wiper. Pull the lever toward you 쎻5

to operate the

washer. Then the wiper will also operate several times.

WARNING

In freezing temperatures the washer so- lution may freeze on the windshield and obscure your vision which may lead to an accident. Warm the windshield with the defroster before you wash the wind- shield.

CAUTION

쐌 Do not operate the washer continu-

ously for more than 30 seconds.

쐌 Do not operate the washer if the

reservoir tank is empty.

쐌 Do not fill the window washer reser- voir tank with washer fluid concen- trates at full strength. Some methyl alcohol based washer fluid concen- trates may permanently stain the grille if spilled while filling the win- dow washer reservoir tank.

Instruments and controls 2-21

墌 07.7.25/Z33-D/V5.0 墍

REAR WINDOW WIPER AND WASHER SWITCH (Coupe models)

쐌 Pre-mix washer fluid concentrates with water to the manufacturer’s rec- ommended levels before pouring the fluid into the window washer reser- voir tank. Do not use the window washer reservoir tank to mix the washer fluid concentrate and water.

SIC3297

The rear window wiper and washer operate when the ignition switch is in the ON position. Turn the switch clockwise from the OFF position to operate the wiper. 쎻1 Intermittent (INT) — intermittent operation

(not adjustable)

쎻2 Low (ON) — continuous low speed operation Push the switch forward 쎻3
to operate the washer. Then the wiper will also operate several times.

WARNING

In freezing temperatures the washer so- lution may freeze on the rear window and obscure your vision. Warm the rear window with the defroster before you wash the rear window.

CAUTION

쐌 If the rear window wiper operation is interrupted by snow or ice, the wiper may stop moving to protect its motor. If this occurs, turn the wiper switch to OFF and remove the snow or ice on and around the wiper arms. After about 1 minute, turn the switch ON again to operate the wiper.

쐌 Do not operate the washer continu-

ously for more than 30 seconds.

쐌 Do not operate the washer if the

reservoir tank is empty.

쐌 Do not fill the window washer reser-

2-22 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

voir tank with washer fluid concen- trates at full strength. Some methyl alcohol based washer fluid concen- trates may permanently stain the grille if spilled while filling the win- dow washer reservoir tank.

쐌 Pre-mix washer fluid concentrates with water to the manufacturer’s rec- ommended levels before pouring the fluid into the window washer reser- voir tank. Do not use the window washer reservoir tank to mix the washer fluid concentrate and water.

REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH

froster.

쐌 Do not use the rear window defroster switch while the soft top is being operated or fully opened. The heat may damage the top material and/or components. (for Roadster models)

SIC3000

To defog/defrost the rear window glass and outside mirrors, start the engine and push the switch on. The indicator light 쎻A will come on. Push the switch again to turn the defroster off.

It will automatically turn off in approximately 15
minutes.

CAUTION

쐌 When cleaning the inner side of the rear window, be careful not to scratch or damage the rear window de-

Instruments and controls 2-23

墌 07.7.25/Z33-D/V5.0 墍

HEADLIGHT AND TURN SIGNAL SWITCH XENON HEADLIGHTS

WARNING

HIGH VOLTAGE

쐌 When xenon headlights are on, they produce a high voltage. To prevent an electric shock, never attempt to modify or disassemble. Always have your xenon headlights replaced at a NISSAN dealer.

쐌 Xenon headlights provide consider- ably more light than conventional headlights. If they are not correctly aimed, they might temporarily blind an oncoming driver or the driver ahead of you and cause a serious accident. If headlights are not aimed correctly, immediately take your ve- hicle to a NISSAN dealer and have the headlights adjusted correctly.

When the xenon headlight is initially turned on, its brightness or color varies slightly. However, the color and brightness will soon stabilize.

2-24 Instruments and controls

쐌 The life of xenon headlights will be shortened by frequent on-off operation. It is generally desirable not to turn off the headlights for short intervals (for example, when the vehicle stops at a traffic signal). Even when the daytime running lights are active (Canada only), the xenon headlights do not turn on. This way the life of the xenon headlights is not reduced.

