2005 Honda Odyssey Owners Manual

Of course, children vary widely. And while age may be one indicator of when a child can safely ride in the front, there are other important factors you should consider.

54

PhysicalSize Physically, a child must be large enough for the lap/shoulder belt to properly fit (see page belt does not fit properly, with or without the child sitting on a booster seat, the child should not sit in front.

). If the seat

52

Maturity To safely ride in front, a child must be able to follow the rules, including sitting properly, and wearing the seat belt properly throughout a ride.

If you decide that a child can safely ride up front, be sure to:

Carefully read the owner’s manual, and make sure you understand all seat belt instructions and all safety information.

Move the vehicle seat to the rear- most position.

Have the child sit up straight, back against the seat, and feet on or near the floor.

Check that the child’s seat belt is properly and securely positioned.

Supervise the child. Even mature children sometimes need to be reminded to fasten the seat belts or sit properly.

Information Provided by:Additional Safety Precautions Donotletachildwearaseatbelt This could result in acrosstheneck. serious neck injuries during a crash.

Donotletachildputtheshoulder partofaseatbeltbehindthebackor underthearm. very serious injuries during a crash. It also increases the chance that the child will slide under the belt in a crash and be injured.

This could cause

Donotputanyaccessoriesonaseat Devices intended to improve a belt. child’s comfort or reposition the shoulder part of a seat belt can make the belt less effective and increase the chance of serious injury in a crash.

Protecting Larger Children

55

Information Provided by:Carbon monoxide gas is toxic. Breathing it can cause unconsciousness and even kill you.

Avoid any enclosed areas or activities that expose you to carbon monoxide.

High levels of carbon monoxide can collect rapidly in enclosed areas, such as a garage. Do not run the engine with the garage door closed. Even with the door open, run the engine only long enough to move the vehicle out of the garage.

With the tailgate open, air flow can pull exhaust gas into your vehicle’s interior and create a hazardous condition. If you must drive with the tailgate open, open all the windows and set the heating and cooling system/climate control system as shown below.

If you must sit in your parked vehicle, even in an unconfined area, adjust the heating and cooling system/ climate control system as follows:

1. 2. 3. 4.

Select the fresh air mode. Select the Turn the fan on high speed. Set the temperature control to a comfortable setting.

mode.

Carbon Monoxide Hazard

Your vehicle’s exhaust contains carbon monoxide gas. You should have no problem with carbon monoxide entering the vehicle in normal driving if you maintain your vehicle properly.

Have the exhaust system inspected for leaks whenever:

The vehicle is raised for an oil change.

You notice a change in the sound of the exhaust.

The vehicle was in an accident that may have damaged the underside.

56

Information Provided by:These labels are in the locations shown. They warn you of potential hazards that could cause serious injury. Read these labels carefully.

If a label comes off or becomes hard to read (except for the U.S. dashboard label which is removed by the owner), contact your dealer for a replacement. HOOD

Safety Labels

DASHBOARD U.S.modelsonly

RADIATOR CAP

CONTINUED

57

Information Provided by:Safety Labels

SUN VISOR U.S.models

Canadianmodels

DOORJAMB U.S.models

Canadianmodels

58

Information Provided by:This section gives information about the controls and displays that contribute to the daily operation of your vehicle. All the essential controls are within easy reach.

Control Locations

...........................

. 60

Instrument Panel Instrument Panel Indicators Gauges Multi-Information Display Controls Near the Steering

............................ .......... ............................................. .............

. 61
. 63
. 71
. 74

Wheel

.........................................

. 120

Windshield Wipers and

Washers

.....................................

. 121

Rear Window Wiper and

Washer

Turn Signal and Headlights Instrument Panel Brightness Hazard Warning Button Rear Window Defogger Steering Wheel Adjustment Keys and Locks Immobilizer System Ignition Switch Remote Transmitter Door Locks

....................................... ......... ...... ............... ............... ........ ............................. ...................... .............................. ..................... .................................... .................... ............ ...................................... .......................... ................................. ...............................................

Power Door Locks Childproof Door Locks Tailgate Power Tailgate

Sliding Doors Seats

. 122
. 122
. 125
. 126
. 126
. 127
. 128
. 129
. 130
. 131
. 137
. 137
. 138
. 138
. 139
. 142
. 148

Instruments and Controls

. 160

Seat Heaters Driver’s Seat Position Memory

..................................

System

. 161
........................................ . 163
............................ Power Windows . 166
....................................... Moonroof . 167
........................................... Mirrors Parking Brake ............................... . 169
Adjustable Driver’s Foot Pedals . 169
. 170
Interior Convenience Items ......... . 171
Retractable Center Tray .......... ..................... Beverage Holders . 171
. 173
Integrated Sunshade ................ . 174
Sunglasses Holder .................... . 174
Conversation Mirror ................ . 175
Sun Visor ................................... ............................ Vanity Mirror . 175
Rear Compartment . 175
................... Removable Second Row

Console

In-Floor Storage Area Lower Glove Box Upper Glove Box Center Pocket Accessory Power Sockets AC Power Outlet

.................................. ............... ...................... ...................... ........................... ........ ....................... ...............................

. 176
. 177
. 180
. 180
. 181
. 182
. 182
. 183

Interior Lights

59

Information Provided by:Control Locations

INSTRUMENT PANEL INDICATORS GAUGES (P.71)

(P.61, 62)

MIRROR CONTROLS (P.168)

POWER DOOR LOCK SWITCHES (P.137)

POWER WINDOW SWITCHES (P.163)

FUEL FILL DOOR RELEASE (P.279)

SHIFT LEVER (P.294)

HEATING AND COOLING SYSTEM/ CLIMATE CONTROL SYSTEM

(P.188)

SEAT HEATER SWITCHES (P.160)

GLOVE BOXES (P.180)

AUDIO SYSTEM/ REAR ENTERTAINMENT SYSTEM (P.199, 230)

HOOD RELEASE HANDLE (P.280)

PARKING BRAKE PEDAL (P.169)

ACCESSORY POWER SOCKETS (P.182)

CENTER TRAY (P.171)

60

Information Provided by:Instrument Panel

VEHICLE STABILITY ASSIST SYSTEM INDICATOR (P.65)

CRUISE CONTROL MAIN INDICATOR (P.69) CRUISE CONTROL INDICATOR (P.69)

ANTI-LOCK BRAKE SYSTEM INDICATOR (P.65) LOW FUEL INDICATOR (P.68) DOOR AND TAILGATE OPEN INDICATOR (P.67)

SIDE AIRBAG OFF INDICATOR ＊ (P.64)

(LX and EX models)

IMMOBILIZER SYSTEM INDICATOR (P.67)

POWER SLIDING DOOR INDICATOR (P.67)

VSA ACTIVATION INDICATOR (P.65)

LIGHTS-ON INDICATOR (P.66)

FUEL ECONOMY (P.70) INDICATOR

CHARGING SYSTEM INDICATOR (P.63)

MALFUNCTION INDICATOR LAMP (P.372)

MAINTENANCE MINDER INDICATOR (P.70)

LOW OIL PRESSURE INDICATOR (P.63)

SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR (P.64)

SEAT BELT REMINDER INDICATOR (P.64)

HIGH BEAM INDICATOR (P.69)

PARKING BRAKE AND BRAKE SYSTEM INDICATOR ＊ (P.63)

＊

The U.S. instrument panel is shown. Differences for the Canadian models are noted in the text.

61

Information Provided by:Instrument Panel

(Touring models)

CHARGING SYSTEM INDICATOR (P.63) FOG LIGHT INDICATOR (P.69)

FUEL ECONOMY INDICATOR (P.70)

LIGHTS-ON INDICATOR (P.66)

IMMOBILIZER SYSTEM INDICATOR (P.67)

VSA ACTIVATION INDICATOR (P.65)

VEHICLE STABILITY ASSIST SYSTEM INDICATOR (P.65)

CRUISE CONTROL MAIN INDICATOR (P.69) LOW TIRE PRESSURE INDICATOR (P.66) CRUISE CONTROL INDICATOR (P.69) ANTI-LOCK BRAKE SYSTEM INDICATOR (P.65) DOOR AND TAILGATE OPEN INDICATOR (P.67) LOW FUEL INDICATOR (P.68)

MALFUNCTION INDICATOR LAMP (P.372)

SYSTEM MESSAGE INDICATOR (P.70)

LOW OIL PRESSURE INDICATOR (P.63)

HIGH BEAM INDICATOR (P.69)

PARKING BRAKE AND BRAKE SYSTEM INDICATOR ＊

(P.63)

SIDE AIRBAG OFF INDICATOR (P.64)

＊

SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR (P.64)

SEAT BELT REMINDER INDICATOR (P.64)

＊

The U.S. instrument panel is shown. Differences for the Canadian models are noted in the text.