쐌 If the xenon headlight bulb is close to burning out, the brightness will drasti- cally decrease, the light will start blink- ing, or the color of the light will become reddish. If one or more of the above signs appear, contact a NISSAN dealer. HEADLIGHT SWITCH

SIC3291

Lighting 쎻1 Turn the switch to the

position:

The front park, side marker, tail, license plate and instrument lights will come on.

쎻2 Turn the switch to the

position:

Headlights will come on and all the other lights remain on.

墌 07.7.25/Z33-D/V5.0 墍

CAUTION

Use the headlights with the engine run- ning to avoid discharging the vehicle battery.

turn off 5 minutes after the ignition switch has been turned to the OFF position.

쐌 After the headlights automatically turn off with the headlight switch in the po- sition, the headlights will illuminate again for 5
minutes if the headlight switch is turned to the OFF position and then turned to the

or

or

position.

CAUTION

Even though the battery saver feature automatically turns off the headlights after a period of time, you should turn the headlight switch to the OFF position when the engine is not running to avoid discharging the vehicle battery.

DAYTIME RUNNING LIGHT SYSTEM (Canada only) The headlights (low beam) automatically illumi- nate when the engine is started with the parking brake released. The daytime running lights op- erate with the headlight switch in the OFF position or in the If the parking brake is applied before the engine is started, the daytime running lights do not Instruments and controls 2-25

position.

SIC3315

Headlight beam select 쎻1 To select the high beam, push the lever forward. The high beam lights come on and illumi- the high beam indicator light nates.

쎻2 Pull the lever back to select the low beam. 쎻3 Pulling the lever toward you will flash the

headlight high beam. Battery saver system 쐌 When the headlight switch is in the

or position while the ignition switch is in the ON position, the lights will automatically

墌 07.7.25/Z33-D/V5.0 墍

illuminate. The daytime running lights illuminate once the parking brake is released. The daytime running lights will remain on until the ignition switch is turned off.

SIC3316

SIC3001

TURN SIGNAL SWITCH 쎻1 Turn signal Move the lever up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically. 쎻2 Lane change signal To indicate a lane change, move the lever up or down to the point where lights begin flashing.

INSTRUMENT BRIGHTNESS CONTROL The instrument brightness control operates when the light switch is in the or position and the ignition switch is in the

ON position. To adjust the brightness of instrument panel lights, press the control switches located on the left side of the meter panel. Pressing the upper switch 쎻A will brighten the lights. The lower switch 쎻B will dim the lights. Repeatedly press- ing the lower switch will turn the lights off.

2-26 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

HAZARD WARNING FLASHER SWITCH

HORN

쐌 Do not use the hazard warning flash- ers while moving on the highway un- less unusual circumstances force you to drive so slowly that your vehicle might become a hazard to other traf- fic.

쐌 Turn signals do not work when the hazard warning flasher lights are on.

The flasher will operate with the ignition switch in any position.

SIC2475

Push the switch (located on the front part of the center console) on to warn other drivers when you must stop or park under emergency condi- tions. All turn signal lights will flash. Some state or provincial laws may prohibit the use of the hazard warning flasher switch while driving.

WARNING

쐌 If stopping for an emergency, be sure to move the vehicle well off the road.

To sound the horn, push the center pad area of the steering wheel.

SIC2195

WARNING

Do not disassemble the horn. Doing so could affect proper operation of the supplemental front air bag system. Tam- pering with the supplemental front air bag system may result in serious per- sonal injury.

Instruments and controls 2-27

墌 07.7.25/Z33-D/V5.0 墍

HEATED SEATS (if so equipped)

The seats are warmed by built-in heaters. The switches are located on the center console.

SIC3002

1. Start the engine.

2. Select heat range.

쎻1 For high heat, push the

of the switch.

쎻2 For low heat, push the

the switch.

(High) side

(Low) side of

쎻3 For no heat, the switch has a center OFF

position between low and high.

The indicator illuminate when low or high is selected.

in the switch will

light 쎻A

on the seat or pierce it with a pin or similar object. This may result in damage to the heater.