62

Information Provided by:The instrument panel has many indicators to give you important information about your vehicle.

Malfunction Indicator Lamp 372

See page

Low Oil Pressure Indicator

The engine can be severely damaged if this indicator flashes or stays on when the engine is running. For more information, see page 371
On the Touring model, you will also see a ‘‘CHECK ENGINE OIL LEVEL’’ message in the multi- information display.

Charging System Indicator

If this indicator comes on when the engine is running, the battery is not being charged. For more information, see page On the Touring model, you will also see a ‘‘CHECK CHARGING SYSTEM’’ message in the multi- information display.

371

U.S.

Canada

Parking Brake and Brake System Indicator

This indicator has two functions: It comes on when you turn the 1. ignition switch to ON (II). It is a reminder to check the parking brake. Driving with the parking brake not fully released can damage the brakes and tires.

Instrument Panel Indicators

2.

If it stays on after you fully release the parking brake while the engine is running, or if it comes on while driving, there could be a problem with the brake system. For more information, see page

373

If you drive without releasing the parking brake, a chime will sound. On the Touring model, you will also see a ‘‘RELEASE PARKING BRAKE’’ message in the multi- information display.

63

Information Provided by:Instrument Panel Indicators

Seat Belt Reminder Indicator

This indicator comes on when you turn the ignition switch to ON (II). It reminds you and your passengers to fasten your seat belts. A beeper also sounds if you have not fastened your seat belt.

If you turn the ignition switch to ON (II) before fastening your belt, the beeper sounds and the indicator flashes. If you do not fasten your seat belt before the beeper stops, the indicator stops flashing but remains on.

If you continue driving without fastening your seat belt, the beeper sounds and the indicator flashes again at regular intervals. On the Touring model, you will also see a ‘‘FASTEN SEAT BELT’’ message in the multi-information display.

64

Supplemental Restraint System Indicator

This indicator comes on briefly when you turn the ignition switch to ON (II). If it comes on at any other time, it indicates a potential problem with your front airbags. This indicator will also alert you to a potential problem with your side airbags, passenger’s side airbag automatic cutoff system, side curtain airbags, automatic seat belt tensioners, driver’s seat position sensor, or the front passenger’s weight sensors. For more information, see page 32

On the Touring model, you will also see a ‘‘CHECK AIRBAG SYSTEM’’ message in the multi-information display.

U.S.

Canada

Side Airbag Off Indicator

This indicator comes on when you turn the ignition switch to ON (II). If it comes on at any other time, it indicates that the passenger’s side airbag has automatically shut off. For more information, see page 33

On the Touring model, you will also see a ‘‘PASSENGER SIDE AIRBAG OFF’’ message in the multi- information display.

Information Provided by:Anti-lock Brake System (ABS) Indicator

This indicator normally comes on for a few seconds when you turn the ignition switch to ON (II), and when the ignition switch is turned to START (III). If it comes on at any other time, there is a problem in the ABS; have your vehicle checked at a dealer. With the ABS indicator on, your vehicle still has normal braking ability but no anti-lock braking. For more information, see page

300

On the Touring model, you will also see a ‘‘CHECK ABS SYSTEM’’ message in the multi-information display.

Vehicle Stability Assist (VSA) System Indicator

This indicator normally comes on for a few seconds when you turn the ignition switch to ON (II).

If it comes on and stays on at any other time or it does not come on when you turn the ignition switch to ON (II), there is a problem with the VSA system. Take your vehicle to a dealer to have it checked. Without VSA, your vehicle still has normal driving ability, but will not have VSA traction and stability enhancement. On the Touring model, you will also see a ‘‘CHECK VSA SYSTEM’’ message in the multi-information display.

For more information, see page

301

Instrument Panel Indicators

VSA Activation Indicator

This indicator has three functions:

1.

2.

3.

It comes on as a reminder that you have turned off the vehicle stability assist (VSA) system.

It flashes when VSA is active (see page

301

).

It comes on along with the VSA system indicator if there is a problem with the VSA system. On the Touring model, you will also see a ‘‘CHECK VSA SYSTEM’’ message in the multi- information display.

This indicator normally comes on for a few seconds when you turn the ignition switch to ON (II). See page 301

for more information.

CONTINUED

65

Information Provided by:more information, see page

303

Lights On Indicator

Your vehicle has Michelin PAX tires. Repair or replacement of PAX tires must be done by a Honda dealer or an authorized Michelin PAX system dealer. For more information, see page

356

or

OnEXandTouringmodels This indicator reminds you that the exterior lights are on. It comes on when the light switch is in either the position. If you turn the

ignition switch to ACCESSORY (I) or LOCK (0) without turning off the light switch, this indicator will remain on. A reminder chime will also sound when you open the driver’s door.

On the Touring model, this indicator also comes on when the light switch is in AUTO and the lights turn on automatically.

Instrument Panel Indicators

Low Tire Pressure Indicator

OnU.S.Touringmodelonly This indicator normally comes on for a few seconds when you turn the ignition switch to ON (II). If it comes on while driving, it means that one or more of your vehicle’s tires are extremely low on pressure. You will also see a ‘‘LOW TIRE PRESSURE’’ message on the multi- information display. The multi- information display will show you which tire has lost the pressure and how much pressure it has lost (see page

303

).

If this happens, pull to the side of the road when it is safe, check which tire has lost pressure on the multi- information display, and determine the cause. If it is because of a flat tire, have the flat tire repaired as soon as possible. If two or more tires are underinflated, call a professional towing service (see page

). For

381

66

Information Provided by:Immobilizer System Indicator

This indicator comes on for a few seconds when you turn the ignition switch to ON (II). It will go off if you have inserted a properly-coded ignition key. If it is not a properly- coded key, the indicator will blink and the engine will not start (see page

129

).

This indicator also blinks several times when you turn the ignition switch from ON (II) to ACCESSORY (I) or LOCK (0).

U.S.

Canada

Power Sliding Door Indicator

OnEXmodelonly This indicator comes on for a few seconds when you turn the ignition switch to ON (II). If it comes on at any other time, there is a problem in the power sliding door system. With this indicator on, move the main switch on the dashboard to the OFF position, and have the system checked by your dealer as soon as possible. You can still open or close each sliding door manually. For more information on the power sliding doors, see page

142

On the Touring model, you will also see a ‘‘CHECK LEFT SLIDING DOOR’’ or ‘‘CHECK RIGHT SLIDING DOOR’’ message in the multi-information display.

Instrument Panel Indicators

Door and Tailgate Open Monitor

The appropriate light comes on in this display if the tailgate or any door is not closed tightly.

All the lights in the monitor come on for a few seconds when you turn the ignition switch to ON (II).

67

Information Provided by:Instrument Panel Indicators

Turn Signal and Hazard Warning Indicators

The left or right turn signal indicator blinks when you signal a lane change or turn. If the indicators do not blink or blink rapidly, it usually means one of the turn signal bulbs is burned out (see page ). Replace the bulb as soon as possible, since other drivers cannot see that you are signaling.

338

Low Fuel Indicator

LOW FUEL INDICATOR

This indicator comes on as a reminder that you must refuel soon.

On the Touring model, you will also see a ‘‘FUEL LOW’’ message in the multi-information display.

When you press the hazard warning button, both turn signal indicators and all turn signals on the outside of the vehicle flash.

68

Information Provided by:High Beam Indicator

This indicator comes on with the high beam headlights. For more information, see page

123

On Canadian models, this indicator comes on with reduced brightness when the daytime running lights (DRL) are on (see page

125

).

Fog Light Indicator Touringmodelonly

This indicator comes on when you turn on the fog lights. See page for information on fog light 123
operation.

‘‘Daytime Running Lights’’ Indicator

Canadianmodelsonly This indicator comes on when you turn the ignition switch to ON (II) with the headlight switch off and the parking brake set. It should go off if you turn on the headlights or release the parking brake. If it comes on at any other time, it means there is a problem with the DRL. There may also be a problem with the high beam headlights. On the Touring model, you will also see a ‘‘CHECK DRL SYSTEM’’ in the multi-information display.

Instrument Panel Indicators

Cruise Main Indicator

This indicator comes on when you turn on the cruise control system by pressing the master button (see page 264

).

Cruise Control Indicator

This indicator comes on when you set the cruise control. See page 264
cruise control.

for information on operating the

Washer Level Indicator

Canadianmodelsonly This indicator comes on when the washer fluid level is low. Add washer fluid when you see this indicator comes on (see page On the Touring model, you will also see a ‘‘WASHER FLUID LOW’’ message in the multi-information display.

333

).