쐌 Any liquid spilled on the heated seat should be removed immediately with a dry cloth.

쐌 When cleaning the seat, never use thinner, or any

gasoline, benzine, similar materials.

쐌 If any abnormalities are found or the heated seat does not operate, turn the switch off and have the system checked by a NISSAN dealer.

The heater is controlled by a thermostat, automatically turning the heater on and off. The indicator light will remain on as long as the switch is on.

3. When the vehicle’s interior is warmed, or before you leave the vehicle, be sure to turn the switch to the OFF position 쎻3 .

An optional ventilated net seat has this built-in heater only in the seat cushion part, not in the seatback.

CAUTION

쐌 The battery could be discharged if the seat heater is operated while the engine is not running.

쐌 Do not use the seat heater for ex- tended periods or when no one is using the seat.

쐌 Do not put anything on the seat which insulates heat, such as a blan- ket, cushion, seat cover, etc. Other- wise, the seat may become over- heated.

쐌 Do not place anything hard or heavy

2-28 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH (if so equipped)

TRACTION CONTROL SYSTEM (TCS) OFF SWITCH (if so equipped)

engine to turn on the system. See “Vehicle Dynamic Control (VDC) system” in the “5. Start- ing and driving” section.

SIC1881

The vehicle should be driven with the Vehicle Dynamic Control (VDC) system on for most driving conditions. If the vehicle is stuck in mud or snow, the VDC system reduces the engine output to reduce wheel spin. The engine speed will be reduced even if the accelerator is depressed to the floor. If maximum engine power is needed to free a stuck vehicle, turn the VDC system off. To turn off the VDC system, push the VDC OFF switch (located on the lower side of the instru- ment panel). The indicator light will come on. Push the VDC OFF switch again or restart the

SIC1967

The vehicle should be driven with the Traction Control System (TCS) on for most driving con- ditions.

If the vehicle is stuck in mud or snow, the TCS reduces the engine output to reduce wheel spin. The engine speed will be reduced even if the accelerator is depressed to the floor. If maximum engine power is needed to free a stuck vehicle, turn the TCS off.

To turn off the TCS, push the TCS OFF switch (located on the lower side of the instrument indicator light will come on. panel). The Push it again or restart the engine to turn the system back on.

Instruments and controls 2-29

墌 07.7.25/Z33-D/V5.0 墍

See “Traction Control System (TCS)” in the “5. Starting and driving” section.

CLOCK

The digital clock (in the audio unit) displays time when the ignition switch is in the ACC or ON position. If the battery cable is disconnected, the clock will reset its time and the correct time will not be indicated. Readjust the time.

SIC3003

ADJUSTING THE TIME Adjust the time in the following steps:

1. Switch the display to the clock adjusting

mode. Type A (audio with 1 CD player): Push and hold the DISP (Clock) button 쎻A until the clock display starts to flash. Type B (audio with 6 CD changer): Push and hold the RPT button 쎻B until the clock display starts to flash.

2. Push the SEEK/TRACK button 쎻C (

) to adjust the hour. Push the TUNE the

button 쎻D

to adjust

2-30 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

POWER OUTLET

or

side will side

or

minute. Pushing the advance the time and the will turn back the time.

3. Push the DISP button 쎻A (Type A), or RPT 쎻B button (Type B) to finish the adjustment.

Resetting Type A (audio with 1 CD player): Push the DISP 쎻A and TUNE 쎻D buttons. Type B (audio with 6 CD changer): Push the RPT 쎻B and TUNE 쎻D buttons. The time will be set to a time signal. For example, if these buttons are pushed while the time is between 8:00 and 8:29, the display will be reset is between 8:30 and 8:59, the display will be reset to 9:00. At the same time the display will return to the previous audio mode.

If pushed while it

to 8:00.

The power outlet is for powering electrical ac- cessories such as cellular telephones.

Front

SIC2258

CAUTION

쐌 The outlet and plug may be hot dur-

ing or immediately after use.

쐌 This power outlet is not designed for

use with a cigarette lighter unit.