69

Information Provided by:Instrument Panel Indicators

Fuel Economy Indicator

OnEXwithleatherandTouringmodels While the engine is operating in its most economical range, this indicator comes on and stays on. It goes off when your vehicle uses extra fuel.

Maintenance MINDER Indicator OnLXandEXmodels This indicator reminds you that the maintenance main items and sub items will be displayed in the odometer/trip meter display. See page for more information on the maintenance minder.

315

This indicator goes off when your dealer resets it after completing the required maintenance service.

70

System Message Indicator

OnTouringmodel This indicator comes on when there is a system message in the multi- information display. Press the INFO button on the steering wheel to see the message (see page

79

).

Most of the time, this indicator comes on along with other indicators in the instrument panel such as the seat belt reminder indicator, SRS indicator, VSA system indicator, etc.

Information Provided by:LX and EX models

TACHOMETER

SPEEDOMETER

FUEL GAUGE

TEMPERATURE GAUGE

ODOMETER/OUTSIDE TEMPERATURE

TRIP METER

TRIP METER SELECT/RESET KNOB

Touring model

TACHOMETER

SPEEDOMETER

FUEL GAUGE

TEMPERATURE GAUGE

MULTI-INFORMATION DISPLAY

TRIP METER SELECT/ RESET KNOB

Gauges

Temperature Gauge This shows the temperature of the engine’s coolant. During normal operation, the pointer should rise to about the middle of the gauge. In severe driving conditions, the pointer may rise to the upper zone. If it reaches the red (hot) mark, pull safely to the side of the road. For instructions and precautions on checking the engine’s cooling system, see page

369

Fuel Gauge This shows how much fuel you have. It may show slightly more or less than the actual amount. The needle returns to the bottom after you turn off the ignition.

Avoid driving with an extremely low f uel level. Running out of f uel could cause the engine to misf ire, damaging the catalytic converter.

71

Information Provided by:Gauges

Odometer The odometer shows the total distance your vehicle has been driven. It measures miles in U.S. models and kilometers in Canadian models. It is illegal under U.S. federal law and Canadian provincial regulations to disconnect, reset, or alter the odometer with the intent to change the number of miles or kilometers indicated.

72

Trip Meter This meter shows the number of miles (U.S.) or kilometers (Canada) driven since you last reset it.

There are two trip meters: Trip A and Trip B. Switch between these displays and the outside temperature display by pressing the Select/Reset knob repeatedly.

Each trip meter works independently, so you can keep track of two different distances.

To reset a trip meter, display it and then press and hold the Select/Reset knob until the number resets to ‘‘0.0.’’ Both trip meters will reset if the vehicle’s battery goes dead or is disconnected.

Outside Temperature Indicator Ifequipped This indicator displays the outside temperature in Fahrenheit (U.S. models) or Centigrade (Canadian models). To see the outside temperature, press and release the Select/Reset button until the temperature is displayed.

The temperature sensor is in the front bumper. The temperature reading can be affected by heat reflection from the road surface, engine heat, and the exhaust from surrounding traffic. This can cause an incorrect temperature reading when your speed is under 19 mph (30 km/h). When you start your trip, the sensor is not fully acclimatized, therefore it may take several minutes until the proper temperature is displayed.

Information Provided by:In certain weather conditions, temperature readings near freezing (32°F, 0°C) could mean that ice is forming on the road surface.

On the Touring model, the odometer, trip meter, and the outside temperature indicator are displayed in the multi-information display. See page

for more information.

77

Check Fuel Cap Indicator (Odometer/trip meter message) OnLXandEXmodels If your fuel cap is loose or missing, a ‘‘CHECK FUEL CAP’’ message appears as text in the odometer/trip meter display after you start the engine. Turn the engine off and confirm the fuel cap is installed. If it is, loosen the cap, then retighten it at least 3 clicks. When you restart the engine, the message appears again. To clear the message, press and hold the select/reset button until the message is replaced in the odometer/trip meter display.

Gauges

If the system still detects a loose or missing fuel cap, the Malfunction Indicator Lamp (MIL) comes on. Turn the engine off and check or retighten the fuel cap at least 3 clicks. The MIL goes out after 3 days of normal driving once the cap is tightened or replaced. If it does not go out, have your dealer inspect the vehicle. For more information, see page

372

73

Information Provided by:Multi-Information Display

OnTouringmodelonly The multi-information display in the instrument panel displays various information and messages when the ignition switch is in the ON (II) position. Some of the messages help you operate your vehicle more comfortably. Others help to keep you aware of the periodic maintenance your vehicle needs for continued trouble-free driving.