쐌 Do not use accessories that exceed a combined power draw of 12 volt, 120W (10A) for both the front and

Rear

SIC1968

rear power outlets. Do not use double adapters or more than one accessory with a single power outlet. 쐌 Use power outlet with the engine running to avoid discharging the ve- hicle battery.

쐌 Avoid using power outlets when the air conditioner, headlights or rear window defroster is on.

쐌 Before inserting or disconnecting a plug, be sure to turn off the power switch of electrical accessory being

Instruments and controls 2-31

墌 07.7.25/Z33-D/V5.0 墍

STORAGE

used or the ACC power of the vehicle. 쐌 Push the plug in as far as it will go. If good contact is not made, the plug may overheat or the internal tem- perature fuse may open.

쐌 Do not allow water to contact the outlet. When not in use, be sure to close the lid.

SIC3004

SIC2317

INSTRUMENT POCKET (except for navigation system equipped models) To open the lid, push the knob up 쎻1 . To close, pull the lid down 쎻2 .

SUNGLASSES HOLDER (Coupe models) The sunglasses holder can be opened by push- ing the button 쎻A .

WARNING

Keep the pocket lid closed while driving to help prevent injury in an accident or a sudden stop.

WARNING

Keep the sunglasses holder closed while driving to prevent an accident.

2-32 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

CAUTION

쐌 Do not use for anything other than

glasses.

쐌 Do not leave sunglasses in the sun- glasses holder while parking in direct sunlight. The heat may damage the sunglasses.

involved in a collision.

쐌 The cargo restrained in the net must not exceed 4 lb (2 kg) or the net may not stay secured.

CUP HOLDERS

CAUTION

쐌 Avoid abrupt starting and braking when the cup holder is being used to prevent spilling the drink. If the liquid is hot, it can scald you or your pas- senger.

쐌 Use only soft cups in the cup holder. Hard objects can injure you in an accident.

SIC3006

located under

CARGO NET The net the instrument panel (passenger’s side) can be used to hold small objects. The net can be removed when necessary.

WARNING

쐌 Do not place sharp objects in the net. Such objects may become dangerous projectiles and cause injury when the vehicle is moving or if the vehicle is

Instruments and controls 2-33

墌 07.7.25/Z33-D/V5.0 墍

SIC3007

SIC3384

SIC3008

Front Type A: To open the cup holder, slide the lid 쎻1 . Install the partition plate into the slit 쎻2 .

2-34 Instruments and controls

Type B: Larger containers can be placed in the console box. Push the button 쎻1 to open the console box lid. The partition 쎻A can be removed.

Soft bottle holder

CAUTION

쐌 Do not use bottle holder for any other objects that could be thrown about in the vehicle and possibly injure people during sudden braking or an accident.

쐌 Do not use bottle holder for open

liquid containers.

墌 07.7.25/Z33-D/V5.0 墍

SIC3385

SIC3010

CONSOLE BOX Pushing the button 쎻1 will open the lid slightly, then pull up the lid manually 쎻2 . The center console box is equipped with a card holder 쎻A . The inside tray (cup holder and partitions) can be removed by pulling it up.

If objects (coins, etc.) fall into the rear section of the center console box, remove the rear wall 쎻B of the box as shown, and pick up the objects.

CAUTION

Be careful not to pinch your fingers when removing the rear wall 쎻B .

SSS0203

Coupe model

REAR FLOOR BOX The rear floor box is located behind the passen- ger’s seat. Fold the passenger’s seatback forward to ac- cess the rear floor box. Coupe model: Pull on the lever 쎻A . Roadster model: Push the upper portion of the power seatback tilt switch 쎻B .

Instruments and controls 2-35

墌 07.7.25/Z33-D/V5.0 墍

SIC3348

Roadster model

Return the passenger’s seatback to a locked position after using the rear floor box. Coupe model: Pull up on the lever 쎻A and return the seatback. Roadster model: Push the lower portion of the power seatback tilt switch 쎻B . 2-36 Instruments and controls

SIC1975A

SIC2377

The rear floor box may be opened by pulling the handle. The rear floor box light illuminates when the box lid is opened with the headlight switch ON. When locking 쎻1 or unlocking 쎻2 the rear floor box, use the master key.

The rear floor box has additional space under the bottom plate.

WARNING

Keep rear floor box lid closed while driving to help prevent injury in an acci- dent or a sudden stop.

墌 07.7.25/Z33-D/V5.0 墍

STOWING GOLF BAGS Follow the instructions here to stow golf bags in the rear cargo space of your vehicle. Normally two bags can be stowed in the luggage area (Coupe models) or one bag in the trunk (Road- ster models). However, in some cases you may not be able to stow the above number of golf bags in your vehicle, depending on their sizes or types.

SIC1977

REAR PARCEL BOX Push the upper part of the lid to open the rear parcel box. For models without the Navigation system, two boxes are available.

WARNING

Keep rear parcel box lid closed while driving to help prevent injury in an acci- dent or a sudden stop.

SIC2196

Coupe models Normally, two standard golf bags can be stowed across the strut tower bar in the luggage area as illustrated (A and B). When stowing a golf bag A in the rear space, insert the top of the golf bag

Instruments and controls 2-37

墌 07.7.25/Z33-D/V5.0 墍

into left side of the luggage area 쎻1 then put the bag down 쎻2 .

SIC2378

COAT HOOK (Coupe models) The hooks are locked above the side windows as shown in the illustration.

CAUTION

Do not apply a total load of more than 2
lb (1 kg) to a single hook.

SIC2237

Roadster models Normally, one standard golf bag C can be stowed in the trunk. Insert the top of the golf bag into left side of the trunk 쎻1 then put the bag down 쎻2 .

2-38 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

WINDOWS

POWER WINDOWS

WARNING

쐌 Make sure that all passengers have their hands, etc. inside the vehicle while it is in motion and before clos- ing the windows. Use the window lock switch to prevent unexpected use of the power windows.

쐌 Do not leave children unattended in- side the vehicle. They could unknow- ingly activate switches or controls and become trapped in a window. Unattended children could become involved in serious accidents.

The power windows operate when the ignition key is in the ON position and for about 45
seconds, after the ignition key is turned to the OFF position. If the driver’s door or the front passenger’s door is opened during this period of about 45 seconds, power to the windows is canceled. The power window switches will be deactivated during the soft top operation. (Roadster models)

SIC3286

Driver’s side power window switch 1. Driver side window 2. Passenger side window 3. Window lock button To open or close the window, push down 쎻A or pull up 쎻B the switch and hold it. The main switch (driver side switches) will open or close all the windows.

SIC3287
Passenger side power window switch The passenger side switch will open or close only the corresponding window. To open or close the window, hold the switch down or up. Locking passenger’s window When the lock button 쎻C is pushed in, only the driver side window can be opened or closed. Push it in again to cancel.

Instruments and controls 2-39

墌 07.7.25/Z33-D/V5.0 墍

AUTOMATIC ADJUSTING FUNCTION

CAUTION

When the battery cable is removed from the battery terminal, do not close either of the front doors. The automatic win- dow adjusting function will not work, and the side roof panel/top side rail may be damaged.

The power window has an automatic adjusting function. When the door is being opened, the window is automatically lowered slightly to avoid contact between the window and the side roof panel/top side rail. When the door is closed, the window is automatically raised slightly.

45 seconds after the ignition key is turned to the OFF position. Depending on the environment or driving conditions, the auto reverse function may be activated if an impact or load similar to something being caught in the window occurs.

WARNING

There are some small distances imme- diately before the closed position which cannot be detected. Make sure that all passengers have their hands, etc., in- side the vehicle before closing the win- dow.

Automatic window lowering (Roadster models) When the soft top operating switch is pressed, the power windows will automatically be low- ered completely. The windows do not rise auto- matically after the soft top open/close operation is completed. Use the power window switches to raise them.