There are four types of messages; normal display messages, engine oil life and maintenance messages, system messages, and PAX system warning messages.

You can also customize some vehicle control settings to your liking with the multi-information display and the two buttons on the steering wheel (see page

89

).

74

Normal Display Messages

When you unlock and open the driver’s door with the key, the display shows ‘‘Welcome DRIVER 1’’ or ‘‘Welcome DRIVER 2’’ depending on which remote transmitter was used last. (The driver’s ‘‘ID’’ is detected by the transmitter.)

If you use the remote transmitter to unlock the driver’s door, the display shows ‘‘Welcome DRIVER 1’’ or ‘‘Welcome DRIVER 2’’ depending on

which remote transmitter you use, and the driver’s seat moves to the position stored in that transmitter.

When you turn the ignition switch to LOCK (0) and remove the key from the ignition switch, the display shows ‘‘Goodbye.’’

Information Provided by:UPPER SEGMENT

INFO BUTTON

LOWER SEGMENT

The multi-information display consists of an upper segment and a lower segment. Each segment can display two lines of messages.

In normal display mode, the upper segment displays trip computer and tire pressures, and the lower segment displays the compass, odometer, trip meter, outside temperature, and engine oil life.

SEL RESET BUTTON

In normal display mode, the upper display is blank when you turn the ignition switch to ON (II). Then each time you press the INFO button, the trip computer changes from ‘‘INST. MPG’’ to ‘‘RANGE’’ to ‘‘ELAPSED TIME’’ to ‘‘AVERAGE SPEED’’ and then to ‘‘AVERAGE FUEL A’’ or ‘‘AVERAGE FUEL B’’ as shown on the next page.

Multi-Information Display

If you press the INFO button when ‘‘AVERAGE SPEED’’ is displayed, the display changes to ‘‘TIRE PRESSURE’’ using both segments. This display is a part of tire pressure monitoring system (TPMS). See for more information. page

303

Pressing the INFO button again brings the display back to the initial display of the trip computer ‘‘INST. MPG.’’

CONTINUED

75

Information Provided by:Multi-Information Display

76

Messages in the trip computer include:

INST. MPG: Your vehicle’s current fuel mileage. RANGE: The estimated distance you can travel on the fuel remaining in the tank. This distance is estimated from the fuel economy you received over the last several miles, so it will vary with changes in speed, traffic, etc. ELAPSED TIME: The time traveled since you last reset the trip computer. AVERAGE SPEED: The average speed you are traveling. AVERAGE FUEL A/AVERAGE FUEL B: Your vehicle’s average fuel economy since you last reset the trip computer.

To reset the values in the trip computer, press the Select/Reset button, and hold it for about 1
second.

Information Provided by:Multi-Information Display

‘‘AVERAGE FUEL A’’ or ‘‘AVERAGE FUEL B’’ will be displayed when average fuel economy is selected in the upper segment depending on which trip meter (TRIP A or TRIP B) is displayed in the lower segment.

77

The initial display in the lower segment is shown above. Each time you press the SEL/RESET button on the steering wheel, the display changes from ‘‘Odometer/Trip Meter’’ to ‘‘Outside Temperature/ Trip Meter’’ to ‘‘Engine Oil Life’’, and then back to the initial display as shown in the next column.

In the lower left corner of the display, a compass indicates which direction your vehicle is pointed.

Trip Meter While a trip meter is displayed, you can change the display between ‘‘TRIP A’’and ‘‘TRIP B’’ by pressing the Select/Reset knob in the instrument panel (see page reset a trip meter, display it, and press and hold the Select/Reset knob until the number reset to ‘‘0.0.’’

). To

72

Information Provided by:Multi-Information Display

Engine Oil Life

Maintenance Messages

ENGINE OIL LIFE

This shows the remaining life of the engine oil. It shows 100% after the engine oil is replaced and the display is reset. The engine oil life is calculated based on engine operating conditions and accumulated engine revolutions.

When the engine oil life reaches 15
percent, the display shows ‘‘SERVICE DUE SOON’’ and the code for the maintenance items to be performed.

When the engine oil life reaches 5
percent, the display shows ‘‘SERVICE DUE NOW’’ along with the same maintenance items.

78

Have your dealer do the indicated maintenance as soon as you see this message, and have them reset the display after completing the service.