墌 07.7.25/Z33-D/V5.0 墍

SIC3288

Automatic operation To fully open or close the window, completely press or lift the switch and release it; it need not be held. The window will automatically open or close all the way. To stop the window, just press or lift the switch on the opposite side. Auto reverse function If the control unit detects something caught in a window as it moves up, the window will be immediately lowered. The auto reverse function can be activated when a window is closed by automatic operation when the ignition key is in the ON position or for about 2-40 Instruments and controls

INTERIOR LIGHTS

SIC1980A

Coupe models

ROOM LIGHT The interior light has a two-position switch. (쎻A : DOOR, 쎻B : OFF) When the switch is in the DOOR position, the light will illuminate when a door is opened.

The light will stay on for about 30 seconds when: 쐌 The doors are unlocked by the keyfob, a key or the power door lock switch while all doors are closed.

쐌 The driver’s door is opened and then closed while the key is removed from the ignition switch.

SIC2238
쐌 The key is removed from the ignition switch

Roadster models

while all doors are closed.

The interior light will turn off while the 30 second timer is activated, when: 쐌 The driver’s door is locked either with the keyfob, a key or the power door lock switch.

쐌 The ignition switch is turned ON. MAP LIGHTS To turn on the light, push the plastic surface 쎻C of the light. Push it again to turn off the light. When the map light stays on, it will auto- matically turn off 30 minutes after the

ignition switch has been turned to the OFF position. To turn on the light again, turn the ignition switch to the ON position. The map and vanity mirror lights will automati- cally turn off 30 minutes after the latest operation of the following with the ignition switch in the ACC or OFF position: 쐌 Opening or closing any door 쐌 Locking or unlocking with the keyfob, a key or

the power door lock switch

쐌 Inserting or removing a key from the ignition

switch

These lights will turn on again when any of the above operations is performed after the lights have turned off automatically. (The lights will turn off 30 minutes after the latest operation of the above as well.)

CAUTION

쐌 Turn off the lights when you leave the

vehicle.

쐌 Do not use for extended periods of time with the engine stopped. This could result in a discharged battery.

Instruments and controls 2-41

墌 07.7.25/Z33-D/V5.0 墍

VANITY MIRROR LIGHT

LUGGAGE COMPARTMENT LIGHT (Coupe models) The light illuminates when the rear hatch is opened. When the rear hatch is closed, the light will go off.

TRUNK LIGHT (Roadster models)

The light illuminates when the trunk lid is opened. When the trunk lid is closed, the light will go off.

SIC1859

The light on the vanity mirror will turn on when the cover on the vanity mirror is opened. When the vanity mirror light stays on, it will automatically turn off 30 minutes after the ignition switch has been turned to the OFF position. To turn on the light again, turn the ignition switch to the ON position.

2-42 Instruments and controls

墌 07.7.25/Z33-D/V5.0 墍

HomeLink UNIVERSAL TRANSCEIVER (if so equipped) The HomeLink Universal Transceiver provides a convenient way to consolidate the functions of up to three individual hand-held transmitters into one built-in device. HomeLink Universal Transceiver: 쐌 Will operate most Radio Frequency (RF) devices such as garage doors, gates, home and office lighting, entry door locks and se- curity systems.

쐌 Is powered by your vehicle’s battery. No separate batteries are required. If the vehi- cle’s battery is discharged or is discon- nected, HomeLink will retain all program- ming.

Once the HomeLink Universal Transceiver is programmed, retain the original trans- mitter for future programming procedures (for example, new vehicle purchases). Upon sale of the vehicle, the programmed HomeLink Universal Transceiver buttons should be erased for security purposes. For additional information, refer to “Pro- gramming HomeLink ” later in this sec- tion.

WARNING

쐌 Do not use the HomeLink Universal Transceiver with any garage door opener that lacks safety stop and reverse features as required by fed- eral safety standards. (These stan- dards became effective for opener models manufactured after April 1, 1982). A garage door opener which cannot detect an object in the path of a closing garage door and then auto- matically stop and reverse, does not meet current federal safety stan- dards. Using a garage door opener without these features increases the risk of serious injury or death.

쐌 Your vehicle’s engine should be turned off while programming the HomeLink Universal Transceiver.

PROGRAMMING HomeLink To program your HomeLink Transceiver to op-