If you do not perform the indicated maintenance or do not reset the display, the message changes to ‘‘SERVICE PAST DUE’’ when the engine oil life becomes 0 percent.

These messages appear on the multi- information display each time you turn the ignition switch to ON (II).

For details on engine oil life and maintenance messages, refer to page 317

Also refer to page maintenance safety precautions.

for important

314

Information Provided by:System Messages If there is a problem with your vehicle, for example, the engine oil level is low or a door is not fully closed, the multi-information display will show you the problem. It does this by interrupting the current message with one or more messages. Most of the messages are displayed for about 5 seconds, and then the current message returns. Some messages stay on until the problem is corrected.

Multi-Information Display

Fasten Seat Belt

In addition to the seat belt reminder indicator in the instrument panel, the multi-information display interrupts the current display and shows ‘‘FASTEN SEAT BELT’’ if you do not fasten your seat belt while driving. This message remains displayed if you ignore it and do not wear your seat belt while the vehicle is moving.

CONTINUED

79

SYSTEM MESSAGE INDICATOR

These messages also trigger the appropriate indicator(s) on the instrument panel and cause the system message indicator to come on. The system message indicator does not go off until the problem(s) are corrected.

The following pages describe each system message that can be displayed.

Information Provided by:Multi-Information Display

Door and Tailgate Open

Release Parking Brake

Remove Key

U.S.

Canada

If the tailgate or any door(s) is not closed tightly, the display reminds you to close the tailgate or the door(s) before you start driving. This display continues until you close the door(s) or the tailgate. Pressing the INFO button on the steering wheel momentarily change the display to the normal display, but it will come back after 5 seconds.

If you start driving without releasing the parking brake, the multi- information display interrupts the current display and shows ‘‘RELEASE PARKING BRAKE.’’ This message continues, and a chime sounds, until you release the parking brake, or the vehicle speed slows down to less than 0.5 mph (0.8
km/h).

If you leave the key in the ignition switch in the LOCK (0) or ACCESSORY (I) position and open the driver’s door, you will see ‘‘REMOVE KEY’’ in the display and hear a reminder beeper.

80

Information Provided by:Check Fuel Cap

Brake Fluid Low

U.S

Canada

If the brake fluid level is at or below the MIN mark on the side of the brake fluid reservoir in the engine compartment, you will see ‘‘BRAKE FLUID LOW.’’ If you see this message, have the brake system checked by your dealer (see page 373

).

If the fuel fill cap is missing or not tightened properly, you will see ‘‘CHECK FUEL CAP.’’ Make sure the fuel cap is installed and tightened at least 3 clicks.

Multi-Information Display

The CHECK FUEL CAP message should go off after tightening the fuel cap, turning the ignition switch off and on, then driving over 30 mph (48 km/h) for at least 45 seconds. Due to different driving conditions, it may take a few driving trips to make the message go off.

If a loose or missing fuel cap was not the cause of the CHECK FUEL CAP message coming on, the message will turn off and the Malfunction Indicator Lamp will come on. If this happens, have your vehicle checked by your dealer as soon as possible.

CONTINUED

81

Information Provided by:Multi-Information Display

Fuel Low

Washer Fluid Low

Passenger Side Airbag Off

U.S.

Canada

If the level of the fuel in the tank gets low, you will see ‘‘FUEL LOW’’ in the display, and you must refuel soon. The low fuel indicator in the instrument panel will also come on.

If the fluid level in the windshield washer reservoir gets low, you will see ‘‘WASHER FLUID LOW’’ in the multi-information display.

82

If the passenger’s side airbag has automatically shut off, you will see ‘‘PASSENGER SIDE AIRBAG OFF’’ in the multi-information display. See page

for more information.

33

Information Provided by:Check Tire Pressure OnU.S.Touringmodelonly

Warning: Approaching Object

Multi-Information Display

The following messages indicate various problems in your vehicle’s systems.

If one or more of your vehicle tires are low on pressure, you will see a ‘‘CHECK TIRE PRESSURE’’ message in the display. See page for more information on the tire 303
pressure monitoring system (TPMS).

This message, and the indicator to the left of the message, is a part of the parking sensor system. If you are approaching too close to an object, you will see ‘‘WARNING APPROACHING OBJECT’’ in the display and hear a beeper. See page 271

for more information.

CONTINUED

83

Information Provided by:Multi-Information Display

Check TPMS System OnU.S.Touringmodelonly

Check VSA System

Check Engine Oil Level

If there is a problem with the vehicle stability assist (VSA) system, you will see ‘‘CHECK VSA SYSTEM’’ in the multi-information display. If you see this message, have the VSA system checked by your dealer (see page

301

).

If the engine oil is very low or has lost pressure, you will see ‘‘CHECK ENGINE OIL LEVEL’’ in the multi- information display. You will also see the low oil pressure indicator in the instrument panel flashing or staying on. If you see this message, you should take immediate action since serious engine damage is possible. Follow the procedure on page 371

If there is a problem in the tire pressure monitoring system (TPMS), you will see ‘‘CHECK TPMS SYSTEM’’ in the multi-information display. If you see this message, the TPMS is not monitoring tire pressures. Have the TPMS checked by your dealer as soon as possible (see page

303

).

84

Information Provided by:Check Charging System

Check Emission System

Check Brake System

Multi-Information Display

U.S.

Canada

If you see ‘‘CHECK CHARGING SYSTEM’’ in the multi-information display, it means the battery is not being charged. See page more information.

371

for

If you see ‘‘CHECK EMISSION SYSTEM’’ in the multi-information display, it means one of the engine’s emission systems may have a problem. Have your vehicle checked by a dealer (see page

372

).

If there is a problem with the brake system, you will see ‘‘CHECK BRAKE SYSTEM’’ in the multi- information display. The parking brake and brake system indicator in the instrument panel will also come on. See page information.

for more

373

CONTINUED

85

Information Provided by:Multi-Information Display

Check Transmission

Check ABS System

Check Airbag System

If there is a problem in the anti-lock brake system (ABS), you will see ‘‘CHECK ABS SYSTEM’’ in the multi-information display. If you see this message, have your vehicle checked by a dealer (see page

300

).

If there is a problem with the automatic transmission, you will see ‘‘CHECK TRANSMISSION’’ in the multi-information display. Avoid rapid acceleration, and have the transmission checked by a dealer as soon as possible.

86

If there is a problem with your front airbags, side airbags, passenger’s side airbag automatic cutoff system, automatic seat belt tensioners, or side curtain airbags, you will see ‘‘CHECK AIRBAG SYSTEM’’ in the multi-information display. Take your vehicle to a dealer as soon as possible (see page

32

).

Information Provided by:Check Parking Sensor System

Check Left/Right Sliding Door

Check Power Tailgate

Multi-Information Display

U.S.

Canada

U.S.

Canada

If there is a problem with the parking sensor system, the multi- information display shows a ‘‘CHECK PARKING SENSOR SYSTEM’’ message. See page 271

for more information.

If there is a problem in the power sliding door, the multi-information display shows ‘‘CHECK LEFT SLIDING DOOR’’ or ‘‘CHECK RIGHT SLIDING DOOR.’’ See page 147

for more information.

If there is a problem with the power tailgate, the display shows ‘‘CHECK POWER TAILGATE.’’ See page 139

for more information.

CONTINUED

87

Information Provided by:Multi-Information Display

Check DRL System

PAX Warning Messages

Canadianmodelonly If there is a problem with the Daytime Running Light (DRL) System, you will see ‘‘CHECK DRL SYSTEM’’ in the multi-information display. If you see this message, have your vehicle checked by a dealer.

U.S.Touringmodelonly Your vehicle is equipped with the Michelin PAX system. The PAX system uses the multi-information display to show you one of three messages while you are driving with a flat tire.

For more information, see page

356

88

Information Provided by:Customized Settings You can customize some vehicle control settings for ‘‘DRIVER 1’’ and ‘‘DRIVER 2’’ separately. If ‘‘DRIVER 1’’ or ‘‘DRIVER 2’’ is not displayed, customizing is not possible.

To enter the customizing mode, the vehicle must be stopped and the transmission must be in Park. Press and hold the INFO button on the steering wheel for about 3 seconds while the multi-information display is in its normal message mode.

The first customizing menu is:

CHANGE SETTING DEFAULT ALL

Every time you press the INFO button, the display cycles from ‘‘CHANGE SETTING,’’ ‘‘DEFAULT ALL,’’ ‘‘EXIT,’’ and then back to ‘‘CHANGE SETTING’’ as shown in the next column.

If you want the settings as they were when the vehicle left the factory, select ‘‘DEFAULT ALL,’’ as described on page

90

If you want to change any vehicle control settings, select ‘‘CHANGE SETTING,’’ and follow the instructions on page

92

Multi-Information Display
